Kangtai Electric 022 90022 (Remote control transmitter) User Manual 98156yingwen

Kangtai Electric Co.,ltd 90022 (Remote control transmitter) 98156yingwen

Contents

user manual 98156+90022-REV1

Wireless Doorbell Manual
Model No.: Receiver： 98156USA,98189USA
Transmitter：90022
Brief Introduction: It's applicable for home, office, factory, hotel and
reception hall, making you not miss any visitor.
Function Detail
B1. Pairing
a. After the batteries have been installed and a sound of DingDong is heard, it
means that the receiver has entered into the pairing mode, which will last for about 30
seconds; then press the button of the transmitter, when a sound of DingDong is
heard, it means that the pairing process has been successfully made.
b. 30 seconds after the batteries have been well installed, Make a simple press the
"L" on the back panel and when a sound of DingDong is heard, it means the doorbell
has entered into the pairing mode.
B2. Melody Selection
Every simple press on the "M" button on the back panel will lead to a melody shift
in turn for the receiver. There are totally 16 melodies for selection.
B3. Remove Pairing Memory
When the doorbell is in the pairing mode, press the button inside the housing of the
transmitter, and when a double "DingDong" is heard, it means the pairing memory has
been successfully deleted.
A1. Battery Installation/Uninstallation
Remove the battery cover and insert 3 pieces of 1.5V AA batteries into the cabinet;
When a sound of DingDong is heard, it means that the battery installation has been
well finished.
Battery Installation/Uninstallation
Techincal Data
Working Frequency: 433.92Mhz;
Power Supply Battery: 3*AA 1.5V DC
Working Range: ≥ 40m in open area;
Working Temperature: 0 ℃~ 35℃ ;
Transportation and Storage Temperature: 0℃~ 50℃
DingDong
DingDong
DingDong
Melody Selection
(Receiver); CR2032 3VDC(Transmitter)
Caution:
This device complies with Part 15 of the FCC Rules / Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
