Kenwood USA Corporation UHF FM Repeater - Transmitter TKR 850K3 s

Instruction Manual

INSTALLATION
To install the handles onto the front panel of the repeater,
align the handles with the holes on the front panel, then
secure the handles using the supplied screws.
Please consult your dealer for installing the repeater and
antenna.
MICROPHONE
Connect an optional KMC-27A, KMC-27B, or KMC-9C
KENWOOD microphone to the MICROPHONE jack on
the front panel.
VHF FM REPEATER/ UHF FM REPEATER
TKR-750/ TKR-850
INSTRUCTION MANUAL
KENWOOD CORPORATION
© B62-1327-00 (K)
09 08 07 06 05 04 03 02 01 00
NOTICES TO THE USER
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking information is for use by your KENWOOD
dealer, an authorized KENWOOD service facility, or the factory.
Carefully unpack the repeater. We recommend that you
identify the items listed in the following table before
discarding the packing material. If any items are missing
or have been damaged during shipment, file a claim with
the carrier immediately.
FCC WARNING
This equipment generates or uses radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless
the modifications are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
GOVERNMENT LAW PROHIBITS THE OPERATION OF
UNLICENSED RADIO TRANSMITTERS WITHIN THE
TERRITORIES UNDER GOVERNMENT CONTROL.
ILLEGAL OPERATION IS PUNISHABLE BY FINE OR
IMPRISONMENT OR BOTH.
REFER SERVICE TO QUALIFIED TECHNICIANS ONLY.
metI rebmuNtraP ytitnauQ
erutxiferawdraH4X-2048-12J1
ssalgtnorF4X-6362-01B1
retliF4X-9521-11B1
noihsuC4X-1081-31G4
noihsuC4X-2081-31G4
tooF5X-5740-20J2
tooF4X-2940-20J2
temmorG5X-2030-95J2
eldnaH5X-5240-10K1
swercS54-6062-53N5
drocCD5X-7243-03E1
esuF5X-7351-50F1
dracytnarraW——1
launamnoitcurtsnIXX-7231-26B1
THANK YOU!
We are grateful you purchased this KENWOOD repeater.
We believe this easy-to-program repeater will be highly
effective in your communications system, and will keep
personnel operating at peak efficiency.
KENWOOD incorporates the latest in advanced
technology into all of our products. As a result, we feel
strongly that you will be pleased with the quality and
features of this product.
FEATURES
You can easily program channel data using the KPG-66D
software on a PC.
You can recall 1 of 16 preset channels using either a PF key or
the external control line.
The firmware can be written to the Flash memory through an
external source.
QT/DQT signalling can be programmed on each channel. It
simultaneously decodes up to 16 different QT/DQT tones.
When using the KPG-66D, RX PLL lock voltage, RX input signal
strength, TX PLL lock voltage, TX output power, and the power
supply voltage can be monitored on a PC.
The interface port can be used with external equipment, such
as a repeater controller.
The repeater has multi-mode capability.
Wide: 30 kHz, 25 kHz/ Narrow: 15 kHz,12.5 kHz (TKR-750)
Wide: 25 kHz/ Narrow: 12.5 kHz (TKR-850)
You can adjust the following functions from a PC:
CW ID Deviation
DQT Deviation
Maximum Deviation
QT Deviation
Remote TA
Repeat Gain Level
TX Power
RX Audio Signal Output (RA)
RX Detector Signal Output (RD)
Signalling Balance
Signalling Deviation (SD)
Squelch (Analog/ RSSI)
Test Tone Deviation
TX Audio Input (TA)
Voting Tone Level
PRECAUTIONS
Do not expose the unit to rain or moisture; to prevent fire or
electric shock.
Do not open the unit under any circumstances; to avoid risk of
electric shock.
Do not expose the unit to long periods of direct sunlight, nor
place it close to heating appliances.
Do not place the unit in excessively dusty and/or humid areas,
nor on unstable surfaces.
If you detect an abnormal odor or smoke coming from the unit,
disconnect the power from the unit immediately. Contact your
KENWOOD service center or dealer.
REPEATER OPERA TION
Note: Please consult your dealer for programming the repeater.
When power is applied to the unit, the POWER indicator
lights green.
Turn the VOLUME control clockwise until a click sounds,
to unmute the volume. Rotate to adjust the volume. Turn
the VOLUME control counterclockwise fully to mute the
volume.
The BUSY indicator lights green while receiving a signal,
and the TX indicator lights red while transmitting.
qq
qq
qSpeaker
ww
ww
wDisplay
Two, 7-segment digits display the channel number
or status.
ee
ee
eVOLUME control
Turn clockwise until a click sounds, to unmute the
volume. Rotate to adjust the volume. Turn
counterclockwise fully to mute the volume.
rr
rr
rPower switch
tt
tt
tPOWER indicator
Lights green when power is applied from the DC
jack. Lights red when power is applied from the
BACKUP battery terminal.
yy
yy
yMICROPHONE jack
Connect a microphone to this 8-pin modular jack.
uu
uu
uProgrammable Function keys
Press these keys to activate their programmable
functions.
ii
ii
iBUSY indicator
Lights green while a signal is being received.
oo
oo
oTX (transmit) indicator
Lights red while transmitting.
Rear Panel
qq
qq
qRX IN jack
Connect a RX antenna or a duplexer to this BNC
receptacle.
ww
ww
wFUSE
Insert a 6 A blade fuse into this fuse holder.
ee
ee
eDC 13.8V jack
Connect a 13.6 V DC power supply to this jack.
rr
rr
rBACKUP battery terminal
tt
tt
tCONTROL I/O jack
Connect an external programming device or
repeater controller to this DB-25 interface.
yy
yy
yTEST/SPKR jack
Test input/output jack. Connect an external
speaker to this jack.
uu
uu
uTX OUT jack
Connect a TX antenna or a duplexer to this BNC
receptacle.
TRANSCEIVER OPERA TION
Receive
Adjust the volume to your desired level. You may
need to readjust the volume when you receive a
message from your dispatcher or another member in
your fleet.
The BUSY indicator lights while a signal is being
received.
Transmit
1Listen to the channel before transmitting, to make
sure it is not being used.
2Press the microphone PTT switch and speak in
your normal speaking voice.
FCC regulations require that you identify the
station you are calling as well as your own
station (your assigned call sign).
The TX indicator lights while transmitting.
3When you finish speaking, release the PTT switch.
CONTROLS AND FUNCTIONS
Front Panel
