LG ELECTRONICS CM900 Wireless Mouse User Manual
LG Electronics Inc. Wireless Mouse Users Manual
Users Manual
![](/img.php?id=744668&img=bg1.png)
1
Appearance
English
1. Right Button
2. Scrolling Wheel
3. Left Button
4. Low-Power-Alert LED (Orange)
5. Sensor LED (Red)
6. Upper Cover Lock
7. Receiver Link Button
8. Power Switch
Before Using
1. Install Batteries.
2. Turn the power on.
3. Connecting the receiver to the laptop
4. Linking the mouse and receiver for connection
- Mouse Body
- Receiver
1. Receiver link button
2. build-in LEDs
(including 1 green & 1 red)
model:CM-900 LG
![](/img.php?id=744668&img=bg2.png)
2
English
Remove the upper cover.
Install two AAA batteries into the
CM-900/ 2.4GHz Piano Mouse’s
battery slot (if you had installed the
batteries, please remove the old one
before install the new batteries).
2.
3.
Plug the USB receiver into an available
USB port on your laptop. The receiver’
s LED turns green, and blink, and then
your laptop identifies the receiver while
a default driver is installed.
Connecting the receiver to the laptop
Install Batteries
Un-lock the Upper Cover Lock.
1.
![](/img.php?id=744668&img=bg3.png)
3
English
Important: If a message or dialog box appears on the screen, follow the
on-screen prompts to complete the driver installation.
- Communications link is as the below steps :
Press and release the link button on the receiver. The receiver
lights first blinks in green when the receiver is activated, and then
turn off.
Press and release the link button on the bottom of the mouse. The
two devices establish their communication link. The receiver lights
first blinks in green, and per mouse motions could be detectable
and reflected as well as green blinks.
1.
2.
Button Switch
Press and hold both buttons for 3 seconds, then release buttons.1.
Linking the mouse and receiver
The mouse has 256 identification codes that allow the mouse and its
receiver to operate without interference from other RF devices. After
your computer detects the USB receiver and then default driver is
installed, you must make a communications link between the mouse
and its receiver before you can use the mouse.
![](/img.php?id=744668&img=bg4.png)
4
English
Conserving power of the Piano Mouse body
Do not use your mouse for five minutes. After five minutes of
inactivity, the mouse automatically enters Sleep mode to conserve
batteries’ power.
To wake up the mouse, just move the mouse or click either mouse
buttons.
1.
2.
When the mouse batteries are running low on power, the LED
light on the Mouse turns orange and blink; and the LED inner the
Receiver lights as well as the index in red.
To use your mouse’s Sleep mode based on the below setps :
If you want to switch buttons back
to its original functional definition,
please repeat the above step 1
and step 2 for change.
3.
The left button and right button
had been functional reversed.
2.
![](/img.php?id=744668&img=bg5.png)
Table OF Contents
English 1
Español 5
Italiano 9
Deutsch 13
Françai 17
Russkey 21
DGT Warning Statement
第十二條 經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均
不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干
擾現象時,應改善至無干擾時方得繼續使用。前項合法通信,指依電信法規定作業
之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性
電機設備之干擾。
FCC warning statement:
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void
your authority to operate the equipment.
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions
(1)•This device may not cause harmful interference and
(2)•This device must accept any interference received, including
interference that may cause undesired operation
1.•This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
