TwinDVDMobileVideoSystem

PVS2970S

OWNER'SMANUAL

E - 1

SAFETY PRECAUTIONS

The lightning flash with an arrowhead symbol,

within the equilateral triangle, is intended to alert

the user to the presence of uninsulated

"dangerous voltage" within the product's enclosure

that may be of sufficient magnitude to cause an

electric shock.

The exclamation point within the equilateral triangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in this owner manual.

WARNING: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-

SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

Notes on Copyright

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public or rent copyrighted material without

permission.

Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098 and 4,907,093 licensed for limited viewing

uses only.

DVD video discs are copy protected, and any recordings made from these discs will be distorted. This product

incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other

intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright

protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited

viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly

is prohibited.

On Placement

• Do not use the unit in places which are extremely hot, cold, dusty, or humid.

• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a cloth, or by placing

it on carpeting.

FCC Information

This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesirable operation.

On Safety

• When connecting or disconnecting the AC cord, grip the plug and not the cord itself. Pulling the cord may damage

it and create a hazard.

• When you are not going to use the unit for a long period of time, disconnect the AC power cord.

On Condensation

• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the unit.

When there is condensation inside the unit, the unit may not function normally. Let the unit stand for 1 to 2 hours

before turning the power on, or gradually heat the room up and dry the unit before use.

WARNING:

• Should any trouble occur, disconnect the AC power cord and refer servicing to a qualified technician.

This product contains

a low power laser

device.

The symbol for Class

II (Double lnsulation)

CAUTION

INVISIBLE LASER

RADIATION WHEN OPEN

AND INTERLOCKS

DEFEATED.

E - 2

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions - All the safety and operating instructions should be read before the appliance is

operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Water and Moisture - The appliance should not be used near water - for example, near a bathtub,

washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and

the like.

6. Carts and Stands - The appliance should be used only with a cart or stand that is

recommended by the manufacturer.

6A. An appliance and cart combination should be moved with care. Quick stops,

excessive force, and uneven surfaces may cause the appliance and cart combination

to overturn.

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended

by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with

its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar

surface that may block the ventilation openings; or, placed in a built-in installation, such as a book case

or cabinet, that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as radiators, heat registers,

stoves, or other appliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power supply only of the type described in

the operating instructions or as marked on the appliance.

11. Grounding or Polarization - Precautions should be taken so that the grounding or polarization means

of an appliance are not defeated.

12. Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked

on or pinched by items placed upon or against them, paying particular attention to cords at plugs,

convenience receptacles, and the point where they exit from the appliance.

13. Cleaning - The appliance should be cleaned only as recommended by the manufacturer.

14. Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left

unused for a long period of time.

15. Object and Liquid Entry - Care should be taken so that objects do not fall, and liquids are not spilled

into the enclosure through openings.

16. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged; or

B. Objects have fallen, or liquid has been spilled into the appliance; or

C. The appliance has been exposed to rain; or

D. The appliance does not appear to operate normally or exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure damaged.

17. Servicing - The user should not attempt to service the appliance beyond that described in the operating

instructions. All other servicing should be referred to qualified service personnel.

E - 3

TABLE OF CONTENTS

Repeat Playback .................................... 20

Repeating a title/chapter (DVD) ............................ 20

Repeating a single track/whole disc (CD) ........... 20

Repeating a specific section (DVD) ..................... 20

Playing MP3 /Digital Picture Files Disc .. 21

Playing a MP3/Digital Picture files Disc ................. 21

Customizing the Function Settings .... 22-23

LANGUAGE setting .................................................. 22

VIDEO setting .......................................................... 22

AUDIO setting .......................................................... 23

RATING setting ....................................................... 23

Language Code List ............................... 24

Maintenance .......................................... 25

Cleaning Disc .......................................................... 25

Cleaning the Unit ................................................... 25

Important Note ....................................................... 25

Trouble Shooting Guide ....................... 26

Safety Precautions ......................................1

Important Safety Instructions ................. 2

Table of Contents .................................... 3

Disc Formats ............................................. 4

Accessories ............................................... 5

Remote Control ........................................ 5

Control Reference Guide ...................... 6-8

Screen Viewing Angle Adjustment ......... 9

Power Supply ........................................... 9

Using the Car plug adaptor ..................................... 9

Using the AC adaptor ............................................ 9

Connections ....................................... 10-13

Connecting the Monitors ................................ 10-11

Using this Unit with Other Equipment ............ 12-13

Using Headphones/Earphones ............................. 13

Installation Guide .................................... 14

Unit Operation .......................................... 14

Sound System .......................................... 14

Playing a Disc .................................... 15-16

Playing a Disc on DISC A / B ................................... 15

Pausing playback (still mode) ............................... 15

Stopping playback ................................................. 15

To skip to a different track ...................................... 15

Fast Foward/Fast Reverse ..................................... 15

Skip (Forward/Reverse) .......................................... 16

Audio selection ....................................................... 16

Angle selection ....................................................... 16

Subtitle selection .................................................... 16

Special Functions ............................. 17-18

Display function .................................................... 17

GOTO function ....................................................... 17

Locating a specific title ......................................... 17

Locating a specific chapter/track ......................... 18

Locating a specific time ......................................... 18

CD / DVD Programmable Memory ......... 19

DVD programmable memory ................................. 19

CD programmable memory .................................. 19

E - 4

The unit can playback.

Region Management Information

Region Management Information: This unit is designed and manufactured to respond to the Region Management

Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond

to the Region number of this unit, this unit cannot play that disc.

The region number of this unit is 1.

Disc Function or Operation that is Not Available

When the symbol appears on the screen, it indicates that the function or operation attempted is not available

at that time. This occurs because the DVD disc manufacturer determines the specific functions. Certain

functions may not be available on some discs. Be sure to read the documentation provided with the DVD.

Notes on Unauthorized Discs

You may not be able to play back some DVD discs on this unit if they were purchased from outside your

geographic area or made for business purposes.

Title, Chapter and Tracks

• DVDs are divided into “titles” and “chapters”. If the

disc has more than one movie on it, each movie would

be a separate “title”. “Chapters” are sections of titles.

• Audio CDs are divided into “tracks”. A “track” is

usually one song on an Audio CD.

Note :

• Numbers identify each title, chapter, and track on a disc. Most discs have these numbers recorded on them,

but some do not.

Icons Used on DVDs

Sample lcons Language selections for audio

Language selections for subtitles

Screen aspect ratio

Multiple camera angles

Region code indicator

Notes:

• This Unit supports 2-channel (L/R) audio and 5.1ch (Multi-channel) MPEG Audio 1/2 (only when the DIGITAL

AUDIO OUT coaxial jack is used for connection). It does not support 7.1 channel MPEG Audio Version 2.0.

• When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played, but the graphic

images will not be shown.

DISC FORMATS

Audio CDs

[8cm/12cm disc]

DVDs

[8cm/12cm disc]

2

2

2

1. English

2. French

1. English

2. French

LB

E - 5

ACCESSORIES

Please check and identify the supplied accessories.

Use item number indicated in parentheses when ordering replacement parts.

To order accessories contact 1-800-252-6123 or visit (http://www.18002526123.com)

Remote control (Disc A / with battery) ................................................................................. x 1

Remote control (Disc B / with battery) ................................................................................ x 1

AC adaptor .......................................................................................................................... x 1

AC power cord ..................................................................................................................... x 1

12V car plug adaptor ............................................................................................................ x 1

Strap .................................................................................................................................... x 2

Carrying bag ........................................................................................................................ x 1

REMOTE CONTROL

Using the Remote Control

• Point the Remote Control at the REMOTE SENSOR located on the unit.

• When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded

causing unreliable operation.

• The recommended effective distance for remote operation is about 16 feet (5 meters).

Remove the protective plastic tab before operating the Remote Control.

BATTERY REPLACEMENT

When battery becomes weak, the operating distance of the Remote Control will be greatly reduced and you will

need to replace the battery.

NOTE:

• If the Remote Control is not to be used for a long time, remove the battery to avoid corrosion damage caused by

battery leakage.

TO CHANGE REMOTE BATTERY

1. Open the battery door. 2. Insert one CR2025 (3V) size battery.

WARNING: Do not dispose of batteries in a fire, batteries may explode or leak.

E - 6

CONTROL REFERENCE GUIDE

Remote Control for Disc A/B

1) TV MODE button

In stop mode, select whether to output the video

signal. TV shows "AUTO" means output signal

depends on DVD (either NTSC or PAL). TV shows

"PAL" or "NTSC" which means output signal fixed to

PAL or NTSC.

2) STOP button

Stop playing a disc.

PLAY button

Press to start˝/T1```eop plbackng a disc.

E - 7

Unit

CONTROL REFERENCE GUIDE

1) Open button

Open the disc door.

2) VOLUME control

Adjust the volume.

3) Headphone jack

4) AV IN / DVD switches

5) AUDIO / VIDEO IN jacks

6) DC IN 12V jack

7) POWER ON / STANDBY switch

8) DIGITAL OUT jack

9) AUDIO / VIDEO OUT jacks

10) MONITOR 1 & 2 ports (output)

11) MONITOR 3 & 4 ports (output)

12) Disc Door B

Close by pushing the disc door.

13) Remote sensor

Receives the remote control unit signals.

14) Operation Indicator (DISC B)

The indicator will illuminate when the unit is playing

the disc.

ÿ

1

2

3

4

5

678 9 10 9 8

5

4

3

2

1

12

1314

151615171318

11

15)

PREV button

Press

PREV button to go back to previous

chapters/tracks. Press and hold PREV button

to begin fast scan. Four speeds are available.

NEXT button

Press

NEXT button to advance to chapters /

tracks. Press and hold

NEXT button to begin

fast scan. Four speeds are available.

PAUSE button

Press to pause playback of disc.

Each time you press the PAUSE button the picture

advances one frame. Press the PLAY button to

resume playback.

STOP button

Stop playing a disc.

PLAY button

Press to start or resume playback a disc.

16) POWER ON / STANDBY indicator

The indicator will illuminate when the unit is in ON

/ Standby mode.

17) Operation Indicator (DISC A)

The indicator will illuminate when the unit is playing

the disc.

18) Disc Door A

Close by pushing the disc door.

E - 8

Monitor

CONTROL REFERENCE GUIDE

1) MONITOR ON / OFF switch

2) STANDBY indicator

The LED will illuminate when the monitor is in

standby mode.

3) Screen

4) Remote sensor

Receives the remote control signal.

5) Speaker

6) VOLUME control

7) SCREEN switch

WIDE: Wide Screen

NORMAL: Pan screen

8) COLOR control

Adjust for color intensity.

9) BRIGHTNESS control

Adjust the lightness or darkness of the color.

10) Headphone / Earphone jack

11) Built-in EZ CABLE CONNECT TO MAIN UNIT

port (Input)

Installation of Monitors

• Use supplied mounting straps to install the monitors onto the seat back in a car.

2) Tightly wrap the mounting

strap around the headrest.

SAFETY WARNING!

• This unit should never be used by the vehicle's driver or left unsecured in the vehicle while driving.

• If this unit is being used in your vehicle, be sure that it is secured or held safely, and does not obstruct

any safey device, including air bags or seat belts.

• All passengers should wear seat belts when using this unit in a moving vehicle.

• If in doubt, please contact your vehicle manufacturer for further advice.

1) Loop the safety band around

the headrest.

13

2445 6

7891011

Mounting

Strap Elastic

Safety Band

E - 9

SCREEN VIEWING ANGLE ADJUSTMENT

The Monitor is designed to allow users to have a comfortable viewing angle. The

viewing angle can be adjusted +/- 12°.

• Gently push the top or bottom of the screen frame to adjust the viewing angle.

POWER SUPPLY

Cautions:

• Use of an incorrect type AC adaptor will damage the unit.

• Turn off the unit before unplugging the AC adaptor from the unit so as to avoid the unit being damaged.

•To prevent electrical shock, match wide blade of plug to wide slot and fully insert.

• When the unit is not going to be used for long time, disconnect the AC power supply cord from the AC

outlet.

AC adaptor (EA10362)

Rear side of Main unit

Power indicator

AC power cord

A. Using the car plug adaptor

The included 12V car plug adaptor is designed for use with vehicles that have a 12V, negative ground electrical

system.

Cautions:

• Use this unit only with the included 12V car plug

adaptor. Use with other car adaptors could

damage the system.

• The included 12V car plug adaptor is for use with

this unit only. Do not use it with other equipment.

• Do not operate the unit or watch videos while

driving a vehicle.

• Make sure the unit is secured correctly to prevent

it from falling inside the vehicle in the event of an

accident.

• When the inside of the 12V car socket is dirty with

ashes or dust, the plug section may become hot

due to poor contact. Be sure to clean the 12V car

socket before use.

• After use, disconnect the 12V car plug adaptor

from both the unit and 12V car socket.

• Check your local traffic laws for rules governing

the use of video devices in vehicles.

B. Using the AC adaptor

This unit can be powered by connecting the included AC adaptor to support TWO monitors.

Before you buy an AC Adaptor, please note, the only AC adaptor suitable for this unit is DC 12V 3.0A, with plus center

polarity . Please check voltage & current (A) carefully.

1

To DC IN 12V jack

ÿþýüûýúùø

Attention:

When 4 monitors are to be used, please visit our

wedsite www.18002526123.com to buy a suitable

AC adaptor to support 4 monitors.

3

To AC outlet

12V car plug adaptor

Rear side of Main unit

1

2

To the 12V car socket

To DC IN

12V jack

ÿþýüûýúùø

Caution:

• Do not force the screen frame over its maximum viewing angle or

damage to the unit could result.

2

To AC adaptor

E - 10

CONNECTIONS

Connecting the Monitors

Connecting 4 monitors to play the same movie in your car

• Use 12V car plug to connect the main unit.

• Connect the built-in EZ View cable of 4 monitors to the rear side of main unit.

• Use Audio/Video cable to connect from "AV OUT" of DISC B to "AV IN" of DISC A.

• Turn on the main unit, slide the AV IN / DVD switch to "AV IN" on DISC A.

• Then turn on the 4 monitors.

• Play your selected disc on DISC B.

• You can see same movie through 4 monitors in different seats of your car.

Note:

• If you play ONE movie for TWO monitors, play your selected disc on DISC A OR B, then connect the monitors to

MONITOR 1 and 2 for DISC A or MONITOR 3 or 4 for DISC B.

Rear side of Main unit

(Play DVD on DISC A) Rear side of Main unit

(Play DVD on DISC B)

Left side of Main unit (DISCA)

Rear side of Main unit (DISC B)

Rear side of Main unit

12V car plug adaptor

Rear side of Main unit

To the 12V car socket To DC IN

12V jack

Built-in EZ view cable of Monitors

Built-in EZ view cable

of Monitors

ÿ

ÿ

Built-in EZ view cable

of Monitors

ÿ

ÿþýüûýúùø

ÿ

Audio / Video Cable

(White)(Red)(Yellow) (Red)(Yellow) (White)

E - 11

CONNECTIONS

Connecting 4 monitors to play the two different movies in your car

• Use 12V car plug to connect the main unit.

• Connect the the built-in EZ View cable of 4 monitors to the rear side of main unit, then turn on the monitors.

[i.e. DISC A for Monitor 1 and 2, DISC B for Monitor 3 and 4.]

• Turn on the main unit, slide the AV IN / DVD switch to "DVD" on DISC A and B.

• Play the two different discs on DISC A and B.

• You can see the two different movies through 4 monitors in different seats of your car.

Rear side of Main unit

Built-in EZ view cable of Monitors

12V car plug adaptor

Rear side of Main unit

To the 12V car socket

To DC IN

12V jack

How to pack them into the carrying bag

E - 12

CONNECTIONS

Watching a DVD on your TV

1.Turn on the unit, slide the AV IN / DVD

switch to "DVD".

2.Turn on the TV and follow the instructions

provided with it to play the DVD.

Note:

Make sure you use the correct Audio/Video

cable.

B. Connecting the unit to a TV

• This DVD Player can be used with a TV that has A/V inputs. If your TV does not have A/V inputs, you can

purchase an RF modulator (sold separately) to connect the DVD player.

Using this Unit with Other Equipment

Watching Video Equipment

1.Turn on the unit, slide the AV IN /

DVD switch to "AV IN".

2.Turn on the video equipment and

follow the instructions provided

with it to playback.

Note:

If you have a mono VCR, the

volume level from the speakers will

be low.

A. Connecting Game Systems / Video Equipment

• You can connect Game Systems or other Video Equipment for playback through the monitors.

C. Connecting a Stereo Receiver or Amplifier

Analog connection

Rear side of Main unit (DISC A / B)

Rear side of Main unit (DISC A / B)

Left / Right side of Main unit (DISC A / B)

Audio / Video Cable

(Red)

(White)

(Yellow)

(Red)(Yellow) (White)

TV

AUDIO

IN

VIDEO

IN

AUDIO

IN

Audio / Video Cable

Stereo Receiver

or Amplifier

No need to connect

the Yellow video plug

(Red)

(White)

(Red)(Yellow) (White)

(Yellow)

Audio / Video Cable

(Red)(Yellow) (White)

(Red)

(White)

(Yellow)

Game Systems /

Video Equipment

E - 13

Notes:

• Make sure to use the correct Audio/Video

cable, connecting the plugs incorrectly

may cause a weak signal.

• If you have a stereo VCR, make sure you

set it to stereo mode.

• Due to copyright protection, DVD movies

cannot be copied. If you copy a DVD movie

onto a videotape, the resulting copy will

be unclear, with poor sound quality. This

is NOT caused by a defective DVD

system.

CONNECTIONS

Listening to another audio equipment

1.Turn on the Unit.

2.Turn on your audio equipment and follow

the instructions provided with it to select

the AUDIO IN or DIGITAL IN function.

Connecting to a Surround Sound System

Right / Left side of unit for DISC A / B

Using Headphones / Earphones

• Turn down the volume before connecting the Headphones / Earphones. Slowly raise the volume with the

headphones / earphones on until you reach your desired volume.

• When headphones / earphones are connected to the monitors, the speakers will be disabled.

Bottom of Monitor

Headphones / Earphones

(3.5mm diameter plug)

Note:

When headphones / earphones are connected to the main unit, the speakers will be disabled.

Headphones / Earphones

(3.5mm diameter plug)

Rear side of Main unit (DISC A / B)

Audio equipment with

digital audio input jack

DIGITAL IN

COAXIAL

COAXIAL DIGITAL

AUDIO CABLE

Caution:

• Listening to audio at an excessive volume

can permanently damage your hearing.

E - 14

INSTALLATION GUIDE

Dolby Digital (for DVD)

Dolby Digital is a sound system developed by Dolby Laboratories Inc. that gives movie theatre ambience to audio

output when the unit is connected to a Dolby Digital 5.1 channel processor or amplifier.

This unit automatically recognises DVDs that have been recorded with Dolby Digital.

Not all Dolby Digital sources are recorded with 6 channels.

Some sources marked Dolby Digital may be recorded in Dolby Surround, a 2 channel system. Look for this logo on

your unit.

Manufactured under license from Dolby Laboratories.

'Dolby' and the double-D symbol are trademarks of Dolby Laboratories.

SOUND SYSTEM

Turning the Unit On

The system is in the standby condition (STANDBY indicator lights) when the AC power supply cord or Car adapter

is connected.

1. Slide the POWER ON / STANDBY switch (on rear of unit) to the ON position to turn ON the

unit.

• If you select DVD the DVD logo (start-up picture) will appear on screen.

• When the unit is not going to be used for a long time, disconnect the AC power supply

cord or Car adapter from the AC outlet or 12V car socket.

UNIT OPERATION

E - 15

PLAYING A DISC

This owner’s manual explains the basic instructions of this unit. Some DVD discs are produced

in a manner that allows specific or limited operation during playback. Such as, the unit may

not respond to all operating commands. This is not a defect in the unit. Refer to the instruction

notes of discs.

“ ” may appear on the screen during operation. A “ ” means that the desired operation is

not permitted by the unit or disc.

Basic playback

Playing a Disc on DISC A / B

1.Slide the POWER ON/STANDBY switch on the rear side of unit into ON mode.

See CUSTOMIZING THE FUNCTION SETTINGS before proceeding to step 2.

2.Hold the top and slide the OPEN switch to open the disc door A / B.

3.Hold the disc by its sides and carefully fit onto the central support of compartment with the label side facing

forward until you hear a “click”.

4.Close the disc door A / B.

It takes a short while for your unit to load the disc. After loading, for some discs, the unit will automatically start

playback of the disc. (The indicator of DISC A / B on left / right side lights up.)

5.Press the PLAY button.

Pausing playback (still mode)

Press the

II

PAUSE button. To resume normal playback, press the PLAY button.

Each time you press the

II

PAUSE button, the picture advances one frame.

Stopping playback

Press the STOP button at the location where you want to interrupt playback. To resume playback at the position

where the disc was stopped, press the PLAY button.

If you press the STOP button twice, the unit’s memory will be cleared and pressing the PLAY button will reset

the disc to the beginning.

To skip to a different track

• Press the PREV button repeatedly to skip to the start of the current or previous track.

• Press the NEXT button to skip to the next track.

• For audio CD disc, use the number buttons (remote control only) to jump straight to that track number.

DVD CD

Fast Forward / Fast Reverse

1.Press the SEARCH or SEARCH button when a disc is

playing.

•The disc begins fast scan at x2 speed.

•Four speeds are available. Each time SEARCH or

SEARCH button is pressed, the speed of fast scan changes in

the following sequence:

Note:

You also can press and hold / (SKIP) buttons repeatedly to select different fast scan speeds.

2.Press the PLAY button when you reach the desired point to resume playback at normal speed.

E - 16

PLAYING A DISC

SKIP (Forward / Reverse)

While you are playing a disc, press the NEXT button to move to the beginning of the next chapter or track. Press

the PREV button to move to the previous chapter or track and automatically start playing it.

Audio selection

On some discs, the sound is recorded in two or more formats. Follow the directions below to select the type of playback.

1.While a disc is playing, press the AUDIO button to show the current audio format number.

2.Press the AUDIO button repeatedly to select the desired audio format.

Notes:

• If only one audio format is recorded, the number does not change.

• About two seconds later, playback continues in the new audio format.

DVD

DVD CD

2/4 D 6 Ch Eng

Subtitle selection

1.While a DVD is playing, press the SUBTITLE / RETURN button to display the current language setting, as shown

in the example below.

2.Press the SUBTITLE / RETURN button repeatedly to select the desired subtitle language.

Notes :

• If only one language is recorded, the language does not change.

• About two seconds later, playback continues with the new subtitle you selected.

• The number of languages recorded differ depending on the disc.

• If no button is pressed within a few seconds, playback continues without changing the current subtitle.

• This function can only be used for discs on which subtitles have been recorded in multiple languages.

• On some DVDs, subtitles are activated from the main menu of the DVD. Press the MENU button to activate the

main menu.

Angle selection

Some DVDs contain scenes which have been shot from a number of different angles. For these discs, the same

scene can be viewed from each of these different angles.

Notes:

• This function can only be used for discs on which scenes shot from multiple angles have been recorded.

• If only one angle is recorded, “

1/1

” is displayed.

1.While you are playing a DVD with different angles recorded,

press the ANGLE button to view the number of the current

angles available.

2.Press the ANGLE button repeatedly to change the scene to

the next angle in those recorded.

• About two seconds later, playback continues from the new

angle you selected.

• If no button is pressed within 10 seconds, playback continues

without changing the current angle.

Sequence of angle shots

(Example)

1/3 Eng

1/2

DVD

Angle BitRate

1/3

Angle BitRate

2/3

Angle BitRate

3/3

DVD

E - 17

DISPLAY function

Using DISPLAY, you can check and change the current settings of the following items: ANGLE, AUDIO and SUBTITLE.

• While the disc is playing, press the DISPLAY button to display the screen shown below.

Elapsed time: Elapsed time from the beginning of the chapter which is currently playing.

Remaining time: Remaining time of the title which is currently playing.

SPECIAL FUNCTIONS

DVD

GOTO function

This function allows you to skip directly to any part of the disc while a disc is playing. Press or button to highlight

time.

Note:

• After settings, press the DISPLAY button again to return to the normal screen.

Title/Chapter - - - / - - -

Time - - : - - : - -

Locating a specific title

If a DVD disc contains title numbers, you can locate a specific title by directly selecting a title number.

1.In stop mode, press the GOTO button.

2.Press or button to highlight a specific field and press the corresponding number button(s) for the title you

want.

3.Press the ENTER button to confirm. The Unit will start playback about 3 seconds later.

Time - - : - - : - - Title/Chapter / - - -- - -

Elapsed time

01:12:1800:07:18

Remaining time

Audio OffSubtitle2/4 D 6 Ch Eng

Angle BitRate

1/1

9.472Mbps

E - 18

SPECIAL FUNCTIONS

DVD CD

Locating a specific chapter / track

If you know the chapter / track number you want to play, you can locate a specifc chapter / track by directly selecting

a chapter / track number.

1.Press the GOTO button to search your desired chapter / track.

2.Press or button to highlight a chapter / track and press the corresponding number button(s) for the chapter

you want.

3.Press the ENTER button to confirm. The Unit will start playback about 3 seconds later.

Locating a specific time

You can move to a specific location by entering its corresponding time (hours, minutes, seconds).

1.Press the GOTO button.

2.Press or button to highlight time.

3.Press the corresponding number buttons for the setting point you want.

4.Press the ENTER button to confirm. The Unit will start playback about 3 seconds later.

Notes:

• Some discs may not respond to this process.

• Some scenes may not be located as precisely as you specified.

• This method for accessing specific locations is available only within the current title of the DVD disc.

Time - - : - - : - - Title/Chapter - - - / - - -

Time - - : - - : - - Track - - -

DVD

Title/Chapter - - - / - - -

Time - - : - - : - -

CD

Track - - -

Time - - : - - : - -

DVD

CD

E - 19

Programmable memory

The two types of programmed playback provided by this Unit are title programmed playback and chapter

programmed playback.

Title / Chapter programmed playback

1.Press the MEMORY button while the disc is stopped.

2.Enter the title numbers in

- -

. Use or button to move the highlight to chapter and enter the chapter numbers

in

- -

.

3.Use , or button to move to the other field.

4.Repeat steps 2 to 3.

5.Press the PLAY button to start the programmed playback.

CD/DVD PROGRAMMABLE MEMORY

DVD

Title Chapter

Note :

• If you press the STOP button twice, the programmed selections will be cleared.

Programmable memory

Track programmed playback

1.Press the MEMORY button while the disc is stopped.

2.Enter the track numbers in

- - -

.

3.Use , or button to other field.

4.Repeat steps 2 to 3.

5.Press the PLAY button to start the programmed playback.

CD

E - 20

You can play a specific title or chapter repeatedly.

(Title repeat, chapter repeat, A-B repeat)

Repeating a chapter

You can play the same chapter repeatedly.

1.While the disc is playing, press the REPEAT DISC button until the

“

Repeat Chapter

” indicator displays on the screen. The current chapter is

played repeatedly.

Repeating a title

You can play the same title repeatedly.

2.While the disc is playing, press the REPEAT DISC button until the

“

Repeat Title

” indicator displays on the screen. The current title is played

repeatedly.

To resume normal playback

3.While the disc is playing, press the REPEAT DISC button until the

“

Off

” indicator displays on the screen.

REPEAT PLAYBACK

DVD

You can play a single track or a whole disc repeatedly.

Repeating a single track

You can play the same track repeatedly.

1.While the disc is playing, press the REPEAT DISC button until the

“

Repeat Single

” indicator displays on the screen. The current track is played

repeatedly.

Repeating a whole disc

2.While the disc is playing, press the REPEAT DISC button until the

“

Repeat All

” indicator displays on the screen. The whole disc is played

repeatedly.

To resume normal playback

3.Press the REPEAT DISC button until the “

Off

” indicator displays on

the screen.

CD

Repeating a specific section

You can play a specific section repeatedly.

1.While the disc is playing, press the REPEAT A-B button at the beginning

of the section ((

ÿþýüûú

) is displayed) you want to play repeatedly.

2.Press the REPEAT A-B button again at the end of the section ((

ÿþýüûúù

)

is displayed).

3.The Unit will immediately begin replaying your selection.

To resume normal playback

4.While the disc is playing, press the REPEAT A-B button until the “

Off

”

indicator displays on the screen.

Notes:

• A-B repeat can only be used within the same title. If the start and end of the section to be repeated are in different

titles, A-B repeat is cancelled.

• The A-B repeat function does not operate in scenes where different camera angles are recorded.

E - 21

Notes:

• You can press the

II

PAUSE button to interrupt playback, and press the PLAY button to resume playback.

• You can also use GOTO function or use the numbered buttons to enter the number to quickly select any image.

• Press the ANGLE button on the remote control to rotate the picture orientation by 90°.

This unit can play MP3 and Picture files recorded on CD-R and CD-RW discs.

Playing a MP3/Picture file disc

1.Slide the OPEN switch to open the disc door A/B.

2.Hold a MP3 files/Picture file disc by its sides and carefully fit onto the central

support of compartment with the label side facing forward you until you hear a

“click”.

3.Push the door to close.

4.The unit will take a short while to load the disc but will begin automatic playback.

The MP3 files or Picture files will begin to play one by one.

Press the , , or CURSOR button to view and select the files you want

to listen to. Then press ENTER button to confirm and this selected file will be

played.

Playable files:

The ability of this unit to read MP3 discs is dependent on the following:

• The Bit Rate must be within 64 - 256 kbps.

• The total number of files on the disc should not exceed 254.

• The maximum number of directories should not exceed 32.

• The maximum depth level of directories should not exceed 4.

• File names should be named using 7 or fewer letters and/or numbers, and must incorporate the “MP3” file

extension. EXAMPLE: *******.MP3 where each * is a letter or number.

• Use only letters and / or numbers in file names. If you use special characters, the file and/or folder names may not

be displayed correctly on the on-screen display.

• When recording on CD-R discs, use 74-minute (650MB) discs.

• The CD-R or CD-RW discs should be “finalized” in computer by “single session format”.

• See your CD/MP3 creation software for details.

Single

Car

Calender

1/117 00:00:35

(Root)

CD-ROM

2

3

4

5

6

7

8

Folk

Rock

Flower

Map

Modern

1

PLAYING MP3 AND PICTURE FILE DISC

E - 22

LANGUAGE setting

1.Press the SETUP button in stop mode.

2.Use or button to one language, then press the ENTER button. The

screen will change to your selected language wordings immediately.

3.To exit the SETUP MENU and return to the normal screen, press the RETURN

button.

VIDEO setting

1.Press the SETUP button in stop mode.

2.Use or button to select Video, then press the ENTER button.

3.Use or button to select the options (TV Shape, Brightness or Edges) to

be adjusted by press or button, then press the ENTER button. (The

screen will change to your desired setting).

4.Repeats step 2 and 3 above to adjust other options.

5.To exit the FUNCTION SETUP MENU and return to the normal screen, press

the RETURN button.

Pan Scan

• When wide-screen video is played, this mode clips the right and left sides of

the image so that it can be viewed on a conventional screen.

• Some wide-screen DVDs that do not permit Pan Scan mode playback are

automatically played in letterbox mode (black bands top and bottom).

Letter Box

• When wide-screen video is played in this mode on a conventional screen,

black bands appear at the top and bottom of the screen.

Wide Screen

• This is the correct mode for playing wide-screen videos on a wide-screen.

Notes:

• The displayable picture size is preset on the DVD disc. Therefore the playback picture of some DVD discs may not

conform to the picture size you select.

• When you play DVD discs recorded in the 4:3 aspect ratio, the playback picture will always appears in the 4:3

aspect ratio regardless of the TV shape setting.

CUSTOMIZING THE FUNCTION SETTINGS

Language

English

Deutsch

Français

Español

Italiano

Svenska

Português

Video Audio Rating

Wide Screen

Letter Box

Cut off when a wide screen

video image is played.

Pan Scan

Language

TV Shape

Brightness

Edges

Wide Screen

Off

Off

Video Audio Rating

E - 23

CUSTOMIZING THE FUNCTION SETTINGS

AUDIO setting

1.Press the SETUP button in stop mode.

2.Use or button to select Audio, press the ENTER button repeatedly to

select Digital Out type.

3.To exit the FUNCTION SETUP MENU and return to the normal screen, press

the RETURN button.

Raw: Use this setting when the unit is connected to an external Dolby Digital

decoder.

PCM: Use this setting when the unit is connected to an external surround

decoder or stereo.

RATING

DVD discs equipped with a password function and are rated according to their

content. The contents allowed by parental lock level and the way a DVD disc is

controlled may vary from disc to disc. For example, if the disc allowed, you

could lock-out violent scenes unsuitable for children or you could lock out

playback of the disc altogether.

Note:

It takes 3-5 seconds to reset the unit to the factory default.

1.Press the SETUP button in stop mode.

2.Use or button to select Rating, press the ENTER button.

3.Use or button to select Parental lock and then press the ENTER button

repeatedly to set the parental lock level.

4.Use or button to shift and select Password, enter your 4-digit security

code and then press the ENTER button.

If you make a mistake before pressing the ENTER button, enter your 4-

digit security code again.

You cannot play DVD discs rated higher than the level you selected unless

you cancel the parental lock function.

The parental lock levels are equivalent to the following ratings.

Level 1 : Kid Safe Level 5 : PG-R

Level 2 : G Level 6 : R

Level 3 : PG Level 7 : NC-17

Level 4 : PG-13 Level 8 : Adult Indicates Parental lock

is NOT active.

The Parental lock is

active.

If you forget the

password, you can

erase your current

password by pressing

number button 8 on the

remote four times, then

press the ENTER button

to confirm the setting

(PASSWORD: 8 8 8 8).

Language Video Audio Rating

Password

Parental lock

Factory Set

- - - -

8. Adult

No

Language

Digital Out Raw

Video Audio Rating

E - 24

Code

AA

AB

AF

AM

AR

AS

AY

AZ

BA

BE

BG

BH

BI

BN

BO

BR

CA

CO

CS

CY

DA

DE

DZ

EL

EN

EO

ES

ET

EU

FA

FI

FJ

FO

FR

Code

FY

GA

GB

GL

GN

GU

HA

HI

HR

HU

HY

IA

IE

IK

IN

IS

IT

IW

JA

JI

JW

KA

KK

KL

KM

KN

KO

KS

KU

KY

LA

LN

LO

LT

LV

LanguageName

Frisian

Irish

Scots Gaelic

Galician

Guarani

Gujarati

Hausa

Hindi

Croatian

Hungarian

Armenian

Interlingua

Interlingue

Inupiak

Indonesian

Icelandic

Italian

Hebrew

Japanese

Yiddish

Javanese

Georgian

Kazakh

Greenlandic

Cambodian

Kannada

Korean

Kashmiri

Kurdish

Kirghiz

Latin

Lingala

Laothian

Lithuanian

Latvian, Lettish

LanguageName

Malagasy

Maori

Macedonian

Malayalam

Mongolian

Moldavian

Marathi

Malay

Maltese

Burmese

Nauru

Nepali

Dutch

Norwegian

Occitan

(Afan) Oromo

Oriya

Panjabi

Polish

Pashto, Pushto

Portuguese

Quechua

Rhaeto-

Romance

Kirundi

Romanian

Russian

Kinyarwanda

Sanskrit

Sindhi

Sangho

Serbo-

Croatian

Singhalese

Slovak

LanguageName

Slovenian

Samoan

Shona

Somali

Albanian

Serbian

Siswat

Sesotho

Sundanese

Swedish

Swahili

Tamil

Telugu

Tajik

Thai

Tigrinya

Turkmen

Tagalog

Setswana

Tonga

Turish

Tsonga

Tatar

Twi

Ukrainian

Urdu

Uzbek

Vietnamese

Volapük

Wolof

Xhosa

Yoruba

Chinese

Zulu

Code

MG

MI

MK

ML

MN

MO

MR

MS

MT

MY

NA

NE

NL

NO

OC

OM

OR

PA

PL

PS

PT

QU

RM

RN

RO

RU

RW

SA

SD

SG

SH

SI

SK

Code

SL

SM

SN

SO

SQ

SR

SS

ST

SU

SV

SW

TA

TE

TG

TH

TI

TK

TL

TN

TO

TR

TS

TT

TW

UK

UR

UZ

VI

VO

WO

XH

YO

ZH

ZU

LanguageName

Afar

Abkhazian

Afrikaans

Ameharic

Arabic

Assamese

Aymara

Azerbaijani

Bashkir

Byerlorussian

Bulgarian

Bihari

Bislama

Bengali

Bangla

Tibetan

Breton

Catalan

Corsican

Czech

Welsh

Danish

German

Bhutani

Greek

English

Esperanto

Spanish

Estonian

Basque

Persian

Finnish

Fiji

Faroese

French

LAGNUAGE CODE LIST FOR DISC LANGUAGE

E - 25

Cleaning Disc

A defective or soiled disc inserted into the unit can cause sound to drop out during playback.

Handle the disc by holding its inner and outer edges.

• Do NOT touch the surface of the unlabeled side of the disc.

• Do NOT stick paper or tape on the surface.

• Do NOT expose the disc to direct sunlight or excessive heat.

• Clean the disc before playback. Wipe the disc from the center outward with a

cleaning cloth.

• NEVER use solvents such as benzine or alcohol to clean the disc.

• Do NOT use irregular shape discs (example : heart shaped, octagonal, etc.). They may cause malfunctions.

Cleaning the unit

• Be sure to turn the unit off and disconnect the AC adapter before maintaining the unit.

• Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has been

dipped in a weak soap-and-water solution and wrung out thoroughly, then wipe with a dry cloth.

• Never use alcohol, benzine, thinner, cleaning fluid or other chemicals. Do NOT use compressed air to remove

dust.

Important Note

Before transporting the unit, take out the disc from the disc compartment.

MAINTENANCE

E - 26

SYMPTOM CAUSE (AND REMEDY)

• The region number of the disc doesn't match the region number of this unit.

• Clean the disc.

• The disc is scratched.

The picture is not

clear.

No picture.

• Make sure that you've select DVD mode.

• The system is in pause mode. Press the PLAY button to return to normal play mode.

• Fast forward or fast reverse is performed. Press the PLAY button to return to normal play

mode.

• Make sure that AUDIO / VIDEO output and AV IN input connections are correct.

• The DTS DVD disc cannot be decoded to have speaker output.

• This unit is too hot, shut off the unit for 30 minutes to cool down.

The remote does

not function.

• Check that the AC cord and AC adpater or the Car plug adapter are connected.

• You did not turn on the unit.

No power.

DVD

No sound or only

a very low-level

sound is heard.

•The plugs and jacks are dirty. Wipe them with a cloth slightly moistened with alcohol.

• Clean the disc.

• There is no disc inside ("No Disc" appears on the screen).

• Insert the disc correctly with the playback side facing forward.

• Clean the disc.

• A non-NTSC disc has been inserted. The unit and disc region number are incompatible.

• Condensation may have formed inside the unit due to a sudden change in temperature. Wait

about an hour for it to clear and try again.

The disc does not

play.

Severe hum or

noise is heard.

• Remove any obstacles between the remote and the unit.

• Use the remote near the unit.

• Point the remote at the remote sensor on the unit.

• Replace the battery in the remote with new one.

TROUBLE SHOOTING GUIDE

NOTICE: Kawasaki is trademark licensed by Kawasaki Motors Corp., U.S.A. However, this product

is neither manufactured nor distributed by Kawasaki Motors Corp., USA.

Consumer inquiries should be directed to Alco Electronics at 1-800-252-6123.
