King of Fans 29523-71523 Low Voltage LED Bluetooth Audio Path Light User Manual

King of Fans, Inc. Low Voltage LED Bluetooth Audio Path Light Users Manual

Users Manual

2HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
Care & Cleaning
Bluetooth Pairing
Bluetooth Audio Play
Troubleshooting
Warranty
Before attempting to clean the xtures, disconnect the power to the xtures by unplugging the transformer from the outlet.
To clean the xtures, use a dry or slightly dampened, clean cloth.
Do not use cleaners with chemicals, solvents, or harsh abrasives, as damage to the xtures may occur.
The Bluetooth audio path light kit is compatible with iPhone, iPad, Android, Blackberry, or similar devices whose Bluetooth protocol is compatible with 3.0+EDR
protocol. To pair, ensure that the audio path lights are plugged in and powered up. In the rst 30 seconds, the primary audio path light and the other three
secondary audio path lights (labeled on the wire) will pair with each other and synchronize automatically. At the same time, the Bluetooth function is available
for pairing.
Follow the below instructions to pair your audio path lights with your music source.
Position the Bluetooth device within 33 feet (10 meters) from the primary audio path light.
On your Bluetooth device, search for a new Bluetooth device called “Path Light ****” under the list of devices available. Please note that **** will actually be
a number that corresponds to your specic set of path lights.
If you are asked for a password, enter ‘1234’. Pairing is successful when you hear a short conrmation tone from the audio path lights.
Start streaming audio from your music source.
When the audio path light is turned ON, for the rst 15 seconds it will automatically search for the last device it was connected to. Most of the Bluetooth audio
sources support this function, but some of them might not. In this case, you must manually set up the connection again. If the previous Bluetooth device is not
available, the audio path light will search for new devices.
For some Bluetooth devices and mobile phones, ‘Stereo Speaker’ mode should be enabled to stream audio wirelessly.
The audio path light is compatible with the 3.0+EDR protocol. Full Bluetooth functionality and volume control cannot be guaranteed if the audio source has an
older Bluetooth protocol.
To pair to a new Bluetooth device, you need to disable the current paired device. After about 30 seconds, the audio path light will be available for the new device.
Once paired, you will be able to control the playback and volume through your device.
If available on your device, access the sound settings or equalizer settings. Selecting the correct audio prole or sometimes turning off the equalizer
will improve the quality and maximum volume of the playback.
If you should wander out of range of the Bluetooth device, simply move closer to the primary audio path light. No pairing actions will be needed if the
lost connection is regained within 30 minutes; the devices will regain the lost connection automatically. If the lost connection is more than 30 minutes,
you are required to manually connect the Bluetooth device and audio path light again.
The Bluetooth audio path lights feature a built-in privacy mode which disconnects speaker playback when a phone call is being received from the
device. It will automatically resume playback when the call is completed.
Since the lights are activated by photo sensors independently from the audio function, audio play operation is not affected during day or night hours.
The manufacturer warrants this product to be free for two (2) years against any defects that are due to faulty materials or workmanship. This warranty applies only
to the original consumer and only to products used in normal use and service. If this product is found to be defective, the manufacturer’s only obligation, and your
exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion, provided that the product has not been damaged through misuse,
abuse, accident, modications, alterations, neglect or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, set
up, or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an
accident, misuse, abuse, negligence, alteration, or faulty installation or any other failure not relating to faulty workmanship. This warranty shall not apply to the nish
on any portion of the product, such as surface and/or weathering, as this is considered normal wear and tear. The manufacturer does not warrant and specically
disclaims any warranty, whether expressed or implied, or tness for a particular purpose, other than the warranty contained herein. The manufacturer specically
disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including any labor/expense costs involved in the replacement or
repair of said product.
Contact the Customer Service Team at 1-877-527-0313 or visit www.HomeDepot.com.
Problem Possible Cause Solution
The lights do not turn
on at night. There is no power.
There is a disconnected wire/
break in the wire.
The audio lights are installed
too close to a light source.
Check the outlet and ensure that a breaker or GFI circuit has not been tripped.
Follow the wires from the xture and ensure a continuous connected path back to the
transformer.
Move the audio path lights away from other xtures or light sources.
The lights do not turn
off during the day. The audio path lights are in
too much shade. Move the audio path lights to an area with adequate light (away from shrubs and trees).
One xture light
ickers. There is a loose wire
connector to the xture. Tighten the wire connector, and ensure the metal contacts pierce the insulation on the low
voltage cable from the transformer.
All of the lights
icker. There is a loose connection
at the transformer. Unplug the transformer from the outlet and visually inspect the positive and negative con-
necting posts. Each wire should be securely screwed in and not in contact with any other.
The light is on, but
there is no audio. The lights did not power up
at the same time. Unplug the transformer from the outlet and plug it back in again.
The audio is
distorted. There is interference with the
Bluetooth signal. Unplug the transformer from the outlet and plug it back in again.
Ensure your Bluetooth device is within 33 ft. (10m) from the primary audio path light.
Ensure the distance between the primary audio path light and the secondary xtures is no
more than 33 ft. (10m) and there is a line of sight between the xtures.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
