- Kodak EasyShare M753/M853/MD853 zoom digital camera
- Product features
- Table of contents
- Setting up your camera
- Taking pictures/videos
- Working with pictures/videos
- Doing more with your camera
- Changing picture-taking settings
- Customizing your camera
- Using exposure compensation to adjust picture brightness
- Using the framing grid to compose a picture
- Sharing your pictures
- Transferring and printing pictures
- Installing the software
- Transferring pictures with the USB cable
- Printing pictures
- Dock compatibility for your camera
- Troubleshooting
- Getting help
- Appendix
- Index
Eastman Kodak Company
Rochester, NY 14650
© Eastman Kodak Company, 2007
All screen images are simulated.
Kodak, EasyShare, and Perfect Touch are trademarks of Eastman Kodak Company.
P/N 4J6215_en
Product features
www.kodak.com/go/support i
Front view
1 Shutter button 7Lens
2Mode dial 8 Speaker
3Flash button 9 USB
4 On/Off button 10 DC-In (5V) , for optional AC adapter
5 Flash 11 Microphone
6 Self-timer/video light
5
4
1
8
6
2
3
7
9
10
11
ii www.kodak.com/go/support
Product features
Back view
1 LCD 9 Slot for optional SD or MMC card
2 Ready/Battery charging light 10 Battery compartment
3 LCD/Info button 11 Share button
4 Delete button 12 Menu button
5 Zoom button (Wide/Telephoto) 13 Review button
6 14 Dock connector
7 OK button 15 Tripod socket
8Strap post
2
6
1
10
11
12
13
7
14
5
optional
8
9
3 4
15
www.kodak.com/go/support iii
Table of contents 1
1 Setting up your camera .........................................................................1
Attaching the strap ....................................................................................... 1
Loading the KLIC-7001 battery......................................................................1
Charging the battery with the USB cable ....................................................... 2
Turning on the camera ..................................................................................3
Setting the language, date/time..................................................................... 3
Storing pictures on an SD or MMC card .........................................................4
2 Taking pictures/videos ...........................................................................5
Taking a picture ............................................................................................5
Taking a video ..............................................................................................6
Using optical zoom ....................................................................................... 7
Using the flash.............................................................................................. 8
Using different picture-taking modes ............................................................. 9
Using camera Help...................................................................................... 11
Taking panoramic pictures...........................................................................12
Understanding the picture-taking icons........................................................13
3 Working with pictures/videos ..............................................................14
Reviewing pictures/videos ........................................................................... 14
Deleting pictures/videos .............................................................................. 16
Using Kodak Perfect Touch technology ........................................................17
Cropping pictures........................................................................................ 17
Editing videos ............................................................................................. 18
Running a slide show ..................................................................................19
Copying pictures/videos............................................................................... 21
Understanding the review icons................................................................... 22
4 Doing more with your camera .............................................................24
Changing picture-taking settings ................................................................. 24
Customizing your camera ............................................................................28
Using exposure compensation to adjust picture brightness...........................31
iv www.kodak.com/go/support
Table of contents
Using the framing grid to compose a picture................................................31
Sharing your pictures...................................................................................31
5 Transferring and printing pictures .......................................................39
Installing the software................................................................................. 39
Transferring pictures with the USB cable...................................................... 40
Printing pictures.......................................................................................... 41
Dock compatibility for your camera.............................................................. 43
6 Troubleshooting ..................................................................................44
Camera problems........................................................................................ 44
Camera/computer communications.............................................................. 47
LCD screen messages .................................................................................. 47
7 Getting help ........................................................................................50
8 Appendix .............................................................................................52
Camera specifications .................................................................................52
Care and maintenance ................................................................................54
Upgrading your software and firmware........................................................ 55
Storage capacities ....................................................................................... 55
Important safety instructions .......................................................................55
Battery life .................................................................................................. 56
Limited Warranty ........................................................................................57
Regulatory compliance ................................................................................ 59
2www.kodak.com/go/support
Setting up your camera
Charging the battery with the USB cable
NOTE: If the battery charging light does not turn on, ensure:
■The USB cable is connected to the computer’s USB port, not a USB HUB
■The computer is turned on and not in sleep mode
NOTE: Rechargeable batteries have a limited number of charging cycles. Battery life and number of charge
cycles vary by use and settings.
Other battery charging accessories that may be sold separately include:
■Kodak EasyShare camera dock
■Kodak EasyShare printer dock
To purchase accessories, visit: www.kodak.com/go/m753accessories,
www.kodak.com/go/m853accessories, www.kodak.com/go/md853accessories.
To learn more about battery charging, visit www.kodak.com/go/support.
USB computer Kodak 5V AC adapter
(May be sold separately)
USB cable
Battery charging light:
On—charging
Off—fully charged (up to 3 hours)
Ready/Battery
charging light
Setting up your camera
www.kodak.com/go/support 3
Turning on the camera
Setting the language, date/time
NOTE: To change the date/time and language in the future, use the Menu button (see page 29).
2
1
to change.
for previous/next field.
OK to accept.
At the prompt, press OK.
2
1to change.
OK to accept.
Language:
Date/Time:
4www.kodak.com/go/support
Setting up your camera
Storing pictures on an SD or MMC card
Your camera has internal memory. You can purchase an SD or MMC card to
conveniently store more pictures and videos (www.kodak.com/go/m753accessories,
www.kodak.com/go/m853accessories, www.kodak.com/go/md853accessories). We
recommend Kodak SD or MMC cards.
NOTE: When using the card for the first time, format the card in this camera before taking pictures
(see page 30). To choose a storage location for pictures and videos, see page 28.
CAUTION:
A card can only be inserted one way; forcing it may cause
damage. If you insert or remove a card while the camera is
accessing it, the card, pictures, or camera may be damaged.
See page 55 for storage capacities.
1Turn off the camera.
2Insert or remove the
optional card.
3Turn on the camera.
www.kodak.com/go/support 5
2Taking pictures/videos
Taking a picture
Reviewing the picture just taken
After you take a picture or video, the LCD displays a quickview for approximately 10
seconds. (To exit the quickview sooner, press the Shutter button halfway.)
To review pictures/videos anytime, see page 14.
1
Press the Shutter button
halfway to focus and set
exposure.
When the framing
brackets turn green, press
the Shutter button
completely down.
Framing marks
2
3
The picture is saved
unless you press the
Delete button.
Delete
Press to play a video.
to adjust the volume
during playback
6www.kodak.com/go/support
Taking pictures/videos
Using the framing marks to take pictures
Framing marks indicate the camera focus area. The camera attempts to focus on
foreground subjects, even if the subjects are not centered in the scene.
1Press the Shutter button halfway.
When the framing marks turn green, focus is
accomplished.
2If the camera is not focusing on the desired subject
(or if the framing marks disappear), release the
Shutter button and recompose the scene.
3Press the Shutter button completely down to
take the picture.
NOTE: Framing marks do not appear in all modes. When you use AF Zone and set Center Zone, the framing
marks are fixed at Center Wide.
Taking a video
Framing marks
1
Press the Shutter button
completely down and
release.
To stop recording, press
and release the Shutter
button again.
2
3
Taking pictures/videos
www.kodak.com/go/support 7
Using optical zoom
Use optical zoom to get up to 3X closer to your subject.
1Use the LCD to frame your subject.
2Press Telephoto (T) to zoom in. Press Wide Angle
(W) to zoom out.
The zoom indicator shows zoom status.
3Take the picture or video.
NOTE: For focus distances, see page 52.
■Always use the auto focus framing marks,
page 6.
■If you are not using zoom (1X, wide angle), you
can be as close as 24 in. (60 cm) to your
subject.
■As you zoom, you need to move further from
your subject.
Using the digital zoom
Use digital zoom in any Still mode or during video recording to get up to 5X
magnification beyond optical zoom.
1Press Telephoto (T) to the maximum optical zoom limit. Release the button, then
press it again.
2Take the picture.
NOTE: You may notice decreased image quality when using digital zoom. The slider on the zoom indicator
turns red when the picture quality reaches the limit for an acceptable 4 x 6-in. (10 x 15 cm) print.
Optical
zoom
range
Digital
zoom
range
WTD
8www.kodak.com/go/support
Taking pictures/videos
Using the flash
Use the flash when you take pictures at night, indoors, or outdoors in heavy shadows.
Flash-to-subject distance
Zoom position Flash distance
Wide angle 0.6–3.5 m (2–11.5 ft) @ ISO 200
Telephoto 0.6–2.0 m (2–6.6 ft) @ ISO 200
Flash modes Flash fires
Auto
Flash
When the lighting conditions require it.
Fill Every time you take a picture, regardless of the lighting conditions. Use when
the subject is in shadow or is “backlit” (when the light is behind the subject).
In low light, hold the camera steady or use a tripod.
Red-
eye
If Red-eye Pre-flash is turned off:
■The flash fires once and the
camera automatically
corrects red-eye in the
picture.
If Red-eye Pre-flash is turned on:
■The flash fires once so the eyes
become accustomed to the flash, then
fires again when the picture is taken.
To turn the Red-eye Pre-flash feature on/off, see page 30.
Off Never.
Press the
The current flash mode appears in the LCD screen.
button repeatedly to scroll
through flash modes (see Flash modes below).
Taking pictures/videos
www.kodak.com/go/support 9
Using different picture-taking modes
Use this mode For
Auto General picture taking—offers an excellent balance of image quality
and ease of use.
Digital Image
Stabilization
Minimizing the effects of camera shake and subject movement.
Close-up Close range. Use available light instead of flash if possible.
Scene Point-and-shoot simplicity when taking pictures under special
conditions. (See page 10.)
High ISO People in low-light scenes indoors using a higher ISO.
Video Capturing video with sound. (See page 6.)
Favorites Reviewing favorite pictures. (See page 14.)
Choose the mode that best suits
your subjects and surroundings.
SCN
ISO
10 www.kodak.com/go/support
Taking pictures/videos
Scene modes
Choose a Scene mode—for great pictures in practically any situation!
1Turn the Mode dial to Scene .
2Press to display Scene mode descriptions.
If the mode description turns off before you finish reading it, press OK.
3Press OK to choose a Scene mode.
Use this
SCN mode
For
Portrait Full-frame portraits of people.
Panorama
Left-Right
Stitching up to 3 captured images from left to right into one image.
Panorama
Right-Left
Stitching up to 3 captured images from right to left into one image.
Sports Subjects in motion.
Landscape Far-away scenes. The camera uses infinity auto-focus. Auto-focus framing
marks are not available in Landscape.
Night
Portrait
Reducing red eye of people in night scenes or low-light conditions. Place the
camera on a flat, steady surface or use a tripod.
Night
Landscape
Distant scenery at night. Flash does not fire. Place the camera on a flat, steady
surface or use a tripod.
Snow Bright snow scenes.
Beach Bright beach scenes.
Text/
Document
Documents. Focus is set to Auto Focus (see page 27).
Fireworks Bright, colorful light displays. Flash does not fire. Place the camera on a flat,
steady surface or use a tripod.
Flower Close-ups of flowers or other small subjects in bright light. Focus is set to Auto
Focus (see page 27).
view single picture.
Taking pictures/videos
www.kodak.com/go/support 11
Using camera Help
To better understand each menu option, use camera Help. Select an option you want
to learn more about, then press the button.
Manner/
Museum
Quiet occasions, like a wedding or lecture. Flash and sound are disabled.
Self-
Portrait
Close-ups of yourself. Assures proper focus and minimizes red eye.
Children Action pictures of children in bright light.
Backlight Subjects that are in shadow or “backlit” (when light is behind the subject).
Candle light Capturing subjects in low light.
Sunset Capturing the deep hues seen at sunset.
Use this
SCN mode
For
Turn on/off Help
Scroll up/down
12 www.kodak.com/go/support
Taking pictures/videos
Taking panoramic pictures
Use panorama to “stitch” up to 3 pictures into a panoramic scene.
NOTE: For best results, use a tripod. Individual pictures are not saved, even if panorama capture is
cancelled before stitching occurs. (Picture size is set to 3.1 MP for each picture. Exposure
Compensation, White Balance, AF Zone, AF Control, and Color Mode are set with the first picture.
The flash is set to Off.)
1Turn the Mode dial to SCN.
2Press on the 4-way button to highlight Panorama Left-Right or Panorama
Right-Left (depending on the direction you want to pan), then press the OK
button.
3Take the first picture.
After a quickview, the LCD displays the liveview and an “overlay” from the first picture.
4Compose the second picture. Make the overlay from the first picture cover the
same portion in the new picture. (You can press the Delete button to re-take a
picture.)
5If you are taking only 2 pictures, press the OK button to stitch them together.
After you take 3 pictures, the pictures are automatically stitched together.
The LCD displays a quickview for approximately 5 seconds.
1
23
Take 2 or 3
pictures.
Get 1
panoramic picture.
Taking pictures/videos
www.kodak.com/go/support 13
Understanding the picture-taking icons
In capture mode—shutter pressed halfway
Picture size
Pictures/time remaining
Storage location
Exposure metering
White balance
Low battery
Camera mode
Exposure compensation
Zoom:
Date stamp
Self-timer
Flash
ISO speed
Wide
Digital
Telephoto
Exposure compensation
Low battery
Auto Exposure/
Auto Focus warning
Album
14 www.kodak.com/go/support
3Working with pictures/videos
Reviewing pictures/videos
Press the Review button to view and work with your pictures/videos. Press Review
again to exit.
1Press the Review button.
2Press to view previous/next picture/video.
To save battery power, use an optional Kodak
EasyShare dock or Kodak 5-volt AC adapter. (Visit:
www.kodak.com/go/m753accessories,
www.kodak.com/go/m853accessories,
www.kodak.com/go/md853accessories.)
NOTE: Pictures taken at 3:2 and 16:9 picture sizes have a black bar at the top
and bottom. A video’s
duration is displayed at the top of the LCD.
Magnifying pictures
1Press the Review button.
2Press W/T to magnify 2X–8X.
3Press to view other parts of the
picture.
4Press OK to return to 1X.
NOTE: If you press while at 1X, the view changes from
single-picture to multi-up thumbnail pictures. (See page 15.)
Review
Working with pictures/videos
www.kodak.com/go/support 15
Playing a video
1Press the Review button.
2Press to find previous/next video.
3Press to play. Press OK to pause/unpause.
4Press during playback to adjust the
volume.
5Press during playback to play at 2X, 4X.
6Press during playback to reverse at 2X, 4X.
Viewing thumbnails (multi-up)
1Press the Review button.
2Press to change from single-picture view
(Still pictures only) to multi-up thumbnails.
3Press OK to return to single-picture view.
Viewing picture/video information
1Press the Review button.
2Repeatedly press the LCD/Info button to
turn on/off status icons and picture/video info.
4X
Forward
Reverse
2X
2X
Playback speed
4X 1X
16 www.kodak.com/go/support
Working with pictures/videos
Deleting pictures/videos
1Press the Review button.
2Press for previous/next picture/video.
3Press the Delete button.
4Follow the screen prompts.
Protecting pictures/videos from deletion
1Press the Review button.
2Press for previous/next picture/video.
3Press the Menu button.
4Press to highlight Protect, then press OK.
The picture/video is protected and cannot be deleted. The Protect icon appears
with the protected picture/video.
■Press the Menu button to exit the menu.
CAUTION:
Formatting internal memory or an SD or MMC card deletes all (including
protected) pictures/videos. (Formatting internal memory also deletes
email addresses, album names, and favorites. To restore them, see
EasyShare software Help.)
Working with pictures/videos
www.kodak.com/go/support 17
Using Kodak Perfect Touch technology
Kodak Perfect Touch technology helps ensure better, brighter pictures.
1Press the Review button, then for previous/next picture.
2Press the Menu button. Press to highlight Edit Picture, then press OK.
3Press to highlight Perfect Touch tech., then press OK.
The enhancement is previewed in a split screen. Press to view other parts of the
picture.
4Press OK. Follow the screen prompts to replace the original picture or to save the
enhanced picture as a new one.
NOTE: You cannot enhance previously enhanced pictures.
■Press the Menu button to exit the menu.
Cropping pictures
You can crop a picture so that only the desired portion of the picture remains.
1Press the Review button, then to find a
picture.
2Press the Menu button. Press to
highlight Edit Picture, then press OK.
3Press to highlight Crop, then press OK.
4Press Telephoto (T) to zoom in, or to move the crop box. Press OK.
5Follow the screen prompts.
The picture is cropped. The original is saved. (Cropped pictures cannot be cropped
again.)
■Press the Menu button to exit the menu.
Picture Cropped picture
18 www.kodak.com/go/support
Working with pictures/videos
Editing videos
Making a picture from a video
You can choose a single frame from a video, then make a picture suitable for printing.
1Press the Review button, then to find a video.
2Press the Menu button. Press to
highlight Edit Video, then press OK.
3Press to highlight Make Picture, then
press OK.
4Press to select a video frame.
5Follow the screen prompts to save the picture.
A picture is created. (The original video is saved.)
■Press the Menu button to exit the menu.
Trimming a video
You can delete an unwanted portion from the beginning or end of a video.
1Press the Review button, then to find a
video.
2Press the Menu button. Press to
highlight Edit Video, then press OK.
3Press to highlight Trim, then press .
4Follow the screen prompts. (Use fast-forward and
fast-reverse, if needed.)
The video is trimmed. (You can save it as a new video
or replace the original.)
■Press the Menu button to exit the menu.
Video Picture
Video Trimmed video
Working with pictures/videos
www.kodak.com/go/support 19
Making a video action print
From a video, you can make a 4-, 9-, or 16-up picture, suitable for a 4 x 6-inch
(10 x 15 cm) print.
1Press the Review button, then to find a
video.
2Press the Menu button. Press to
highlight Edit Video, then press OK.
3Press to highlight Video Action Print,
then press OK.
4Choose an option, then press OK.
Auto options: The camera includes the first and last frames, then 2, 7, or 14
equally spaced frames.
Manual options: You choose the first and last frames; the camera chooses 2, 7,
or 14 equally spaced frames.
■Press the Menu button to exit the menu.
Running a slide show
Use Slide Show to display your pictures/videos on the LCD.
Starting the slide show
1Press the Review button, then the Menu button.
2Press to highlight Slide Show, then press OK.
3Press to highlight Begin Show, then press OK.
Each picture/video is displayed once.
To interrupt the Slide Show, press OK.
Video 4-, 9-, or
16-up picture
20 www.kodak.com/go/support
Working with pictures/videos
Changing the slide show display interval
The default interval setting displays each picture for 5 seconds. You can set the display
interval from 3–60 seconds.
1On the Slide Show menu, press to highlight Interval, then press OK.
2Select a display interval.
To scroll through the seconds quickly, press and hold .
3Press OK.
The interval setting remains until you change it.
Running a continuous slide show loop
When you turn on Loop, the slide show is continuously repeated.
1On the Slide Show menu, press to highlight Loop, then press OK.
2Press to highlight On, then press OK.
3Press to highlight Begin Show, then press OK.
The slide show repeats until you press OK or until battery power is exhausted. The loop
feature remains until you change it.
Working with pictures/videos
www.kodak.com/go/support 21
Copying pictures/videos
You can copy pictures/videos from a card to internal memory or from internal memory
to a card.
Before you copy, make sure that:
■A card is inserted in the camera.
■The camera’s image storage location is set to the location from which you are
copying (see page 28).
Copy pictures/videos:
1Press the Review button, then the Menu button.
2Press to highlight Copy, then press OK.
3Press to highlight an option.
4Press OK.
NOTE: Pictures/videos are copied, not moved. To remove pictures/videos from the original location after
copying, delete them (see page 16).
Tags that you applied for print, email, and favorites are not copied. Protection settings are not
copied. To apply protection to a picture/video, see page 16.
22 www.kodak.com/go/support
Working with pictures/videos
Understanding the review icons
Pictures
Videos
Scroll arrows
Email tag
Favorite tag
Print tag/number of prints
Kodak Perfect Touch tech.
Picture number
Image storage location
Review mode
Protected
Album
Blur warning
Scroll arrows
Email tag
Favorite tag
Protected
Video number
Image storage
location
Review mode
Date/Time
Video length
Working with pictures/videos
www.kodak.com/go/support 23
Understanding blur warning icons
A picture blur warning icon is displayed during quickview and review.
Green—Picture is sharp enough for an acceptable 4 x 6-inch (10 x 15 cm) print.
Yellow—Picture may be sharp enough for an acceptable 4 x 6-inch (10 x 15 cm)
print or sharpness is not determined.
Red—Picture is not sharp enough for an acceptable 4 x 6-inch (10 x 15 cm) print.
White—Printability is still being determined.
24 www.kodak.com/go/support
4Doing more with your camera
Changing picture-taking settings
You can change settings to get the best results from your camera.
1Press the Menu button.
2Press to highlight a setting, then press OK.
3Choose an option, then press OK.
■Press the Menu button to exit the menu.
NOTE: To better understand each menu option, use camera Help. Highlight a menu choice, then press the
button. Some settings remain until you change them; others, until you change modes or
turn off the camera. Some modes offer limited settings.
Press Menu , and
OK to access settings
Options
Self-timer
Choose a self-timer setting.
10 seconds (default)—so you have time to get into the
scene.
2 seconds—for a steady, auto-shutter release on a tripod.
2-shot—one picture is taken after a 10-second delay. A
second picture is taken 8 seconds later.
Burst
Capture an expected event.
Camera takes up to 4 pictures
(3 pictures for the M853 and
MD853) while the Shutter
button is pressed. All the
pictures are saved.
Off (default)
On
NOTE: You cannot use Burst when Long Time Exposure is
turned on.
Doing more with your camera
www.kodak.com/go/support 25
Exposure Compensation
Increase or decrease
brightness before taking a
picture. (Also see page 31.)
-2.0 to +2.0 (in 0.3 increments)
Picture Size
Choose a picture resolution.
For recommended print sizes,
visit:
www.kodak.com/go/printsizes
M753 For M853
MD853
7.0 MP
(4:3)
(default)
Pictures at the highest resolution,
largest file size
8.1 MP
(4:3)
(default)
6.2 MP
(3:2)
Printing on EasyShare printer
docks and photo printers
7.2 MP
(3:2)
5.3 MP
(16:9) HDTV format in high resolution 6.1 MP
(16:9)
5.0 MP
(4:3)
Medium file size 5.0 MP
(4:3)
3.1 MP
(4:3)
Medium file size 3.1 MP
(4:3)
2.2 MP
(3:2)
Printing on EasyShare printer
docks and photo printers (at a
lower resolution than 6.2/7.2 MP)
2.2 MP
(3:2)
2.1 MP
(16:9)
HDTV format 2.1 MP
(16:9)
1.2 MP
(4:3)
Email, Internet, or to
conserve space
1.2 MP
(4:3)
Press Menu , and
OK to access settings
Options
26 www.kodak.com/go/support
Doing more with your camera
White Balance
Choose your lighting
condition.
Auto (default)—automatically corrects white balance. Ideal
for general picture taking.
Daylight—for pictures in natural lighting.
Tungsten—corrects the orange cast of household light bulbs.
Ideal for indoor pictures under tungsten or halogen lighting
without flash.
Fluorescent—corrects the green cast of fluorescent lighting.
Ideal for indoor pictures under fluorescent lighting without
flash.
Open Shade—for pictures in shade in natural lighting.
Exposure Metering
Evaluate light levels at specific
areas of a scene.
Multi-Pattern (default)—evaluates lighting conditions
throughout the image to give an optimum picture exposure.
Ideal for general picture taking.
Center-Weight—evaluates the lighting conditions of the
subject centered in the lens. Ideal for backlit subjects.
Spot—similar to Center-weighted, except the metering is
concentrated on a smaller area of the subject centered in the
viewfinder. If used with Selectable AF zones, the exposure spot
follows the focus zone. Ideal when you need an exact exposure
of a specific area in the picture.
ISO Speed
Control the camera’s
sensitivity to light.
Choose a lower ISO setting in brightly lit scenes; use a higher
ISO for low-light scenes. Choose Auto (default), 80, 100, 200,
400, 800, 1250.
NOTE: ISO returns to Auto when the camera is set to Portrait or SCN
mode.
Unavailable in Video mode.
Press Menu , and
OK to access settings
Options
Doing more with your camera
www.kodak.com/go/support 27
AF Zone
Select a large or concentrated
area of focus.
Multi-zone (default)—evaluates 5 zones to give an even
picture focus. Ideal for general picture taking.
Center-zone—evaluates the small area centered in the
viewfinder. Ideal when precise focus of a specific area in the
picture is needed.
NOTE: For the best pictures, the camera is set to Multi-zone when in
Landscape mode.
Color Mode
Choose color tones.
Unavailable in Video mode.
High Color
Natural Color (default)
Low Color
Black & White
Sepia—pictures have a reddish-brown, antique look.
NOTE: EasyShare software also lets you change a color picture to
black-and-white or sepia.
Unavailable in Video mode.
Long Time Exposure
Choose how long the shutter
stays open.
0.5 - 4.0 seconds
Set Album
Choose Album names.
Clear All—selected album settings are cancelled
Pre-select album names before you take pictures/videos. Then,
all the pictures/videos you take are tagged with those album
names. See page 37.
Press Menu , and
OK to access settings
Options
28 www.kodak.com/go/support
Doing more with your camera
Customizing your camera
Use Setup to customize your camera settings.
1In any mode, press the Menu button.
2Press to highlight Setup, then press OK.
3Press to highlight a setting, then press OK.
4Choose an option, then press OK.
Image Storage
Choose a storage location for
pictures/videos.
Auto (default)—the camera uses the card if one is in the
camera. If not, the camera uses internal memory.
Internal Memory—the camera uses internal memory, even
if a card is installed.
NOTE: If you fill up your card while taking pictures, your camera’s
memory plus feature prompts you to switch to internal
memory, if space is available. Memory plus is unavailable in
Video mode.
Maintain Settings
Choose which settings are
saved, even after the camera is
turned off.
Available only in Auto mode.
Exit (default)
Flash
White Balance
ISO Speed
Color Mode
AF Zone
Clear All
Video Size
Available only in Video mode.
640 x 480 (default)
320 x 240
Setup Menu
Choose additional settings.
See Customizing your camera on page 28.
Press Menu , and
OK to access settings
Options
Doing more with your camera
www.kodak.com/go/support 29
5Press the Menu button to exit.
NOTE: Press the LCD/Info button for information about camera settings and options. These
settings remain until you change them.
Press Menu, to highlight Setup,
then OK to access settings
Options
Return to previous menu.
Camera Sounds
Choose sound effects.
Themes—applies the same sound effect set to
all functions.
Individual—choose a sound effect for each
function.
Sound Volume Off
Low
Medium (default)
High
LCD Brightness Power Save
High Power (default)
Auto Power Off
Choose inactivity time until camera turns off.
10 minutes
5 minutes
3 minutes (default)
1 minute
Date & Time See page 3.
Video Out
Choose the regional setting that lets you
connect the camera to a television or other
external device.
NTSC (default)—used in North America and
Japan.
PAL—used in Europe and China.
Orientation Sensor
Orient pictures so that they are displayed
with the correct side up.
On (default)
Off
30 www.kodak.com/go/support
Doing more with your camera
Red-eye Pre-flash
Choose if the Red-eye flash fires
automatically before a picture is taken.
NOTE: The camera automatically corrects red-eye
when the Red-eye Pre-flash is set to Off.
On (default)
Off
Date Stamp
Imprint the date on pictures.
Choose a date option, or turn off the feature.
(Default is off.)
Video Date Display
Display Date/Time at the start of video
playback.
On (default)—choose from date formats.
Off
Blur Warning
See page 23.
On (default)
Off
Language See page 3.
Format
CAUTION:
Formatting deletes all
pictures/videos, including
those that are protected.
Removing a card during
formatting may damage
the card.
Memory Card—deletes everything on the
card; formats the card.
Cancel—exits this setting.
Internal Memory—deletes everything in
internal memory including email addresses,
album names, and favorites; formats the
internal memory.
About
View camera information.
Press Menu, to highlight Setup,
then OK to access settings
Options
Doing more with your camera
www.kodak.com/go/support 31
Using exposure compensation to adjust picture
brightness
Before you take a picture, you can adjust exposure compensation to make pictures
darker or lighter.
■Press to decrease exposure compensation.
■Press to increase exposure compensation.
The exposure compensation level is shown on the LCD; the LCD gets brighter or dimmer.
Using the framing grid to compose a picture
The framing grid divides the LCD into thirds—vertically and horizontally. This is
helpful if, for example, you want to balance a picture between water, earth, and sky.
To turn on the framing grid in Auto/SCN modes,
press the Info/Display button until the grid
appears.
Sharing your pictures
Press the Share button to tag your pictures and videos. When they are transferred to
your computer, you can share them. Use the Share button:
■Any time. (The most recent picture/video taken is then displayed.)
■Just after you take a picture/video, during quickview.
■After pressing the Review button.
32 www.kodak.com/go/support
Doing more with your camera
Tagging pictures for printing
1Press the Share button. Press to locate a picture.
2Press to highlight Print, then press OK.*
3Press to select the number of copies (0-99). Zero removes the tag for that
picture.
Optional: You can apply a print quantity to other pictures. Press to locate a
picture. Press to change the print quantity. Repeat until the desired print
quantity is applied to pictures.
4Press OK.
The Print icon appears in the status area.
5Press the Share button to exit the menu.
* To tag all pictures in the storage location, highlight Print All, press OK, then indicate
the number of copies. Print All is not available in quickview. To remove print tagging
for all pictures in the storage location, highlight Cancel Prints, then press OK. Cancel
Prints is not available in quickview.
Printing tagged pictures
When you transfer the tagged pictures to your computer, the Kodak EasyShare
software print screen opens. For details, click the Help button in EasyShare software.
For more information on printing from your computer, printer dock, PictBridge
enabled printer, or card, see page 41.
NOTE: For the best 4 x 6 in. (10 x 15 cm) prints, set the camera to the 3:2 picture size setting (see
page 25.)
Doing more with your camera
www.kodak.com/go/support 33
Tagging pictures and videos for emailing
First—on your computer
Use Kodak EasyShare software to create an email address book on your computer.
Then copy up to 32 email addresses to the camera’s internal memory. For details, click
the Help button in EasyShare software.
Second—tag pictures/videos on your camera
1Press the Share button. Press to locate a picture/video.
2Press to highlight Email, then press OK.
The Email icon appears in the status area.
3Press to highlight an email address, then press OK.
4To tag other pictures/videos with the same address, press to scroll through
them. When the picture you want is displayed, press OK.
5To send the pictures/videos to more than one address, repeat step 3 for each
address.
Selected addresses are checked.
6To remove a selection, highlight a checked address and press OK. To remove all
email selections, highlight Clear All.
7Press to highlight Exit, then press OK.
8Press the Share button to exit the menu.
Third—transfer and email
When you transfer the tagged pictures/videos to your computer, the Email screen
opens and lets you send them to the addresses you specified. For details, click the
Help button in Kodak EasyShare software.
34 www.kodak.com/go/support
Doing more with your camera
Tagging pictures as favorites
You can preserve your favorite pictures in the Favorites section of your camera’s
internal memory, then share them with friends and family.
NOTE: When you transfer pictures from your camera to your computer, all pictures (including favorites) are
stored on your computer at full size. Favorite pictures - smaller copies of your originals - are loaded
back to your camera, so you can share and enjoy more.
NOTE: The camera holds a limited number of favorites. Use Camera Favorites in the EasyShare software to
customize the size of your camera Favorites section. Videos tagged as favorites remain in the
Favorites folder in EasyShare software. For details, click the Help button in EasyShare software.
1. Tag pictures as
favorites
1Press the Share button. Press to locate a picture.
2Press to highlight Favorite, then press OK.
The Favorite icon appears in the status area. To remove the tag, press
OK again.
Press the Share button to exit the menu.
2. Transfer
pictures to your
computer
1To enjoy all the available features, load and use the EasyShare
software that was packaged with this camera. (See page 39.)
2Connect the camera to the computer using the USB cable (see
page 40) or an EasyShare dock.
The first time you transfer pictures, the software helps you make choices
about your favorite pictures. Then, your pictures are transferred to the
computer. Favorite pictures (smaller versions of the originals) are loaded
to the Favorites section of your camera’s internal memory.
3. View favorites
on your camera
1Turn the Mode dial to Favorites .
2Press to scroll through favorites.
Doing more with your camera
www.kodak.com/go/support 35
Optional settings
In Favorites mode, press the Menu button to access optional settings.
NOTE: Pictures taken at 3:2 and 16:9 picture sizes have a black bar at the top
and bottom. A video’s
duration is displayed at the top of the LCD.
Removing favorites from your camera
1Turn the Mode dial to Favorites .
2Press the Menu button.
3Highlight Remove Favorites, then press OK.
All pictures stored in the Favorites section of internal memory are removed. Favorites are
restored the next time you transfer pictures to the computer.
4Press the Menu button to exit the menu.
Slide Show (page 19) Remove favorites (page 35)
Multi-up (page 15) Setup Menu (page 28)
36 www.kodak.com/go/support
Doing more with your camera
Preventing camera favorites from synchronizing with the software
If you don’t want to use the favorites feature:
1Open EasyShare software.
2From the Tools menu, select Cameras/Viewers > Sync and Transfer Manager.
3Click to highlight your camera, then click Camera Favorites Album Properties.
NOTE: If your camera model is not visible, use the USB cable to connect your camera to the computer.
4Drag the Internal Memory slider to 0%, then click OK.
5Close the Sync and Transfer Manager window.
Camera favorites will no longer synchronize with EasyShare software.
To turn on the sync feature, select Yes, synchronize with my software.
To delete favorites from your camera, press the Delete button while in Favorites mode.
Printing and emailing favorites
1Turn the Mode dial to Favorites . Press to locate a picture.
2Press the Share button.
3Highlight Print or Email, then press OK.
NOTE: Favorites that were taken on this camera (not imported from another source) are good for prints up
to 4 x 6 in. (10 x 15 cm).
Tagging pictures/videos for albums
Use the Album feature in Review mode to tag the pictures/videos in your camera with
album names.
First—on your computer
Use EasyShare software to create albums on your computer, then copy up to 32 album
names to the camera’s internal memory. See EasyShare software Help for details.
Doing more with your camera
www.kodak.com/go/support 37
Second—on your camera
1Press the Review button, then locate the picture or video.
2Press the Menu button.
3Press to highlight Album, then press OK.
4Press to highlight an album folder, then press OK.
To add other pictures to the same album, press to scroll through the pictures.
When the picture you want is displayed, press OK.
To add the pictures to more than one album, repeat step 4 for each album.
The album name appears with the picture. A plus (+) after the album name means the
picture was added to more than one album.
To remove a selection, highlight an album name and press OK. To remove all album
selections, select Clear All.
Third—transfer to your computer
When you transfer the tagged pictures/videos to your computer, EasyShare software
opens and categorizes your pictures/videos in the appropriate album folder. See
EasyShare software Help for details.
Pre-tagging for album names
Use the Set Album feature to pre-select album names before you take pictures or
videos. Then, all the pictures or videos you take are tagged with those album names.
First—on your computer
Use the EasyShare software that was packaged with your camera to create album
names on your computer. The next time you connect the camera to the computer, copy
up to 32 albums to the album name list. See EasyShare software Help for details.
38 www.kodak.com/go/support
Doing more with your camera
Second—on your camera
1In any mode, press the Menu button.
2Press to highlight Set Album, then press OK.
3Press to highlight an album name, then press OK. Repeat to mark pictures
or videos for albums.
Selected albums are noted with a check mark.
4To remove a selection, highlight an album name and press OK. To remove all
album selections, select Clear All.
5Highlight Exit, then press OK.
Your selections are saved. If you turn on the LCD, your album selection is displayed on
the screen. A plus (+) after the album name means more than one album is selected.
6Press the Menu button to exit the menu.
Third—transfer to your computer
When you transfer the tagged pictures or videos to your computer, EasyShare
software opens and categorizes your pictures in the appropriate album. See EasyShare
software Help for details.
www.kodak.com/go/support 39
5Transferring and printing
pictures
Installing the software
CAUTION:
Install EasyShare software
before
connecting the camera to the
computer. Failure to do so may cause the software to load
incorrectly.
1Close all software applications that are open on your computer (including
anti-virus software).
2Place the EasyShare software CD into the CD-ROM drive.
3Load the software:
Windows OS—if the install window does not appear, choose Run from the Start
menu and type d:\setup.exe where d is the drive letter that contains the CD.
Mac OS X—double-click the CD icon on the desktop, then click the Install icon.
4Follow the on-screen instructions to install the software.
NOTE: When prompted, take few minutes to electronically register your camera and software. To register
later, visit
www.kodak.com/go/register
.
5If prompted, restart the computer. If you turned off anti-virus software, turn it back
on. See the anti-virus software manual for details.
For information on the software applications included on the EasyShare software CD,
click the Help button in EasyShare software.
40 www.kodak.com/go/support
Transferring and printing pictures
Transferring pictures with the USB cable
NOTE: Visit
www.kodak.com/go/howto
for an online tutorial on connecting.
Also available for transferring
You can also use these Kodak products to transfer your pictures and videos.
■Kodak EasyShare camera dock, Kodak EasyShare printer dock (see page 41)
■Kodak multi-card reader, Kodak SD multimedia card reader-writer
Purchase these and other accessories at a dealer of Kodak products or visit
www.kodak.com/go/m753accessories, www.kodak.com/go/m853accessories,
www.kodak.com/go/md853accessories.
Turn on the camera.
3
2Connect the USB cable (U-8).
1Turn off the camera.
Kodak EasyShare software opens on your computer
and prompts you through the transfer process.
Transferring and printing pictures
www.kodak.com/go/support 41
Printing pictures
Printing with a Kodak EasyShare printer dock
Dock your camera to the Kodak EasyShare printer dock and print directly—with or
without a computer. Purchase this and other accessories at a dealer of Kodak
products or visit www.kodak.com/go/m753accessories,
www.kodak.com/go/m853accessories, www.kodak.com/go/md853accessories.
Direct printing with a PictBridge enabled printer
Your camera is compatible with PictBridge technology, so you can print directly to
PictBridge enabled printers. You need:
■Camera with fully charged batteries
■PictBridge enabled printer
■USB cable (may be sold separately)
Connecting the camera to a PictBridge enabled printer
1Turn off the camera and printer.
2Connect the appropriate USB cable from the camera to the printer. (See your
printer user guide or visit www.kodak.com/go/m753accessories,
www.kodak.com/go/m853accessories, www.kodak.com/go/md853accessories.)
42 www.kodak.com/go/support
Transferring and printing pictures
Printing from a PictBridge enabled printer
1Turn on the printer. Turn on the camera.
The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu interface turns off, press any
button to redisplay it.
2Press to choose a printing option, then press OK.
Current Picture—Press to choose a picture. Choose the number of copies.
Tagged Pictures—If your printer is capable, print pictures that you tagged for
printing and choose a print size.
Index Print—Print thumbnails of all pictures. This option requires one or more
sheets of paper. If the printer is capable, choose a print size.
All Pictures—Print all pictures in internal memory, on a card, or in Favorites.
Choose the number of copies.
Image Storage—Access internal memory, a card, or Favorites.
NOTE: During direct printing, pictures are not permanently transferred or saved to the computer or printer.
Disconnecting the camera from a PictBridge enabled printer
1Turn off the camera and printer.
2Disconnect the USB cable from the camera and the printer.
Using a printer that is not PictBridge enabled
For details on printing pictures from your computer, click the Help button in EasyShare
software.
Transferring and printing pictures
www.kodak.com/go/support 43
Ordering prints online
Kodak
Gallery (www.kodakgallery.com) is one of the many online print services
offered in the Kodak EasyShare software. You can easily:
■Upload your pictures.
■Edit, enhance, and add borders to your pictures.
■Store pictures, and share them with family and friends.
■Order high-quality prints, photo greeting cards, frames, and albums—and have
them delivered to your door.
Printing from an optional SD/MMC card
■Automatically print tagged pictures when you insert your card into a printer with
an SD/MMC card slot. See your printer user’s guide for details.
■Make prints at an SD/MMC-capable Kodak picture maker/picture kiosk. (Contact a
location before visiting. Visit www.kodak.com/go/picturemaker.)
■Take the card to your local photo retailer for professional printing.
Dock compatibility for your camera
To see which Kodak EasyShare docks are compatible with your camera, visit
www.kodak.com/go/dockcompatibility.
Purchase camera docks, printer docks, and other accessories at a dealer of Kodak
products or visit www.kodak.com/go/m753accessories,
www.kodak.com/go/m853accessories, www.kodak.com/go/md853accessories.
44 www.kodak.com/go/support
6Troubleshooting
For step-by-step product support, visit www.kodak.com/go/m753support,
www.kodak.com/go/m853support or www.kodak.com/go/md853support, and select
Interactive Troubleshooting & Repairs.
Camera problems
If... Try one or more of the following
Camera does not
turn on.
■Remove the battery, then reinsert correctly (see page 1).
■Install new battery.
■Charge rechargeable battery (see page 2).
Camera does not
turn off.
Camera buttons
and controls do
not function
Pictures remaining
number does not
decrease after
taking a picture.
■The camera is operating normally. Continue taking pictures.
Short battery life
with Kodak Li-Ion
rechargeable
digital camera
battery KLIC-7001.
■Wipe the contacts with a clean, dry cloth (see page 54) before loading
batteries in the camera.
■Limit the following activities that quickly deplete battery power:
reviewing pictures/videos on the LCD; excessive use of the flash.
■If you own an EasyShare camera dock series 3 or EasyShare printer
dock series 3, use the Battery Refresh feature.
Troubleshooting
www.kodak.com/go/support 45
Stored pictures are
corrupted.
■Retake pictures. Do not remove card while the camera is accessing it.
Keep rechargeable batteries charged.
■Transfer pictures to the computer (see page 40), then format the card
in the camera (see page 30).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
In Review mode,
you do not see a
picture (or the
expected picture)
on the LCD screen.
■Check the image storage location setting (see page 28).
In Review mode, a
blue or black
screen is displayed
instead of a
picture.
■Transfer the picture to the computer (see page 40), then format the
card in the camera (see page 30).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
Shutter button
does not work.
■Turn on the camera (see page 3).
■Transfer pictures to the computer (see page 40), delete pictures from
the camera (see page 16), switch image storage locations (see
page 28), or insert a card with available memory (see page 4).
Picture is too light. ■Move so there is at least 2 ft (0.6 m) between the camera and the
subject.
■Decrease Exposure Compensation (see page 31).
Picture is not clear. ■Clean the lens (see page 54).
■Make sure your camera is not in Close-up mode.
■Move so there is at least 2 ft (0.6 m) between the camera and the
subject.
■Place the camera on a flat, steady surface or use a tripod.
If... Try one or more of the following
46 www.kodak.com/go/support
Troubleshooting
Picture is too dark. ■Turn on the flash (see page 8).
■Move so there is no more than 11.5 ft (3.5 m) in wide angle and
6.6 ft (2.0 m) in telephoto between the camera and the subject.
■Use Fill flash (page 8) or change your position so light is not behind
the subject.
■Increase Exposure Compensation (see page 31).
Camera does not
recognize
SD/MMC card.
■Purchase a certified SD/MMC card.
■Reformat the card (see page 30).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
■Insert a card into the slot, then push to seat (see page 4).
Camera freezes up
when a card is
inserted or
removed.
■Turn the camera off, then back on.
■Make sure the camera is turned off before inserting or removing a
card.
Memory card full. ■Insert a new card (see page 4), transfer pictures to the computer (see
page 40), or delete pictures (see page 16).
Memory card and
internal memory
full.
■Transfer pictures to the computer (see page 40), then format the card
or internal memory (see page 30).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
If... Try one or more of the following
Troubleshooting
www.kodak.com/go/support 47
Camera/computer communications
LCD screen messages
If... Try one or more of the following
The computer does
not communicate
with the camera.
■Turn on the camera (see page 3).
■Install new batteries (see page 1) or charge rechargeable batteries
(see page 2).
■Connect the USB cable to camera and computer port (see page 40).
■Install the software (see page 39).
■Disconnect the USB cable. Close all software applications. Re-install
the software (see page 39).
■Disconnect camera from the computer. Close all software applications,
reconnect camera.
Cannot transfer
pictures.
(The Add New
Hardware Wizard
cannot locate
drivers.)
■Disconnect the USB cable. (If using camera dock or printer dock,
disconnect cable and remove camera from dock). Close all open
applications. Re-install the software (see page 39).
■Disconnect the USB cable. Close all software applications. Re-install
the software (see page 39).
If... Try one or more of the following
No images to
display
■Change image storage location setting (see page 28).
Memory card
requires
formatting
■Insert a new card (see page 4) or format the card (see page 30).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
Memory card
cannot be read
(Please format
memory card or
insert another
card)
48 www.kodak.com/go/support
Troubleshooting
Only one USB
connection
allowed.
Disconnect cable
or rem. (remove)
camera from dock.
■Unplug the USB cable from the camera.
Internal memory
requires
formatting
■Format the internal memory (see page 30).
Caution: Formatting deletes all pictures and videos, including
protected files. (Formatting internal memory also deletes email
addresses, album names, and Favorites. To restore them, see the
Kodak EasyShare software Help.)
Internal memory
cannot be read
(Please format
internal memory)
No memory card
(Files not copied)
■Insert a card (see page 4).
Not enough space
to copy files (Files
not copied)
■Delete pictures from the image storage location you are copying to
(see page 16), or insert a new card (see page 4).
Memory card is
locked (Insert new
memory card)
■Insert a new card (see page 4), move the switch on the card to unlock
the card, or change the image storage location to internal memory
(see page 28).
Read-only memory
card.
Remove write
protection to
capture or write to
card.
Memory card is
unusable (Insert
new memory card)
■Insert a new card (see page 4) or format the card (see page 30).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
If... Try one or more of the following
Troubleshooting
www.kodak.com/go/support 49
Date and time
have been reset
■Reset the clock (see page 3).
No address book
on camera
(Connect with
computer to
import address
book)
■Create and copy address book from computer. See the Kodak
EasyShare software Help.
No album names
on camera
(Connect with
computer to
import album
names)
■Create and copy album names from computer. See the Kodak
EasyShare software Help.
High camera
temperature.
(Camera will be
turned off.)
■Leave the camera off for 10 minutes, then turn it back on.
Can only mark
image with 32
album names. Only
the first 32 album
names will be
saved
■Delete one or more album names associated with the image (see
page 36).
Unrecognized file
format
■Transfer the picture to the computer (see page 40), or delete it (see
page 16).
Camera error
#XXXX. See user’s
guide.
■Turn camera off, then back on.
If... Try one or more of the following
50 www.kodak.com/go/support
7Getting help
Camera
Software
Other
Email, write, or phone customer support www.kodak.com/go/contact
Get support for your product (FAQs,
troubleshooting information, arrange for repairs,
etc.)
www.kodak.com/go/m753support
www.kodak.com/go/m853support
www.kodak.com/go/md853support
Purchase camera accessories (camera docks,
printer docks, lenses, cards, etc.) www.kodak.com/go/m753accessories
www.kodak.com/go/m853accessories
www.kodak.com/go/md853accessories
Download the latest camera firmware and
software www.kodak.com/go/m753downloads
www.kodak.com/go/m853downloads
www.kodak.com/go/md853downloads
See online demonstrations of your camera www.kodak.com/go/howto
Get information on EasyShare software www.kodak.com/go/easysharesw (or click
the Help button in EasyShare software)
Get help with the Windows operating system and
working with digital pictures
www.kodak.com/go/pcbasics
Get support for other cameras, software, accessories www.kodak.com/go/support
Get information on Kodak EasyShare printer docks www.kodak.com/go/printerdocks
Get information on Kodak inkjet products www.kodak.com/go/inkjet
Optimize your printer for truer, more vibrant colors www.kodak.com/go/onetouch
Register your camera www.kodak.com/go/register
Getting help
www.kodak.com/go/support 51
NOTE: If you have questions concerning this product, you may speak with Kodak customer support.
Australia 1800 267 588 Netherlands 020 346 9372
Austria 0179 567 357 New Zealand 0800 880 120
Belgium 02 713 14 45 Norway 23 16 21 33
Brazil 0800 891 42 13 Philippines 1 800 1 888 9600
Canada 1 800 465 6325 Poland 00800 4411625
China 800 820 6027 Portugal 021 415 4125
Czech Republic 00 800 56325000 Russia 8 495 929 9166
Denmark 3 848 71 30 Singapore 800 6363 036
Ireland 01 407 3054 Slovakia 00 800 56325000
Finland 0800 1 17056 Spain 91 749 76 53
France 01 55 1740 77 Sweden 08 587 704 21
Germany 069 5007 0035 Switzerland 01 838 53 51
Greece 00800 44140775 Taiwan 0800 096 868
Hong Kong 800 901 514 Thailand 001 800 631 0017
Hungary 06 80 456 325 Turkey 00800 448827073
India 91 80 41374555
(toll free 000800 440 1227)
United Kingdom 0870 243 0270
Italy 02 696 33452 United States 1 800 235 6325
Japan 03 5540 9002 International Toll Line +44 131 458 6714
Korea 080 708 5600 International Toll Fax +44 131 458 6962
52 www.kodak.com/go/support
8Appendix
Camera specifications
For more specifications, visit www.kodak.com/go/m753support,
www.kodak.com/go/m853support, www.kodak.com/go/md853support.
CCD—1/2.5 in. CCD, 4:3 aspect ratio
Picture sizes—
Color display—6.4 cm (2.5 in.); 154K (640 x 240) pixels; 30 fps; field-of-view:
100%.
Taking lens—3X optical zoom lens f/2.8–f/5.2;
37 mm–111 mm (35 mm equivalent)
Lens barrier—Automatic built-in
Focus system—TTL-AF; selectable multi-zone AF, center-zone AF. Working range:
0.4 m (1.3 ft)–infinity @ normal
M753 M853/MD853
7.0 MP (4:3): 3056 x 2292 pixels 8.1 MP (4:3): 3296 x 2472 pixels
6.2 MP (3:2): 3056 x 2038 pixels 7.2 MP (3:2): 3296 x 2196 pixels
5.3 MP (16:9): 3056 x 1720 pixels 6.1 MP (16:9): 3296 x 1854 pixels
5.0 MP (4:3): 2592 x 1944 pixels 5.0 MP (16:9): 2592 x 1944 pixels
3.1 MP (4:3): 2048 x 1536 pixels 3.1 MP (4:3): 2048 x 1536 pixels
2.2 MP (3:2): 1800 x 1200 pixels 2.2 MP (3:2): 1800 x 1200 pixels
2.1 MP (16:9): 1920 x 1080 pixels 2.1 MP (16:9): 1920 x 1080 pixels
1.2 MP (4:3): 1280 x 960 pixels 1.2 MP (4:3): 1280 x 960 pixels
Appendix
www.kodak.com/go/support 53
0.15–0.7 m (5.9–28 in.) @ close-up/macro, wide
0.40–0.7 m (15.7–28 in.) @ close-up/macro, tele
10 m (32.8 ft)–infinity @ Landscape
Digital zoom—5.0X continuous with 0.2X increments
Exposure metering—Multi-pattern, Center-weight, Spot
Exposure compensation—+/-2.0 EV with 0.3 EV steps
Shutter speed—Mechanical shutter with CCD; Auto: 4–1/1400 sec.
ISO speed—Auto: 80–200; Digital Image Stabilization, High ISO: 80–1000
Manual: 80, 100, 200, 400, 800, 1250 (selectable)
Electronic flash—Guide no. 7.0 (@ ISO 100); auto flash working range at ISO 200:
Wide: 0.6–3.5 m (2–11.5 ft.); Tele: 0.6–2.0 m (2–6.6 ft.)
Flash modes—Auto, Off, Fill, Red-eye
Capture modes—Auto, Digital Image Stabilization, Close-up, SCN, High ISO, Video
Video capture—VGA (640 x 480) @ 15 fps; QVGA (320 x 240) @ 30 fps
Image file format—Still: EXIF 2.21 (JPEG compression); file organization: DCF
Video: MOV; CODEC Motion JPEG; G.711 (audio)
Image storage—Optional SDHC/SD/MMC Card . (The SD logo is a
trademark of the SD Card Association.)
Internal storage capacity—16 MB internal memory/11 MB available for image
storage (1 MB equals one million bytes)
Power—Kodak Li-Ion rechargeable digital camera battery KLIC-7001; 5V AC adapter
Communication with computer—USB 2.0 Full Speed (PIMA 15740 protocol), via
USB cable model U-8, EasyShare camera dock or printer dock
PictBridge support—Yes
Self Timer—2 seconds, 10 seconds, or 2-shot
White balance—Auto, Daylight, Tungsten, Fluorescent, Open Shade
54 www.kodak.com/go/support
Appendix
Auto power off—Selectable 1, 3, 5, 10 minutes
Microphone—Yes (for audio recording at Video mode)
Color modes—Color (high, natural, low), Black & White, Sepia
Tripod mount—1/4 inch
Operating temperature—32–104°F (0–40°C)
Size—93 mm (3.7 in.) x 58 mm (2.3 in.) x 23 mm (0.9 in.) @ power off
Weight—145 g (5.1 oz.) without battery or card
Care and maintenance
■If you suspect water has gotten inside the camera, remove the battery and card.
Allow all components to air-dry for at least 24 hours before using the camera.
■Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,
lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.
■Service agreements may be available in your country. Contact a dealer of Kodak
products for more information.
■For digital camera disposal or recycling information, contact your local authorities.
In the US, visit the Electronics Industry Alliance Web site at www.eiae.org or the
Kodak Web site at www.kodak.com/go/m753support,
www.kodak.com/go/m853support, www.kodak.com/go/md853support.
Appendix
www.kodak.com/go/support 55
Upgrading your software and firmware
Download the latest versions of the software included on the Kodak EasyShare
software CD and the camera firmware (the software that runs on the camera). Visit
www.kodak.com/go/m753downloads, www.kodak.com/go/m853downloads,
www.kodak.com/go/md853downloads.
Storage capacities
The LCD displays the approximate number of pictures (or minutes/seconds of video)
remaining. For average SD card capacities, visit www.kodak.com/go/SDcapacities.
Actual storage capacity varies depending on subject composition, card size, and other
factors. You may be able to store more or fewer pictures and videos. Favorites take up
additional space in internal memory.
Important safety instructions
CAUTION:
Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. Kodak AC adapters
and battery chargers are intended for indoor use only. The use of controls,
adjustments, or procedures other than those specified herein may result
in exposure to shock and/or electrical or mechanical hazards. If the LCD
breaks, do not touch the glass or liquid. Contact Kodak customer support.
■The use of an accessory that is not recommended by Kodak may cause fire, electric
shock, or injury. For approved accessories, visit www.kodak.com/go/accessories.
■Use only a USB-certified computer equipped with a current-limiting motherboard.
Contact your computer manufacturer if you have questions.
■If using this product in an airplane, observe all instructions of the airline.
■When removing the battery, allow it to cool; it may be hot.
■Read and follow all warnings and instructions supplied by the battery
manufacturer.
56 www.kodak.com/go/support
Appendix
■Use only batteries approved for this product to avoid risk of explosion.
■Keep batteries out of the reach of children.
■Do not allow batteries to touch metal objects, including coins. Otherwise, a battery
may short circuit, discharge energy, become hot, or leak.
■Do not disassemble, install backward, or expose batteries to liquid, moisture, fire,
or extreme temperature.
■Remove the battery when the product is stored for an extended period of time. In
the unlikely event that battery fluid leaks inside the product, contact Kodak
customer support.
■In the unlikely event that battery fluid leaks onto your skin, wash immediately with
water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.
■Dispose of batteries according to local and national regulations. Visit
www.kodak.com/go/kes.
■Do not charge non-rechargeable batteries.
For more information on batteries, visit www.kodak.com/go/batterytypes.
Battery life
For acceptable battery life, and to make sure your camera operates dependably, use
the batteries listed. Actual battery life may vary based on usage.
0
Approximate number of pictures in Auto mode
(CIPA testing method using internal memory.)
400
Kodak Li-Ion rechargeable
digital camera battery KLIC-7001
200
250-350
Appendix
www.kodak.com/go/support 57
Extending battery life
■See Auto Power Off (see page 29).
■Limit the following activities that quickly deplete battery power:
– Reviewing your pictures on the LCD (see page 14)
– Excessive use of the flash
■Dirt on the battery contacts can affect battery life. Wipe the contacts with a clean,
dry cloth before loading batteries in the camera.
■Battery performance is reduced at temperatures below 41° F (5° C). When using
your camera in cold weather, carry spare batteries and keep them warm. Do not
discard cold batteries that do not work; when they return to room temperature,
they may be usable.
Limited Warranty
Kodak warrants Kodak consumer electronic products and accessories (“Products”),
excluding batteries, to be free from malfunctions and defects in both materials and
workmanship for one year from the date of purchase.
Retain the original dated sales receipt. Proof of the date of purchase will be required
with any request for warranty repair.
Limited warranty coverage
Warranty service is only available from within the country where the Products were
originally purchased. You may be required to ship Products, at your expense, to the
authorized service facility for the country where the Products were purchased.
Kodak will repair or replace Products if they fail to function properly during the
warranty period, subject to any conditions and/or limitations stated herein. Warranty
service will include all labor as well as any necessary adjustments and/or replacement
parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option,
refund the purchase price paid for the Product provided the Product has been
returned to Kodak along with proof of the purchase price paid. Repair, replacement,
or refund of the purchase price are the sole remedies under the warranty.
58 www.kodak.com/go/support
Appendix
If replacement parts are used in making repairs, those parts may be remanufactured,
or may contain remanufactured materials. If it is necessary to replace the entire
Product, it may be replaced with a remanufactured Product. Remanufactured
Products, parts, and materials are warranted for the remaining warranty term of the
original Product, or 90 days after the date of repair or replacement, whichever is
longer.
Limitations
This warranty does not cover circumstances beyond Kodak’s control. This warranty
does not apply when failure is due to shipping damage, accident, alteration,
modification, unauthorized service, misuse, abuse, use with incompatible accessories
or attachments (such as third party ink or ink tanks), failure to follow Kodak’s
operation, maintenance, or repacking instructions, failure to use items supplied by
Kodak (such as adapters and cables), or claims made after the duration of this
warranty.
Kodak makes no other express or implied warranty for this product, and
disclaims the implied warranties of merchantability and fitness for a
particular purpose. In the event that the exclusion of any implied warranty is
ineffective under the law, the duration of the implied warranty will be one year from
the purchase date or such longer period as required by law.
The option of repair, replacement, or refund is Kodak’s only obligation. Kodak will not
be responsible for any special, consequential or incidental damages resulting from the
sale, purchase, or use of this product regardless of the cause. Liability for any special,
consequential or incidental damages (including but not limited to loss of revenue or
profit, downtime costs, loss of the use of the equipment, cost of substitute
equipment, facilities or services, or claims of your customers for such damages
resulting from the purchase, use, or failure of the Product), regardless of cause or for
breach of any written or implied warranty is expressly disclaimed.
Appendix
www.kodak.com/go/support 59
Your rights
Some states or jurisdictions do not allow exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Some states or jurisdictions do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
This warranty gives you specific rights, and you may have other rights which vary from
state to state or by jurisdiction.
Outside the United States and Canada
In countries other than the United States and Canada, the terms and conditions of
this warranty may be different. Unless a specific Kodak warranty is communicated to
the purchaser in writing by a Kodak company, no warranty or liability exists beyond
any minimum requirements imposed by law, even though defect, damage, or loss may
be by negligence or other act.
Regulatory compliance
FCC compliance and advisory
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed or used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures: 1) reorient
Kodak EasyShare M753/M853/MD853 zoom digital
60 www.kodak.com/go/support
Appendix
or relocate the receiving antenna; 2) increase the separation between the equipment
and the receiver; 3) connect the equipment to an outlet on a circuit different from that
to which the receiver is connected; 4) consult the dealer or an experienced radio/TV
technician for additional suggestions.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Where shielded
interface cables have been provided with the product or specified additional
components or accessories elsewhere defined to be used with the installation of the
product, they must be used in order to ensure compliance with FCC regulation.
Australian C-Tick
Canadian DOC statement
Observation des normes-Classe B
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Waste Electrical and Electronic Equipment labeling
Korean Class B ITE
In the European Union, do not discard this product as unsorted municipal waste.
Contact your local authorities or visit www.kodak.com/go/recycle for recycling
program information.
N137
Appendix
www.kodak.com/go/support 61
VCCI Class B ITE
China RoHS
Russian GOST-R
Eastman Kodak Company
Rochester, NY 14650
AIO-40
62 www.kodak.com/go/support
Index 1
A
about picture, video, 15
about this camera, 30
accessories, 40
battery, 57
buying, 50
printer dock, 41
SD/MMC card, 4
album
tagging pictures, 37
albums
set, 27
appendix, 52
auto, 9
flash, 8
focus framing marks, 6
B
backlight, 11
battery
charge, 2
compartment, ii
extending life, 57
loading, 1
types, 53
beach, 10
blur, 23
blur warning, 30
button
delete, 5
flash/status, 8
LCD/info, ii
ok, ii
on/off, i
review, ii, 14
share, ii
shutter, i
zoom, 7
C
cable, USB, 40
camera sounds, 29
candle light, 11
caring for your camera, 54
charge battery, 2
children, 11
clock, setting, 3
color mode, 27
compatibility, dock, 43
copy pictures
card to memory, 21
memory to card, 21
to computer, 39
cropping pictures, 17, 18
customer support, 50, 51
customizing camera settings, 28
D
date
setting, 3
stamp, 30
DC-in, i
deleting
during quickview, 5
www.kodak.com/go/support 63
Index
from internal memory, 16
from SD/MMC card, 16
protecting pictures, videos, 16
digital image stabilization, 9
digital zoom, using, 7
displaying slide show, 19
disposal, recycling, 54, 60
dock
compatibility, 43
connector, ii
printer, 41
doing more with your camera, 24
download pictures, 39
E
EasyShare software
installing, 39
emailing pictures, videos, 33
exposure
compensation, 31
long time, 27
metering, 26
F
favorites
removing, 35
settings, 35
tagging, 34
fireworks, 10
firmware, upgrading, 55
flash
settings, 8
flower, 10
focus
framing marks, 6
zone, 27
format, 30
framing grid, 31
G
grid, framing, 31
guidelines, battery, 57
H
help, 44
I
icon
blur, 23
icons, mode dial, 9
image storage, 28
information
about pictures, videos, 15
installing
batteries, 1
SD/MMC card, 4
software, 39
internal memory
storage capacity, 55
ISO speed, 26
K
Kodak
EasyShare software, 39, 55
Perfect Touch technology, 17
L
landscape, 10
LCD, ii
64 www.kodak.com/go/support
Index
brightness, 29
reviewing pictures, 14
reviewing videos, 14
LCD/info button, ii
lens
cleaning lens, 54
loading
batteries, 1
SD/MMC card, 4
software, 39
long time exposure, 27
M
Macintosh computers, installing
software on, 39
maintenance, camera, 54
manner/museum, 11
memory
inserting card, 4
storage capacities, 55
mode dial, i, 9
modes
auto, 9
backlight, 11
beach, 10
candle light, 11
children, 11
fireworks, 10
flower, 10
landscape, 10
manner/museum, 11
night landscape, 10
night portrait, 10
portrait, 10
SCN, 9
self-portrait, 11
snow, 10
sports, 10
sunset, 11
text/document, 10
N
night landscape, 10
night portrait, 10
O
ok button, ii
on/off button, i
online prints, ordering, 43
optical zoom, 7
orientation sensor, 29
P
panoramic pictures, 12
Perfect Touch technology, 17
PictBridge enabled printer, 41
picture size, 25
pictures
checking settings, 22
copying, 21
cropping, 17, 18
deleting, 16
emailing tagged, 33
printing, 42
protecting, 16
reviewing, 14
storage capacity, 55
tagging, 37
taking, modes, 9
www.kodak.com/go/support 65
Index
transfer, 39
picture-taking settings, 24
portrait, 10
power, camera, 3
printer dock, 41
printing
from a card, 43
from computer, 42
order online, 43
PictBridge technology, 41
tagged pictures, 43
with EasyShare printer dock, 41
problem-solving, 44
protecting pictures, videos, 16
Q
quickview, using, 5
R
recycling, disposal, 54, 60
red-eye, flash, 8
regulatory information, 59
removing favorites, 35
repair, 50
return, 29
review button, ii, 14
reviewing pictures
as you take them, 5
deleting, 16
LCD, 14
protecting, 16
slide show, 19
reviewing videos
deleting, 16
LCD, 14
protecting, 16
slide show, 19
running slide show, 19
S
scene modes, 10
panorama, 12
SCN, 9
SD/MMC card
inserting, 4
printing from, 43
storage capacities, 55
self-portrait, 11
self-timer light, i
service and support telephone
numbers, 51
setting
about, 30
blur warning, 30
camera sounds, 29
color mode, 27
date and time, 3
date stamp, 30
exposure metering, 26
flash, 8
focus zone, 27
image storage, 28
ISO, 26
LCD brightness, 29
long time exposure, 27
orientation sensor, 29
picture size, 25
picture taking mode, 9
66 www.kodak.com/go/support
Index
return, 29
sound volume, 29
video date display, 30
video out, 29
video size, 28
white balance, 26
setting, albums, 27
settings
picture taking, 24
setup mode, using, 28
shaking hand, 23
share button, ii
sharing pictures, videos, 31
shutter
button, i
problems, 45
slide show
continuous loop, 20
running, 19
snow, 10
software
installing, 39
upgrading, 55
sound volume, 29
sounds, 29
specifications, camera, 52
sports, 10
status
blur, 23
storage capacity, 55
strap post, ii
sunset, 11
support, technical, 50, 51
T
tagging
favorites, 34
for albums, 37
for email, 33
for print, 32
telephone support, 51
text/document, 10
time, setting, 3
tips
care & maintenance, 54
transferring pictures, videos, 39
trash can, deleting, 5
tripod socket, ii
troubleshooting, 44
turning camera on and off, 3
U
upgrading software, firmware, 55
USB cable, 40
USB, A/V out, i
V
VCCI compliance, 61
video
action print, 19
checking settings, 22
copying, 21
date display, 30
deleting, 16
out, 29
protecting, 16
reviewing, 14
size, 28
www.kodak.com/go/support 67
Index
storage capacities, 55
viewing, 14
videos
emailing tagged, 33
transfer, 39
viewing picture
after taking, 5, 14
viewing picture, video information, 15
volume, 29
W
warranty, 57
WEEE, 60
white balance, 26
Windows OS-based computers
installing software, 39
wrist strap, 1
Z
zoom
digital, 7
optical, 7
