Front BackSide
10 5⁄16"
(262 mm)
11 3⁄16"
(284 mm)
31⁄8"
(79 mm)
23⁄4"
(70 mm) 35⁄16"
(84 mm)
Dimensions
Application
Solitaire locks quickly replace any traditional key operated door lock to provide
access with a magnetic stripe card. Each user carries one personalized card
(ID card, keycard or bank card) for access to all rooms they are authorized
to enter. The Solitaire series offers a choice of concepts that fit any size of
facility, from just a few doors to thousands of doors in a large office, factory,
lab, educational campus or public institution.
Features
•Replaces your current door lock
•Battery powered, with no wiring required
•Automatically locks or unlocks on a schedule
• Keeps an audit record in memory each
time access is granted
• Each user needs just one keycard for all
their access needs
•Adapts to any size of facility, from just
a few doors to thousands of doors
•Uses economical magnetic stripe cards
• Off-the-shelf AA batteries last 4 to 5 years or
100,000 openings
• Heavy duty construction and extra-durable finish
• ANSI Grade 1 certification
Tel.: 1-800-849-8324
www.kaba-ilco.com
KAA1001 0305
Construction: Heavy-duty cylindrical or mortise lock; cast front
housing and brass trim plate; cast levers
Card: Operates with magnetic cards (like bank cards)
Operating Conditions: -31°F to 151°F (-35°C to 66°C)
Batteries: 4 x AA alkaline
Lock Operation:
• Audit: Solitaire 850 and 850L last 1000 transactions,
Solitaire 950 last 800 transactions
• Time Zones: 14 programmable zones per door
• Vacations & Holidays: 18 per door
• Passage Mode: Accessible by card, thumbturn or lock
programming
Key Override: Removable core cylinder (accepts major brands)
or conventional key-in-lever cylinder
Certification:
• Cylinder Drive Lock: Conforms to ANSI/BHMA A156.25
• Mortise Lock: ANSI/BHMA 15.13 grade 1
• ADA compliant
• Three-hour U.L./U.L.C. Fire Door rating
Strike: Included
Latch: 1⁄2" (13 mm)
Backset: 23⁄4" (70 mm)
Door Thickness: 13⁄8" (35 mm) to 2 1⁄2" (66 mm)
Installation:
• Cylindrical Drive Lock: ASA 161 door preparation with
additional through bore holes
• Mortise Lock: Standard mortise preparation
Door Handing: Factory set
Standard Finish: 626 Satin Chrome
Optional Finishes: 605 Bright Brass, 625 Bright Chrome, 612
Satin Bronze, 622 Black Painted, and 606 Satin Brass
The Higher Security System Solitaire 850
This system is suitable for any facility that needs higher security, for up to 1,000,000 users and 100,000
doors. The best security you can offer is to encode your own custom cards using Kaba’s proprietary encryp-
tion and a dedicated encoder and database, which you control. The database is Microsoft Access based.
The LearnLok System Solitaire 850L
Ideal for up to 25 users (Maximum 200) and less than 10 doors.
This system requires no computer. The lock "learns" to recognize each user's card when you swipe a "learn"
card through the lock, followed by the user's card.
Model 85150 Vers. L Model 85010 Vers. L • Mortise Lock
• Passage mode
activated
with card
• 1" Deadbolt
•Cylindrical
Drive Lock
• Passage mode
activated
with card
Model 85112 Vers. L
• Mortise Lock
•Passage mode
activated
with card
• No deadbolt
Model 85250 Model 85010 • Mortise Lock
•Passage mode
activated
with card
• 1" Deadbolt
• Auto Lock/Unlock
• Cylindrical
Drive Lock
•Passage mode
activated with
thumbturn or card
•No deadbolt
•Auto Lock/Unlock
Model 85212
• Mortise Lock
• Passage mode
activated with
thumbturn or card
• No deadbolt
• Auto Lock/Unlock
Three Kinds of Security: Choose the software that matches the current needs of your facility, and upgrade anytime:
System Specifications
Model 95250 Model 95010 •Mortise Lock
• Passage mode
activated
with card
• 1" Deadbolt
•Auto Lock/Unlock
• Cylindrical
Drive Lock
•Passage mode
activated with
thumbturn or card
• Auto Lock/Unlock
Model 95212
•Mortise Lock
•Passage mode
activated with
thumbturn or card
• No deadbolt
•Auto Lock/Unlock
The Compatible System Solitaire 950
Ideal for any company or institution that already has an ID badge system using the credit card encoding
standard. This access system supports up to 1,000,000 users and 100,000 doors, and can use your
existing ID cards with a magnetic stripe and import the user database you have on file. The Database is
Microsoft SQL based and is networkable.
