LANYA ELECTRONIC BLE02 Pedometer User Manual

LANYA ELECTRONIC CO., Ltd. Pedometer

user manual

APP
PEDOMETER
Copyright © XD P417.091
10/11/13 2:45 PM
Congratulations on your Bluetooth pedometer!
Thispedometermeasurestheamountofwalkingandrunningandcollectstheexercisedatausingafree
software app for smartphones or tablets. The app provides a detailed record of steps taken, distance, speed
andcaloriesburnedduringexercise.
Regularexercisesuchaswalkingorrunningcanimprovegeneralhealth,assisttolowerbloodpressureand
reduce weight.
Setup
To begin using the pedometer please follow this procedure:
1. Download the free app for Apple iOS Devices from the App Stores on your smartphone or
tablet.
https://itunes.apple.com/gb/app/pedometer-bluetooth/id570940702?mt=8
Once you have installed the app continue with the setup.
2. Remove the battery insulation tab either by pulling the tab outwards or by opening the
pedometer battery cover using a coin or small screwdriver.
3. Start the pedometer app and select Settings.
4. Select Scan Device and the app will automatically look for the pedometer. The ID number of
the pedometer will be shown in the Choose Device Window.
5. Nextinputyourstepwidthandthenyourweight.
Note: To estimate step width measure the distance it takes to walk 10 steps and divide the distance walked
between 10.
6. NextselectRegisterandinputanaccountnameandpassword
7. The pedometer is now registered to your device.
8. The pedometer can now be clipped to shoe laces, belts, clothing or simply be stored in a
pocketwhileyouexercise.
9. Thereisnoneedtohavethemobiledevicewithyouduringyourexercise.Allthedatawillbe
stored for up to 1 month on the Pedometer and can be transferred to the app at any time.
Battery
The pedometer uses a CR2032 cell battery with an average lifetime of 4 months. When the battery needs
to be replaced please dispose of the used battery in accordance with local laws.
Health concerns
The pedometer is to be used as a daily record of activities and fitness, Should you have any health concerns
please consult a Doctor before starting a fitness regime.
Caution
• Avoidplacingthisproductinextremetemperaturesorhumidity.
• Donotsubmerseorallowthisproducttocomeintocontactwithwater.Useindrylocations
only.
• Anadultshouldsuperviseyoungchildrenwhenusingthisproduct.
• Donotuseanynonrecommendedaccessorieswiththisproduct,asthismayresultinre,
electrical shock or injury to persons or product.
• Donotcleananypartswithalcohol,cleaningsolutionscontainingalcoholorstrongabra-
sives. Use a soft cloth and some water
ENGLISH
Pedometer
User Manual
Model name:BLE02
FCC ID:ZG8BLE02
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications to this unit not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
