Kingsun TM-003 Manual for Bluetooth Music Yoga Matt User Manual
Shenzhen Kingsun Enterprises Co., Ltd. Manual for Bluetooth Music Yoga Matt
Kingsun >
User Manual
Manual for Bluetooth Music Yoga Matt
Item number:TM-003
A: Volume + B: Volume –
C: Select button up D: Select button down
E：Play or pause F: Indicator light
G: Build-in Battery 800mAh H: Power interface
I:Power ON/OFF J:LINE in/AUX in
Produce solution
Power on, if you connect LINE,then LINE default. No LINE,then Bluetooth default.
When the voltage of the product is lower than3.3v,will have a warning tone. When the voltage is or lower
to 3.1v, will issue a beep sound and shutdown.
Charging
1, Please choose standard power DC5V/500MA and use Micro USB for charging.
2, Charging 1.5-3hours to full power.
3 ,Initial charging time should be 12 hours to ensure battery fully activated.
4, When product in charging, the red indicator light on.
5, When red indicator lights off, means power is full.
Operation Instructions
1,Switch power on,and Music Matt will have a response ring, the blue&red indicator will light on and
• When linked with Bluetooth
1，
Short press to next song.
2，Short press to last song.
3, Short press to play or to pause..
4，Long press Volume up.
5，Long press Volume down.
TM-003 丝印
VOL-
VOL+
TM-003 丝印
VOL-
VOL+
TM-003 丝印
VOL- VOL+
DC 5V OFFON AUX
TM-003 丝印
VOL- VOL+
DC 5V OFFON AUX
AB
C D
F
E
G
HIJ
• When Line in(Aux in)
1，Long press Volume up.
2，Long press Volume down.
3， , and are invalid.
VOL-
VOL+
VOL-
VOL+
TM-003 丝印
VOL- VOL+
TM-003 丝印
VOL- VOL+
• When linked with Bluetooth
2,Bluetooth connected/playing/pause, blue light long light on.
• Line in(Aux in)
Blue indicator light on
• when in Charging
When in charging, red indicator light on. When power is full, red indicator will light off.
Category Program Description
Bluetooth
Standard Bluetooth 3.0+EDR
Frequency range 2.4 ～2.48GHz
Range ≤10meters
Communication protocol HSP/HFP、A2DP、AVRCP、
HT6809 Dual channel stereo
output
Audio
Speaker 3W
Output Power 3W
Frequency response 150Hz-15KHz
Power supply
Impedance 4R
The battery type Built-in rechargeable battery 800mAh
Charging voltage DC5V
Warning: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority
to operate the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
