Users Manual
Quick Start Guide for the
KYOCERA DuraForce
Get Started 2
Important Safety Information 18
Manufacturer’s Warranty 33
End User License Agreement 36
© 2014 Kyocera Corporation. All rights reserved. KYOCERA is a registered trademark of Kyocera Corporation. All other trademarks are
the property of their respective owners.
Android, Google Play, Google Maps, Gmail, and YouTube are trademarks of Google Inc.
The
Bluetooth
® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Kyocera
Corporation is under license. Other trademarks and trade names are those of their respective owners.
Get Started 2
♦Your KYOCERA DuraForce (page 2)
♦Get Your Phone Ready (page 3)
♦Use Your Phone (page 6)
♦ Customer Support (page 16)
♦Notes (page 17)
This section introduces you to the basics of getting started with
your KYOCERA DuraForce. Visit http://www. com/ for
the complete User Guide and additional information.
Get Started
Your KYOCERA DuraForce
LED Indicator
Touchscreen
Home Key
Primary Microphone
USB/Charging Port
Audio Jack
Speakers
Recent Apps Key
< Front > < Top >
< Bottom >
Front Camera
Back Key
Secondary
Microphone Power/Lock Key
Speaker Key
Proximity/
Light Sensor
3 Get Started
Charge the Battery
Important: Before turning on your phone, fully charge the
battery. Be sure to use the charger that came
with your phone.
1. Open the cover to the USB/charging port on the
bottom of the phone.
2. Plug the smaller end of the micro-USB cable into the
phone’s USB/charging port.
3. Plug the other end of the USB cable into the charger,
and then plug the charger into an electrical outlet.
4. When charging is complete, remove the cable from the
port and close the cover. Press around the edges of
the cover to ensure that it is securely closed.
Warning:Be sure all ports and covers are properly sealed
to maintain the phone's waterproof capability.
Back
Camera
Volume Key
Programmable
Key
< Sides > < Back >
microSD Card/
SIM Card Slots
Camera
Flash
Internal
Antennas
Get Your Phone Ready
Get Started 4
Insert the SIM Card
If not already inserted, follow the instructions below to insert
a SIM card.
Warning:Use only a Nano SIM card for this phone.
1. Open the cover to the microSD card/SIM card slots on
the side of the phone.
2. Place the SIM card on the SIM card tray so that the cut
corner of the card follows the shape of the tray. Holding
the card and the tray with your fingers, insert them into
the SIM card slot on the left and close the cover.
3. Press around the edges of the cover to the microSD
card/SIM card slots to ensure that it is securely closed.
Warning:Be sure all ports and covers are properly sealed
to maintain the phone's waterproof capability.
Insert the microSD Card
A microSD™ card is an optional accessory that allows you
to store images, videos, music, documents, and voice data.
1. Open the cover to the microSD card/SIM card slots on
the side of the phone.
2. Insert a microSD card into the microSD card slot on
the right with the gold terminals facing up. Gently push
the card in until it snaps into place and close the cover.
Tra y
Cut
SIM Card
5 Get Started
3. Press around the edges of the cover to the microSD
card/SIM card slots to ensure that it is securely closed.
Warning:Be sure all ports and covers are properly sealed
to maintain the phone's waterproof capability.
Turn the Phone On
Press and hold the Power/Lock key until the screen
lights up.
Turn the Screen On and Off
Press the Power/Lock key to turn the screen on and off.
Start the Phone
On the default screen, swipe toward Start.
Turn the Phone Off
1. Press and hold the Power/Lock key until the phone
options are displayed.
2. Tap Power off > OK.
microSD Card
Terminals
Get Started 6
Voicemail
Set Up Your Voicemail
All unanswered calls are automatically transferred to your
voicemail, even if your phone is in use or turned off. You
should set up your voicemail and personal greeting as soon
as your phone is activated:
1. Tap the Phone icon on the Home screen and tap
Dialpad to display the phone dialpad.
2. Touch and hold .
3. Follow the voice prompts to create your password and
record your name and greeting.
It is strongly recommended that you set a voicemail
password. Without a password, anyone who has access to
your phone can access your messages.
Retrieve Your Voicemail
Touch and hold on the phone dialpad.
From any other phone:
1. Dial your wireless phone number.
2. When your voicemail answers, press the asterisk key (*).
3. Enter your password.
Phone Calls
Make a Phone Call
1. Tap the Phone icon on the Home screen and tap
Dialpad to display the phone dialpad.
2. Tap the digits of the number you want to call on the
dialpad. Tap Delete to delete one or more digits.
3. Tap Call at the bottom of the screen to place the call.
4. Tap End call when you are finished.
Use Your Phone
7 Get Started
Respond to an Incoming Call
On the incoming call screen, swipe or touch and hold
to answer the call.
Swipe or touch and hold to send the call to your
voicemail inbox.
Swipe or touch and hold to ignore the call and
send a message to the caller.
Note: While on a call and holding the phone near your face
to speak, the touchscreen automatically deactivates
to avoid accidental screen presses. When you move
the phone away from your face, the touchscreen
automatically reactivates.
Home Screen Display Settings
Add App Shortcuts or Widgets to the Home Screen
1. Touch and hold the empty area on the Home screen.
2. Tap Apps or Widgets and slide the screen to find the
item you want to add to the Home screen.
3. Touch and hold the app icon or a widget and move
your finger to one of the Home screens.
4. When you find the position to place the item, release
your finger.
Move or Remove Items on the Home Screen
Touch and hold the item you want to move or remove
from the Home screen.
▪To move the item, drag it to a new area and release it.
▪To remove the item, drag it to “Remove” at the top of
the screen and release it when it turns red.
Get Started 8
Change the Wallpaper
1. Touch and hold the empty area on the Home screen.
2. Tap Wallpapers and select an option:
▪Gallery to use a saved picture in Gallery.
▪Wallpapers to use a preset wallpaper.
▪Live wallpapers to use a Live wallpaper.
▪Photos to use a saved picture in Photos.
3. Select an image, crop it if necessary, and tap Set
wallpaper or SET WALLPAPER.
Sound Settings
Adjust the Volume
1. Press > > Settings > Sound > Volumes.
2. Use the sliders to set the volume level for Music,
video, games, & other media, Ringtone &
notifications, Alarms, or System.
3. Tap OK to save your settings.
Tip: You can adjust the ringer volume in standby mode (or
the earpiece volume during a call) by using the volume
key on the left side of your phone.
Mute All Sounds
Press the volume key down in standby mode until you see
or on the status bar.
9 Get Started
Select a Ringtone
1. Press > > Settings > Sound > Phone
ringtone.
2. Tap a ringtone from the list. The ringtone briefly plays
when selected.
– or –
Tap Add and select a sound data.
3. Tap OK to assign the ringtone.
Select a Notification Sound
1. Press > > Settings > Sound >
Default notification sound.
2. Tap a sound from the list. The sound briefly plays
when selected.
– or –
Tap Add and select a sound data.
3. Tap OK to assign the notification sound.
Select a Vibrate Pattern
1. Press > > Settings > Sound >
Vibrate pattern.
2. Tap a vibrate pattern from the list. Your phone briefly
vibrates when selected.
3. Tap OK to assign the vibrate pattern.
Contacts
View Contacts
1. Tap the Contacts icon on the Home screen.
2. Scroll through the list to view your contacts.
Add a New Contact
1. Tap the
Contacts
icon on the Home screen and tap
.
2. Select an account to add your new contact to, if prompted.
Get Started 10
3. Add as much or as little information as you want.
▪To add information in a field, tap the field to display
the touchscreen keyboard.
▪To assign a number or address type (such as
MOBILE, HOME, WORK, etc.), tap the label next to
the number or address field.
▪
To assign a picture, tap the icon next to the name, and
select to take a picture or choose a picture from Gallery.
4. Tap Save when you are finished.
Edit Contacts
1. Tap the Contacts icon on the Home screen.
2. Tap a contact to open it, and tap > Edit.
▪Tap a field to add or edit information.
3. Tap Save when you are finished.
Note: To delete a contact, tap > Delete > OK.
Messaging
Send a Message
1. Tap the Messaging icon on the Home screen and
tap .
2. Enter a phone number or email address in the To field.
Tip: Enter a name saved in contacts to call up the phone
number or email address. Tap a match from an
available list.
Tip: Tap next to the field to access your contacts.
3. Tap the Type message field and type your message.
▪To attach pictures or files, tap and select a file.
▪To add a subject, tap > Add subject, and then
type a subject.
4. When you are finished, tap .
11 Get Started
Access Messages
Tap the Messaging icon on the Home screen. Tap a
thread to open and read the messages in the thread.
If you have a new message notification, drag the status
bar down to open the Notifications panel. Tap a message
to open and read it.
Email Setup
Set Up a Gmail® Account
1. Tap the Google folder on the Home screen and tap the
Gmail icon.
2. Follow the instructions to set up or sign in to a Gmail
account.
Note: Although you need a Gmail account to use certain
features such as Google Play™, you do not have to
use Gmail as the default account for your phone.
Note: When setting up a new Google Account, you will be
prompted to add a secondary email address. Enter a
second Gmail address or any other email address
from which you currently send and receive email.
This address is used to authenticate your account
should you ever encounter problems or forget your
password. It is strongly encouraged for Android
users so you can regain access to Google Mobile™
services and purchases on your phone.
Set Up an Email Account
1. Tap the Email icon on the Home screen.
2. Follow the instructions to sign in to your email account.
▪If you are adding an account from a common email
provider, such as Windows Live Hotmail or Yahoo
Mail, enter your email address and password and tap
Next. Your email should be set up automatically.
▪If you are adding an account from a less common
email provider, or if you have additional settings to
configure, enter your email address and password
Get Started 12
and tap Manual setup. Follow the instructions to
provide the required information.
Note: If you are not sure about your account, tap Next
after entering your email address and password. If
your phone can’t autoconfigure your account, you’ll
then be asked to configure it manually.
Set Up a Microsoft® Exchange® Account
1. Press > > Settings > Add account >
Corporate.
2. Enter the Exchange server account details and tap
Next.
▪Contact your Exchange Server administrator for
required sign-in information.
3. Select the frequency and sync options and tap Next.
4. Identify your new account with a unique name and tap
Next.
Send an Email Message
1. Tap the Email icon on the Home screen.
▪If necessary, tap the email account you want to use.
2. On the email account inbox, tap .
3. Enter an email address or contact name in the To field.
Tap next to the field to access your contacts.
4. Enter a subject and a message.
▪To add attachments, tap > Attach file and select
an attachment.
5. Tap .
13 Get Started
Bluetooth
Pair and Connect With a Bluetooth® Device
1. Press > > Settings > Bluetooth.
▪If Bluetooth is not turned on, tap the Bluetooth
ON/OFF icon to ON.
2. Select an available device and follow the prompts to
pair your phone with the device. You may be required
to enter a passcode (often 0000) to complete pairing.
Web
Go Online
Tap the Browser icon on the Home screen.
Open a Web Page by Entering an URL
1. From any open Web page, tap the URL field and enter
the Web address.
▪As you type the address, if your desired website
appears within the suggested sites list, tap the entry
to begin surfing.
2. Tap Go.
Tip: You can also enter a search term to the URL field to
perform Web search.
Access Bookmarks
From any open Web page, tap > Bookmarks.
Create Bookmarks
1. Open the Web page you want to bookmark and
tap > Bookmarks > Add bookmark.
2. Enter a descriptive name for the new bookmark.
3. Select where to save the bookmark and tap OK.
Get Started 14
Camera & Camcorder
Take a Picture
1. Tap the Camera icon on the Home screen.
▪Tap Switch to to switch between the front camera
and the back camera.
2. Frame your subject on the screen.
3. Tap to take a picture.
Record a Video
1. Tap the Camera icon on the Home screen.
▪Tap Switch to to switch between the front camera
and the back camera.
▪Tap Settings > More > Video size and then select
QVGA(MMS) or QCIF(MMS) to select the video size
for MMS.
2. Frame your subject on the screen.
3. Tap to begin recording. Tap to stop.
Google Play™ on Your Phone
Download Applications and Games
1. Tap the Play Store icon on the Home screen.
2. The first time you visit the Google Play Store app, the
Terms of Service window will appear. Tap Accept to
continue if you agree to the Terms of Service.
3. Find an application you want and tap it to open its
details screen.
4. Tap INSTALL (for free applications) or the price button
(for paid applications).
5. If you agree for the app to access the listed information,
tap ACCEPT.
Note: You must have a Google (Gmail™) Account set up
on your phone to purchase and download content
from Google Play.
15 Get Started
Note: You need a Google Wallet account to purchase items
on Google Play.
Emergency Alerts
Your phone is compatible with the federally supervised cell
phone alert services to send out broadcast SMS messages
for public warning.
Display the Emergency Alerts
Press > > Emergency Alerts.
Disable the Emergency Alerts
1. Press > > Emergency Alerts > >
Settings.
2. Clear the check box next to each alert under
EMERGENCY ALERT SETTINGS.
Note: You cannot disable the Presidential alert.
Your Navigator Deluxe
With Your Navigator Deluxe, get all of the features of an
advanced car navigation system on your mobile phone with
voice turn-by-turn navigation enabled by GPS. Search for
any destination including gas stations, ATMs, restaurants,
and more. Get detailed maps of any location.
Activate Location Mode
In order to use Your Navigator Deluxe, you must first turn on
your phone’s location and GPS settings.
1. Tap > > Settings > Location.
2. Tap the OFF icon at the top right on the screen.
3. Read the message and tap Agree to allow apps to use
the GPS location feature.
4. Read the second message and tap Agree to allow
apps to use Google’s location service.
Get Started 16
Use Your Navigator Deluxe
1. Scroll to the right on the Home screen and tap the
Your Navigator Deluxe icon.
2. From the Home screen, you can select:
▪Drive To for turn by turn direction to an address,
airport, contacts addresses and more.
▪Places to search for nearby businesses, the
cheapest gas prices and more.
▪Maps & Traffic to see where you currently are
located on a map and what traffic is in the area.
customer support is available from the following
resources:
●Access http://www. com/support to see a range
of support for your smartphone.
●Call Customer Service at 1-888- , or from
your smartphone.
Customer Support
17 Get Started
●The services described in this guide may require a
subscription to a service plan and/or may incur additional
charges. Not all services will work on all phones. Please
visit http://www. com/ for more details.
●Instructions to perform tasks in this guide may change
depending on the software version on your phone.
●All screens and icon images in this guide are simulated.
Actual displays may vary.
●Important Privacy Message. This phone is capable of
determining its/your geographical location. To set controls
for access and use of your location information by others,
press > > Settings > Location and enable or
disable the Location services. Follow any applicable
prompts. For some applications and services you select,
a phone must be turned on and set to allow collection of
location information in order to function.
Notes
Important Safety Information 18
♦General Precautions (page 18)
♦Maintaining Safe Use of and Access to Your Phone
(page 19)
♦Waterproof Capability (page 24)
♦Using Your Phone With a Hearing Aid Device (page 25)
♦Caring for the Battery (page 27)
♦Radio Frequency (RF) Energy (page 29)
♦Owner’s Record (page 32)
This section contains important operational and safety
information that will help you safely use your phone. Failure
to read and follow the information provided in this section
may result in serious bodily injury, death, or property
damage.
There are several simple guidelines to operating your phone
properly and maintaining safe, satisfactory service.
●To maximize performance, do not touch the portions of
your phone where the internal antennas are located while
using the phone.
●Speak directly into the mouthpiece.
●Do not expose your phone to direct sunlight for extended
periods of time (such as on the dashboard of a car).
●Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending, or sitting on it.
Important Safety Information
General Precautions
19 Important Safety Information
●Any changes or modifications to your phone not expressly
approved in this document could void your warranty for
this equipment and void your authority to operate this
equipment.
Note: For the best care of your phone, only Kyocera-
authorized personnel should service your phone and
accessories. Failure to do so may be dangerous and
void your warranty.
Do Not Rely on Your Phone for Emergency
Calls
Mobile phones operate using radio signals, which cannot
guarantee connection in all conditions. Therefore you should
never rely solely upon any mobile phone for essential
communication (e.g., medical emergencies). Emergency
calls may not be possible on all cellular networks or when
certain network services or mobile phone features are in
use. Check with your local service provider for details.
Using Your Phone While Driving
Talking on your phone while driving (or operating the phone
without a hands-free device) is prohibited in some
jurisdictions. Laws vary as to specific restrictions.
Remember that safety always comes first.
Following Safety Guidelines
To operate your phone safely and efficiently, always follow
any special regulations in a given area. Turn your phone off
in areas where use is forbidden or when it may cause
interference or danger.
Maintaining Safe Use of and Access
to Your Phone
Important Safety Information 20
Medical Devices
If you have a medical device, including an implantable
medical device such as a pacemaker or defibrillator, consult
your healthcare provider and the device manufacturer’s
directions before using this mobile phone.
Persons with implantable medical devices:
●Should always keep the mobile phone more than six (6)
inches from the implantable medical device when the
mobile phone is turned ON.
●Should not carry the mobile phone in the breast pocket.
●Should use the ear opposite the implantable medical
device to minimize the potential for interference.
●Should turn OFF the mobile phone immediately if you
have any reason to suspect that interference is taking
place.
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, RF signals from wireless
phones may affect inadequately shielded electronic
equipment.
RF signals may affect improperly installed or inadequately
shielded electronic operating systems or entertainment
systems in motor vehicles. Check with the manufacturer or
their representative to determine if these systems are
adequately shielded from external RF signals. Also check with
the manufacturer regarding any equipment that has been
added to your vehicle.
Consult the manufacturer of any personal medical devices,
such as pacemakers and hearing aids, to determine if they
are adequately shielded from external RF signals.
21 Important Safety Information
Note: Always turn off the phone in healthcare facilities,
and request permission before using the phone near
medical equipment.
Turning Off Your Phone Before Flying
Turn off your phone before boarding any aircraft. To prevent
possible interference with aircraft systems, the U.S. Federal
Aviation Administration (FAA) regulations require you to have
permission from a crew member to use your phone while the
plane is on the ground. To prevent any risk of interference,
FCC regulations prohibit using your phone while the plane is in
the air.
Turning Off Your Phone in Dangerous Areas
To avoid interfering with blasting operations, turn your phone
off when in a blasting area or in other areas with signs
indicating two-way radios should be turned off. Construction
crews often use remote-control RF devices to set off
explosives.
Turn your phone off when you’re in any area that has a
potentially explosive atmosphere. Although it’s rare, your
phone and accessories could generate sparks. Sparks can
cause an explosion or fire, resulting in bodily injury or even
death. These areas are often, but not always, clearly
marked. They include:
●Fueling areas such as gas stations.
●Below deck on boats.
●Fuel or chemical transfer or storage facilities.
●Areas where the air contains chemicals or particles such
as grain, dust, or metal powders.
●Any other area where you would normally be advised to
turn off your vehicle’s engine.
Important Safety Information 22
Note: Never transport or store flammable gas, flammable
liquids, or explosives in the compartment of your
vehicle that contains your phone or accessories.
Note: Your phone complies with the Standards for Hazardous
Location Equipment. Refer to the following section
‘Using Your Phone in Hazardous Locations’ for details.
Using Your Phone in Hazardous Locations
Your phone complies with the Standards for Hazardous
Location Equipment as a Nonincendive Electrical Equipment
for use in a Class I, Division 2, Groups A, B, C & D with a
Temperature Code of T4.
Precautions
●Ensure that your phone is not exposed to the temperature
outside the limits stated below.
▪Ambient Temperature:
-22° F to 140° F (-30° C to 60° C)
▪Charging Temperature:
32° F to 122° F (0° C to 50° C)
▪Storage Temperature:
-40° F to 185° F (-40° C to 85° C)
●Do not charge your phone in Division 2 hazardous
locations.
●Use only the charger provided with your phone: battery
charger SCP-44ADT and USB data cable SCP-17SDC.
●The audio jack, charger/data port, and microSD card/SIM
card slot covers must be properly sealed in Division 2
hazardous locations.
●Do not connect anything to the audio jack or the
charger/data port in Division 2 hazardous locations.
●Do not open the microSD card/SIM card slot covers,
remove, or insert a microSD card or a SIM card in
Division 2 hazardous locations.
23 Important Safety Information
Detecting Damages
If you suspect any compromise on the safety of your phone,
immediately stop the operation and remove it from the
hazardous locations. Some examples where the safety of the
phone may be impaired are when:
●the exterior of the phone has a visible damage, or the
markings or inscriptions are illegible.
●the phone has been damaged in transit, improperly
stored, or subjected to excessive loads.
●malfunctions occur.
●permitted limit values have been exceeded.
Warning:EXPLOSION HAZARD - SUBSTITUTION OF
COMPONENTS MAY IMPAIR SUITABILITY FOR
USE IN CLASS I, DIVISION 2.
4009869
Conforms to ANSI/ISA 12.12.01 & UL 60950-1
Restricting Children’s Access to Your Phone
Your phone is not a toy. Do not allow children to play with it
as they could hurt themselves and others, damage the
phone or make calls that increase your invoice.
Important Safety Information 24
Your DuraForce is waterproof and meets IPX5, protection
against sprayed water and IPX8 standards, submersible for
up to 30 minutes at a depth not exceeding 1.8 meters
(about 6 feet). Exposing your phone to water outside these
limits or not following the precautions can result in water
damage and will invalidate the Consumer Limited Warranty.
To ensure that your phone maintains waterproof capability,
the following precautions must be observed.
●Make sure the charger/data port, audio jack and card slot
covers are properly seated, with no foreign objects
obstructing the seals.
●Do not spray or immerse your phone in liquids other than
fresh water or tap water, such as detergent, beverages,
or chlorinated or treated water. Certain liquids such as
salt water and chlorinated water are corrosive over time.
Should your phone be accidentally exposed to other
liquids, rinse the phone gently in clean fresh water.
●Do not expose your phone to water heated in excess of
104°F (40°C).
●Your phone is inoperable under water and should be dried
as quickly as possible when wet.
●Do not use the charger/data port for charging, data
transmission, etc. until the phone is completely dry.
●Do not use the audio jack to plug in an accessory until the
phone is completely dry.
If your phone gets wet:
Water in the phone’s open microphone and speaker ports
may affect outbound audio quality and speaker performance.
These are temporary conditions and will subside once the
phone is dry.
1. Wipe the phone surfaces with a dry clean cloth.
2. Water in the phone’s open microphone and speaker
ports (small holes located at the top and bottom and
grid of holes along the bottom front of the phone)
should be removed with puffs of air directly into the
Waterproof Capability
25 Important Safety Information
ports. Phone audio may not operate properly until
ports are dry. Apply a dry clean cloth to the open
areas and crevices to remove the moisture left on the
phone: microphones; speakers; all physical keys;
card slot cover; audio jack cover; and charger/data
port cover.
3. Repeat the process until the phone is completely dry.
Charging
●Dry your phone with a clean cloth before charging.
●Do not touch the charger, charging cable, or charger/data
port with wet hands. Doing so may cause electric shock,
injury, or product failure.
●Do not charge your phone in a wet or damp place, such
as in a bathroom or near a kitchen sink.
When some wireless phones are used with certain hearing
devices (including hearing aids and cochlear implants),
users may detect a noise which can interfere with the
effectiveness of the hearing device.
Some hearing devices are more immune than others to this
interference noise, and phones also vary in the amount of
interference noise they may generate. ANSI standard
C63.19 was developed to provide a standardized means of
measuring both wireless phone and hearing devices to
determine usability rating categories for both.
Ratings have been developed for mobile phones to assist
hearing device users find phones that may be compatible
with their hearing device. Not all phones have been rated for
compatibility with hearing devices. Phones that have been
rated have a label located on the box. Your DuraForce has
an M4 and a T3 rating.
Using Your Phone With a Hearing Aid
Device
Important Safety Information 26
These ratings are not guarantees. Results will vary
depending on the user’s hearing device and individual type
and degree of hearing loss. If a hearing device is particularly
vulnerable to interference noise; even a phone with a higher
rating may still cause unacceptable noise levels in the
hearing device. Trying out the phone with your hearing
device is the best way to evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements
for hearing aid compatibility and are likely to generate less
interference to hearing devices than unrated phones. (M4 is
the better/higher of the two ratings.)
T-Ratings: Phones rated T3 or T4 meet FCC requirements
and are likely to be more usable with a hearing device’s
telecoil (“T Switch” or “Telephone Switch”) than unrated
phones. (T4 is the better/higher of the two ratings. Note that
not all hearing devices have telecoils in them.)
Note: This phone has been tested and rated for use with
hearing aids for some of the wireless technologies
that it uses. However, there may be some newer wireless
technologies used in this phone that have not been
tested yet for use with hearing aids. It is important to
try the different features of this phone thoroughly
and in different locations, using your hearing aid or
cochlear implant, to determine if you hear any
interfering noise. Consult your service provider or the
manufacturer of this phone for information on
hearing aid compatibility. If you have questions about
return or exchange policies, consult your service
provider or phone retailer.
Hearing aid devices may also be measured for immunity to
interference noise from wireless phones and should have
ratings similar to phones. Ask your hearing healthcare
professional for the rating of your hearing aid. Add the rating
of your hearing aid and your phone to determine probable
usability:
●Any combined rating equal to or greater than six offers
excellent use.
27 Important Safety Information
●Any combined rating equal to five is considered normal
use.
●Any combined rating equal to four is considered usable.
Thus, if you pair an M3 hearing aid with an M3 phone, you
will have a combined rating of six for “excellent use.” This is
synonymous for T ratings.
More information about hearing aid compatibility may be
found at: www.fcc.gov, www.fda.gov, and
www.accesswireless.org.
Getting the Best Hearing Device Experience
With Your Phone
To further minimize interference, move the phone around to
find the point with least interference.
Note: The battery cannot be removed from the phone. For
replacing or disposing the battery, contact a
KYOCERA authorized service center.
Your DuraForce is installed with a lithium ion (Li-Ion) battery.
The guidelines listed below help you get the most out of your
battery’s performance.
Charging
●Only use the battery with a qualified charger. Use of an
unqualified battery charger may present a risk of fire,
explosion, leakage, or other hazard. If you are unsure
about whether a charger is qualified, contact customer
support.
●In order to avoid damage, charge the battery only in
temperatures that range from 32° F to 113° F (0° C to
45° C).
Caring for the Battery
Important Safety Information 28
●Don’t use the battery charger in direct sunlight or in high
humidity areas, such as the bathroom.
●The battery may need recharging if it has not been used
for a long period of time.
●It’s best to replace the battery when it no longer provides
acceptable performance. It can be recharged hundreds of
times before it needs replacing. The battery cannot be
removed from the phone. Contact a KYOCERA authorized
service center for replacing the battery.
Common Causes of Battery Drain
●Playing games or using the Web.
●Keeping backlighting on.
●Operating the phone far away from a base station or cell
site.
●Using data cables or accessories.
●Operating the phone when no service is available, or
service is available intermittently.
●High volume settings.
●Repeating sound, vibration, or lighted alerts.
Storing
●Don’t store the battery in high temperature areas for long
periods of time. It’s best to follow these storage rules:
▪Less than one month:
-4° F to 140° F (-20° C to 60° C)
▪More than one month:
-4° F to 113° F (-20° C to 45° C)
29 Important Safety Information
Disposal of Lithium Ion (Li-Ion) Battery
Installed in Your Phone
●The battery cannot be removed from the phone. For safe
disposal options of your Li-Ion battery, contact your
nearest KYOCERA authorized service center.
Understanding How Your Phone Operates
Your phone is a radio transmitter and receiver. When it’s
turned on, it receives and transmits radio frequency (RF)
signals. Your phone is designed to transmit just enough RF
power to reach the network. The system handling your call
controls the RF power level. Depending on network
conditions, your phone may operate at an actual Specific
Absorption Rates (SAR) level below the maximum value
specified. Your phone is designed not to exceed the
recommended international guidelines for limits on RF
exposure.
Knowing Radio Frequency Safety
The design of your phone complies with updated NCRP
standards described below.
In 1991–92, the Institute of Electrical and Electronics
Engineers (IEEE) and the American National Standards
Institute (ANSI) joined in updating ANSI’s 1982 standard for
safety levels with respect to human exposure to RF signals.
More than 120 scientists, engineers and physicians from
universities, government health agencies and industries
developed this updated standard after reviewing the
available body of research. In 1993, the Federal
Communications Commission (FCC) adopted this updated
standard in a regulation. In August 1996, the FCC adopted
hybrid standard consisting of the existing ANSI/IEEE
Radio Frequency (RF) Energy
Important Safety Information 30
standard and the guidelines published by the National
Council of Radiation Protection and Measurements (NCRP).
Body-Worn Operation
To maintain compliance with FCC RF exposure guidelines,
always use an appropriate accessory if using the phone for
body worn operations. Accessories used with this phone for
body worn operations must not contain any metallic
components and must provide at least 0.39 inches
(1.0 centimeters) separation distance between the user’s
body and the phone, including antennas. Body worn
accessories that do not meet these requirements may not
comply with FCC RF exposure requirements and should be
avoided.
For more information about RF exposure, visit the FCC
website at www.fcc.gov.
Specific Absorption Rates (SAR) for
Wireless Phones
The SAR value corresponds to the relative amount of RF
energy absorbed into the head of a user of a wireless
handset.
The SAR value of a phone is the result of an extensive
testing, measuring and calculation process. It does not
represent how much RF the phone emits. All phone models
are tested at their highest value in strict laboratory settings.
But when in operation, the SAR of a phone can be
substantially less than the level reported to the FCC. This is
because of a variety of factors including its proximity to a
base station antenna, phone design and other factors. What
is important to remember is that each phone meets strict
federal guidelines. Variations in SARs do not represent a
variation in safety.
All phones must meet the federal standard, which
incorporates a substantial margin of safety. As stated above,
31 Important Safety Information
variations in SAR values between different model phones do
not mean variations in safety. SAR values at or below the
federal standard of 1.6 W/kg are considered safe for use by
the public.
The highest reported SAR values of the DuraForce are:
Head: 1.48 W/kg
Body-worn: 1.56 W/kg
In the US, the SAR limit for mobile devices used by the public
is 1.6 watts/kg (W/kg) averaged over 1 gram of tissue for
the body or head.
Phone models may have different versions and more than
one value. Changes in design or components may occur
over time and some changes could affect SAR values. More
information on the phone’s SAR can be found on the
following FCC website: http://fcc.gov/oet/ea/.
FCC Radio Frequency Emission
This phone meets the FCC Radio Frequency Emission
Guidelines.
FCC ID number: V65E6762.
FCC Notice
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
25
0.98
Important Safety Information 32
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
●Reorient the direction of the internal antennas.
●Increase the separation between the equipment and
receiver.
●Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician
for help.
The model number and regulatory number are on the side of
the phone. The serial number is located on a sticker on the
microSD card slot. Record the serial number in the space
provided below. This will be helpful if you need to contact us
about your phone in the future.
Model: DuraForce
Serial No.:
Owner’s Record
33 Manufacturer’s Warranty
Kyocera Communications Inc. (“KYOCERA”) offers you a
limited warranty that the enclosed product or products (the
“Product”) will be free from defects in material and
workmanship for a period that expires one year from the
date of sale of the Product to you, provided that you are the
original end-user purchaser of the Product and provided that
your purchase was made from an authorized supplier.
Transfer or resale of a Product will automatically terminate
warranty coverage with respect to that Product.
This limited warranty is not transferable to any third party,
including but not limited to any subsequent purchaser or
owner of the Product. KYOCERA shall, at its sole and
absolute discretion, either repair or replace a Product (which
unit may use refurbished parts of similar quality and
functionality) if found by KYOCERA to be defective in material
or workmanship, or if KYOCERA determines that it is unable
to repair or replace such Product, KYOCERA shall refund the
purchase price for such Product, provided that the subject
Product (i) is returned, with transportation prepaid, to a
KYOCERA authorized service center within the one year
warranty period, and (ii) is accompanied by a proof of
purchase in the form of a bill of sale or receipted invoice
which evidences that the subject Product is within the one
year warranty period (“Proof of Purchase”). After the one
year warranty period, you must pay all shipping, parts and
labor charges. This limited warranty does not cover and is
void with respect to the following: (i) Products which have
been improperly installed, repaired, maintained or modified
(including the antenna); (ii) Products which have been
subjected to misuse (including Products used in conjunction
with hardware electrically or mechanically incompatible or
Products used with software, accessories, goods or ancillary
or peripheral equipment not supplied or expressly authorized
by KYOCERA for use), abuse, accident, physical damage,
abnormal use or operation, improper handling or storage,
Manufacturer’s Warranty
Manufacturer’s Warranty 34
neglect, exposure to fire, water (except for product certified
for protection against water; see the Kyocera product
website for details on your Product) or excessive moisture or
dampness or extreme changes in climate or temperature;
(iii) Products operated outside published maximum ratings;
(iv) cosmetic damage; (v) Products on which warranty
stickers or Product serial numbers have been removed,
altered, or rendered illegible; (vi) customer instruction; (vii)
cost of installation, set up, removal or reinstallation; (viii)
signal reception problems (unless caused by defect in
material or workmanship); (ix) damage the result of fire,
flood, acts of God or other acts which are not the fault of
KYOCERA and which the Product is not specified to tolerate,
including damage caused by mishandling and blown fuses;
(x) consumables (such as memory cards, fuses, etc.); (xi)
third party software or applications, data and equipment not
originally supplied with the Product; (xii) any Product in
which the software has not been updated to the current
version; (xiii) any Product in which the operating system has
been unlocked (allowing installation of a third party operating
system); or (xiv) any Products which have been opened,
repaired, modified or altered by anyone other than KYOCERA
or a KYOCERA authorized service center. Before returning
any Product for service, be sure to back up data and remove
any confidential, proprietary, or personal information from
the Product. KYOCERA is not responsible for damage to or
loss of any software, applications, data or removable storage
media.
USE ONLY KYOCERA APPROVED ACCESSORIES WITH
KYOCERA PHONES. USE OF ANY UNAUTHORIZED
ACCESSORIES MAY BE DANGEROUS AND WILL INVALIDATE
THE PHONE WARRANTY IF SAID ACCESSORIES CAUSE
DAMAGE OR A DEFECT TO THE PHONE.
KYOCERA SPECIFICALLY DISCLAIMS LIABILITY FOR ANY
AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, PUNITIVE,
EXEMPLARY, AGGRAVATED, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE
POSSIBILITY THEREOF, WHETHER FORESEEABLE OR
UNFORESEEABLE OF ANY KIND WHATSOEVER, INCLUDING
BUT NOT LIMITED TO LOSS OF PROFITS, UNANTICIPATED
BENEFITS OR REVENUE, ANTICIPATED PROFITS ARISING
35 Manufacturer’s Warranty
OUT OF USE OF OR INABILITY TO USE ANY PRODUCT (FOR
EXAMPLE, WASTED AIRTIME CHARGES DUE TO THE
MALFUNCTION OF A PRODUCT) OR CONTRIBUTION OR
INDEMNITY IN RESPECT OF ANY CLAIM RELATED TO A
PRODUCT.
REPAIR OR REPLACEMENT OF A DEFECTIVE PRODUCT OR
REFUND OF THE PURCHASE PRICE RELATING TO A
DEFECTIVE PRODUCT, AS PROVIDED UNDER THIS
WARRANTY, ARE YOUR SOLE AND EXCLUSIVE REMEDIES
FOR BREACH OF THE LIMITED WARRANTY, AND SUBJECT
TO THIS WARRANTY, THE PRODUCTS ARE APPROVED AND
ACCEPTED BY YOU “AS IS”.
KYOCERA MAKES NO OTHER WARRANTIES,
REPRESENTATIONS OR CONDITIONS OF ANY KIND, ORAL
OR VERBAL, EXPRESS OR IMPLIED, STATUTORY OR
OTHERWISE, WITH RESPECT TO THE PRODUCTS,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE OR AGAINST INFRINGEMENT OR
ANY IMPLIED WARRANTY OR CONDITION ARISING OUT OF
TRADE USAGE OR OUT OF A COURSE OF DEALING OR
COURSE OF PERFORMANCE. NO DEALER, DISTRIBUTOR,
AGENT OR EMPLOYEE IS AUTHORIZED TO MAKE ANY
MODIFICATION OR ADDITION TO THIS WARRANTY.
Some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages, or allow limitations on
how long an implied warranty lasts, so the above limitations
or exclusions may not apply to you. This limited warranty
gives you specific legal rights, and you may also have other
rights which vary from jurisdiction to jurisdiction. For
warranty service information, please call the following
telephone number from anywhere in the continental United
States and Canada: 1-800-349-4478 or 858-882-1401.
End User License Agreement 36
Kyocera Communications, Inc. (“Kyocera”) End User License
Agreement
CAREFULLY READ THE FOLLOWING TERMS AND
CONDITIONS (“AGREEMENT”) BEFORE USING OR
OTHERWISE ACCESSING THE SOFTWARE OR SERVICES
PROVIDED WITH YOUR KYOCERA DEVICE. THE
SOFTWARE AND SERVICES PROVIDED WITH YOUR
KYOCERA DEVICE ARE SOLELY FOR PERSONAL USE BY
YOU, THE ORIGINAL END USER, AS SET FORTH BELOW.
BY ACTIVATING, USING, DOWNLOADING OR INSTALLING
THIS KYOCERA DEVICE AND/OR THE SOFTWARE
PROVIDED WITH IT, YOU ARE AGREEING TO BE BOUND
BY THE TERMS OF THIS LICENSE AGREEMENT. IF YOU
DO NOT AGREE TO THE TERMS AND CONDITIONS OF
THIS AGREEMENT, DO NOT USE, DOWNLOAD OR
OTHERWISE ACCESS THE SOFTWARE OR SERVICES AND
(I) PROMPTLY RETURN THE SOFTWARE OR SERVICE TO
KYOCERA OR DELETE IT; OR (II) IF YOU HAVE
PURCHASED THE KYOCERA DEVICE ON WHICH THE
SOFTWARE OR SERVICE IS PRE-INSTALLED, PROMPTLY
RETURN THE DEVICE AND THE ACCOMPANYING
SOFTWARE (INCLUDING DOCUMENTATION AND
PACKAGING) TO KYOCERA OR THE KYOCERA
AUTHORIZED DISTRIBUTOR FROM WHICH YOU
PURCHASED THE KYOCERA DEVICE.
License: Subject to the terms and conditions of this
Agreement and any other terms that may be incorporated by
reference or otherwise presented to you prior to your use of
the Software, Kyocera grants you a limited, non-exclusive,
license to use Kyocera and third party proprietary software
and services found on your Kyocera device and/or packaged
with your Kyocera device, including any updates to such
material by whatever means provided, and any related
documentation (“Software”). You may use the Software only
as expressly authorized by this Agreement.
End User License Agreement
37 End User License Agreement
Limitations: This Software is licensed for use only on the
single Kyocera device you originally purchased. You
acknowledge and agree that ownership of the Software and
all other rights associated with the Software not expressly
granted in this Agreement are retained by Kyocera or its
suppliers or licensors. You are not permitted to, in any way,
distribute the Software or make it available over a network
for use on more than the single Kyocera device for which it
was originally supplied. The Software may be copied only as
permitted by applicable law and as necessary for backup
purposes. You may not remove any proprietary notices or
labels on the Software or any copies thereof. You may not in
any way, modify, reverse engineer, decompile, disassemble
or create derivative works based on the Software (except to
the extent that this restriction is expressly prohibited by law).
You agree that you will not attempt to circumvent, disable or
modify any security technology associated with the Software.
You may use the Software only in a manner that complies
with all applicable laws in the jurisdictions in which you use
it, including, but not limited to, applicable restrictions
concerning copyright and other intellectual property rights
and/or the export control regulations.
Some of the Software packaged with your Kyocera device
may be provided by third parties (“Third Party Software”).
Third Party Software may also be available from third party
content distributors such as application stores. Third Party
content may be subject to different or additional terms and
conditions as determined by the Third Party Software
provider. THIRD PARTY SOFTWARE IS NOT A KYOCERA
PRODUCT. KYOCERA IS NOT RESPONSIBLE FOR AND
HAS NO LIABILITY WITH REGARD TO THIRD PARTY
SOFTWARE.
Open Source Software: The Software contains certain
open source software which may be subject to the GNU
General Public License (“GPL”), GNU Library/ Lesser General
Public License (“LGPL”) and/or other copyright licenses,
disclaimers and notices (“Open Source License Terms”). The
applicable Open Source License Terms for the
corresponding Open Source Software are reproduced and
End User License Agreement 38
available at http://www.opensource.org/licenses. Please
refer to the Open Source License Terms regarding your
rights under such licenses to the Open Source Software. To
the extent any such agreement requires that Kyocera
provide you the rights to copy, modify, distribute or otherwise
use any Open Source Software that are inconsistent with the
limited rights granted to you in this Agreement, then such
rights in the applicable Open Source License shall take
precedence over the rights and restrictions granted in this
Agreement, but solely with respect to such Open Source
Software.
Disclaimer of Warranty and Liability: THE SOFTWARE IS
PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND.
KYOCERA FURTHER DISCLAIMS ALL WARRANTIES,
INCLUDING WITHOUT LIMITATION ANY IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, NONINFRINGEMENT, TITLE,
ACCURACY, CORRESPONDENCE WITH DESCRIPTION AND
SATISFACTORY QUALITY. TO THE MAXIMUM EXTENT
PERMISSIBLE BY LAW, THE ENTIRE RISK ARISING OUT
OF THE USE OR PERFORMANCE OF THE SOFTWARE
REMAINS WITH YOU. IN NO EVENT WILL KYOCERA, ITS
EMPLOYEES, OFFICERS, SHAREHOLDERS, LICENSORS,
SUPPLIERS, CARRIER OR DISTRIBUTOR CUSTOMERS OR
AFFILIATES BE HELD LIABLE FOR ANY CONSEQUENTIAL,
INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR OTHER
DAMAGES WHATSOEVER (INCLUDING, WITHOUT
LIMITATION, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS
INFORMATION, OR OTHER PECUNIARY LOSS) ARISING
OUT OF THIS AGREEMENT OR THE USE OF OR INABILITY
TO USE THE SOFTWARE, WHETHER BASED IN
CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT
PRODUCT LIABILITY OR ANY OTHER THEORY, EVEN IF
KYOCERA HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES AND EVEN IF ANY LIMITED REMEDY IS
DEEMED TO HAVE FAILED ITS ESSENTIAL PURPOSE.
KYOCERA’S TOTAL LIABILITY FOR ANY DAMAGES UNDER
THIS AGREEMENT SHALL NEVER EXCEED THE
PURCHASE PRICE YOU PAID FOR THE KYOCERA DEVICE.
39 End User License Agreement
No software is fault free. The Software is designed for use in
systems that do not require fail-safe performance. You may
not use the software in any device or system in which a
malfunction of the software would result in foreseeable risk
of loss, injury or death to any person. This includes operation
of nuclear or infrastructure facilities, medical equipment,
aircraft navigation or communication systems or use in risky
or dangerous situations or environments.
Consent to Use of Data: You agree that Kyocera, its
affiliates and its designated agents may collect and use
technical and related information, gathered in any manner,
as part of its product support services. Kyocera, its affiliates
and designated agents may use this information solely to
improve its products or to provide customized services or
technologies to you. Kyocera will collect and use this
information in accordance with its privacy policy and
accordance with applicable data protection laws. Kyocera,
its affiliates and designated agents may disclose this
information to others, but not in a form that personally
identifies you.
Modification of Software and Terms of Use: Kyocera
reserves the right to from time to time modify any portion of
the Software. Kyocera may be required to take these actions
due to restrictions from third party licensors or due to safety
or security concerns or government restrictions or court
orders.
Kyocera reserves the right to modify the terms of this
Agreement at its sole discretion. Any such modification will
be effective upon Kyocera or a Kyocera affiliate or agent
sending notice to you by email, text message, other
electronic communication or postal mail. Your continued use
of the Software after such notice will constitute your binding
acceptance of the Agreement as revised. Additionally, some
Software may be subject to different or additional terms
presented to you through a separate click-through or other
type of agreement or notice prior to your use of such
Software.
Termination: This License Agreement will automatically
terminate without notice from or action by Kyocera if you fail
to comply with any term hereof.
End User License Agreement 40
Governing Law: This Agreement is governed by the laws of
State of California except any conflict of law provisions. The
U.N. Convention on Contracts for the International Sales of
Goods is hereby excluded in its entirety from this
Agreement.
Severability: If any provision of this Agreement is found to
be invalid, illegal or unenforceable, the validity, legality or
enforceability of the remaining provisions will not in any way
be impacted or impaired.
Entire Agreement: By using or otherwise accessing the
Software, you agree that this Agreement sets forth the entire
agreement between you and Kyocera with regard to the
Software and supersedes all prior agreements,
notwithstanding the terms of any such agreements.
