Kenmore Medium 40 Gallon Electric Water Heater
42-31242
• Factory-installed temperature and pressure relief valve
• Single 3800 Watt heating element
• Cobalt Blue Ultra Coat Glass-Lined tank with single anode rod
for tank protection
Effective 01/24/11
00211
Due to Sears policy of continuous improve ment on its products, Sears
reserves the right to change materials and specifications without notice.
Before installing, consult installation instructions packed with product
for current dimensional and installation data.
SELECTION KENMORE 42-31242
Tank Capacity 40 Gallons
Number of Elements per Unit 1
Upper Element Type N / A
Lower Element Type Copper
Anode 1
Dip Tube PEX
Tank Material Glass-Lined Steel
Insulation Material Foam
Insulation R Value 16
Insulation Depth (Inches) 2
Recovery at 90 Degree Rise 17.3 G.P.H. @ 3,800W
First Hour Rating 49
Voltage 240 Volts
Kilowatt Hrs. Per Year 4,773
Wattage at 240V 3,800 Watts
Maximum Fuse Required 20 Amps
Minimum Wire Size 12 Gauge
Wattage at 240V N / A
Maximum Fuse Required N / A
Minimum Wire Size N / A
Est. Yearly Operating Cost 508
Shipping Weight (Approx. Lbs.) 103
DIMENSIONS (INCHES)
Maximum Height 44
Height 44
Width 20.50
Depth 20.50
Diameter 20.50
WARRANTY
1-Year Limited Warranty –
Entire Appliance Labor
3-Years Limited Warranty Tank & Parts
If used for other than private family purposes, warranty applies for only 2 years.
