LEADER PREMIUMS AB0010 Wireless Charger User Manual 88200
LEADER PREMIUMS LIMITED Wireless Charger 88200
User manual
Wireless Charger Instruction Sheet
Wireless Charger`s Charging Method
Size: 14 x 12 cm
Connector for power supply
Charging area
Indicator Light area
Instruction sheet
The diagram of installation
Product specs:
Product model:
Main functions: wireless charging transmitter;
Standard version: WPC - 1.1;
Charging type: one-on-one charge corresponding area;
Input Specs: DC: 5V/1A;
Output Specs: 5V, up to 900mA output
Effective Distance: 4 to 6 MM；
Conversion efficiency: ≥70%；
Charging methods: induction model;
Working frequency: 111.5-205 kHZ;
Accessories: USB cable; Wireless charging pad;
Packing box, and instruction sheet.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
‐Reorient or relocate the receiving antenna.
‐Increase the separation between the equipment and receiver.
‐Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
‐Consult the dealer or an experienced radio/TV technician for help.
1) Connect wireless charging pad to a power source via included
micro USB cable. Charging pad entering standby mode with
green indicator flash.
2) Place your portable device in the center area of the charging
pad, charging begins with green color indicator light on.
3) Green light turns back on when charging completed.
FCC Warning Statement:
