Keeson Technology RF358B Remote Control User Manual
Keeson Technology Corporation Limited Remote Control Users Manual
Users Manual
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 1 of 7
Made by: Jarek Checked by: Confirmed by:
1 / 7
Function Instructions of JLDK.33.03.14
1. Product description
Massage mode 3
LED for massage mode
Massage mode 2
Massage mode 1
Foot massage intensity adjusting
Head massage intensity adjusting
Head actuator adjustment
Foot actuator adjustment
Massage mode all on/off
Zero G
Memory III
Memory I
UBB
Memory II
Flat
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 2 of 7
Made by: Jarek Checked by: Confirmed by:
2 / 7
2. Function description
1.1. LED flashes when power on
Power supply by control box, PAIRINGLED of control box turns off after flashes for 4 times , and
POWER LED turns on.
1.2. Paring code
Process of paring code:
Double click RESET button on control box，pairing LED turns on，The control box enters the mode
of code paring;
Press and hold the code paring button under battery cover, the backlight of paring LED flashes,
and the backlight of remote flashes, the remote enters into mode of code paring;
The backlight of paring LED stops flashing and the paring LED of control box turns off, it indicates
that the code paring is successful;
If fails, repeat all the steps above;
1.3. Head actuator moves out
Press and hold the head up button, head actuator moves out, stop when released;
1.4. Head actuator moves in
Press and hold the head down button, head actuator moves in, stop when released;
1.5. Foot actuator moves out
Press and hold foot up button, foot actuator moves out, stop when released;
1.6. Foot actuator moves in
Press and hold foot down button, head actuator moves in, stop when released;
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 3 of 7
Made by: Jarek Checked by: Confirmed by:
3 / 7
1.7. Underbed lighting
Click underbed lighting button, turn on (or turn off) the undered lighting, it switches its status
once when click the button every time;
1.8. FLAT function
Click FLAT button, head and foot actuators move to the lowest position(when the actuators are
free, you can stop the massage motor, turn off the massage motor LED), running can be stopped
by clicking any button;
1.9. ZERO G position
Click ZERO G button, head and foot actuators move to the memory position which is preset,
running can be stopped by clicking any button;
1.10. ANTISNORE position
Click ANTISNORE button, head and foot actuator actuators move to the memory position
which is preset, running can be stopped by clicking any button;
1.11. LOUNGE position
Click LOUNGE button, head and foot actuators move to the memory position which is
preset, running can be stopped by clicking any button;
1.12. TV position
Click TV button, head and foot actuators move the memory position which is preset, running
can be stopped by clicking any button;
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 4 of 7
Made by: Jarek Checked by: Confirmed by:
4 / 7
1.13. Customized position button（ANTISNORE ，LOUNGE，TV）
The custom setting processes are as follows:
1. Click FLAT button, flat the actuator;
2. Operate the head up or head down or foot up or foot down button, adjust the
head actuator and foot actuator to an expected position;
3. Press and hold the button that needs customize position, hold for 5s, the LED
on the top of the remote cycle flashes;
4. Release the button, LED stops flashing, it indicates that the customization is
finished.
The default position setting can be restored to the default setting. Press and
hold the ZERO G + FLAT button for about 5 seconds. The LED on the top of the
remote cycle flashes, when the LED stops flashing, it indicates that the setting
to the default position is finished.
1.14. Description of massage mode 1
Every time when click “MODE 1“ button, the LED1 of remote turns on, the
intensity of head and foot massage motors enhances by one level,there are
three massage intensities totally. When in the third intensity, click “MODE
1“ button again, the intensity level switches to 0, the mode cycles;
1.15. Description of massage mode 2
Every time when click“MODE 2“ button, LED2 of the remote turns on,, the
intensity of head and foot massage motors enhances by one level,there are
three massage intensities totally. When in the third intensity, click “MODE
2“ button again, the intensity level switches to 0, the mode cycles;
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 5 of 7
Made by: Jarek Checked by: Confirmed by:
5 / 7
1.16. Description of massage mode 3
Every time when click“MODE 3“ button, LED3 of the remote turns on,, the
intensity of head and foot massage motors enhances by one level, there are
three massage intensities totally. When in the third intensity, click “MODE
3“ button again, the intensity level switches to 0, the mode cycles;
1.17. Head massage adjustment function
Every time when click “HEAD +“ button, the intensity of head massage
motor enhances by one level, there are three massage intensities totally. When
in the third intensity, click “ HEAD +“ button again, the intensity level switches
to 0, the mode cycles;
Every time when click “HEAD -“ button, the intensity of head massage motor
weakenes by one level, there are three massage intensities totally. When in the
0 intensity, click “ HEAD -“ button again, the intensity level switches to the third
level, the mode cycles;
1.18. Foot massage adjustment function
Every time when click “FOOT +“ button, the intensity of head massage
motor enhances by one level, there are three massage intensities totally. When
in the third intensity, click “ FOOT +“ button again, the intensity level switches
to 0, the mode cycles;
Every time when click “FOOT -“ button, the intensity of head massage motor
weakenes by one level, there are three massage intensities totally. When in the
0 intensity, click “ FOOT -“ button again, the intensity level switches to the third
level, the mode cycles;
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 6 of 7
Made by: Jarek Checked by: Confirmed by:
6 / 7
1.19. Massage all on/off test
Click massage all on/off button, if it is in a state that there is already a
massage motor on, then the operation will close massage directly; if it is in a
state that no massage motor is on, then the operation will start the head and
foot massage simultaneously(general mode, the first intensity)
Note: The massage mode and LED instructions are as follows:
LED turns on, enters into massage mode 1
LED turns on, enters into massage mode 2
LED turns on, enters into massage mode 3
Note: The default massage time is 10min;
1.20. Description of remote control current and backlight
After power on, observe the work current of remote(<40mA);
After the key operation, place still for 5s, the backlight of remote turns off and
the remote enters into sleep mode. Observe the sleep current of remote
control (< 10uA).
If the remote control enters into sleep mode, the remote can be wakened up
by pressing any button or shaking; Continues to wake it up for 6 times and do
not press any button, then you can only wake up the remote control by key
operation.
Note: When the actuator is in flat postion, and you press the memory
position button, the motor can move to the theoretical angle or
theoretical stroke, the error range will no more than 3 ° or 5mm.
Issuing Department：Bedding
Division
Date：
2016-11-28
Function Test
Instructions
Author：
Jarek
Model：RF358B
Function Test Instructions of JLDK.33.03.14
Edition：
1.0
Page 7 of 7
Made by: Jarek Checked by: Confirmed by:
7 / 7
FCC warnning:
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
ForIC
This device complies with Innovation,Science and Economic Development
Canada licence-exempt RSS standard (s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference,including interference that
may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Innovation,Science and
Economic Development Canada applicables aux appareils radio exempts de
licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
