KODAK EASYSHARE Digital Frame

User guide

S730

www.kodak.com

For help with your digital frame, www.kodak.com/go/digitalframesupport

Eastman Kodak Company

Rochester, New York 14650

© Kodak, 2009

All screen images are simulated.

KODAK, EASYSHARE, and PERFECT TOUCH are trademarks of Eastman Kodak

Company.

P/N 4H5194_en

Product features

www.kodak.com/go/digitalframesupport 1

ENGLISH

Back View

See the Extended user guide www.kodak.com/go/digitalframesupport

1 Memory card slot - SD/SDHC/MMC/XD/

MS/MS Pro Duo

3Speakers (2)

4 Rotating stand

2 DC-In 12V 1.5A 5 Wall mounting holes (3)

34

5

1

2

3

2www.kodak.com/go/digitalframesupport

Product features

ENGLISH

Front/Side Views

NOTE: When your hand is within

1 - 3 in. (2.5 - 7.6 cm)

of the borders, the lights turn on and

indicate where to touch. Tap a light on the right border to turn on the screen icons.

To use the Quick Touch Borders

, see page 4.

1LCD screen 4Volume button

Quick Touch Borders: 5 Mode button

2 Side touch lights—tap only 6 Power button

3 Bottom touch lights—slide/tap arrows 7 USB connector (to USB drive)

8 USB connector (to computer)

9 Audio out (headphones or speakers)

10 Speakers (2)

2

1

3

7

6

8

9

5

4

10

www.kodak.com/go/digitalframesupport 3

1Getting started

Setting up the stand

Attaching the power cable

CAUTION:

Do not use this power cable with other devices, including digital

cameras.

Pull to adjust the frame angle for

best viewing.

Your frame displays pictures in landscape

orientation .

To change to portrait orientation , turn the

frame on its side.

Charge the battery (installed at the factory)

by leaving the power connected for at

least 3 hours. The frame does not need to

be turned on.

Your power cable may look different

from the one pictured. Use the plug

that accommodates your type of

power outlet.

4www.kodak.com/go/digitalframesupport

Getting started

Turning your frame on and off

Using the Quick Touch Borders

Power button - press and hold (for about 2

seconds), then release

Hover within 1 - 3 in. (2.5 - 7.6 cm) of

any border to turn on the lights.

Right border tap

lights

tap arrow lights or slide to move

forward or backward thru pictures

Menu

Play

Up

Down

OK or

move thru the

menus and

thumbnail rows

Bottom border

Right border icons

Tap the right border to turn on the icons.

(Select) or (Picture Finder)

Getting started

www.kodak.com/go/digitalframesupport 5

CAUTION:

Only use your finger on the borders. Borders do not react to sharp

or metal objects—and they may damage the border or screen.

Touch the lights—not the screen

Only the lights on the Borders are touch-sensitive.

Tapping on the right border

■Tap the light next to an icon to select it. Icons

change color when they’re selected.

■Tap the light next to the up/down arrows to move

up or down through menus or rows of thumbnails.

■Tap the light next to OK or to select the

highlighted item.

Tapping and sliding on the bottom border

■Tap the arrow lights to move the highlight one

picture at a time or to change selected values.

■Slide between the arrow lights to scroll through

pictures: like turning the pages of a book, slide left

to go forward, slide right to go back.

■For faster scrolling through large numbers of

thumbnail pictures, touch and hold an arrow light

(3 seconds).

DON’T

Tap the screen

DO

Tap the light

6www.kodak.com/go/digitalframesupport

Getting started

Setting your language

The language screen appears the first time you turn on your frame.

■Tap the light next to an up/down arrow to

highlight your language, then tap OK.

To change the language later:

■Tap (Menu) (Settings) Language

OK. Tap an up/down arrow to highlight your

language, then tap OK.

Your settings are saved and the Clock and Date screen

appears.

Setting the clock and date

1 Set the clock. Tap the down arrow to

highlight Clock, then slide or tap between the

left/right arrow lights to select the current time

(based on a 24-hour clock).

2 Set the date. Tap the down arrow to

highlight Year/Month/Day, then slide or tap

between the left/right arrow lights to select the

current date (three separate settings).

3Tap OK to save your settings and close the Menu

screen.

To close the screen without saving, highlight Exit,

then tap OK.

To change or set the clock, date, energy saver, and automatic timer later:

■Tap (Menu) (Settings) OK Time/On Off OK.

Press and hold to move quickly

through the time and date

settings.

Getting started

www.kodak.com/go/digitalframesupport 7

Inserting a memory card

Connecting a computer or USB device

MMC (MULTIMEDIA Card)

To insert a card, push it firmly into the slot.

To remove a card, pull it out of the slot.

XD

SD/SDHC (SECURE DIGITAL/SECURE

DIGITAL High Capacity)

MS Pro Duo (MEMORY STICK)

MS (MEMORY STICK)

Supported USB devices include a computer, flash

drive, card reader, hard drive*, etc.

USB devices are sold separately.

*External hard drives must be self-powered.

Connect to a computer

USB cable included

Connect a USB device

8www.kodak.com/go/digitalframesupport

Getting started

Enjoying your pictures immediately!

Installing the software

Use KODAK EASYSHARE Digital Display Software to manage your frame right from

your computer. Use the Sync feature to copy all your pictures from your computer to

your frame’s internal memory (see page 11).

1Insert the CD into your computer and follow the

on-screen instructions to install the software.

■Click Typical to install EASYSHARE Digital

Display Software and to upgrade a previous

version of EASYSHARE Software. Click Custom

to choose which applications to install.

■Update—if an update to Digital Display

Software is available on the Web, you receive a

notice during installation. Click Yes to install the

latest version and take advantage of new

features, including Sync.

2Double-click the Digital Display Software icon on your desktop to open the

software if it doesn’t open automatically.

When prompted, take a few minutes to electronically register your frame and software

for exclusive tips and offers. To register later, visit www.kodak.com/go/register.

To view your pictures and videos, insert a memory card or

other USB device. Your pictures play automatically.

CD packaged with

your frame.

Digital Display Software icon

EASYSHARE Software icon

www.kodak.com/go/digitalframesupport 9

2Viewing pictures and videos

Viewing your pictures and videos

View your pictures and videos from the frame’s internal memory or any connected

picture source.

1Tap (Menu), then (Pictures & Videos).

All connected sources and internal memory are listed.

2Tap an up/down arrow to highlight a picture source,

then:

■Tap (Play) to start playback of the pictures

in the highlighted source.

■Or, tap OK to view thumbnails of the pictures in

the highlighted source.

Up/down arrows

Picture sources:

Default play location—your automatic go-to location (see page 14).

Internal memory—the frame’s 1 GB internal memory.

A Sync folder in the internal memory contains the collection of pictures and

videos copied from your computer (see page 11).

Memory card—appears when you insert a card (see page 7).

USB drive—appears when you insert a USB flash or other type drive (see page 7).

10 www.kodak.com/go/digitalframesupport

Viewing pictures and videos

Playback information

■The default display order is Shuffle. To turn off Shuffle and change to a different

display order, tap (Menu) → (Settings). Use the Shuffle and Display

Picture Order By settings, see page 19.

■You can change the duration (how long each picture stays on the screen) and

transition style between pictures. See Changing frame settings, page 19.

Changing viewing modes

Press the Mode button for quick access to the four viewing modes on your frame:

Pictures & Videos, Collage, Clock, and Calendar.

Each time you press the Mode button, the frame advances to the next mode.

NOTE: Videos and multimedia slide shows do not play in Collage mode.

Mode button

Pictures & Videos

(default)

Collage

(4 pictures)

Calendar/picture Clock/picture

Viewing pictures and videos

www.kodak.com/go/digitalframesupport 11

Copying your computer’s entire picture collection

Use the Sync (synchronize) feature in KODAK EASYSHARE Digital Display Software to

create a collection of all the pictures and videos on your computer, and copy the

collection into your frame’s internal memory.

As the collection is created, the pictures are resized to a lower resolution so they will

fit on the frame. Videos are copied at full resolution.

On your computer

1Insert a removable device (memory card or USB drive) in your computer.

2Open KODAK EASYSHARE Digital Display Software (double-click on your

desktop). See page 8 for software installation.

NOTE: Take advantage of all the latest Digital Display Software features, including Sync, by downloading

and installing the current update. Visit www.kodak.com/go/digitalframedownloads.

For more detail on using Digital Display Software, click the Help menu.

3Click the Sync tab at the top of the right pane and follow the screen directions.

The pictures in your collection are resized, then copied to the card or USB drive.

You can also connect your frame to your computer and Sync your pictures directly to

the frame. For more information, see the Extended user guide at

www.kodak.com/go/digitalframesupport

.

On your frame

■Remove the device from your computer and insert it in the frame.

A message appears on the frame notifying you that a collection is available and ready to

copy to internal memory or view without copying.

To view the collection on your frame at any time, tap Menu Pictures & Videos

Internal Memory. Then select the Sync folder and tap (Play).

12 www.kodak.com/go/digitalframesupport

Viewing pictures and videos

Picture Finder—auto-play similar pictures

If you have many pictures on your frame (for instance, if you copied your entire

collection from your computer, see page 11), you may want to find specific pictures

quickly. Let Picture Finder do it for you!

While viewing pictures on your frame—from any picture source or in any viewing

mode:

1Tap the right border to display the icons and to pause play.

2Tap the light next to the Picture Finder button .

Pictures that were taken on the same day as the selected picture begin playing.

Viewing thumbnails

While pictures are playing or from a single view:

1Tap a touch border to display the icons, then tap

(Menu).

2Tap (Thumbnails).

NOTE: You can also display thumbnails from the Pictures & Videos

source list (see page 9).

Tips when viewing thumbnails:

■To move to the next or previous row, tap the up/down arrows on the right border.

■To move through the thumbnails, tap the arrows or slide your finger left/right

along the bottom slider. To move even faster through the thumbnails, press and

hold until the speed changes (about 3 seconds).

■To play a folder of images, highlight the folder then tap (Play).

■To play a video or a slide show, highlight the thumbnail and tap (Play).

Viewing pictures and videos

www.kodak.com/go/digitalframesupport 13

Viewing a single picture

■To view a single, full-screen picture, highlight it in

thumbnails view, then tap OK.

■Or, when a slide show is playing, tap the right

border. The slide show pauses and the picture in

view is displayed. Tap OK to hide the icons and

lights.

■Tap Picture Finder to start a slide show of pictures taken on the same day as

the displayed picture (see Picture Finder—auto-play similar pictures, page 12).

Playing a video

From thumbnails view—highlight a video thumbnail, then tap OK (MOV videos

are indicated with a movie icon ; AVI, MPEG, MPG videos display the first frame).

During picture playback—videos play automatically. When the video ends, the

slide show advances to the next picture or video.

Pause a video—tap the right border to pause ( ) the video. Play resumes after 15

seconds of inactivity.

NOTE: Video formats created with digital cameras are certified for KODAK Digital Frames. Videos created

with or copied from other sources may not play on your frame.

HD (high definition) video files are not supported and do not play on your frame.

Video controls (tap the right or bottom border to display the icons)

play and resume the video

rewind / fast forward

Slider bar & arrows (on bottom border)

To view the next / previous picture or video, tap the bottom arrow lights.

14 www.kodak.com/go/digitalframesupport

Viewing pictures and videos

Saving a default play location

Save the picture source where you usually store your favorite pictures (internal

memory, memory card, USB drive, etc.) as your default go-to location.

1While viewing pictures, tap a Quick Touch Border.

Play is paused and the lights and screen icons appear.

2Tap (Menu), then (Settings).

3Tap an up/down arrow to highlight Default play location.

4Tap the up/down arrows to highlight an option:

■Yes—to confirm.

■No—to exit the menu.

■Clear my Default Play Location—to delete reference to the currently

designated picture source.

The next time you turn on your frame, it will automatically start playing from the same

source you were in when you entered the Settings Menu.

The Default Play Location icon appears in the Pictures & Videos list as a picture

source (see page 9).

www.kodak.com/go/digitalframesupport 15

3Doing more with your frame

Accessing menu options

View and work with your pictures and videos, and change your frame settings.

1Tap (Menu).

2Tap an up/down arrow to highlight a menu

option, then tap OK.

IMPORTANT:

You may need to keep tapping the

up/down arrows to see a complete list of

available options.

Menu options Description

Pictures & videos View and play all available pictures and videos (see page 9).

Slide shows Play multimedia slide shows. See the Extended user guide.

Thumbnails View pictures as thumbnails (see page 12).

Multi-select Select multiple pictures for copy, rotate, delete, or play (see page 16).

Select All/

Deselect all

Select or deselect everything in your current picture source (see

page 16). Available from the Multi-select menu only.

Copy See Copying on your frame, page 16.

Rotate See the Extended user guide.

Delete See Deleting pictures and videos, page 17.

Music View and play songs in the current source (see page 17).

Settings Customize your frame. See Changing frame settings, page 19.

Exit Close the menu screen without saving any selections.

See the Extended user guide www.kodak.com/go/digitalframesupport

16 www.kodak.com/go/digitalframesupport

Doing more with your frame

Selecting multiple pictures

Use the multi-select feature to copy, delete, or rotate multiple pictures at once. Or

select just the pictures you want to play in a slide show.

1Tap (Menu), then tap the down arrow to highlight Multi-Select. Tap OK.

2To find and highlight a picture, tap the arrow lights or slide between them, then

tap (Select).

A check mark appears on the selected picture.

3Continue selecting pictures. To select or deselect all at once, tap Menu again.

Copying on your frame

Copy pictures, videos, or music from your current viewing location to other connected

devices (see page 7) or into your frame’s internal memory.

CAUTION:

Do not remove a card or disconnect a device while copying.

1Highlight a picture in thumbnails view (see page 12) or display it in single view

(see page 13). To select multiple pictures, see page 16.

2Tap (Menu), then tap an up/down arrow to highlight (Copy). Tap OK.

3Tap an up/down arrow to highlight the copy-to destination, then tap OK.

Notes on copying to internal memory

When you copy pictures into the frame’s internal memory, the copies are

automatically resized to a lower resolution (smaller size). Full resolution is

unnecessary for viewing and quickly fills up the frame’s memory.

To turn off the automatic resizing feature, tap Menu Settings Automatic

resizing (see Changing frame settings, page 19).

Videos are always copied at full resolution.

Doing more with your frame

www.kodak.com/go/digitalframesupport 17

Deleting pictures and videos

CAUTION:

Do not remove a card or disconnect a device while deleting.

1Highlight a picture in thumbnails view (see page 12) or display it in single view

(see page 13). To select multiple pictures, see page 16.

2Tap (Menu), then tap an up/down arrow to highlight (Delete).

3Highlight Yes to confirm.

4Tap OK to delete the picture and return to the menu.

If you change your mind, highlight No, then tap OK to return to the menu.

Playing music—MP3 files

Play music automatically

Your frame automatically plays music (MP3 files) in the background with your pictures

and videos. The music files must be in the same picture source (internal memory,

memory card, USB drive) as the pictures and videos.

To turn off automatic music play, set Music auto-play to Off. See Changing frame

settings, page 19.

Play music manually

1Set Music auto-play to Off. See Changing frame settings, page 19.

2Tap (Menu). Tap the down arrow to highlight (Music), then tap OK.

All music files in the current picture source are listed.

3Tap an up/down arrow to highlight a song, then tap to select it.

Repeat to select more songs.

18 www.kodak.com/go/digitalframesupport

Doing more with your frame

To select all songs in the list, tap (Menu), then tap the down arrow to

highlight Select All.

4Tap (Play).

Picture playback resumes, with your selected songs playing in the background.

Working with your music files on your frame

The Music menu lets you work with your music files. To display the Music menu:

1Tap (Menu), then tap the down arrow to highlight Music , then tap OK.

Your available music files are listed.

2Tap (Menu) again for the music menus:

* Shuffle play and Audio priority are also available in the Settings menus, see

Changing frame settings, page 19.

Music menu options Description

Copy/Delete Copy or delete your music files.

Select All/

Deselect all

Select or deselect all the songs in your current picture source for

copy, delete, or play.

Shuffle play* Play selected songs in random order.

Audio priority* When music and video are playing at the same time, choose whether

to play the music or the audio portion of the video.

Exit Close the menu screen without saving any selections.

Doing more with your frame

www.kodak.com/go/digitalframesupport 19

Changing frame settings

The options in the Settings menu let you customize and configure your frame.

IMPORTANT:

You may need to keep tapping the up/down arrows to see the complete list

of available options.

1Tap (Menu), then tap (Settings).

2Tap the up/down arrows to highlight a setting, then tap OK.

3Follow the on-screen instructions. Tap OK to accept your selections.

4Tap (Play) to return to playback from the current image. Tap (Menu) to

return to the top level menu.

Settings menus

Setting Description

Upgrade Firmware This setting is only displayed and available if the upgrade file

(.img) is present on an inserted memory card or flash drive, or

copied into internal memory (see page 20).

Duration Specify how long each picture is displayed.

NOTE: When Transition is set to Zoom & pan, the Duration is

always 10 seconds.

Transition Specify the transition style between pictures during playback.

Default Play Location Set your default go-to location (see page 14).

Shuffle Play pictures in random order.

Slide Show Starting Point Specify where playback starts.

Music auto play Allow music to play automatically during picture playback (see

page 17).

Brightness Adjust the screen brightness.

Automatic Resizing Copy pictures to internal memory at a lower resolution

(smaller size) or at full resolution (larger size). See page 16.

20 www.kodak.com/go/digitalframesupport

Doing more with your frame

Upgrading your firmware (recommended)

Firmware is the software that runs on your frame.

1On your computer, go to www.kodak.com/go/digitalframedownloads and follow

the screen directions to download the frame firmware to your computer.

2Copy the IMG file to the root directory (not in a folder or subfolder) of a memory

card or USB flash drive, then insert into the frame.

Fit or Fill Specify how to scale the pictures on the screen.

KODAK PERFECT TOUCH

Technology

Automatically enhance your pictures to look their best on your

frame.

Display Picture Order By Specify the order in which to play your pictures—by date or

file name.

NOTE: If Shuffle is On, pictures play in random order, regardless of

this setting.

Time/On Off Set the clock, date, energy saver*, and automatic timer.

* Energy saver is available on frames with firmware dated

September 2009 or later. See About this frame, below.

Audio Options Configure how your music plays.

For more details about playing music on your frame see

page 17.

Language Choose your language (page 6).

About this frame Check your frame model, serial number, and firmware version.

Exit Return to the top menu with no actions performed or saved.

See the Extended user guide www.kodak.com/go/digitalframesupport

Settings menus

Setting Description

Doing more with your frame

www.kodak.com/go/digitalframesupport 21

3Tap (Menu), then tap (Settings).

4Highlight Firmware Upgrade, then tap OK to begin the upgrade.

The upgrade may take up to 5 minutes.

When the upgrade is complete, your frame automatically restarts.

CAUTION:

Do not turn off the frame or remove the memory card or USB

flash drive until the upgrade is complete and the frame has

restarted.

Hanging your frame on the wall

To hang your frame on the wall, close the stand, then use wall anchoring hardware

(not included) to securely mount the frame to the wall.

See Back View, page 1 for the location of the mounting holes.

Learning more about your frame

www.kodak.com/go/digitalframes Learn more about your frame. Order accessories.

www.kodak.com/go/digitalframesupport Extended user guide

Interactive troubleshooting and repairs

Interactive tutorials

Frequently asked questions

Software and firmware downloads

Product registration

22 www.kodak.com/go/digitalframesupport

4Troubleshooting and support

For step-by-step product support, visit www.kodak.com/go/digitalframesupport and

select Step-by-Step Solutions & Repair.

Picture frame problems

If... Try one or more of the following

Frame does not

turn on.

■Make sure the power cable that was included with your frame is

connected securely (see page 3).

■Unplug the power cable for 5 seconds, then reconnect the cable.

Press and hold the power button (for about 2 seconds), then

release.

Nothing happens when

a memory card or USB

device is connected.

■Insert a certified SD/SDHC/MMC/XD/MS/MS Pro Duo Card, with

images, into the card slot, then push to seat it (see page 7).

■Make sure the USB device is connected securely (see page 7).

■Make sure the file format of your pictures and videos are

supported. (See the Extended user guide).

NOTE: Pictures may take a longer time to display when the picture/video files are large

or when using a large capacity memory card or other connected device.

Touch border doesn’t

work.

■Use your finger to make your selections on the Quick Touch

Borders (see page 4). Lights on the border show you where to

touch.

IMPORTANT:

Do not slide on the right border (tap only).

■Unplug the power cable for 5 seconds, then reconnect the cable.

Press and hold the power button (for about 2 seconds), then

release.

Troubleshooting and support

www.kodak.com/go/digitalframesupport 23

Frame loses battery

power (power cable

disconnected)—

doesn’t work on battery

power or works for less

than 1 hour.

■Charge the battery (see page 3).

■Refresh the battery:

– Fully charge the battery—connect the power cord and leave

connected for at least 3 hours.

– Fully discharge the battery—disconnect the power cable, start

the frame and let it run until the battery is discharged (the

frame turns itself off).

– Repeat the above charge/discharge procedure 2 or 3 times.

■Battery may need replacing. Visit www.kodak.com/go/accessories.

Frame freezes up or

doesn’t work properly.

■Unplug the power cable for 5 seconds, then reconnect the cable.

Press and hold the power button (for about 2 seconds), then

release.

■Reset the frame. Press the Mode and Power buttons (see page 2)

at the same time, then tap Yes to reset the frame. (Resetting your

frame does not erase your saved files.)

Audio portion of video

doesn’t play.

■Press + on the Volume button (see page 2).

You set automatic

on/off but the frame

doesn’t turn on and off

at the specified times.

■If your frame loses power, the clock returns to the factory setting

and auto on/off times are disabled. See Resetting the clock and

calendar after losing power, page 24.

If... Try one or more of the following

24 www.kodak.com/go/digitalframesupport

Troubleshooting and support

Resetting the clock and calendar after losing power

If you turn off the power on the frame or otherwise lose power for longer than 12

hours, the clock and calendar return to the factory setting and the automatic on/off

times, if set, are disabled.

When you turn the frame back on, the Clock and Date screen appears.

1 Set the clock.

Tap the arrow lights or slide to select the current time (based on a 24-hour clock).

2 Set the date.

Tap the down arrow to highlight Year/Month/Day, then slide or tap between

the left/right arrow lights to select the current date (three separate settings).

3Tap OK.

The time is reset and the automatic on/off times (if set) are re-enabled. It is not

necessary to reset the on/off times.

NOTE: If you exit the Clock and Date screen without setting the time, you can manually reset the clock and

re-enable the automatic on/off times (see page 6). It is not necessary to reset the on/off times.

Cannot copy pictures

from one device

(memory card or USB

flash drive) to another

even though the copy

destination is not full.

Storage devices that have FAT (File Allocation Table) 16 formatting can

only store up to 512 files in the top level (root) directory. To make sure

all your pictures copy properly, format the copy destination to FAT32

before copying to it:

CAUTION: Formatting deletes all pictures and videos,

including protected files.

1Connect the device to your computer.

2Open My Computer and locate the device.

3Right-click on it and choose Format.

4From the File system drop-down menu, choose FAT32 then click

Start.

If... Try one or more of the following

www.kodak.com/go/digitalframesupport 25

5Appendix

Important safety instructions

CAUTION:

Do not disassemble this product; there are no user-serviceable parts inside. Refer

servicing to qualified service personnel. Do not expose this product to liquid,

moisture, or extreme temperatures. The use of controls, adjustments, or procedures

other than those specified herein may result in exposure to shock and/or electrical

or mechanical hazards. If the LCD breaks, do not touch the glass or liquid. Contact

Kodak customer support.

■The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury. For

approved accessories, visit www.kodak.com/go/accessories.

■Use only the AC adapter that was packaged with your frame. (Leader Electronics Inc. AC Adapter Model

#MU18-D120150-A1; in Europe, Phihong AC Adapter Model #PSA18R-120P) Use of other AC adapters

may damage the frame and void your warranties.

■When displayed with the stand extended, the frame rests at a 68 - 76° angle.

■Do not place frame near open flame sources such as lighted candles or heaters.

■Excessive sound pressure from earphones and headphones may cause hearing loss.

■When removing the battery from the frame, allow it to cool; it may be hot.

■Keep batteries out of the reach of children.

■Do not allow batteries to touch metal objects, including coins. Otherwise, a battery may short circuit,

discharge energy, become hot, or leak.

■Do not disassemble, install backward, or expose batteries to liquid, moisture, fire, or extreme

temperature.

■Remove the battery when the product is stored for an extended period of time. In the unlikely event that

battery fluid leaks inside the product, contact Kodak customer support.

■In the unlikely event that battery fluid leaks onto your skin, wash immediately with water and contact

your local health provider. For additional health-related information, contact your local Kodak customer

support.

■Dispose of batteries according to local and national regulations. Visit www.kodak.com/go/kes.

26 www.kodak.com/go/digitalframesupport

Appendix

Additional care and maintenance

■Always disconnect the power before cleaning. Do not use water, cleaning solutions, or other adhesives on

the frame or any of its parts. Gently wipe the frame and screen with a clean, dry, lint-free cloth. For

fingerprints on the frame, apply light pressure.

■Service agreements are available in some countries. Contact a dealer of KODAK Products for more

information.

■For digital frame disposal or recycling information, contact your local authorities. In the US, visit the

Electronics Industry Alliance at www.eiae.org or visit www.kodak.com/go/digitalframesupport.

Limited Warranty

Kodak warrants KODAK Consumer Electronic Products and Accessories (“Products”), excluding batteries, to

be free from malfunctions and defects in both materials and workmanship for one year from the date of

purchase. Retain the original dated sales receipt. Proof of the date of purchase will be required with any

request for warranty repair.

Limited warranty coverage

Warranty service is only available from within the country where the Products were originally purchased. You

may be required to ship Products, at your expense, to the authorized service facility for the country where the

Products were purchased. Kodak will repair or replace Products if they fail to function properly during the

warranty period, subject to any conditions and/or limitations stated herein. Warranty service will include all

labor as well as any necessary adjustments and/or replacement parts. If Kodak is unable to repair or replace a

Product, Kodak will, at its option, refund the purchase price paid for the Product provided the Product has

been returned to Kodak along with proof of the purchase price paid. Repair, replacement, or refund of the

purchase price are the sole remedies under the warranty. If replacement parts are used in making repairs,

those parts may be remanufactured, or may contain remanufactured materials. If it is necessary to replace the

entire Product, it may be replaced with a remanufactured Product. Remanufactured Products, parts and

materials are warranted for the remaining warranty term of the original Product, or 90 days after the date of

repair or replacement, whichever is longer.

Limitations

This warranty does not cover circumstances beyond Kodak's control. This warranty does not apply when

failure is due to shipping damage, accident, alteration, modification, unauthorized service, misuse, abuse, use

with incompatible accessories or attachments (such as third party ink or ink tanks), failure to follow Kodak's

operation, maintenance or repacking instructions, failure to use items supplied by Kodak (such as adapters

and cables), or claims made after the duration of this warranty. Kodak makes no other express or implied

warranty for this product, and disclaims the implied warranties of merchantability and fitness for a particular

purpose. In the event that the exclusion of any implied warranty is ineffective under the law, the duration of

the implied warranty will be one year from the purchase date or such longer period as required by law. The

option of repair, replacement, or refund is Kodak's only obligation. Kodak will not be responsible for any

special, consequential or incidental damages resulting from the sale, purchase, or use of this product

regardless of the cause. Liability for any special, consequential or incidental damages (including but not

Appendix

www.kodak.com/go/digitalframesupport 27

limited to loss of revenue or profit, downtime costs, loss of the use of the equipment, cost of substitute

equipment, facilities or services, or claims of your customers for such damages resulting from the purchase,

use, or failure of the Product), regardless of cause or for breach of any written or implied warranty is expressly

disclaimed.

Your rights

Some states or jurisdictions do not allow exclusion or limitation of incidental or consequential damages, so

the above limitation or exclusion may not apply to you. Some states or jurisdictions do not allow limitations

on how long an implied warranty lasts, so the above limitation may not apply to you. This warranty gives you

specific rights, and you may have other rights which vary from state to state or by jurisdiction.

Outside the United States and Canada

In countries other than the United States and Canada, the terms and conditions of this warranty may be

different. Unless a specific Kodak warranty is communicated to the purchaser in writing by a Kodak company,

no warranty or liability exists beyond any minimum requirements imposed by law, even though defect,

damage, or loss may be by negligence or other act.

Regulatory compliance and advisory

FCC compliance and advisory

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Canadian DOC statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CE

Hereby, Eastman Kodak Company declares that this KODAK Product is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

Australian C-Tick

MPEG-4

Use of this product in any manner that complies with the MPEG-4 visual standard is prohibited, except for use

by a consumer engaging in personal and non-commercial activities.

N137

28 www.kodak.com/go/digitalframesupport

Appendix

Waste Electrical and Electronic Equipment labeling

Russian GOST-R

Licensing

Supply of this product does not convey a license nor imply any right to distribute content created with this

product in revenue-generating broadcast systems (terrestrial, satellite, cable and/or other distribution

channels), streaming applications (via Internet, intranets and/or other networks), other content distribution

systems (pay-audio or audio-on-demand applications and the like) or on physical media (compact discs,

digital versatile discs, semiconductor chips, hard drives, memory cards and the like). An independent license

for such use is required. For details, please visit http://mp3licensing.com.

ENERGY STAR Product

ENERGY STAR® qualified product

In Europe: For human/environmental protection, it is your responsibility to dispose of this

equipment and battery at a collection facility established for this purpose (separate from

municipal waste). For more information, contact your retailer, collection facility, or

appropriate local authorities; or visit www.kodak.com/go/recycle. (Product weight: 816 g.)

Eastman Kodak Company

Rochester, New York 14650

Appendix

www.kodak.com/go/digitalframesupport 29

China RoHS

Eastman Kodak Company

Rochester, New York 14650

© Eastman Kodak Company, 2009

KODAK, EASYSHARE, and PERFECT TOUCH are trademarks of Eastman Kodak Company.

4H5194_en
