LEADER PREMIUMS AB0006 Wireless Charger & USB HUB User Manual 88200
LEADER PREMIUMS LIMITED Wireless Charger & USB HUB 88200
Users Manual
Wireless Charger Instruction Sheet
Size: 14 x 10 cm
USB Port
Charging area
USB Cable
Instruction sheet
The diagram of installation
Wireless Charger`s Charging Method
1) Connect the wireless charging pad to a USB adapter with the
integrated USB cable. Charging pad entering standby mode.
2) Place your enabled device in the center area of the charging
pad, Device wil automatically begin to charge, charging begins.
Micro USB
Product specs:
Product model:
Main functions: wireless charging transmitter;
Standard version: WPC - 1.1;
Charging type: one-on-one charge corresponding area;
Input Specs: DC: 5V/1A;
Output Specs: 5V, up to 900mA output
Effective Distance: 4 to 6 MM；
Conversion efficiency: ≥70%；
Charging methods: induction model;
Working frequency: 111.5-205 kHZ;
Accessories: USB cable; Wireless charging pad;
Packing box, and instruction sheet.
FCC Warning Statement
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
The distance between user and products should be no less than
20cm
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
‐Reorient or relocate the receiving antenna.
‐Increase the separation between the equipment and receiver.
‐Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
‐Consult the dealer or an experienced radio/TV technician for help.
