LG Electronics USA 9QK-DMPD221 Pocket Photo User Manual
LG Electronics USA Pocket Photo
User Manual-Rev.02(1025)
STEP 2 Charging battery
This device uses built-in battery. Before using it, charge
the battery in full. (Refer to below)
Battery Charging Time : 1.5 hour
Battery Indications of LED indicator ( button)
yCharging : / 100 % : (When turned o)
y10 % : ashes for about 3 sec.
y0 % : ashes for about 30 sec and turned o.
yUsing unauthorized device may cause
malfunction. In this case, free product service is
not provided.
yHandle with care while charging the device to
prevent electric shock.
>Caution
Notes on charging battery
yYou can connect the device to PC using the USB
data transfer & recharging cable provided, but
charging time can be longer.
yBattery lasting time can dier depending on
the temperature, period you have used for, and
personal mobility .
yOnce fully charged, you can print up to 15 papers
in a row.
yWhen the battery is dead, printing is available
after charging it for minimum 10 mins.
(Charge in full when you want to print in a row.)
Notes on handling device (battery)
yDo not place near heating appliance.
yDo not disassemble or deform.
yDo not give shock on.
yAvoid too high or low temperature or humidity.
,Note
STEP 1 Getting started
Components
USB data transfer &
recharging cable
AC adaptor
LG Pocket Photo Printer
ZINK Photo Paper
Owner’s manual
Product Overview
Micro USB port
(for recharging)
USB port
(Type A, for Smartphone)
Reset hole
Paper Insert Slot
Paper Exit Slot
button
(Power)
Paper Insert Slot Cover
Upper Cover
Power On / O
On : Press & hold for 4 sec
Off : Press & hold for 2 sec
yWhen turning the device on, the button ashes
for 5 sec. After that, printing is available.
yThe LED indicator ( button) uses color display
to give a visual indication of the device condition.
For more information, see “About LED indicator”
on the back page.
,Note
Bluetooth®
Safety information
Owner’s manual
STEP 3 Inserting Photo Paper
1. Open the Paper Insert Slot Cover.
2. Unwrap the pack of the photo papers.
3. Slide Smart Sheet (Blue one) and photo papers
together into as shown below. Smart Sheet will be out
automatically before rst printing.
yDo not insert more than 1 pack (10 Photo papers and 1
Smart Sheet). 2 papers may be out at the same time or
paper jam may occur.
yInsert a new pack after using up the remains.
ZINK
Smart Sheet
with Barcode side down
Photo Paper
with White side up
Cleaning Printer head using Smart Sheet
Smart Sheet cleans printer head and corrects the color of
photo. Keep the best print quality by using it repeatedly.
Paper Jam Solution
Do not pull the paper out. Turn the device o and on
again, the paper will be out automatically.
If this problem is not solved, please refer to “Things to
check before reporting problem”.
Pulling out jammed paper by force may result in
malfunction.
>Caution
Notes on Photo Paper
yDo not damage or bend the papers.
yBe careful when you touch the paper not to get
dirt on.
yUsing soiled paper may result in malfunction.
yUsing photo papers from other company may
result in malfunction or paper jam.
yCheck the expiration date on the wrapping before
using.
yDo not place inside a car or, expose to direct
sunlight or moisture.
yDo not leave in a place where the temperature
or humidity is too high or low. It may cause low
quality images.
yPapers can begin to veer o after unwrapping for
a long time. Quickly using them is recommended.
,Note
STEP 4 Installing App
From Play store (Android market)
Search for “LG Pocket Photo”.
Using QR code
Scan the QR code on the product box or cover of the
manual.
Using NFC
Refer to “Printing by using NFC” in the back page.
App Setting
Set the options in [Setting].
yNFC* : Prints by using NFC
(NFC mounted phone only)
yBluetooth : Prints by using Bluetooth
yUSB debugging : Prints by connecting to smartphone
with a USB cable
yGPS** : Saves the location where you took a photo
* NFC : Near Field Communication
** GPS : Global Positioning System using a satellite
See “Help” for details
For more information about the App, touch “Help”.
STEP 5 Printing Image
Printing by using Bluetooth ( )
Preparation : Turn the device on, and start printing with
the white LED ( button) turning on.
1. Launch LG Pocket Photo App on smartphone.
2. Select photo to print, and touch [Print].
3. Touch [Select], then searching Bluetooth device is
processed.
4.
When Bluetooth connecting for the rst time, [Bluetooth
pairing request] appears. To start printing, touch [Pairing].
yIf Smart Sheet is in the paper tray, it will be out
before starting printing.
yThe color of impression can be dierent between
printed photo and image on smartphone’s display.
yIf there are more than a LG Pocket Photo device, check
MAC address on the label to choose appropriate one.
(Refer to “Checking Label” on the back page.)
yYou can print photos without App, but using Bluetooth
on Smartphone. Choose a photo to print in [Gallery]
and select Bluetooth in [Share] or [Menu].
yDo not pull paper out by force while printing.
yDo not open the Paper Insert Slot Cover while printing.
yDo not place an object in front of the Paper Exit Slot.
yIf the device is vibrated or given shock, the print
quality may be lower.
yOnce the battery is fully charged, you can print up
to 15 papers in a row. It depends on using time or
way it may dier.
yThe Bluetooth searching and transferring may
fail depending on its environment. Check the
Bluetooth condition on your phone and try again.
>Caution
Please read this manual carefully before
operating your device.
.0%&-1%
Micro USB port
Scan the QR code.
Do not put the container
containing liquid on.
Do not place in too low
temperature.
Do not disassemble, repair,
or converse.
Do not spray water on
directly.
Keep out of reach of
children.
Do not place near a magnet or
within the magnetic field.
Clean with a dry cloth.
Do not place in hot or
humid place.
Do not drop or give shock.
Do not place in dirty or
sooty place.
Do not place an heavy
object.
Observe the rated voltage
and current (5 V 1 A).
Avoid direct sunlight
or heat.
Android Only
The actual product may dier from the image.
Take a photo with the smartphone and
print it right away with
LG Pocket Photo
PD221_OM_ENG_CEO Sample.indd 1
FCC Warning:
Changes or modifications not expressly approved
by the party responsible for compliance could void
user＇s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
THE FOLLOWING APPLIES ONLY IN CANADA. CE QUI
SUIT NE S’ APPLIQUE QU’ AU CANADA.
This device complies with RSS-210 of the IC Rules.
Operation is subject to the following two conditions:
(1)this device may not cause interference, and (2) this device
must accept any interference, including interference that may
cause undesired operation of the device
Cet appareil radio est conforme au CNR-210 d’Industrie
Canada. L’utilisation de ce dispositif est autorisée seulement
aux deux conditions suivantes : (1) il ne doit pas produire de
brouillage, et (2) l’utilisateur du dispositif doit être prêt à
accepter tout brouillage radioélectrique reçu, même si ce
brouillage est susceptible de compromettre le fonctionnement
du dispositif
FCC/IC Radio Frequency Exposure
The available scientific evidence does not show that any
health problems are associated with using low power wireless
devices. There is no proof, however, that these low power
wireless devices are absolutely safe. Low power Wireless
devices emit low levels of radio frequency energy (RF)
in the microwave range while being used. Whereas high levels
of RF can produce health effects (by heating tissue), exposure
to low level RF that does not produce heating effects causes
no known adverse health effects. Many studies of low level
RF exposures have not found any biological effects. Some
studies have suggested that some biological
effects might occur, but such findings have not been
confirmed by additional research. This device have been
tested and found to comply with FCC/IC radiation exposure
limits set forth for an uncontrolled environment and meets the
FCC radio frequency (RF) Exposure Guidelines in
Supplement C to OET65 and RSS-102 of the IC radio
frequency (RF) Exposure rules.
Exposition aux radiofréquences FCC/IC
Selon les preuves scientifiques disponibles, aucun problème
de santé n’est associé à l’utilisation d’appareils sans fil de
faible puissance. Rien ne prouve cependant que ces appareils
sont absolument sans danger. Lorsqu’ils sont utilisés, les
appareils sans fil de faible puissance émettent de faibles
niveaux d’énergie radiofréquence (RF) dans la gamme des
hyperfréquences. Bien que les niveaux élevés de
radiofréquence puissant avoir un effet sur la santé
(réchauffement des tissus), l’exposition à de faibles niveaux
n’ayant pas d’effet thermique n’a aucun impact négatif connu
sur la santé. De nombreuses études sur l’exposition aux
radiofréquences de faible niveau n’ont révélé aucun effet
biologique. Certaines d’entre elles ont sous-entendu qu’il
pourrait y avoir de tells effets, mais leurs résultats n’ont pas
été confirmés par des recherches supplémentaires. Les modele
suivants ont ete testes et se sont averes conformes aux limites
d’exposition aux rayonnements definies par la FCC
et IC pour l’environnement non controle ; ils repondent aux
regles sur l’exposition aux rayonnements RF (radiofrequence)
de la FCC et a celles de la norme RSS-102 d’IC.
Hereby declares that this pocket photo is in compliance
with essential requirements and other relevant provision
of R&TTE Directive 1999/5/EC. The standard for
complying are as following:
ETSI EN 301 489-1 V1.9.2:2011-09
ETSI EN 301 489-17 V2.1.1:2009-05
ETSI EN 300 328 V1.7.1:2006
EN 60950-1:2005+A11:2009
