Please read this manual carefully before operating your set
and retain it for future reference.
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.
84LM9600-UB
P/NO : MFL67652637 (1312-REV00)
*MFL67652637*
ENGLISH
2IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
y Do not use this apparatus near water.
y Clean only with a dry cloth.
y Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
y Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
y Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet (Can differ by
country).
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
WARNING
If you ignore the warning message, you may be
seriously injured or there is a possibility of accident
or death.
CAUTION
If you ignore the caution message, you may be
slightly injured or the product may be damaged.
NOTE
The note helps you understand and use the
product safely. Please read the note carefully
before using the product.
WARNING: This product contains chemicals known to
the State of California to cause cancer and birth defects
or other reproductive harm.
:DVKKDQGVDIWHUKDQGOLQJ
ENGLISH
3
IMPORTANT SAFETY INSTRUCTIONS
y Do not press strongly upon the panel with a hand
or a sharp object such as a nail, pencil or pen, or
make a scratch on it.
y Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
y Only use attachments/accessories specified by
the manufacturer.
y Use only with a cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
y Unplug this apparatus during lightning storms or
when unused for long periods of time.
y Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
y Do not stick metal objects or any other conductive
material into the power cord. Do not touch the
end of the power cord while it is plugged in.
y Keep the packing anti-moisture material or vinyl
packing out of the reach of children. Anti-moisture
material is harmful if swallowed. If swallowed
by mistake, force the patient to vomit and visit
the nearest hospital. Additionally, vinyl packing
can cause suffocation. Keep it out of the reach of
children.
y CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be placed
upon a dedicated circuit; that is, a single outlet
circuit which powers only that appliance and
has no additional outlets or branch circuits.
Check the specification page of this owner’s
manual to be certain. Do not connect too many
appliances to the same AC power outlet as
this could result in fire or electric shock. Do not
overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked wire
insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically
examine the cord of your appliance, and if its
appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and
have the cord replaced with an exact replacement
part by an authorized service. Protect the power
cord from physical or mechanical abuse, such
as being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord
exits the appliance. Do not move the TV with the
power cord plugged in. Do not use a damaged
or loose power cord. Be sure do grasp the plug
when unplugging the power cord. Do not pull on
the power cord to unplug the TV.
y Warning - To reduce the risk of fire or electrical
shock, do not expose this product to rain,
moisture or other liquids. Do not touch the TV
with wet hands. Do not install this product near
flammable objects such as gasoline or candles, or
expose the TV to direct air conditioning.
ENGLISH
4IMPORTANT SAFETY INSTRUCTIONS
y Do not expose to dripping or splashing and do
not place objects filled with liquids, such as
vases, cups, etc. on or over the apparatus (e.g. on
shelves above the unit).
y Grounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground wire to
prevent possible electric shock (i.e. a TV with a
three-prong grounded AC plug must be connected
to a three-prong grounded AC outlet). If grounding
methods are not possible, have a qualified
electrician install a separate circuit breaker. Do
not try to ground the unit by connecting it to
telephone wires, lightening rods, or gas pipes.
Short-circuit
Breaker
Power Supply
y As long as this unit is connected to the AC wall
outlet, it is not disconnected from the AC power
source even if the unit is turned off.
y Do not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product.
y Outdoor Antenna Grounding
(Can differ by country):
If an outdoor antenna is installed, follow the
precautions below. An outdoor antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can come in contact with
such power lines or circuits as death or serious
injury can occur. Be sure the antenna system
is grounded to provide some protection against
voltage surges and built-up static charges. Section
810 of the National Electrical Code (NEC) in the
U.S.A. provides information with respect to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to
grounding electrodes and requirements for the
grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Ground Clamp
Grounding Conductor
(NEC Section 810-21)
Antenna Lead in Wire
Electric Service
Equipment
Antenna Discharge Unit
(NEC Section 810-20)
Ground Clamp
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
NEC: National Electrical Code
y Cleaning
When cleaning, unplug the power cord and wipe
gently with a soft cloth to prevent scratching. Do
not spray water or other liquids directly on the TV
as electric shock may occur. Do not clean with
chemicals such as alcohol, thinners, or benzine.
y Moving
Make sure the product is turned off, unplugged,
and all cables have been removed. It may take 2
or more people to carry larger TVs. Do not press
or put stress on the front panel of the TV.
y Ventilation
Install your TV where there is proper ventilation. Do
not install in a confined space such as a bookcase.
Do not cover the product with cloth or other
materials while plugged. Do not install in excessively
dusty places.
y If you smell smoke or other odors coming from
the TV, unplug the power cord and contact an
authorized service center.
y Keep the product away from direct sunlight.
y Never touch this apparatus or antenna during a
thunder or lightning storm.
y When mounting a TV on the wall, make sure not
to install the TV by hanging the power and signal
cables on the back of the TV.
y Do not allow an impact shock or any objects to fall
into the product, and do not drop anything onto
the screen.
y Disconnecting the Main Power
The power outlet used with this device must
remain easily accessible.
y Store the accessories (battery, etc.) in a safe
location out of the reach of children.
y This apparatus use batteries. In your community
there might be regulations that require you
to dispose of these batteries properly due to
environmental considerations. Please contact
your local authorities for disposal or recycling
information.
y Do not dispose of batteries in a fire.
y Do not short circuit, disassemble, or allow the
batteries to overheat.
ENGLISH
5
IMPORTANT SAFETY INSTRUCTIONS
y Dot Defect
The Plasma or LCD panel is a high technology product
with resolution of two million to six million pixels. In a
very few cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots are deactivated
pixels and do not affect the performance and reliability
of the TV.
y Generated Sound
Cracking noise: A cracking noise that occurs when
watching or turning off the TV is generated by plastic
thermal contraction due to temperature and humidity.
This noise is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A low level
noise is generated from a high-speed switching circuit,
which supplies a large amount of current to operate a
product. It varies depending upon the product.
This generated sound does not affect the performance
and reliability of the product.
y Take care not to touch the ventilation openings. When
watching the TV for a long period, the ventilation
openings may become hot. This does not affect the
performance of the product or cause defects in the
product.
y Do not install this product on a wall if it could be
exposed to oil or oil mist. This may damage the product
and cause it to fall.
y If the TV feels cold to the touch, there may be a small
flicker when it is turned on. This is normal, there is
nothing wrong with TV. Some minute dot defects may
be visible on the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse effect on
the TV’s performance. Avoid touching the LCD screen
or holding your finger(s) against it for long periods of
time. Doing so may produce some temporary distortion
effects on the screen.
Preventing Image burn or Burn-in on
your TV screen
y If a fixed image displays on the TV screen for
a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is image burn or burn-in and not
covered by the warranty.
y If the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on the
letterboxed area of the screen.
y Avoid displaying a fixed image on the TV screen
for a long period of time (2 or more hours for LCD,
1 or more hours for the Plasma TV) to prevent
image burn.
For USA and Canada
FCC NOTICE
y This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there
is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment
off and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
y - Reorient or relocate the receiving antenna.
y - Increase the separation between the
equipment and the receiver.
y - Connect the equipment to an outlet on
a circuit different from that to which the
receiver is connected.
y - Consult the dealer or an experienced radio/
TV technician for help.
y This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation of the device.
Any changes or modifications in construction
of this device which are not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
NOTE TO CABLE/TV INSTALLER
y This reminder is provided to call the CATV
system installer’s attention to Article 820-
40 of the National Electric Code (U.S.A.).
The code provides guidelines for proper
grounding and, in particular, specifies that
the cable ground shall be connected to the
grounding system of the building, as close to
the point of the cable entry as practical.
ENGLISH
6IMPORTANT SAFETY INSTRUCTIONS
Viewing 3D Imaging
WARNING
Viewing Environment
y Viewing Time
- When watching 3D content, take 5 - 15
minute breaks every hour. Viewing 3D
content for a long period of time may
cause headache, dizziness, fatigue or eye
strain.
Those that have a photosensitive seizure
or chronic illness
y Some users may experience a seizure or
other abnormal symptoms when they are
exposed to a flashing light or particular
pattern from 3D content.
y Do not watch 3D videos if you feel
nauseous, are pregnant and/ or have a
chronic illness such as epilepsy, cardiac
disorder, or blood pressure disease, etc.
y 3D Content is not recommended for those
who suffer from stereo blindness or stereo
anomaly. Double images or discomfort in
viewing may be experienced.
y If you have strabismus (cross-eyed),
amblyopia (weak eyesight) or astigmatism,
you may have trouble sensing depth and
easily feel fatigue due to double images.
It is advised to take more frequent breaks
than the average adult.
y If your eyesight varies between your right
and left eye, revise your eyesight prior to
watching 3D content.
Symptoms which require discontinuation
or refraining from watching 3D content
y Do not watch 3D content when you feel
fatigue from lack of sleep, overwork, or
intoxication.
y When these symptoms are experienced,
stop using/watching 3D content and get
enough rest until the symptom subsides.
- Consult your doctor when the symptoms
persist. Symptoms may include headache,
eyeball pain, dizziness, nausea, palpitation,
blurriness, discomfort, double image, visual
inconvenience, or fatigue.
CAUTION
Viewing Environment
y Viewing Distance
- Maintain a distance of at least twice the
screen diagonal length when watching 3D
content. If you feel discomfort in viewing
3D content, move further away from the
TV.
Viewing Age
y Infants / Children
- Usage/ Viewing 3D content for children
under the age of 5 are prohibited.
- Children under the age of 10 may
overreact and become overly excited
because their vision is in development
(for example: trying to touch the screen or
trying to jump into it. Special monitoring
and extra attention is required for children
watching 3D content.
- Children have greater binocular disparity of
3D presentations than adults because the
distance between the eyes is shorter than
one of adults. Therefore they will perceive
more stereoscopic depth compared to
adults for the same 3D image.
y Teenagers
- Teenagers under the age of 19 may be
stimulated to light coming from 3D videos.
Advise them not to watch 3D videos for a
long time when they are tired.
y Elderly
- The elderly may perceive less of a 3D
effect than the youth. Do not sit closer to
the TV than the recommended distance.
Cautions when using the 3D glasses
y Only use LG 3D glasses. Otherwise,
you may not be able to view 3D videos
properly.
y Do not use 3D glasses instead of your
normal glasses, sunglasses, or protective
goggles.
y Using modified 3D glasses may cause eye
strain or image distortion.
y Do not keep your 3D glasses in extremely
high or low temperatures. It will cause
deformation.
y The 3D glasses are fragile and are easy to
scratched. Use a soft, clean piece of cloth
when wiping the lenses. Do not scratch
the lenses of the 3D glasses with sharp
objects or clean/wipe them with chemicals.
ENGLISH
7
LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the
double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that
plays DivX video. Visit divx.com for more information and software tools to
convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete
your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium
content.”
“DivX®, DivX Certified® and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380;
6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the
Symbol & DTS and the Symbol together are registered trademarks & DTS
2.0+Digital Out is a trademark of DTS, Inc. Product includes software. ©
DTS, Inc. All Rights Reserved.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in
this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost
of performing such distribution (such as the cost of media, shipping and handling) upon email request
to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased
the product.
ENGLISH
8TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
6 Viewing 3D Imaging
7 LICENSES
7 OPEN SOURCE SOFTWARE NOTICE
8 TABLE OF CONTENTS
9 INSTALLATION PROCEDURE
9 ASSEMBLING AND PREPARING
9 Unpacking
11 Optional Extras
12 Parts and Buttons
13 Lifting and Moving the TV
14 Setting up the TV
14 - Attaching the Stand
15 - Mounting on a Table
16 - Tidying cables
17 - Mounting on a Wall
18 MAKING CONNECTIONS
18 Connecting to an Antenna or Cable
19 Connecting to a HD receiver, DVD Player or
VCR
19 - HDMI Connection
20 - DVI to HDMI Connection
21 - Connecting to a Mobile Phone
22 - Component Connection
23 - Composite Connection
24 Connecting a PC
24 - HDMI Connection or DVI to HDMI
Connection
26 Connecting to an Audio System
26 - Digital Optical Audio Connection
27 Connecting a USB Device
28 MAGIC REMOTE CONTROL
FUNCTIONS
29 Registering Magic Remote Control
29 How to use Magic Remote Control
29 Precautions to Take when Using the Magic
Remote Control
30 WATCHING TV
30 Turning the TV on for the First Time
31 USING THE USER GUIDE
32 SPECIFICATIONS
36 MAINTENANCE
36 Cleaning Your TV
36 - Screen, Frame, Cabinet, and Stand
36 - Power Cord
36 TROUBLESHOOTING
TABLE OF CONTENTS
y Image shown may differ from your TV.
y Your TV’s OSD (On Screen Display) may
differ slightly from that shown in this
manual.
y The available menus and options may
differ from the input source or product
model that you are using.
y New features may be added to this TV in
the future.
NOTE
ENGLISH
9
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
4 Make sure the network connection is available.
You can use the TV network functions only when the network connection is made.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
y Do not use any unapproved items to ensure the safety and product life span.
y Any damages or injuries by using unapproved items are not covered by the warranty.
y Some models appear to have a thin film on the screen. It is actually part of the screen; do not
remove it.
CAUTION
y The items supplied with your product may vary depending upon the model.
y Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
y For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
(0.39 inches) thick and 18 mm (0.7 inches) width.
y Use an extension cable that supports USB 2.0 if the USB cable or USB FLASH DRIVE does not
fit into your TV’s USB port.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
NOTE
ENGLISH
10 ASSEMBLING AND PREPARING
Magic Remote Control,
Batteries (AA)
(See p. 28)
Owner’s Manual Cinema 3D Glasses
The number of 3D glasses
may differ depending upon
the model or country.
Stand Body / Stand Base
(See p. 14)
Stand Screws
4 EA, M4 x 20
6 EA, M5 x 16
(See p. 14)
Cable Holder
(See page 16.)
Component Video Cable
(See p. 22)
Composite Video Cable
(See p. 22, 23)
ENGLISH
11
ASSEMBLING AND PREPARING
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer to buy these items.
These devices only work with certain models.
The model name or design may be changed manufacturer’s circumstances or policies.
AN-MR400
Magic Remote
AG-F***
Cinema 3D Glasses
AG-F***DP
Dual Play Glasses
Tag On
LG Audio Device Tag On
ENGLISH
12 ASSEMBLING AND PREPARING
Parts and Buttons
Button Description
/ ( / ) Scrolls through the saved channels.
/ ( / ) Adjusts the volume level.
(OK ) Selects the highlighted menu option or confirms an input.
(SETTINGS)Accesses the main menus, or saves your input and exits the menus.
(INPUT)Changes the input source.
( ) Turns the power on or off.
SETTINGS
INPUT
OK
Screen
Logo light
Buttons
Remote control sensor
Speakers
ENGLISH
13
ASSEMBLING AND PREPARING
Lifting and Moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless
of its type and size.
y Avoid touching the screen at all times, as
this may result in damage to the screen.
y Do not place the product on the floor with
its front facing down. Doing so may result
in damage to the screen.
CAUTION
y Hold the top and bottom of the TV
frame firmly. Make sure not to hold the
transparent part, speaker, or speaker grill
area.
y It is recommended to move the TV in
the box or packing material that the TV
originally came in.
y Before moving or lifting the TV, disconnect
the power cord and all cables.
y When holding the TV, the screen should
face away from you to avoid damage.
y When transporting a large TV, there should
be at least 2 people.
y When transporting the TV by hand, hold the
TV as shown in the following illustration.
y When transporting the TV, do not expose
the TV to jolts or excessive vibration.
y When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
ENGLISH
14 ASSEMBLING AND PREPARING
Setting up the TV
You can mount your TV to a wall or attach the stand if you wish to place the TV on an entertainment
center or other furniture.
Attaching the Stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
y When attaching the stand to the TV set, place the screen facing down on a cushioned table or
flat surface to protect the screen from scratches.
y Make sure that the screws are fastened tightly. (If they are not fastened securely enough, the
TV may tilt forward after being installed.)
y Do not tighten the screws with too much force; otherwise they may be damaged and come
loose later.
CAUTION
y Remove the stand before installing the TV on a wall mount by performing the stand attachment
in reverse.
NOTE
1
2
3
Front
Stand Base
Stand Body
Front
M5 x 16
6 EA
4
M4 x 20
4 EA
ENGLISH
15
ASSEMBLING AND PREPARING
Mounting on a Table
1 Lift and tilt the TV into its upright position on
a table.
- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2 Connect the power cord to a wall outlet.
y Do not place the TV near or on sources
of heat, as this may result in fire or other
damage.
CAUTION
Adjusting the angle of the TV to suit view
Swivel 7 degrees to the left or right and adjust
the angle of the TV to suit your view.
7˚
7˚
y When adjusting the angle of the TV, watch
out for your fingers.
y Personal injury may occur if hands or
fingers are pinched. If the product is tilted
too much, it may fall, causing damage or
injury.
Rear Front
CAUTION
ENGLISH
16 ASSEMBLING AND PREPARING
Tidying cables
y Do not move the TV by holding the cable
holder and cable management, as the
cable holders may break, and injuries and
damage to the TV may occur.
CAUTION
1 Gather and bind the cables with the Cable
Management.
2 Gather and bind the cables with the Cable
Holder.
Cable
Management
Cable Holder
Securing the TV to a wall (optional)
1 Insert and tighten the eye-bolts, or TV
brackets and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2 Mount the wall brackets with the bolts to
the wall.
Match the location of the wall bracket and
the eye-bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets
tightly with a sturdy rope.
Make sure to keep the rope horizontal with
the flat surface.
y Make sure that children do not climb on or
hang on the TV.
CAUTION
y Use a platform or cabinet that is strong
and large enough to support the TV
securely.
y Brackets, bolts, and ropes are optional.
You can obtain additional accessories from
your local dealer.
NOTE
ENGLISH
17
ASSEMBLING AND PREPARING
Mounting on a Wall
An optional wall mount can be used with your
LG Television. Consult with your local dealer for
a wall mount that supports the VESA standard
used by your TV model. Carefully attach the wall
mount bracket at the rear of the TV. Install the
wall mount bracket on a solid wall perpendicular
to the floor. If you are attaching the TV to other
building materials, please contact qualified
personnel to install the wall mount. Detailed
instructions will be included with the wall mount.
We recommend that you use an LG brand wall
mount.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mounts that
meet the VESA standard. Standard dimensions
for the wall mount kits are described in the
following table.
Model 84LM9600-UB
VESA (A x B)
A
B
600 x 400
Standard screw M8
Number of screws 4
Wall mount bracket
(optional)
LSW630B
(4 inches)
Wall mount bracket (optional)
LSW630B
y Disconnect the power before moving or
installing the TV. Otherwise electric shock
may occur.
y If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and
contact the local dealer or qualified
personnel.
y Do not over tighten the screws as this
may cause damage to the TV and void
your warranty.
y Use the screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.
CAUTION
y Use the screws that are listed in the VESA
standard screw specifications.
y The wall mount kit includes an installation
manual and necessary parts.
y The wall mount bracket is optional. You
can obtain additional accessories from
your local dealer.
y The length of screws may differ depending
upon the wall mount. Make sure to use
the proper length.
y For more information, refer to the manual
supplied with the wall mount.
NOTE
ENGLISH
18 MAKING CONNECTIONS
MAKING CONNECTIONS
You can connect various external devices to the TV. Supported external devices are: HD receivers,
DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external
devices. For more information on external device’s connection, refer to the manual provided with
each device.
y If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For more information of recording, refer to the
manual provided with the connected device.
y The external device connections shown may differ slightly from illustrations in this manual.
y Connect external devices to the TV regardless of the order of the TV port.
y If you connect a gaming device to the TV, use the cable supplied with the gaming device.
y Refer to the external equipment’s manual for operating instructions.
NOTE
Connecting to an Antenna or Cable
Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations
may differ from the actual items and a RF cable is optional.
y Make sure not to bend the copper wire of
the RF cable.
Copper wire
y Complete all connections between
devices, and then connect the power cord
to the power outlet to prevent damage to
your TV.
CAUTION
(*Not Provided)
Antenna
Coaxial (75Ω)
Terminal
y Use a signal splitter to use more than 2
TVs.
y DTV Audio Supported Codec: MPEG,
Dolby Digital.
y Display of Ultra HD (3840 x 2160 pixels)
content compatible; additional device
capable of processing Ultra HD source
content (in 2D or 3D) may be required and
will be sold separately.
NOTE
VHF Antenna
UHF Antenna
ENGLISH
19
MAKING CONNECTIONS
Connecting to a HD receiver, DVD Player or VCR
Connect a HD receiver, DVD Player, or VCR to the TV and select an appropriate input mode.
HDMI Connection
HDMI is the best way to connect a device.
Transmits digital video and audio signals from an external device to the TV. Connect the external
device and the TV with the HDMI cable as shown in the following illustration.
y Use the latest High Speed HDMI™ Cable that supports CEC (Customer Electronics Control)
function.
y High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
y HDMI Audio Supported Format: PCM (Up to 192 kHz, 32 kHz / 44.1 kHz / 48 kHz / 88 kHz /
96 kHz / 176 kHz / 192 kHz)
NOTE
ARC (Audio Return Channel)
y When connected with a high-speed HDMI cable,
digital audio can be sent to a compactible device
without an additional optical audio cable.
y ARC is only supported on the HDMI/DVI IN 1
(ARC) port. An external audio device that supports
ARC should be connected to HDMI/DVI IN 1 if
you wish to use ARC.
HDMI
DVD / Blu-Ray / HD Cable Box / HD STB
(*Not Provided)
Choose any HDMI input port to connect.
It does not matter which port you use.
ENGLISH
20 MAKING CONNECTIONS
AUDIO OUT
DVI OUT
DVI to HDMI Connection
Transmits the digital video signal from an external device to the TV. Connect the external device and
the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal,
connect an audio cable.
Choose any HDMI input port to connect.
It does not matter which port you use.
y When using the HDMI/DVI cable, Single link only is supported.
NOTE
(*Not Provided)
(*Not Provided)
DVD / Blu-Ray / HD Cable Box
YELLOW
ENGLISH
21
MAKING CONNECTIONS
Connecting to a Mobile Phone
Mobile High-definition Link (MHL) is an interface for transmitting digital audio/visual signals from
mobile phones to television sets.
y Connect the mobile phone to the HDMI/DVI IN 3 (MHL) port to view the phone screen on the TV.
y This only works with an MHL-enabled phone.
y With some MHL supporting mobile phones, you can use the TV remote to control the phone.
y An MHL passive cable is needed to connect the TV and a mobile phone.
y Remove the MHL cable from the TV when:
- the MHL function is disabled
- your mobile device is fully charged in standby mode
NOTE
3
(MHL)
(*Not Provided)
MHL Cable
Mobile phone
ENGLISH
22 MAKING CONNECTIONS
Component Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external
device and the TV with a component cable as shown in the following illustration.
y If cables are installed incorrectly, it could cause the image to display in black and white or with
distorted color.
y Check to ensure the cables are matched with the corresponding color connection.
NOTE
IN
COMPONENT
AV
VIDEO AUDIO
Y
P
B
P
R
VIDEO
AUDIO
LR
GREEN
BLUE
RED
RED
WHITE
GREEN
YELLOW
YELLOW
WHITE
RED
GREEN
BLUE
RED
WHITE
RED
GREEN
BLUE
RED
(Use the composite video cable provided.) (Use the component video cable provided.)
DVD / Blu-Ray / HD Cable Box
(*Not Provided)(*Not Provided)
ENGLISH
23
MAKING CONNECTIONS
Composite Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown in the following illustration.
IN
COMPONENT
AV
VIDEO AUDIO
Y
P
B
P
R
VIDEO
MONO
( )
AUDIOLR
RED
WHITE
YELLOW
WHITE
RED
WHITE
RED
YELLOW YELLOW
YELLOW
(Use the composite video cable provided.)
y If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of
the TV.
y Check to ensure the cables are matched with the corresponding color connection.
NOTE
VCR / DVD / Blu-Ray / HD Cable Box
(*Not Provided)
ENGLISH
24 MAKING CONNECTIONS
Connecting a PC
y It is recommended to use an HDMI connection for the best image quality.
y Depending upon the graphics card, DOS mode video may not work if a HDMI to DVI Cable
is in use.
y In PC mode, there may be noise associated with the resolution, vertical pattern, contrast, or
brightness. If noise is present, change the PC output to another resolution, change the refresh
rate to another rate or adjust the brightness and contrast on the PICTURE menu until the picture
is clear.
y The synchronization input form for Horizontal and Vertical frequencies is separate.
y Depending upon the graphics card, some resolution settings may not allow the image to be
positioned on the screen properly.
y If you are using DVI out from a PC, you have to connect analog audio separately. Refer to the
instructions on the next page.
y When using the HDMI/DVI cable, Single link is only supported.
NOTE
HDMI Connection or DVI to HDMI Connection
Choose method A or B to make connection.
Method A: HDMI Connection
HDMI
(*Not Provided)
PC
Choose any HDMI input port to connect.
It does not matter which port you use.
ENGLISH
25
MAKING CONNECTIONS
Method B: DVI to HDMI Connection
AUDIO OUT DVI OUT
PC
(*Not Provided)
(*Not Provided)
YELLOW
Choose any HDMI input port to connect.
It does not matter which port you use.
ENGLISH
26 MAKING CONNECTIONS
Connecting to an Audio System
You can use an optional external audio system instead of the built-in speaker.
Digital Optical Audio Connection
Transmits a digital audio signal from the TV to an external device. Connect the external device and the
TV with the optical audio cable as shown in the following illustration.
y Do not look into the optical output port. Looking at the laser beam may damage your vision.
y Audio with ACP (Audio Copy Protection) function may block digital audio output.
NOTE
OPTICAL AUDIO IN
Digital Audio System
(*Not Provided)
ENGLISH
27
MAKING CONNECTIONS
Connecting a USB Device
Connect a USB storage device such as USB flash memory, external hard drive, or a USB memory card
reader to the TV and access the Smart Share menu to use various multimedia files.
Choose any USB input port to connect.
It does not matter which port you use.
y Some USB Hubs may not work. If a USB device connected using a USB Hub is not detected,
connect it directly to the USB port on the TV.
NOTE
(*Not Provided)
USB / USB HUB / HDD
ENGLISH
28 MAGIC REMOTE CONTROL FUNCTIONS
MAGIC REMOTE CONTROL FUNCTIONS
When the message
Magic remote control battery is low.
Change the battery.
is
displayed, replace the battery. To install batteries, open the battery cover, replace
batteries (1.5 V AA) matching and ends to the label inside the compartment,
and close the battery cover. Failure to match the correct polarities of the battery
may cause the battery to burst or leak, resulting in fire, personal injury, or ambient
pollution. Be sure to point the remote control at the remote control sensor on the TV.
To remove the batteries, perform the installation actions in reverse.
y Do not mix old and new batteries, as this may damage the remote control.
CAUTION
This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote
sensor.
VOL CH
/Q.MENU
Accesses the Universal Control
(Depending on country)
Accesses the quick menus.
Wheel(OK)
Selects menus or options and confirms
your input.
Scrolls through the saved programmes.
If you press the navigation button while
moving the pointer on the screen,
the pointer disappears, and the Magic
Remote Control works as a regular
remote control.
To display the pointer again, shake the
Magic Remote Control from side to
side.
(POWER)
Turns the TV on or off.
Used for viewing 3D video.
BACK
Returns to the previous level.
CH
Scrolls through the saved programmes
or channels.
Navigation buttons
(up/down/left/right)
Scrolls through menus or options.
MUTE
Mutes all sounds.
92/
Adjusts the volume level.
Voice recognition
-This is a beta version and only available
in selected functions for supported
models.
-Network connection is required to use
the voice recognition function.
1. Press the Voice recognition button.
2. Speak slowly and precisely.
When a voice is recognized, the
processing message appears on the
screen.
further than 10 cm from your face.
SMART
Accesses the Smart Home.
Pointer (RF transmitter)
LIGHTING ON/OFF
Turns the light on and off.
If you set it to ON, the light
automatically turns off in 5 seconds
ENGLISH
29
MAGIC REMOTE CONTROL FUNCTIONS
Registering Magic Remote Control
The Magic Remote Control operates by pairing
with your TV.
Please register the remote as follows.
How to register the Magic Remote Control
(Wheel)
To register automatically, turn the
TV on and press the Wheel (OK).
When registration is completed, the
completion message appears on the
screen.
If registration fails, turn the TV off
and back on, then press the
Wheel (OK) to complete registration.
How to Re-register the Magic Remote Control
BACK
SMART
1 Press and hold the BACK and
SMART buttons together for 5
seconds to reset, then register it
by following How to register the
Magic remote control above.
2 To re-register the Magic remote
control, press and hold the
BACK button for 5 seconds
toward the TV.
How to use Magic Remote Control
1 You can move the pointer by
aiming the Pointer Receiver of the
remote control at your TV then
move it left, right, up or down.
» If the pointer does not work
properly, leave the remote control
for 10 seconds then use it again.
2 If the pointer disappears, move
the remote control slightly to left
or right. Then, it will automatically
appear on the screen.
» If the pointer has not been used
for a certain period of time, it will
disappear.
1
If you press Wheel (OK) on the
Magic remote control, the screen
appears.
Shows information about the current
program and screen.
2You can select More Menu.
Precautions to Take when Using
the Magic Remote Control
y Use the Magic remote control within the
maximum communication distance (10 m,
32.8 ft). Using the remote control beyond this
distance, or with an object obstructing it, may
cause a communication failure.
y A communication failure may occur due to nearby
devices. Electrical devices such as a microwave
oven or wireless LAN product may cause
interference, as these use the same bandwidth
(2.4 GHz) as the Magic remote control.
y The Magic remote control may be damaged or
may malfunction if it is dropped or receives a
heavy impact.
y Take care not to bump into nearby furniture or
other people when using the Magic remote
control.
y Manufacturer and installer cannot provide
service related to human safety as the applicable
wireless device has possibility of electric wave
interference.
y It is recommended that an Access Point (AP) be
located more than 1 m (3.28 ft) away from the
TV. If the AP is installed closer than 1 m (3.28 ft),
the Magic remote control may not perform as
expected due to frequency interference.
ENGLISH
30 WATCHING TV
WATCHING TV
Turning the TV on for the First Time
When you turn the TV on for the first time, the
Initial setting screen appears. Select a language
and customize the basic settings.
1 Connect the power cord to a power outlet.
2 In Standby mode, press the power button
on the remote control to turn the TV on.
The Initial setting screen appears if you turn
the TV on for the first time.
y You can also access Initial Setting by
accessing OPTION in the main menu.
NOTE
3 Follow the on-screen instructions to
customize your TV settings according to
your preferences.
Language Selection Selects a language to
display.
Ø
Environment
Selection
Select Home for the home
environment.
Ø
Time Zone Setting
Selects the time zone and
daylight saving.
(Depending upon country)
Ø
Network Connection Sets your network to
enable network-related
features on the TV.
Ø
Select TV watching
Type
Set the TV and set-top box
for each watching type.
(Depending upon country)
Ø
Auto Tuning Scans and saves available
channels automatically.
Ø
Setting is complete Confirms the setting
options.
Ø
Experience Magic
Remote Control
Simple guide of Magic
Remote Control
(Depending upon model)
y Select Home when prompted. Store mode
puts the TV in demo mode.
y If you select Store, the any customized
settings will switch back to the default
settings of Store in 5 minutes.
y The Standby light feature is disabled in
Store Demo mode.
NOTE
4 When the basic settings are complete,
press the Wheel (OK).
y If you do not complete the initial setting, it
will appear whenever the TV turns on.
y Disconnect the power cord from the
power outlet when you do not use the TV
for a long period of time.
NOTE
5 To turn the TV off, press the power button
on the remote control.
ENGLISH
31
USING THE USER GUIDE
USING THE USER GUIDE
User Guide allows you to access detailed TV
information easily.
1 Press
SMART button to access the Smart
Home menu.
2 Select
User Guide and press the Wheel
(OK) button.
User Guide
Ö
OPTION > To set language
SMART Ö Settings ¨ OPTION ¨ Language
Selects Menu Language and Audio Language displayed on the screen.
Menu
Language
Audio
Language
Selects a screen menu language.
[In Digital Mode Only]
Selects the desired language when watching digital
broadcasting containing several audio languages.
Voice
Recognition
Language
Select the language to make voice search.
ܩ
Only the voice search adopted model support this
setting.
Try Now
Close
1
2
1Shows the description of the selected
menu. You can use / to move
between pages.
2Moves to the selected menu directly
from the User Guide.
(Depending upon country)
To use input device
To set time options
To set language
To set caption
To set other options
To set TV lock options
User Guide
Index
Online User Guide
OPTION
CHANNEL Setting
PICTURE, SOUND Setting
LG SMART Function
Advanced Function
Information
1
2 3 4 5
To set Magic remote control
Check with your remote control right now.
1Shows the video you were watching.
2Guide categories.
3List of topics in the current category.
You can use / button to move
between pages.
4An index of key words present in the
User Guide.
5
Provides the detailed information on
the functions of LG Smart TV when the
Internet is connected.
(It may not be available depending upon
the country/language.)
Index
Online User Guide
ENGLISH
32 SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement AC 120 V~ 50/60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating Temperature 0 °C ~ 40 °C (32 °F ~ 104 °F)
Operating Humidity Less than 80 %
Storage Temperature -20 °C ~ 60 °C (-4 °F ~ 140 °F)
Storage Humidity Less than 85 %
MODELS 84LM9600
(84LM9600-UB)
Dimensions (Width x
Height x Depth)
With stand 1,916 x 1214 x 399 (mm)
Without stand 1,916 x 1120 x 39.9 (mm)
Weight With stand 81.7 Kg
Without stand 70.4 Kg
Current Value / Power consumption 5.2 A / 520 W
ENGLISH
33
SPECIFICATIONS
HDMI (DTV) supported mode
Resolution Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
720 x 480 31.469
31.50
59.94
60.00
1280 x 720 44.96
45.00
59.94
60.00
1920 x 1080
33.72
33.75
26.97
27.000
33.716
33.75
67.43
67.500
59.94
60.00
23.97
24.000
29.976
30.00
59.94
60
3840 x 2160
53.95
54
56.25
61.43
67.5
23.976
24.00
25.00
29.970
30.00
HDMI (PC) supported mode
Resolution Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
640 x 350 31.468 70.09
720 x 400 31.469 70.08
640 x 480 31.469 59.94
800 x 600 37.879 60.31
1024 x 768 48.363 60.00
1152 x 864 54.348 60.053
1280 x 1024 63.981 60.020
1360 x 768 47.712 60.015
1920 x 1080 67.5 60.00
3840 x 2160
54
56.25
67.5
24.00
25.00
30.00
Component port connecting information
Component ports on the TV Y PB PR
Video output ports
on DVD player
YPBPR
Y B-Y R-Y
YCbCr
YPbPr
Wireless LAN module (WN8122E1) specification
Standard IEEE802.11a/b/g/n
Frequency Range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Output PoweU (Max.)
802.11a: 16.5 dBm
802.11b: 16 dBm
802.11g: 15.5 dBm
802.11n - 2.4GHz: 15.5 dBm
802.11n - 5GHz: 16.5 dBm
y Because band channel used by the country
could be different, the user can not change
or adjust the operating frequency and this
product is set for the regional frequency
table.
y Contains FCC ID: BEJWN8122E1
Contains IC: 2703H-WN8122E1
Bluetooth module (BM-LDS401) specification
Standard Bluetooth Version 3.0
Frequency Range 2400 ~ 2483.5 MHz
Output Power (Max.) 10 dBm or lower
y Contains FCC ID: BEJLDS401
Contains IC: 2703H-LDS401
ENGLISH
34 SPECIFICATIONS
3D supported mode
y Video, which is input as below media contents is switched into the 3D screen automatically.
3D supported mode automatically
Input Signal Horizontal
Frequency (kHz)
Vertical Frequency
(Hz) Playable 3D video format
HDMI
1080p
54.00 24 F/P, L/A
67.50 30
27.00 24 S/S, T&B, S/S Full
33.75 30
67.50 60 S/S, T&B
1080i 67.50
60
F/P, F/A
33.75 S/S, T&B, S/S Full
720p 90.00 F/P, L/A
45.00 S/S, T&B, S/S Full
480p 63.00 F/P, L/A
31.50 T/B, S/S, S/S Full
USB 1080p 33.75 30 S/S, T&B, C/B, MPO (Photo)
DLNA
S/S : Side by Side, S/S Full : Side by Side Full, S/S Half :Side by Side Half,
T/B : Top & Bottom, F/P : Frame Packing, F/A : Field Alternative, L/A : Line Alternative, C/B : Checker Board,
R/I : Row Interleaving, C/I: Column Interleaving, F/S : Single Frame Sequential
ENGLISH
35
SPECIFICATIONS
3D supported mode manually
Input Signal Playable 3D video format
TV -
2D to 3D, S/S, T&B
ATV (CVBS) -
Component -
HDMI-PC
1080p 2D to 3D, S/S, T&B, C/B, R/I, C/I
(60Hz : F/S)
Others 2D to 3D, S/S, T&B
HDMI-DTV
Interlace 2D to 3D, S/S, T&B
Progressive 2D to 3D, S/S, T&B, C/B, R/I, C/I
(60Hz : F/S )
USB / DLNA
(Movie)
704 x 480p (Over) 2D to 3D, S/S, T&B, C/B, R/I, C/I
(60Hz : F/S )
704 x 480i (Over) 2D to 3D, S/S, T&B
704 x 480 (Under) 2D to 3D
USB / DLNA
(Photo)
320 x 240 (Over) 2D to 3D, S/S, T&B
320 x 240 (Under) 2D to 3D
Miracast™ / WiDi
1024 x 768p
2D to 3D, S/S, T&B1280 x 720p
1920 x 1080p
Others 2D to 3D
ENGLISH
36 MAINTENANCE / TROUBLESHOOTING
MAINTENANCE
Cleaning Your TV
Clean your TV regularly to keep it at peak performance and to extend the product lifespan.
y Before cleaning, turn the power off and disconnect the power cord and all other cables.
y When the TV is left unattended or unused for a long time, disconnect the power cord from the
wall outlet to prevent possible damage from lightning or power surges.
CAUTION
Screen, Frame, Cabinet, and Stand
To remove dust or light dirt, wipe the surface with a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild
detergent. Then wipe immediately with a dry cloth.
y Do not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in
scratches on the screen and image distortions.
y Do not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air
fresheners, or lubricants, as these may damage the screen’s finish and cause discoloration.
y Do not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock,
or malfunction.
CAUTION
Power Cord
Remove the accumulated dust or dirt on the power cord regularly.
TROUBLESHOOTING
Problem Solution
Cannot control the TV with
the remote control.
y Check the remote control sensor on the product and try again.
y Check if there is any obstacle between the product and the remote control.
y Check if the batteries are still working and properly installed ( to , to ).
No image display and no
sound is produced.
y Check if the product is turned on.
y Check if the power cord is connected to a wall outlet.
y Check if there is a problem in the wall outlet by connecting other products.
The TV turns off suddenly.
y Check the power control settings. The power supply may be interrupted.
y Check if the Auto sleep feature is activated in the TIME settings.
y If there is no signal while the TV is on, the TV will turn off automatically after 15
minutes of inactivity.
THE CONSUMER ELECTRONICS INDUSTRY CARES
BVcj[VXijgZgh! gZiV^aZgh VcY i]Z gZhi d[ i]Z XdchjbZg ZaZXigdc^Xh ^cYjhign VgZ Xdbb^iiZY id
bV`^c\]dbZZciZgiV^cbZcihV[ZVcYZc_dnVWaZ#
6hndjZc_dnndjgiZaZk^h^dc!eaZVhZcdiZi]ViVaaiZaZk^h^dch¸cZlVcYdaY"bjhiWZhjeedgiZYdc
egdeZghiVcYhdg^chiVaaZYVXXdgY^c\idi]ZbVcj[VXijgZg½hgZXdbbZcYVi^dch#IZaZk^h^dchi]Vi
VgZ^cVeegdeg^ViZanh^ijViZYdcYgZhhZgh!Wdd`XVhZh!h]ZakZh!YZh`h!heZV`Zgh!X]Zhih!XVgih!ZiX#!
bVn[VaadkZg!gZhjai^c\^c^c_jgn#
TUNE IN TO SAFETY
ALWAYS[daadli]ZbVcj[VXijgZg½hgZXdbbZcYVi^dch[dgi]ZhV[Z^chiVaaVi^dcd[ndjgiZaZk^h^dc#
ALWAYSgZVYVcY[daadlVaa^chigjXi^dch[dgegdeZgjhZd[ndjgiZaZk^h^dc#
NEVERVaadlX]^aYgZcidXa^bWdcdgeaVndci]ZiZaZk^h^dcdgi]Z[jgc^ijgZdcl]^X]i]ZiZaZk^h^dc
^heaVXZY#
NEVER eaVXZ i]Z iZaZk^h^dc dc [jgc^ijgZ i]Vi XVc ZVh^an WZ jhZY Vh hiZeh! hjX] Vh V X]Zhi d[
YgVlZgh#
ALWAYS^chiVaai]ZiZaZk^h^dcl]ZgZ^iXVccdiWZejh]ZY!ejaaZYdkZgdg`cdX`ZYYdlc#
ALWAYSgdjiZXdgYhVcY XVWaZh XdccZXiZYidi]Z iZaZk^h^dchdi]Vi i]ZnXVccdiWZ ig^eeZY
dkZg!ejaaZYdg\gVWWZY#
WALL OR CEILING MOUNT YOUR TELEVISION
ALWAYSXdciVXindjggZiV^aZgVWdjiegd[Zhh^dcVa^chiVaaVi^dc^[ndj]VkZVcnYdjWihVWdjindjg
VW^a^inidhV[ZanbdjcindjgiZaZk^h^dc#
ALWAYSjhZVbdjcii]Vi]VhWZZcgZXdbbZcYZYWni]ZiZaZk^h^dcbVcj[VXijgZgVcY]VhV
hV[ZinXZgi^ÅXVi^dcWnVc^cYZeZcYZciaVWdgVidgnhjX]VhJA!8H6!:IA#
ALWAYS[daadlVaa^chigjXi^dchhjeea^ZYWni]ZiZaZk^h^dcVcYbdjcibVcj[VXijgZgh#
ALWAYSbV`ZhjgZi]Vii]ZlVaadgXZ^a^c\l]ZgZndjVgZbdjci^c\i]ZiZaZk^h^dc^hVeegdeg^ViZ#
HdbZbdjcihVgZcdi YZh^\cZYidWZ bdjciZYidlVaahVcYXZ^a^c\hl^i]hiZZahijYhdgX^cYZg
WadX`XdchigjXi^dc#>[ndjVgZjchjgZ!XdciVXiVegd[Zhh^dcVa^chiVaaZg#
IZaZk^h^dch XVc WZ ]ZVkn# 6 b^c^bjb d[ ild eZdeaZ ^h gZfj^gZY [dg V lVaa dg XZ^a^c\ bdjci
^chiVaaVi^dc#
MOVING AN OLDER TELEVISION TO A NEW PLACE IN
YOUR HOME
BVcncZl iZaZk^h^dcWjnZghbdkZi]Z^gdaYZg8GIiZaZk^h^dch^cid V hZXdcYVgn gddb V[iZg i]Z
ejgX]VhZd[VÆVi"eVcZaiZaZk^h^dc#HeZX^VaXVgZh]djaYWZbVYZ^ci]ZeaVXZbZcid[daYZg8GI
iZaZk^h^dch#
ALWAYSeaVXZndjgdaYZg8GIiZaZk^h^dcdc[jgc^ijgZi]Vi^hhijgYnVcYVeegdeg^ViZ[dg^ihh^oZ
VcYlZ^\]i#
NEVER eaVXZndjgdaYZg8GIiZaZk^h^dcdcVYgZhhZgl]ZgZX]^aYgZcbVnWZiZbeiZYidjhZi]Z
YgVlZghidXa^bW#
ALWAYSbV`ZhjgZndjgdaYZg8GIiZaZk^h^dcYdZhcdi]Vc\dkZgi]ZZY\Zd[ndjg[jgc^ijgZ#
CHILD SAFETY:
PROPER TELEVISION PLACEMENT MATTERS
CE.org/safety
The model and serial numbers of the TV are located
on the back and one side of the TV.
Record them below should you ever need service.
MODEL
SERIAL
LG Customer Information Center
For inquires or comments, visit www.lg.com or call;
1-800-243-0000 USA, Consumer User
1-888-865-3026 USA, Commercial User
1-888-542-2623 CANADA
Register your product Online!
www.lg.com
