LANYA ELECTRONIC BH803 Bluetooth Headset User Manual 13 06 24 BH803 02
LANYA ELECTRONIC CO., Ltd. Bluetooth Headset 13 06 24 BH803 02
User Manual
Use Manual
Model:BH803
Appearance
earhook
power on/off
led light
1.power on:press and hold multifunction key for 3s,the blue light
start to flash 3 times and headset beeps.
2.power off:press and hold the multifunction key for 3s until headset
beeps and the red light flash 3 times.
3.pair headset:make sure headset is turn off.put the multifunction
key 7s until headset beeps ,blue and red light start alternate flashing.
open your mobile phone bluetooth to search and connect.
4.NFC pair:standby mode,put headset NFC site touch with mo
-bile phone NFC site the bluetooth will automatic connect.
(note:mobile phone need have NFC function)
5.answer calls:press the multifunction key to answer calls,the blue
light flash 2 times every 2s.
6.end calls:press the multifunction key to end calls.
7.refuse calls:press the multifunction key 3s refuse the call and headset
beeps.
8.volume+:press volume+ button to increase the volume.
(max voice headset beeps)
9.volume-:press volume- button to reduce the volume.
(min voice headest beeps)
10.switch the call between phone and headset:
during a conversation,press and hold the multifunction key 3s until
the headset beeps,the call will be transferred to you phone.
if you want transfer the call to the headset use the same way.
Bluetooth wireless connect
microphone
loudspeaker
volume-/last
volume+/next
micro-usb port
1.charging voltage:5V 2.charging current:75-80Ma
3.charging time:15.-2h 4.full charge current voltage:4.1-4.2v
LANYA ELECTRONIC Co., Ltd.
Bluetooth Headset
Bluetooth V4.0
Caution: Any changes or modifications to this device not explicitly
approved by manufacturer could void your authority to operate this
equipment.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
