LEADER PREMIUMS AB0030 Car Wireless Charger User Manual 2981 instruction sheet
LEADER PREMIUMS LIMITED Car Wireless Charger 2981 instruction sheet
Users Manual
Wireless Charger Instruction Sheet
Connector for power supply
Charging area
Indicator Light area
Car charger
Instruction sheet
Wireless Charger`s Charging Method
1)Connect wireless charging pad to a power source via
included micro USB cable. Charging pad
entering standby mode with white indicator flash.
2)Place your portable device in the center area of the
charging pad, charging begins with white color
indicator light on.
Product specs:
Product model:AB0030
Main functions: wireless charging transmitter;
Standard version: WPC - 1.1;
Charging type: one-on-one charge corresponding area;
Input Specs: DC: 5V/1A;
Output Specs: 5V, up to 900mA output
Effective Distance: 4 to 6 MM；
Conversion efficiency: ≥70%；
Charging methods: induction model;
Working frequency: 111.5-205 kHZ;
Accessories: USB cable; Wireless charging
pad; Packing box, and instruction sheet.
FCC Warning Statement
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment. This equipment has been tested and
found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
‐‐ Reorient or relocate the receiving antenna.
‐‐ Increase the separation between the equipment and receiver.
‐‐ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
‐‐ Consult the dealer or an experienced radio/TV technician for
help.
The distance between user and products should be no less than
20cm
Size: 7 x 12 cm
