LG ELECTRONICS MNC4U1106 Wireless Mouse User Manual
LG Electronics Inc. Wireless Mouse Users Manual
Users Manual
CM-400 User Manual English
Exterior
1) Mouse Body
1 Right-click Button 5
Sensor
2 Scroll Wheel 6
Upper Cover（Battery Insertion Cover）
3 Left-click Button 7
Power button/Bind button
4 Lower Power indicator
LED(Blue) 8
Upper Cover Knob
2) Receiver
1. USB Receiver
CM-400 User Manual English
To use the product
1) Insert the batteries.
2) Connect the receiver to the PC.
3) Establish communication line between the mouse and the receive.
Inserting Batteries
1) At the bottom of the mouse, follow the direction of the arrow to push gently,
at the same time, to pull out the battery cover in opposite direction, to pull
out the battery cover.
2) Follow the arrow where how to put the batteries in the right direction
※ Electricity of the enclosed batteries begins to be discharged little by little
immediately after production. Therefore, according to when the products are
opened, battery life could be shorter than expected. The company requests
users’ understanding of such electricity discharge.
CM-400 User Manual English
Connecting the receiver to the PC
Connect the USB receiver to an unused USB port on your computer
1) Turn on the computer power, mouse will working normally.
2) If computer on, your PC will recognize the receiver and automatically install
a basic driver.
※ Important: Please wait until a message or a window appears and
then follow the instructions to the completion of the driver
installation.
ON
To readily carry the mouse
1) Open the battery case.
2) Insert nano wireless receiver inside the compartment by the
direction of the arrow
3) Close the battery case back.
CM-400 User Manual English
To establish a wireless connection, please follow the instructions
If the mouse LED is blinking blue, please replace the batteries.
If the mouse is not working
1) Make sure the mouse power is on(turn-on/working)
2) Check the battery capacity and installation.
3) Click bind button one time shortly.
4) Check receiver installation.
5) Try another USB port.
Battery Power Saving
When not using the mouse, press the power button on the bottom of
mouse for 3~5 seconds to shut down the mouse power for battery
power saving. Then, press the power button for 1 to 3 seconds to
re-start the mouse power.
Battery replacement indicator LED and low power mode of the
mouse for prolonged use
After being used for quite a while, the battery voltage drops. The
lower power indicator LED (located on the upper area of the mouse)
also turns on blue at about 80% of battery power used. When the LED
is turned on, replace the battery as soon as possible. If the batteries
are not replaced, the mouse cursor movement slows down.
(Mouse may not work until batteries are replaced)
