1

External Setups

E

2

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

0

KORG

KLC M1

Name OSC BAL RESO CUTOFF EG INT

Click the “KORG” logo. Select “ Load Controller Map...” from the displayed KORG logo

menu. Load the controller settings file “M1.cmap” from the “Presets” folder that’s

located inside the folder where the KORG Legacy Collection is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 CC#71 CC#74 CC#79

1KLC M1 Le

Name OSC BAL Free CUTOFF EG INT

Click the “KORG” logo. Select “Load Controller Map...” from the displayed KORG logo

menu. Load the controller settings file “M1 Le.cmap” from the “Presets” folder that’s

located inside the folder where the KORG Legacy Collection is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 off CC#74 CC#79

2KLC WAVESTATION

Name Vector X Vector Y Free Free

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#16 CC#17 off off

3

KLC MS-20

[A]

Name VCO 1 WAVE FORM VCO 2 WAVE FORM HPF CUTOFF LPF CUTOFF

Click the “KORG” logo. Select “Load Controller Map...” from the displayed KORG logo

menu. Load the controller settings file “MS-20.cmap” from the “Presets” folder located

inside the folder where the KORG Legacy Collection is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#82 CC#28 CC#74

4[B]

Name VCO 1 LEVEL VCO 2 LEVEL HPF PEAK LPF PEAK

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#20 CC#21 CC#29 CC#71

5

KLC Polysix

[A]

Name VCO WAVE FORM VCO PWM ADJUST VCF CUTOFF VCF RESONANCE

Click the “KORG” logo. Select “Load Controller Map...” from the displayed KORG logo

menu. Load the controller setting file “Polysix.cmap” from the “Presets” folder located

inside the folder where the KORG Legacy Collection is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#14 CC#74 CC#71

6[B]

Name MG FREQUENCY MG DELAY TIME MG LEVEL EG ATTACK

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#27 CC#24 CC#76 CC#73

3

7

KORG

KLC LegacyCell

[Encoder]

Name Encoder 1 Encoder 2 Encoder 3 Encoder 4

Click the controller logo on the “PERFORMANCE” page. Select “Load Controller Map...”

from the displayed controller menu. Load the controller setting file “LegacyCell.cmap”

from the “Presets” folder that’s located inside the folder where the KORG Legacy Collec-

tion is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#28 CC#29 CC#30 CC#31

8[Slider]

Name Slider 1 Slider 2 Slider 3 Slider 4

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#15 CC#5 CC#20

9

KLC Mono/Poly

[A]

Name XMOD INT FREQ MOD PWM INT VCF Cut

Click the “FILE” button at the bottom of the screen. Click the “LOAD” button in the dis-

play and make the popup menu appear. Choose “Controller Map...” from the popup

menu. Load the controller setting file “MonoPoly.cmap” from the “Presets” folder

located inside the folder where the KORG Legacy Collection is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#12 CC#13 #CC15 #CC74

10 [B]

Name VCF EG ATTACK VCF EG DECAY VCF EG SUSTAIN VCF EG RELEASE

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note #CC28 #CC29 #CC30 #CC31

11

microKORG

[A]

Name OSC 1 Wave Filter Cutoff Filter Resonance Filter EG Int

1: Connect the microSTATION’s MIDI OUT jack to the microKORG’s MIDI IN jack with a

MIDI cable.

2: Set the EDIT SELECT 2 knob to “MIDI”. Move Knob 1 to set the MIDI CH to “1”. Move

Knob 3 to set the CLOCK to “Ext”.

3: Set the EDIT SELECT 2 knob to “GLOBAL”. Move Knob 4 to set the POSITION to “PrE”

(Pre TG).

4: Press the 4 key while holding the SHIFT key to enter MIDI Filter settings. Move Knob 1

to select “P-E” (PROGRAM CHANGE Enabled). Move Knob 2 to select “C-E” (CONTROL

CHANGE Enabled). Move Knob 3 to select “b-E” (PITCH BEND Enabled).

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#74 CC#71 CC#79

12 [B]

Name OSC 1 Control2 OSC 2 Tune OSC 1 Level OSC 2 Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#15 CC#19 CC#20 CC#21

13

microKORG XL

[A]

Name Filter1 Balance Filter1 Cutoff Filter1 Resonance Drive/WS Depth

1: Connect the microSTATION’s MIDI OUT jack to the microKORG XL’s MIDI IN jack with a

MIDI cable.

2: Set the KNOB FUNCTION SELECT dial to “FULL EDIT”.

3: Move Knob 1 to set the page to “MIDI.” Move Knob 2 to set the parameter to “MIDI

CH.” Move Knob 3 to set the value to “01.” Move Knob 2 to set the parameter to

CLOCK” Move Knob 3 to set the value to “EXT MIDI.”

4: Move Knob 1 to set the page to “GLOBAL.” Move Knob 2 to set the parameter to

“POSITION ” Move Knob 3 to set the value to “PRE TG.”

5: Move Knob 1 to set the page to “MIDI FLT.” Move Knob 2 to set the parameter to

“PROG CHG ” Move Knob 3 to set the value to “ENABLE.” Move Knob 2 to set the

parameter to “CTRL CHG ” Move Knob 3 to set the value to “ENABLE.” Move Knob 2 to

set the parameter to “P.BEND CHG ” Move Knob 3 to set the value to “ENABLE.”

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#27 CC#74 CC#71 CC#83

14 [B]

Name EG2(AmpEG) Attack EG2(AmpEG) Release MFX1 We/Dry MFX2 We/Dry

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#73 CC#72 CC#115 CC#116

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

4

15

KORG

RADIAS

[A]

Name OSC1 Wave Filter 1 Cut Filter 1 Resonance Filter 1 Balance

1: Connect the microSTATION’s MIDI OUT jack to the RADIAS’ MIDI IN jack with a MIDI

cable.

2: Press the [GLOBAL] key to enter Global mode. Set “Position” on the “GLOBAL” page to

“Pre TG”.

3: Press the [PAGE] key to move to the “MIDI” page. Set “MIDI Ch” to “01” and “Clock” to

“Ext-MIDI”.

4: Press the [PAGE] key to move to the “MIDI FILTER” page. Set “ProgChg” to “o”,

“CtrlChg” to “o”, “P.Bend” to “o”.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 CC#74 CC#71 CC#27

16 [B]

Name OSC 1 Control2 LFO 1 Frequency OSC 2 Tune Amp Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#17 CC#90 CC#21 CC#7

17

R3

[A]

Name OSC1 Wave Filter 1 Cut Filter 1 Resonance Filter 1 Balance

1: Connect the microSTATION’s MIDI OUT jack to the R3’s MIDI IN jack with a MIDI cable.

2: Turn [PAGE SELECT] dial to move to “EDIT-P40 Global-A” page and set [KNOB4]’s

“Position” to “Pre TG.”

3: Turn [PAGE SELECT] dial to move to “EDIT-P42 MIDI” page and set [KNOB1]’s “MIDI

Ch” to “01”, [KNOB4]’s “Clock” to “Ext-MIDI.”

4: Turn [PAGE SELECT] dial to move to “EDIT-P43 MIDIFilt” page and set [KNOB1]’s

“PROG Chg” to “Enable,” [KNOB2]’s “Ctrl Chg” to “Enable”, [KNOB3]’s “PitchBend” to

“Enable.”

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 CC#74 CC#71 CC#27

18 [B]

Name OSC 1 Control2 LFO 1 Frequency OSC 2 Tune Amp Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#17 CC#90 CC#21 CC#7

19

Ableton Live

[Send]

Name Track 1 Send Track 2 Send Track 3 Send Track 4 Send

Load the “KORG microSTATION template.als” file.

Select “Preferences...” in the “Options” menu (or select “Preferences...” from the “Live”

menu on the Mac) to open the “Preferences” dialog. Set “Input” of “Remote Control” to

“microSTATION(KEYBOARD)”.

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#18 CC#18 CC#18 CC#18

20 [Pan]

Name Track 1 Pan Track 2 Pan Track 3 Pan Track 4 Pan

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#10 CC#10 CC#10 CC#10

21 [Volume]

Name Track 1 Volume Track 2 Volume Track 3 Volume Track 4 Volume

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#7 CC#7 CC#7 CC#7

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

5

22

Applied Acoustics

Systems

Lounge Lizard EP-3

[A]

Name Mallet Stiffness

soft/hard

Mallet Force

strength Mallet Noise pitch Mallet Noise decay

Select “Import...” from the “File” menu and load the setting file “KORG Midi Links.lx3”.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#44 CC#45 CC#46 CC#47

23 [B]

Name Pickup Geometry

Symmetry

Pickup Geometry

Distance

Pickup Volume

Input

Pickup Volume Out-

put

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#52 CC#53 CC#54 CC#55

24

Ultra Analog VA

[A]

Name OSC1 Detune OSC1 PW FILTER1 Cutoff FILTER1 Q

Select “Import...” from the “File” menu and load the setting file “KORG Midi Links.axf”

file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#44 CC#45 CC#46 CC#47

25 [B]

Name FILTER1 ENV1 A FILTER1 ENV1 D FILTER1 ENV1 S FILTER1 ENV1 R

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#52 CC#53 CC#54 CC#55

26

String Studio VS

[A]

Name Chorus Mix Chorus Depth Chorus Rate Delay Mix

Select “Import...” from the “File” menu and load the setting file “KORG Midi Links.sxf” file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#44 CC#45 CC#46 CC#47

27 [B]

Name Excitator Prot

(Force, Mass)

Excitator Stiff (Fric-

tion) Excitator Velocity Filter Cutoff

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#102 CC#103 CC#104 CC#105

28 Lounge Lizard Session

Name Piano Tune Tremolo Depth Tremolo Speed

Select “Import...” from the “File” menu and load the setting file “KORG Midi Links.lls” file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#71 CC#70 CC#92 CC#79

29 Ultra Analog Session

Name Keyboard Glide Filter Cutoff Filter Q Filter Env Attack

Select “Import...” from the “File” menu and load the setting file “KORG Midi Links.uas”

file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#5 CC#74 CC#71 CC#85

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

6

30

Arturia

minimoog V

[A]

Name Wave Osc 1 Wave Osc 2 Wave Osc 3 Cutoff

Copy the setting file “controlMidi” into the following folder:

Windows: The “save” folder is located inside the folder where minimoog V is installed.

(e.g. C:\Program Files\Arturia\minimoog V\save)

Mac: /Library/Preferences/minimoog V/save folder This operation will overwrite the

previous MIDI Control settings. If necessary, back up the previous controlMidi file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#16 CC#17 CC#18 CC#74

31 [B]

Name Level Osc 1 Level Osc 2 Level Osc 3 Level Ext

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#80 CC#81 CC#82 CC#83

32

CS-80V

[A]

Name Attack Time Vca 1 Decay Time Vca 1 Sustain Level Vca 1 Release Time Vca 1

Copy the setting file “controlMidi” into the following folder:

Windows: The “save” folder is located inside the folder where CS-80V is installed.

(e.g. C:\Program Files\Arturia\CS-80V\save)

Mac: /Library/Preferences/Cs80V/save folder. This operation will overwrite the previous

MIDI Control settings. If necessary, back up the previous controlMidi file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#92 CC#94 CC#95 CC#96

33 [B]

Name HighPass 1 Cutoff HighPass 1 Reso-

nance LowPass 1 Cutoff LowPass 1 Reso-

nance

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#65 CC#66 CC#67 CC#68

34

moog modular V

[A]

Name Filter 1 Cutoff Fre-

quency Filter 1 Resonance Filter 2 Cutoff Fre-

quency Filter 2 Resonance

Copy the setting file “controlMidi” into the following folder:

Windows: The “save” folder is located inside the folder where Moog Modular V is

installed. (e.g. C:\Program Files\Arturia\Moog Modular V\save)

Mac:/Library/Preferences/MoogModularV/save folder This operation will overwrite the

previous MIDI Control settings. If necessary, back up the previous controlMidi file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#80 CC#16 CC#81 CC#17

35 [B]

Name 125Hz Band Gain 350Hz Band Gain 1000Hz Band Gain 2800Hz Band Gain

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#106 CC#107 CC#108 CC#109

36

ARP2600 V

[A]

Name PORTAMENTO TIME DELAY Dry/Wet DELAY time L DELAY time R

Copy the setting file “controlMidi” into the following folder:

Windows: The “save” folder inside the folder where ARP2600 V is installed.

(e.g. C:\Program Files\Arturia\ARP2600V\save)

Mac: /Library/Preferences/arp2600v/save folder This operation will overwrite the previ-

ous MIDI Control settings. If necessary, back up the previous controlMidi file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#44 CC#45 CC#46 CC#47

37 [B]

Name INT.FIRTER FRE-

QUENCY RESONANCE ADSR FILTER TYPE

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#52 CC#53 CC#54 CC#55

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

7

38

Arturia

Prophet V

[V]

Name Osc A PW Filter Cutoff Filter Resonace Filter Env Amount

Copy the setting file “controlMidi” into the following folder:

Windows: The “save” folder is located inside the folder where Prophet V is installed.

(e.g. C:\Program Files\Arturia\ProphetV\save)

Mac: /Library/Preferences/prophetv/save folder This operation will overwrite the previ-

ous MIDI Control settings. If necessary, back up the previous controlMidi file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#20 CC#74 CC#71 CC#79

39 [VS]

Name Filter Env Amount Filter Cutoff Filter Resonace Volume

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#69 CC#30 CC#68 CC#83

40

Analog Factory

[A]

Name Level Cut Off Resonance LFO Rate

Copy the setting file “midi.prefs” into the following folder:

Windows: The “save” folder inside the folder where Analog Factory is installed. (e.g.

C:\Program Files\Arturia\Analog Factory\save)

Mac: /Library/Preferences/AnalogFactory folder This operation will overwrite the previ-

ous MIDI Control settings. If necessary, back up the previous controlMidi file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#7 CC#74 CC#71 CC#90

41 [B]

Name Param 1 Param 2 Param 3 Param 4

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#18 CC#19 CC#16 CC#17

42 Apple GarageBand

Name Pan Volume Free Free

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#10 CC#7 off off

43

Fxpansion BFD

[master]

Name Direct Master Level Overhead Level Room Level PZM Level

Click the “Load” icon (located in the upper right corner of the BFD window) to load the

“BFD_KORG.bfd” file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#16 CC#17 CC#18 CC#19

44 [trim]

Name Kick Trim Snr Trim HiH Trim F Tom Trim

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#52 CC#53 CC#54 CC#55

45 [tune]

Name Kick Tune Snr Tune HiH Tune F Tom Tune

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#44 CC#45 CC#46 CC#47

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

8

46

GMEDIA

impOSCar

Name Filter Frequency Filter Q Filter Separation Filter Amount

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#73 CC#52

47 M-Tron

Name Volume Tone Pitch Amp Env Attack

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#7 CC#74 CC#95 CC#73

48 Oddity

Name VCF Cutoff Fre-

quency VCF Resonance HPF Cutoff Freq Q LFO Freq Q

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#9 CC#8

49 minimonsta

Name Filter Emphasis Filter Cutoff Filter Contour VCF Attack

For stand-alone operation Windows: Click the “SET UP” button in the lower right part of

the “minimonsta” window to open the menu. Click on “Input device” and select “micro-

STATION KEYBOARD”. Mac: Click the “SET UP” in the lower right part of the “minimonsta”

window to open the menu. Click on “Input device” and select “CoreMIDI”.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#71 CC#74 CC#70 CC#20

50

Image-Line Software FL Studio

[Pan]

Name Master Pan FX1 Pan FX2 Pan FX3 Pan

For stand-alone and plug-in synthesizer operation Select “MIDI settings” (located in the

“OPTIONS” menu in the upper left corner of FL STUDIO window), and select “microSTA-

TION 1 KEYBOARD”. Select “Open” from the “FILE” menu, and load the “KORG microSTA-

TION.flp” file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#16 CC#17 CC#18 CC#19

51 [Volume]

Name Master Volume FX1 Volume FX2 Volume FX3 Volume

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#80 CC#81 CC#82 CC#83

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

9

52

MOTU

MachFive

Name Filter Cutoff Filter Resonance Drive Transpose

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#75 CC#76

53

DP (Digital Performer)

[Pan]

Name Track 1 Pan Track 2 Pan Track 3 Pan Track 4 Pan

Select “Open...” from the “File” menu and open the song file “DP_microSTATION”.

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#10 CC#10 CC#10 CC#10

54 [Level]

Name Track 1 Level Track 2 Level Track 3 Level Track 4 Level

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#7 CC#7 CC#7 CC#7

55

Native Instruments

B4

[A]

Name PERCUSSION VOL-

UME

PERCUSSION

DECAY VIBRATO MIX VIBRATO DEPTH

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#70 CC#71 CC#73 CC#74

56 [B]

Name UPPER MANUAL 16' UPPER MANUAL 5

1/3' UPPER MANUAL 8' UPPER MANUAL 4'

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#12 CC#13 CC#14 CC#15

57

B4 II

[A]

Name PERCUSSION VOL-

UME

PERCUSSION

DECAY VIBRATO MIX VIBRATO DEPTH

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#70 CC#71 CC#73 CC#74

58 [B]

Name Upper Drawbar 16' Upper Drawbar 5 1/

3' Upper Drawbar 8' Upper Drawbar 4'

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#12 CC#13 CC#14 CC#15

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

10

59

Native Instruments

Battery

Name Controller A Controller B Controller C Controller D

Press the “OPTIONS” button and open the Preference dialog. Set the MIDI controllers as

below.

A: CC#0, B: CC#1, C: CC#2, D: CC#3, E: CC#4, F: CC#5, G: CC#6, H: CC#7

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#0 CC#1 CC#2 CC#3

60 Elektrik Piano

Name Sound Control

Knob 1

Sound Control

Knob 2

Sound Control

Knob 3

Sound Control

Knob 4

Press the “OPTIONS” button to open the “Settings” dialog. Confirm that “USE STD. CC#7

/ CC#10 VOLUME & PAN” is active. In case it is not active, click it.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#20 CC#21 CC#22 CC#23

61

FM7

[A]

Name Easy Edit Timbre

Brightness

Easy Edit Timbre

Harmonic

Easy Edit Timbre

Detune

Easy Edit Timbre

Env Amount

On the “MASTER” page, locate the “CONTROLLER DEFINE” parameters then press the

“LOAD” button for “CONTROLLER ASSIGN” to load the setup file “KORG microSTA-

TION.f7c”.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#102 CC#103 CC#104 CC#105

62 [B]

Name Filter Cutoff Filter 1 Resonance Filter Envelope

Amount Filter 1 Mode

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#111 CC#112 CC#113 CC#110

63

FM8

[A]

Name Timbre Harmonic Timbre Detune Timbre Brightness Timbre Env Amount

On the “MASTER” page, locate the “MIDI Controller Assignment” parameters then press

the “LOAD” button for “CONTROLLER ASSIGN” to load the setup file “KORG MIDI Assign-

ment.f8c”.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#83 CC#20 CC#74 CC#79

64 [B]

Name LFO Rate LFO Vibrato LFO Timbre LFO Tremolo

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#90 CC#103 CC#104 CC#105

65 Massive

Name Filter 1 Cutoff Filter 1 Resonance Filter 2 Cutoff Filter 2 Resonance

1: Copy the setting file “KORG MIDI Setup.mca” into the following folder. Windows: The

“mca” folder is located in the folder where the Massive is installed.

(e.g. C:\Program Files\Native Instruments\Massive\mca)

Mac: /Library/Application Support/Native Instruments/Massive/mca

2: Select “Preference...” in “Massive” menu to open “Massive Options”. Double-Click

“KORG MIDI Setup” in the “Midi Setups” of “Midi” page to turn it “on”.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#30 CC#68

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

11

66 Native Instruments PRO-53

Name Oscillator A Pulse

Width

Oscillator B Pulse

Width Filter Cutoff Filter Resonance

Click the “NI” logo. Select “Load Controllermap” in the displayed menu and load

“DefaultMap.txt” from the “Presets”-“Controller maps” folder inside the folder where

PRO-53 is installed.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#43 CC#55 CC#70 CC#71

67

Propellerhead

Reason

[Pan]

Name Channel 1 Pan Channel 2 Pan Channel 3 Pan Channel 4 Pan

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#23 CC#24 CC#25 CC#26

68 [Volume]

Name Channel 1 Level Channel 2 Level Channel 3 Level Channel 4 Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 CC#9 CC#10 CC#12

69 Dr.Rex

Name Filter Freq Filter Res Filter Mode Filter Env Amount

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#76 CC#18

70 Malstrom

Name OSC A motion OSC A shift Filter A res Filter A Freq

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#92 CC#86 CC#78 CC#79

71 NN-19

Name Filter Freq Filter Res Filter Mode Filter Env Attack

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#76 CC#14

72 NN-XT

Name Filter Freq Filter Res Amp Env Attack Amp Env Decay

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#73 CC#9

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

12

73

Propellerhead

ReDrum

[Pan]

Name Drum 1 Pan Drum 2 Pan Drum 3 Pan Drum 4 Pan

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#19 CC#20 CC#21 CC#22

74 [Level]

Name Drum 1 Level Drum 2 Level Drum 3 Level Drum 4 Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 CC#9 CC#10 CC#12

75 [Pitch]

Name Drum 1 Pitch Drum 2 Pitch Drum 3 Pitch Drum 4 Pitch

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#51 CC#52 CC#53 CC#54

76 Subtractor

Name OSC 1 Phase OSC 2 Phase FM MIX

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#93 CC#106 CC#108 CC#107

77

Spectrasonics

Atmosphere

Name Layer A Pan Layer A Level Layer B Pan Layer B Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#83 CC#81 CC#84 CC#82

78

Stylus RMX

[A]

Na me F ILTER LFOS RAT E FILTER LF O S DEPTH FILTER LFOS WAVE CHAOS DOWN/UP

Load the “StylusRMX_KORG.mlt_rmx” as the MIDI Learn set file.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#16 CC#17 CC#18 CC#19

79 [B]

Name CHAOS PATTERN CHAOS REPEAT CHAOS REVERSE SAMPLE START

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#80 CC#81 CC#82 CC#83

80 Trilogy

Name Layer A Pan Layer A Level Layer B Pan Layer B Level

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#83 CC#81 CC#84 CC#82

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

13

81

Steinberg

Cubase

[Audio Pan]

Name Audio Pan1 Audio Pan2 Audio Pan3 Audio Pan4

First, you need to install the KORG USB/MIDI driver.

1: Select “Device Setup...” from the “Devices” menu and open the “Device setup” dialog.

Select “Generic Remote” from the “Devices” list in the left column. Select “keyboard”

for the “MIDI input” and press the “Import” button. Load “Cubase_KORG.xmll”. (If you

do not find “Generic Remote” in the left column, please add it using the “Add/

Remove” function.)

2: Press the “Apply” button.

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#10 CC#10 CC#10 CC#10

82 [Audio Level]

Name Audio Level 1 Audio Level 2 Audio Level 3 Audio Level 4

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#7 CC#7 CC#7 CC#7

83 [MIDI Pan]

Name MIDI Pan1 MIDI Pan2 MIDI Pan3 MIDI Pan4

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#41 CC#41 CC#41 CC#41

84 [MIDI Level]

Name MIDI Level 1 MIDI Level 2 MIDI Level 3 MIDI Level 4

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#35 CC#35 CC#35 CC#35

85 A1

Name Oscillator 1 FM Filter Cutoff Filter Resonance Filter Drive

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#74 CC#71 CC#29

86 Monologue

Name OSC1 DEPTH OSC2 PWM OSC2 DEPTH FX OVER DRIVE

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#103 CC#19 CC#105 CC#70

87 Tonic

Name ENV MOD ATTACK ENV MOD RELEASE RES CUTOFF

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#73 CC#72 CC#71 CC#74

88 Embracer

Name OSC1 WAVE OSC1 TONE OSC1 WIDTH OSC2 WAVE

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#9 CC#74 CC#16 CC#14

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

14

89

Steinberg

Groove Agent

Name Kick Volume Snare Volume Tom Volume Hi-Hat Volume

In the host application, change the MIDI output channel for the MIDI track you want to

use “Groove Agent” on to “ANY” or other multi-channel outputs.

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#73 CC#73 CC#73 CC#73

90 HALion

Name DCF CUTOFF DCF RESONANCE DCF VELOCITY DCF ENV. AMOUNT

Enable “RECEIVE MIDI CONTROLLER” in “KEY/CONTROL OPTION” of the “OPTIONS”

page.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#15 CC#80

91 Hypersonic

Name GM Edit: cutoff GM Edit: resonance GM Edit: filt env att GM Edit: filt env

dec+rel

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#74 CC#71 CC#77 CC#78

92 Virtual Guitarist

Name Shuffle Dynamics Timing Decay

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#76 CC#79 CC#78 CC#75

93

Waldorf

Attack

Name Osc 1 Pitch Osc 1 Level Osc 2 Pitch Osc 2 Level

In the host application, change the MIDI output channel for the MIDI track on which

“Attack” is used for each of the sounds that you want to remote-control such as kick,

snare, drum, etc.

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#13 CC#28 CC#22 CC#30

94 PPG Wave 2.V

Name BASIS VCF-CUTOFF VCF-EMPHASIS ENV1>VCF

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#8 CC#74 CC#71 CC#28

95

ToonTrack

dfh

Name Free Free Free Free

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note Off Off Off Off

96 EZ Drummer

Name Free Free Free Free

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note Off Off Off Off

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

15

Manufacturer Name

•KORG:TheseproductnamesarethetrademarkoraregisteredtrademarksofKORGInc.

•Ableton:ThisproductnameisatrademarkoraregisteredtrademarkofAbletonAG.

• AppliedAcousticsSystems:TheseproductnamesarethetrademarkoraregisteredtrademarksofApplied

AcousticsSystemsDVMInc.

• Arturia:TheseproductnamesarethetrademarkoraregisteredtrademarksofArturia.

• Apple:ThisproductnameisatrademarkoraregisteredtrademarkofAppleInc.

• Fxpansion:ThisproductnameisatrademarkoraregisteredtrademarkofFXpansionAudioUKLtd.

• GMEDIA:TheseproductnamesarethetrademarkoraregisteredtrademarksofGMEDIAMusic.

•Image‐LineSoftware:ThisproductnameisatrademarkoraregisteredtrademarkofImage‐LineSoftware.

•MOTU:TheseproductnamesarethetrademarkoraregisteredtrademarksofMOTU,Inc.

•NativeInstruments:TheseproductnamesarethetrademarkoraregisteredtrademarksofNativeInstruments

GmbH.

•Propellerhead:TheseproductnamesarethetrademarkoraregisteredtrademarksofPropellerheadSoftwareAB.

• Spectrasonics:TheseproductnamesarethetrademarkoraregisteredtrademarksofSpectrasonics.

• Steinberg:TheseproductnamesarethetrademarkoraregisteredtrademarksofSteinbergMediaTechnologies

GmbH.

•WaldorfandtheWaldorfLogoareregisteredtrademarksofWaldorfMusicGmbH.

• ToonTrack:TheseproductnamesarethetrademarkoraregisteredtrademarksofToontrackMusicAB.

• UltimateSoundBank:TheseproductnamesarethetrademarkoraregisteredtrademarksofUniversSons,SA.

97

UltimateSoundBank

PLUGSOUND PRO

[Pan]

Name Timbre 1 Pan Timbre 2 Pan Timbre 3 Pan Timbre 4 Pan

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#10 CC#10 CC#10 CC#10

98 [Volume]

Name Timbre 1 Volume Timbre 2 Volume Timbre 3 Volume Timbre 4 Volume

Ch Ch:01G Ch:02 Ch:03 Ch:04

CC#/Note CC#7 CC#7 CC#7 CC#7

99 Charlie

Name Filter Cutoff Filter Resonance Master filter cutoff Master filter reso-

nance

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#78 CC#74 CC#71

100 Ultra Focus

Name Filter Cutoff Filter Resonance Master filter cut fre-

quency

Master filter reso-

nance

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#78 CC#74 CC#71

101 X-treme FX

Name Filter Cutoff Filter Resonance Master filter cut fre-

quency

Master filter reso-

nance

Ch Global Ch Global Ch Global Ch Global Ch

CC#/Note CC#77 CC#78 CC#74 CC#71

1: These operations will overwrite the previous MIDI Control settings. If necessary, back up the previous control Midi file.

2: When the MIDI channel settings of the host application and the plug-in software are the same, proper control may not be available. Please change the MIDI channel setting on

either the host application or the plug-in software. Please refer to the application’s manual for the correct setting

Manufacturers Product Name Scene

Variation Knob 1 Knob 2 Knob 3 Knob 4 HINT

4015-2 Yanokuchi, Inagi-city, Tokyo 206-0812 Japan

© 2010 KORG INC.

IMPORTANT NOTICE TO CONSUMERS

This product has been manufactured according to strict specifications and voltage

requirements that are applicable in the country in which it is intended that this product should

be used. If you have purchased this product via the internet, through mail order, and/or via a

telephone sale, you must verify that this product is intended to be used in the country in

which you reside.

WARNING: Use of this product in any country other than that for which it is intended could

be dangerous and could invalidate the manufacturer’s or distributor’s warranty.

Please also retain your receipt as proof of purchase otherwise your product may be

disqualified from the manufacturer’s or distributor’s warranty.
