LG ELECTRONICS BTM900 Wireless Mouse User Manual
LG Electronics Inc. Wireless Mouse Users Manual
Users Manual
1
Appearance
English
1. Right Button
2. Scrolling Wheel
3. Left Button
4. Low-Power-Alert LED (Orange)
5. Spare USB Power Supply Jack
6. Sensor LED (Red)
7. Upper Cover Lock
8. Receiver Link Button
9. Power Switch
Before Using
1. Install Batteries.
2. Turn the power on.
3. Pair the BTM-900 Bluetooth Mouse with your computer.
Install Batteries
Note: Please make sure that your Bluetooth software supports HID (Human
Interface Device) profile before the pairing process.
Un-lock the Upper Cover Lock.
1.
2
English
Remove the upper cover.
Install two AAA batteries into the
BTM-900 Bluetooth Piano Mouse’s
battery slot (if you had installed the
batteries, please remove the old one
before install the new batteries).
2.
3.
Pairing Process
- For Windows XP SP2
Press the Pairing button on the
bottom of the mouse for connection
link.
1.
Open the Windows control panel, then select “Bluetooth devices”.
Click “Add…”
Select “My device is setup and ready to be found”, then click “Next”.
In “Peripherals (keyboards, mice, joysticks)”, select BTM-900, then
click “Next”.
Select “Don’t use a passkey”, then click “Next”.
The windows will start to connect BTM-900 automatically. Please
press Finish button after the connection process completed.
2.
3.
4.
5.
6.
7.
Once the connection between BTM-900 Bluetooth Mouse and your
computer is established, the connection will keep permanently. That means
the connection will re-establish automatically when the Windows runs.
3
English
- For Mac OS X 10.2.6 or later
Press the Pairing button on the bottom of the mouse for
connection link.
Click the Bluetooth icon n the task bar and select “Setup Bluetooth
device”.
Click “Continue” when the “Bluetooth Setup Assistant” shows up.
Choose “Mouse” and then press “Continue” to the next step.
The “Piano BTM-900 Mouse” is found by Bluetooth, please press
“Continue” to the next step.
Click “Continue” when the “Passkey exchange with your mouse”
shows up.
The process is finished successfully. The BTM-900 Piano Mouse
is working now.
1.
2.
3.
4.
5.
6.
7.
Now you can use the BTM-900 Bluetooth Piano Mouse wirelessly with
Bluetooth-enabled Apple computer. Afterward, the connection of the two
Bluetooth-enabled devices will re-establish automatically when the Mac
OS X runs.
Button Switch
Press and hold both buttons for 3 seconds, then release buttons.1.
The left button and right button
had been functional reversed.
2.
4
English
If you want to switch buttons back
to its original functional definition,
please repeat the above step 1 and
step 2 for change.
3.
Spare USB Power Supply
Insert USB connector of spare USB
power cable into your laptop.
1.
Insert DC power connector of spare
USB power cable into your BTM-900
2.
Conserving power
Do not use your mouse for five minutes. After five minutes of
inactivity, the mouse automatically enters Sleep mode to conserve
batteries’ power.
To wake up the mouse, just move the mouse or click either mouse
buttons.
1.
2.
When the mouse batteries are running low on power, the LED light
on the Mouse turns orange, and blink.
To use your mouse’s Sleep mode based on the below setps:
Table OF Contents
English 1
Español 5
Italiano 9
Deutsch 13
Françai 17
Russkey 21
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void
your authority to operate the equipment.
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions
(1)•This device may not cause harmful interference and
(2)•This device must accept any interference received, including
interference that may cause undesired operation
1.•This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
