page 1 of 2
Effective 07/21/08
12308
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specifications without
notice. Consult installation instructions packed with the product for
final dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
22-99613.PDF
All ranges are equipped with an
Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Model 22-99613
Overall Stainless
Console Stainless / Glass
Knobs Graphite
Door Stainless
Handles Stainless
Sides Graphite
Surface Black
Flecks Graphite
Kenmore Elite 40-Inch Self-Clean Radiant Range
22-99613 – Stainless
• True convection cooking with third element in main oven
• 3.7 cu. ft. self-clean main oven
• 1.7 cu. ft. standard-clean auxiliary oven
• Three heavy duty oven racks in main oven, plus one standard auxiliary oven rack
• Ceramic glass top easily wipes clean
• One dual 12”/9” @ 2,700/1,700W, one dual 9”/6” @ 2,500/1,000W, one 6” @ 1,200W, plus
two 7” @ 1,800W radiant elements with 800W bridge
• Three hot surface indicator lights
• Electronic oven controls with auto convection conversion, auto oven shutoff,
sabbath mode, delay cooking and cleaning, and oven control lockout
• Extra large storage drawer
40-inch self-clean radiant range | 22-99613
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specifications without
notice. Consult installation instructions packed with the product for
final dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
Selection
Stainless 22-99613
Oven Features
Oven Capacity (cu. ft.) 3.7 (Aux. 1.7)
Variable Time Self-Cleaning Flexible Clean 2–4 Hrs.
Electronic Oven Controls •
Control Lockout Oven
Auto Convection Conversion •
Slow Cook •
Add-1-Minute Timer •
Cook & Hold Warm Oven •
Delay Start Cook & Clean
Automatic Oven Shutoff •
Sabbath Mode* •
True Convection with Third Element •
Variable Broiling System Advanced 400°–550°
Total Adjustable Oven Racks 3 Heavy-Duty (Aux. 1)
Searing Grill & Roasting Rack •
Broiler Pan and Grill •
Oven Lights 2, Auto / Manual
Removable Stainless Door •
Window X-Large (Main)
Deluxe Reach-Through Handle •
Oven Interior WxHxD (In.) Main 225/8x15 3/4x17 3/4
Oven Interior WxHxD (In.) Aux. 9 9/16 x 16 x 19 1/2
Cooktop Features
Element Type Radiant
12-in. / 9-in. Dual (Watts) 1@ 2,700 / 1,700
9-in. / 6-in. Dual (Watts) 1 @ 2,500 / 1,000
7-in. w/800W Bridge (Watts) 1 @ 1,800 / 2,600
7-in. (Watts) 1@ 1,800
6-in. (Watts) 1 @ 1,200
Cooktop Surface Ceramic Glass
Cooktop On Indicator Lights 4
Hot Surface Indicator Lights 3
General Features
Drawer X-Large Storage
Power Rating (kW) @ 240V / 208V 15.4 / 11.6
Bake / Broil @ 240V (Watts)
3,000 / 2,700
(Aux. 1,500 / 1,500)
Bake / Broil @ 208V (Watts)
2,253 / 2,065
(Aux. 1,127 / 1,127)
Breaker / Copper Wire Size (240V) 40 / 8
Shipping Weight (Approx. Lbs.) 283
Warranty
1-Year Limited Warranty –
Entire Appliance Parts & Labor
2-5 Year Limited Warranty –
Glass Cooktop, Cooktop Elements Parts
If used for other than private family purposes, warranty applies for
only 90 days.
Aux. = Auxiliary
*Sabbath Mode overrides auto oven shutoff
12308
22-49624, 22-49626
22-49614, 22-49616
Range Cords for Electric Ranges
Order Wire Length
22-49614 3 4 ft.
22-49616 3 6 ft.
22-49624* 4 4 ft.
22-49626* 4 6 ft.
*Complies with 1/1/96 NEC code
revision for new construction and
remodeling
page 2 of 2
40-inch self-clean radiant range | 22-99613
Effective 07/21/08
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specifications without
notice. Consult installation instructions packed with the product for
final dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
22-99613.PDF
All ranges are equipped with an
Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specifications without
notice. Consult installation instructions packed with the product for
final dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
