Use & Care Guide
Manual de Uso y Cuidado
Models/Modelos: 721.86012, 86013, 86019
Microwave Hood Combination
Combinación Microondas Campana
P/No.: MFL57601504
Sears Brands Management Corporation
Homan Estates, IL 60179 U.S.A.
www.kenmore.com
www.sears.com
English / Español
Kenmore Elite®
![](asset-2.png)
2
Table Of Contents Microwave Hood
Combination Warranty
Warranty .....................................................................2
Protection Agreements ................................................3
Safety .........................................................................4
Overview .....................................................................7
How Your Microwave Hood Combination Works ..........7
Radio Interference ...............................................................7
Testing Your Microwave Oven ...........................................7
Testing Your Dinnerware Or Cookware ...........................8
Operating Safety Precautions ..........................................8
Electrical Connection ..........................................................8
Microwave Oven Features ................................................9
Control Panel Features ..............................................10-11
How To Use .............................................................. 12
Audible Signals .................................................................. 12
Clock .................................................................................... 12
Interrupting Cooking ......................................................... 12
Control Lock ........................................................................ 12
Kitchen Timer ...................................................................... 12
Vent ...................................................................................... 13
Cooktop Light ..................................................................... 13
Light Timer .......................................................................... 13
Add 30 Sec. ....................................................................... 14
Timed Cooking ................................................................... 14
Two-Stage Cooking .......................................................... 14
Microwave Power Levels ................................................. 15
Turntable On/O ............................................................. 16
Option.................................................................................. 16
Favorite ............................................................................... 16
Melt/Soften ........................................................................ 17
Auto Defrost ................................................................18–21
Sensor Operating Instructions ......................................... 22
Cook Sensor Guide ........................................................... 22
Popcorn Sensor ................................................................. 22
Cook Sensor/Reheat Sensor .......................................... 22
Cook Sensor Table/Reheat Sensor Table .................... 23
Auto Cook/Auto Cook Table .......................................... 24
Warm & Hold .................................................................... 25
Tips For Convection Cooking ........................................... 25
Convection .......................................................................... 26
Convection Baking Guidelines .................................27–28
Meat Roasting Guidelines For Convection Cooking ... 29
Tips For Combination Cooking ........................................ 30
Combination Roast ............................................................ 30
Speed Cook/Speed Cook Chart .................................... 31
Combination Roast Cooking Guide ............................... 32
Combination Bake Cooking Guide ................................ 33
Heating/Reheating Guide ............................................... 34
Fresh Vegetable Guide .................................................... 35
Care And Cleaning ...................................................36
Replacing The Cooktop And Oven Lights ..................... 37
Caring For The Filters ....................................................... 38
Cooking Tips ........................................................39–43
Questions And Answers ...........................................44
Troubleshooting ...................................................45–46
Service ......................................................... Back Cover
One-Year Limited Warranty
When installed, operated, and maintained according to
all instructions supplied with the product, if this appliance
fails due to a defect in material or workmanship within
one year from the date of purchase, call
1-800-4-MY-HOME
®
to arrange for free repair.
Five-Year Limited Warranty on the Magnetron
For ve years from the date of purchase, if the
magnetron in this microwave oven fails due to a defect
in material or workmanship, Sears will replace the
magnetron. Safety regulations require the magnetron to
be installed by Sears. After the rst year, the customer
assumes any labor costs associated with magnetron
replacement.
If this appliance is used for other than private family
purposes, this warranty applies for only 90 days from the
date of purchase.
This warranty covers only defects in material and
workmanship. Sears will NOT pay for:
1. Expendable items that can wear out from normal use,
including but not limited to lters, belts, light bulbs,
and bags.
2. A service technician to instruct the user in correct
product installation, operation, or maintenance.
3. A service technician to clean or maintain this product.
4. Damage to or failure of this product if it is not
installed, operated, or maintained according to all
instructions supplied with the product.
5. Damage to or failure of this product resulting from
accident, abuse, misuse, or use for other than its
intended purpose.
6. Damage to or failure of this product caused by the
use of detergents, cleaners, chemicals, or utensils other
than those recommended in all instructions supplied
with the product.
7. Damage to or failure of parts or systems resulting
from unauthorized modications made to this product.
Disclaimer of Implied Warranties; Limitation of
Remedies
Customer’s sole and exclusive remedy under this
limited warranty shall be product repair as provided
herein. Implied warranties, including warranties of
merchantability or tness for a particular purpose,
are limited to one year or the shortest period allowed
by law. Sears shall not be liable for incidental or
consequential damages. Some states and provinces
do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on the duration of
implied warranties of merchantability or tness, so these
exclusions or limitations may not apply to you.
This warranty applies only while this appliance is used in
the United States and Canada.
This warranty gives you specic legal rights, and you
may also have other rights which vary from state to state.
Sears, Roebuck and Co., Homan Estates, IL 60179
Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8
![](asset-3.png)
3
PROTECTION AGREEMENTS
Master Protection Agreements
Congratulations on making a smart purchase. Your new Kenmore
®
product is designed and manufactured
for years of dependable operation. But like all products, it may require preventive maintenance or
repair from time to time. That’s when having a Master Protection Agreement can save you money and
aggravation.
The Master Protection Agreement also helps extend the life of your new product. Here’s what the
Agreement* includes:
Parts and labor needed to help keep products operating properly under normal use, not just defects.
Our coverage goes well beyond the product warranty. No deductibles, no functional failure excluded
from coverage – real protection.
Expert service by a force of more than 10,000 authorized Sears service technicians, which means
someone you can trust will be working on your product.
Unlimited service calls and nationwide service, as often as you want us, whenever you want us.
“No-lemon” guarantee – replacement of your covered product if four or more product failures occur
within twelve months.
Product replacement if your covered product can’t be xed.
Annual Preventive Maintenance Check at your request – no extra charge.
Fast help by phone – we call it Rapid Resolution – phone support from a Sears representative on all
products. Think of us as a “talking owner’s manual.”
Power surge protection against electrical damage due to power uctuations.
$250 Food Loss Protection annually for any food spoilage that is the result of mechanical failure of
any covered refrigerator or freezer.
Rental reimbursement if repair of your covered product takes longer than promised.
10% discount o the regular price of any non-covered repair service and related installed parts.
Once you purchase the Agreement, a simple phone call is all that it takes for you to schedule service. You
can call anytime day or night, or schedule a service appointment online.
The Master Protection Agreement is a risk-free purchase. If you cancel for any reason during the product
warranty period, we will provide a full refund or a prorated refund anytime after the product warranty
period expires. Purchase your Master Protection Agreement today!
Some limitations and exclusions apply.
For prices and additional information in the U.S.A., call 1-800-827-6655.
* Coverage in Canada varies on some items. For full details, call Sears Canada at 1-800-361-6665.
Sears Installation Service
For Sears professional installation of home appliances, garage door openers, water heaters, and other
major home items, in the U.S.A. or Canada call 1-800-4-MY-HOME
®
.
•
•
•
•
•
•
•
•
•
•
•
![](asset-4.png)
4
Product Record
WARNING:
Microwave Oven Safety
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including
the following:
SAVE THESE INSTRUCTIONS
To reduce the risk of
burns, electric shock, re, injury to persons, or
exposure to excessive microwave energy:
Read all instructions before using the
microwave oven.
Read and follow the specic
“PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY” found in this section.
The microwave oven must be grounded.
Connect only to a properly grounded
outlet. See “GROUNDING INSTRUCTIONS”
found at the end of this section.
Install or locate the microwave oven only in
accordance with the provided installation
instructions.
•
•
•
•
DANGER
WARNING
Some products such as whole eggs in
the shell and sealed containers, such as
closed jars, can explode and should not
be heated in the microwave oven.
Use the microwave oven only for its
intended use as described in this
manual.
Do not use corrosive chemicals or
vapors in the microwave oven. This type
of oven is specically designed to heat,
cook, or dry food. It is not designed for
industrial or laboratory use.
As with any appliance, close supervision
is necessary when used by children.
Do not operate the microwave oven if
it has a damaged cord or plug, if it is
not working properly, or if it has been
damaged or dropped.
•
•
•
•
•
In the space at right, record the date of purchase, model,
and serial number of your product. You will nd the
model and serial number printed on an identication
plate located inside the oven door. Have these items
of information available whenever you contact Sears
concerning your product.
Model No.
Date of Purchase
Serial No.
Save these instructions and your sales receipt for future
reference.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your microwave oven.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and theword
“DANGER” or “WARNING.” These words mean:
You will be killed or seriously injured
if you do not follow instructions.
You can be killed or seriously injured
if you do not follow these instructions.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell
you what can happen if the instructions are not followed.
![](asset-5.png)
5
The microwave oven should be serviced only by
qualied service personnel. Call an authorized
service company for examination, repair, or
adjustment.
See door surface cleaning instructions in the
“Care and Cleaning” section.
To reduce the risk of re in the oven cavity:
– Do not overcook food. Carefully attend to the
microwave oven when paper, plastic, or other
combustible materials are placed inside the
oven to facilitate cooking.
– Remove wire twist-ties from paper or plastic
bags before placing bags in oven.
– If materials inside the oven ignite, keep the oven
door closed, turn the oven o, and disconnect
the power cord, or shut o power at the fuse
or circuit breaker panel.
– Do not use the oven cavity for storage purposes.
Do not leave paper products, cooking utensils,
or food in the oven cavity when not in use.
This Microwave Oven is suitable for use above
both gas and electric cooking equipment.
This Microwave Oven is intended to be used
above ranges with a maximum width of
36 inches (91 cm).
Clean Ventilating Hoods frequently - grease
should not be allowed to accumulate on the
hood or lter.
When aming foods under the hood, turn the
fan on.
Use care when cleaning the vent-hood lter.
Corrosive cleaning agents, such as lye-based
oven cleaners, may damage the lter.
Oversized foods or oversized metal utensils
should not be inserted in the microwave oven as
they may start a re or create risk of electric
shock.
•
•
•
•
•
•
•
•
•
Do not clean with metal scouring pads. Pieces
can break o the pad and touch electrical
parts causing a risk of electric shock.
Do not store anything directly on top of the
microwave oven when the microwave oven is in
operation.
Do not cover or block any openings on the
microwave oven.
Do not store this microwave oven outdoors.
Do not use the microwave oven near water
- for example, near a kitchen sink, in a wet
basement, near a swimming pool, or similar
location.
Do not immerse the cord or plug in water.
Keep the cord away from heated surfaces.
Do not let the cord hang over the edge of a
table or counter.
Do not mount the oven over a sink.
Do not cover the racks or any other part of the
oven with metal foil. Doing so will cause the
oven to overheat.
Liquids such as water, coee, or tea can be
overheated beyond the boiling point without
appearing to be boiling, due to surface tension
of the liquid. Visible bubbling or boiling when
the container is removed from the microwave
oven is not always present. This could result in
very hot liquids suddenly boiling over when
a spoon or other utensil is inserted into the
liquid. To reduce the risk of injury to persons:
1) Do not overheat the liquid.
2) Stir the liquid before and halfway through
heating it.
3) Do not use straight-sided containers with
narrow necks.
4) After heating, allow the container to stand in
the microwave oven for a short time before
removing the container.
5) Use extreme caution when inserting a spoon
or other utensil into the container.
•
•
•
•
•
•
•
•
•
•
•
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
MICROWAVE OVEN SAFETY
![](asset-6.png)
6
WARNING:
(a) Do not attempt to operate this oven with
the door open. Doing so can result in harmful
exposure to microwave energy. It is important not
to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven
front face and the door, or allow soil or cleanser
residue to accumulate on sealing surfaces.
For all cord-connected appliances:
The microwave oven must be grounded.
In the event of an electrical short circuit,
grounding reduces the risk of electric shock
by providing an escape wire for the electric
current. The microwave oven is equipped
with a cord having a grounding wire with a
grounding plug. The plug must be plugged
into an outlet that is properly installed and
grounded.
(c) Do not operate the oven if it is damaged. It is
particularly important that the oven door closes
properly and that there is no damage to the:
(1) Door (bent)
(2) Hinges and latches (broken or loosened)
(3) Door seals and sealing surfaces
(d) The oven should not be adjusted or repaired
by anyone except for a properly qualied service
technician.
Improper grounding can
result in a risk of electric shock. Consult a
qualied electrician or service technician if you
do not understand the grounding instructions or if
doubt exists whether the appliance is properly
grounded. Do not use an extension cord. If the
power supply cord is too short, have a qualied
electrician or service technician install an outlet
near the microwave oven.
For a permanently connected appliance:
This appliance has a short power supply cord
to reduce the risk of anyone tripping over or
becoming entangled in the cord. The microwave
oven must be connected to a grounded, metallic,
permanent wiring system, or an equipment
grounding conductor should be run with the
circuit conductors and connected to the
equipment grounding terminal or lead on the
microwave oven.
•
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
GROUNDING INSTRUCTIONS
ELECTRICAL REQUIREMENTS
Observe all governing codes and ordinances.
A 120-Volt, 60-Hz, AC-only, 20-amp fused
electrical supply is required. A time delay fuse is
recommended. It is recommended that a separate
circuit, serving only this appliance, be provided.
Electrical Shock Hazard
Plug into a grounded 3-prong
outlet. Do not remove ground
prong. Do not use an adapter.
Do not use an extension
cord.Failure to follow these
instructions can result in
electrical shock, re, or death.
SAVE THESE INSTRUCTIONS
DANGER
Ensure proper
ground exists
before use
MICROWAVE OVEN SAFETY
![](asset-7.png)
7
Overview
This section discusses the concepts behind microwave cooking. It also discusses the basic information you
need to know to operate your microwave oven. Please read this information before you use your oven.
HOW YOUR MICROWAVE HOOD COMBINATION WORKS
Microwave energy is not hot. It causes food to
make its own heat, and it is this heat that cooks the
food. Microwaves are like TV waves, radio waves,
or light waves. You cannot see them, but you can
see what they do.
A magnetron in the microwave oven produces
microwaves. The microwaves move into the
oven where they contact food as it turns on the
turntable.
The glass turntable of your microwave oven lets
microwaves pass through. Then they bounce o a
metal oor, back through the glass turntable, and
are absorbed by the food.
Microwaves pass through most glass, paper, and
plastics without heating them so food absorbs the
energy. Microwaves bounce o metal containers
so food does not absorb the energy.
Sensor Cooking
The Microwave System features Sensor Cooking
functions. A humidity sensor in the oven cavity
detects moisture and humidity emitted from food
as it heats. The sensor adjusts cooking times to
various types and amounts of food. Sensor cooking
takes the guess work out of microwave cooking.
For the best cooking results
• Always cook food for the shortest cooking time
recommended. Check to see how the food is
cooking.
• Stir, turn over, or rearrange the food being
cooked about halfway through the cooking time
for all recipes. This will help make sure the food
is evenly cooked.
• If you do not have a cover for a dish, use wax
paper, or microwave-approved paper towels or
plastic wrap. Remember to turn back a corner of
the plastic wrap to vent steam during cooking
• Always remove the cooking rack from the oven
when the rack is not in use.
TESTING YOUR MICROWAVE OVEN
To test the oven, put approximately 1 cup of cold
water in a glass container in the oven. Close the
door.
Cook at 100% power for 1 minute. When the time
is up, the water should be heated.
Magnetron
Oven cavity
Glass tray
Metal oor
RADIO INTERFERENCE
Using your microwave oven may cause interference to your radio, TV, or similar equipment. When there is
interference, you can reduce it or remove it by:
Cleaning the door and sealing surfaces of the oven.
Adjusting the receiving antenna of the radio or television.
Moving the receiver away from the microwave oven.
Plugging the microwave oven into a dierent outlet so that the microwave oven and receiver are on
dierent branch circuits.
•
•
•
•
![](asset-8.png)
8
OVERVIEW
TESTING YOUR DINNERWARE OR COOKWARE
Test dinnerware or cookware before using. To
test a dish for safe use, put it into the oven with
a cup of water beside it. Cook at 100% cook
power for one minute.
If the dish gets hot, do not use it. Some dishes
(melamine, some ceramic dinnerware, etc.) absorb
microwave energy, becoming too hot to handle
and slowing cooking time. Cooking in metal
containers not designed for microwave use could
damage the oven, as could containers with hidden
metal (twist-ties, foil lining, staples, metallic glaze
or trim).
OPERATING SAFETY PRECAUTIONS
Never lean on the door or allow a child to
swing on it when the door is open.
Use hot pads. Microwave energy does not heat
containers, but the heat from the food can make
the container hot.
Do not use newspaper or other printed paper in
the oven.
Do not dry owers, fruit, herbs, wood, paper,
gourds, or clothes in the oven.
Do not start a microwave oven when it is empty.
Product life may be shortened. If you practice
programming the oven, put a container of
water in the oven. It is normal for the oven door
to look wavy after the oven has been running
for a while.
Do not try to melt paran wax in the oven.
Paran wax will not melt in a microwave oven
because it allows microwaves to pass through it.
Do not operate the microwave oven unless the
glass turntable is securely in place and can
move freely. The turntable can move in either
direction. Make sure the turntable is correct-
side up in the oven. Handle your turntable with
care when removing it from the oven to avoid
possibly breaking it. If your turntable cracks or
breaks, contact your dealer for a replacement.
When you use a browning dish, the browning
dish bottom must be at least 3 ⁄16 inch above
the turntable. Follow the directions supplied with
the browning dish.
Never cook or reheat a whole egg inside
the shell. Steam buildup in whole eggs may
•
•
•
•
•
•
•
•
•
cause them to burst, and possibly damage the
oven. Slice hard-boiled eggs before heating.
In rare cases, poached eggs have been known
to explode. Cover poached eggs and allow a
standing time of one minute before cutting into
them.
For best results, stir any liquid several times
during heating or reheating. Liquids heated in
certain containers (especially containers shaped
like cylinders) may become overheated. The
liquid may splash out with a loud noise during
or after heating or when adding ingredients
(coee granules, tea bags, etc.). This can harm
the oven.
Microwaves may not reach the center of a
roast. The heat spreads to the center, from the
outside, cooked areas just as in regular oven
cooking. This is one of the reasons for letting
some foods (for example, roasts or baked
potatoes) stand for a while after cooking, or for
stirring some foods during the cooking time.
Do not deep fry in the oven. Microwavable
utensils are not suitable and it is dicult to
maintain appropriate deep-frying temperatures.
Do not overcook potatoes. At the end of the
recommended cooking time, potatoes should be
slightly rm because they will continue cooking
during standing time. After microwaving, let
potatoes stand for 5 minutes. They will nish
cooking while standing.
•
•
•
•
ELECTRICAL CONNECTION
If your electric power line or outlet voltage is less
than 110 volts, cooking times may be longer. Have
a qualied electrician check your electrical system
![](asset-9.png)
9
MICROWAVE OVEN FEATURES
Your microwave oven is designed to make your
cooking experience as enjoyable and productive
as possible. To get you up and running quickly, the
following is a list of the oven’s basic features:
A. Metal Shielded Window. The shield prevents
microwaves from escaping. It is designed as a
screen to allow you to view food as it cooks.
B. Model and Serial Number Plate
C. Charcoal Filter (behind Vent Grille)
D. Cooking Guide Label
E. Vent Grille
F. Glass tray. The glass tray moves food as it cooks
for more even cooking. It must be in the oven
during operation for best cooking results.
G. Cooktop Light
H. Grease Filter. See “Caring for the Filters”
section.
I. Control Panel. Touch the pads on this panel to
perform all functions.
The turntable rotates in both directions to help food
cook more evenly. Do not operate the microwave
oven without the glass tray in place.
To Install:
1. Place the support on the oven cavity bottom.
2. Place the glass tray on the support.
Fit the raised, hollowed groove on the bottom of
the glass tray between the rollers of the hub. The
rollers on the support should t inside the ridge
on the bottom of the glass tray.
1.
Convection Rack
2. Metal Tray/Drip Pan
3. Turntable
4. Rotate Ring
5. Shaft
OVERVIEW
F G H ID
A B C E
![](asset-a.png)
10
OVERVIEW
CONTROL PANEL FEATURES
Your microwave oven control panel lets you select the desired cooking function quickly and easily. If Micro,
Conv, Combi pad is not selected, it automatically defaults to micro. All you have to do is touch the necessary
Command Pad. The following is a list of all the Command and Number Pads located on the control panel.
For more information on these features, see the “How to Use” section.
1
24
7
11
8
14
24
17
18
3
5
6
9
10
12
13
15
16
21
22
19
20
23
25
26
27
100°F 250°F 275°F
300°F 325°F 350°F
375°F 400°F 425°F
450°F
![](asset-b.png)
11
1. Display. The Display includes a clock and
indicators to tell you time of day, cooking time
settings and cooking functions selected.
2. Sensor Cook. Touch this pad to cook baked
potato, frozen vegetable, fresh vegetable,
canned vegetable, frozen entree and rice. The
oven’s sensor will tell the oven how long to cook
depending on the amount of humidity coming
from the food.
3. Popcorn. Touch this pad when popping popcorn
in your microwave oven. The oven’s sensor will
tell the oven how long to cook depending on the
amount of humidity it detects from the popcorn.
4. Sensor Reheat. Touch this pad to reheat
casserole, dinner plate, pizza slice and soup/
sauce. The oven’s sensor will tell the oven how
long to cook depending on the amount of
humidity coming from the food.
5. Auto Defrost. Touch this pad to select food type
and defrost food by weight.
6. Auto Cook. Touch this pad to cook Bacon, Fresh
Roll & Mun, Frozen Roll & Mun, Beverage,
Chicken Pieces, Hot Cereal.
7. Soften/Melt.
Soften. Touch this pad to soften Butter, Ice
Cream, Cream Cheese or Frozen Juice.
Melt. Touch this pad to melt Butter or Margarine,
Chocolate or Cheese.
8. Speed Cook. Touch this pad when setting weight
combination cooking.
9. Micro. Touch this pad when setting Microwave
cooking.
10. Convection. Touch this pad when setting
Convection cooking.
11. Combo. Touch this pad when setting combination
cooking or preheat.
12. Number. Touch number pads to enter cooking
time, power level, quantities, weights, or cooking
temperature.
13. Power Level. Touch this pad to select a cooking
power level.
14. Add 30 Sec. Touch this pad to set and start
quickly at 100% power level.
15. Favorites. Touch this pad to recall a cooking
instruction previously programmed into memory.
16. Turntable On/O. Touch this pad to turn o the
turntable. OFF will appear in the display.
NOTE: This option is not available in cook sensor
and defrost modes.
17. Options. Touch this pad to change the oven’s
default settings for sound, clock, display speed
and defrost weight.
18. Warm & Hold. Touch this pad to keep hot,
cooked foods safely warm in your oven for up to
90 minutes.
19. Clock. Touch this pad to enter the time of day.
20. Kitchen Timer. Touch this pad to set the kitchen
timer.
21. Control Lock. Touch and hold this pad for three
seconds to lock the control panel.
22. Light Timer. Touch this pad to set the light timer.
23. Start. Touch this pad to start a function or enter
all entries. If you open the door after oven
begins to cook, touch START again.
24. Stop. Touch this pad to stop the oven or to clear
all entries.
25. Vent On/O. Touch this pad to turn the fan on/o.
26. Vent 5 Speed. Touch this pad to choose one of
ve fan speeds.
27. Light On/O. Touch this pad to turn on the
cooktop/countertop light.
OVERVIEW
![](asset-c.png)
12
How To Use
enter time in min
and sec
3:00 touch start
Your microwave oven can be used as a timer.
You can set up to 99 minutes, 99 seconds.
Example: To set 3 minutes.
Touch: Display Shows:
KITCHEN TIMER
Time counting down.
1.
2.
3. 3:00 timer
This section gives you instructions for operating each
function. Please read these instructions carefully.
Use this safety feature to lock the control panel
when you are cleaning the oven, or to ensure that
children cannot use the oven unsupervised.
To set CONTROL LOCK:
Touch: Display Shows:
CONTROL LOCK
Touch and hold until
LOCKED appears
in the display.
(approximately 3
seconds)
To cancel CONTROL LOCK:
Touch: Display Shows:
Time of day.
Time of day.
1.
1.
2.
Audible signals are available to guide you when
setting and using your oven:
A programming tone will sound each time
you touch a pad.
Seven tones signal the end of a Kitchen Timer
countdown.
Four tones signal the end of a cooking cycle.
•
•
•
AUDIBLE SIGNALS
You can stop the oven during a cycle by opening
the door. The oven stops heating and the fan
stops, but the light stays on. To restart cooking,
close the door and Touch START.
If you do not want to continue cooking, open
the door and touch STOP.
INTERRUPTING COOKING
Example: To set the clock for 10:30(AM).
Touch: Display Shows:
When your microwave oven is rst plugged in or
after a power failure, the Display will show “PLEASE
SET TIME OF DAY”. If a time of day is not set, “ : ”
will show on the Display until you touch “Clock”.
CLOCK
1.
2.
3.
NOTES:
If you enter in an incorrect time and touch
“Clock”, you cannot set time of day. Enter the
correct time.
If you touch STOP while setting the clock, the
Display will show the last time of day set or “:”
if no time of day has been set.
•
•
10:30 touch start
enter time of day
10:30
am touch 1
pm touch 2
4.
am 10:30
touch start
5.
am 10:30
6.
:
Touch and hold until
LOCKED disappears
in the display
(approximately three
seconds).
![](asset-d.png)
13
The bottom of the control panel controls the 5-
speed exhaust fan.
Example: To set Level 4.
Touch: Display Shows:
VENT
This shows the last
level until you select
the fan speed level.
Touch this pad until
LEVEL 4 appears in
the display.
Turn o fan when desired
1.
2.
NOTE: If the temperature from the range or
cooktop below the oven gets too hot, the exhaust
fan in the vent hood will automatically turn on at
the 4-Speed setting to protect the oven. It may
stay on up to an hour to cool the oven. When this
occurs, the Exhaust Fan pad will not turn the fan
o. You cannot turn the exhaust fan o during
microwave cooking.
LIGHT TIMER
1.
2.
You can set the LIGHT to automatically turn on
and o at specied times. The light comes on at
the same time every day until reset.
Example: Turn on 2:00 AM, turn o 7:00 AM
Touch: Display Shows:
To cancel the LIGHT TIMER when oven is On or
O.
Touch: Display Shows:
3.
4.
6.
5.
enter light on time
or touch clear to
reset light timer
2:00 touch start
am touch 1
pm touch 2
am 2:00 touch start
1.
2.
enter light on time
or touch clear to
reset light timer
reset light timer
enter light off time
touch start
7.
8.
9.
am touch 1
pm touch 2
touch start
set light timer
A pad on the bottom of the control panel
controls the cooktop light.
Example: To set the Lamp for HIGH.
Touch: Display Shows:
COOKTOP LIGHT
1.
level 4
light on
light off
2.
HOW TO USE
![](asset-e.png)
14
TIMED COOKING
1.
2.
5.
3.
4.
This feature lets you program a specic cook time
and power. For best results, there are 10 power
level settings in addition to HIGH (100%) power.
Refer to the “Microwave Power Levels Table” on
page 15 for more information.
NOTE: If you do not select a power level, the
oven will automatically cook at HIGH (100%)
power.
Example: To cook for 5 minutes, 30 seconds at
80% power.
Touch: Display Shows:
enter cooking time
5:30 touch start
or power level
5:30 power 100
enter power
level 0 to 10
5:30 power 80
touch start
Time counting
down and
COOK.
power 80
For best results, some recipes call for dierent
power levels during a cook cycle. You can
program your oven for 2 power level stages
during the cook cycle.
Example: To set a 2-stage cook cycle.
Touch: Display Shows:
TWO-STAGE COOKING
1.
2.
5.
3.
4.
6.
to set a 7 minute
cook time for second
stage.
to set a 3 minute
cook time for rst
stage.
7.
9.
enter cooking time
enter cooking time
3:00 touch start
or power level
7:00 touch start
or power level
3:00 power 100
enter power
level 0 to 10
7:00 power 100
enter power
level 0 to 10
3:00 power 80
touch start
8.
to set a 50% cook
power for the second
stage.
to set an 80% cook
power for the rst
stage.
7:00 power 50
touch start
When the rst stage is over, you will hear
two short tones as the oven begins the
second cook stage.
10.
Time counting down
and COOK.
1st stage power 80
2nd stage power 50
ADD 30 SEC
1.
2.
A time-saving pad, this simplied control lets
you quickly set and start microwave cooking at
100% power without the need to touch START.
Example: To cook for 1 minutes.
Touch: Display Shows:
NOTE: Each time you touch 30 SEC., it will add
30 sec. up to 99 min, 59 sec.
Twice Time counting down
and COOK.
power 100
Time of day
NOTE: You may set the second stage to 0 power to
establish a period of standing time within the oven.
HOW TO USE
![](asset-f.png)
15
For best results, some recipes call for dierent cook
powers. The lower the cook power, the slower the
cooking. Each number from 10 to 0 stands for a
dierent percentage of full cook power.
The following chart gives the percentage of cook
power each number pad stands for, and the cook
power name usually used.
It also tells you when to use each cook power. Follow
recipe or food package instructions if available.
NOTE: Refer to a reliable cookbook for cooking
times based on the 950 Watt cook power of your
microwave oven.
MICROWAVE POWER LEVELS
COOK POWER LEVEL WHEN TO USE IT
100% of full power
9 = 90% of full power
8 = 80% of full power
7 = 70% of full power
6 = 60% of full power
5 = 50% of full power
4 = 40% of full power
3 = 30% of full power
2 = 20% of full power
1 = 10% of full power
0 = 0% of full power
High
Medium-High
Medium
Medium-Low,
Defrost
Low
None
Quick heating many convenience foods and foods with high
water content, such as soups and beverages.
Cooking tender cuts of meat, ground meat.
Heating cream soups
Heating rice, pasta, or casseroles
Cooking and heating foods that need a Cook Power lower than
high (for example, whole sh and meat loaf) or when food is
cooking too fast
Reheating a single serving of food
Cooking requiring special care, such as cheese and egg dishes,
pudding, and custards
Finishing cooking casseroles
Cooking ham, whole poultry, and pot roasts
Simmering stews
Melting chocolate
Heating pastries
Manually defrosting foods, such as bread, sh, meats, poultry,
and precooked foods
Softening butter, cheese, and ice cream
Keeping food warm
Taking chill out of fruit
Standing time in oven
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
HOW TO USE
![](asset-10.png)
16
TURNTABLE ON/OFF
1.
2.
For best cooking results, leave the turntable on. It
can be turned o for large dishes.
Touch: Display Shows:
NOTE:
This option is not available in cook sensor and
defrost modes.
Sometimes the turntable can become hot to
touch. Be careful touching the turntable during
and after cooking.
Do not run the oven empty.
•
•
•
Press TURNTABLE
ON/OFF to turn the
turntable on or o.
on t/table
off t/table
OPTION
1.
2.
You can change the default values for beep
sound, clock, display speed and defrost weight.
See following chart for more information.
Example: To change defrost weight mode
(from Lbs. to Kg).
Touch: Display Shows:
3.
sound on/off touch 1
clock on/off touch 2
scroll speed touch 3
lbs/kg touch 4
lbs touch 1
kg touch 2
kg
1
2
1
2
1
2
3
1
2
Sound ON
Sound OFF
Clock ON
Clock OFF
Slow speed
Normal speed
Fast speed
Lbs.
Kg.
1
2
3
4
Beep ON/ OFF control
Clock display control
Display
Defrost weight mode
selected
FAVORITE
1.
2.
FAVORITE RECIPE lets you recall one cooking
instruction previously placed in memory and
begin cooking quickly.
Example: To cook for 2 minutes.
Touch: Display Shows:
Example: To recall the custom recipe.
Touch: Display Shows:
When the cook time is over, you will hear four
beeps and COOK END will display.
3.
1:00 power 100
touch start or
manual key
1.
2:00 power 100
touch start or
manual key
enter cooking time
2:00 touch start
or power level
4. Time counting down.
power 100
2. Time counting down
and cook.
power 100
No. Function No. Result
HOW TO USE
![](asset-11.png)
17
MELT
1.
2.
The oven uses low power to melt foods (butter or
margarine, chocolate, or processed cheese food).
See the following table.
Example for 8 oz. Chocolate:
Touch: Display Shows:
3.
Time of day
select menu 1 to 4
chocolate
touch 1 to 2
4.
5. Time counting down.
chocolate
8 OZ
touch start
MELT TABLE
1, 2 or
3 sticks
8 or 16
oz.
4 or 8
oz.
Unwrap and place
in microwavable
container. No need to
cover butter. Stir at
the end of cooking to
complete melting.
Use processed cheese
food only. Cut into
cubes. Place in a single
layer in microwavable
container. Stir at the
end of cooking to
complete melting.
Chocolate chips or
squares of baking
chocolate may be used.
Unwrap squares and
place in microwavable
container. Stir at
the end of cycle to
complete melting.
Butter
CODE
CATEGORY
DIRECTION
AMOUNT
1
3Chocolate
Cheese
2
SOFTEN
1.
2.
The oven uses low power to soften foods (butter,
ice cream, cream cheese, and frozen juice). See
the following table.
Example for quart of ice cream:
Touch: Display Shows:
3.
Time of day
select menu 1 to 4
ice cream
touch 1 to 3
4. quart touch start
5. Time counting down.
ice cream
SOFTEN TABLE
1, 2 or
3 sticks
3 or 8
oz.
Pint,
Quart,
Half
gallon
Unwrap and place in
microwavable container.
Butter will be at room
temperature and ready
for use in recipe.
Unwrap and place in
microwavable Container.
Cream cheese will be at
room temperature and
ready for use in recipe.
Place container in oven.
Ice cream will be soft
enough to make scooping
easier.
Butter
CODE
CATEGORY
DIRECTION
AMOUNT
1
3Ice cream
Cream
cheese
2
HOW TO USE
![](asset-12.png)
18
WEIGHT CONVERSION TABLE
You are probably used to food weights as being in
pounds and ounces that are fractions of a pound (for
example, 4 ounces equals 1/4 pound). However, in
order to enter food weight in Auto Defrost, you must
specify pounds and tenths of a pound. If the weight
on the food package is in fractions of a pound, you
can use the following table to convert the weight to
decimals.
OPERATING TIPS
For best results, remove sh, shellsh, meat, and
poultry from its original closed paper or plastic
package (wrapper). Otherwise, the wrap will
hold steam and juice close to the foods, which
can cause the outer surface of the foods to cook.
For best results, shape your ground meat into
the form of a doughnut before freezing. When
defrosting, scrape o thawed meat when the
beep sounds and continue defrosting.
Place foods in a shallow container or on a
microwave roasting rack to catch drippings.
For more defrost help, please read “Defrosting
Tips” following the Auto Defrost Table.
This table shows you food type selections and the
weights you can set for each type. For best results,
loosen or remove covering on food.
•
•
•
•
Example: To defrost 1.2 lbs of ground beef.
Touch: Display Shows:
1.
2.
3. and
4. Time counting
down.
defrost
to enter the weight
AUTO DEFROST
Three defrost sequences are preset in the oven.
The auto defrost feature provides you with the
best defrosting method for frozen foods. The Auto
Defrost Table will show you which defrost sequence
is recommended for the food you are defrosting.
For added convenience, the Auto Defrost includes
a built-in beep mechanism that reminds you to
check, turn over, separate, or rearrange to get best
defrost results. Three dierent defrost settings are
provided.
1 MEAT
2 POULTRY
3 FISH
4 BREAD
5 RAPID - only 1 lb.
* You can set Auto Defrost from 0.1 to 6.0 pounds
in each setting.
NOTE:
When you touch the START pad, the display
changes to defrost time count down. The oven will
beep during the DEFROST cycle. At this time, open
the door and turn, separate, or rearrange the food.
Remove any portions that have thawed.
Return frozen portions to the oven and touch START
to resume the defrost cycle.
meat touch 1
poultry touch 2
fish touch 3
bread touch 4
rapid touch 5
meat
enter weight
1.2 lbs
touch start
OUNCES
1.6
3.2
4.8
6.4
8.0
9.6
11.2
12.8
14.4
16.0
DECIMAL WEIGHT
.10
.20
.30
.40
.50 One-Half Pound
.60
.70
.80
.90
1.00 One Pound
Equivalent Weight
FOOD
Meat
Poultry
Fish
Bread
Rapid
TOUCH
Auto Defrost
1
2
3
4
5
WEIGHTS YOU CAN SET
(tenths of a pound)
.1 to 6.0 (45g to 2722g)
.1 to 6.0 (45g to 2722g)
.1 to 6.0 (45g to 2722g)
.1 to 1.0 (45g to 454g)
only 1 lb.
HOW TO USE
![](asset-13.png)
19
AUTO DEFROST TABLE
NOTE: Meat of irregular shape and large, fatty cuts of meat should have the narrow or fatty areas shielded
with foil at the beginning of the defrost sequence.
Meat settings
FOOD
BEEF
Ground Beef,
Bulk
Ground Beef,
Patties
Round Steak
Tenderloin
Steak
Stew Beef
Pot Roast,
Chuck Roast
Rib Roast
Rolled Rump
Roast
LAMB
Cubes for
Stew
Chops
(1 inch thick)
PORK
Chops
(1/2 inch thick)
Hot Dogs
Spareribs
Country-style
Ribs
Sausage,
Links
Sausage,
Bulk
Loin Roast,
Boneless
SETTING
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
MEAT
AT BEEP
Remove thawed portions with fork.
Turn over. Return remainder to oven.
Separate and rearrange.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Remove thawed portions with fork.
Separate remainder.
Return remainder to oven.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Turn over. Cover warm areas with
aluminum foil.
Remove thawed portions with fork.
Return remainder to oven.
Separate and rearrange.
Separate and rearrange.
Separate and rearrange.
Turn over. Cover warm areas with
aluminum foil.
Separate and rearrange.
Remove thawed portions with fork.
Turn over. Return remainder to oven.
Turn over. Cover warm areas with
aluminum foil.
SPECIAL INSTRUCTIONS
Do not defrost less than 1/4 lb.
Freeze in ball shape.
Do not defrost less than 2 oz. patties.
Depress center when freezing.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
Place in a microwave safe dish.
HOW TO USE
![](asset-14.png)
20
AUTO DEFROST TABLE (CONT.)
Poultry setting
Fish setting
FOOD AT BEEP
SETTING
SPECIAL INSTRUCTIONS
CHICKEN
Whole
(up to 6 lbs)
Cut-up
CORNISH
HENS
Whole
TURKEY
Breast
(up to 6 lbs)
POULTRY
POULTRY
POULTRY
Turn over (nish defrosting
breast-side down). Cover warm
areas with aluminum foil.
Separate pieces and rearrange.
Turn over. Cover warm areas
with aluminum foil.
Turn over. Cover warm areas
with aluminum foil.
Turn over. Cover warm areas
with aluminum foil.
Place chicken breast-side up on a
microwavable roast rack. Finish defrosting
by immersing in cold water. Remove giblets
when chicken is partially defrosted.
Place on a microwavable roasting rack.
Finish defrosting by immersing in cold water.
Place on a microwavable roasting rack.
Finish defrosting by immersing in cold water.
Place on a microwavable roasting rack.
Finish defrosting by immersing in cold water.
FOOD AT BEEP
SETTING
SPECIAL INSTRUCTIONS
FISH
Fillets
Steaks
Whole
SHELLFISH
Crabmeat
Lobster tails
Shrimp
Scallops
FISH
FISH
FISH
FISH
FISH
FISH
FISH
Turn over. Separate llets when
partially thawed if possible.
Separate and rearrange.
Turn over.
Break apart. Turn over.
Turn over and rearrange.
Separate and rearrange.
Separate and rearrange.
Place in a microwavable baking dish.
Carefully separate llets under cold water.
Place in a microwavable baking dish.
Run cold water over to nish defrosting.
Place in a microwavable baking dish. Cover
head and tail with foil; do not let foil touch
sides of microwave . Finish defrosting by
immersing in cold water.
Place in a microwavable baking dish.
Place in a microwavable baking dish.
Place in a microwavable baking dish.
Place in a microwavable baking dish.
HOW TO USE
![](asset-15.png)
21
Bread setting
FOOD AT BEEP
SETTING
SPECIAL INSTRUCTIONS
Bagel
Dinner Roll
Mun
Hamburger
Hot Dog
Bun
Slices of
Bread
Loaf of
Bread
BREAD Turn over and rearrange. Place on 3 sheets of paper towel.
DEFROSTING TIPS
When using Auto Defrost, the weight to be
entered is the net weight in pounds and tenths
of pounds (the weight of the food minus the
container).
Before starting, make sure you have removed
any of the metal twist-ties which often come with
frozen food bags, and replace them with strings
or elastic bands.
Open containers such as cartons before they are
placed in the oven.
Always slit or pierce plastic pouches or
packaging.
If food is foil wrapped, remove foil and place
food in a suitable container.
Slit the skins, if any, of frozen food such as
sausage.
Bend plastic pouches of food to ensure even
defrosting.
Always underestimate defrosting time. If
defrosted food is still icy in the center, return it to
the microwave oven for more defrosting.
•
•
•
•
•
•
•
•
The length of defrosting time varies according to
how solidly the food is frozen.
The shape of the package aects how quickly
food will defrost. Shallow packages will defrost
more quickly than a deep block.
As food begins to defrost, separate the pieces.
Separated pieces defrost more easily.
Use small pieces of aluminum foil to shield
parts of food such as chicken wings, leg tips, sh
tails, or areas that start to get warm. Make sure
the foil does not touch the sides, top, or bottom of
the oven. The foil can damage the oven lining.
For better results, let food stand after defrosting.
( For more information on standing time, see the
“Microwave Cooking Tips” section.)
Turn over food during defrosting or standing
time. Break apart and remove food as required.
•
•
•
•
•
•
HOW TO USE
![](asset-16.png)
22
Sensor Cook allows you to cook most of your
favorite foods without selecting cooking times
and power levels. The display will indicate
Sensing during the initial sensing period.
The oven automatically determines required
cooking time for each food item. When the
internal sensor detects a certain amount of
humidity coming from the food, it will tell the
oven how much longer to heat. The display
will show the remaining heating time. For best
results for cooking by Sensor, follow these
recommendations.
1. Food cooked with the sensor system should
be at normal storage temperature.
2. Glass Tray (TURNTABLE) and outside of
container should be dry to assure best
cooking results.
3. Foods should always be covered with
microwavable plastic wrap, waxed paper,
or a lid.
4. Do not open the door or touch the STOP key
during the sensing time. When sensing time
is over, the oven beeps and the remaining
cooking time will appear in the display
window.
At this time you can open the door to stir,
turn, or rearrange the food.
SENSOR OPERATING
INSTRUCTIONS
Appropriate containers and coverings help
assure good Sensor cooking results.
1. Always use microwavable containers and
cover them with lids or plastic wrap.
2. Never use tight-sealing plastic covers. They
can prevent steam from escaping and cause
food to overcook.
3. Match the amount to the size of the container.
Fill containers at least half full for best
results.
4. Be sure the outside of the cooking container
and the inside of the microwave oven are
dry before placing food in the oven. Beads
of moisture turning into steam can mislead
the sensor.
COOK SENSOR GUIDE
POPCORN SENSOR
1.
Popcorn lets you pop popcorn without needing to
program times and power.
Example : To pop popcorn.
Touch: Display Shows:
When the cook time is over, you will hear four
beeps and COOK END will display.
popcorn
COOK SENSOR
1.
Using COOK SENSOR lets you heat common
microwave-prepared foods without needing
to program times and Cook Powers. COOK
SENSOR has preset Cook Power for 6 food
categories.
Example: To cook rice.
Touch: Display Shows:
When the cook time is over, you will hear four
beeps and COOK END will display.
select menu 1 to 6
2. rice
REHEAT SENSOR
1.
Using REHEAT SENSOR lets you reheat common
microwave-prepared foods without selecting
cooking times and power levels.
Example: To reheat 2 slices of pizza.
Touch: Display Shows:
When the cook time is over, you will hear four
beeps and COOK END will display.
select menu 1 to 4
2. pizza slice
HOW TO USE
![](asset-17.png)
23
COOK SENSOR TABLE
TOUCH PAD
NUMBER DIRECTION AMOUNT
CATEGORY
Baked
Potato
Canned
Vegetable
Fresh
Vegetable
Frozen
Entree
Frozen
Vegetable
Rice
1
2
3
4
5
6
Pierce each potato with a fork and place the oven tray around
the edge, at least one inch apart.
After cooking, allow to stand for 5 minutes.
Remove from the outer display can. Place in an appropriately
sized microwave container, cover with plastic wrap, and vent.
After cooking, stir and allow to stand for 3 minutes.
Prepare as desired, wash, and leave residual water on the
vegetables. Place in an appropriately sized microwave
container. Add amount of water according to the quantity (1~2
cups : 2 tablespoons, 3~4 cups : 4 tablespoons).
Cover with plastic wrap and vent. After cooking, stir and allow
to stand for 3 minutes.
Remove from outer display package. Slit cover. If not in
microwave-safe container, place on a plate.
Cover with plastic wrap and vent the plastic film by piercing
with a fork (3 times). After cooking, allow to stand for 3 minutes.
Remove from package, rinse off frost under running water.
Place in an appropriately sized microwave container. Add
amount of water according to the quantity (1~2 cups : 2
tablespoons, 3~4 cups : 4 tablespoons).
Cover with plastic wrap and vent. After cooking, stir and allow
to stand for 3 minutes.
Place rice and twice as much liquid (water, chicken or
vegetable stock) in a 2 quart microwave dish.
Cover with plastic wrap and vent. After cooking, allow to stand
for 10 minutes. Stir for fluffier rice.
1~4 medium
(approx. 8 to 10
oz. each)
1~4 cups
1~4 cups
10 to 21 oz.
1~4 cups
1/2-2 cups
Use medium or
long grain rice.
Cook instant rice
according to
directions on the
package.
REHEAT SENSOR TABLE
TOUCH PAD
NUMBER DIRECTION AMOUNT
CATEGORY
Casserole
Dinner Plate
Pizza Slice
Soup/Sauce
1
2
3
4
Place in a microwavable bowl or casserole.
Cover with vented plastic wrap.
After cooking, Stir and let stand 3 minutes.
Place on a low plate. Cover with vented plastic wrap.
Let stand 3 minutes after cooking.
This is reheat function for a leftover pizza.
Place on paper towel on a microwave safe plate.
Place in shallow microwavable casserole.
Cover with vented plastic wrap.
After cooking, Stir and let stand 3 minutes.
1~4 cups
1 to 2 servings
1~4 slices
1~4 cups
HOW TO USE
![](asset-18.png)
24
AUTO COOK
1.
2.
Auto Cook provides 6 preset categories for
cooking.
Example: To cook bacon 2 slices.
Touch: Display Shows:
3.
4.
select menu 1 to 6
bacon touch 2 to 6
2 slices touch start
Time counting down
and cook.
bacon
1.
2.
Example: To cook beverage 2 cups.
Touch: Display Shows:
3.
4.
select menu 1 to 6
beverage touch 1 to 2
2 cups touch start
Time counting down
and cook.
beverage
AUTO COOK TABLE
TOUCH PAD
NUMBER DIRECTION AMOUNT
CATEGORY
Bacon
Beverage
Chicken
Pieces
Fresh Roll/
Muffin
Frozen
Roll/Muffin
Hot cereal
1
2
3
4
5
6
Place bacon strips on a microwave bacon rack for best
results. (Use dinner plate lined with paper towels if rack is
not available)
Use a wide-mouth mug. Do not cover.
Remove from display package and place on a plate.
(Be careful! The beverage will be very hot! Sometimes liquids
heated in cylindrical containers will splash out when the cup
is moved.)
Place the chicken pieces in an appropriately sized
microwavable container, cover with plastic wrap, and vent.
Remove from display package and place on plate.
(If muffins are over 3 oz. each, count as two when entering
quantity.)
Remove from display package and place on plate.
(If muffins are over 3 oz. each, count as two when entering
quantity.)
Prepare as directed on package and cook.
Stir well before eating. Use only instant hot cereal.
2~6 slices
1~2 cups
0.5 ~ 2 lbs.
1~6 pieces
(2-3 oz. each)
1~6 pieces
(2-3 oz. each)
1~6 servings
HOW TO USE
![](asset-19.png)
25
WARM & HOLD
1.
2.
You can safely keep hot, cooked food warm in
your microwave oven for up to 90 minutes (about
1 hour, 30 minutes). You can use Warm & Hold
by itself, or to automatically follow a cooking
cycle.
Example: To use the Warm & Hold.
Touch: Display Shows:
At the end of the warm & hold, “END” will be
displayed and four tones will sound.
To make Warm & Hold automatically follow
another cycle:
After entering cooking instructions, touch Warm
& Hold before touching START.
When the last cooking cycle is over, you will
hear two tones. “Hold” will come on while the
oven continues to run.
You can set Warm & Hold to follow Auto Defrost,
Cook, or two stage cooking.
NOTES:
Warm & Hold operates for up to 90 minutes.
Opening the oven door cancels Warm & Hold.
Close the door and touch Warm & Hold, then
touch START if additional Warm & Hold time is
desired.
Food that is cooked covered should also be
covered during Warm & Hold.
Pastry items (pies, turnovers, etc.) should be
uncovered during Warm & Hold.
Complete meals kept warm on a dinner plate
should be covered during Warm & Hold.
Do not use more than one complete Warm &
Hold cycle (about 1 hour, 30 minutes). The quality
of some foods will suer with extended time.
•
•
•
•
•
•
•
•
•
hold warm touch
start
90:00
hold warm
TIPS FOR CONVECTION COOKING
This section gives you cooking instructions and
procedures for operating each convection function.
Please read these instructions carefully.
Convection cooking circulates hot air through the
oven cavity with a fan. The constantly moving air
surrounds the food to heat the outer portion quickly,
creating even browning and sealed-in avor by the
constant motion of hot air over the food surfaces.
Your oven uses convection cooking whenever you
use the Convection Button. DO NOT USE THE OVEN
WITHOUT THE TURNTABLE IN PLACE.
1.
Always use the metal rack on the turntable
when convection cooking.
2.
Do not cover turntable or metal rack with
aluminum foil. It interferes with the ow of air
that cooks the food.
3.
Round pizza pans are excellent cooking utensils
for many convection-only items.
Choose pans that do not have extended handles.
4.
Use convection cooking for items like soués,
breads, cookies, angel food cakes, pizza, and
for some meat and sh cooking.
5. Your oven comes equipped with metal tray
which can be used for cooking in convection
mode or combination mode.
6.
You do not need to use any special techniques
to adapt your favorite oven recipes to
convection cooking; however, you need to lower
oven temperature by 25°F from recommended
temperature mentioned in package instructions
when cooking packaged food in convection
mode.
7.
When baking cakes, cookies, breads, rolls,
or other baked foods, most recipes call for
preheating. Preheat the empty oven just as you
do a regular oven. You can start heavier dense
foods such as meats, casseroles, and poultry
without preheating.
8. All heat-proof cookware or metal utensils can
be used in convection cooking.
9.
As in conventional cooking, the distance of
the food from the heat source aects cooking
results. Refer to the charts in this Use and Care
Guide.
10.
Use metal utensils only for convection cooking.
Never use for microwave or combination
cooking since arcing and damage to the oven
may occur.
11.
After preheating, if you do not open the
door, the oven will automatically hold at the
preheated temperature for 30 minutes.
PRECAUTIONS
The oven cavity, door, turntable, roller rest,
metal tray, metal rack, and cooking utensils will
become very hot. USE THICK OVEN GLOVES
when removing the food, cooking utensils, metal
rack, metal tray, and turntable from the oven
after convection cooking.
Do not use lightweight plastic containers, plastic
wraps, or paper products during any convection
cycle.
•
•
HOW TO USE
![](asset-1a.png)
26
Example: To set the convection cooking at 325°F for
45 minutes with preheating.
Touch: Display Shows:
1.
3.
4.
Time counting down
and cook.
Time of day
2.
CONVECTION
During convection cooking, a heating element is
used to raise the temperature of the air inside the
oven.
Convection cooking temperature ranges from
100°F to 450°F.
It is best to preheat the oven when convection cooking.
Note: Lower oven temperature by 25°F from
package recommended temperature, instructions. The
baking time may vary according to the food condition
or individual preference.
NOTES:
When the oven reaches the set preheat
temperature, ve (5) tones will sound and
the display will scroll the message “PREHEAT
END”. The oven will automatically hold that
temperature for 30 minutes.
The oven temperature drops very quickly when
the door is opened; however, this should not
prevent food from being fully cooked during
normal cooking time.
During convection cooking, the exhaust fan in
the vent hood will automatically turn on at the
1-speed setting to protect the oven.
•
•
•
350 f enter
temperature or
touch start
325 f touch start
325 f preheat
5.
6.
45:00 touch start
325 f convection
Example: To set the convection cooking at 375°F for
30 minutes without preheating.
Touch: Display Shows:
1.
3.
4.
Time counting
down and cook.
Time of day
2.
NOTE: If you press the start button, it will operate.
NOTE:
The temperature range has 10 steps from 100°F to
450°F.
350 f enter
temperature or
touch start
375 f touch start
375 f enter
cooking time
5.
6.
30:00
375 f touch start
375 f convection
HOW TO USE
Number Pad Temperature
1 100°F
2 250°F
3 275°F
4 300°F
5 325°F
6 350°F
7 375°F
8 400°F
9 425°F
0 450°F
![](asset-1b.png)
27
CONVECTION BAKING GUIDELINES
1. Always use the metal rack when convection
baking. Place food directly on rack or place in
metal tray and then place tray on rack. (See
page 15.)
2. Aluminum pans conduct heat quickly. For most
convection baking, light, shiny nishes give best
results because they prevent over-browning in
the time it takes to cook the center areas. Pans
with dull (satin-nish) bottoms are recommended
for cake pans and pie pans for best bottom
browning.
3. Dark or non-shiny nishes, glass, and pyroceram
absorb heat which may result in dry, crisp crusts.
4. Preheating the oven is recommended when baking
foods by convection.
5. To prevent uneven heating and save energy, open
the oven door to check food as little as possible.
Notes:
The oven temperature indicated in the chart above is recommended over the package instruction temperature.
The baking time in the chart above is only a guideline for your reference. You need to adjust time according to
the food condition or your preference. Check readiness at the minimum time.
•
•
Food Time, Min.
Oven Temp. Comments
Breads
Cakes
Cookies
Fruits,
Other
Desserts
Refrigerated Biscuits
Corn Bread
Muns
Popovers
Nut Bread or Fruit
Bread
Yeast Bread
Plain or Sweet Rolls
Devil’s Food
Fudge brownies
Coee Cake
Cup Cakes
Fruit Cake (loaf)
Gingerbread
Butter Cakes, Cake
Mixes
9 x 13a
Tube Cake
Pound Cake
Chocolate Chip
Sugar
Baked Apples or
Pears
Bread Pudding
Cream Pus
Meringue Shells
375°F
350°F
425°F
325°F
325°F
375°F
350°F
350°F
350°F
325°F
325°F
275°F
300°F
325°F
325°F
325°F
325°F
350°F
350°F
350°F
300°F
400°F
300°F
11 to 14
35 to 40
18 to 22
45 to 55
60 to 70
16 to 23
13 to 16
35 to 40
26 to 30
30 to 35
20 to 25
90 to 100
25 to 30
35 to 45
35 to 45
30 to 40
45 to 55
11 to 14
11 to 14
35 to 40
35 to 40
30 to 35
30 to 35
Allow additional time for large biscuits.
Remove from pans immediately and cool
slightly on wire rack.
Pierce each popover with a fork after
removing from oven to allow steam to
escape.
Interiors will be moist and tender.
Lightly grease baking sheet.
Place cake pan on rack.
Bake 2 layers of brownies at a time.
Interior will be moist and tender.
Turn end for end half way through baking.
Grease and our pan.
Cool in pan 10 minutes before inverting
on wire rack.
Place metal tray on rack. Allow extra
time for frozen cookie dough.
Place metal tray on rack.
Bake in cookware with shallow sides.
Pudding is done when knife inserted near
center comes out clean.
Puncture pus twice with toothpick to release
steam after 25 minutes of baking time.
When done, turn oven o and let shells
stand in oven 1 hour to dry.
HOW TO USE
![](asset-1c.png)
28
Notes:
The oven temperature indicated in the chart above is recommended over the package instruction temperature.
The baking time in the chart above is only a guideline for your reference. You need to adjust time according to
the food condition or your preference. Check doneness at the minimum time.
•
•
Food Time, Min.
Oven Temp. Comments
Pies, Pastries
Casseroles
Convenience
Foods
Main Dishes
Vegetables
Frozen Pie
Meringue-Topped
Two-Crust
Quiche
Pastry Shell
Meat, Chicken, Seafood
Combinations
Pasta
Potatoes, scalloped
Vegetable
Frozen Bread Dough
Frozen Entree
Frozen Pizza Rising
Crust
Frozen Pizza
French Fries Crinkle Cut
Frozen Wae
Frozen Cheese Sticks
Frozen Turnovers
Meat Loaf
Oven-Baked Stew
Swiss Steak
Stued Peppers
Acorn Squash Halves
Baked Potatoes
Twice-Baked Potatoes
400°F
450°F
400°F
350°F
400°F
350°F
350°F
350°F
350°F
350°F
325°F
400°F
400°F
450°F
400°F
450°F
450°F
400°F
325°F
350°F
350°F
375°F
425°F
400°F
50 to 60
9 to 11
50 to 55
30 to 35
10 to 16
20 to 40
25 to 45
55 to 60
25 to 35
30 to 35
70 to 80
25 to 35
17 to 21
15 to 19
5 to 7
6 to 8
18 to 22
30 to 40
80 to 90
60 to 70
40 to 45
55 to 60
50 to 60
25 to 30
Place metal tray on rack and place in
cold oven. Preheat oven, tray and rack
to 400°F. When preheated, place
frozen pie on metal tray and bake
according to package time or until
crust is browned and lling is hot.
Follow package directions for preparation.
Follow package directions for preparation.
Let stand 5 minutes before cutting.
Pierce pastry with fork to prevent shrinkage.
Cook times vary with casserole size
and ingredients.
Cook times vary with casserole size
and ingredients.
Let stand 5 minutes before serving.
Cook times vary with casserole size
and ingredients.
Follow package directions for preparation.
Follow package directions for preparation.
Follow package directions for preparation.
Pizza should not extend over the rack.
Follow package directions for preparation.
Pizza should not extend over the rack.
Follow package directions for preparation.
Follow package directions for preparation.
Follow package directions for preparation.
Follow package directions for preparation.
Let stand 5 minutes after cooking.
Brown meat before combining with
liquid and vegetables.
Let stand 2 minutes after cooking.
Use green, red, or yellow peppers.
Pierce skin several places. Add 1/2
cup water to dish. Turn squash halves
cut side up after 30 minutes of cook
time and cover.
Pierce skin with fork before baking.
Pierce skin with fork before baking.
CONVECTION BAKING GUIDELINES (cont'd)
HOW TO USE
![](asset-1d.png)
29
Note:
The roasting time in the chart above is only a guideline for your reference. You need to adjust the time
according to the food condition or your preference. Check readiness at the minimum time.
Food Time, Min. / lb.
Oven Temp.
Beef
Ham
Lamb
Pork
Poultry
Seafood
Ribs (2 to 4 lbs.)
Rare
Medium
Well
Boneless Ribs, Top Sirloin
Rare
Medium
Well
Beef Tenderloin
Rare
Medium
Pot Roast (21/2 to 3 lbs.)
Chuck, Rump
Meat Loaf (2 lbs.)
Canned (3-lb. fully cooked)
Butt (5-lb. fully cooked)
Shank (5-lb. fully cooked)
Bone-in (2 to 4 lbs.)
Medium
Well
Boneless (2 to 4 lbs.)
Medium
Well
Bone-in (2 to 4 lbs.)
Boneless (2 to 4 lbs.)
Pork Chops (1/2 to 1-inch thick)
2 chops
4 chops
6 chops
Whole Chicken (21/2 to 31/2 lbs.)
Chicken Pieces (21/2 to 31/2 lbs.)
Duckling (4 to 5 lbs.)
Turkey Breast (4 to 6 lbs.)
Fish, whole (3 to 5 lbs.)
Lobster Tails (6 to 8-oz. each)
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
400°F
325°F
325°F
325°F
300°F
300°F
300°F
300°F
300°F
300°F
325°F
325°F
325°F
375°F
425°F
375°F
325°F
400°F
350°F
45 to 50
50 to 55
55 to 60
53 to 58
58 to 63
63 to 68
28 to 32
32 to 36
83 to 88
65 to 75
20 to 25
20 to 25
17 to 20
42 to 47
47 to 52
50 to 55
55 to 60
48 to 52
56 to 61
42 to 45
45 to 48
48 to 55
25 to 35
10 to 12
19 to 21
21 to 25
13 to 18
12 to 17
MEAT ROASTING GUIDELINES FOR CONVECTION COOKING
HOW TO USE
![](asset-1e.png)
30
TIPS FOR COMBINATION
COOKING
This section gives you instructions to operate each
combination cooking function. Please read these
instructions carefully. Sometimes combination
microwave-convection cooking is suggested to
get the best cooking results since it shortens the
cooking time for foods that normally need a long
time to cook. This cooking process also leaves
meats juicy on the inside and crispy on the outside.
In combination cooking, the convection heat and
microwave energy alternate automatically. Your
oven has three preprogrammed settings that make
it easy to use combination cooking.
HELPFUL HINTS FOR
COMBINATION COOKING
1. Meats may be roasted directly on the metal
rack or in a shallow roasting pan placed on the
rack. When using the metal rack, please check
your cooking guide for information on proper
use.
2.
Less tender cuts of beef can be roasted and
tenderized using oven cooking bags.
3.
When baking, check for doneness after cooking
time is up. If not completely done, let stand in
oven for a few minutes to complete cooking.
PRECAUTIONS
1. All cookware used for combination cooking
must be BOTH microwave-safe and oven-safe.
2. During combination baking, some baking
cookware may cause arcing when it comes in
contact with the oven walls or metal accessory
racks. Arcing is a discharge of electricity that
occurs when microwaves come in contact with
metal.
— If arcing occurs, immediately stop the
cooking cycle and place a heat resistant
dish between the pan and the metal rack.
— We recommend you use the metal tray
applied with your oven. It has rubber feet
that helps prevent arcing.
— If arcing occurs with other baking cookware,
do not use them for combination cooking.
Example: To roast with combination cooking for
45 minutes at 400°F.
Touch: Display Shows:
1.
3.
4.
Time counting
down and cook.
2.
COMBINATION ROAST
Once Co-1,
twice Co-2.
NOTES:
• The temperature range has 9 steps from 250°F
to 450°F.
• During combination cooking, the exhaust fan in
the vent hood will automatically turn on at the
1-speed setting to protect the oven.
Time of day
375 f enter
temperature or
touch start or
combi.
400 f touch start
400 f enter
cooking time
5.
6.
45:00
400 f touch start
400 f combi 1
TOUCH
COMBI PAD
Once
Twice
CATEGORY
Combination
ROAST
Combination
BAKE
OVEN
TEMPERATURE
Convection
375°F
Convection
325°F
COMBI
Co-1
Co-2
HOW TO USE
Co-1
![](asset-1f.png)
31
Example: To cook 2 lb. roast pork.
Touch: Display Shows:
1.
3.
4.
Time counting
down and cook.
2.
SPEED COOK
CATEGORY
Baked Potato
Frozen Lasagna
Roast Pork
Whole Chicken
AMOUNT
1 - 4 EA
10 or 21 oz.
2.0 - 4.0 lbs
2.0 - 4.0 lbs
DIRECTION
Pierce each potato several times with a fork and place on
metal rack on metal tray.
Remove from outer package. Remove lm cover. If lasagna
is not in a ovenproof container, place it on a ovenproof dish.
Place on metal rack on metal tray. Let stand for 5 minutes
after cooking.
Pat dry with paper towels. Place roast on metal rack on
metal tray. After cooking, loosely tent roast with aluminum
foil and let stand 5 to 10 minute.
Thoroughly wash inside and outside of chicken with cold
water. Pat chicken dry with paper towels, secure the legs
with kitchen twine. Brush outside of chicken with melted
butter or margarine. Place chicken breast side down on
metal rack on metal tray. After cooking, loosely tent chicken
with aluminum foil. Let stand for 10 minutes after cooking.
TOUCH PAD
NUMBER
1
2
3
4
SPEED COOK CHART
This oven can cook food without entering cooking
time or power level on combination mode. SPEED
COOK has 4 food categories. See the SPEED COOK
CHART on this page for the settings available.
For best results, place food on the rack. When
cooking meats, use the metal tray/drip pan to
catch drippings.
Time of day
select menu 1 to 4
roast pork
enter weight
2.0
touch start
5. roast pork
HOW TO USE
Lbs
![](asset-20.png)
32
Food Time, Min./lb.
Oven Temp.
Beef
Ham
Lamb
Pork
Poultry
Seafood
Turn over after half of cooking time.
Ribs (2 to 4 lbs.)
Rare
Medium
Well
Boneless Ribs, Top Sirloin
Rare
Medium
Well
Beef Tenderloin
Rare
Medium
Chuck, Rump or Pot Roast (21/2 to 3 lbs.)
(Use cooking bag for best results.)
Turn over after half of cooking time.
Canned (3-lb. fully cooked)
Butt (5-lb. fully cooked)
Shank (5-lb. fully cooked)
Turn over after half of cooking time.
Bone-in (2 to 4 lbs.)
Medium
Well
Boneless (2 to 4 lbs.)
Medium
Well
Turn over after half of cooking time.
Bone-in (2 to 4 lbs.)
Boneless (2 to 4 lbs.)
Pork Chops (3/4 to 1-inch thick)
2 chops
4 chops
6 chops
Turn over after half of cooking time.
Whole Chicken (21/2 to 6 lbs.)
Chicken Pieces (21/2 to 6 lbs.)
Cornish Hens (untied)
Unstued
Stued
Duckling
Turkey Breast (4 to 6 lbs.)
Fish
1-lb. llets
Lobster Tails (6 to 8-oz. each)
Shrimp (1 to 2 lbs.)
Scallops (1 to 2 lbs.)
375°F
375°F
375°F
375°F
375°F
375°F
375°F
375°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
350°F
305°F
305°F
375°F
375°F
425°F
375°F
375°F
300°F
350°F
350°F
350°F
350°F
9 to 13
11 to 15
13 to 17
9 to 13
11 to 15
13 to 17
16 to 18
18 to 20
18 to 20
15 to 18
15 to 18
15 to 18
13 to 18
18 to 23
14 to 19
19 to 24
17 to 20
19 to 22
10 to 13
13 to 16
16 to 19
15 to 17
15 to 18
15 to 18
22 to 25
15 to 18
11 to 15
7 to 10
10 to 15
9 to 14
8 to 13
COMBINATION ROAST COOKING GUIDE
Note:
The roasting time in the chart above is only a guideline for your reference. You need to adjust time according to the
food condition or your preference. Check doneness at the minimum time.
HOW TO USE
![](asset-21.png)
33
Food Time, Min.
Oven Temp.
Pies, Pastries
Convenience
Foods
Vegetables
Quiche
Frozen Entree
Frozen Pizza
Rolls, Egg Rolls
Pizza
Baked Potatoes
425°F
375°F
450°F
450°F
450°F
15 to 17
39 to 43
4 to 6
23 to 26
36 to 40
Comments
Let stand 5 minutes before cutting.
Follow package directions for preparation.
Follow package directions for preparation.
Follow package directions for preparation.
Pierce skin with a fork before baking.
Place on rack.
COMBINATION BAKE COOKING GUIDE
HOW TO USE
![](asset-22.png)
34
ITEMS SPECIAL INSTRUCTIONSCOOK TIME (AT HIGH)
Sliced meat
3 slices (¼ -inch thick)
Chicken pieces
1 breast
1 leg and thigh
Fish fillet
(6-8 oz.)
Lasagna
1 serving (10½ oz.)
Casserole
1 cup
4 cups
Casserole – cream or
cheese
1 cup
4 cups
Sloppy Joe or
Barbecued Beef
1 sandwich (½ cup
meat filling)without bun
Mashed potatoes
1 cup
4 cups
Baked beans
1 cup
Ravioli or pasta in sauce
1 cup
4 cups
Rice
1 cup
4 cups
Sandwich roll or bun
1 roll
Vegetables
1 cup
4 cups
Soup
1 serving (8 oz.)
1-2 minutes
2-3½ minutes
1½-3 minutes
2-4 minutes
4-6 minutes
1-3½ minutes
5-8 minutes
1½-3 minutes
3½-5½ minutes
1-2½ minutes
1-3 minutes
5-8 minutes
1½-3 minutes
2½-4 minutes
7½-11 minutes
1½-3½ minutes
4-6½ minutes
15-30 seconds
1½-2½ minutes
4-6 minutes
1½-2½ minutes
Place sliced meat on microwavable plate.
Cover with plastic wrap and vent.
Note: Gravy or sauce helps to keep meat juicy.
Place chicken pieces on microwavable plate. Cover
with plastic wrap and vent.
Place fish on microwavable plate. Cover with plastic
wrap and vent.
Place lasagna on microwavable plate. Cover with
plastic wrap and vent.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
Reheat filling and bun separately.
Cook filling covered in microwavable casserole.
Stir once.
Heat bun as directed in chart below.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
Wrap in paper towel and place on glass
microwavable rack
COOK covered in microwavable casserole. Stir once
halfway through cooking.
COOK covered in microwavable casserole. Stir once
halfway through cooking.
HEATING / REHEATING GUIDE
To heat or reheat successfully in a microwave oven, it is important to follow several guidelines. Measure the
amount of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for
best results. Room temperature food will heat faster than refrigerated food. Canned foods should be taken
out of the can and placed in a microwave-safe container. The food will heat more evenly if covered with a
microwave-safe lid or vented plastic wrap. Remove cover carefully after cooking to prevent steam burns. Use
the following chart as a guide for reheating cooked food.
HOW TO USE
![](asset-23.png)
35
VEGETABLE AMOUNT INSTRUCTIONS STANDING
TIME
COOK TIME
AT HIGH
(MINUTE)
Artichokes
(8 oz.each)
Asparagus,
Fresh, Spears
Beans, Green
&Wax
Beets,Fresh
Broccoli,Fresh,
Spears
Cabbage, Fresh,
Chopped
Carrots, Fresh,
Sliced
Cauliflower,
Fresh, Whole
Flowerettes,
Fresh Celery,
Fresh, Sliced
Corn, Fresh
Mushrooms,
Fresh, Sliced
Parsnips, Fresh,
Sliced
Peas, Green,
Fresh
Sweet Potatoes
Whole Baking
(6-8 oz.each)
White Potatoes,
Whole Baking
(6-8 oz.each)
Spinach, Fresh,
Leaf
Squash, Acorn or
Butternut,
Fresh
Zucchini, Fresh,
Sliced
Zucchini, Fresh,
Whole
2 medium
4 medium
1 Ib.
1 lb.
1 Ib.
1 Ib.
1 Ib.
2 cups
1 lb.
2 cups
4 cups
2 ears
½ Ib.
1 Ib.
4 cups
2 medium
4 medium
2 potatoes
4 potatoes
1 Ib.
1 medium
1 Ib.
1 Ib.
5-8
10-13
3-6
7-11
12-16
4-8
4-7
2-4
7-11
2½-4½
6-8
5-9
2-3½
4-8
7-10
5-10
7-13
5-8
10-14
4-7
6-8
4½-7½
6-9
Trim.Add 2 tsp water and 2 tsp juice. Cover.
Add ½ cup water. Cover.
Add ½ cup water in 1½ qt.casserole.
Stir halfway through cooking.
Add ½ cup water in 1½ qt.covered casserole.
Rearrange halfway through cooking.
Place broccoli in baking dish. Add 1/2 cup water.
Add ½ cup water in 1½ qt. covered casserole.
Stir halfway through cooking.
Add ¼ cup water in 1 qt. covered casserole.
Stir halfway through cooking.
Trim.Add ¼ cup water in 1 qt. covered casserole.
Stir halfway through cooking.
Slice.Add ½ cup water in 1½ qt. covered
casserole. Stir halfway through cooking.
Husk.Add 2 tbsp water in 1½ qt. baking dish.
Cover.
Place mushrooms in 1½ qt. covered casserole.
Stir halfway through cooking.
Add 1/2 cup water in 1½ qt.covered casserole.
Stir halfway through cooking.
Add 1/2 cup water in 1½ qt. covered casserole.
Stir halfway through cooking.
Pierce potatoes several times with fork.
Place on 2 paper towels.
Turn over halfway through cooking.
Pierce potatoes several times with fork.
Place on 2 paper towels.
Turn over halfway through cooking.
Add½ cup water in 2 qt. covered casserole.
Cut squash in half. Remove seeds.
Place in 8 x 8-inch baking dish. Cover.
Add½ cup water in 1½ qt. covered casserole.
Stir halfway through cooking.
Pierce. Place on 2 paper towels. Turn over and
rearrange halfway through cooking.
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
2-3 minutes
FRESH VEGETABLE GUIDE
HOW TO USE
![](asset-24.png)
36
For interior surfaces: Wash often with warm, sudsy
water and a sponge or
soft cloth. Use only mild,
nonabrasive soaps or a
mild detergent. Be sure
to keep the areas clean
where the door and
oven frame touch when
closed. Wipe well with
clean cloth.
Over time, stains can
occur on the surfaces as
the result of food particles
spattering during cooking.
This is normal.
For stubborn soil, boil a
cup of water in the oven
for 2 to 3 minutes. Steam
will soften the soil. To get
rid of odors inside the
oven, boil a cup of water
with some lemon juice or
vinegar in it.
For exterior surfaces and control panel: Use a
soft cloth with spray
glass cleaner. Apply the
spray glass cleaner to the
soft cloth; do not spray
directly on the oven.
NOTE: Abrasive
cleansers, steel wool
pads, gritty wash cloths,
some paper towels, etc.,
can damage the control
panel and the interior and
exterior oven surfaces.
To clean grass tray and rotating ring, wash in
mild, sudsy water; for
heavily soiled areas
use a mild cleanser
and scouring sponge.
The glass tray and
rotating ring are
dishwasher safe.
Care And Cleaning
To make sure your microwave oven looks good and works well for a long time, you should maintain it properly.
For proper care, please follow these instructions carefully.
Metal Rack
Metal Tray
Glass Turntable
Rotate Ring
![](asset-25.png)
37
REPLACING THE COOKTOP AND OVEN LIGHTS
The cooktop light
1. Unplug microwave oven or disconnect power.
2. Remove the bulb cover mounting screws.
5.
Remove bulb holder by pushing locking tab back
slightly to disengage tab from the bulb holder.
Use a cloth or towel when replacing the bulb.
- If you touch the halogen bulb with your bare hands it will reduce the life of the bulb.
3. Replace bulb.
4. Reinstall bulb cover with mounting screws.
5. Plug in microwave oven or reconnect power.
The oven light
1. Unplug microwave oven or disconnect power.
2. Remove the vent grille mounting screws.
3.
Open the door. Tip the grille forward; then slide
to the left and pull out.
4.
Remove charcoal lter.
6. Lift up the bulb holder and slide out of the
compartment.
7. Replace the bulb.
8. Reinstall bulb holder. Slide bulb holder back into
the compartment and press down rmly so lock-
ing tab snaps into place.
9. Replace charcoal lter.
10.
Set the bottom of the grille in place, slide to the
right, and then snap the top in place. Replace
the mounting screws.
11. Plug in microwave oven or reconnect power.
CARE AND CLEANING
![](asset-26.png)
38
vent grille
CARING FOR THE FILTERS
The grease lters should be removed and cleaned often, at least once a month.
NOTE: If your microwave hood combination is installed to recirculate air, the chacoal lter (Part
No.5230W1A003A) is available from Sears by calling 1-800-4-MY-HOME®. The charcoal lter cannot be
cleaned and should be replaced every 6 to 12 months.
Grease lters (Part No.2B72705B):
1. Unplug microwave oven or disconnect power.
2. To remove grease lters, slide each lter to
the side. Pull lters downward and push to the
other side. The lter will drop out.
3. Soak grease lters in hot water and a
mild detergent. Scrub and swish to remove
embedded dirt and grease. Rinse well and
shake to dry. Do not clean lters with ammonia,
corrosive cleaning agents such as lye-based
oven cleaners, or place them in a dishwasher.
The lters will turn black or could be damaged.
4. To replace grease lters, slide lter in the
frame slot on one side of the opening. Push
lter upward and push to the other side to lock
into place.
5. Plug in microwave oven or reconnect power.
CHARCOAL FILTER REPLACEMENT
If your oven is vented inside, the charcoal lter
should be replaced every 6 to 12 months, and
more often if necessary. The charcoal lter
cannot be cleaned. Purchase a new charcoal
lter from the nearest Sears Parts & Repair
Service Center, or by calling 1-800-4-MY-HOME®.
1. Disconnect power or unplug microwave oven.
2. Remove the two vent grille mounting screws.
Slide vent grille slightly to the left.
3. Tip the grille forward; then lift out to remove.
4. Remove old lter.
5. Slide a new charcoal lter into place. The lter
should rest at the angle shown.
6. Push the vent grille into place. Slide the grille
to the right until it snaps into place.
7. Replace the mounting screws.
8. Reconnect power or plug in microwave oven.
CARE AND CLEANING
![](asset-27.png)
39
Cooking Tips
Amount of food
If you increase or decrease the amount of
food you prepare, the time it takes to cook
that food will also change. For example, if you
double a recipe, add a little more than half the
original cooking time. Check for doneness and,
if necessary, add more time in small increments.
Starting temperature of food
• The lower the temperature of the food being
put into the microwave oven, the longer it takes
to cook. Food at room temperature will be
reheated more quickly than food at refrigerator
temperature.
Composition of food
Food with a lot of fat and sugar will be heated
faster than food containing a lot of water. Fat
and sugar will also reach a higher temperature
than water in the cooking process.
The more dense the food, the longer it takes to
heat. “Very dense” food like meat takes longer
to heat than lighter, more porous food like
sponge cakes.
Size and shape
Smaller pieces of food will cook faster than
larger pieces. Also, same-shaped pieces cook
more evenly than dierent-shaped pieces.
With foods that have dierent thicknesses,
the thinner parts will cook faster than the thicker
parts. Place the thinner parts of chicken wings
and legs in the center of the dish.
Stirring, turning foods
Stirring and turning foods spreads heat
quickly to the center of the dish and avoids
overcooking at the outer edges of the food.
Covering food
Cover food to reduce splattering, shorten cooking
times, and Keep food moist.
You can use any covering that lets microwaves
pass through. See
How Your Microwave Hood
Combination Works
on page 5 for materials that
microwaves will pass through. If you are using the
Sensor function, be sure to vent.
•
•
•
•
•
•
•
Releasing pressure in foods
Several foods (for example, baked potatoes,
sausages, egg yolks, and some fruits) are tightly
covered by a skin or membrane. Steam can
build up under the membrane during cooking,
causing the food to burst. To relieve the pressure
and to prevent bursting, pierce these foods
before cooking with a fork, cocktail pick, or
toothpick.
Using standing time
Always allow food to stand either inside or
outside the oven after the cooking or defrost
period ends. Standing time after defrosting
and cooking allows the temperature to evenly
spread throughout the food, improving cooking
or defrosting results.
The length of the standing time depends on
how much food you are cooking and how dense
it is. Sometimes it can be as short as the time
it takes you to remove the food from the oven
and take it to the serving table. However, with
larger, denser food, the standing time may be
as long as 10 minutes. For such longer periods,
you may want to program a "0" power second
stage of the cooking cycle for standing time
inside the oven. See
Two-Stage Cooking
.
Arranging food
For best results, place food evenly on the plate. You
can do this in several ways:
If you are cooking several items of the same
food, such as baked potatoes, place them in a
ring pattern for uniform cooking.
When cooking foods of uneven shapes or
thickness, such as chicken breasts, place the
smaller or thinner area of the food towards the
center of the dish where it will be heated last.
Layer thin slices of meat on top of each other.
When you cook or reheat whole sh, score the
skin – this prevents cracking.
Do not let food or a container touch the top
or sides of the oven. This will prevent possible
arcing.
•
•
•
•
•
•
•
•
![](asset-28.png)
40
COOKING TIPS
Using aluminum foil
Metal containers should not be used in a microwave
oven. There are, however, some exceptions. If you
have purchased food which is prepackaged in an
aluminum foil container, refer to the instructions on
the package. When using aluminum foil containers,
cooking times may be longer because microwaves
will only penetrate the top of the food. If you use
aluminum containers without package instructions,
follow these guidelines:
Place the container in a glass bowl and add
some water so that it covers the bottom of
the container, not more than 1⁄4-in. (.64-cm)
high. This ensures even heating of the container
bottom.
Always remove the lid to avoid damage to the
oven.
Use only undamaged containers.
Do not use containers taller than 3⁄4 in. (1.9
cm).
Container must be at least half lled.
To avoid arcing, there must be a minimum 1⁄4
in. (.64 cm) between the aluminum container
and the walls of the oven and also between two
aluminum containers.
Always place the container on the turntable.
Shield with small pieces of aluminum foil the
parts of food that may cook quickly, such as
wing tips and leg ends of poultry.
Heating food in aluminum foil containers
usually takes up to double the time compared
to reheating in plastic, glass, china, or paper
containers. The time when food is ready will
vary depending upon the type of container you
use.
Let food stand for 2 to 3 minutes after heating
so that heat is spread evenly throughout the
container.
Cooking you should not do in your microwave
oven
Do not do canning of foods in the oven. Closed
glass jars may explode, resulting in damage to
the oven.
Do not use the microwave oven to sterilize
objects (baby bottles, etc.). It is dicult to keep
the oven at the high temperature needed for
sterilization.
•
•
•
•
•
•
•
•
•
•
•
•
Removing the rack
When popping commercially packaged
popcorn, remove the rack from the oven. Do
not place the bag of microwave popcorn on the
rack or under the rack.
In the case of popping microwave popcorn with
the rack, that can cause re or damage to your
microwave oven.
•
•
![](asset-29.png)
41
COOKING COMPARISON GUIDE
Cooking with your new oven oers a wide variety
of food preparation options: microwave cooking,
convection cooking, and combination cooking.
Microwave cooking uses very short, high-frequency
radio waves. The movement of the microwaves
through the food generates heat and cooks most
foods faster than regular methods, while retaining
their natural texture and moisture. Microwave cooking
heats food directly, not the cookware or the interior
of the oven. Reheating is easy and defrosting is
particularly convenient because less time is spent in
food preparation.
Convection cooking constantly circulates heated air
around the food, creating even browning and sealed-in
avor by the constant motion of hot air over the food
surfaces.
Combination cooking combines microwave energy
with convection to cook with speed and accuracy,
while browning and crisping to perfection.
You can use microwave cooking, convection cooking,
or combination cooking to cook by time. Simply
preset the length of cooking time desired and your
oven turns o automatically.
The following guide shows at a glance the dierence
between microwave, convection, and combination
cooking.
Microwave energy is
distributed evenly throughout
the oven for fast, thorough
cooking of food.
Microwave energy.
Fast, high eciency
cooking.
Oven and surroundings do
not get hot.
Easy clean-up.
•
•
•
COOKING
METHOD
HEAT
SOURCE
BENEFITS
MICROWAVE CONVECTION COMBINATION
Hot air circulates around food
to produce browned exteriors
and sealed-in juices.
Circulating heated air.
Aids in browning and seals
in avor.
Cooks some foods faster
than regular ovens.
•
•
Microwave energy and
convection heat combine to
shorten the cooking time of
regular ovens, while browning
and sealing in juices.
Microwave energy and
circulating heated air.
Shortened cooking
time from microwave
energy.
Browning and crisping
from convection heat.
•
•
Read this guide to learn the many dierent things your Microwave/Convection/Combination Oven can do.
You will nd a wide variety of cooking methods and programs designed to suit your lifestyle.
COOKING TIPS
![](asset-2a.png)
42
COOKING TIPS
COOKWARE GUIDE
Microwave Cooking
Most heat-resistant, non-metallic cookware is safe for
use in your microwave oven.
However, to test cookware before using, follow these
steps:
1. Place the empty cookware in the microwave oven.
2. Measure 1 cup of water in a glass measuring cup
and place it in the oven beside the cookware.
3. Microwave on 100% power for 1 minute. If the
dish is warm, it should not be used for microwave
cooking.
Convection Cooking
Metal Pans are recommended for all types of
baked products, but especially where browning or
crusting is important.
Dark or dull nish metal pans are best for breads
and pies because they absorb heat and produce a
crisper crust.
Shiny aluminum pans are better for cakes, cookies,
or muns because these pans reect heat and
help produce a light, tender crust.
Glass or glass-ceramic casserole or baking dishes
are best suited for egg and cheese recipes due to
the cleanability of glass.
•
•
•
•
Combination Cooking
Glass or glass-ceramic baking containers are
recommended. Be sure not to use items with metal
trim as it may cause arcing (sparking) with oven
wall or oven shelf, damaging the cookware, the
shelf or the oven.
Heat-resistant plastic microwave cookware (safe
to 450°F) may be used, but is not recommended
for foods that require crusting or all-around
browning, because plastic is a poor conductor of
heat.
•
•
COOKWARE MICROWAVE CONVECTION COMBINATION
Heat-Resistant Glass, Ceramic Glass Yes Yes Yes
Ceramics, China Yes Yes Yes
(Do not use china
with gold or silver trim.)
Metal Cookware No Yes No
Non Heat-Resistant Glass No No No
Microwave-Safe Plastic Yes No Yes*
Plastic Wrap, Wax Paper Yes No No
Paper Products Yes No No
Straw, Wicker, and Wood Yes No No
* Use only microwave cookware that is safe to 450° F
![](asset-2b.png)
43
HOW TO USE ACCESSORIES
Glass Turntable
MICROWAVE CONVECTION COMBINATION
Notes :
Do not operate the oven when it is empty except preheating.
: Possible to use
: Recommended method
: Do not use
Metal Tray Metal Rack X
X
X
X
X
X
COOKING TIPS
![](asset-2c.png)
44
Questions And Answers
QUESTIONS ANSWERS
Can I operate my microwave oven without the glass
tray or move the glass tray over to hold a large
dish?
Can I use either metal or aluminum pans in my mi-
crowave oven?
Is it normal for the guide tray to move in either
direction?
Why does the dish become hot when I microwave
food in it?
I thought that this should not happen.
What does “standing time” mean?
Why does steam come out of the air exhaust vent?
Can I pop popcorn in my microwave oven?
How do I get the best results?
No. If you remove or move the glass tray, you will get
poor cooking results. Dishes used in your oven must t on
the glass or guide tray.
You can use aluminum foil for shielding (use small, at
pieces), small skewers, and shallow foil trays (if tray is
not taller than 3⁄4-in. [1.9-cm] deep and is lled with
food to absorb microwave energy). Never allow metal
to touch walls or door.
Yes. The guide tray moves from side to side, depend-
ing on the rotation of the motor when the cooking cycle
begins.
As the food becomes hot, it will conduct the heat to the
dish. Be prepared to use hot pads to remove food after
cooking.
“Standing time” means that after the timed ccoking
period ends, food should be allowed to stand either
inside or outside of the oven to completely nish cooking.
Outside oven standing time will allow the oven to be
available for other use. For inside oven standing time,
you can program a "0" power second stage of the cook-
ing cycle. See
Two-Stage Cooking
.
Steam is normally produced during cooking. The
microwave oven has been designed to vent this steam
out of the vents.
Yes. Pop packaged microwave popcorn following
manufacturer’s guidelines. Do not use regular paper
bags. Do not repop unpopped kernels. Do not pop
popcorn in glass cookware.
![](asset-2d.png)
45
Troubleshooting
PROBLEM CAUSE
Nothing works.
The microwave oven will not run.
The power supply cord is not plugged into a grounded three
prong outlet. (See the Electrical Requirements section on page
6 and the Electrical Connection section on page 8.)
A household fuse has blown or a circuit breaker has tripped.
The electric company has had a power failure.
You are using the oven as a timer. Touch STOP to cancel the
Timer.
The door is not rmly closed and latched.
You did not touch START.
You did not follow directions exactly.
An operation that you set earlier is still running. Touch STOP to
cancel that operation.
•
•
•
•
•
•
•
•
Most cooking problems often are caused by little things you can nd and x without tools of any kind. Check
the lists below and on the next page before calling for assistance or service. If you still need help, call Sears
Service at 1-800-4-MY-HOME®.
MICROWAVE OVEN DOES NOT WORK
PROBLEM CAUSE
Food is not cooked enough.
The display shows a time counting
down but the oven is not cooking.
The cook power is not at the recommended setting. Check the
chart on page 15.
The electric supply to your home or wall outlets is low or
lower than normal. Your electric company can tell you if the
line voltage is low. Your electrician can tell you if the outlet
voltage is low.
Refer to Cooking Tips Guide.
The oven door is not closed completely.
You have set the controls as a kitchen timer. Touch the STOP
pad and cancel the Timer.
•
•
•
•
•
COOKING TIMES
PROBLEM CAUSE
Vent fan comes on automatically The vent fan will automatically turn on if it senses to much heat
during cooking on the cooktop below.
•
VENT MOTOR
PROBLEM CAUSE
You hear the humming sound This is normal noise during operation from the magnetron, fan
noise and the transformer.
•
NOISE
![](asset-2e.png)
46
PROBLEM CAUSE
The glass tray will not move. The glass tray is not correctly in place. It should be correct-side up
and sitting rmly on the center hub.
The turntable has been turned o. Refer to the Turntable section.
The support is not operating correctly. Remove the glass tray and
restart the oven. If the hub still does not move, call Sears Service at
1-800-4-MY-HOME®. Cooking without the glass tray can give you
poor results.
•
•
•
If none of these items is causing your problem, call Sears Service at 1-800-4-MY-HOME®.
PROBLEM CAUSE
You do not hear the programming
or end-of-cycle tone.
The audible tone has been disabled.
You have not entered the correct command.
Tone must be enabled
•
•
TONES
GLASS TRAY
PROBLEM CAUSE
The display is ashing ":". There has been a power interruption. Reset the clock. (See the
“Clock” section.)
•
DISPLAY MESSAGES
TROUBLESHOOTING
