LANYA ELECTRONIC SPRAY Bluetooth Speaker User Manual

LANYA ELECTRONIC CO., Ltd. Bluetooth Speaker

User Manual

VOLUME DECREASETwist the dome to the left and release to decrease volume one increment, repeat as necessary to achieve desired volume.VOLUME INCREASETwist the dome to the right and release to increase volume one increment, repeat as necessary to achieve desired volume.  ANSWER/END A CALLShort press the nozzle when call comes in, There 15will be a two tone beep to indicate the call is picked up.  When the call is disconnected the music automatically starts playing again. To send a call directly to your voicemail press the nozzle for 2 seconds. MUTINGPress the nozzle for  2 seconds when on a call.  The red light will flash twice. LAST NUMBER RE-DIALDouble tap the nozzle to redial last number.  SAFETYInsure that all persons who use the product read and follow these warnings and instructions:1. Do not expose the product to rain or water2.  Keep all accessories and electronics out of the     reach of small children.3. Do not use while driving, biking, walking, and    jogging or where traffic is present.1716WARRANTY INFO1 Year WarrantyMizco International, Inc. warrants this product to be free from defects in materials and workmanship to the original purchaser for a period of 1 Year from the original purchase date.Mizco’s responsibilities with regard to this limited warranty shall be limited solely to the repair or replacement, at Mizco’s own option, of any product, which fails during normal consumer use.18This warranty does not extend to damage or failure, which results from misuse, neglect, alteration, abuse, improper installation, or improper maintenance. 19For manual’s in French and Spanish visit our website www.mizco.com/eckoDeclaration of Conformity with FCC Rules for Electromagnetic CompatibilityWe, Mizco International, Inc., of 80 Essex Ave East, Avenel, NJ 07001, declare under our sole responsibility that the product to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device mustaccept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentialinstallation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is 20 21noguarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouragedto try to correct the interference by one of the following measures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment    and receiver.• Connect the equipment into an outlet on a circuit    different from that which the receiver is    connected.• Consult the dealer or an experienced radio/TV    technician for help. Mizco International, Inc.,    is not responsible for any interference caused    by unauthorized modifications to this equipment.    Such modifications could void the user’s authority    to operate this equipment.ICESThis Class B digital apparatus complies with Canadian ICES-003.22 23INSTRUCTION MANUALTO TURN OFFWhen not in call mode press and hold the nozzle until the voice command indicates the speaker is off. The red LED will flash five times.PAIRINGWhen powered off press and hold the nozzle until the voice command indicates it is in pairing mode (Red and blue LEDs  flash alternately.) PAIRED The voice command will indicate the speaker has 13been paired with your device. The LEDs will then turn off. PLAY/PAUSE  Short press of the nozzle when you play musicPREVIOUS SONG Twist the dome to the LEFT and hold for 2 seconds to go to PREVIOUS song, repeat as needed.NEXT SONGTwist the dome to the right for two seconds to go to the next song, repeat as needed1424Mizco International Inc.80 Essex Ave East  |  Avenel, NJ 07001All trademarks used under license from IP Holdings Unltd LLC
Your new Ecko Unltd. Spray is the most unique Bluetooth wireless speaker. The Spray offers superb wireless audio streaming. With a twist of the dome or a short press of the nozzle you control the experience. The Spray will be your go to device for streaming audio from your phone, mp3 player, tablet or laptop.TABLE OF CONTENTSWHAT’S INSIDE?   3FEATURES   4SPECS   6USING THE SPRAY       CHARGING      7     PAIRING AND BATTERY    9     AUXILIARY AND CONTROLS    10SAFETY INFORMATION    17WARRANTY INFORMATION    18WHAT’S INSIDE?Ecko Spray Bluetooth Speaker3.5mm Audio dubbing cableUSB to micro USB charge cableUSB wall charger1100mAh removable Li-Ion battery, (Pre-installed)3Up to 10 hours of playtime per battery chargeSwappable Li-Ion battery for extended playtimeFor use with mobile phones, mp3 players, tablets or laptops devicesControlsPlay/Pause Skip Track/Back Track Answer/End callFEATURESTechBuilt in omni-directional microphone for hands-free Bluetooth calling.Stereo Bluetooth with extended dynamic range to deliver premium wireless audio quality.Wireless range up to 33 feet (10 meters) 3.5mm audio jack for use with non Bluetooth54SPECSBluetooth V2.1 + EDRAmplifier : 3.2-W/Ch Stereo Class-D Audio AmplifierSpeakers : Two full range high output 40mm (1.6”) drivers with Neodymium high energy magnetsTwin 45mm (1.8”) base radiators1100mAh Li-ion rechargeable battery USING THE SPRAYCharging the Spray  |  Battery status informationPlug the wall charger directly into an ac outlet.  1. Plug the USB connector into the included wall     charger and plug the other end into the micro     USB port on the Spray.2. The red LED in the nozzle remains on while      charging .  Fully charging the battery may take     up to 2 hours. Once the battery is fully charged      the LED indicator will turn off. 763. When the battery  is low (under 15%) a beep      will be heard two times in a row.  When the      battery is under 5% a beep will be heard five      times in a row. 4. When the Spray is being used and is plugged     into a power source the red LED will remain     on until fully charged.  This Spray is compatible with any mobile phone, tablet, desktop/notebook or any other device that supports the A2DP bluetooth profile and all wired devices.Pairing the speaker with your Bluetooth device1. Ensure your phone or audio device is on     and the Spray is off.2. Press and hold the nozzle until the voice    command indicates it is in pairing mode.3. On your device make sure that Bluetooth is     turned on and then choose  “scan for devices”.4. Select SPRAY from the list of found devices.    The voice command feature will indicate     when the speaker is paired with your device. 98Important note about wireless audio: Try to avoid being between your music player and the speaker, it can cause interference which may result in signal drop out.  Just move your player if this should happen.Using the audio cableConnect the audio cable to the Spray jack and plug the other end into the device. When using the audio cable you can control the volume from the Spray or from your device.  You cannot use track controls or the microphone while connected via an audio cable, you must use the controls on your device.Important note:  No sound will be heard if the speaker is paired via Bluetooth and connected via the 3.5mm cable at the same time.  Either disconnect Bluetooth or remove the 3.5mm cable to resume play.Changing the Li-Ion batteryTurn the speaker upside down and with a small coin  turn the black screw  counterclockwise until it becomes loose and you can remove the bottom 1110cover.  Note that It will  not separate from the bottom cap piece to prevent it from being lost. Change the battery with a fully charged battery for extended playtime. ControlsTO TURN ONWhen powered off press and hold the nozzle until the voice command indicates the speaker is  on The blue LED will flash five times.12
