Effective July 9, 2018 • Rev. 7/18

Price book 6

Click next for quick tips on

how to navigate Allegion

Price Books quicker!

Price Book 6

Effective July 9, 2018 • Rev. 07/18

This price list supersedes and cancels all previous price lists. Prices shown are subject to change without notice.

Administrative Offices

Allegion Administrative Office

11819 N. Pennsylvania St.

Carmel, IN 46032

allegion.com/us

Customer Care

Our Customer Care Representatives are available for questions or assistance.

You can reach them at 877-671-7011 (Press 1 for Sales Support | Press 2 for Product Support | Press 3 for SSC) or

through the email addresses listed below:

Placing orders

You can place orders with Allegion via the fax number or email listed below:

Fax#: 1-800-248-1460

Email: Order_LcnClosers@allegion.com

Request for Quote

Carolinas

(North Carolina, South Carolina, Virginia)

Carolinas.Quotes@allegion.com

Central

(Arkansas, Illinois, Iowa, Kansas, Missouri,

Nebraska, Oklahoma)

Central.Quotes@allegion.com

Chicago

(Illinois-Northern, Wisconsin)

Chicago.Quotes@allegion.com

Florida

Florida.Quotes@allegion.com

Great Lakes

(New York, Pennsylvania)

GreatLakes.Quotes@allegion.com

Metro New York

Metro.Quotes@allegion.com

Technical Product Support

Closers

Closers_TechProdSupport@allegion.com

Michigan

Michigan.Quotes@allegion.com

Mid Atlantic

(Delaware, Maryland, New Jersey)

MidAtlantic.Quotes@allegion.com

Midwest

(Indiana, Kentucky, Ohio, West Virginia)

Midwest.Quotes@allegion.com

Mountain States

(Colorado, Idaho, Montana, Nevada, Utah, Wyoming)

Mtn.States.Quotes@allegion.com

New England

(Connecticut, Main, Massachusetts, New Hampshire,

Rhode Island, Vermont)

NewEngland.Quotes@allegion.com

North Central

(Minnesota, North Dakota, South Dakota)

NorthCentral.Quotes@allegion.com

Northern California

NoCal.Quotes@allegion.com

Northwest

(Alaska, Oregon, Washington)

Northwest.Quotes@allegion.com

South

(Alabama, Georgia, Louisiana,

Mississippi, Tennessee)

South.Quotes@allegion.com

Southern California

(California-Southern, Hawaii)

SoCal.Quotes@allegion.com

Southwest

(Arizona, New Mexico)

Southwest.Quotes@allegion.com

Texas

Texas.Quotes@allegion.com

Sales Support

support@allegion.com

Price Book 6

Effective July 9, 2018 • Rev. 07/18 3

TABLE OF CONTENTS

HOW TO ORDER CLOSERS, COMPONENTS, PARTS & ACCESSORIES

1. Identify the closer series; 1460, 2030, 4040XP, 4210T, 4310ME, 4640, 6030, etc.

2. Determine if any additional information is required, such as: handing, finish, spring size, voltage, etc.

3. Order the material using suffix number with the description and include all necessary information.

Examples: 4111 Closer x RH x CUSH x AL or 4040SE Closer x 24v x DKBRZ

4. For additional information on how to order specific closers, please see the ‘How to Order’ page in each individual closer

section of the LCN General Catalog or call LCN Customer Care.

SPECIAL NOTES

1. All RAL custom finishes will be powder coated and metal covers (list add $10 for most series, list add $30 for 1450 and

4050 series) will be substituted for standard covers for all closers except the 1460 series. 1460 series closers may be custom

finished but a DS cover (list add $32) must be selected.

2. LCN offers more than 180 RAL custom finishes. There is a list add of ($40) per closer for an RAL finish. Most series require

a metal cover (MC) ($10 add). LCN also offers a Brite Metallic (MTLPC) powder coat finish. There is a list add of ($60) per

closer for the MTLPC finish.

3. LCN plated list prices already include -72MC (1460 includes -72DS). Disregard the additional list add for metal cover (MC).

4. LCN powder finishes exceed ANSI/BHMA standard A156.4 for corrosion resistance by at least a factor of four. LCN powder

coat finishes combined with the LCN Special Rust Inhibitor (SRI) pre-treatment exceed this standard even further.

5. Special Rust Inhibitor (SRI) is a pretreatment that is applied prior to the LCN powder coat finish and greatly exceeds

ANSI/BHMA Standard A156.4 for corrosion resistance. LCN requires an additional (list add $40) charge per closer,

component or part.

6. LCN plated finishes exceed ANSI/BHMA standard A156.4 for corrosion resistance.

7. Optional TORX security screw packs can be substituted for standard screw packs on most closers. See ‘Add for TORX Screw

Pack’ for additional charge. In some cases, not all fasteners can be provided as TORX, consult factory for details.

LCN can mark individual closer boxes with door or opening #’s. Please specify ‘itemized’ when ordering. Markings (e.g., door number,

stock reference numbers) on individual product cartons will be provided with no charge.

9. Special Template (ST) pricing is available by contacting LCN Technical/Product Support or LCN Customer Care.

10. All closers conform to standards UL10C and UBC 7-2 (1997).

11. If an item or price is not listed in the LCN July 9, 2018 Price List, consult factory for availability & pricing.

12. Prices listed in the LCN July 9, 2018 Price List are subject to change without notice. The current ‘Terms of Sale’ applies. All prices

listed in the LCN July 9, 2018 are in US dollars.

Contact Information ............................................... 2

Table of Contents/How to Order ........................ 3

Available Finishes/SRI ............................................ 4

Order Form .................................................................5

General Terms .......................................................6-9

Door Closer Specialists ......................................... 10

Complete Door Closers .................................... 11-23

Magnets ....................................................................24

Specialty Products, Fasteners ............................25

Control Boxes ................................................... 26-27

Control Box Components ..............................28-29

Actuator/Sensors Quick Find Guide ............ 30-31

Actuators, Sensors and Accessories ......... 32--49

Parts & Accessories ........................................50-63

Senior Swing Diagram ......................................... 64

Benchmark Diagram..............................................65

Glossary of Abbreviations ................................... 66

Wiring Diagrams .....................................................67

Wiring Diagram Request Form .......................... 69

LCN Warranty ...........................................................71

4Price Book 6
