User manual

Please read this manual carefully before operating

your set.

Retain it for future reference.

Record model number and serial number of the set.

See the label attached on the back cover and quote

this information to your dealer

when you require service.

LCD TV

OWNER’S MANUAL

22LG3DCH

P/NO : SAC30708037 (0807-REV00)

www.lgcommercial.com

WARNING / CAUTION

To prevent fire or shock hazards, do not expose

this product to rain or moisture.

FCC NOTICE

Class B digital device

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be determined

by turning the equipment off and on, the user is

encouraged to try to correct the interference by one

or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

receiver.

- Connect the equipment to an outlet on a circuit

different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

Any changes or modifications not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.

CAUTION

Do not attempt to modify this product in any way

without written authorization from LG Electronics.

Unauthorized modification could void the user’s

authority to operate this product

The lightning flash with arrowhead

symbol, within an equilateral triangle, is

intended to alert the user to the presence

of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral

triangle is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the litera-

ture accompanying the appliance.

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK). NO

USER SERVICEABLE PARTS INSIDE. REFER TO

QUALIFIED SERVICE PERSONNEL.

WARNING/CAUTION

TO REDUCE THE RISK OF FIRE AND ELECTRIC

SHOCK, DO NOT EXPOSE THIS PRODUCT TO

RAIN OR MOISTURE.

NOTE TO CABLE/TV INSTALLER

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the National

Electric Code (U.S.A.). The code provides guidelines for

proper grounding and, in particular, specifies that the

cable ground shall be connected to the grounding system

of the building, as close to the point of the cable entry

as practical.

IMPORTANT SAFETY INSTRUCTIONS

SAFETY INSTRUCTIONS

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including amplifiers)that produce heat.

Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has

two blades with one wider than the other. A

grounding type plug has two blades and a third

grounding prong, The wide blade or the third

prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an

electrician for replacement of the obsolete outlet.

Protect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

Only use attachments/accessories specified by

the manufacturer.

Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold

with the apparatus. When a cart is used, use

caution when moving the cart/apparatus

combination to avoid injury from tip-over.

Unplug this apparatus during lighting storms or

when unused for long periods of time.

Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has

been exposed to rain or moisture, does not operate

normally, or has been dropped.

Never touch this apparatus or antenna during a

thunder or lighting storm.

When mounting a TV on the wall, make sure not to

install the TV by the hanging power and signal

cables on the back of the TV.

Do not allow an impact shock or any objects to fall

into the product, and do not drop onto the screen

with something.

CAUTION concerning the Power Cord :

It is recommend that appliances be placed upon a

dedicated circuit; that is, a single outlet circuit which

powers only that appliance and has no additional

outlets or branch circuits. Check the specification

page of this owner's manual to be certain.

Do not connect too many appliances to the same

AC power outlet as this could result in fire or elec-

tric shock.

Do not overload wall outlets. Overloaded wall out-

lets, loose or damaged wall outlets, extension cords,

frayed power cords, or damaged or cracked wire

insulation are dangerous. Any of these conditions

could result in electric shock or fire. Periodically

examine the cord of your appliance, and if its

appearance indicates damage or deterioration,

unplug it, discontinue use of the appliance, and

have the cord replaced with an exact replacement

part by an authorized servicer. Protect the power

cord from physical or mechanical abuse, such as

being twisted, kinked, pinched, closed in a door, or

walked upon. Pay particular attention to plugs, wall

outlets, and the point where the cord exits the

appliance.

Do not make the TV with the power cord plugged

in. Do not use a damaged or loose power cord. Be

sure do grasp the plug when unplugging the power

cord. Do not pull on the power cord to unplug the

TV.

WARNING - To reduce the risk of fire or electrical

shock, do not expose this product to rain, moisture

or other liquids. Do not touch the TV with wet

hands. Do not install this product near flammable

objects such as gasoline or candles or expose the

TV to direct air conditioning.

Do not expose to dripping or splashing and do not

place objects filled with liquids, such as vases, cups,

etc. on or over the apparatus (e.g. on shelves above

the unit).

GGRROOUUNNDDIINNGG

Ensure that you connect the earth ground wire to

prevent possible electric shock. (i.e. a TV with a

three-prong grounded AC plug must be connected

to a three-prong grouned AC outlet) If grounding

methods are not possible, have a qualified electri-

cian install a separate circuit breaker.

Do not try to ground the unit by connecting it to

telephone wires, lightening rods, or gas pipes.

DDIISSCCOONNNNEECCTTIINNGG DDEEVVIICCEE FFRROOMM MMAAIINNSS

Mains plug is the disconnecting device. The plug

must remain readily operable.

Keep the product away from direct sunlight.

Power

Supply

Short-circuit

Breaker

AANNTTEENNNNAASS

OOuuttddoooorr aanntteennnnaa ggrroouunnddiinngg

If an outdoor antenna is installed, follow the precau-

tions below. An outdoor antenna system should not

be located in the vicinity of overhead power lines or

other electric light or power circuits, or where it can

come in contact with such power lines or circuits as

death or serious injury can occur.

Be sure the antenna system is grounded so as to pro-

vide some protection against voltage surges and

built-up static charges.

Section 810 of the National Electrical Code (NEC) in

the U.S.A. provides information with respect to prop-

er grounding of the mast and supporting structure,

grounding of the lead-in wire to an antenna dis-

charge unit, size of grounding conductors, location of

antenna discharge unit, connection to grounding

electrodes and requirements for the grounding elec-

trode.

AAnntteennnnaa ggrroouunnddiinngg aaccccoorrddiinngg ttoo tthhee

NNaattiioonnaall EElleeccttrriiccaall CCooddee,, AANNSSII//NNFFPPAA 7700

Cleaning

When cleaning, unplug the power cord and scrub

gently with a soft cloth to prevent scratching. Do not

spray water or other liquids directly on the TV as

electric shock may occur. Do not clean with chemi-

cals such as alcohol, thinners or benzene.

Moving

Make sure the product is turned off, unplugged

and all cables have been removed. It may take 2 or

more people to carry larger TVs. Do not press

against or put stress on the front panel of the TV.

Ventilation

Install your TV where there is proper ventilation. Do

not install in a confined space such as a bookcase.

Do not cover the product with cloth or other mate-

rials (e.g.) plastic while plugged in. Do not install in

excessively dusty places.

If you smell smoke or other odors coming from the

TV or hear strange sounds, unplug the power cord

contact an authorized service center.

Antenna Lead in Wire

Antenna Discharge Unit

(NEC Section 810-20)

Grounding Conductors

(NEC Section 810-21)

Ground Clamps

Power Service Grounding

Electrode System (NEC

Art 250, Part H)

Ground Clamp

Electric Service

Equipment

NEC: National Electrical Code

CONTENTS

WARNING / CAUTION

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

SAFETY INSTRUCTIONS

. . . . . . . . . . . . . . . . . . . . . . . . . . 2

FEATURE OF THIS TV

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PREPARATION

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Front Panel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Back Panel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Stand Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Cable Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Desktop Pedestal Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Swivel Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Attaching the TV to a desk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

VESA Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Securing the TV to the wall to prevent falling

When the TV is used on a stand

. . . . . . . . . . . . . . . . . . . . . . . . . . 15

Antenna or Cable Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 16

EXTERNAL EQUIPMENT SETUP

HD Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Other A/V Source Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Pillow Speaker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

WATCHING TV / CHANNEL CONTROL

Remote Control Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Turning On TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

On-Screen Menus Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Channel Setup

- Auto Scan (Auto Tuning) . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

- Add / Delete Channel (Manual Tuning) . . . . . . 38

- Channel Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Channel Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Input List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

PICTURE CONTROL

Picture Size (Aspect Ratio) Control . . . . . . . . . . . . . . . . . . 42

Preset Picture Settings

- Picture Mode - Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

- Color Tone - Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Manual Picture Adjustment

- Picture Mode - User Mode . . . . . . . . . . . . . . . . . . . . . . . . 47

- Picture Mode - Expert Control . . . . . . . . . . . . . . . . . . 48

Picture Improvement Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Advanced Control - Black (Darkness) Level . . . . . . . 50

Advanced Control - Real Cinema . . . . . . . . . . . . . . . . . . . . . .51

Picture Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

SOUND & LANGUAGE CONTROL

Auto Volume Leveler (Auto Volume) . . . . . . . . . . . . . . . . . 53

Clear Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Preset Sound Settings (Sound Mode) . . . . . . . . . . . . . . . 55

Sound Setting Adjustment - User Mode . . . . . . . . . . . 56

Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

TV Speakers On/Off Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Audio Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Stereo/SAP Broadcast Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

On-Screen Menus Language Selection . . . . . . . . . . . . . 63

Caption Mode

- Analog Broadcasting System Captions . . . . . . . 64

- Digital Broadcasting System Captions . . . . . . . . 65

- Caption Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

TIME SETTING

Clock Setting

- Auto Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

- Manual Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Auto On/Off Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Sleep Timer Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Auto Shut-off Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

PARENTAL CONTROL / RATINGS

Set Password & Lock System . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Channel Blocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Movie & TV Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Downloadable Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

External Input Blocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

APPENDIX

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

IR Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

FEATURE OF THIS TV

is a trademark of SRS Labs, Inc.

TruSurround XT technology is incorporated under

license from SRS Labs, Inc.

Manufactured under license from Dolby Laboratories.

“

Dolby

“and the double-D symbol are trademarks of

Dolby Laboratories.

LG's own special digital image generator, consisting

of a full digital image processor, six different main

picture quality factors.

High-definition television. High-resolution digital

television broadcast and playback system composed

of roughly a million or more pixels, 16:9 aspect-ratio

screens, and AC3 digital audio. A subset of digital

television, HDTV formats include 1080i and 720p

resolutions.

USB IN

SERVUCE ONLYSERVUCE ONLY

USB port shall be used for software update by service

personnel only.

FOR LCD TV

■

If the TV feels cold to the touch, there may be a small “flicker” when it is turned on. This is normal, there is nothing wrong

with TV.

■

Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse

effect on the monitor's performance.

■

Avoid touching the LCD screen or holding your finger(s) against it for long periods of time. Doing so may produce some

temporary distortion effects on the screen.

On Disposal

The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with general

household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority.

PREPARATION

ACCESSORIES

Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the

dealer where you purchased the TV.

The accessories included may differ from the images below.

OOppttiioonn EExxttrraass

* Wipe spots on the exterior only with the polishing cloth.

* Do not wipe roughly when removing stains. Excessive

pressure may cause scratches or discoloration.

Polishing Cloth

D-sub 15 pin Cable

Owner’s Manual Power CordCD Manual

When using the VGA (D-sub 15 pin cable) PC connection, the

user must use shielded signal interface cables with ferrite

cores to maintain standards compliance.

Protection Cover

(Refer to P.11)

PREPERATION

Protective Bracket and

Bolt for Power Cord

(Refer to P.12)

OOppttiioonnaall IInnssttaalllleerr RReemmoottee CCoonnttrrooll ffoorr MMooddeell NNoo.. SSeerriieess 2222LLGG33DDCCHH

There is an optional Installer remote control available for the 22LG3DCH models. The installer

remote control is NOT included with the TV.

Wall Mounting Bracket

(RW120)

PREPARATION

FRONT PANEL INFORMATION

■

Image shown may differ from your TV.

■

NOTE: If your TV has a protection tape attached, remove the tape.

And then wipe the TV with a cloth (If a polishing cloth is included with your TV, use it).

VOL

INPUT

ENTER

VOLUME (+, -)

Buttons

ENTER Button

MENU Button

INPUT Button

CHANNEL(+, -)

Buttons

POWER Button

Power/Standby Indicator

Illuminates red in standby mode.

Illuminates green when the set is switched

on.

Remote Control Sensor

PREPARATION

BACK PANEL INFORMATION

■

Image shown may differ from your TV.

PREPARATION

AV (Audio/Video) IN

Analog composite connection. Supports standard

definition video only (480i).

UPDATE / RESET

USB IN SERVICE ONLY

Used for software updates.

REMOTE CONTROL OUT

PILLOW SPEAKER

Used to connect to pillow speaker.

SPEAKER SWITCH

Used to select the speaker output switch.

Note: If Pillow Speaker is selected, no Sound will be

heard from TV speakers.

(NORMAL SPEAKER or PILLOW SPEAKER.)

HDMI/DVI IN

Digital Connection. Supports HD video and Digital

audio.

Accepts DVI video using an adapter or HDMI to

DVI cable (not included)

RS-232C IN (SERVICE ONLY)

Used for software updates.

PILLOW

SPEAKER

NORMAL

SPEAKER

PILLOW

SPEAKER

SPEAKER SWITCH

PILLOWPILLOW

SPEAKERSPEAKER

HDMI/DVI INHDMI/DVI IN

RS-232C INRS-232C IN

(SERVICE ONLY)(SERVICE ONLY)

USB INUSB IN

SERVUCE ONLYSERVUCE ONLY

REMOTEREMOTE

CONTROL OUTCONTROL OUT

AV IN 1AV IN 1

VIDEOVIDEO

AUDIOAUDIO

MONOMONO

( )

NORMALNORMAL

SPEAKERSPEAKER PILLOWPILLOW

SPEAKERSPEAKER

SPEAKER SWITCHSPEAKER SWITCH

RESETRESET

UPDATEUPDATE

PREPARATION

After removing the stand, install the included

pprrootteeccttiioonn ccoovveerrover the hole for the stand.

Press the PPRROOTTEECCTTIIOONN CCOOVVEERRinto the TV

until you hear it click.

PROTECTION COVER

PREPARATION

CABLE MANAGEMENT

■

Image shown may differ from your TV.

Connect the cables as necessary.

To connect additional equipment, see the

EXTERNAL EQUIPMENT SETUP section.

Secure the power cable with the

PROTECTIVE BRACKET and the screw as

shown. It will help prevent the power cable

from being removed by accident.

Install the CABLE MANAGEMENT CLIP as

shown.

CABLE MANAGEMENT CLIP

Put the cables inside the CABLE MANAGEMENT

CLIP and snap it closed.

PROTECTIVE BRACKET

PREPARATION

VESA WALL MOUNTING

Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materi-

als, please contact your nearest dealer.

If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.

We recommend that you use an LG brand wall mount when mounting the TV to a wall.

GGDo not install your wall mount kit while the TV is plugged in. It may result in personal injury due to electric

shock.

CAUTION

GGScrew length needed depends on the wall mount

used. For further information, refer to the instruc-

tions included with the mount.

GGStandard dimensions for wall mount kits are shown

in the table.

GGWhen purchasing our wall mount kit, a detailed

installation manual and all parts necessary for

assembly are provided.

GGDo not use screws longer then the standard dimen-

sion, as they may cause damage to the inside to

the TV.

GGFor wall mounts that do not comply with the VESA

standard screw specifications, the length of the

screws may differ depending on their specifica-

tions.

GGDo not use screws that do not comply with the

VESA standard screw specifications.

Do not tighten the screws too much. It may dam-

age the TV or allow the TV to a fall and cause per-

sonal injury. LG is not liable for these kinds of acci-

dents.

GGLG is not liable for TV damage or personal injury

when a non-VESA or non specified wall mount is

used or the consumer fails to follow the TV installa-

tion instructions.

NOTE

Product Model VESA

(A *B) Standard Screw Quantity

22LG3DCH 200 * 10 0 M4 4

LCD TV

GGTo prevent injury, this apparatus must be securely attached to the wall in accordance with the installa-

tion instructions.

WARNING

ANTENNA IN

PREPARATION

ANTENNA OR CABLE CONNECTION

1. Antenna (Analog or Digital)

Wall Antenna Socket or Outdoor Antenna without a Cable Box

Connection.

For optimum picture quality, adjust the direction if needed.

2. Cable

Wall

Antenna

Socket

Outdoor

Antenna

(VHF, UHF)

Cable TV

Wall Jack

Multi-family Dwellings/Apartments

(Connect to wall antenna socket)

RF Coaxial Wire (75 ohm)

Single-family Dwellings /Houses

(Connect to wall jack for outdoor antenna)

Be careful not to bend the copper wire

when connecting the antenna.

Copper Wire

■To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.

■If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.

■If the antenna is not installed properly, contact your dealer for assistance.

( )

■To prevent damage do not connect to the power outlet until all connections are made between the devices.

EXTERNAL EQUIPMENT SETUP

HD RECEIVER SETUP

This TV can receive Digital Over-the-air or Digital Cable signals without an external digital set-top box. However,

if you do receive digital signals from a digital set-top box or other digital external device, refer to the figure as

shown below.

■To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.

EXTERNAL EQUIPMENT SETUP

HDMI Connection

Connect the digital set-top box to HHDDMMII//DDVVII IINN

jack on the TV.

No separate audio connection is necessary.

HDMI supports both audio and video.

1. How to connect

2. How to use

■Turn on the digital set-top box.

(Refer to the owner’s manual for the digital set-top box.)

HDMI-DTV

Horizontal Vertical

Frequency(KHz)Frequency(Hz)

15.73 59.94

15.73 60.00

31.469 59.94

31.500 60.00

44.96 59.94

45.00 60.00

33.72 59.94

33.75 60.00

67.50 60.00

Resolution

720x480p

1280x720p

1920x1080i

1920x1080p

( )

AUDIO IN

(RGB/DVI)

( )

RGB IN (PC)

RESET

UPDATE

RS-232C IN

(SERVICE ONLY)

REMOTE

CONTROL OUT SPEAKER OUT

HDMI/DVI IN

USB IN

SERVUCE ONL

VIDEO

MONO

( )

AUDIO

S-VIDEOS-VIDEO

RESET

UPUPDATE

AV IN 1AV IN 1

VIDEO

COMPONENT

HDMI-DTV OUTPUT

720x480i

EXTERNAL EQUIPMENT SETUP

DVI to HDMI Connection

( )

AUDIO IN

(RGB/DVI)

( )

RGB IN (PC)

RESET

UPDATE

RS-232C IN

(SERVICE ONLY)

REMOTE

CONTROL OUT SPEAKER OUT

RESET

UPDATE

AUDIO IN

(RGB/DVI)

AUDIO IN

(RGB/DVI)

HDMI/DVI IN

USB IN

SERVUCE ONLY

VIDEO

MONO

( )

AUDIO

S-VIDEOS-VIDEO

RGB IN (PC)

RS-232C IN

(SERVICE ONLY)

RS-232C IN

(SERVICE ONLY)

AV IN 1AV IN 1

VIDEO

AUDIO

COMPONENT

DVI-DTV OUTPUT LR

GGA DVI to HDMI cable or adapter is required for this

connection. DVI doesn't support audio, so a separate

audio connection is necessary.

NOTE

Connect the DVI output of the digital set-top box to

the HHDDMMII//DDVVII IINNjack on the TV.

Connect the audio output of the digital set-top box to

the AAUUDDIIOO IINN((RRGGBB//DDVVII))jack on the TV.

1. How to connect

2. How to use

■Turn on the digital set-top box. (Refer to the owner’s man-

ual for the digital set-top box.)

EXTERNAL EQUIPMENT SETUP

DVD SETUP

HDMI Connection

Connect the HDMI output of the DVD to the

HHDDMMII//DDVVII IINNjack on the TV.

No separate audio connection is necessary.

HDMI supports both audio and video.

1. How to connect

2. How to use

■Refer to the DVD player's manual for operating instructions.

HDMI/DVI IN

USB IN

SERVUCE ONLY

VIDEO

MONO

( )

AUDIO

S-VIDEOS-VIDEO

RESET

UPDUPDATE

AV IN 1AV IN 1

VIDEO

AUDI

COMPONENT

HDMI OUTPUT

EXTERNAL EQUIPMENT SETUP

VCR SETUP

Antenna Connection

■To avoid picture noise (interference), leave an adequate distance between the VCR and TV.

■If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible on the

screen. This phenomenon is common to all TVs and is not covered by warranty.

L R

S-VIDEO VIDEO

OUTPUT

SWITCH

ANT IN

ANT OUT

ANTENNA IN M.P.I.

( )

Wall Jack

Antenna

Connect the RF antenna out socket of the

VCR to the AANNTTEENNNNAA IINNsocket on the

TV.

Connect the antenna cable to the RF

antenna in socket of the VCR.

1. How to connect

2. How to use

■Set VCR output switch to 3 or 4 and then

tune TV to the same channel number.

■Insert a video tape into the VCR and press

PLAY on the VCR. (Refer to the VCR owner’s

manual.)

EXTERNAL EQUIPMENT SETUP

Composite (RCA) Connection

Connect the AAUUDDIIOO/VVIIDDEEOOjacks between TV and

VCR. Match the jack colors (Video = yellow, Audio Left

= white, and Audio Right = red)

1. How to connect

2. How to use

■Insert a video tape into the VCR and press PLAY on the

VCR. (Refer to the VCR owner’s manual.)

■If connected to AAVV IINN22, select AAVV22input source on the TV.

GGIf you have a mono VCR, connect the audio cable

from the VCR to the AAUUDDIIOO LL((MMOONNOO))jack of

the TV.

NOTE

ANTENNA IN M.P.I.

AUDIO

(RGB/

VIDEO

MONO

( )

AUDIO

RGB IN (P

AV IN 1

VIDEO

AUDIO

COMPONENT

S-VIDEO

RS-VIDEO

VIDEO

OUTPUT

SWITCH

ANT IN

ANT OUT

EXTERNAL EQUIPMENT SETUP

OTHER A/V SOURCE SETUP

AV IN 2

L/MONO

AUDIO

VIDEO

H/P

L R

VIDEO

Camcorder

Video Game Set

Connect the AAUUDDIIOO/VVIIDDEEOOjacks

between TV and external equipment.

Match the jack colors

(Video = yellow, Audio Left = white, and

Audio Right = red)

1. How to connect

2. How to use

■If connected to AAVV IINN11input, select the AAVV11

input source on the TV.

■Operate the corresponding external equipment.

EXTERNAL EQUIPMENT SETUP

PILLOW SPEAKER SETUP

■Connect a pillow speaker to the LCD TV/Monitor.

Pillow speaker not included with TV.

PILLOW

SPEAKER

NORMAL

SPEAKER

PILLOW

SPEAKER

SPEAKER SWITCH

PILLOWPILLOW

SPEAKERSPEAKER

NORMAL

SPEAKER PILLOW

SPEAKER

SPEAKER SWITCHSPEAKER SWITCH

1. How to connect

Connect the PPIILLLLOOWW SSPPEEAAKKEERRoutput jack on the

back of the TV.

Connect an acccessory pillow speaker or wired remote

control unit to this 6-pin jack.

Select PPIILLLLOOWW SSPPEEAAKKEERRon the rear panel of the

TV.

■NOTE:

If the pillow speaker switch is set to Pillow Speaker, no

sound will be heard from the TV speakers. Also, Auto Volume will

be grayed out and not accessible on the Sound menu.

Use a pillow speaker by Curbell, Model A-16455-02 or other UL

recognized pendant control bearing the warning:

“Risk of fire if used in oxygen enriched atmosphere. Keep pen-

dant control away from oxygen equipment.”

Controlling the TV with Serial Data

The TV is capable of being controlled by a single-wire, serial data

signal. This is a LG patented technology and is being implemented

by certain brands of “smart” pillow speakers, such as Curbell’s

“GEN-II” models.

Pillow Speaker Interface

This connector furnishes three control lines and an audio output.

A patient-pendant remote control, or entertainment audio and

nurse call system may be connected here. All lines are isolated

from the AC power line and earth ground. (Optoisolators isolate

the control lines, and a transformer isolates the audio. There are

no relays or inductive components in the control lines.)

Controlling the TV with Mechanical Switches

Pin 4(common) is momentarily connected to pin

1, 3, or 6 via push-action switches to control

On/Off and Channel Up/Down. These pins are

at +13volts DC(when measured from pin4) with

the switches open. Current draw is 8 mA when a

switch is closed. (This operation is identical to

previous LG models using the 5-Wire Interface

except that only +7 volts DC was supplied and

current draw was only 2.5 mA.)

pin No.

External TV On/Off switch.

(Not used.)

External Channel Up switch or Data in.

Common connection for control, data, and

audio output. Impedance to earth ground is a

10-meg resistor in parallel with a 1100 pf

capacitor.

Isolated audio output. Nominal 14-ohm source

impedance with short circuit protection.

Intended for a pillow speaker with a low-impe

ance pad-type volume control.

External Channel Down switch.

Purpose

EXTERNAL EQUIPMENT SETUP

This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.

VGA (D-Sub 15 pin) Connection

RGB OUTPUT AUDIO

AUDIO IN

(RGB/DVI)

AUDIO IN

(RGB/DVI)

VIDEO

MONO

( )

RGB IN (PC)RGB IN (PC)

REMOT

CONTROL

AUDIOAUDIO

2. How to use

■Turn on the PC and the TV.

■Select the RRGGBBinput source on the TV using the IINNPPUUTT

button on the remote control.

Connect the VGA output of the PC to the RRGGBB

IINN((PPCC)) jack on the TV.

Connect the PC audio output to the AAUUDDIIOO IINN

((RRGGBB//DDVVII))jack on the TV.

1. How to connect

PC SETUP

EXTERNAL EQUIPMENT SETUP

Horizontal Vertical

Frequency(KHz)Frequency(Hz)

31.469 70.08

31.469 59.94

37.879 60.31

48.363 60.00

47.776 59.87

47.712 60.01

47.720 59.799

47.130 59.65

GGTo get the the best picture quality, adjust the

PC graphics card to 1360x768.

GGDepending on the graphics card, DOS mode

may not work if a HDMI to DVI Cable is in use.

GGIn PC mode, there may be noise associated

with the resolution, vertical pattern, contrast

or brightness. If noise is present, change the

PC output to another resolution, change the

refresh rate to another rate or adjust the

brightness and contrast on the PICTURE menu

until the picture is clear.

GGAvoid keeping a fixed image on the screen for a

long period of time. The fixed image could

become permanently imprinted on the screen.

GGThe synchronization input form for Horizontal

and Vertical frequencies is separate.

GGDepending on the graphics card, some resolu-

tion settings may not allow the image to be

positioned on the screen properly.

NOTES

Supported Display Specifications

(RGB-PC, HDMI-PC)

Resolution

720x400

1360x768

640x350

640x480

800x600

1024x768

1366x768

1280x768

* Only RGB-PC mode

DVI to HDMI Connection

( )

AUDIO IN

(RGB/DVI)

AUDIO IN

(RGB/DVI)

HDMI/DVI IN

USB IN

SERVUCE ONLY

VIDEO

MONO

( )

AUDIO

S-VIDEOS-VIDEO

RGB IN (PC)

UPDATE

RS-232C IN

(SERVICE ONLY)

AV IN 1AV IN 1

VIDEOVIDEO

AUDIOAUDIO

COMPONENT

DVI-PC OUTPUT AUDIO

2. How to use

■Turn on the PC and the TV.

■Select the HHDDMMIIinput source on the TV using the IINNPPUUTT

button on the remote control.

Connect the DVI output of the PC to the HHDDMMII//DDVVII

IINN jack on the TV.

Connect the PC audio output to the AAUUDDIIOOIINN

((RRGGBB//DDVVII))jack on the TV.

1. How to connect

EXTERNAL EQUIPMENT SETUP

Screen Setup for PC mode

Select the desired resolution.

1024 x 768

1280 x 768

1360 x 768

1366 x 768

Auto config.

Resolution

Position

Size

Phase

Reset

Screen

Move

Prev.

ADJUST

ENTER

RETURN

Select RReessoolluuttiioonn.

Selecting Resolution

You can choose the resolution in RGB mode.

The PPoossiittiioonn, PPhhaassee, and SSiizzeecan also be adjusted.

Press the AADDJJUUSSTTbutton.

Return to TV viewing.

■ You can also adjust SSccrreeeenn((RRGGBB--PPCC))

in the PPIICCTTUURREEmenu.

EXTERNAL EQUIPMENT SETUP

Auto Configure

Automatically adjusts picture position and minimizes image instability. After adjustment, if the image is still

not correct, try using the manual settings or a different resolution or refresh rate on the PC.

Select AAuuttoo ccoonnffiigg...

Auto config. G

Resolution

Position

Size

Phase

Reset

Screen

Move

Prev.

To Set

Select YYeess.

ENTER

Start Auto Configuration.

ENTER

Press the AADDJJUUSSTTbutton.

• If the position of the image is still not

correct, try Auto adjustment again.

• If picture needs to be adjusted again

after Auto adjustment in RGB, you can

adjust the PPoossiittiioonn, SSiizzee or PPhhaassee.

Yes No

ADJUST

EXTERNAL EQUIPMENT SETUP

Adjustment for screen Position, Size, and Phase

If the picture is not clear after auto adjustment and especially if characters are still trembling, adjust the picture

phase manually.

This feature operates only in RGB mode.

Make appropriate adjustments.

Auto config.

Resolution

Position

Size

Phase

Reset

Screen

Move

Prev.

ENTER

RETURN

■PPoossiittiioonn: This function is to adjust pic-

ture to left/right and up/down as you

prefer.

■SSiizzee: This function is to minimize any

vertical bars or stripes visible on the

screen background. And the horizontal

screen size will also change. The SSiizzee

adjustment range is --3300~3300.

■PPhhaassee: This function allows you to

remove any horizontal noise and clear or

sharpen the image of characters. The

PPhhaasseeadjustment range is --3322~3311.

Press the AADDJJUUSSTTbutton.

Select PPoossiittiioonn, SSiizzee, or PPhhaassee.

ADJUST

Return to TV viewing.

EXTERNAL EQUIPMENT SETUP

Screen Reset (Reset to original factory values)

Returns PPoossiittiioonn, SSiizzee, and PPhhaasseeto the default factory settings.

This feature operates only in RGB mode.

ENTER

Select RReesseett.

ADJUST

Select YYeess.

ENTER

Auto config.

Position

Resolution

Size

Phase

Reset

Screen

Move

Prev.

Initialize Settings.

Yes No

Press the AADDJJUUSSTTbutton.

WATCHING TV / CHANNEL CONTROL

TURNING ON TV

WATCHING TV / CHANNEL CONTROL

NOTE

GGIf you intend to be away on vacation, disconnect the power plug from the wall power outlet.

First, connect power cord correctly.

At this moment, the TV switches to standby mode.

■In standby mode to turn TV on, press the button on the TV.

■This TV is programmed to remember which power state it was last set to,

even if the power cord is out.

When finished using the TV, press the button on the TV. The TV reverts

to standby mode.

WATCHING TV / CHANNEL CONTROL

Press the CCHH((++ or --))or NNUUMMBBEERRbuttons to select a channel number.

VOLUME ADJUSTMENT

CHANNEL SELECTION

Press the VVOOLL((++ or --))button to adjust the volume.

If you want to switch the sound off, press the MMUUTTEEbutton.

You can cancel the Mute function by pressing the MMUUTTEEor VVOOLL((++ or --))

button.

Adjust the volume to suit your personal preference.

WATCHING TV / CHANNEL CONTROL

ON-SCREEN MENUS SELECTION

Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual.

Display each menu.

Select a menu item.

Enter to the pop up menu.

ENTER

Return to TV viewing.

Enter

Move

CHANNEL

TIME


OPTION

AUDIO

LOCK

Enter

Move

Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0


Enter

Move

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

AUDIO

Enter

Move

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

TIME

Enter

Move

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

LOCK

Auto Tuning

Manual Tuning

Channel Edit

Channel Label

Enter

Move

Language : English

Caption : Off

OPTION

WATCHING TV / CHANNEL CONTROL

CHANNEL SETUP

Auto Scan (Auto Tuning)

Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the

channel list.

Run Auto Tuning again after any Antenna/Cable connection changes.

Select CCHHAANNNNEELL.

Select AAuuttoo TTuunniinngg.

Select YYeess.

Run AAuuttoo ttuunniinngg.

ENTER

■A password is required to gain access to

Auto Tuning menu if the Lock System is

turned on.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel Label

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel Label Press ‘Yes’ button to begin

auto tuning.

Yes

WATCHING TV / CHANNEL CONTROL

Select CCHHAANNNNEELL.

ENTER

If selecting DTV or CADTV input signal, you can view the on-screen signal strength monitor to see the quality

of the signal being received.

Add/Delete Channel (Manual Tuning)

Select MMaannuuaall TTuunniinngg.

Select DDIIGGIITTAALLor AANNAALLOOGG.

Select channel you want to add

or delete.

ENTER

Select AAdddd or DDeelleettee.

ENTER

■A password is required to gain access to

Manual Tuning menu if the Lock System

is turned on.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

CHANNEL

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel Label

Channel

Select channel type and

RF-channel number.

DIGITAL

FF2GG

Delete

DIGITAL 2-1

Bad Normal Good

Auto Tuning

Manual Tuning

Channel Edit

Channel Label

WATCHING TV / CHANNEL CONTROL

Select a channel.

Select channel you want to add or delete.

ENTER

A custom list can be created by toggling each channel on or off with ENTER button. The channels in the Custom

List are displayed in black and the channels deleted from the Custom List are displayed in gray.

Once a channel is highlighted you can add or delete the channel by referring to the small window at the top-

right corner of the screen.

Channel Editing

Select CCHHAANNNNEELL.

ENTER

Select CChhaannnneell EEddiitt.

RETURN

Return to TV viewing.

Return to the previous menu.

Add/Delete Move Page

Move Previous RETURN EXIT

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel Label

WATCHING TV / CHANNEL CONTROL

CHANNEL LABEL

Choose preset labels for your channels.

If a channel label is provided on the signal from the broadcasting station, the TV displays a short name for a

channel even if you didn't preset a label for the channel.

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel Label

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel Label Logo FF Disney GG

Channel DIGITAL 2-1

Select CCHHAANNNNEELL.

Select CChhaannnneell LLaabbeell.

Select Channel.

ENTER

Select the appropriate logo for the channel.

Select a channel to set logo.

RETURN

Return to the previous menu.

Return to TV viewing.

WATCHING TV / CHANNEL CONTROL

INPUT LIST

Select the desired input source.

INPUT

TV AV1 AV2

Component

HDMI RGB

TV AV1 AV2 Component RGB

ENTER

■TTVV: Select it to watch over-the-air, cable

and digital cable broadcasts.

■AAVV11--22: Select them to watch a VCR or

other external equipment.

■CCoommppoonneenntt: Select them to watch

DVD or a Digital set-top box.

■RRGGBB: Select it to view PC input.

■HHDDMMII: Select them to watch high defin-

ition devices.

PICTURE CONTROL

PICTURE SIZE (ASPECT RATIO) CONTROL

PICTURE CONTROL

This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV.

■ RGB input source use 4:3 or 16:9 aspect ratio.

NOTE

GGIf a fixed image is displayed on the screen for a long time, the image could become imprinted on the

screen and remain visible. This phenomenon is rare on LCDs, but is possible when the image is on the

screen for a very long time. This phenomenon is common to all manufacturers and is not covered by

warranty. When watching video that does not fill the screen, any after-image from the black bars will

normally dissipate after a few minutes.

Press the RRAATTIIOObutton repeatedly to select the picture options

: SSeett BByy PPrrooggrraamm,, 44::33,, 1166::99,, FFuullll,,ZZoooomm11,, ZZoooomm22.

RATIO

RETURN

Return to TV viewing.

■ You can also adjust AAssppeecctt RRaattiiooin

the PPIICCTTUURREEmenu.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

Enter

Move

Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0 RG


Set By Program

4:3

16:9

Full

Zoom1

Zoom2

PICTURE CONTROL

Set by program

Selects the proper picture proportion to match

the source’s image.

4:3

Choose 4:3 when you want to view a picture

with an original 4:3 aspect ratio.

16 : 9

Adjust the picture horizontally, in a linear pro-

portion to fill the entire screen.

(4:3 4:3)

(16:9 16:9)

Zoom 1

Choose Zoom 1 when you want to view the pic-

ture without any alteration. However, the top and

bottom portions of the picture will be cropped.

Zoom 2

Choose Zoom 2 when you want the picture to be

altered, both vertically extended and cropped.

The picture taking a halfway trade off between

alteration and screen coverage.

Just Scan

Normally the edges of video signals are cropped

1-2%. Just Scan turns off this cropping and

shows the complete video.

Notes: If there is noise on the edges of the original

signal, it will be visible when Just Scan is activated.

JJuusstt SSccaannoperates only with

DTV/CADTV/HDMI-DTV/DVI-DTV

(720p/1080i/1080p),

Component(720p/1080i) input sources.

PICTURE CONTROL

PRESET PICTURE SETTINGS

Picture Mode - Preset

There are factory presets for picture settings available in the user menus. You can use a preset, change each

setting manually.


Press the PPIICCTTUURREEbutton repeatedly to select the picture options

: VViivviidd,SSttaannddaarrdd, CCiinneemmaa, SSppoorrtt, GGaammee and EExxppeerrtt11--22.

■ You can also adjust PPiiccttuurree MMooddeein

the PPIICCTTUURREEmenu.

Return to TV viewing.

RETURN

VViivviidd

PICTURE CONTROL

Color Tone - Preset

Choose one of three automatic color adjustments. Set to warm to enhance hotter colors such as red, or set to

cool to see less intense colors with more blue.

Select PPIICCTTUURREE.

Select CCoolloorr TTeemmppeerraattuurree.

ENTER

Select CCooooll, MMeeddiiuumm, or WWaarrmm.

Select AAddvvaanncceedd CCoonnttrrooll.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Color Temperature

FFMedium GG

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Auto

Gamma

Medium

Black Level

Medium

Real Cinema

Off

PICTURE CONTROL

MANUAL PICTURE ADJUSTMENT

Picture Mode - User Mode

Adjust the picture appearance to suit your preference and viewing situations.

Select PPIICCTTUURREE.

Make appropriate adjustments.

Select BBllaacckklliigghhtt,, CCoonnttrraasstt,, BBrriigghhttnneessss,,

SShhaarrppnneessss,, CCoolloorr,, oorr TTiinntt..

Select PPiiccttuurree MMooddee.

ENTER

Select VViivviidd,SSttaannddaarrdd, CCiinneemmaa, SSppoorrtt, or GGaammee.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 90

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Backlight 80

Enter

PICTURE CONTROL

Picture Mode - Expert Control

Select your desired menu option.

Select PPIICCTTUURREE.

Select PPiiccttuurree MMooddee.

Select EExxppeerrtt CCoonnttrrooll.

Select EExxppeerrtt11or EExxppeerrtt22.

ENTER

Make appropriate adjustments.

EExxppeerrtt11and EExxppeerrtt22allow you set you own custom settings.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

Enter

Move


Vivid

Standard

Cinema

Sport

Game

Expert1

Expert2

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Expert Control

• Reset

Screen (RGB-PC)

FFOff GG

Fresh Contrast

Noise Reduction

Off

Gamma Medium

Black Level Auto

Off

Real Cinema

Color Standard

White Balance Normal

Red Contrast 50

PICTURE CONTROL

PICTURE IMPROVEMENT SETTINGS

Fresh Contrast: Optimizes the contrast automatically according to the brightness of the reflection.

Fresh Color: Adjusts the color of the reflection automatically to reproduce as close as possible natural colors.

Noise Reduction: Removes interference up to the point where it does not damage the original picture.

Gamma: High gamma values display whitish images and low gamma values display high contrast images.

Select PPIICCTTUURREE.

Select AAddvvaanncceedd CCoonnttrrooll.

Select FFrreesshh CCoonnttrraasstt, FFrreesshh CCoolloorr,

NNooiissee RReedduuccttiioonn, or GGaammmmaa.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Select your desired options.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Color Temperature

FFMedium GG

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Auto

Gamma

Medium

Black Level

Medium

Real Cinema

Off

Medium

FF Off GG

PICTURE CONTROL

ADVANCED CONTROL - BLACK (DARKNESS) LEVEL

Adjusting the contrast and the brightness of the screen using the black level of the screen.

This feature is disable in DTV and RGB mode.

Select PPIICCTTUURREE.

Select AAddvvaanncceedd CCoonnttrrooll.

Select BBllaacckk LLeevveell.

ENTER

Select LLoowwor HHiigghh.

■LLooww: The reflection of the screen gets

darker.

■HHiigghh: The reflection of the screen gets

brighter.

■AAuuttoo: Realizing the black level of the

screen and set it to High or Low auto-

matically.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Medium

Off

Color Temperature

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Auto

Gamma

Medium

Black Level

Real Cinema

Off

FF Low GG

PICTURE CONTROL

ADVANCED CONTROL - REAL CINEMA

Set up the TV for the best picture appearance for viewing movies.

When you operate Real Cinema (3:2 Pull-Down Mode or Cinema Correction Mode), the TV will adjust 24 fps

video from movies to 30 fps video for display.

This feature operates only in TV (Analog TV/CATV, Digital DTV/CADTV), AV1, AV2, Component 480i/1080i,

and HDMI 480i, 1080i mode.

Select PPIICCTTUURREE.

Select AAddvvaanncceedd CCoonnttrrooll.

Select RReeaall CCiinneemmaa.

ENTER

Select OOnnor OOffff.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Color Temperature

FFMedium GG

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Auto

Gamma

Medium

Black Level

Medium

Real Cinema

Off

Medium

FF Off GG

PICTURE CONTROL

PICTURE RESET

Settings of the selected picture modes return to the default factory settings.

Select PPIICCTTUURREE.

Select RReesseett.

Initialize the adjusted value.

ENTER

Return to TV viewing.

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Contrast 50

• Brightness 50

• Sharpness 50

• Color 50

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Resetting video configuration...

SOUND & LANGUAGE CONTROL

AUTO VOLUME LEVELER (AUTO VOLUME)

Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a

regular TV program.

Select AAUUDDIIOO.

Select AAuuttoo VVoolluummee.

Select OOnnor OOffff.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

LR LR

Off

SOUND & LANGUAGE CONTROL

CLEAR VOICE

By differentiating the human sound range from others, it improves the sound quality of voices.

■If you select “CClleeaarr VVooiiccee--OOnn”, SSRRSS

TTrruuSSuurrrroouunndd XXTTfeature will not work.

Select AAUUDDIIOO.

Select CClleeaarr VVooiiccee.

Select OOnnor OOffff.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

LR LR

Off

SOUND &LANGUAGE CONTROL

SOUND & LANGUAGE CONTROL

PRESET SOUND SETTINGS (SOUND MODE)

Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate

sound options based on the program content.

SSttaannddaarrdd, MMuussiicc, CCiinneemmaa, SSppoorrtt, and GGaammeeare preset for optimum sound quality at the factory and are

not adjustable.

SOUND

Press the SSOOUUNNDDbutton repeatedly to select the sound options

: SSttaannddaarrdd, MMuussiicc, CCiinneemmaa, SSppoorrtt, and GGaammee.

■ You can also adjust SSoouunndd MMooddeein

the AAUUDDIIOOmenu.

Return to TV viewing.

RETURN

SSttaannddaarrdd

SOUND & LANGUAGE CONTROL

SOUND &LANGUAGE CONTROL

SOUND SETTING ADJUSTMENT - USER MODE

Adjust the sound to suit your taste and room situations.

Select AAUUDDIIOO.

Select SSoouunndd MMooddee.

Select TTrreebblleeor BBaassss.

ENTER

Select SSttaannddaarrdd, MMuussiicc,

CCiinneemmaa, SSppoorrtt, or GGaammee.

ENTER

Make appropriate adjustments.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

LR LR

Treble 50

Bass 50

SRS TruSurround XT

Off

Enter

Move

AUDIO

SOUND & LANGUAGE CONTROL

SRS TRUSURROUND XT

Select AAUUDDIIOO.

Select SSRRSS TTrruuSSuurrrroouunndd XXTT.

Select OOnnor OOffff.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Treble 50

Bass 50

SRS TruSurround XT

Off

FF Off GG

Takes advantage of any multi-channel format without needing to add extra speakers or equipment. Dialog

clarity, bass enrichment, and the addition of stereo audio enhancement produces an immersive sound experi-

ence from standard stereo material.

SOUND & LANGUAGE CONTROL

SOUND &LANGUAGE CONTROL

BALANCE

Select AAUUDDIIOO.

Select BBaallaannccee.

Make appropriate adjustments.

ENTER

Adjust the left/right sound of speaker to suit your taste and room situations.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

LR LR

Balance : 0 LR

SOUND & LANGUAGE CONTROL

TV SPEAKERS ON/OFF SETUP

Turn the TV speakers off if using external audio equipment.

Select AAUUDDIIOO.

Select TTVV SSppeeaakkeerr.

Select OOnnor OOffff.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

LR LR

Off

SOUND & LANGUAGE CONTROL

SOUND &LANGUAGE CONTROL

AUDIO RESET

Settings of the selected Sound Mode return to the default factory settings.

Select AAUUDDIIOO.

Select RReesseett.

ENTER

Initialize the adjusted value.

ENTER

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

LR LR

E E

Resetting audio configuration...

SOUND & LANGUAGE CONTROL

Each time you press the SSAAPPbutton,

MMoonnoo, SStteerreeoo, or SSAAPPappear in turn.

Return to TV viewing.

SAP

STEREO/SAP BROADCAST SETUP

For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accom-

panies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used

if the broadcast is only in Mono.

■If other languages available on the digital signal,

select them with the SSAAPPbutton.

RETURN

MONO SAPSTEREO

SOUND &LANGUAGE CONTROL

SOUND & LANGUAGE CONTROL

Enter

Move

OPTION

Enter

Move

OPTION

AUDIO LANGUAGE

Other languages may be available if a digital signal is provided by the broadcasting station.

This feature operates only in DTV/CADTV mode.

Select OOPPTTIIOONN.

Select LLaanngguuaaggee.

Select AAuuddiioo.

ENTER

Select your desired language:

EEnngglliisshh, SSppaanniisshh, or FFrreenncchh

RETURN

Return to the previous menu.

Return to TV viewing.

Language : English

Caption : Off

Menu English

Audio FFEnglish GG

Language : English

Caption : Off

SOUND & LANGUAGE CONTROL

Enter

Move

OPTION

Enter

Move

OPTION

ON-SCREEN MENUS LANGUAGE SELECTION

The menus can be shown on the screen in the selected language.

Select OOPPTTIIOONN.

Select LLaanngguuaaggee.

Select MMeennuu.

ENTER

Select your desired language.

From this point on, the on-screen menus

will be shown in the selected language.

RETURN

Return to the previous menu.

Return to TV viewing.

Language : English

Caption : Off

Language : English

Caption : Off

Menu FFEnglish GG

Audio English

SOUND & LANGUAGE CONTROL

SOUND &LANGUAGE CONTROL

CAPTION MODE

Caption must be provided to help people with hearing loss watch TV.

This feature operates only in TV, AV1-2 mode.

Select Caption OOnnor OOffff.

■When selecting OOffff, Sub-menus for

Analog, DTV, and Digital Option

become disabled.

Caption must be provided to help people with hearing loss watch TV. Select a caption mode for displaying cap-

tioning information if provided on a program. Analog caption displays information at any position on the screen

and is usually the program's dialog. Caption/Text, if provided by the broadcaster, would be available for both

digital and analog channels on the Antenna/Cable.

Analog Broadcasting System Captions

Select OOPPTTIIOONN.

Select CCaappttiioonn.

Select OOnn.

ENTER

Select CCCC11-44or TTeexxtt11-44.

■CCAAPPTTIIOONN

The term for the words that scroll

across the bottom of the TV screen;

usually the audio portion of the pro-

gram provided for the hearing impaired.

■TTEEXXTT

The term for the words that appear in a

large black frame and almost cover the

entire screen; usually messages provid-

ed by the broadcaster.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Mode CC1

Digital Option

Language : English

Caption : CC1

Enter

Move

OPTION

Language : English

Caption : Off

SOUND & LANGUAGE CONTROL

Digital Broadcasting System Captions

Choose the language you want the DTV/CADTV Captions to appear in.

Other Languages can be chosen for digital sources only if they are included on the program.

This function in only available when Caption Mode is set On.

Enter

Move

OPTION

Select OOPPTTIIOONN.

Select CCaappttiioonn.

Select OOnn.

ENTER

Select CCCC11-44, TTeexxtt11-44, or

SSeerrvviiccee11- 66.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Caption : CC1

Language : English

Caption : Off

Mode CC1

Digital Option

SOUND & LANGUAGE CONTROL

SOUND &LANGUAGE CONTROL

Enter

Move

OPTION

Caption Option

Customize the DTV/CADTV captions that appear on your screen.

This function in only available when Caption Mode is set On.

Select OOPPTTIIOONN.

Select CCaappttiioonn.

Select OOnn.

ENTER

Select CCuussttoomm.

ENTER

Customize the SSttyyllee, FFoonntt, etc., to your

preference. A preview icon is provided at

the bottom of the screen, use it to see the

caption language.

Select DDiiggiittaall OOppttiioonn.

■SSiizzee: Set the word size.

■FFoonntt: Select a typeface for the text.

■TTeexxtt CCoolloorr: Choose a color for the

text.

■TTeexxtt OOppaacciittyy: Specify the opacity

for the text color.

■BBgg ((BBaacckkggrroouunndd)) CCoolloorr: Select a

background color.

■BBgg ((BBaacckkggrroouunndd)) OOppaacciittyy: Select

the opacity for the background color.

RETURN

Return to the previous menu.

Return to TV viewing.

Size A Standard

Font Font 1

Text Color White

Text Opacity

Solid

Bg Color Black

Bg Opacity

Solid

FFCustom GG

Mode CC1

Digital Option

Enter

Move

OPTION

Language : English

Caption : Off

Language : English

Caption : CC1

TIME SETTING

CLOCK SETTING

TIME SETTING

Auto Clock Setup

The time is set automatically from a digital channel signal.

The digital channel signal includes information for the current time provided by the broadcasting station.

Set the clock manually if the current time is set incorrectly by the auto clock function.

Select TTIIMMEE.

Select CClloocckk.

Select AAuuttoo.

ENTER

Select your viewing area time zone.

: EEaasstteerrnn, CCeennttrraall, MMoouunnttaaiinn, PPaacciiffiicc,

AAllaasskkaa, or HHaawwaaiiii.

Select AAuuttoo, OOnn, or OOffff(depending on

whether or not your viewing area observes

Daylight Saving time).

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Year

Month 2

Date 21

Hour 2 AM

2008

Minute 10

Time Zone Eastern

Daylight

Saving Auto

FF Auto GG

TIME SETTING

Manual Clock Setup

If the current time setting is wrong, set the clock manually.

Select TTIIMMEE.

Select CClloocckk.

Select MMaannuuaall.

ENTER

Select the Year, Month, Date, Hour, or Minute option.

Set the Year, Month, Date, Hour, or Minute option.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Year

Month 2

Date 21

Hour 2 AM

2008

Minute 10

Time Zone Eastern

Daylight

Saving Auto

Manual

TIME SETTING

AUTO ON/OFF TIME SETTING

This function operates only if the current time has been set.

The OOffff TTiimmeefunction overrides the OOnn TTiimmeefunction if they are both set to the same time.

The TV must be in standby mode for the OOnn TTiimmeeto work.

Select TTIIMMEE.

Select OOffff TTiimmeeor OOnn TTiimmee.

Select RReeppeeaatt.

ENTER

Select OOffff, OOnnccee, EEvveerryyddaayy, MMoonn~FFrrii,

MMoonn~SSaatt, WWeeeekkeenndd, or SSuunnddaayy.

Select and set HHoouurror MMiinnuuttee.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : 6:30 AM (Once)

Sleep Timer : Off

Auto Sleep : Off

Repeat FF

Once

Hour 6 AM

Minute 30

TIME SETTING

SLEEP TIMER SETTING

The Sleep Time turns the TV off at the preset time.

Note that this setting is cleared when the TV is turned off.

Press the TTIIMMEERRbutton repeatedly to select the number of minutes.

Sleep timer options: Off, 10, 20, 30, 60, 90, 120, 180, and 240 minutes.

TIMER

RETURN

■ You can also adjust SSlleeeepp TTiimmeerrin the TTIIMMEE

menu.

10min

Return to TV viewing.

TIME SETTING

AUTO SHUT-OFF SETTING

TV will be automatically turned off, in case of no signal for 10 minutes.

Select TTIIMMEE.

Select AAuuttoo SSlleeeepp.

Select OOnnor OOffff.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off Off

TV will be automatically turned off,

in case of No Signal for 10 minutes.

PARENTAL CONTROL / RATINGS

PARENTAL CONTROL / RATING

Parental Control can be used to block specific channels, ratings and other viewing sources.

The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broad-

casting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the

type of the program and the categories. It is also possible to block all program viewing for a time period. To use

this function, the following must be done :

1. Set ratings and categories to be blocked.

2. Specify a password

3. Enable the lock

V-Chip rating and categories

Rating guidelines are provided by broadcasting stations. Most television programs and television movies can be

blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-to-

video movies use the Movie Rating System (MPAA)only.

Ratings for Television programs including made-for-TV movies :

■TV-G (General audience)

■TV-PG (Parental guidance suggested)

■TV-14 (Parents strongly cautioned)

■TV-MA (Mature audience only)

■TV-Y (All children)

■TV-Y7 (Children 7 years older)

Set up blocking schemes to block specific channels, ratings, and external viewing sources.

A password is required to gain access to this menu.

Setting up Your Password

Enter Password

** * *

Select LLOOCCKK.

ENTER

Input the password.

456

■Enter the password as requested.

■The TV is set up with the initial pass-

word “0-0-0-0”.

SET PASSWORD & LOCK SYSTEM

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

PARENTAL CONTROL / RATING

Enables or disables the blocking scheme you set up previously.

Lock System

Select LLoocckk SSyysstteemm.

Select OOnnor OOffff.

ENTER

■When you select OOnn, the Lock System

is enable.

Select LLOOCCKK.

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : On

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Off

PARENTAL CONTROL / RATING

PARENTAL CONTROL /RATINGS

Change the password by inputting a new password twice.

Set Password

Select SSeett ppaasssswwoorrdd.

Choose any 4 digits for your new password.

As soon as the 4 digits are entered, re-enter

the same 4 digits on the CCoonnffiirrmm.

ENTER

456

Select LLOOCCKK.

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

New ** * *

Confirm * * * *

PARENTAL CONTROL / RATING

CHANNEL BLOCKING

Select BBlloocckk CChhaannnneell.

Select a channel to block or unblock.

ENTER

Block or unblock a channel.

ENTER

Blocks any channels that you do not want to watch or that you do not want your children to watch.

Select LLOOCCKK.

ENTER

Input the password.

456

Return to the previous menu.

RETURN

Return to TV viewing.

Block/Unblock Move Page

Move Previous RETURN EXIT

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block +

PARENTAL CONTROL / RATING

PARENTAL CONTROL /RATINGS

MOVIE & TV RATING

Movie Rating (MPAA)

Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can

set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that

the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.

Select MMoovviiee RRaattiinngg.

Select GG, PPGG, PPGG--1133, RR, NNCC--1177,

XX, or BBlloocckkiinngg OOffff.

ENTER

■G (General audience)

■PG (Parental guidance suggested)

■PG-13 (Parents strongly cautioned)

■R (Restricted)

■NC-17 (No one 17 and under admitted)

■X (Adult only)

■Blocking Off (Permits all programs)

GGIf you set PG-13: G and PG movies will

be available, PG-13, R, NC-17 and X will

be blocked.

Select LLOOCCKK.

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

PG-13

NC-17

Blocking Off

Blocking off : Permits all

programs

PARENTAL CONTROL / RATING

Select TTVV RRaattiinngg--CChhiillddrreenn.

Select AAggeeor FFaannttaassyy VViioolleennccee.

ENTER

Select block options.

■Age (applies to TV-Y, TV-Y7)

■Fantasy Violence (applies to TV-Y7)

TV Rating Children

Prevents children from watching certain children's TV programs, according to the ratings limit set. The children

rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audi-

ences in the TV Rating - sub menu, your children can view those programs.

Select LLOOCCKK.

ENTER

Input the password.

456

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Age GG

Fantasy Violence

PARENTAL CONTROL / RATING

TV Rating General

Based on the ratings, blocks certain TV programs that you and your family do not want to view.

Select AAggee, DDiiaalloogguuee, LLaanngguuaaggee,

SSeexxor VViioolleennccee.

ENTER

Select block options.

■Age (applies to TV-G,TV-PG,TV-14,TV-

MA).

■Dialogue-sexual dialogue (applies to

TV-PG,TV-14).

■Language-adult language (applies to

TV-PG, TV-14, TV-MA).

■Sex-sexual situations (applies to TV-PG,

TV-14, TV-MA).

■Violence (applies to TV-PG, TV-14, TV-

MA).

Select LLOOCCKK.

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Age GG

Dialogue

Language

Sex

Violence

PARENTAL CONTROL /RATINGS

PARENTAL CONTROL / RATING

DOWNLOADABLE RATING

■Based on rating table, your TV's OSD

(On Screen Display) may differ slightly

from what is shown in this manual.

This function may become available in the future and will be available only for digital channels.

This function operates only when TV has received Region5 Rating data.

Select DDoowwnnllooaaddaabbllee RRaattiinngg.

Select desired DDoowwnnllooaaddaabbllee

RRaattiinngg option.

ENTER

Select desired option and block it.

ENTER

Select LLOOCCKK.

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Humor

Sport

Cruelty

Language

Sadness

Genre

Age

PARENTAL CONTROL /RATINGS

EXTERNAL INPUT BLOCKING

Enables you to block an input.

Select IInnppuutt BBlloocckk.

Select input source.

Select OOnnor OOffff.

ENTER

Select LLOOCCKK.

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

AV FF

Off

HDMI

PARENTAL CONTROL / RATING

APPENDIX

TROUBLESHOOTING

TThhee vviiddeeoo ffuunnccttiioonn ddooeess nnoott wwoorrkk..

No picture &No sound

No or poor color

or poor picture

Poor reception on

some channels

Lines or streaks

in pictures

No picture

when connecting HDMI

Horizontal/vertical bars

or picture shaking

Picture appears slowly

after switching on

The remote control

doesn’t work

Power is suddenly

turned off

■Check to see if there is any object between the product and the remote control

causing obstruction. Ensure you are pointing the remote control directly at the TV.

■Ensure that the batteries are installed with correct polarity (+ to +, - to -).

■Ensure that the correct remote operating mode is set: TV, VCR etc.

■Install new batteries.

■Is the sleep timer set?

■Check the power control settings. Power interrupted.

■Check whether the product is turned on.

■Try another channel. The problem may be with the broadcast.

■Is the power cord inserted into wall power outlet?

■Check your antenna direction and/or location.

■Test the wall power outlet, plug another product’s power cord into the outlet

where the product’s power cord was plugged in.

■This is normal, the image is muted during the product startup process. Please

contact your service center, if the picture has not appeared after five minutes.

■Adjust Color in menu option.

■Try unplugging any others electronics that are near by to see if interference is

causing the problem.

■Try another channel. The problem may be with the broadcast.

■Are the video cables installed properly?

■Activate any function to restore the brightness of the picture.

■Check for local interference such as an electrical appliance or power tool.

■Station or cable product experiencing problems, tune to another station.

■Station signal is weak, reorient antenna.

■Check for sources of possible interference.

■Check antenna (Change the direction of the antenna).

■Check HDMI cable over version 1.3.

If the HDMI cables don’t support HDMI version 1.3, it can cause flickers or no

screen display. In this case use the latest cables that support HDMI version 1.3.

TThhee ooppeerraattiioonn ddooeess nnoott wwoorrkk nnoorrmmaallllyy..

APPENDIX

APPENDIXAPPENDIX

TThheerree iiss aa pprroobblleemm iinn PPCC mmooddee.. ((OOnnllyy PPCC mmooddee aapppplliieedd))

■Adjust resolution, horizontal frequency, or vertical frequency.

■Check the input source.

■Run the Auto configure or adjust clock, phase, or H/V position. (Option)

■Check the signal cable.

■Update video card drivers.

The signal is out of range

Screen color is unstable

or single color

Vertical bar or stripe on

background &

Horizontal Noise &

Incorrect position

Picture OK but No sound

Unusual sound from

inside the product

No sound

when connecting HDMI

or USB

No output from one

of the speakers

TThhee aauuddiioo ffuunnccttiioonn ddooeess nnoott wwoorrkk..

■Press the VOL or VOLUME button.

■Sound muted? Press the MUTE button.

■Try another channel. The problem may be with the broadcast.

■Are the audio cables installed properly?

■Adjust Balance in menu option.

■A change in ambient humidity or temperature may result in an unusual noise

when the product is turned on or off and does not indicate a fault with the

product.

■Check HDMI cable over version 1.3.

■Check USB cable over version 2.0.

*This feature is not available for all models.

APPENDIX

■The specifications shown above may be changed without prior notice for quality improvement.

PRODUCT SPECIFICATIONS

MAINTENANCE

Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can

enjoy your new TV.

Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.

Cleaning the Screen

Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm

water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then

use it to wipe the screen.

Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.

GG If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug

the power cord to protect against possible damage from lightning or power surges.

CAUTION

GGDo not use window/glass cleaner or anything with ammonia to clean the screen.

WARNING

Cleaning the Cabinet

■To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.

■Please be sure not to use a wet cloth.

Extended Absence

MODEL

NTSC-M, VSB, 64 & 256 QAM

VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135

75 ohm

32 ~ 104°F (0 ~40°C)

Less than 80%

-4 ~ 140°F (-20 ~60°C)

Less than 85%

Dimensions

(Width x Height

x Depth)

Weight

Power requirement

Television System

Program Coverage

External Antenna Impedance

Environment

condition

With stand

Without stand

With stand

Without stand

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

26LG3DCH

(26LG3DCH-UA)

26.1 x 17.6 x 3.1 inches

663.3 x 449.8 x 80.0 mm

18.9 pounds / 8.6 kg

AC120V ~50/60Hz

31.5 x 21.4 x 4.2 inches

801.8 x 544.4 x 109 mm

26.2 pounds / 11.9 kg

AC120V ~50/60Hz

32LG3DCH

(32LG3DCH-UA)

APPENDIX

■

Configuration of frame

1st frame

Repeat frame

■

Lead code

■

Repeat code

■BBiitt ddeessccrriippttiioonn

■FFrraammee iinntteerrvvaall:: TTff

The waveform is transmitted as long as a key is depressed.

C0 C1 C2 C3 C4 C5 C6 C7 C0 C1 C2 C3 C4 C5 C6 C7 D0 D1 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7

Lead code Low custom code High custom code Data code Data code

Repeat code Tf

4.5 ms

9 ms

2.25 ms

9 ms

0.55 ms

0.56 ms

1.12 ms

0.56 ms

2.24 ms

Tf Tf

Tf=108ms @455KHz

Bit ”0” Bit ”1”

1. How to Connect

■Connect your wired remote control to the Remote Control port on the TV.

2. Remote Control IR Codes

■

Output waveform

Single pulse, modulated with 37.917KHz signal at 455KHz

Carrier frequency

FCAR = 1/TC = fOSC/12

Duty ratio = T1/TC = 1/3

IR CODES

APPENDIX

Code Function Note

(Hexa)

08 POWER

Remote control Button (Power On/Off)

0F TV

Remote control Button

0B INPUT Remote control Button

4D PICTURE Remote control Button

52 SOUND Remote control Button

0A SAP Remote control Button

79 RATIO Remote control Button

10-19 Number Key 0-9 Remote control Button

4C - (Dash) Remote control Button

1A FLASHBK Remote control Button

02 VOL + Remote control Button

03 VOL - Remote control Button

00 CH + Remote control Button

01 CH - Remote control Button

0E TIMER Remote control Button

39 CC Remote control Button

09 MUTE Remote control Button

CB ADJUST Remote control Button

43 MENU Remote control Button

5B RETURN Remote control Button

40 Remote control Button

41 Remote control Button

07 Remote control Button

06 Remote control Button

44 ENTER Remote control Button

Code Function Note

(Hexa)

D6 TV Discrete IR Code

(TV Input Selection)

5A AV1

Discrete IR Code

(AV1 Input Selection)

BF COMPONENT

Discrete IR Code

(

COMPONENT

Input Selection)

D5 RGB

Discrete IR Code

(

RGB

Input Selection)

CE HDMI1

Discrete IR Code

(

HDMI1

Input Selection)

76 Ratio 4:3

Discrete IR Code

(

Only 4:3 Mode

)

77 Ratio 16:9

Discrete IR Code

(

Only 16:9 Mode

)

AF Ratio Zoom

Discrete IR Code

(

Only Zoom1 Mode

)

C4 POWER ON

Discrete IR Code

(

Only Power On

)

C5 POWER OFF

Discrete IR Code

(

Only Power Off)

LG Electronics USA 22LG3DCHUA LCD TV/MONITOR User Manual 22LG3DCH Edit1 en

LG Electronics USA LCD TV/MONITOR 22LG3DCH Edit1 en

User manual

Navigation menu

Namespaces

Views

Navigation
