Watch Specification

Picture of Watch：



i. PlatformandRequirements

Android4.4andabove

iOS8.4andabove

MobilehardwaresupportBluetooth4.0



powerbutton

DisplayScreen



ii. Usepreparation

Pleaseensurethatthebatteryissufficientforthefirsttime.Ifthe

batterycannotbeturnedonduetolowpower,pleasechargefor1‐1.5

hours(pleasemakesurethebatteryisfullforthefirstuse).Thewatch

screenwilldisplaytheflowofthebatterywhencharged,andstop

flowingwhenfilled.

iii. ConnectingtoUse

ThenormaluseofthewatchrequiresconnecttothephoneAPP.Please

makesurethattheusedphonesmeettherequirementsofthe

appropriateplatformandthehardwareoftheequipments,andthen

downloadthecorrespondingAPP.

DownloadForm：

AndroidPhone：ScantheQRcodebelowtodownload

ApplePhone：ScantheQRcodebelowtodownload



Notice：

AndroidPhone：Setting‐ AuxiliaryFunction‐HBAND‐Allowall

functions/Allowbackgroundrunning

Setting–APPsHBAND—allowedtouseallfunctions

ApplePhone：Setting‐HBAND‐allowedtouseallfunctions

APPlanguagewillbeswitchedaccordingtothephonelanguage

Pairaccounttouse：

Pleaseensuremobilebluetoothisopenedafterdownloadingthe

software,opentheHBAND,clickonthe"pairdevice",choosethedevice

inthelistofbluetoothdevices,clicktopairandmatchtheBluetooth.

Enterintothemaininterfaceofsoftwareaftercompletingyourpersonal

information.

Boot:Longpressthebuttonfor3Stostartupintheshutdownstate,

thenenterintothemaininterface ,anditwillautomatically

enterintostandbymodeifno‐operationfor5S.

Function usage:

（1）clickthetouchbuttoninthestateofthemaininterfacetoenter



theSTEPinterface(gif)whichdisplaysthecurrentnumberof

steps,andautomaticallyenterintostandbymodeifno‐operationfor5S

（2）Clickthetouchbuttontwiceinthestateofthemaininterfaceto

enterthedistanceinterface(gif)toshowthecurrentdistance,

andautomaticallyenterintostandbymodeifno‐operationfor5S

（3）Clickonthetouchbuttonforthreetimesinthestateofthemain

interfacetoenterthecalorieinterface (gif),showingthecurrent

calorieconsumption,andautomaticallyenterintostandbymodeif

no‐operationfor5S

（4）Shortpressbuttonfourtimesinthemaininterfacestatetoenter

bloodoxygeninterface(static),andthenlongpressfor3secondsto

enterthebloodoxygentestmode,thecurrentinterfacebecomes

dynamic （gif）Andstartmeasuringin180stodisplayreal‐time

data,andthenscreenoff.Thescreenwillbeoffaswellasnopassthe

weardetection.

（5）Inthemaininterfacestate,shortpressthebuttonforfivetimesto

enterintotheheartrateinterface (static),thenlongpressfor3



secondstoentertheheartratemeasurementmode,thecurrent

interfaceintothedynamicandstartmeasuringanddisplaytheresults

aftertestingiscompleted.Itwillalwaysshow‐‐‐/‐‐‐ifheartrateisfailed

tobemeasured,andautomaticallyenterintostandbymodeif

no‐operationfor60S(nomatteriftheheartrateismeasured).

（6）Pressthebuttonsixtimestoenterthesleepinterface

underthestateofthemaininterface,showthetotalsleeplast

night,andautomaticallyenterintostandbymodeifno‐operationfor5S.

Longpressthebutton6stoclearthebluetoothpasswordinthesleep

interface.

（7）Shortpressthebuttonseventimesinthestateofthemain

interfacetoenterthefindthephoneinterface .Longpressthe

button3sinfindthephoneinterface,displaythedynamicimageintothe

searchmode,underthebluetoothconnectionstate,theconnected

phonerangthepromptsound.Afterenteringthefindthephonemode,

shortpressonce,exitthesearchmode,andenterthenextinterface.and

automaticallyenterintostandbymodeifno‐operationfor5S.

Shutdown：Shortpressbutton8timesunderthemaininterfacetoenter

theMACaddressinterface ,longpressthebutton3stoenter



shutdowninterface ,shortpressYESorNOtoswitch,selectYES

andlong3stoshutdownthedeviceandscreenoff.

Charge：Displaythechargingprogressicon8s （gif）whenyou

startcharging,andthengointostandbymode.Displaythecharging

progressicon（gif）for8sagainoncetakingthewatch,andautomatically

enterintostandbymodeifno‐operationfor5S.

【Afterenteringanyfunctionalinterface,clickthetouchbuttontoenter

thenextscreeninturn】

Otherfunctionshavebeensetupwillalertthevibration：

(1) call\Call barring\call mute

ConnectAPP,display whenthephonecallsreminding,,if

callsfrompeopleinthemobilecontacts,showcallingpeoplenames,and

continuousvibration1swithanintervalof2suntilthecallpickedup,

hanguporrejected.Ifcontinueddon'tanswerthephone,thedevice

willcontinuetoshowcallnumberandtheUIfor1minute,vibration20

times,withanintervalof2sand1svibrationatatime,ifyouwantto

rejectthecall,pleaselongpressthebutton3s,thenphone



callsresisted(thecallcanberejectedunderhang‐upstate).Shortpress

thebuttontoswitchtothemuteofthephone.Thebracelet

displaysthemuteiconandturnsoffthemotoruntilthephonepickedup

orhungup

Mark:Onlyifrejectionofcalloperated,thehangupofcallswillalways

displayUIofcallrejection.

（Connectedtothe3.0earphone,4.0bluetooth,itwillanswerthe

phoneautomaticallyifwetakeouttheearphoneoutofstrapwhen

phonecalls,andtherewillbeapausefor2S.Hangup:longpress3

secondstohangup.20170619）

（2）For SMS notification,displaytheinterface andshowthe

namesofsender.Ifthesenderisnotrecordedinthemobilephone

addressbook,thenshowcaller’snumber,residualpageshowsallthe

contentsfor5s.Ifthecontentisbeyondonescreenandneedtoturn

pages,showellipsiswith3points.Andvibrates1s,thenautomaticenter

intostandbymodeaftervibration

(3) Instant Message tools notification

ConnectedAPP,switchoninstantmessagetoolsinthe"Message

notification"column,suchasWechat,QQ,facebook,twitter,intotal12



sets(excludingcallsandSMS).Displaytheinterface(wechat,forexample)

whenmessagesreceived,icondisplayedinabove,andbelowsender’s

nameandmessagecontent.Thecontentwillbeshowedfor5s.Ifthe

contentisbeyondonescreenandneedtoturnpages,showellipsiswith

3points.Andvibrates1s,thenautomaticenterintostandbymodeafter

vibration

Newfunctionlogic：

20sets of alarm：

APPconnectedbluetooth,enterthe"setalarm"columninAPP,click"+"

tosetupthecorrespondingalarmclocktime,date,labels,andthenclick

"✔"setalarmclocksuccessfully.Youcansetmultiplesetsofthem,each

withaswitchindividually.Thewatchwilldisplaythelableofthealarm

clockWhenthealarmisstarted,andthetagflashes20times,vibrate

twosetwith3S.

Set reminder interval of sedentary：

Openthe“mydevice ”columnatAPP ，thenswitchｏｎthe

“sedentary”ｔｏｓｅｔ startingtimeandstoptime，andreminder

intervalofsedentary.Whenthewatchdetectsthatthetimeperiodof

thesettinghasreachedthetimeofsittingtime,theinterfaceofthe

watchwillappearforsedentaryUIandvibrationreminder.(UIshows8S

andvibrating2setswith3S,spacing2S)



Heart rate alarm：

Openthe“mydevice”columnatAPP,thenswitchｏｎthe“heartrate

alar,”functiontoset“maximumheartrate”.Thewatchwilldisplayalarm

UIandvibratewhenthewatchdetecttofindtheheartratereachthe

maximumheartrate(UIshows10sandvibrating3setswith1S,spacing

1s).

Paging functions of notifications：

Openthe“messagenotification”columnafterthewatchBluetooth

connectingtoAPP,andthenswitchonthe“appswtich”.Thewatchwill

displaythesenderinformationandthecontentwhenmessagesreceived.

Singleclickorup‐slidethescreentochecktherestinformation.The

watchwilldisplaythecontentofmessagewhenyouwristyourhandor

clickthescreenifthemessageshavenotbeencheckedyet.Thenitwill

returntothemaininterfaceafterreadingwithsingleclickorup‐slidethe

screen(displayfor3swithno‐operation,andthenscreenoff).

Stopwatch （function）：

Openthe“switchsetting”columnatAPPafterconnectingthewatch

bluetoothwithAPP,thenswitchonthe”stopwatchfunction”.Thewatch

willdisplaystopwatchinterface(permanent),andenterinto

preparationstateofstopwatchwithlongpressfor3s(seepicture),single

clicktostartthestopwatch,singleclicktostopandlongpressfor3sto



quitthestopwatch.Thewatchwillnotshowthestopwatchinterfaceif

thestopwatchisswitchedoffinAPP.

Count-down

Enterthecount‐downinterface atAPPafterconnectingthe

watchbluetoothwithAPP.Startthecount‐downwithsingleclick,then

setthetimeofasinglecount‐downandclickok.Thewatchwillbright

screenanddisplaycountdownUI,thenscreenoffafter3s,atthesame

time,starttocountdowninAPP.And5svibrationand9sUIdisplayed

afterthecountdownfinished.(count‐downinterfaceisnotpermanentat

watchside).

Enterthecount‐downinterface atAPP,switchonthe“interface

display”,thewatchwillshowpermanentinterfaceUI(click9timesfrom

maininterface),thenset“usualtime”whichisthetimethatwillbe

counteddownwhenlongpressfor3satcount‐downinterface(the

count‐downgifdisplaysfor3s).youcanalsoset“usualtime”atAPPby

clickingatcount‐downinterfaceofAPP.Chose“confirm”tostartthe

count‐down,andthewatchwilldisplaycount‐downgif,thenscreenoff

after3s.Inthisway,thecount‐downwillbestartedatAPPsidetoo.Long



pressfor3satwatchifyouwanttoexitthecount‐downinthemiddleof

it.5svibrationand9sUIdisplayedafterthecountdownfinished

Find the phone：

Openthe“switchsetting”columnatAPP,thenswitchonthe“findthe

phone”,thewatchwillshowpermanentinterfaceoffindthephone.

Longpressfor3satfindthephoneinterface,thewatchwilldisplayfind

thephonegifandtheconnectedphonewillvibrateandringsounds.It

willbestoppedifyousingleclickatfindthephoneinterfcace,it

willexitthefindthephonefunctiontonextinterfaceandthevibrationg

andringstoped.

Take photo：

Openthe“device”columnatAPP，clickon“takephoto”functionto

startthephotomode.ThewatchwilldisplaytakephotoUI.

Thephonewilltakephotosautomaticllyifyoushakethewatchorsingle

clickattheinterfaceofwatch.Exitthetakephotofunctionbysingleclick

thephysicalbuttonsatphone.

Brightness adjustment：

Openthe“mydevice”columnatAPP,thenswitchｏｎthe“Brightness

adjustment”,thenswitchon“automaticadjustment”,themaininterface

ofwatchwillbrightenfor5s,whichisthedefault(thedefaultfrom8am



to10pmisdifferentwiththedefaultfrom11pmto7am).Switchoffthe

automaticadjustment,themaininterfacewillbrightenfor5s,andscreen

offafter5s’no‐operation.Thebrightnessofwatchwillbeadjusted

accordingtothevaluesetbybrightnessadjustmentfunction.

Low battery reminding：

Underlowbatteryandscreenoffcondition,itwilldisplayabiglow

batteryiconfor1s,thendisplayotherinterfaces,alwaysremindyouto

charge(samelogicasV08).Itwilldisplaythechargingicon(gif)for8s

whencharging,thenstartstandbymode.Itwilldisplaychargingicon(gif)

for8sagainwhenbeentaken,thenstartstandbymode.



Gesture

1、Whenthewatchinthestandbymode,

therearetwowaystowakeupthewatchgotothemaininterface.

Toraiseyourhandorsingleclickatthewatch'sinterface.

2、DealwithconditionsofBluetoothconnection



FCCWarning



ThisdevicecomplieswithPart15oftheFCCRules.Operationissubject

tothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevice

mustacceptanyinterferencereceived,includinginterferencethatmay

causeundesiredoperation.



NOTE:Anychangesormodificationstothisunitnotexpresslyapproved

bythepartyresponsibleforcompliancecouldvoidtheuser'sauthority

tooperatetheequipment.



L8star Technology L8STAR-5 smart fitness tracker User Manual

Shenzhen L8star Technology Co., Ltd. smart fitness tracker Users Manual

User Manual

Navigation menu

Namespaces

Views

Navigation
