LEMON TECHNOLOGY 001 Bluetooth Speaker User Manual
LEMON TECHNOLOGY INC Bluetooth Speaker
User Manual
LED STATUS
- No active call, Outgoing call is ringing > Short press: Cancel the call
- No active call, Incoming call is ringing > Short press: Answer the call
/ Long press to Reject the call
- Call is active, no 2nd call > Short press: Hang up the call / Long press:
Switch the phone call between the units to the phone
- 1st call is active, 2nd incoming call is ringing > Short press: Put the
active call on hold and answer the incoming call / Long press: Reject
the incoming call
- 1st call is active, 2nd call is holding > Short press: Hold on current call
and switch to another call / Long press: Hang up the current call and
switch to another call
PAIRING 2 CALIFORNIA ROLLS
NEAR FIELD COMMUNICATION
REMOVABLE D-RING
Reveals standard tripod mount insert
POWER
PAIR & PLAY
CHARGE
BLUETOOTH
POWER
White: Power On
Red Slow Flash: Standby mode (without signal after 30min)
VOLUME
USB CHARGE OUT
3.5MM AUX-IN
MICRO USB CHARGE IN
WATERPROOF GATES
Close both gates completely
before putting in the water
> 75%
60% - 75%
45% - 60%
30% - 45%
15% - 30%
Flash (red): 5%-15%
Flash (white): Charging by USB/Solar
30 m / 100 ft
GETTING STARTED
CALL FUNCTION
(Long Press) VOICE ACTIVATION
PLAY / PAUSE
(x2) NEXT TRACK
Designed by Lemon in California Made in China Model CALIFORNIA ROLL Lemon Technology Inc. California, USA ©2017 Lemon Technology Inc.
www.lemon-california.com
FCC Statement - This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference caused undesired operation. The
has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNINGS, CAUTIONS & LEGAL INFORMATION
the CALIFORNIA ROLL to rain or moisture while charging.
being charged or charging other devices.
- As with any electronic products, use care not to spill liquids into any part of the product. Liquids can cause a failure and
- The power supply must be used indoors only.
performance and will void the warranty.
near the CALIFORNIA ROLL.
- The CALIFORNIA ROLL contains small parts that may be a choking hazard and is not suitable for children under age 3.
- Do not continue charging the battery if it does not reach f
- Overcharging may cause the battery to become hot, rupture, or ignite. If you see any heat deformation or leakage, properly dispose of the battery.
- Do not attempt to charge the battery in temperatures outside the range of 0°C-40°C / 32°F-105°F.
temperatures in excess of 60°C / 140°F.
- Do not step on, throw, or drop batteries or the power supply or device, or expose them to a strong shook. Do not pierce, crush, dent, or deform
the batteries or power supply in any way, if either becomes deformed, properly dispose of it.
- Do not short-circuit batteries. Do not attempt to service the CALIFORNIA ROLL yourself. Opening or removing covers may expose you to
dangerous voltages or other hazards and will void the manufacturer`s warranty.
NOTE: Any changes or modifications not expressly approved by LEMON could void the user’s authority to
operate the equipment. Caution: FCC Radiation Exposure Statement This equipment complies with FCC
radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20cm / 8 in between the radiator and any part of your body.
