FCC ID: SSNDP1W0702

HCT CO., LTD.

SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA

TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr

Report No. : HCTR1005FR15 1/1

ATTACHMENT E.

- User Manual -

UL1F30HZH

- This user manual contains instructions on how to use the product properly.

- Please read this manual carefully. Be sure to follow the instructions and notices.

- GUI and package contents are subject to change without prior notice to improve the product quality.

- To view HD quality resolution, you must connect the HDMI cable.

- Firmware can be updated frequently to improve the product quality.

- To download the latest ﬁrmware, please visit www.lg.com or www.lgservice.com

* Manufactured under license from Dolby Laboratories.

* "Dolby" and the double-D symbol are trademarks of Dolby Laboratories

DP1B

DP1W

Portable Theater

Quick Guide

Under the U.S. Copyright laws and Copyright laws of other countries, unauthorized recording, use,

display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and

other materials may subject you to civil and/or criminal liability.

2 LG Multimedia Player User’s Manual

Open Source Software Notice

The following GPL executables and LGPL libraries used in this product are subject to the GPL2.0 /

LGPL2.1 License Agreements

GPL EXECUTABLES :

Linux kernel 2.6, busybox-1.10.0, dhcpcd-1.3.22-pl1, e2fsprogs-1.41.12, proc_pipe, samba-3.0.28a,

utelnetd-0.1.9-nommu, udev-141, udev-146, wireless_tools.29

LGPL LIBRARIES :

ﬂac-1.2.1, libiconv-1.12, log4c-1.2.1, mac-3.99-u4-b5, mxml-2.2, zeroconf-0.6

LG Electronics offers to provide source code to you on CD-ROM for a charge covering the cost of

performing such distribution, such as the cost of media, shipping and handling upon e-mail

request to LG Electronics at : opensource@lge.com

This offer is valid for a period of three (3) years from the date of the distribution of this product

by LG Electronics. You can obtain a copy of GPL, LGPL license from http://www.gnu.org/licenses/

old-licenses/gpl-2.0.html, http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html

Thomas G. Lane.

This product includes

Version 1.0

· dbus-1.3.0 : Academic Free License version 2.1

· expat-2.0.1 :

- The FreeType Project LICENSE, 2006-Jan-27

BSD license

· jpeg-6b : This software is based in part on the work of the Independent JPEG Group copyright

1991-1998, Thomas G. Lane.

· openssl-0.9.8k :

- crytographic software written by Eric Young (eay@cryptsoft.com).

- software written by Tim Hudson (tijh@cryptsoft.com)

- software developed by the OpenSSL Project for use in the OpenSSL Toolkit.

(http://www. Openssl.org)

Open Source Software Notice

3 LG Multimedia Player User’s Manual

· microwin-0.90 : Mozilla Public License Version 1.1

· tiff-3.7.1 :

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and

associated documentation ﬁles (the Software), to deal in the Software without restriction, including

without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and / or sell

copies of the Software, and to permit persons to whom the Software is furnished to do so, subject

to the following conditions:

The software is provided “AS IS”, without warranty of any kind, express or implied, including but not

limited to the warranties of merchantability, ﬁtness for a particular purpose and no infringement.

In no event shall the authors or copyright holders be liable for any claim, damages or other liability,

whether in an action of contract, tort or otherwise, arising from, out of or in connection with the

software or the use or other dealings in the software.

Table of contents

Open Source Software Notice

Cautions & Warnings

General Information

Compatibility Notes

Package Contents

Name of Parts

Remote control

Touch Button

USB Device Connection / Stand Installation

Connecting to your TV

Connecting to an Ampliﬁer

Connecing to your Home Network

Wired Network Connection

Wireless Network Connection

Notes on Network Connection

Home Menu

Video / Audio Setting

Digital Audio Output

Audio Output Speciﬁcations

TV Aspect Ratio

Resolution

Resolution Setting

Brightness | Contrast

HDMI Color Setting

Network Setting

Connection Setting

Connection Status

Device Name

Sharing on Network | Auto Login |

Clear Login Information

Disclaimer Notice

Others Setting

Menu Language Setting

DivX VOD

Power Mode

Screen Saver

Information | Initialize

Software (Firmware Upgrade)

USB Device Connection

Caution During Using USB Device

File Setting

File Information | File Search

File Copy

File Rename

File Delete

5~6

10~13

15~16

17~18

30~32

.....................

.........................................

........................................................

..............................................................

....................................................................

...................................................................

.......................................................................

................

.......................................................

..............................................

...........................................

.......................................

......................................

........................................................................

......................................................

.........................................

..............................................................

........................................................................

..........................................................

......................................................

.........................................................

........................................................

.........................................................

..................................................................

.................................................

............................................................

................................................

.........................................................................

.....................................................................

...................................................................

.....................................................

.......................................

...............................................

..............................

.........................................

...........................................................................

.....................................................................

........................................................................

Playing a Video File

General Playback | Using colored buttons (R, G, Y, B)

General Playback

Slow | Fast Forward / Rewind |

Fast Forward / Rewind Skip (5 min)

Previous / Next ﬁle playback | Repeat | Information

Enlarge the Playback Video | Time Search

On-Screen Display

Selecting Audio dubbing | Selecting Subtitle ﬁle

Video ﬁles

Listening to Music File

General Playback

General Playback | Fast Forward / Rewind |

Repeat Playback

Previous / Next ﬁle playback | Information

Viewing a Photo File

General Playback

Repeat Playback | Enlarge the Playback Image

On-Screen Display

Playing YouTube Videos

About YouTube Menu

Playing YouTube Videos

Searching Videos

Viewing Picasa Web Albums

About Picasa Web Albums Menu

Viewing Picasa Web Albums

Searching Photos

Adding NetCast friends

Using the AccuWeather

Playing content via your home network

Accessing a DLNA media server

Entering a network user ID and the password

Sharing ﬁles and folders for PC

Sharing Files and Folders in DLNA (UPnP)

File Compatibility

Trouble Shooting

IMPORTANT INFORMATION RELATING

TO NETWORK SERVICES

Trademarks and Licenses

FCC Regulation

Speciﬁcation

LG Service Site

72~73

76~77

79~82

87~88

...

.................................................................

.................................

.....

......................

..............................................................

..........

.............................................................................

.................................................................

..................................................................

.....................

.................................................................

.............

..............................................................

........................................................

.....................................................

................................................................

...................................

.............................................

...............................................................

................................................................

.....................................................

........................................................

.....................................

.................

.........................................

.....................

.................................................................

.....................................................................

....................................................

.....................................................

........................................................................

............................................................................

.......................................................................

4 LG Multimedia Player User’s Manual

Cautions & Warnings

5 LG Multimedia Player User’s Manual

Warning

- This user manual contains instructions on how to use the product properly.

- Please read this manual carefully.

- Be sure to follow the instructions and notices.

● Notes are divided into “Warning”, “Caution” and “Tip” each denotes the following:

Warning

Caution

Tip

Failure to follow the instructions below may result

in injuries or product damage.

Failure to follow the instructions below may result

in serious injuries or product damage.

It provides a recommendation to prevent product failure

or malfunction in advance when using the product.

- LG EXCLUDES LIABILITY FOR ALL CONSEQUENTIAL AND OTHER LOSS,

INCLUDING LOSS OF DATA.

- Defects may occur under following circumstance.

: Keep away from humidity, dust, and soot (may cause ﬁre or electrocution).

: Keep away from areas with temperature of above 35 ℃ (95 ℉).

: Keep away from magnetic ﬁelds, water, heat.

: Do not use during thunder and lightning.

: Do not drop the product or place heavy objects on it.

- Make sure no dust or other foreign matter gets inside the port.

It may cause data damage.

- Do not pull out the USB cable while the product operating.

(The product may malfunction.)

- If smoke, unpleasant odor or noise is produced, unplug the power

and peripherals immediately and remove all cables.

- Use only power supplies listed in the user's manual.

- The USB-Modem has to be connected to USB interfaces USB 2.0 versions or higher.

The connection to the so-called power USB is prohibited.

- Switching Adapter: Shenzhen Honor Electronics Co., Ltd.(type: ADS-24RD-12 1224G)

Rating: Input: 100-240 V~, 50/60 Hz, max. 0.7 A /Output: 12 V , 2.0 A

Cautions & Warnings

6 LG Multimedia Player User’s Manual

Cautions

- DO NOT PLACE THIS PRODUCT WHERE IT CAN BE REACHED BY CHILDREN.

THE PRODUCT CAN GET HOT WHILE WORKING. IT MAY RESULT IN BURNS.

- Do not touch the heat vent when the product is operating.

It may become hot and may result in burns.

- Intended for personal use. Do not use for commercial purposes.

- Do not use the product for a long time without cooling it down.

- Do not drop the product or place heavy objects on it.

- This product is intended for use with TV’s and monitors.

Do not use this product for anything other than its intended purpose.

- Do not touch the power plug with wet hands. Additionally,

if the cord pin is wet or covered with dust, dry the power plug completely

or wipe dust off. You may be electrocuted due to moisture.

- Do not attempt to modify this product in any way without authorization from

LG Electronics. Unauthorized modiﬁcation could void the user’s authority

to operate this product

- Please read this manual carefully before using the product.

If you abuse the product, it can be damaged.

General Information

7 LG Multimedia Player User’s Manual

Compatibility Notes

· To display full HD contents, the TV with HDMI port is required.

· This player supports Dolby digital and DTS 5.1 Channels if an ampliﬁer / receiver is connected

using a HDMI cable or a Optical Digital audio cable.

· OGG and FLAC (Audio codec) only support audio ﬁles. (Video ﬁles are not supported.)

· This product is not support external Blue ray Drive and DVD Drive.

Certain System Requirement

Requirement for HD content display

· To display full HD contents, the TV with HDMI port is required.

- To connect TV or monitor with DVI port, please use the HDMI-DVI conversion cable, and please

connect Optical Digital audio cable or composite cable for audio.

- The USB Storage device including HD contents is required.

· For up-conversion of standard deﬁnition DVD, a HDMI or HDCP capable DVI input on your display

device is required for copy protected content.

Requirement for Dolby Digital Audio playback.

· Ampliﬁer with Dolby Digital or DTS decoder (A/V receiver)

· 5.1 Channel speaker

(Front surround speaker, Rear surround speaker, Center speaker, Sub woofer)

AVCHD

AVCHD (Advanced Video Codec High Deﬁnition)

· This player can playback AVCHD format. These format is normally recorded and used in camcorders.

· The AVCHD format is a high deﬁnition digital video camera format.

· The MPEG-4 AVC/H.264 format is capable of compressing images at higher efﬁciency than that

of the conventional image compressing format.

· Some AVCHD format use the “x.v.Color” format.

· This player can playback AVCHD format using “x.v.Color” format.

· Some AVCHD format may not play depending on the recording condition.

· “x.v.Color” is trademarks of Sony Corporation.

· “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

Compatibility Notes

Package Contents

8 LG Multimedia Player User’s Manual

1. Multimedia Player

2. Remote control

3. Power adapter (Optional Plug)

4. A/V composite cable

5. Manual CD

6. Quick guide

7. SCART adapter (EU region only)

8. Batteries (2 pcs, AAA type)

ڤ ڥ

ڢڣ

Depending on the region, some

of the plugs may not be included

(EU region only)

※ Check to make sure that you have all the components shown above.

If there are any problems with the package contents,

please consult the store or retailer.

※ The accessories included may differ from the images.

※ Components are subject to change without prior notice to improve

the product quality.

※ Depending on the region, some of the plugs may not be included.

<< Note for cable connection >>

- Connect the audio/video connection securely.

(Please see the User’s manual of TV or monitor for your reference.)

- After audio/video connection, plug in the product to protect it from over heat

and electric shock.

- Connect the A/V composite cable properly to corresponding jack.

- This user manual contains instructions on how to use the product properly.

- Please read this manual carefully. Be sure to follow the instructions and notices.

- GUI and package contents are subject to change without prior notice to improve the product quality.

- To view HD quality resolution, you must connect the HDMI cable.

- Firmware can be updated frequently to improve the product quality.

- To download the latest ﬁrmware, please visit www.lg.com or www.lgservice.com

* Manufactured under license from Dolby Laboratories.

* "Dolby" and the double-D symbol are trademarks of Dolby Laboratories

DP1B

DP1W

Portable Theater

Quick Guide

Name of Parts

9 LG Multimedia Player User’s Manual

ڡ ڢ ڣ ڤ ڥ ڦ ڧ ڨ

ګ ڬ ڭ ڮ گ װ

1. Direction (Down) Button

2. Direction (Up) Button

3. Direction (Left) Button

4. Direction (Right) Button

5. OK Button

6. Menu Button

7. Return Button

8. Power Button

9. USB Host port 1

10. USB Host port 2

11. Reset Button

12. Digital audio out port (Optical)

13. A/V composite port (Phone jack type)

14. HDMI port

15. LAN port

16. Power supply connector (12 V, 2 A)

17. Status LED

18. Remote Control Sensor

19. Stand

Remote control

10 LG Multimedia Player User’s Manual

EJECT

POWER

INFO

NET CAST

NET TEST

REWIND

STOP

SETUP

MUTE

VOLUME (+, -)

LEFT

GREEN

RED

ZOOM

SUBTITLE

If you press and hold the button, it may jump to the next step

due to the remote control sensitivity.

COPY

POWER MODE

SLOW

PLAY / PAUSE

FAST FORWARD

HOME

REPEAT

PAGE (ખL@ગ)

RIGHT

DOWN

RETURN

YELLOW

BLUE

ROTATE

BGM

AUDIO

Remote control

11 LG Multimedia Player User’s Manual

POWER

EJECT

COPY

INFO

POWER MODE

NET TEST

NET CAST

SLOW

PLAY / PAUSE

REWIND

FAST FORWARD

STOP

SETUP

HOME

REPEAT

VOLUME (+, -)

MUTE

PAGE (ખL@ગ)

Turn on / off power

USB safely remove

File copy

Display the ﬁle information

Change power mode

(Power Off – Network – Check Mode)

Network connection test

Display YouTube, Picasa, AccuWeather

Play movie slowly in full screen mode

Play / pause the ﬁle

Rewind the movie or music playback

Forward the movie or music playback

Stop playing

Play the previous ﬁle, movie chapter

Play the next ﬁle, movie chapter

Go to the setup menu

Go to the main menu

Change the repeat function of movie, music, photo

Increase / decrease the volume

(To maximize the volume, increase the TV volume)

Mute / resume audio output

Go to the next / previous page of the list

Remote control

12 LG Multimedia Player User’s Manual

DOWN

LEFT

RIGHT

RETURN

RED

GREEN

YELLOW

BLUE

ZOOM

ROTATE

BGM

SUBTITLE

AUDIO

Conﬁrm / play selected ﬁle

Display the status bar during playing movie, photo

Move down

Move up

Move left,

Move to 5 minutes before in movie full screen mode

Move right,

Move to 5 minutes after in movie full screen mode

Go to option menu

Stop / return playing ﬁle

Go to upper folder / menu

Control function button

File search,

Playback navigation available in movie full screen mode

Zoom in / out during movie, photo playing

Rotate the photo to 90 degrees (Clockwise)

in full screen mode

Background music customizable in photo full screen screen

Subtitle setting

Change the available audio track of movie

Remote control

Touch Button

13 LG Multimedia Player User’s Manual

Remove the battery cover on the rear of the Remote control,

and insert two R03 (size AAA) batteries with + and – matched

correctly.

・ Do not mix old or used batteries with new ones.

Point the remote control directly at the remote control sensor

within 7 m.

30°30°

Battery Installation

Precaution in Installing the Product

ڡ ڢ ڣ ڤ ڥ ڦ ڧ ڨ

Move down

Move up

Move left,

Move to 5 minutes before in movie full screen mode

Move right,

Move to 5 minutes after in movie full screen mode

Conﬁrm / play selected ﬁle

Display the status bar during playing movie, photo

Go to option menu

Stop / return playing ﬁle

Go to upper folder / menu

Turn on / off power

DOWN

LEFT

RIGHT

RETURN

POWER

USB Device Connection / Stand Installation

14 LG Multimedia Player User’s Manual

This high performance portable multimedia device supports

Full HD capabilities. (It works properly without the stand as well.)

<< Precaution in USB connection >>

- When you connect the 3.5 External HDD, use the power adapter as well.

(HDD would not be recognized due to insufﬁcient power.)

※

If you lack USB port space or a USB port is blocked

due to multiple input devices, please utilize USB

extension cables.

(USB extension cable is not included.)

※

This player can play movie, music and photo ﬁles contained

in the USB drive, external HDD and ﬂash memory card reader.

When you connect a USB Storage device to the player,

USB icon will be activated on ﬁle list mode.

1. To secure the device into the stand, ﬁrmly support the back of the device

from below while positioning the insertion tab into corresponding opening.

Slide device forward to lock the device in place.

2. To disengage the stand, press lightly on it while sliding back

and out of locking device.

USB Device Connection

Stand Installation

Connecting to your TV

15 LG Multimedia Player User’s Manual

HDMI Connection

HDMI cable delivers all the

picture and sound data.

1. If you have a HDMI TV or monitor, you can connect it to this player using a HDMI cable (Type A,

Version 1.3). Connect the HDMI jack on the player to the HDMI jack on a HDMI compatible TV

or monitor.

2. When you us HDMI connection, you can change the resolution for the HDMI output (Auto, 480p,

720p, 1080i, 1080p)

(Refer to “resolution setting” chapter.)

3. Select the type of video output from the HDMI OUT jack using [HDMI Color Setting] option on

[Setup] menu.

HDMI cable (Ver. 1.3)

※ Additional Information for HDMI ※

・ When you connect a HDMI or DVI

compatible device make sure of the

following:

-Try switching off the HDMI/DVI device

and this player. Next, switch on the HDMI /

DVI device and leave it for around 30

seconds, then switch on this player.

-The connected device’s video input is set

correctly for this unit.

-The connected device is compatible with

720x480p, 1280x720p, 1920x1080i or

1920x1080p video input.

・ Not all HDCP-compatible HDMI or DVI

devices will work with this player.

- The picture will not be displayed properly

with non-HDCP device.

- This player does not playback and TV

screen is changed to black screen.

- To view HD quality resolution you must

connect the HDMI cable.

Video in

(Right)

Audio in

(Left)

AV in

S-Video

· It takes about few seconds (Approximately 30 seconds) to display Main menu after showing

LG Logo.

Connecting to your TV

16 LG Multimedia Player User’s Manual

Audio (Left / Right) / Video Connection

Connect the A/V Composite port on the player to the video / Audio jack on the TV

using A/V Composite cable (Phone jack type).

・ Depending on TV, it can be connected to [AV1], [AV2], [AV3] or [AV4]

・ It takes about few seconds (Approximately 30 seconds) to display Main menu after showing LG Logo.

Video in

(Right)

Audio in

(Left)

(Power Button)

※ Power adapter connection ※ LED operating status

※ Connect the power adapter with

regional plug.

Depending on the region, some

of the plugs may not be included.

※ To turn on the product, press power

button of the remote control or product.

Plugged in (Red LED) → Boot up (Red

LED Flashes) → Ready to use (Blue LED)

Blue LED will ﬂash during operating.

It takes about few seconds (Approximately

30 seconds) to display Main menu

after showing LG logo.

AV in

S-Video

Connecting to an Amplifier

17 LG Multimedia Player User’s Manual

Dolby Digital Ampliﬁer | DTS Ampliﬁer (High Quality Digital Audio)

1. Connect the player’s Digital audio out port (Optical) to the corresponding in optical

jack on your ampliﬁer. Use an optional digital audio cable. You will need to activate

the player’ digital output.

- It supports surround sound.

2. Connect the player’s [A/V composite port (phone jack type)] to TV’s [Video in]

port using a A/V composite cable, or Connect the player’s [HDMI port] to TV’s

[HDMI in] port using a HDMI cable.

・ Select the output sound format when a device equipped with a HDMI or Digital Audio input jack

is connected to the HDMI OUT or DIGITAL AUDIO OUT jack on this player.

・ Depending on the Amplifier or receiver, the port will be differ from image. Please see the User’s

manual of Amplifier.

・ Output levels should be properly adjusted before use to prevent damage to the output device.

Composite A/V cable

HDMI cable (ver. 1.3)

Optical cable

Video in

(Right)

Audio in

(Left)

Receiver / Ampliﬁer

AV in

S-Video

Connecting to an Amplifier

18 LG Multimedia Player User’s Manual

Connecting to an Ampliﬁer via HDMI Output

・ Select the output sound format when a device equipped with a HDMI or Digital Audio input jack

is connected to the HDMI OUT or DIGITAL.

・ Depending on the amplifier, location of jack will be different. Please see the User’s manual of

amplifier for a reference.

HDMI cable (ver. 1.3)

Receiver / Ampliﬁer

1. Connect the player’s HDMI out jack to the corresponding in jack on your ampliﬁer

using a HDMI cable (ver. 1.3).

2. Connect the ampliﬁer’s HDMI output jack to HDMI input jack on your TV using a

HDMI cable if your ampliﬁer has HDMI jack. (to connect TV and ampliﬁer using

HDMI cable, please see the User’s manual of ampliﬁer for you reference.)

Connecting to your Home Network

19 LG Multimedia Player User’s Manual

Wired Network Connection

Modem or Router

This player can be connected to a local area network (LAN) via the LAN port on the rear panel

or the wireless device. By connecting the player to a broadband home network, you have access

to service such as YouTube, Picasa and AccuWeather.

Connect the player’s LAN Port(RJ-45) to the corresponding port on your Modem or Router using a

commercially available LAN or Ethernet cable.

Using a wired network provides the best performance,

because the attached devices connect directly to the

network and are not subject to radio frequency

interference.

Please refer to the documentation for your network

device for further instructions.

Connect the player’s LAN port to the corresponding

port on your Modem or Router using a commercially

available LAN or Ethernet cable (CAT5 or better with

RJ45 connector).

In the example conﬁguration for wired connection

above, this player would be able to access content

from either of the PCs.

If there is a DHCP server on the local area network

(LAN) via wired connection, this player will

automatically be allocated an IP address. After

making the physical connection, small number of

home networks ma required the player’s network

setting to be adjusted.

Note

When plugging or unplugging the LAN cable, hold

the plug portion of the cable. When unplugging, do

not pull on the LAN cable but unplug while pressing

down on the lock.

Do not connect a modular phone cable to the LAN

port.

Since there are various connection conﬁgurations,

please follow the speciﬁcations of your

telecommunication carrier or internet service provider.

If you want to access content from PCs or DLNA

servers, this player must be connected to the same

local area network with them via a router.

Internet

Service

Connecting to your Home Network

20 LG Multimedia Player User’s Manual

Wireless Network Connection

This player can be connected to a local area network (LAN) via the LAN port on the rear panel

or the wireless device. By connecting the player to a broadband home network, you have access

to service such as YouTube, Picasa and AccuWeather.

※ DP1W Model : Wi-Fi module is embedded for Wireless network connection.

※ DP1B Model : Wi-Fi dongle is required for Wireless network connection.

Another connection option is to use an Access Point or

a wireless router. In the example conﬁguration for

wireless connection above, this player would be able to

access content from either of the PCs.

The network conﬁguration and connection method may

vary depending on the equipment in use and the

network environment.

This player is equipped with an IEEE 802.11n (2.4 GHz

band only) wireless module, which also supports the

802.11b / g standards. For the best wireless

performance, we recommend using a IEEE 802.11n

certiﬁed Wi-Fi network (access point or wireless router).

Available Wi-Fi standards:

802.11b / 802.11g / 802.11n (single-band 2.4 GHz)

※ WPS PBC Mode

WPS : Wi-Fi Protect Setup

PBC : Push Button Connect

· Press PBC button on the Access Point / Wireless

router to connect to player directly.

(Some of Access Point / Wireless routers do not

have the PBC button.)

· First of all, proper wireless network setting is required.

· In the Wireless Network list, Press “Push Button” and

the press PBC button on the Access Point / Wireless

router, it will be directly connected in 2 minutes

Access Point /

Wireless router

Wireless

Communication

For the wireless network connection, the player needs to

be set up for network communication. This adjustment

can be done from the [Setup] menu, Adjust the

[Network] setting as follow. Setting up the access point

or the wireless router is required before connecting the

player to the network.

Wired internet connection is strongly recommended.

Using the [Home Link] features, network update and

video streaming services (such as, YouTube, Picasa and

AccuWeather) with wireless network can be affected by

the household devices using radio frequencies.

The content of internet service and related service

information, including user interface, is subject to

change. Please refer to the web site of each service for

updated information.

※ Note for DP1B Model

Wi-Fi Dongle is only compatible with pre-approved

models listed on LG website.

(www.lg.com or www.lgservice.com)

Check LG website for compatibility before purchasing

Wi-Fi dongle.

Connecting to your Home Network

21 LG Multimedia Player User’s Manual

Notes on Network Connection

※ Many network connection problems during set up can often be ﬁxed by re-setting the router or

modem. After connecting the player to the home network, quickly power off and/or disconnect

the power cable of the home network router or cable modem. Then power on and/or connect

the power cable again.

※ Depending on the internet service provider (ISP), the number of devices that can receive

internet service may be limited by the applicable terms of service. For details, contact your ISP.

※ Our company is not responsible for any malfunction of the player and/or the internet

connection feature due to communication errors/malfunctions associated with your broadband

internet connection, or other connected equipment.

※ The features of contents made available through the Internet Connection feature are not

created or provided by our company, and our company is not responsible for their functionality

or continued availability. Some contents related material available by the Internet Connection

may not be compatible with this player. If you have questions about such content, please contact

the producer of the content.

※ Some internet contents may require a higher bandwidth connection.

※ Even if the player is properly connected and conﬁgured, some internet contents may not operate

properly because of internet congestion, the quality or bandwidth of your internet service, or

problems at the provider of the content.

※ Some internet connection operations may not be possible due to certain restrictions set by the

Internet service provider (ISP) supplying your broadband Internet connection.

※ Any fees charged by an ISP including, without limitation, connection charges are your

responsibility.

※ A 10 Base-T or 100 Base-TX LAN port is required for wired connection to this player. If your

internet service does not allow for such a connection, you will not be able to connect the player.

※ You must use a Router to use xDSL service.

※ A DSL modem is required to use DSL service and a cable modem is required to use cable

modem service. Depending on the access method of and subscriber agreement with your ISP,

you may not be able to use the internet connection feature contained in this player or you may

be limited to the number of devices you can connect at the same time. (If your ISP limits

subscription to one device, this player may not be allowed to connect when a PC is already

connected.)

※ The use of a IRouterI may not be allowed or its usage may be limited depending on the policies

and restrictions of your ISP. For details, contact your ISP directly.

※ The wireless network operate at 2.4 GHz radio frequencies that are also used by other household

devices such as cordless telephone, Bluetooth® devices, Microwave oven, and can be affected by

interference from them.

※ Turn off all unused network equipment in your local home network. Some devices

may generate network trafﬁc.

※ For the purpose of the better transmission, placing the player from the access point as close as

possible.

※ In some instances, placing the access point or wireless router at least 0.45 m (1.5 ft) above the

ﬂoor may improve the reception.

※ Move closer to the access point if possible or re-orient the player so there is nothing between it

and the access point.

※ The reception quality over wireless depends on many factors such as type of the access point,

distance between the player and access point, and the location of the player.

Home Menu

22 LG Multimedia Player User’s Manual

Home Menu

※ Media Selection Menu.

When a USB Device or External Hard Disk Drive is connected on the product.

Media Selection Menu will be displayed.

Select the [USB1] or [USB2] option using < / >, and press enter [OK].

・ Some of Menus are not activated without proper

contents.

・ If you press [HOME] during playing content,

Home Menu is shown. (the played content is

paused.)

· After connecting to wired / wireless network, you will see the icons.

(You can check the connection strength of a wireless connection.)

· The network connection screen can only be seen in each menu within browser mode. You can not see

these icons during playing movie, photo and music ﬁles. These icons can not see in [Setup] menu as well.

Home Menu

In Home Menu, use various Multimedia

player’s functions conveniently.

Movie : Display [Movie] Menu.

Photo : Display [Photo] Menu.

Music : Display [Music] Menu.

Home Link : Display Media Server Selection Menu.

NetCast : Display [Netcast] Menu.

Setup : Display [Setup] Menu.

Press [HOME]. Select option

using < / >.

Press [OK]. Selected option

ormenu will be shown.

[HOME]

Navigation button

and [OK]

[RETURN]

: Wired network is connected : Wireless network is connected

Video / Audio Setting

23 LG Multimedia Player User’s Manual

Digital Audio Output

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

[PCM Stereo]

Select if you connect this unit’s HDMI out or

Digital audio out jack to a device with two-channel

digital stereo decoder.

[Primary Pass-Thru]

Select if you connect this unit’s Digital Audio Out

and HDMI Out jack to a device with LPCM, Dolby

digital, DTS decoder.

・ If the audio format of the digital output does not

match the capabilities of your receiver, the

receiver will produce a strong, distorted sound or

no sound at all.

Digital Audio Output

Select the output sound format when a

device equipped with a HDMI or Digital

Audio input jack is connected to the HDMI

out or Digital Audio jack on this player.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK] for

conﬁrmation.

Move to [VIDEO

/ AUDIO].

Go to [SPDIF].

Select option

using ∧ / ∨.

※ Caution

· If you select [Primary Pass-Thru] for

[Digital Audio Output], This player

cannot support to increase / decrease

the volume of Dolby Digital (AC3) and

DTS audio format.

· To increase / decrease the volume,

control the volume of Ampliﬁer.

Video / Audio Setting

24 LG Multimedia Player User’s Manual

Audio Output Speciﬁcations

1. The secondary and interactive audio may no be included in the output bitstream if

[Digital Output] or [HDMI] option is set to [Primary Pass-Thru]. (Except LPCM Codec :

the output always include interactive and secondary audio.)

2. [Primary Pass-thru] does not support Multi-Channel analog audio source. (the sound

may not be heard through SPDIF or HDMI.) Please set to [PCM Stereo] for Multi-

Channel analog audio source.

3. If the Audio format of the digital output does not match the capabilities of your

receiver, the receiver will produce a strong, distorted sound or no sound at all.

Dolby Digital (5.1 Ch) PCM 2 Ch PCM 2 Ch Dolby Digital (5 .1 Ch)

Dolby Digital Plus (7.1 Ch) PCM 2 Ch PCM 2 Ch Dolby Digital (5.1 Ch)

Dolby TrueHD (7.1 Ch) PCM 2 Ch PCM 2 Ch Dolby Digital (5.1 Ch)

DTS (5.1 Ch) PCM 2 Ch PCM 2 Ch DTS (5.1 Ch)

DTS-HD (7.1 Ch) PCM 2 Ch PCM 2 Ch DTS (5.1 Ch)

Linear PCM 2 Ch PCM 2 Ch PCM 2 Ch PCM 2 Ch

Linear PCM 5.1 Ch PCM 2 Ch PCM 2 Ch PCM 2 Ch

Linear PCM 7.1 Ch PCM 2 Ch PCM 2 Ch PCM 2 Ch

Multi-Channel analog PCM 2 Ch PCM 2 Ch No Sound

Jack / Setting Analog

Audio Out

Digital Audio Out (HDMI / SPDIF)

PCM Stereo Primary Pass-thru

Audio Source

Video / Audio Setting

25 LG Multimedia Player User’s Manual

Digital Audio Output

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

TV Aspect Ratio

Select a TV aspect ratio option according

to your TV type.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK] for

conﬁrmation.

Move to [VIDEO

/ AUDIO].

Go to [TV Aspect

Ratio].

Select option

using ∧ / ∨.

4 : 3 TV / Monitor

Aspect

Ratio

16 : 9 TV / Monitor

Aspect

Ratio

4 : 3

16 : 9

4 : 3

16 : 9

4 : 3

Photo / Video

4 : 3

Photo / Video

16 : 9

Photo / Video

16 : 9

Photo / Video

Video / Audio Setting

26 LG Multimedia Player User’s Manual

Resolution

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

・ If you select a resolution that your TV does not

accept, the warning message or abnormal screen

will appear.

・ If you select a resolution manually and then

connect the HDMI jack to TV and your TV does

not accept it, the resolution setting is set to

[Auto].

・ For more detail resolution information, please

see the next page.

Resolution

Sets the output resolution of the Composite

and HDMI video signal

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK] for

conﬁrmation.

Move to [VIDEO

/ AUDIO].

Go to [Resolution].

Select option using ∧ / ∨.

Auto, 480i, 480p, 720p, 1080i, 1080p

Video / Audio Setting

27 LG Multimedia Player User’s Manual

Resolution Setting

Resolution Type

- Auto : If the HDMI OUT jack is connected to TV’s providing display information (EDID),

automatically selects the resolution best suited to the connected TV.

- NTSC : Outputs 480 lines of interlaced video. (60 Hz)

- PAL : Outputs 576 lines of interlaced video. (50 Hz)

- 480p : Outputs 480 lines of progressive video. (60 Hz)

- 576p : Outputs 576 lines of progressive video. (50 Hz)

- 720p 50 Hz : Outputs 720 lines of progressive video. (50 Hz)

- 720p 60 Hz : Outputs 720 lines of progressive video. (60 Hz)

- 1080i 50 Hz : Outputs 1080 lines of interlaced video. (50 Hz)

- 1080i 60 Hz : Outputs 1080 lines of interlaced video. (60 Hz)

- 1080p 50 Hz : Outputs 1080 lines of progressive video. (50 Hz)

- 1080p 60 Hz: Outputs 1080 lines of progressive video. (60 Hz)

- 1080p 24 Hz: When the resolution is set to 1080p, select [24 Hz] for smooth presentation of ﬁlm material

(1080p / 24 Hz) with a HDMI-equipped display compatible with 1080p / 24 Hz input.

HDMI / Video out connection

HDMI out Connection

- Auto, 1080p, 1080i, 720p, 576p, 480p is available.

- If you select a resolution manually and then connect the HDMI jack to TV and your TV does not accept it,

the resolution setting is set to [Auto].

Video out connection

- The resolution of the Video out jack is always outputted at NTSC or PAL resolution.

The optimized mode for TV

The optimized mode for PAL TV’s and NTSC TV’s is 50 Hz and 60 Hz, respectively.

- Choosing the wrong frequency mode(50 Hz or 60 Hz) can cause the screen to shake

during movie or picture playback.

· This product supports HDMI out and A/V out simultaneously.

· HDMI or HDCP capable DVI input on your display device is required for some content.

This 1080p video output frame rate may be automatically set to either 24 Hz or 60 Hz depending both on the

capability and preference of the connected TV and based on the native video frame rate of the content.

- When you select [24 Hz], you may experience some picture disturbance when the video switches video and ﬁlm

material. In this case, select [60 Hz].

- Even when [1080p Display Mode] is set to [24 Hz], if your TV is not compatible with 1080p / 24 Hz, the actual

frame frequency of the video output will be 60 Hz to match the video source format.

Video / Audio Setting

28 LG Multimedia Player User’s Manual

Brightness | Contrast

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

・ Brightness / Contrast level range is 0 to 50.

Brightness / Contrast

Sets the Brightness / Contrast level of the

Composite and HDMI video signal

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK] for

conﬁrmation.

Move to [VIDEO

/ AUDIO].

Go to [Brightness]

or [Contrast]

Select option

using ∧ / ∨.

Video / Audio Setting

29 LG Multimedia Player User’s Manual

HDMI Color Setting

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

HDMI Color Setting

Select the type of output from the HDMI

OUT jack. For this setting, please refer to

the manuals of your display device.

- YCbCr : Select when connect to HDMI

display device.

- RGB : Select when connect to DVI

display device.

- Auto : Automatically selects the HDMI

Color Setting

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK] for

conﬁrmation.

Move to [VIDEO

/ AUDIO].

Go to [HDMI Color

Setting].

Select option using ∧ / ∨.

YCbCr, RGB

· Default setting are recommended. When

choosing YCbCr or RGB, the screen may take a

few seconds to apply the settings.

(Screen will turn off.)

Network Setting

30 LG Multimedia Player User’s Manual

Connection Setting

[HOME]

Navigation button

and [OK]

[RETURN]

・ Using a wired network provides the best performance,

because the attached devices connect directly to the

network and are not subject to radio frequency

interference.

・ Before setting the wired network, you need to connect

the broadband internet to your home network.

・ After connecting to wired network, you will see the

icons. (The network connection screen can only be

seen in each menu within browser mode.

You can not see these icons during playing movie,

photo and music ﬁles. These icons can not see in

[Setup] menu as well.)

Note

If there is no DHCP server on the network and you want to set the IP

address manually, select [Static] then set [IP Address], [Subnet Mask],

[Gateway] and [DNS Server] using < / > / ∧ / ∨ buttons.

To check for network connection, please click the [Test] button.

Please refer to “Connection Status” Chapter.

Wired network Setting

Choose [Network] → [Connection setting] and press [OK]

By connecting the unit to a broadband home

network, you have access to services such Home

Link and NetCast

2) Static Mode

Select [Wired] and press [OK].

Select IP mode [Static] and press [OK].

Set [IP Address], [Subnet Mask], [Gateway]

and [DNS Server].

<- : Deletes the character.

<< : Move to previous block.

>> : Move to next block.

» Press [OK] to complete the network connection.

1) Dynamic Mode

Select [Wired] and press [OK].

Select IP mode [Dynamic] and press [OK].

» Press [OK] to complete the network

connection.

* Dynamic connection is recommended for home use.

: IP is automatically found.

: Most Internet service providers (ISP) provide DHCP functions.

DHCP (Dynamic Host Conﬁguration Protocol) – IP automatically assigned.

* When connecting to a static IP, Please beware of IP collision.

: This means connecting to a static IP within its own network.

: If the same IP is shared within the network, functions may be limited.

: Before connecting to a static IP, please verify if it is currently in use by another machine.

: When connecting to a static IP via router or other device, please refer to its user manual and follow IP address / DHCP connection settings

or seek assistance from a specialist.

: Wired network is connected

Network Setting

31 LG Multimedia Player User’s Manual

Connection Setting

※ Push Button

If your access point or wireless router that supports the Push

Button Conﬁguration method, select this option and

press the Push Button on your access point or wireless router within

120 seconds. You do not need to know the access point name (SSID)

and security code of your access point or wireless router.

※ Favorite

The last network connection information will be stored automatically

in favorite list. (If there is no network connection information,

favorite list is not activated.)

If you connect network in favorite list, Network ID and password are

not required.

Wireless network setting

For the wireless network connection, the player needs to be set up for network communication.

This adjustment can be done from the [Setup] menu. Setting up the access point or the

wireless router is required before connecting the player to the network.

After connecting to wireless network, you will see the icons.

(You can check the connection strength of a wireless connection.)

The network connection screen can only be seen in each menu within browser mode. You can not see these

icons during playing movie, photo and music ﬁles. These icons can not see in [Setup] menu as well.

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Select [Wireless] and press [OK].

Select an access point or wireless router on the

list, and then press [OK].

» The player scans the all available access

points or wireless routers within range and

display them as a list.

» If you have security on your access point or

wireless router, you need to input the security

code as necessary.

» Press [OK] to complete the network connection.

Press [NET TEST] to scan the all available access

point or wireless routers in [Connection Setting] Menu.

For password input / keyboard use, please refer to

[File Rename] chapter.

※ WPS PBC Mode

WPS : Wi-Fi Protect Setup

PBC : Push Button Connect

· Press PBC button on the Access Point / Wireless router to connect to player directly.

(Some of Access Point / Wireless routers do not have the PBC button.)

· First of all, proper wireless network setting is required.

· In the Wireless Network list, Press “Push Button” and the press PBC button on the Access Point / Wireless

router, it will be directly connected in 2 minutes

Choose [Network] → [Connection setting] and press [OK].

1) Dynamic Mode

: Wireless network is connected

Network Setting

32 LG Multimedia Player User’s Manual

Connection Setting

Note

If there is no DHCP server on the network and you want to set the IP

address manually, select [Static] then set [IP Address], [Subnet Mask],

[Gateway] and [DNS Server] using < / > / ∧ / ∨ buttons.

Wireless network setting

Press [HOME] or [RETURN] to exit menu or cancel the selection.

2) Manual Mode

5-1

5-2

Select [Wireless] and press [OK].

Select [Manual] and press [OK]. Manually

enter the access point name (SSID) and

then select [OK] and press [OK].

Choose a security for wireless network and

press [OK].

» Selectable option (No Security, WEP,

WPA-PSK TKIP, WPA-PSK AES, WPA2-

PSK TKIP, WPA2-PSK AES)

Input the password for wireless network.

Select [OK] and press [OK].

» If you choose [No Security] for previous

step, you do not need to input the password.

Select IP mode [Dynamic] and press [OK].

» Press [OK] to complete the network

connection.

Select IP mode [Static] and press [OK].

Set [IP Address], [Subnet Mask], [Gateway]

and [DNS Server].

<- : Deletes the character.

<< : Move to previous block.

>> : Move to next block.

» Press [OK] to complete the network connection.

If the network is secured, the SSID may be unable to be found.

These are steps to manually input and connect to the SSID.

※ For keyboard use when entering SSID, please refer to [File Rename] chapter.

※ Dynamic connection is recommended for home use.

: IP is automatically found.

: Most Internet service providers (ISP) provide DHCP functions.

DHCP (Dynamic Host Conﬁguration Protocol) – IP automatically assigned.

※ When connecting to a static IP, Please beware of IP collision.

: This means connecting to a static IP within its own network.

: If the same IP is shared within the network, functions may be limited.

: Before connecting to a static IP, please verify if it is currently in use by another machine.

: When connecting to a static IP via router or other device, please refer to its user manual and follow IP address / DHCP connection

settings or seek assistance from a specialist.

※ Please refer to the next page for more details.

Network Setting

33 LG Multimedia Player User’s Manual

Connection Status

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Connection Status

Current network connection status will be

displayed.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Network].

Go to [Connection

Status].

Select the option you want and press [OK].

» Setting : Go to [Connection setting] menu.

» Test : Select to test network connection

» OK: Select for conﬁrmation.

(Please refer to previous page [Connection

Setting] chapter.)

※ If the IP address, subnet mask, gateway address, or DNS server in the connection properties screen shows “0.0.0.0”, then proper

connection could not be established.

Please retry connection. If problem persists, please consult your ISP.

Problem may occur when AP is changed. If this is the case : press [HOME] → [Setup] → [Others] → [Initialize] then [OK] to reset

the settings.

※ For more network connection trouble shooting, please refer to the manual or homepage Q&A section.

Network Setting

34 LG Multimedia Player User’s Manual

Device Name

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Access Device Name

Select to change or re-name device name.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Network].

Go to [Device Name].

Change the Device name

and press [OK] for conﬁrmation.

· Default Device name is LG DP1.

Network Setting

35 LG Multimedia Player User’s Manual

Sharing on Network | Auto Login | Clear Login Information

Depending on your PC’s environment, you may need to enter a network user ID and the

password for accessing a shared folder. The network user ID and password will be remembered

after accessing the folder for your convenience. If you do not want the network user ID and

password to be remembered.

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Network].

Go to [Sharing on Network],

[Auto Login] or [Clear Login

Information].

Select option and press [OK]

for conﬁrmation

❖ Disclaimer Notice

For more detail information, please see the [Important information

relating to network services] chapter.

In the menu, select [Disclaimer Notice] and press [OK] to see the

notice.

Others Setting

36 LG Multimedia Player User’s Manual

Menu Language Setting

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Menu Language

Select to choose the OSD (On Screen

Display) language.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Others].

Go to [Menu Language].

· Korean : Select to choose the Korean Language.

· English : Select to choose the English Language.

French, German, Polish, Portuguese, Spanish,

Italian, Dutch, Russian, Turkish, Greek, Chinese,

Japanese are supported.

(Depending on the region, supported GUI

language may change.)

Press [OK] for

conﬁrmation.

Select the menu

language.

Others Setting

37 LG Multimedia Player User’s Manual

DivX VOD

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

DivX Register / Deregister

DivX Register is required to play DivX

formatted (Encoding) video ﬁle.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Others].

Go to [DivX VOD].

For more DivX register and deregister

information, please visit www.divx.com

Press [OK] for

conﬁrmation.

DivX

Others Setting

38 LG Multimedia Player User’s Manual

Power Mode

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Power Mode

Select to change the power mode.

[Power Off] → [Network] → [Check Mode]

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Others].

Go to [Power Mode].

4Select the optional mode and press [OK] for conﬁrmation.

» Power Off : Select [Power Off] to turn off the power directly.

» Network : Select [Network] to turn off the power except

network connection.

» Check Mode : When turn off the power, pop up the selection

massage of [Power Off] and [Network]

Others Setting

39 LG Multimedia Player User’s Manual

Screen Saver

[HOME]

Navigation button

and [OK]

[RETURN]

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Screen Saver

Select to change the time and image of

screen saver.

Press [HOME]. Move to [SETUP]

and press [OK].

Go to next step.

Press [OK]

to go to next step.

Move to [Others].

Go to [Screen Saver].

4Select the optional mode and press [OK] for conﬁrmation.

» Time : Off, 5 Min, 10 Min, 20 Min

» Image : Image 1, Image 2, Image 3

Others Setting

40 LG Multimedia Player User’s Manual

Information | Initialize

Press [HOME] or [RETURN] to exit menu or cancel the selection.

Information

Display the information (Capability, Network

Status, etc) of connected USB Storage

device.

Move to [OTHERS] → [Information], and

press [OK].

· USB Capacity : Display the capacity of USB Storage device

· Network Status : Display network status (Wired or wireless)

· IP Address, MAC Address, Software Version.

Initialize

You can reset the player to its original factory

settings.

Move to [OTHERS] → [Initialize], and press

[OK].

· [Reset] Button on the rear of the unit can reset to its original factory

settings as well. When the device is reset, you will be prompted with

language selection.

· If you reset the player to its original factory settings using [Initialize]

option, you have to set the network settings, all the activations in the

NetCast again.

Others Setting

41 LG Multimedia Player User’s Manual

Software (Firmware Upgrade)

Press [HOME] or [RETURN] to exit menu or cancel the selection.

After extracting the ﬁles downloaded from

the LG homepage. Please verify these ﬁles.

2010xxxxV1.0x

LGE-VerInfo.txt

Please use a USB Storage device. Copy the

ﬁles into the root directory. (ex, D:\, E:\ etc)

The ﬁrmware will not be updated if placed in

a Sub Directory.

After selecting [OTHERS] → [Software] →

[Next]. Press [OK].

* Please wait While the DP1 recognizes the

USB device.

Software

You can update the player using the latest

software to enhance the products operation

and/or add new features. To download the

new ﬁrmware, please visit (www.lg.com or

www.lgservice.com).

The upgrade screen appears.

- If there is upgradable ﬁles, it will start. If not,

you will be prompted with a “No Disk” screen.

- After upgrading, it will automatable reboot.

※ Firmware of an equal version or less can not

be upgrade.

When the device is reset, you will be prompted

with language selection.

After selecting the desired language you will be

able to use the device.

· Do not turn off the power during the software update.

USB Device Connection

42 LG Multimedia Player User’s Manual

USB Device Connection

Playback content in the USB storage

device

In [Home] Menu, choose

[Movie], [Music] or [Photo]

menu and press [OK].

Select [USB1] or [USB2] and

press [OK].

Press [PLAY / PAUSE] after

selecting ﬁle wants to play.

· For more detail information of playing, please

see the [Playing a video ﬁle], [Viewing a Photo

ﬁle] and [Listening to music] chapter.

Insert a USB device to the USB port until it ﬁts

into place.

» File loading may takes few minutes depending

on the number of content stored in the

USB storage device. Press [OK] while [Cancel]

is selected to stop loading.

External Hard

Disk Drive

USB

Drive

Caution)

If an external storage device larger than 2 TB is connected, it may not register. If using this device with NTFS

ﬁle system, a new partition must be created. When splitting the hard drive into partitions, they must be 2TB or smaller.

To create a partition right click [My computer], select [Manage] → [Disk Management], select the drive then select

[New partition]. If your using EXT3 ﬁle system, it will recognize up to 4TB.

Do not remove USB storage during playing contents. For safety removal, go to screen menu and press [EJECT]

USB Device Connection

43 LG Multimedia Player User’s Manual

Caution During Using USB Device

Using USB Device

Compatibility

Caution during using USB device

Note

A USB device which requires additional program installation

when you have connected it to a computer, is not supported.

USB device: USB storage device that supports USB 1.1 and

USB 2.0.

This player supports USB ﬂash memory/external HDD

formatted in FAT16, FAT32 and NTFS when accessing ﬁles

(music, photo,movie).

※ This unit can support up to 4 partitions of the USB device.

Movie, music and photo ﬁles can be played.

※ For details of operations on each ﬁle, refer torelevant pages.

※ Regular back up is recommended to prevent data loss.

※ If you use a USB extension cable, USB HUB or USB

Multi-reader, the USB device may not berecognized.

※ Some USB device may not work with this unit.

※ Digital camera and mobile phone are not supported.

※ USB Port of the unit cannot be connected to PC.

※ The unit cannot be used as a storage device.

File Setting

44 LG Multimedia Player User’s Manual

File Information | File Search

File Information

The player can display the content information.

In [HOME] menu, select

[MOVIE] menu and press [OK].

Select [USB 1] or [USB 2]

and press [OK].

Connect the USB storage device to the player.

File Search

Searching content in the external hard disk drive or USB

Storage device by entering ﬁle name.

1In the folder [Movie, Music or Photo menu], press [SEARCH].

2Select Media type (All, photo, video or music) and then select

Search type (contains or start with).

3Select letters on virtual keyboard and press [OK] to display

the search result.

Select the ﬁle to see the ﬁle

information.

Press [MENU] and select

[Information] sub menu.

Press [OK] to see the ﬁle

information.

File Setting

45 LG Multimedia Player User’s Manual

File Copy

You can copy music, photo, video ﬁle(s) /

folder(s) from USB storage device to another

USB storage device.

· Copying speed may vary depending

on the ﬁle size, number or ﬁles and

network condition.

In [HOME] menu, select [MOVIE]

menu, [PHOTO] or [MUSIC], and

press [OK].

Select the USB storage device you want to

copy and, press [OK].

Connect USB storage devices to corresponding

USB ports of this product.

4Press [Menu] to display the option

menu. Select [COPY] option, and

press [OK] to display the [COPY] Menu.

Select a ﬁle or a folder you wish to copy on

the menu, and press [OK].

Select the destination folder to be copied.

Select [Copy], and press [OK].

Select [OK], and press [OK] to start copying.

(Pop-up window will be shown. To cancel

copying ﬁles, Select [Cancel], and press [OK].)

After completion of copying, press [Return] twice.

File Setting

46 LG Multimedia Player User’s Manual

File Rename

You can re-name a ﬁle (Movie, music and photo) or folder in the USB Storage Device.

In [MOVIE], [MUSIC] or [PHOTO]

Menu, press [MENU] to display the

option menu.

Select [Rename], and press [OK] to

display the virtual keyboard.

Enter a new name using virtual

keyboard.

press [OK] while [OK] in virtual key

board is selected.

» Selected ﬁle or folder name is

changed.

<- : Deletes the previous character at the cursor

position.

Space : Inserts a space at the cursor position.

abc / ABC / #+-=& : Changes the

virtual keyboard setting to capital letters, small

letters or symbols.

File Setting

47 LG Multimedia Player User’s Manual

File Delete

You can delete a ﬁle (Movie, music and photo) or folder in the USB Storage Device.

In [MOVIE], [MUSIC] or [PHOTO]

Menu, press [MENU] to display the

option menu.

Select [Delete], and press [OK].

» [Delete] Menu will be displayed.

Select a ﬁle or a folder you wish to

delete, and press [OK].

» Selected ﬁles or folders will be

shown on the list.

» To select all of ﬁles and folders, press

[OK] while [Select All] is selected.

» To go to upper menu, press [OK] while

[Close] is selected.

Select [Start], and press [OK].

Press [OK] while [YES] is selected.

After completion of deleting,

press [Return].

Playing a Video File

48 LG Multimedia Player User’s Manual

General Playback | Using colored buttons (R, G, Y, B)

General Playback

· To see the ﬁle information (Video codec,

Audio codec, File running time), press

[INFO] after selecting the ﬁle.

You can play various format video ﬁles contained

in a USB Drive and External Hard Disk Drive.

・ Select [Folder], and press [OK] to display contents

in folder. Go to upper folder, Press [∧].

Press [HOME], Select [Movie]

using < / >, and Press [OK].

Select [USB 1] or [USB 2] option using

< / >, and press [OK].

Select a ﬁle using ∧ / ∨ / < / >,

and press [PLAY / PAUSE] to

play the ﬁle.

Using Colored buttons (R, G, Y, B)

Use to navigate guide menus.

They are also used for [MOVIE], [PHOTO], [MUSIC],

[Home Link] and [NetCast] Menu.

Connect USB Drive or External Hard Disk Drive to

Multimedia Player.

Pause

Eject

< A Type >

< B Type >

< C Type >

※ Change the list menu

Press [R] to change the view in [MOVIE], [MUSIC],

[Photo], [Home Link] menu.

Press [PLAY / PAUSE] to play a ﬁle.

Press [PLAY / PAUSE] to pause playing a

ﬁle. Press again to play a ﬁle.

Press [STOP] to stop playing a ﬁle.

» The unit records the point where you pressed

[STOP] depending on the ﬁle. press [PLAY /

PAUSE] to resume playback.

» (from the scene point). Screen Saver : The

screen saver appears when you leave the

player in stop mode.

· The unit records the point where you pressed

[STOP] depending on the ﬁle. press [PLAY /

PAUSE] to resume playback.

· The unit record 20 resume point for each USB

storage drive.

· Resume function does not work properly

depending on ﬁle property.

Removing the USB storage device from

the player without following the safe

removal instruction (Eject)

may cause problem to the stored data

or operation of USB storage device.

EJECT

Playing a Video File

49 LG Multimedia Player User’s Manual

General Playback

Buttons

for Playing

INFORMATION

Playing a Video File

50 LG Multimedia Player User’s Manual

Slow | Fast Forward / Rewind | Fast Forward / Rewind Skip (5 min)

EJECT

Buttons

for Playing

INFORMATION

Slow

To slow down the playing speed.

Fast Forward / Rewind

To scan Fast Forward or Rewind.

Fast Forward / Rewind Skip

Move to 5 minutes (Before / After)

Press [PLAY / PAUSE] to normal speed playback.

Press [PLAY / PAUSE] to normal speed

playback.

While video ﬁle is playing, press [SLOW]

repeatedly to play various speeds of slow

motion.

· Speciﬁc ﬁles including media server may not support some of Fast Forward or Rewind Skip functions.

· Speciﬁc ﬁles including media server may not support some of Fast Forward or Rewind functions.

※ The movie ﬁle running time should be longer than 5 minutes to use this function.

· Depending on the ﬁle properties, actual running speed may differ from displayed speed.

· Speciﬁc ﬁles including media server may not support some of Fast Forward or Rewind functions.

By pressing [Fast Forward] or [Rewind], you can change

the various playback speeds.

During playback, press [>] or [<] to go to the 5 minutes after or before.

Playing a Video File

51 LG Multimedia Player User’s Manual

Previous / Next ﬁle playback | Repeat | Information

Previous / Next ﬁle playback

Play previous / next file.

Repeat Playback

Change repeat function

Information

The player can display the content information.

During playback, press REPEAT repeatedly to

select a desired repeat mode.

To play previous / next ﬁle in the same folder.

(This function is not activated, if only single ﬁle is in the folder.)

During playing ﬁle, press [INFO] to

display the popup message. The ﬁle

information appears on the screen.

To Close popup message, press [OK].

General

Playback

The current ﬁle will

be played back

repeatedly.

The current folder will

be played back

repeatedly.

General

Playback.

Playing a Video File

52 LG Multimedia Player User’s Manual

Enlarge the Playback Video | Time Search

· Enlarge the playback video ﬁle.

· Speciﬁc ﬁles including media server may not support some of Zoom function.

Enlarge the playback video

Zoom in / out during video playing.

Press [ZOOM] to displays or exits the

[Zoom] menu.

Use [R] or [G] to zoom out or in the video.

To return to the normal video size, [Y].

Press [RETURN] to exit the [ZOOM] menu.

You can move through the zoomed video

using ∧ / ∨ / < / >.

· If the Zoom popup menu is activated, other functions cannot

be used. To use other functions,

please press [RETURN] to close the Zoom popup menu.

Time Search

Using time search function, you can easily ﬁnd the point

where you want to start playback

1During Movie playback, press [SEARCH] to see the search time bar.

2Press and hold < / > to select a point what you want to play.

3The movie will be played from the point where you want to start.

(Do not need to press [OK], the movie will be played automatically.)

Playing a Video File

53 LG Multimedia Player User’s Manual

On-Screen Display

· Available items may differ depending on contents

· If no button is pressed for a few seconds, the onscreen display disappears.

Displaying content information on-screen

You can display and adjust various information and settings about the content.

Use ∧ / ∨ / < / > to adjust the selected

option value.

Current chapter number/total number of chapters

Elapsed playing time/total playback time

Selected audio language or channel

Select a TV aspect ratio option. (4:3, 16:9)

Selected subtitle

Sets the Brightness / Contrast level.

Chapter

Time

Audio

TV Aspect Ratio

Subtitle


While playback, press [MENU] to show

various playback information.

Press [MENU] or [RETURN] to exit menu or cancel the selection.

Playing a Video File

54 LG Multimedia Player User’s Manual

Selecting Audio dubbing | Selecting Subtitle ﬁle

· If there is no subtitle mark will be displayed.

· Subtitle may not be displayed properly, depending

on TV aspect ratio or subtitle ﬁle property.

・ If a video ﬁle name and the subtitle ﬁle name are the same, subtitle ﬁle is played automatically

when playing the video ﬁle.

Selecting Audio dubbing

Press AUDIO to change the available audio track of movie.

If there is no dubbing audio track, it is not working.

Or During playing movie, press [AUDIO] to change

the audio.

During playing movie, press [MENU] and select

audio option. Change the audio language you want.

Selecting Subtitle ﬁle

Press SUBTITLE to display/hide the subtitle setting menu.

Or During playing movie, press [SUB] to change

the subtitle language.

During playing movie, press [MENU] and select

subtitle option. Change the subtitle language you

want.

» Text Encoding : Select to choose subtitle encoding.

» Subtitle Size : Select to change subtitle size

» Subtitle Position : Select to change subtitle position.

» Subtitle Color : Select to change subtitle color.

» Subtitle Sync : Select to change subtitle sync.

Playing a Video File

55 LG Multimedia Player User’s Manual

Available resolution size

1920 x 1080 (W x H) pixels

Available File extentions

.dat / .mpg / .mpeg / .avi / .vob / .ts / .mov / .xvid / .mp4 / .mkv / .m2t / .m2ts /

.wmv / .asf / .iso / .m1v / .m2v / .dvr-ms (Unprotected) / .flv / .m1s / .m2p / .ifo / .tp /

.trp / .m4t / .mts

Playable Codec format

MPEG 1 / 2 / 4, DivX 3 / 4 / 5 / 6, Xvid, VC1 (WMV9), MJPEG (SD), H.264, AVC

Playable Audio format

Dolby Digital / DTS : 2 Ch (Down-mix), 5.1 Ch (Pass-through)

PCM, LPCM, ADPCM, BDLPCM, AAC, WMA, WMA Pro, MPEG-1 Layer 1 / 2 / 3

MPEG-2 Layer 1 / 2 / 3, MP3, WAV

» Bit rate : 32 ~ 320 Kbps (MP3), 20 ~ 320 Kbps (WMA)

» Sampling Frequency : 16 ~ 48 KHz (MP3), 32 ~ 48 KHz (WMA)

» Not all the WMA and AAC Audio format is compatible with this unit.

Playable subtitle

SRT, SUB, SMI, SSA, ASS, PGS, Divx Embedded subtitle, MKV Embedded

(SUB, SSA, ASS, SRT)

Note for Video ﬁles

・ Specific files including media server may not be supported.

· This player does not support files that are recorded with GMC or Qpel.

(GMC – Global Motion Compensation, Qpel – Quarter pixel)

· This player supports H.264/MPEG-4 AVC profile Main, High at Level 4.1. For a file with

higher level, the warning message will appear on the screen.

· OGG and FLAC (Audio codec) only support audio files. (Video files are not supported.)

· This product is not support external Blue ray Drive and DVD Drive.

· HD video files contained on the USB 1.0/1.1 may not played properly. USB 2.0 are

recommended to play back HD video files.

· DRM(iTune store, Movielink, etc) is not supported.

Video ﬁles

< A Type >

< B Type >

< C Type >

※ Change the list menu

Press [R] to change the view in [MOVIE], [MUSIC],

[Photo], [Home Link] menu.

Listening to Music File

56 LG Multimedia Player User’s Manual

General Playback

· To see the ﬁle information (Audio codec, Audio

codec, Album title, Musician), press [INFO] after

selecting the ﬁle.

· Select [Folder], and press [OK] to

display contents in folder. Go to upper

folder, Press [Return].

Press [HOME], Select [Music] using

< / >, and Press [OK].

Select [USB1] or [USB2] option using < / >,

and press [OK].

Select a ﬁle using ∧ / ∨ / < / >, and

press [PLAY / PAUSE] to play the ﬁle.

General Playback

The player can play various audio files.

Connect USB Drive or External Hard Disk Drive to

Multimedia Player.

Listening to Music File

57 LG Multimedia Player User’s Manual

General Playback | Fast Forward / Rewind | Repeat Playback

EJECT

Buttons

for Playing

INFORMATION

Pause

Eject

Press [PLAY / PAUSE] to play a ﬁle.

Press [PLAY / PAUSE] to pause playing a ﬁle.

Press again to play a ﬁle.

Press [STOP] to stop playing a ﬁle.

Removing the USB storage device from the

player without following the safe removal

instruction (Eject)

may cause problem to the stored data or

operation of USB storage device.

Fast Forward / Rewind

To scan Fast Forward or Rewind.

· This unit can support the ID3 Tag

embedded MP3 ﬁle.

: Album image, Musician, etc.

· MP3 ﬁles with ID3 Tag including album

image display the album image instead

of note.

By pressing [Fast Forward] or [Rewind],

you can change the various playback speeds.

Repeat playback

Change repeat function

During playback, press REPEAT repeatedly to select a desired repeat mode.

General Playback

The current track or ﬁle will be played back repeatedly.

The current folder will be played back repeatedly.

All the tracks or ﬁles will be played back repeatedly in random order.

The tracks or ﬁles will be played back in random order.

Listening to Music File

58 LG Multimedia Player User’s Manual

Previous / Next ﬁle playback | Information

Previous / Next ﬁle playback

Play previous / next file.

Information

The player can display the content information.

To play previous / next ﬁle in the same folder.

(This function is not activated, if only single

ﬁle is in the folder.)

Select a ﬁle using ∧ / ∨, and press

[OK] to play another music ﬁle.

During playing ﬁle, press [INFO]

to display the popup message.

The ﬁle information appears on

the screen.

To Close popup message, press [OK].

Viewing a Photo File

59 LG Multimedia Player User’s Manual

General Playback

File compatibility

· Available ﬁle extension : .gif .bmp .jpg .jpeg .png

.tif .tiff

· Depending on the size and number of the ﬁles, it

may take several minutes to read the USB storage

drive.

· In [Photo] menu, the photo ﬁle with [?] image is

not supported.

· Recommended size :

- BMP/TIFF/PNG/GIF : Less than 2048 x 2048 pixel

- JPG : Less than 4,096 X 4,096 X 24 bit / pixel

· Animation GIF is not supported.

· Select [Folder], and press [OK] to

display contents in folder. Go to

upper folder, Press [Return].

Press [HOME], Select [Photo]

using < / >, and Press [OK].

Select [USB 1] or [USB 2] option using

< / >, and press [OK].

Select a ﬁle using ∧ / ∨ / < / >, and press

[PLAY / PAUSE] to play the ﬁle.

General Playback

Connect USB Drive or External Hard Disk Drive to

Multimedia Player.

※ Operation of buttons

Moves to the next or previous photo.

Start / pause a slide show.

EJECT

Buttons

for Playing

INFORMATION

Viewing a Photo File

60 LG Multimedia Player User’s Manual

Repeat Playback | Enlarge the Playback Image

Repeat playback

Change repeat function.

During playback, press REPEAT repeatedly to select a desired repeat mode.

Enlarge the playback image

Zoom in / out during photo viewing.

Press [ZOOM] to displays or exits the

[Zoom] menu.

Use [R] or [G] to zoom out or in the image.

To return to the normal image size, [Y].

Press [RETURN] to exit the [ZOOM] menu.

You can move through the zoomed image

using ∧ / ∨ / < / >.

General

Playback

General

Playback

The current folder

will be played

back repeatedly.

All the tracks or

ﬁles will be played

back repeatedly

in random order.

The tracks or ﬁles

will be played back

in random order.

· If the Zoom popup menu is activated, other functions cannot be used. To use other functions,

please press [RETURN] to close the Zoom popup menu.

Viewing a Photo File

61 LG Multimedia Player User’s Manual

On-Screen Display

Select a photo ﬁle you want to view and press

[OK] to see the photo in full screen.

While viewing a photo in full screen, press [MENU]

to display the option menu.

Select an option using ∧ / ∨ and press [OK] to

change options.

※ Option Menu

■ Slide Show : Press [OK] to start or pause slide show.

■ Music Select : Select the background music for the slideshow.

(All of music ﬁles in the same folder will be played.)

Press [BGM] button on the remote control for same function.

Press [REPEAT] button on the remote control to change the repeat playback.

■ Music Start : Press [OK] to start or pause background music.

To start Background music, choose [Music Selection] ﬁrst..

■ Rotate : Press < / > to rotate the photo anticlockwise / clockwise

(or Press [ROTATE] to rotate the photo clockwise.)

■ Zoom/Pan : Press [OK] to display the [Zoom] menu.

■ Effect : select a transition effect between photos in a slide show.

■ scaling : Press < / > to change scaling mode.

(Fit to Screen, Stretch to Screen and Original Size)

■ Speed : select a delaying speed between photos in a slide show.

Playing YouTube Videos

62 LG Multimedia Player User’s Manual

About YouTube Menu

The content of YouTube services and service related information, including user interface, is subject to

changes. Please refer to the web site of each service for most-up-date information.

Using YouTube features with wireless network connection may result in improper streaming speed by

interference from household devices that are using radio frequencies.

· If you select the [Most Viewed] or [Top Rated] option in the YouTube menu, the period options appear

at the bottom of the screen. Use < / > / ∧ / ∨ to select a period option and press [OK] to display the

videos list within the selected period.

· The YouTube menu can display 5 videos in the videos list. Press [PAGE] to display previous / next 5 videos.

· The video list searched from the player may differ with the list searched from a web browser on PC.

In [HOME] Menu, select [NetCast]

Menu, and press [OK].

In [NetCast] Menu, select [YouTube], and

press [OK].

Select the content you want to play, and

press [OK].

About YouTube Menu

You can use YouTube service (Video) via internet with NetCast Entertainment Access

feature. You can browse, search and watch YouTube videos over the internet to your

TV via LG Multimedia Player.

■

Featured : The featured videos list will be displayed.

■

Recent Videos : The most recently updated videos list will be displayed.

■

Most Viewed : The most viewed videos list will be displayed.

The period option appears at the bottom of the screen.

■

Top Rated : The best rated videos list from YouTube server will be

displayed. The period option appears at the bottom of the

screen.

■

My video : Display my video.

■

Favorites : This option will be appeared only when the unit is in sign-in

status. Display the videos list that is arranged in the YouTube

server with your account. Some videos may not appear on the

[Favorites] list, even if the videos are arranged in the server.

■

Playlists : Display playlists.

■

Search : The virtual keyboard will be displayed. See “Searching videos” Chapter.

■

Sign in (Sign out) : Displays the virtual keyboard to sign in or returns to the sign-out status. See “Sign in / Sign out”

Chapter.

■

Local : Choose which country’s videos you would like to view. The countries listed on the [Local Site] menu may

different with those listed on the YouTube web site.

Playing YouTube Videos

63 LG Multimedia Player User’s Manual

Playing YouTube Videos

Even if you use a high-resolution setup, audio / video quality may be compromised based on the speed

of your broadband internet connection. Your Internet Service Provider (ISP) determines your broadband

speed. We recommend a minimum connection speed of 1.5 Mbps. For the best quality picture, a

connection speed of 4.0 Mbps is required. Sometimes your broadband speed varies based on your ISP’s

network conditions. Contact your ISP if you have problems maintaining a fast connection that is reliable,

or if you want to increase your connection speed. Many ISPs offer a variety of broadband speed options.

In [YouTube] menu, use < / > to select a

video and press [OK] or [PLAY / PAUSE].

The Content will be played.

» Video will be played automatically.

(It takes some time to play video)

※ Operation of Buttons

Start playback the video. Press again to pause

current playback. To resume playing a paused

video. Press again.

Skip the playback forward / backward.

(10 seconds)

Toggle between playback in full screen and

playback screen with content detail.

Stop the video and displays related videos list.

Stop the video and go to previous menu.

Playing YouTube Videos

64 LG Multimedia Player User’s Manual

Use < / > / ∧ / ∨ to select a character then

press [OK] to conﬁrm your selection on

the virtual keyboard.

» Refer to previous page for using virtual

keyboard.

When you ﬁnish entering the user name

and the password, select [OK] and press

[OK] to sign in.

» Some of menus will be selected after

Use < / > to select [Sign In] option from the

menu and press [OK] to display the virtual

keyboard.

To Watch videos from your [Favorites] video list on the YouTube server with your

account, you need to sign in with your YouTube account.

If you want to sign out, select the [Sign

Out] from the YouTube menu and press [OK].

» Some of menus will not be selected after

sign out.

Playing YouTube Videos

65 LG Multimedia Player User’s Manual

Searching Videos

In [YouTube] menu, select [Search], and

press [OK] to display the virtual keyboard.

Finish entering the search words.

Select [OK] and press [OK] to display the

related video list.

Searching Photos

Viewing Picasa Web Albums

70 LG Multimedia Player User’s Manual

Adding NetCast friends

If there is no NetCast friend, select [Add to

NetCast Friends List], and press [OK].

» The virtual keyboard will be displayed.

Enter a name / ID using the virtual keyboard

and select [OK], and press [OK] to see the

photo what your friends uploaded.

Select the [NetCast Friends] on the Picasa

menu using < / > / ∧ / < / > / ∧ / ∨, and press

[OK].

Adding NetCast friends

If you add your friends on the [NetCast Friends] menu, you can see the photos of your

friend’s public photos directly.

· To display the [NetCast Friends] List, press [Y]

· If you want to delete your friend from the list, select [X] and

press [OK].

Using the AccuWeather

71 LG Multimedia Player User’s Manual

The content of AccuWeather services and service related information, including user interface, is subject

to changes. Please refer to the web site of each service for most-up-date information.

Using AccuWeather features with wireless network connection may result in improper streaming speed

by interference from household devices that are using radio frequencies.

You can use AccuWeather service (Weather) via internet with NetCast Entertainment

Access feature.

See on-line local and global weather forcasts from AccuWeather.com.

In [HOME] Menu, select [NetCast]

Menu, and press [OK].

In [NetCast] Menu, select [AccuWeather], and

press [OK].

» The city selection menu appears on the screen.

In [Favorite City List], select region, country and

city and press [OK].

Select the [X] symbol and press [OK] to delete

the stored favorite city.

Select a city from the [Favorite City List], and

press [OK] to display the weather information.

Playing content via your home network

72 LG Multimedia Player User’s Manual

About DLNA

This Player is a DLNA Certiﬁed digital media player that can display and play movie, photo and music

content from your DLNA compatible digital media server (PC and Consumer Electronics).

The Digital Living Network Alliance (DLNA) is a cross-industry organization of consumer electronics,

computing industry and mobile device companies. Digital Living provides consumers with easy sharing

of digital media through a wired or wireless network in the home.

When a PC running DLNA server software or other DLNA compatible device is connected to this player,

some setting changes of software or other devices may be required. Please refer to the operating

instructions for the software or device for more information.

The player can browse and play content on your PC and DLNA certified media servers

connected on your home network.

Accessing a DLNA media server

Depending on the media server, this player may need to get permission

from the server.

The playback and operating quality of the [Home Link] function may be

affected by your home network condition.

Playing content via your home network

Please make sure that the PC with shared folder and

network DLNA recognized media server device (PC

software and media server device) are accessible.

After selecting [Home Link] from [HOME] menu, press

[OK]. When connect to a Wi-Fi network connection

and use may not be smooth depending on interference.

After selecting Samba server or DLNA (UPnP) server

from the list, press [OK].

※ If your internal router does not show DLNA or Samba servers on list:

- Referring [Network Status], check to see if you are connected to

DP1 network.

- Check to see if the server you are trying to connect to is connected

to DP1 and AP.

If the server is connected to your ISP via cable and the DP1 is

connected via wireless router then the different subnet mask and

gateway prevents retrieval of server list.

: Connect both via cable to the router.

: When manually connecting to subnet mask and gateway, refer to ISP / device manual.

- UPnP is compatible with Windows Media Player 11 or higher. Make sure ﬁrewall settings have a port open for UPnP.

- Press the green [G] button to refresh server list.

- Depending on network connection status, additions to the server list may require some time. If the server does not appear

ever after waiting, please verify the connection status of the media server and computers containing the shared folder.

- Depending on the management and operating conditions of the computer, the server may not appear.

- The server list may not appear due to ﬁrewall settings. Please consult your network manager.

※Caution

To connect to UPnP Server, current connected AP’s UPnP port should be enable.

To connect to UPnP Server, Windows Media Player 11.0 or later version is required.

Playing content via your home network

73 LG Multimedia Player User’s Manual

Accessing a DLNA media server

・ The UPnP selection screen can differ according to server.

(UPnP is controlled by the server.)

・ CIFS (Common Internet File System)

CIFS is the current standard protocol that allows one computer

to access the system and ﬁles of another. It is able to access

request and command ﬁles through the use of internet

programs.

CIFS ID / Password input

- Depending on the security settings of your shared folder,

ID / PW input may be necessary.

: Normally for home use computer without security settings,

(No user ID / Password) pressing the [OK] button after

entering your ID will bring you to the shared folder menu.

- If your computer is used as a gateway then you may be

prompted for a network ID / Password. Please consult your

network manager.

The selected DLNA (UPnP) server / Shared folder appears

on the screen.

- If your PC doesn’t have the share function selected, after

the “no playable ﬁles” message press the [OK] button to

be taken back to the server list screen.

: For PC sharing options, please refer to “Sharing ﬁles /

folders” on the next page.

Play the desired ﬁle.

- Please refer to “ﬁle compatibility”

- DLNA (UPnP) compatible ﬁles are limited to ﬁles that are

shared and Windows Media Player compatible.

Playing content via your home network

74 LG Multimedia Player User’s Manual

Entering a network user ID and the password

The keyboard menu appears automatically if the network user

ID and the password are required.

The network user ID and password will be remembered after

accessing the folder for your convenience.

Entering a network user ID and the password

Depending on your PC’s environment, you may need to enter a network user ID and

the password for accessing a shared folder.

When you ﬁnish entering the network user ID and password, select

[OK] and press [OK] to access the folder..

In [HOME] menu, select [Home Link] and press [OK].

» Server selection menu will be displayed.

Playing content via your home network

75 LG Multimedia Player User’s Manual

Sharing ﬁles and folders for PC

You may experience connection problems depending on your PC’s environment.

PC requirements

Windows® XP (Service Pack 2 or higher),

Windows Vista® (no Service Pack required)

Windows 7® (no Service Pack required)

1.2 GHz Intel® Pentium® III or AMD

Sempron™ 2200+ processors

Network environment: 100 Mb Ethernet,

WLAN (IEEE 802.11 b/g/n)

If you use Windows® XP or Windows Vista®, visit link below for more information on ﬁle share settings.

Windows XP : http://support.microsoft.com/kb/304040

Windows Vista : http://support.microsoft.com/kb/961498

* Sharing ﬁles on Windows XP

・ To share the folder using UPnP Server, Windows Media Player 11.0 or later version is required.

In [My computer] right click the desired ﬁle

and select properties.

In the [Sharing] tab select [Share this folder

on the network].

If there is an ID / Password error when

logging into CIFS. After sharing the folder,

go to [Start] → [Control Panel] →

[User Accounts] and add a user or reset

the password and try to log in again.

- When resetting the password, please be sure

to reset the [User] or [Guest].

Password and not the [Administrator] password.

Playing content via your home network

76 LG Multimedia Player User’s Manual

Sharing Files and Folders in DLNA (UPnP)

UPnP Installation for PC

In order to share UPnP files / folders an upgraded version of Windows Media Player 11

or higher must be installed.

* UPnP Files and Folders Sharing in XP

After selecting [My Computer] → [My network Places] and click. The LG DP1 icon should appears.

- if the icon does not appear, please refer to [Accessing a DLNA media server].

After opening Windows Media Player, and press right button on the title bar to go to

[Tools] → [Options] → [Library].

Playing content via your home network

77 LG Multimedia Player User’s Manual

Sharing Files and Folders in DLNA (UPnP)

UPnP Installation for PC

After going into [Conﬁgure Sharing] →

[settings], please check [New device and

computer sharing automatically] and then

press [OK].

The LG DP1 should appear as seen in the

picture below.

- If LG DP1 does not appear try restarting

the computer or resend a signal from the

DP1 by selecting the PC Message, the LG

DP1 icon should appear on your computer

screen.

After going into [Library] → [Monitor folders],

please press [OK] to apply DP1 and folder

sharing settings.

- To input additional folders, press [Add] and

select desired locations.

※ If the UPnP and Windows Media Player device are shown on the computer but the UPnP fails to

recognize the PC, check the ﬁrewall settings by going into [My Network Places] → [View network

connections] → [Change Windows Firewall settings] → [Exceptions] tab and verify the UPnP framework

settings. Please consult your network start ICS(Internet Connection Share) due to the changed ﬁrewall

settings, please consult your network manager.

Playing content via your home network

78 LG Multimedia Player User’s Manual

File Compatibility

Overall

・ Available ﬁle extensions differ depending on the DLNA servers.

・ The overall ﬁles are not always compatible. There may have some restrictions

by ﬁle features and media server’s ability.. This function may not work on some [Home Link] content

depending on the ﬁle type and ability of the DLNA server.

・ The thumbnail of the unplayable ﬁles can be displayed in the [My Media] menu, but those cannot be

played on this player.

・ The subtitle ﬁle name and video ﬁle name have to be the same and located at the same folder.

・ Some of functions are not available for NetCast on-line content and content in DLNA servers.

・ Some of functions may not work on some [Home Link] content depending on the ﬁle type and ability of

the DLNA server.

・ The ﬁles from removable media such as USB Storage Drive on your media server may not be shared

properly.

※ Available file extentions

.dat / .mpg / .mpeg / .avi / .vob / .ts / .mov / .xvid / .mp4 / .mkv / .m2t / .m2ts / .wmv /

.asf / .iso / .m1v / .m2v / .dvr-ms(Unprotected) / .flv / .m1s / .m2p / .ifo / .tp / .trp / .m4t / .mts

.wma / .mp3 / .ogg / .flac / .gif / .bmp / .jpg / .jpeg / .png / .tif / .tiff

» Available file extensions differ depending on the DLNA servers.

※ Available resolution size

1920 x 1080 (W x H) pixels

※ Playable video codec format

MPEG 1 / 2 / 4, DivX 3 / 4 / 5 / 6, Xvid, VC1 (WMV9), MJPEG (SD), H.264, AVC

※ Playable audio codec format

Dolby Digital / DTS : 2 Ch (Down-mix), 5.1 Ch (Pass-through)

PCM, LPCM, ADPCM, BDLPCM, AAC, WMA, WMA Pro, MPEG-1 Layer 1 / 2/ 3

MPEG-2 Layer 1 / 2 / 3, MP3, WAV

Bit rate : 32 ~ 320 Kbps (MP3), 20 ~ 320 Kbps (WMA)

Sampling frequency : 16 ~ 48 KHz (MP3), 32 ~ 48 KHz (WMA)

Not all the WMA, AAC Audio format is compatible with this unit.

※ Playable Subtitle

SRT, SUB, SMI, SSA, ASS, vobsub, PGS

※ Audio Codec

WAV, AC3, AAC, WMA, WMAPro, MP3, FLAC

OGG (Sample rate 32 K (Q0) ~ 192 K (Q6),

※ Recommended Photo size

Less than 4,096 X 4,096 X 24bit/pixel

Trouble Shooting

79 LG Multimedia Player User’s Manual

General

You can reset the unit as follows.

1. Press and hold the [POWER] for at least ﬁve seconds.

This will force the unit to power off then turn the unit back on.

2. Unplug the power cord, wait at least ﬁve seconds, and

then plug it in again.

» Press [Reset] button on the rear of the player to reset.

Symptom

The Power does not

turned on.

Cannot play movie,

photo or audio ﬁles.

The remote control

does not work properly.

The unit is plugged in,

but the power will not

turn on or off.

The unit is not operating

normally.

Cause & Solution

Plug the power cord into the wall outlet securely.

The ﬁles are not recorded in a format that the unit

can play.

The unit does not support the codec of the video ﬁle.

The remote control is not pointed at the remote sensor

of the unit.

The remote control is too far from the unit.

There is an obstacle in the path of the remote control

and the unit.

The batteries in the remote control are exhausted.

Trouble Shooting

80 LG Multimedia Player User’s Manual


Symptom

There is no picture.

Picture noise appears

During playing movie,

“Bitstream error”

message is shown.

Cause & Solution

Select the appropriate video input mode on the TV so the

picture from the unit appears on the TV screen.

Connect the video connection securely.

Check the [HDMI Color Setting] in the [Setup] menu is set

to the appropriate item that conforms to your video

connection.

Your TV may not suppot the resolution you have set on

the player. Change the resolution that your TV accepts.

The player’s HDMI OUT jack is connected to a DVI device

that does not support copyright protection.

Sound

Symptom

There is no sound or

the sound is distorted.

Cause & Solution

Connect the audio connection securely.

The input source setting on the ampliﬁer or the connection

to the ampliﬁer is incorrect.

The unit is in scan, slow motion, or pause mode.

The sound volume is low.

Check that the connected ampliﬁer is compatible with audio

format output from the player.

The player’s HDMI OUT jack is connected to a DVI device.

The DVI jack does not accept audio signal.

Check the device connected to player’s HDMI OUT jack is

compatible with audio format output from the player.

You are playing a disc recorded in a color system that is

different from your TV.

Set the resolution which your TV accepts..

In case of display “Bitstream Error” during playing, please

press FF to skip the error section of abnormal ﬁle

before message comes up again. The movie may or may

not play depending on the error severity of ﬁle.

(It may not work depending on the ﬁle.)

Trouble Shooting

81 LG Multimedia Player User’s Manual

Network

The access point or wireless LAN router may not broadcast its

SSID. Set your access point to broadcast its SSID through your

computer.

Symptom

Streaming video services

(such as YouTube™, etc.)

are often stopped or “ buffer”

during playback.

Shared folder or ﬁles from

your PC or a media server

are not displayed on the

[Home Link] menu.

Cannot connect the player to

the access point or wireless

LAN router.

Access point is not displayed

on the “Access point name”

list.

Cause & Solution

Your broadband service speed may not be fast enough to

stream video services. Contact your Internet Service Provider

(ISP) and increase the broadband speed is recommended.

The ﬁrewall or anti-virus software on your media server is

running. Turn off the ﬁrewall or anti-virus software running on

your PC or media server.

The player is not connected to the local area network that your

PC or the media server are connected.

The wireless communication may be interrupted from

household devices that are using radio frequencies.

Move the player away from them.

※ Customer Support

You can update the Player using the latest software to enhance the products operation and/or

add new features. To obtain the latest software for this player (if updates have been made),

please visit http://www.lgservice.com

※ WPS PBC Mode

WPS : Wi-Fi Protect Setup

PBC : Push Button Connect

· Press PBC button on the Access Point / Wireless router to connect to player directly.

(Some of Access Point / Wireless routers do not have the PCB button.)

· First of all, proper wireless network setting is required.

· In the Wireless Network list, Press “Push Button” and the press PCB button on the Access

Point / Wireless router, it will be directly connected in 2 minutes

※ If the product is not working properly, press [Reset] button on the rear of the product to

restore factory default.

Troubleshooting (FAQ)

82 LG Multimedia Player User’s Manual

Network Connection

1. How does you manually connect to the network?

- Please refer to the connection setting directions under network options in the user’s manual.

- Automatic connection is the recommended setting.

2. Network failed to connect.

1) Check to see if the network (wired or wireless) is connected.

2) Check to see if the local network is connected.

3) Network access can be restricted or limited, please check your security options and allow access.

4) In addition, there could be a problem with your AP router.

5) If problem persists, please contact your network service providers.

3. What are the compatible Wi-Fi speeds?

- 802.11 b / g is available in Russia.

- 802.11 b / g / n is available in all others areas.

4. Is the AP plug-n-playable when connecting to it via LAN cable while using a dynamic IP?

- Most ISP use DHCP so when using the AP, it should automatically ﬁnd an IP without having to change any settings.

The AP should be able to function on default settings.

5. The AP does not work after plugging in the LAN cable.

- If your device does not automatically connect to the internet, your ISP might be restarting your MAC address.

If this is the case please refer to the manual for each device or seek assistance from your ISP/network manager



Home Link Guide

1. My PC is connected to a compatible router( wired or wireless),

but the DP1 is not responding.

1) Check to see that the Multimedia player and PC are connected to the same network.

2) Check to see that the router is functioning correctly.

3) To refresh the network, press [G] button in the remote control.

4) Check to see if ﬁrewalls are on.

2. Which OS are supported?

- Windows 7, Windows Vista, Windows XP, MAC and Linux compatible.

3. Where must the PC ﬁles be placed to be seen on DP1?

Is there a designated location?

- There is no designated location but the ﬁles and folders must be accessible and

shared on network.

- It is recommend that ﬁles be kept as close to the directory as possible instead of

being placed within many folders.

4. When connecting to a PC through Home link, is an ID/PW required?

- You should use the ID/PW from your account.

- Depending on user settings, a password may not be required to connect to a network. If

a password is not required, press [OK] button without entering any characters.

5. Home link cannot connect.

- ID/PW was not entered correctly.

- Firewall settings may be turned on.

6. Home link appears connected when using a cable but does not connect

through Wi-Fi.

- When using AP in both cable and Wi-Fi connections, be sure the Gateway information

is correct. If Home link and PC are not using the same Gateway, then the PC may not appear

on Home link. If possible, it is recommended that both the PC and DP1 are connected by cable.

7. What do I do if either device(DP1, PC, Media device) does not recognize each other?

-Your UPnP port may be restricted by ﬁrewall protection, If this is the case please consult your network manager.

IMPORTANT INFORMATION RELATING

TO NETWORK SERVICES

83 LG Multimedia Player User’s Manual

IMPORTANT INFORMATION RELATING TO NETWORK SERVICES

PLEASE READ CAREFULLY. USE OF THE NETWORK SERVICES IS SUBJECT TO THE FOLLOWING

TERMS AND CONDITIONS.

Use of the Network Services requires an Internet connection which is sold separately and for which you

are solely responsible. The Network Services may be limited or restricted depending upon the quality,

capabilities and technical limitations of your Internet service.

The Network Services belong to third parties and may be protected by copyright, patent, trademark

and/or other intellectual property laws. The Network Services are provided solely for your personal and

noncommercial use. Unless expressly authorized by the respective content owner or service provider,

you shall not modify, copy, republish, upload, post, transmit, translate, sell, create derivative works,

exploit, or distribute in any manner or medium any content or services accessible through this product.

LG IS NOT RESPONSIBLE FOR YOUR USE OF THE NETWORK SERVICES. THE NETWORK

SERVICES ARE PROVIDED “AS IS.” TO THE FULLEST EXTENT PERMISSIBLE BY LAW, LG MAKES

NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WHATSOEVER (i) FOR THE ACCURACY,

VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY NETWORK SERVICE MADE

AVAILABLE THROUGH THIS PRODUCT; OR (ii) THAT THE NETWORK SERVICES ARE FREE OF

VIRUSES OR OTHER COMPONENTS THAT MAY INFECT, HARM, OR CAUSE DAMAGE TO THIS

PRODUCT, YOUR COMPUTER, TELEVISION, OTHER EQUIPMENT, OR ANY OTHER PROPERTY. LG

EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO,

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL THEORY, WHETHER IN CONTRACT, TORT,

STRICT LIABILITY OR OTHERWISE, SHALL LG BE LIABLE TO YOU OR ANY THIRD PARTY

FOR ANY DIRECT, INDIRECT, INCICENTAL, SPECIAL, STATUTORY, CONSEQUENTIAL OR OTHER

DAMAGES OR ATTORNEY FEES OR EXPENSES RELATING TO OR ARISING OUT OF THE

NETWORK SERVICES EVEN IF ADVISED OF THE POSSIBLITY OF SUCH DAMAGES OR IF SUCH

DAMAGES COULD HAVE BEEN REASONABLY FORESEEN.

The Network Services may be terminated or interrupted at any time, and LG makes no representation

or warranty that any Network Service will remain available for any period of time. Use of the Network

Services may be subject to additional terms and conditions of the respective third party service

provider. The Network Services are transmitted by third parties by means of networks and

transmission facilities over which LG has no control. LG EXPRESSLY DISCLAIMS ANY

RESPONSIBILITY OR LIABILITY FOR ANY INTERRUPTION OR SUSPENSION OF ANY NETWORK

SERVICE.

LG shall be neither responsible nor liable for customer service related to the Network Services. Any

question or request should be made directly to the respective Network Service providers.

“Network Service(s)” means the third party services accessible through this product including but

not limited to all data, software, links, messages, video and other content found thereon or used in

connection therewith.

“LG” means LG Electronics, Inc. its parent company and all of their respective subsidiaries, affiliates

and related companies worldwide.

Trademarks and Licenses

84 LG Multimedia Player User’s Manual

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674;

5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents

issued & pending. DTS and the Symbol are registered trademarks, &

DTS 2.0+ Digital Out and the DTS logos are trademarks of DTS, Inc.

HDMI, the HDMI logo and High-Definition Multimedia Interface are

trademarks or registered trademarks of HDMI licensing LLC.

DLNA®, the DLNA Logo and DLNA CERTIFIED® are trademarks, service

marks, or certification marks of the Digital Living Network Alliance.

The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc.

This is an official DivX Certified device that plays DivX video. Visit

www.divx.com for more information and software tools to convert your files

into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be

registered in order to play DivX Video-on-Demand (VOD) content.

To generate the registration code, locate the DivX VOD section in the

device setup menu. Go to vod.divx.com with this

code to complete the registration process and learn more about DivX VOD.

YouTube™ is a trademark of Google Inc.

Picasa™ Web Albums is a trademark of Google Inc.

85 LG Multimedia Player User’s Manual

FCC Regulation

U.S.A.

U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE

STATEMENT INFORMATION TO THE USER

NOTE : This equipment has been tested and founded to comply with the limits for a Class B digital

device pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular Installation.

If this equipment dose cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encourage to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet of a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for assistance.

Changes or modification not expressly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

Connecting of peripherals requires the use of grounded shielded signal cables.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum 20 cm betwe the radiator and your body.

This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC.

Specification

86 LG Multimedia Player User’s Manual

- Dolby Digital (AC3) / DTS : 2 ch (Down-mix), 5.1 ch (Pass-through)

- OGG : Audio ﬁle only, Sample rate 32 K (Q0) to 192 K (Q2)

- LPCM : Video ﬁle only

- FLV : H.264 codec only

- This product may not support ﬁle formats other than the formats speciﬁed above

- Premium contents DRM is not supported. (iTunes store, Movielink, etc.)

File extension Codec

dat, mpg, mpeg, avi, vob, ts, mov, xvid,

mp4, mkv, m2t, m2ts, wmv, asf, iso, divx,

m1v, m2v, m4v, dvr-ms (Unprotected),

flv, m1s, m2p, ifo, tp, trp, m4t, mts

MPEG 1 / 2 / 4, DivX 3 / 4 / 5 / 6,

VC1 (WMV9), H.264, MJpeg (SD), AVC

mp3, wma, wav, ogg, aac, m4a, flac,

mka, ape, aif, aiff, mp1, mp2, ac3, mpa,

mp4a

GIF, BMP, JPEG, TIF / TIFF, PNG

SRT, SUB, SMI, SSA, ASS, VOBSUB (IDX + SUB), PGS

English, Korean, Arabic, Chinese, Simplified-Chinese, Dutch, French, German, Greek,

Hungarian, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Turkish

CGMS-A, HDCP

MP3, WAV / PCM / LPCM / ADPCM /

BLDPCM, AAC, FLAC, DTS, WMA, OGG,

Dolby Digital (AC3), AIF / AIFF, APE, WMA Pro,

MPEG-1 Layer 1 / 2 / 3, MPEG-2 Layer 1 / 2 / 3

Format

Audio

Video


Subtitle

Language

DRM

ver.1.5 DMP (Digital Multimedia Players)

AccuWeather, etc.

DLNA

Internet Service

802.11 b / g / n (Russia : 802.11 b / g)

Built-in (DP1W Mncdknmkx(

Wi-Fi

10 / 100 Mbps

Ethernet

Antenna

DP1B Model : Wi-Fi dongle is required for Wireless network connection.

Depending on the region, some of the Wi-Fi service can be limited.

(Ex. Russia region)

File information

Network speciﬁcation

DC input

Composite Out

Digital Audio Out

HDMI Out

USB

Power

Dimension

Product Weight

Humidity (Storage)

Humidity (Operation)

Storage Temperature

Operating Temperature

❖ Product Spec

2 EA (Host)

265 (W) x 88 (H) x 26 (T) mm

DC 12 V / 2 A

336.6 g

1 EA

1 EA (Optical type)

1 EA (Phonejack type)

1 EA (1.3a)

❖ Physical & Environmental

5 ~ 95 %

Non-Condensation

- 20 ~ 60 ŭ

20 ~ 80 % Non-Condensation

0 ~ 35 ŭ

Caution)

If an external storage device larger than 2 TB is connected, it may not register. If using this device with NTFS

ﬁle system, a new partition must be created. When splitting the hard drive into partitions, they must be 2TB or smaller.

To create a partition right click [My computer], select [Manage] → [Disk Management], select the drive then select

[New partition]. If your using EXT3 ﬁle system, it will recognize up to 4TB.

LG Service Site

87 LG Multimedia Player User’s Manual

LG Service Site

88 LG Multimedia Player User’s Manual

LG Service Site

LG ELECTRONICS DP1W0702 Portable Theater Wi-Fi User Manual PA710MDLSB ATT C E G H I J

LG Electronics Inc. Portable Theater Wi-Fi PA710MDLSB ATT C E G H I J

user manual

Navigation menu

Namespaces

Views

Navigation
