LG ELECTRONICS LGI3000W Single-Band PCS CDMA Phone User Manual Rainbow spec1 phone
LG Electronics, Inc. Single-Band PCS CDMA Phone Rainbow spec1 phone
Users Manual
![](/img.php?id=84303&img=bg1.png)
1
LGI - 3000W Users Manual
LG Information & Communications, Ltd.
1 Product Features
Light Weight, Compact, Solid Design
Low Cost Smartphone
Easy to Use
• Voice Activated Dialing
• Large Graphic LCD Display with Touch Panel
- 160 X 240(dots)
- Partial Display in Phone Mode
- Virtual Keyboard for Easy Entry
- Backlight for High Visibility
• Intuitive and Easy-to-use Phonebook,Large Screen Call Log
• Scheduler(Datebook) with Alarms.
• Various useful PIMs : Phonebook, Datebook, Todo List, Memo, Sketch, World Clock, Calculator, …
• Speaker Phone Capability(0.3W Max)
Support Data Communication
• Phone.com Browser
• Text Message, E-Mail
• PC Connectivity-Compatible with the Microsoft Outlook,Scheduler+
![](/img.php?id=84303&img=bg2.png)
i
FCC RF EXPOSURE INFORMATION
In August 1996 the Federal Communications Commission (FCC) of the United States
with its action in Report and Order FCC 96-326 adopted an updated safety standard for
human exposure to radio frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The design of this
phone complies with the FCC guidelines and these international standards.
Use only the supplied or an approved antenna. Unauthorized antennas, modifications,
or attachments could impair call quality, damage the phone, or result in violation of
FCC regulations.
Do not use the phone with a damaged antenna. If a damaged antenna comes into
contact with the skin, a minor burn may result. Please contact your local dealer for
replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with the back of the phone kept
0.79 inches (2 cm) from the body. To comply with FCC RF exposure requirements, a
minimum separation distance of 0.79 inches (2 cm) must be maintained between the
user’s body and the back of the phone, including the antenna, whether extended or
retracted. Third-party belt-clips, holsters and similar accessories containing metallic
components should not be used. Body-worn accessories that cannot maintain 0.79
inch (2 cm) separation distance between the user’s body and the back of the phone,
and have not been tested for typical body-worn operations may not comply with FCC
RF exposure limits and should be avoided.
Vehicle Mounted External Antenna (optional, if available.)
A minimum separation distance of 7.9 inches (20 cm) must be maintained between the
user/bystander and the vehicle mounted external antenna to satisfy FCC RF exposure
requirements.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
WARNING! Read this information before using your phone
![](/img.php?id=84303&img=bg3.png)
2
Specification
Size FlipUp type : 135 * 56.5 * 25mm
Button / Dial Key pad : 12 keys
Connector 4 function keys, cursor key, Backlight/Power On-Off
Button : Volume up/down
Jack : Headset jack
ICA/SIO jack
Connector : for External device
Contact : for Charger
Weight TBD
LCD Resolution : 160 * 240
Module Dot Pitch : 0.25mm
Graphic LCD with Backlight
Size : Full Active size : 40* 60mm , Partial Active size : 40 * 27.5mm
Module size : 50.5*70.65mm(min)
Touch Panel Size : 50.3 * 70.3
Battery 3.6V Li-ion 1 cell / 1300 mAH
Cell Size : 9 * 34 * 48mm
3 Hours Talk (@+10dBm, 45 % rate, standard batt.)
100 hours Stand-by Time (@2.56s slot mode 2, standard)
2 Product Specifications
3 Design Rendering
![](/img.php?id=84303&img=bg4.png)
3
CLR
OK
END
PWR
1 2 3
4 5 6
7 8 9
*0 #
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
OPER
LGIC
Phone Mode(Flip Closed)
Volume Control
Adjust the sound level,
both voice(during a call)
and ringer(when in standby)
OK
Select highlighted menu item
(Place a call, Receive a call, etc.) CLR
Clear user input and
Back to the previous menu
Up/Down
navigate
throughout
the menu
Message button
Headset Jack
BackLight
4 Description
Menu Area
Banner Area
Status Icon Area
ICON DESCRIPTION
Signal Strength Indicator
No Service
Roaming
New page/text messages
New voicemail
Vibrator Indicator
Battery Charge Status
Display Icons
Phone Mode LCD Display
Basic Display Format
3 line
3 line
144 dot
20 dot
48 dot
(16 dot/line)
42 dot
(14 dot/line)
110 dot
![](/img.php?id=84303&img=bg5.png)
4
CLR
OK
END
PWR
Apr.23 12:35A
PIM Mode(Flip Opened)
Contrast Control
Adjust the Contrast level
Flip
Touch Panel
touch with
stylus pen or finger
Stylus pen
touch icons,
input keyboard,
draw line, etc.
Go to select application
3:46p
Status Bar
Always display in the top of the screen
current time BatteryRSSI
All
Home All
PIMs
Communication
5 UI Specification
![](/img.php?id=84303&img=bg6.png)
5
Initial Screen
1. Turning the Power On
Call History
Messages
Phone Book
LGI-3000W
2:23p Mar 18, (Th)
Unlock
Call 911
LGI-3000W
2:23p Mar 18, (Th)
--Locked-- *Power Save*
No Service available
Press any key to exit.
No System found
within 15 minutes
Phone Mode (Flip Closed)
Security
Setup
Phone Off
Phone On
[PWR] Press & Hold O.K
Call History
Messages
Phone Book
Searching for
Service
Sprint PCS
Handset locked
System
found?
yes
No
System Found
User can abort animation
by pressing any key
Trade Mark Tone
2.2 Phone Power Off
O.K
Phone is Off,
while System Power
is still On.
Security
Setup
Phone Off
LGI-3000W
2:20p Mar 18, (Th)
2. Power Off
2.1 System Power Off
- Battery out or [PWR] press & hold in standby state
Phone Mode (Flip Closed)
Initial Screen (continued)
Sprint PCS
Powering Off Good-Bye!
System
Power
Off
3 Sec
Trade Mark Tone
NV Write
Application Close
Beep
Beep
Security
Setup
Phone Off
Phone On
![](/img.php?id=84303&img=bg7.png)
6
3. Standby State
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Default Standby State
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Different size font for
status indicator
-Ringer Off- Call History
Messages
Phone Book
Digital Roam
-Ringer Off-
Digital Roam flashing
Unlock
Call 911
LGI-3000W
2:23p Mar 18, (Th)
--Locked--
Locked State
*KeyGuard*
To disable, hold
the clear key
LGI-3000W
2:29p Mar 18, (Th)
KeyGuard State Power Save State
Call History
Messages
Phone Book
* Car Kit*
2:29p Mar 18, (Th)
Only in Car-kit mode and
auto-answer is enabled
-Auto Answer-
Initial Screen (continued)
Unlock
Call 911
Digital Roam
-Locked-
Locked State
(Digital Roam blinking)
Main Menu
Items
Customer Care
Customer Care
H Joe Roberts
032-456-2345l
O Charley Brown
Missed Calls
Missed Call Notification
during standby state
Phone Book
MiniBrowser
Environment
Sounds
Display
Security
Setup
KeyGuard
PC Sync
Phone Off
Messages
Call History
Phone Mode (Flip Closed)
Call History
Messages
Phone Book
*Headset*
2:29p Mar 18, (Th)
-Auto Answer-
Only in headset mode and
auto-answer is enabled
*Power Save*
No Service available
Press any key to exit.
Call Origination
Phone Mode (Flip Closed)
OK
1. 1-Digit Input
2 Sec. Pause
Exit
Jump to speed dial entry #2
Dial the number in phonebook entry #2
Hard Pause
02: M Aaron
Find
2OK
Jump to “Find Number” in phonebook menu
M Aaron
H Seo
O Jung
2
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Default Standby State
Go to Inuse state
End Call
M 310-234-5090
Aaron
Connecting...
Speed Dial #2
Call
Prepend
Aaron
M 310-234-5090
Edit
Find
02: M Aaron
Hard Pause
2
OK
Press & Hold
Speaker On
![](/img.php?id=84303&img=bg8.png)
7
Call Origination (continued)
Phone Mode (Flip Closed)
2. 4-Digit Input
Find
Hard Pause
2Sec. Pause
Exit
OK
4-Digit Dial
Call
Save
6595
H Brian
O Julia Huffman
6595
OK
If there are more than two phone numbers of “6595” in phone book.
Call
4-Digit Dial
Save
6595 OK
End Call
H 619-892-6595
Brian
Connecting...
End Call
6595
Connecting...
One match
End Call
816-559-6595
Abbre. Dialing
Connecting...
- No Phonebook Match
- Abbreviate Dial to prefix
that set in
setup->abbre. dialing
Only one match in phonebook
Speaker On
Speaker On
Speaker On
Speaker On
Call Origination (continued)
Phone Mode (Flip Closed)
3. Others
Hard Pause
2 Sec. Pause
Exit
OK
Call
Save
Find
619-123-4567
4. Dynamic Numeric Character Sizing
Call
Find
Hard Pause
312-345-6789
Call
Find
Hard Pause
312-345-67890123
456
When the number entered less than or
equal to 10 digits, the larger font are used When the number entered more than 10 digits,
the smaller font are used
Go to Inuse State
End Call
619-123-4567
Connecting...
Hyphenation follows
NANP and if “0” or
“1” is the first digit,
it will be
hyphenated in the
form 0-123-456-
7890
Hyphenation follows
NANP and if “0” or
“1” is the first digit,
it will be
hyphenated in the
form 0-123-456-
7890
![](/img.php?id=84303&img=bg9.png)
8
Speaker On
Call Origination (continued)
Phone Mode (Flip Closed)
5. Voice Dialing
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Default Standby State
Exit
User speaks
the programmed
name
OK or CLR or
Mouse Key, or
Timeout(5 Secs)
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Go back to default standby state
Any Keypad
Go to the dialing state
End Call
H 310-234-5090
Aaron
Connecting...
Find
02: M Aaron
Hard Pause
2
If hot key is set to Voice Dial
Left Rocker
Voice Prompt:
handset should
repeat the name
of the found voice
dial entry.
Voice Prompt:
handset should
repeat the name
of the found voice
dial entry.
“Who would you like to call?”
or
“Name Please” “Connecting <Name>”
Speaker On
Call Origination (continued)
Phone Mode (Flip Closed)
Call
Save
Find
619-123-4567p36
3t1111
End Call
619-123-4567
Connecting...
6. Continue Dialing after Pause
Send Tones
End Call
Speaker On
Sprint: 00:00:06
619-123-4567
p363t1111
End Call
Speaker On
Mute
Sprint: 00:00:06
619-123-4567
OK
OK
connected
![](/img.php?id=84303&img=bga.png)
9
Phone Mode (Flip Closed)
Incoming Call / In use / End Call
1. Incoming Call
Answer
Silent Ringer
Call From:
Cindy
H 714-870-8842
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th) Incoming
Call
Answer
Silent Ringer
Answer(Speaker On)
Call From:
Cindy
H 714-870-8842 Answer
Call From:
Cindy
H 714-870-8842
End Call
Speaker On
Sprint: 00:00:25
Cindy
H 714-870-8842
Mute
[CLR], [END] or [vol] keys pressed to
mute ringer temporary
OK
Default Stand-By State
(Incoming Call also occurs
when handset not in stand-by state)
CLR or Volume
Keys pressed to
mute ringer
temporally
OK
Down Rocker
Answer(Speaker On)
Answer(Speaker On)
OK
2. In Use State
Phone Mode (Flip Closed)
Incoming Call / In use / End Call (continued)
Unmute
Mute: 00:00:25
Cindy
H 714-870-8842
Toggle mute
and unmute
Call Waiting State(Call Waiting Blinks)
same menu options in Roaming
Flash
End Call
Call Waiting :
Kathy Zoe
O 913-398-2234
Speaker On End Call
Speaker On
Roam: 00:00:25
Cindy
H 714-870-8842
Mute
Default In Use State(ROAM Blinks)
End Call
Mute
End Call
Sprint: 00:00:25
Cindy
H 714-870-8842
Speaker On
2.1. Default Inuse State
2.2. Call Waiting State 2.3. Roam State
3-Way Call
Call History
Messages
Phone Book
Environment
Display
End Call
Speaker On
Sprint: 00:00:25
Cindy
H 714-870-8842
Mute
3-way call may not be
applicable in roaming,
especially analog
roaming. The menu
option “ Flash” will be
used instead
3-way call may not be
applicable in roaming,
especially analog
roaming. The menu
option “ Flash” will be
used instead
Speaker On
Unmute
Sprint: 00:00:25
Cindy
*Speaker Phone*
Toggle
Speaker Phone
Mode End Call
Mute
End Call
Sprint: 00:00:25
Cindy
H 714-870-8842
Speaker On Speaker Off
![](/img.php?id=84303&img=bgb.png)
10
Phone Mode (Flip Closed)
Incoming Call / In use / End Call (continued)
2.4. 3-Way Call
2. In Use State
3-Way Call
Mute
Sprint: 00:00:25
Cindy
H 714-870-8842
Speaker On
While Inuse state, highlight “3-Way Call”
and press OK
OK
Call
Save
Find
619-570-4567
Dial the second number, highlight
“Call” and press OK
OK
Flash
End Call
Sprint: 00:00:45
Brown
M 619-570-4567
Mute
3-Way Call
Alternate #
Time/Date
Outgoing Calls#1
Brown
M 619-570-4567
View Details
3-Way Call
Extract Phone #
Messages From:
Brown
M 619-570-4567
3-Way Call
H 332-456-2345l
Call Alarm
[Business]
Brown
M 310-234-5090
From Messages From Phone Book
3. End Call & Post-Call Number Storage
End Call
Speaker On
Sprint: 00:00:25
Joe Roberts
H 714-870-8842
Mute
OK
Call
Sprint: 00:00:25
Joe Roberts
H 714-870-8842
Alternate #s
End Call
Speaker On
Sprint: 00:00:25
714-870-8842
Mute
OK
Call
Sprint: 00:00:25
714-870-8842
Save
Call
H 032-456-2345
Call Alarm
[Business]
Joe Roberts
M 310-234-5090
No Phone Book Match
Phone Book Match
display times out in 10 seconds
Home
Work
Select Label :
Mobile
714-870-8842
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Call
Save Phone #
Phone Mode (Flip Closed)
Incoming Call / In use / End Call (continued)
OK
OR
END
OK
OK OK
End Call
714-870-8842
Connecting...
Scroll down 2 items
Speaker On
![](/img.php?id=84303&img=bgc.png)
11
Phone Mode (Flip Closed)
Incoming Call / In use / End Call (continued)
3.1 Incoming Roaming Call
Call History
Messages
Phone Book
Digital Roam
Call Guard
Answer
Answer(Speaker On)
Roam Call From:
Cindy
H 714-870-8842
[OK]
[OK] OK
Roaming rate
applies. Select
Answer to accept End Call
Speaker On
Roam: 00:00:25
Cindy
H 714-870-8842
Mute
“Answer”
3.1 Outgoing Roaming Call
Call History
Messages
Phone Book
Digital Roam [OK]
[OK] OK
Roaming rate
applies. Select
Roam Call to call End Call
Speaker On
Roam: 00:00:25
619-123-4567
Mute
“Roam Call”
Roam Call
Call Guard
Save
619-123-4567
In case that “Setup:Roaming:Call Guard” is “yes”.
Call Guard menu is visible
Ringer lowered in volume when “Call Guard” is selected.
Beep
Phone Mode (Flip Closed)
Missed Call Notification
Answer
Answer(Speaker On)
Sprint: 00:00:25
Joe Roberts
H 714-870-8842 H Joe Roberts
If network terminates
incoming call Call
Alternate #s
Time/Date
Missed Calls #1
Joe Roberts
H 714-870-8842
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
-Missed Calls-
Unlock
Call 911
LGI-3000W
2:23p Mar 18, (Th)
--Locked--
Correct Lock
Code Entered
*KeyGuard*
To disable, hold
the clear key
LGI-3000W
2:29p Mar 18, (Th)
Missed Calls KeyGuard disabled
H Seo
O Jung
Missed Calls OK
CLR
Press and hold CLR
Silent Ringer
![](/img.php?id=84303&img=bgd.png)
12
Locked State
Unlock
Call 911
LGI-3000W
2:23p Mar 18, (Th)
--Locked-- Exit
Lock Code :
* * _ _
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
Invalid
Lock Code
Call
Find
Hard Pause
714-870-8842 Emergency #
or Special #
Calls Only Unlock
Call 911
LGI-3000W
2:23p Mar 18, (Th)
--Locked--
Number Entry
If entered # is not
a special #
If entered # is
a special #
Correct Lock Code
Lock code entered incorrectly
Phone Mode (Flip Closed)
OK
End Call
714-870-8842
Connecting...
Speaker On
Menu
Items
Phone Mode (Flip Closed)
Main Menu
Call History
Messages
Phone Book
LGI-3000W
12:20p Mar 18 (We) Call History
Messages
Phone Book
MiniBrowser
Environment
Sounds
Display
Security
Setup
KeyGuard
PC Sync
Phone Off
![](/img.php?id=84303&img=bge.png)
13
Phone Mode (Flip Closed)
Menu Structures
Fax/Data In
Roaming
Any Key Answer
MiniBrowser
Hot Key
Car Kit
Speaker Phone
Abbre. Dialing
8. Security
Lock Phone
Change Lock
Edit Special #s
Erase Phone Book
Phone Reset
9. Setup
1. Call
History
Outgoing Calls
Incoming Calls
Missed Calls
Air Time(Voice Calls, MiniBrowser,
Data/Fax, Roam Calls)
Erase Calls
Call
Save Phone#/Alternate #
Time/Date
Prepend
Erase
Next
Previous
Outgoing Calls
Incoming Calls
Missed Calls
All Calls
3. Phone
Book
Look up Name
Find Speed Dial(Call, Prepend, Edit(Phone #, Name), Erase, Next, Previous, Exit)
Add New Entry(Name,Phone#)
Voice Dial Entry(Play, Erase, Next, Previous, Exit)
My Phone #
Services(Customer Care, etc)
2. Messages
Voicemail
Page/Text
MiniBrowser
<Folder1>
..
Edit Folder
Erase All
Call Voicemail
Read Message(In case VMN/SMS)
Clear Count
Exit View Detail
Call
Extract Phone #
Add Folder
Next
Previous
Erase
5. Environment
6. Sounds
Volume
Ringer Type
Tone Length
Alert
Ringer
Key Beep
Speaker
Service Change
Minute Beep
7. Display
Backlight
Greeting(Keep, Change)
Contrast
Version(S/W, PRL)
Call
Call Alarm
Add Phone #
Set Voice Dial
Set Speed Dial
Set ID Ringer
Prepend
Edit
Erase Entry
Next
Previous
Voice
Calls
Messages
Alarms
Phone #
Name
Category
Make Secret
W/ caller ID
Restricted Caller ID
No caller ID
Roaming
4. MiniBrowser
11. PC Sync
Voicemail
Page/Text
MiniBrowser
12. Phone On/Off
10. KeyGuard
Normal
Meeting
…
Edit
<Messages>
Erase All
Exit
<Folder1>
..
New Folder
Exit
Label
Keyword
# of msgs
Ringer Type
Erase Folder
Exit
Air Time
Erase Calls
Menu : Call History
Call History
Messages
Phone Book
LGI-3000W
Prepend
Erase
Next
Previous
OK OK
Incoming Calls
Call
Alternate #
Time/Date
Outgoing Calls#1
Joe Roberts
H 019-229-4040
OK
H 019-229-4040
3:15p Feb 25(Th)
1min 55 sec.
“Alternate #” appears only if
there is more than 1 phone#s
in phonebook entry
Right Arrow Key Entered
Or Next Selected should scroll to next entry
Call
Save
Time/Date
Outgoing Calls#2
H 032-456-2345
OK
12:20p Mar 18 (We) Call History
Outgoing Calls
Missed Calls
H Joe Roberts
032-456-2345
O Seo
Outgoing Calls
End Call
H 019-229-4040
Joe Roberts
Connecting...
Phone Mode (Flip Closed)
OK
Time/Date
Alternate #
Speaker On
![](/img.php?id=84303&img=bgf.png)
14
Menu : Call History(Continued)
OK
Incoming Calls
Call
Alternate #
Time/Date
Missed Calls#1
Joe Roberts
H 019-229-4040
“Alternate #” appears only if
there is more than 1 phone#s
in phonebook entry
OK
Call History
Outgoing Calls
Missed Calls
* H Joe Roberts
* H Kim
* O Jang
Missed Calls
End Call
H 019-229-4040
Joe Roberts
Sprint: 00:01:23
Phone Mode (Flip Closed)
Add “Return Call” Statue to Missed Call
Speaker On
Mute
H Joe Roberts
* H Kim
* O Jang
Missed Calls
Icon : return call = TRUE
(If an incoming or outgoing number matches
that missed number)
* : Missed Calls not returned
H Joe Roberts
H Seo
O J Lee
Outgoing Calls
Joe Roberts added to
outgoing calls Joe Roberts in missed
calls has check mark
If an incoming or outgoing number
that matches the number in
missed calls, put a check mark
before the number or name.
If an incoming or outgoing number
that matches the number in
missed calls, put a check mark
before the number or name.
Menu : Call History (continued)
OK
OK OK
OK OK
Call History
Messages
Phone Book
LGI-3000W
Data/Fax
OK
Yes
No
Erase Outgoing?
12:20p Mar 18 (We)
Incoming Calls
Call History
Air Time
Missed Calls
Air Time
Voice Calls
MiniBrowser
Missed Calls
Call History
Erase Calls
Air Time Missed Calls
Erase Calls
Outgoing Calls
Incoming Calls
Erase All
Phone Mode (Flip Closed)
OK
Reset
Total Voice Calls
02:03:12
52 Calls
Not intended
for billing purpose
2 sec
Roam Calls
![](/img.php?id=84303&img=bg10.png)
15
Edit Folder
Erase All
Menu : Messages-Voicemail
OKOK OK
Call History
Messages
Phone Book
LGI-3000W
12:20p Mar 18 (We)
MiniBrowser
Messages
Voicemail
Page/Text End Call
Voicemail
Connecting...
Phone Mode (Flip Closed)
10 New Voicemail
2 new Page/Text
If there are new messages
*New*
Voicemail
12:10p Mar 18(We)
10 New Messages
---------------------
Press[OK] for
message option
*New*
Voicemail
12:10p Mar 18(We)
---------------------
Press[OK] for
message option
VMN/SMS Notification
MWI Notification
Call Voicemail
Read Message
Clear Count
Voicemail
12:10p Mar 18(We)
10 New Messages
[Read
Message]
OK
Call Voicemail
Clear Count
Exit
Voicemail
12:10p Mar 18(We)
New Messages
[CLR]
Go to previous state
[CLR]
Go to
previous
state
Voicemail
12:10p Mar 18(We)
10 New Messages
---------------------
Press[OK] for
message option
OK
[EXIT]
Speaker On
Menu : Messages -Page/Text
OK
OK
Call History
Messages
Phone Book
LGI-3000W
12:20p Mar 17 (We)
12:27p Mar 17(We)
Please call me
at 213-456-3344
Need to talk
--------------------
Messages From:
View Details
Call
Extract Phone #
12:27p Mar 18(We)
Please call me
At 213-456-3344
* Hi, Call me ...
* 213-456-4566
* Call Boss
OK Page / Text
3 New
7 Old
SMS Notification
OK
at 213-456-3344
Need to talk.
---------------------
Messages From:
Wonjung Seo
M 213-456-3344
->old message
MiniBrowser
Messages
Page/Text
Voicemail
Icon - * : new
check mark : read
! : urgent
Messages From:
Wonjung Seo
M 213-456-3344
---------------------
Press [OK] for
Messages options
End Call
M 213-456-3344
Wonjung Seo
Connecting...
Phone Mode (Flip Closed)
[CLR]
stay new messages
Old message
If there is no call back #, “Call” menu is not appear
OK
[CLR]
When the SMS
ringer rings,
pressing any key
will stop the ring
but it will not
dismiss the
notification display
When the SMS
ringer rings,
pressing any key
will stop the ring
but it will not
dismiss the
notification display
3 new Page/Text
Down Rocker Down Rocker
Speaker On
![](/img.php?id=84303&img=bg11.png)
16
Menu : Messages (continued)
Extract #
OK
View Details
Extract #
Call
12:27p Mar 18(We)
Please call me
At 213-456-3344
Extracted
213-245-3344
Phone Mode (Flip Closed)
Call
Find
Save
213-345-3344
OK
OK
View Details
Extract #
Call
12:27p Mar 18(We)
Please call me
At 1-800-FLOWERS
Extracted
1-800-356-9377 Call
Find
Save
1-800-356-9377
OK
Menu : Messages (continued)
Make New Folder from Received Msg
OK
Extract #
Erase
Add Folder
XYZ! Weather
Kansas City
Sunshine
Phone Mode (Flip Closed)
Select a keyword.
Future Msgs with
matched keyword
will be saved in
Folder.
Match Keyword
Next Keyword
Prev Keyword
Exit
Help Tip
Weather
Kansas City
Sunshine
XYZ!
Match Keyword
Help Tip
XYZ!
Kansas City
Sunshine
Next Keyword
Weather
“Help Tip”
3 Secs
or [CLR]
You can use
[Right] or [Left]
rocker key as
[Next keyword] or
[Prev Keyword]
[Next Keyword]
1 Secs
Next Step
Exit
Enter Folder Name
Weather
OK
One Only
Two
Three
Help Tip
Exit
Select # of Msgs
One Only
Select Maximum
number of messages
allowed.
“Help
Tip”
3 Secs
or [CLR]
*Default
Folder Name = Keyword
[Weather]
Folder
Created
OK
MiniBrowser
Weather
Edit Folder
Erase All
Messages
Voicemail
Page/Text
10 New Voicemail
2 new Page/Text OK
OK
Standard
Select Ringer Type
Standard
1-Beep
Chirp
Vibrate
None
...
Sang:
Period added to
help cue.
Default settings
(e.g., # of Msgs)
added.
Sang:
Period added to
help cue.
Default settings
(e.g., # of Msgs)
added.
![](/img.php?id=84303&img=bg12.png)
17
Edit Folder
Messages
Stock
Erase All
10 New Voicemail
2 new Page/Text
Menu : Messages (continued)
Phone Mode (Flip Closed)
Edit Folder - Modify Folder
New Folder
Edit Folder
Weather
Stock # of msgs
Ringer Type
Erase Folder
Exit
[Weather] 1msg
Name
Keyword
Key:Weather
Ring:None
Enter Folder Name
OK
Exit
Weather
OK OK OK
Exit
[Weather]
# of msgs
Erase Folder
Weather
1 Message
[Weather]
Folder
Erased
OK All messages in this
folder will be erased.
Are you sure?
No
Yes
OK
Edit Folder
Messages
Stock
Erase All
10 New Voicemail
2 new Page/Text
Menu : Messages (continued)
Phone Mode (Flip Closed)
Edit Folder - New Folder
New Folder
Edit Folder
Weather
Stock
Enter Folder Name
Next Step
Exit
Rainbow
OK OK
[Rainbow]
Folder
Created
Next Step
Exit
Help Tip
Enter Keyword
Rainbow
One Only
Two
Three
Select # of Msgs
Standard
Select Ringer Type
1-Beep
Chirp
![](/img.php?id=84303&img=bg13.png)
18
Unlock
Call 911
LGI-3000W
2:23p Mar 18, (Th)
--Locked--
Locked State
*KeyGuard*
To disable, hold
the clear key
LGI-3000W
2:29p Mar 18, (Th)
KeyGuard State
Customer Care
SMS Notification when locked or keyguarded state
Unlock
2:23p Mar 18, (Th)
Please call me
at 213-456-3344
*KeyGuard*
To disable, hold
the clear key
2:29p Mar 18, (Th)
Please call me
at 213-456-3344
Exit
Lock Code :
* * _ _ 12:27p Mar 17(We)
Please call me
at 213-456-3344
Need to talk
--------------------
Messages From:
Correct
Lock
Code
Menu : Messages (continued)
Phone Mode (Flip Closed)
Voice Dial Entry
My Phone#
Services
Menu : Phone Book
Add Phone #
Set Voice Dial
Set Speed Dial
Set ID Ringer
Prepend
Edit
Erase Entry
Next
Previous
Exit
Call
H 032-456-2345
Call Alarm
[Business]
Aaron
M 310-234-5090
Add New Entry
Phone Book
Look Up Name
Find Speed Dial
Enter Name :
AA_
M Aaron
Exit
Look up Name
Phone Mode (Flip Closed)
OK OK
![](/img.php?id=84303&img=bg14.png)
19
Add New Entry
Phone Book
Look Up Name
Find Speed Dial
Find Speed Dial
Speed Dial # : 2_
02 : M Aaron
03 : O Joonsup Yi
Speed Dial #2
Call
Prepend
Aaron
M 310-234-5090
Erase
OK
OK
01 : M Voice Dial
Menu : Phone Book
Phone Mode (Flip Closed)
Speed Dial # : 1_
02 : M Aaron
03 : O Joonsup Yi
Speed Dial #1
Call
Prepend
Voicemail
M (Secret)
Erase
Next
Previous
Exit
OK
01 : M Voice Dial
Exit
Lock Code :
* * _ _
“Edit” or
“Erase”
WARNING!
Changes made may
affect the way
you access
voicemail
by using ‘1’ key
Menu : Phone Book (continued)
Look Up Name -> Call Alarm
Add Phone #
Set Voice Dial
Set Speed Dial
Set ID Ringer
Prepend
Edit
Erase Phone #
Erase Entry
Next
Previous
Call Alarm
H 032-456-2345l
Call
Aaron
M 310-234-5090
[Business] OK
Enter Date and Time of the event.
OK
2 Secs Timeout
Phone Mode (Flip Closed)
Set Repeating
Done
12:00a 04/29/99
Time/Date :
AM/PM Set Repeating
Done
03:39a 04/29/99
Time/Date :
AM/PM
Set Repeating
Done
03:39p 04/29/99
Time/Date :
AM/PM
Toggle
AM/PM
Weekly
None
None
Repeats :
Daily
Monthly
Yearly
Set Repeating
Done
03:39p 04/29/99
(Weekly)
AM/PM
Time/Date :
OK OK
Display
Call Alarm Saved
OK
Set Repeating
Done
03:39p 04/29/99
Time/Date :
AM/PM
![](/img.php?id=84303&img=bg15.png)
20
Look Up Name -> Add Phone #
Add Phone #
H 032-456-2345l
Aaron
M 310-234-5090
[Business]
Call Alarm
OK
Next Step
Hard Pause
Enter Phone #:
2Second Pause
H Home
W Work
Select Label :
M Mobile
Entered
Phone # 818-922-4552
Add Phone #
H 818-922-4552
Aaron
M 310-234-5090
[Business]
Call Alarm
Entered
Label
Menu : Phone Book (continued)
Phone Mode (Flip Closed)
Menu : Phone Book (continued)
Look Up Name -> Set Voice Dial
Call History
Messages
Phone Book
LGI-3000W
12:20p Mar 17 (We) OK
Move to the entry
that you want to
edit voice dialing
Exit
“Please Say Name!”
& Beep
Exit
“Please Say Again!”&
Beep
Phone book
Saved
Voice Dial
2 Secs
Timeout
Phone Mode (Flip Closed)
Add New Entry
Phone Book
Look Up Name
Find Speed Dial Call Alarm
Add Phone #
Set Voice Dial
Aaron
M 310-234-5090
[Business]
Exit
(Say Name & play <Name>)
Exit
Say name & play <Name>
OK
Beep Beep
Call
Call Alarm
Add Phone #
Aaron
M 310-234-5090
[Business]
Voice Dial List Full
Voice Dial List Full
Any More Voice Dial
Can’t save Voice Dial
Indicator
![](/img.php?id=84303&img=bg16.png)
21
Menu : Phone Book (continued)
Look Up Name -> Set Speed Dial
Call History
Messages
Phone Book
LGI-3000W
12:20p Mar 17 (We) OK
Move to the entry
that you want to
edit speed dialing
Phone book
Saved
Speed Dial #18 2 Secs
Timeout
Phone Mode (Flip Closed)
Add Phone #
Set Voice Dial
Set Speed Dial
Aaron
M 310-234-5090
[Business]
Add New Entry
Phone Book
Look Up Name
Find Speed Dial
Select Speed Dial#:
17
17 : M wonjung
18 : (Empty)
19 : (Empty)
Enter “17”
Select Speed Dial#:
18
17 : M wonjung
18 : (Empty)
19 : (Empty)
OK
OK
Down Rocker
Add Phone #
Set Voice Dial
Set Speed Dial
Aaron
M 310-234-5090
[Business] :18
Speed Dial
Indicator
Menu : Phone Book (continued)
Look Up Name -> Edit
Edit
Prepend
Set ID Ringer
Aaron
M 310-234-5090
[Business] OK
Phone #
Name
Edit
Category
Make Secret
Choose # to Edit
M 310-234-5090
H 032-456-2345
O 619-452-3459
OK
Aaron_
Save
Exit
Phone Mode (Flip Closed)
Add New Entry
Phone Book
Look Up Name
Find Speed Dial
OK
“CLR”
Next Step
Hard Pause
2 Sec. Pause
310-234-5090
“Name”
OK
![](/img.php?id=84303&img=bg17.png)
22
Menu : Phone Book (continued)
Look Up Name -> Edit(continued)
Edit
Prepend
Set ID Ringer
Aaron
M 310-234-5090
[Business]
OK
Make Secret
Name
Edit
Category
OK Make Secret
Yes
No Call
H (Secret)
Aaron
M (Secret)
[Business]
Call Alarm
OK
Phone Mode (Flip Closed)
Category
Phone #
Edit
Name
OK Select Category :
Business
Business
Private
Group1
Group…
Cancel
Edit
Prepend
Set ID Ringer
Aaron
M 310-234-5090
[Private]
OK
OK Phone book
Category Changed
Aaron
2 Sec
Menu : Phone Book (continued)
Phone Mode (Flip Closed)
Look Up Name -> Secret Item Edit(continued)
Call
H (Secret)
Aaron
M (Secret)
[Business]
Call Alarm
Aaron
M (Secret)
[Business]
Edit
Prepend
Set ID Ringer
OK
Exit
Lock Code :
* * _ _
OK
![](/img.php?id=84303&img=bg18.png)
23
Menu : Phone Book (continued)
OK
Save w/o Name
Cancel
Exit
Enter Name:
Next Step
Cancel
Exit
Tom Hanks_
Enter
Name OK
Next Step
Hard Pause
Enter Phone #:
2Second Pause
Home
Work
Select Label :
Mobile
After Enter Phone #,
818-453-4552 Select
Label
Find Speed Dial
Phone Book
Add New Entry
Look up Name
Select Category:
Unfiled
Business
Group1
Group2
Add New Entry
OK Phone Book
Entry
Saved
OK
OK
2 Secs
Timeout
Phone Mode (Flip Closed)
….
Unfiled
Tom Hanks
H 818-453-4552
[Unfiled]
Add Phone #
Call Alarm
Call
O.K
Voice Dial Entry
01 :(Empty)
03: O Wonjung
02: H Aaron
Add New Entry
Phone Book
Voice Dial Entry
Find Speed Dial
O.K
Play
Erase
Aaron
H 032-456-2345
Voice Dial #2
Next
Previous
Exit
O.K
Play the recorded
name.
Menu : Phone Book (continued)
Phone Mode (Flip Closed)
Voice Dial Entry
My Phone #
Voice Dial Entry
Phone Book
My Phone#
Add New Entry
OK My Phone #
OK
M 310-559-3070 OK
Add New Entry
Phone Book
My Phone#
Find Number
![](/img.php?id=84303&img=bg19.png)
24
Menu : Phone Book (continued)
Services
OK
Call
Customer Care :
*2
OK
My Phone #
Phone Book
Services
Voice Dial Entry Customer Care
Dir Assistance
Services
Prepaid
Road Assistance
Call
Dir Assistance :
411
OK
Dir Assistance
Customer Care
Services
Prepaid
Call
Prepaid :
*729
OK
Prepaid
Dir Assistance
Services
Customer Care
Call
Road Assistance :
*7623
OK
Road Assistance
Dir Assistance
Services
Prepaid
Phone Mode (Flip Closed)
Menu : MiniBrowser
Display
Card
Phone Mode (Flip Closed)
Choice
Card
Entry
Card
Soft1
Line1
Line2
Line3
Line4
Home Help Exit
Soft2 Soft2
Line1
Line2
Line3
Line4
Soft1
Soft1
Line1
Line2
Line3
Line4
Soft2
Line1
Soft1
Line1
Line2
Line3
Line4
Soft2
Line2
Soft1
Prompt :
_
Soft2
Text Input
Soft1
Prompt :
Sprint PCS
Soft2
Down Rocker
Left Rocker
![](/img.php?id=84303&img=bg1a.png)
25
MiniBrowser Prompt To Start
Phone Mode (Flip Closed)
Messages
Phone Book
MiniBrowser
LGI-3000W
12:20p Mar 17 (We)
Soft1
Line1
Line2
Line3
Line4
Soft2
Display
Corresponding
UP splash
Connecting...
[OK]
[No]
[Yes]
[OK]
On “Setup:MiniBrowser:Prompt”, “To Exit” or “None” is selected
“To Start” or “Both”
Messages
Phone Book
MiniBrowser
LGI-3000W
12:20p Mar 17 (We)
Soft1
Line1
Line2
Line3
Line4
Soft2
[END]
[No]
[Yes]
[END]
On “Setup:MiniBrowser:Prompt”, “To Start” or “None” is selected
“To Exit” or “Both”
MiniBrowser Prompt To Exit
Yes
Charges will apply
for MiniBrowser
calls.
Start MiniBrowser?
No
Yes
Exit MiniBrowser?
No
O.K
O.K
Phone Book
MiniBrowser
Environment
LGI-3000W
12:20p Mar 17 (We)
O.K
Phone Mode (Flip Closed)
Menu : Environment
Meeting
Silent
Environment
Normal
Outside
Home
Car
Edit
Car
Home
Car
Edit
Environment
Car OK
To Edit
Environment,
Please open flip
![](/img.php?id=84303&img=bg1b.png)
26
Menu : Sounds
O.K O.K O.K
O.K
Sounds
Display
Security
LGI-3000W Sounds
Ringer Type
Tone Length
Volume
Volume
Key Beep
Speaker
Ringer
Volume
Speaker
Key Beep
Ringer
O.K
Volume
Speaker
Ringer
Key Beep
12:20p Mar 17 (We)
Off
Vibrate
High
Medium
Low
Ringer
Medium
High
Medium
Low
Key Beep
Medium
High
Medium
Low
Speaker
Medium
1. Volume
Phone Mode (Flip Closed)
Alert Alert
Off
Menu : Sound (continued)
O.K O.K
O.K
Sounds
Tone Length
Ringer Type
Ringer Type
Messages
Alarms
Voice Call
Ringer Type
Alarms
Messages
Voice Call
O.K
Ringer Type
Alarms
Voice Call
Messages
Volume
O.K
Voice Call
Restricted Caller ID
No Caller ID
W/ Caller ID Standard
1-Beep
Chirp
W/ Caller ID
Standard
Voicemail
Page/Text
MiniBrowser
Messages
2. Ringer Type
Phone Mode (Flip Closed)
O.K
Ringer Type
Data Calls
Messages
Alarms
Standard
1-Beep
Chirp
Voicemail
Standard
O.K
Same in Fax Calls
Standard
1-Beep
Chirp
Alarms
Standard
Standard
1-Beep
Chirp
Data Calls
Standard
Ringer Type
Standard
1-Beep
Chirp
Vibrate
None
Melodies TBD
Ringer Type
Standard
1-Beep
Chirp
Vibrate
None
Melodies TBD
Roaming
![](/img.php?id=84303&img=bg1c.png)
27
10min
Menu : Sound (continued)
O.K O.K O.K
Sounds
Alert
Alert
Minute Beep
Service ChangeRinger Type
Tone Length
Sounds
Display
Security
LGI-3000W
12:20p Mar 17 (We)
Alert
Minute Beep
OK
Service Change
On
Off
Service Change
Off
Off
1 min
3 min
Minute Beep
1 min
4. Alert
Phone Mode (Flip Closed)
O.K
Sounds
Tone Length
Volume
Ringer Type Short
Long
Tone Length
Short
3. Tone Length
Alert is Medium Volume
Menu : Display
O.K O.K
O.K
Display
Security
Setup
LGI-3000W Display
Greeting
Contrast
Version
Backlight
Display
Contrast
Greeting
Backlight
O.K
Display
Contrast
Backlight
Greeting
In HFK Mode(External Power),
Backlight setting shall
automatically change to
always on
Change
Keep
Greeting
O.K
Save
Cancel
12:20p Mar 17 (We)
Always Off
8 secs
15 secs
Backlight
8 secs
High
Medium
Low
Contrast
Medium
LGI-3000W
RAINBOW_
Phone Mode (Flip Closed)
![](/img.php?id=84303&img=bg1d.png)
28
Menu : Display (continued)
O.K
Display
Version
Greeting
Contrast
SW:LGR990222
PRL:10005
OK
Phone Mode (Flip Closed)
Erase PhoneBook
Phone Reset
Menu : Security
O.K
O.K
Security
Setup
KeyGuard
LGI-3000W Security
Change Lock
Edit Special #s
Lock Phone
Exit
Enter Lock Code :
____
Security
Edit Special #s
Change Lock
Lock Phone O.K
Exit
New Lock Code :
_
12:20p Mar 17 (We)
Unlocked
Lock Now
On Power Up
Lock Phone
Unlocked
Correct
Code
Entered
Exit
Re-enter Code :
_
Code
Entered
New Lock Code
Saved
2 Secs Timeout
Phone Mode (Flip Closed)
Same
Code
Entered
![](/img.php?id=84303&img=bg1e.png)
29
Menu : Security (continued)
O.K
Security
Erase PhoneBook
Change Lock Code
Edit Special #s
Erase Phone Book
Cancel
O.K.
O.K
Security
Lock Phone
Change Lock Code
Special #s
2:Special #
3:Special #
1:Special #
Edit Special #s
Save
Cancel
Special #1
_
O.K
Edit Special Phone #
All Entries in Phone
Book will be erased.
Are you sure?
No
Yes
O.K
O.K
Security
Phone Reset
Edit Special #s
Erase Phone Book
Phone Reset
Cancel
O.K.
Reset all settings to
factory defaults
Are you sure?
No
Yes
O.K
Phone Mode (Flip Closed)
O.K
Security
Setup
KeyGuard
LGI-3000W
12:20p Mar 17 (We)
MiniBrowser
Hot Key
Menu : Setup(Continued)
Security
Setup
KeyGuard
LGI-3000W
12:20p Mar 17 (We) O.K
Setup
Roaming
Fax/Data In
Incoming Fax
Off
Fax/Data In
Any Key Answer Incoming Data
Fax/Data In
Incoming Fax
Off
Incoming Data
No incoming
voice calls
can be received.
O.K Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
- Fax Only -
5 Secs
Timeout
Fax/Data In
Incoming Data
Off
Incoming Fax
No incoming
voice calls
can be received.
O.K Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18, (Th)
- Data Only -
5 Secs
Timeout
Phone Mode (Flip Closed)
O.K
“Incoming Fax” and
“Incoming Data”.
These options do not
be active if there is no
cable connected to
PC.
“Incoming Fax” and
“Incoming Data”.
These options do not
be active if there is no
cable connected to
PC.
Down Rocker
No incoming
fax/data calls
can be received.
O.K
![](/img.php?id=84303&img=bg1f.png)
30
Menu : Setup(Continued)
O.K
Setup
Hot Key
Roaming
Call Guard
Set Mode
Roaming
Any Key Answer
O.K
Phone Mode (Flip Closed)
Set Mode
Automatic
Sprint PCS
Phone will
operate on
Sprint PCS
Service only.
Roaming rate
if outside
Sprint PCS
Service area.
Entering
Sprint PCS
Service Area
“Sprint PCS”“Automatic”
Call History
Messages
Phone Book
LGI-3000W
2:29p Mar 18 (Th)
Call History
Messages
Phone Book
Searching for
Service
*****
Call History
Messages
Phone Book
Digital Roam
12:20p Mar 17 (We)
Entering
Digital Roaming
Service Area
Beep Beep
5 sec 5 sec
Digital
Roaming
Menu : Setup:Roaming:Call Guard
Roaming
Call Guard
Set Mode
O.K
Phone Mode (Flip Closed)
Call Guard
No
Yes
Extra step
required to
make or take
roam calls
Extra key press
required for
roam calls
No extra
step to
make or take
roam calls
Yes(default)
Beep Beep No
5 sec
![](/img.php?id=84303&img=bg20.png)
31
Environment
O.K
Setup
MiniBrowser
Any Key Answer On
Off
Any Key Answer
Off
Roaming
O.K
Setup
Hot Key
Any Key Answer
MiniBrowser Backlight
KeyGuard
Voice Dial
Hot Key
Backlight
Menu : Setup(Continued)
Phone Mode (Flip Closed)
Setup
MiniBrowser
Any Key Answer
Hot Key
Prompt
To Exit
To Start
Both
Both
None
O.K
Security
Setup
KeyGuard
LGI-3000W
12:20p Mar 17 (We) O.K
O.K
Setup
Abbre. Dialing
Car Kit On
Off
Auto Answer
Off
Hot Key
O.K
Setup
Abbre. Dialing
Car Kit
Speaker Phone O.K.
Edit
Exit
Abbre. Dialing
816-555-XXXX
Menu : Setup(Continued)
Phone Mode (Flip Closed)
Security
Setup
KeyGuard
LGI-3000W
12:20p Mar 17 (We) O.K
O.K.
Exit
Enter Prefix :
816-559-XXXX
“Edit”
Setup
Speaker Phone
Hot Key
Car Kit Menu Only
Menu or Flip
Speaker Phone
Menu or Flip
O.K
O.K
O.K
![](/img.php?id=84303&img=bg21.png)
32
Phone Mode (Flip Closed)
Menu : KeyGuard
Setup
KeyGuard
PC Sync
LGI-3000W
12:20p Mar 17 (We)
*KeyGuard*
To disable, hold
the clear key
LGI-3000W
12:20P Mar 17(We)O.K
Menu : PC Sync
PC Sync
Start Stop
O.K
Phone Mode (Flip Closed)
Phone detects
PC connection
Call History
Messages
PC Sync
LGI-3000W
12:30p Mar 17 (We)
*PC Connected*
O.K
Answer
Silent Ringer
Call From:
Cindy
H 714-870-8842
Synchronizing
Stop
Sync aborted
Reconnect
handset to
sync with PC
Complete the Call
Beep
twice
Synchronizing
