LEADER PREMIUMS AB0001 wireless charger & power bank User Manual 88200
LEADER PREMIUMS LIMITED wireless charger & power bank 88200
User manual
Size: 21x10 cm
1) When charging your portable devices:
Connect the USB charging cable that came with your portable
device to the USB output port; connect the other end of the USB
charging cable to your portable device and turn it on.
your portable device will begin charging immediately.
Power Bank 's Charging Method FCC Warning Statement
Product specs:
Wireless Charger`s Charging Method
Connector for power supply
Charging area
Indicator Light area
Instruction sheet
The diagram of installation
Micro USB
1) Connect wireless charging pad to a power source via included
micro USB cable and turn it on. Charging pad entering standby
mode.
2) Place your protable device in the center area of the charging
pad, charging begins.
2) When recharging:
Connect the Micro USB Charging Cable to the Micro USB
recharger port; connect the other end of the Micro USB charging
cable to a powered USB port.
Product model: # AB0001
Main functions: wireless charging transmitter& power bank;
Standard version: WPC - 1.1;
Charging type: one-on-one charge corresponding area;
Power bank Input Specs: DC: 5V/2A; Output: DC: 5V/2A
Wireless charger Iuput Specs: 5V/2A; Output: DC 5V/1A
Battery Capacity: 6000mAh
Effective Distance: 4 to 6 MM；
Conversion efficiency: ≥70%；
Charging methods: induction model;
Working frequency: 111.5-205 KHZ;
Accessories: USB cable; Wireless charging pad; Packing box,
and instruction sheet.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
‐ Reorient or relocate the receiving antenna.
‐ Increase the separation between the equipment and receiver.
‐ Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
‐ Consult the dealer or an experienced radio/TV technician for help.
