User Manual
COPYRIGHT ©2013 ALL RIGHTS RESERVED LANKE XUNTONG TECHNOLOGY CO.,LTD
TEL: +86 755 26674742 +86 755 26675941 E-mail: nrf@freqchina.com
1
\\
Fingertip-size Ultra Low Power Bluetooth 4.0 Low Energy RF Module
Important Notice:
Reserves the right to make corrections, modifications, and/or improvements to the product and/or
its specifications at any time without notice.
Assumes no liability for the user’s product and/or applications.
Products are not authorized for use in safety-critical applications, including but not limited to
life-support applications.
ATTENTION!
Electrostatic Sensitive Device
Observe Precaution for handling.
PTR5528 -Bluetooth low energy 4.0 modules
1. Installation ： SMT on the customer’s Main board.
2. Warning:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Please notice that if the FCC identification number is not visible when the module is installed inside
another device, then the outside of the device into which the module is installed must also display a label
referring to the enclosed module. This exterior label can use wording such as the following: “Contains
FCC ID:2AA72-PTR5528” any similar wording that expresses the same meaning may be used.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator
& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
The module is limited to OEM installation ONLY.
The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove or
install module.
The module is limited to installation in mobile application;
A separate approval is required for all other operating configurations, including portable configurations
with respect to Part 2.1093 and difference antenna configurations.
There is requirement that the grantee provide guidance to the host manufacturer for compliance with Part
15B requirements.
Remark：FCC ID:2AA72-PTR5528，since the size of Shied cover is too small, we can't mark the FCC
ID Number on the product .
