KingBoard Technology KTS170A BLUETOOTH SPEAKER User Manual Bluetooth Speaker
Shenzhen KingBoard Technology Co., Ltd. BLUETOOTH SPEAKER Bluetooth Speaker
User Manual
Shenzhen KingBoard Technology Co., Ltd.
Bldg. A, Dakanglong Industry Zone Dabuxiang, Guanlan,Shenzhen,
China
Bluetooth Speaker
MODEL NO.: KTS-170A
Specification:
Product Size: 60*60MM
Impedance: 4ohm
Rated Power:3W
Bluetooth Parameter
Bluetooth version : V2.1+EDR
Operation Frequency: 2. 400GHz -2. 480GHz
Power Output (peak): Class 2/4 dbm
Operation Range: 10M
Battery Parameter
Capacity： 300mAh, Polymer Li-ion Battery
Music Playback time： 2.5 Hours at 70% volume
Charging voltage： DC5V/300MA
Charging Time： 2hours
Accessory：
USB charging cable: 1 piece;
3.5MM audio cable: 1 piece;
User manual: 1 piece
Connect to Bluetooth device
Turn on the speaker unit and the Bluetooth switch on your mobile or other device and search for
the speaker model name "BT107".Pair the device.
Once device is paired Bluetooth will automatically connect when unit is turned on subsequently.
Answer a call with hands free function:
When a call comes through, press “ ” to get through the call. The speaker includes a
microphone to allow you to answer the caller. Press “ ”'again to hang up the call when end
of talking.
Bluetooth
Turn off the speaker, It come into the Bluetooth model directly .After pair the device, it can play
the music, Short time Press the " " to Play/Pause, press the " / "and the " / " to
Prev and Next. Long time press the" / " and " / " button to turn down and turn up the
Volume.
AUX-IN
AUX-IN, Using the audio cable into AUX solt, it automatically shift its status and into Aux model.
Long time press the" / " and " / " button to turn down and turn up the Volume.
In the AUX IN status, it couldn’t shift Prev and Next by Bluetooth speaker, but can control by
connection device.
USB/TF Card
Insert the U flash memory or Micro-TF card into the USB/TF slot., BT-3118 will read the MP3
format music automatically. Press the “ ” to Play/Pause, short time press the" / " and
the" / "to Prev. and Next, Long time press the" / "and " / "button to turn down
and turn up the Volume.
FM RADIO
Press “ ”to search FM channel automatically .This operation will
scan all FM stations and Pre-record them to memory. The scan procedure
will take several minutes to complete and should not be interrupted. Once
complete , you can short press " / " or / " to move forward or
backward. Long press " / " or / " button to turn down or turn up
Volume.
NOTE: connected the cable into AUX Port can received the FM radio
clearly. Beacuse it is the same function as antenna
Charging
Plug the USB cable into speaker MICRO USB port and connect to power source.
Red LED on panel when charging.
When charging is complete, the red LED will be off.
FCC Warning Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Caution: Any changes or modifications to this device not explicitly
approved by manufacturer could void your authority to operate this
equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
