4-way Navigation Wireless Laser Mouse
User's Quick Guide
Latest Laser Technology for Excellent Detection and Movement!
4-way Navigation Wireless Laser Mouse
![](/img.php?id=794081&img=bg2.png)
4-way Navigation Wireless Laser Mouse
- 1 -
© 2006 All Rights Reserved. The copyright is the property of its respective owners.
Federal Communications Commission (FCC) requirements, Part 15
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Any changes of modifications not expressly approved by the grantee of this device could void
the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE
USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
This product complies with 21 CFR, Chapter 1, Sub-chapter J at the date of manufactured. This Class B
digital apparatus meets all requirements of the Canadian interference-causing equipment regulations.
Caution: Avoid direct or indirect (such as reflection) eye exposure to laser light! Keep out of the reach of
children!
CE Declaration Of Conformity
Hereby, the manufacturer, declares that this 2.4GHz Wireless Laser Mouse is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Essential requirements - Article 3
Protection requirements for health and safety - Article 3.1a
--Testing for electric safety according to EN 60950 has been conducted. These are considered relevant and
sufficient.
Protection requirements for electromagnetic compatibility -Article 3.1b
--Testing for electromagnetic compatibility according to EN 301 489-1, EN 301 489-17 and EN 55024 has
been conducted. These are considered relevant and sufficient.
Effective use of the radio spectrum -Article 3.2
--Testing for radio test suites according to EN 300 328-2 has been conducted. These are considered
relevant and sufficient.
Congratulations on your purchase of this Advanced 2.4GHz 4-
way Navigation Wireless Laser Mouse. Please carefully read
the User's Quick Guide to learn about the installation and the
powerful functions of your new Wireless Laser Mouse.
![](/img.php?id=794081&img=bg3.png)
4-way Navigation Wireless Laser Mouse
- 2 -
Package Content
ü 4-way Navigation Laser Mouse
ü 2.4GHz Dongle
ü Battery: Alkaline AA * 2
ü User's Quick Guide
CAUTION:
- The batteries may explode or leak if they are improperly recharged, inserted,
disposed in fire or mixed with used or different battery types.
- Risk of explosion will be caused if battery is replaced by an incorrect type.
- Dispose of used batteries according to the instructions.
- It's important that batteries should be recycled in a proper way for green
environment.
Install Hardware
Note:
- If you are running Windows 98 and plug the connector into the computer, you
may find a pop-up window that requires to insert the Windows 98 CD-ROM.
Please follow the window instruction to install the required driver or set the
driver path as "Windows\system" or the other path that the driver located.
n Install Receiver
1) Turn on the computer.
2) Connect the USB dongle to the computer.
n Link Mouse with Receiver
Note:
- Please link the devices within the effective distance.
- The linkage period is 15 seconds. Once press the
dongle's Link Button, please complete the mouse linkage process within the
linkage period.
- There is a power switch located at the back of mice for some models. Please
select "On" before linking the mouse with the dongle.
1) Place batteries into the mouse.
2) Press the ID Link Button on the receiver. There are 15 seconds for the mouse
linkage.
3) Press the ID Link Button of the mouse.
4) The mouse is linked with the receiver.
5) The product designs with the unique Smart Link function. Once the linkage
process is complete, you don't have to re-link the mouse even if you change
batteries or restart the computer.
6) If the mouse does not link with the cradle, please repeat Step 2~3.
7) The 2.4GHz product features with 4 channels and there are 256 changeable IDs
for each channel. If the selected channel or ID is interfered by other wireless-
mouse users nearby, please change the Link ID by re-linkage the device
immediately. The channel and the ID will automatically change.
USB Port
USB Version
![](/img.php?id=794081&img=bg4.png)
4-way Navigation Wireless Laser Mouse
- 3 -
Install Software (Option)
Note:
- The driver supports Windows 98/ 2000/ ME/ XP.
- When you change the interface port, please reinstall the driver.
n Install Driver
1) Insert the driver CD-ROM to your computer. The PC system may automatically
install the driver through selecting the PC auto-install function.
2) If the PC system does not set the auto-install function, please double click the file
"Setup.exe" and follow the setup instructions to complete the driver installation.
3) Restart the computer.
4) A Mouse Setting icon will appear on the task bar of Windows after you
successfully finish the installation.
5) Double click the Mouse Setting icon and then follow the instructions of the
selection items to set the mouse properties.
Introduce 4-way Navigating Function
The scroll wheel is designed with the 4-way navigating function. You
may easily view whole documents through the scroll wheel controlling
up, down, left and right.
Introduce dpi Switch Function
A dpi switch button is located at the top of the mouse. Press the
button to change the mouse's dpi to 800 or 1,600 dpi.
- 800 dpi: Default without light indicated
- 1,600 dpi: Green light
Introduce Zoom Button and 2
Side Buttons
Specially designed Zoom Button for viewing documents with efficient
usage. The side buttons are located at the mouse's left side and this
is easier to totally control the mouse application.
Uninstall Driver
Mouse Software can be removed from Windows by clicking the Add/Remove Programs
icon in the Control Panel or clicking the "Uninstall" icon in the folder that "Setup.exe"
created in "Programs" of "Start" on Windows desktop. Select Mouse Software installed
and click the "Remove" button.
![](/img.php?id=794081&img=bg5.png)
4-way Navigation Wireless Laser Mouse
- 4 -
Power Saving Function (Option)
You may continuously press the link button and then press the scroll button to turn off
the optical sensor.
Notification
Ÿ This equipment is intended for use in the following countries.
28 European Countries:
Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,
Hungary, Germany, Greece, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg,
Malta, Netherlands, Norway, Poland, Portugal, Slovak Republic, Slovenia, Spain,
Sweden, Switzerland and United Kingdom.
Ÿ The LED indicator on the receiver or the mouse, or the mouse scroll wheel will light
while the mouse is low battery. Please recharge or change the batteries immediately.
Ÿ Please do not use the mouse during charge periods.
Ÿ Scroll the wheel to wake up the mouse while the mouse is in the sleeping mode.
Ÿ New Laser Device with 800-dpi High Resolution: provides the most reliable and
accurate movement and is 20 times as sensitive as any traditional optical sensor.
Please avoid using the mouse on any reflective surfaces such as glasses and mirrors.
Ÿ Please avoid using the mice under the following conditions.
- Direct sunlight
- Extreme hot, cold, dusty or magnetic environment
- Near by fax machine, television, radio, mobile phone or any wireless device
- Metal surface
Ÿ If the wireless product is malfunction, please change or recharge the batteries, or
move the receiver away from the computer and the monitor.
Trouble Shooting
Question 1: No mouse movement.
Solution:
1) Make sure the software that you are using supports a mouse.
2) Check that mouse is plugged into serial port at the back of computer.
3) Ensure that mouse driver is installed into system.
Question 2: The cursor on the screen remains at one spot or moves erratically.
Solution:
1) Check the mouse cable for any breaks or sharp twists. Examine the cable closely
where it connects to the mouse.
Question 3: The cursor movement stops at a corner and no longer responds to the
mouse movement.
Solution:
1) Run the mouse driver to check which mode the mouse is operating in.
2) If the mouse is wireless, please check the battery power or re-link the mouse.
Question 4: Mouse movement does not produce corresponding cursor movement or
there is a brief pause during movement.
Solution:
1) Check the connecter or the cables of the mouse and the receiver if there is any break
or tangled.
![](/img.php?id=794081&img=bg6.png)
4-way Navigation Wireless Laser Mouse
- 5 -
2) If the mouse is wireless, please check the distance between the mouse and the
receiver.
Question 5: Displayed error number -115 on screen when install mouse driver software.
Solution:
1) The error usually occurs because a virus-checking program is being used on the
System to prevent files from being renamed. Please shutdown any virus checking
software running on the system and then run the setup again.
Question 6: Detection problems of the mouse
Solution:
If your mouse is connected to the mouse port and is not detected by the system, attempt
the following step(s):
1) Please check the mouse port setting from the computer.
2) If you have a mouse with a mouse port adapter, please connect the mouse to the
computer through the mouse port adapter. Restart the computer and check if the
mouse is detected properly.
3) If the mouse port adapter is not included in your package, your mouse was designed to
work on only one type of ports (PS/2 or USB). Please check the mouse port setting
from the computer.
4) If the problem persists, please check for a possible computer BIOS ROM upgrade from
your computer manufacturer.
5) Some notebook systems, such as IBM Thinkpad, have both an external Mouse Port
and an integrated Pointing Stick, which is connected to the Mouse Port. If your mouse
is having difficulty running on the Mouse Port of this type of system, please other ports.
Question 7: Conflicts with other Devices
Solution:
1) Some softwares, provided by other manufacturers, include mouse functions, which
may conflict with the Office mouse. We recommend you to remove the software
installed previously and then install the Office mouse software.
Question 8: Too much interference to wireless mice
Solution:
1) Change the location of the receiver.
2) Please remain a certain distance from other high-voltage or wireless devices.
Question 9: Problems of operating the wheel
Solution:
1) Verify that the "Browser Mouse" or "Mouse Control Panel" application is installed
properly. If you do not find the "Browser Mouse" or "Mouse Control Panel" icon in the
system tray, you need to reinstall mouse software.
2) Please install the mouse driver while the OS is under Windows 98.
3) Some other applications with mouse scrolling function may conflict with this mouse
function. Remove these applications before install the Office mouse software.
Wireless Mouse Patents
- Wireless Mouse and Stand Body: Taiwan 078386, China 01360042.7, Germany 401 06
575.8, and USA Pending
- Improved Structure of Wireless Mouse System: Taiwan 89222812, China 01100419.3,
![](/img.php?id=794081&img=bg7.png)
4-way Navigation Wireless Laser Mouse
- 6 -
Germany 201 12 178.6 and USA Pending
- Wireless Mouse Recharge System: Taiwan 90104125, China 01109443.5, Germany
20112177.8, USA Pending
- Multiple Recharge System: Taiwan 90115187, China 01120050.2, Germany 20201110.0,
USA Pending
Laser Device:
Laser Class: I
Max. Output Power: <0.716mW
Max. Wave Length at Peak Emission: 850 nm
Eye Safety: The nature of laser light gives mice the ability to track with amazing accuracy
on more surfaces. The Class I Laser is nearly invisible to the human eye and it's eye
safety.
![](/img.php?id=794081&img=bg8.png)
4-way Navigation Wireless Laser Mouse
LG-C409_2.4G manual / MADE IN CHINA
