LANKE XUNTONG TECHNOLOGY PTR9018E Bluetooth low energy 4.0 modules User Manual

LANKE XUNTONG TECHNOLOGY CO.,LTD Bluetooth low energy 4.0 modules Users Manual

Contents

Users Manual 2

COPYRIGHT ©2013 ALL RIGHTS RESERVED LANKE XUNTONG TECHNOLOGY CO.,LTD
TEL: +86 755 26674742 +86 755 26675941 E-mail: nrf@freqchina.com
1
\\
Bluetooth Low Energy System on Module
Embedded Cortex
™
M0 32 bit processor
Important Notice:
Reserves the right to make corrections, modifications, and/or improvements to the product and/or
its specifications at any time without notice.
Assumes no liability for the user’s product and/or applications.
Products are not authorized for use in safety-critical applications, including but not limited to
life-support applications.
ATTENTION!
Electrostatic Sensitive Device
Observe Precaution for handling.
PTR9018
1. Installation ： SMT on the customer’s Main board.
2. Warning:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Please notice that if the FCC identification number is not visible when the module is installed inside
another device, then the outside of the device into which the module is installed must also display a
label referring to the enclosed module. This exterior label can use wording such as the
following: “Contains FCC ID:2AA72-PTR9018E” any similar wording that expresses the same meaning
may be used.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between the
radiator & your body. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The module is limited to OEM installation ONLY.
The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove
or install module.
The module is limited to installation in mobile application;
A separate approval is required for all other operating configurations, including portable configurations
with respect to Part 2.1093 and difference antenna configurations.
There is requirement that the grantee provide guidance to the host manufacturer for
compliance with Part 15B requirements.
