Users Manual
IMPORTANT SAFETY PRECAUTIONS
1
IMPORTANT SAFETY PRECAUTIONS
Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is
given in this user guide.
WARNING! Violation of the instructions may cause serious injury or death.
1. Never use an unapproved battery since this could damage the phone and /or battery and could
cause the battery to explode.
2. Never place your phone in a microwave oven as it will cause the battery to explode.
3. Do not dispose of your battery by fire or with hazardous or flammable materials.
4. Make sure that no sharp-edged items such as animal’s teeth, nails, come into contact with the
battery. There is a risk of this causing a fire.
5. Store the battery out of reach of children.
6. Be careful that children do not swallow any parts of the phone. This could cause asphyxiation or
suffocation.
IMPORTANT SAFETY PRECAUTIONS
2
IMPORTANT SAFETY PRECAUTIONS
1. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.
2. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If
wireless equipment is improperly installed and the air bag is activated, you may be seriously
injured.
3. Do not use a hand-held phone while driving.
4. Do not use the phone in areas where its use is prohibited. (For example: aircraft)
5. Do not expose the battery charger or adapter to direct sunlight or use it in places with high
humidity, such as a bathroom.
6. Never store your phone in temperatures less than -20°C (-4°F) or greater than 50°C (122°F).
7. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean
your phone. There is a risk of this causing a fire.
8. Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit
boards of the phone.
9. Do not use your phone in high explosive areas as the phone may generate sparks.
10. Do not damage the power cord by bending, twisting, pulling or heating. Do not use the plug if
it is loose as it may cause a fire or electric shock.
3
IMPORTANT SAFETY PRECAUTIONS
1. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as
it may cause fire or electric shock.
2. Do not handle the phone with wet hands while it is being charged. It may cause an electric
shock or seriously damage your phone.
3. Do not disassemble the phone.
4. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or
cause electric shock or fire.
5. Only use the batteries, antennas and chargers provided by LG. The warranty will not be applied
to products provided by other suppliers.
6. Only authorized personnel should service the phone and its accessories. Faulty installation or
service may result in accidents and consequently invalidate the warranty.
7. Do not hold or let the antenna come in contact with your body during a call.
8. An emergency call can be made only within a service area. For an emergency call, make sure that
you are within a service area and that the phone is turned on.
CONTENTS
CONTENTS
4
IMPORTANT SAFETY
PRECAUTIONS 1
CONTENTS 4
Welcome 9
Important Information 9
FCC Part 15 Class B Compliance 9
Industry Canada Compliance 9
Technical Details 10
FCC RF Exposure Information 11
Bodily Contact During Operation 11
Caution 11
Phone Overview 12
Menus Overview 14
Getting Started with Your
Phone 16
The Battery 16
Installing the Battery 16
Removing the Battery 16
Charging the Battery 16
Battery Charge Level 16
Turning the Phone On and Off 17
Turning the Phone On 17
Turning the Phone Off 17
Signal Strength 17
Screen Icons 18
Making Calls 19
Correcting Dialing Mistakes 19
Redialing Calls 19
Receiving Calls 19
Quick Access to Convenient
Features 20
Manner Mode 20
Lock Mode 20
Mute Function 20
Volume Quick Adjustment 20
Call Waiting 21
Caller ID 21
To dial Speed Dials 21
Some of contents in this user guide maybe different from your phone
depending on the software of the phone or your service provider. Features
and specifications might be subject to change without prior notice.
5
CONTENTS
Entering and Editing
Information 22
Text Input 22
Key Functions 22
Contacts in Your Phone’s
Memory 24
Contacts Entries 24
Storing Basics 24
Customizing Individual Entries 24
Speed Dial 24
Storing a Number with Pause 25
Adding Another Phone Number 25
From the Contact List Screen 26
Adding a Pause to a Contact Entry 26
Changing Saved Information 26
Changing the Default Number 26
Deleting 27
Deleting a Phone Number 27
Searching Your Phone’s Memory 28
Calling From Your Phone’s Memory 28
Speed Dialing 29
Using Phone Menus 30
Menu Access 30
Contacts 30
Access and Options 30
1. List Entries 30
2. New Entry 31
3. Groups 31
4. Speed Dials 32
5. Voice Dials 32
6. Erase All Contacts 32
Call History 33
Access and Options 33
1. All Calls 33
2. Incoming Calls 34
2. Outgoing Calls 34
4. Missed Calls 34
5. Erase History 35
6. Call Timers 35
CONTENTS
CONTENTS
6
Messaging 35
1. Voice Mail 36
2. Text and Multimedia 36
1. Send New 36
2. Inbox 38
3. Outbox 39
4. Templates 39
5. Drafts 40
6. Saved 40
7. Erase Messages 41
8. Settings 41
9. Memory Info 43
3. E-mail 43
4. IM & Chat 43
3. Web Alerts 43
6. Short Codes 43
Wireless Web 44
Music 45
1. Ringtones 46
2. Wallpaper 46
3. Camera 46
3.1 Take Photo 46
4. My Albums 47
4.1 Sound Album 47
4.2 Picture Album 48
4.3 Online Album 48
Shop 49
Games 49
Tool & App 50
1. Get New 50
2. GPS Services 50
3. Calculator 50
4. Alarm Clock 51
5. Scheduler 51
6. Notepad 52
7. EZ Tip Calc 52
8. World Clock 52
9. Voice Memo 53
7
CONTENTS
Settings 54
1. Sound 54
1.1 Ringers 54
1.2 Keypad 55
1.3 Volume 55
1.4 Alerts 56
2. Display 56
2.1 Banner 56
2.2 Wallpaper 57
2.3 Backlight 57
2.4 Keypad light 57
2.5 Clock Format 57
2.6 Menu Style 58
2.7 Dialing font 58
3. Games / Tools 58
3.1 Backlight Settings 58
3.2 Volume 58
3.3 Notifications 58
4. BluetoothTM 59
4.1 Power 59
4.2 Device List 59
4.3 Discovery Mode 60
4.4 Device Scan 60
4.5 Device Name 60
5. GPS 60
5.1 GPS Status 60
5.2 GPS Privacy 60
6. Others 61
6.1 Nav. Key Shortcuts 61
6.2 Call Setup 61
6.3 Language 62
6.4 TTY Mode 62
6.5 Data Setup 64
6.6 Memory Info 64
7. S y s t e m 64
7.1 Phone Info 64
7.2 System 64
7.3 Security 66
8. Airplane Mode 67
CONTENTS
8
CONTENTS
Safety 68
TIA(Telecommunications
Industry Association) Safety
Information 68
Exposure to Radio Frequency Signal 68
Antenna Care 68
Phone Operation 68
Tips on Efficient Operation 69
Driving 69
Electronic Devices 69
Pacemakers 69
Persons with Pacemakers: 69
Hearing Aids 70
Other Medical Devices 70
Health Care Facilities 70
Vehicles 70
Posted Facilities 70
Aircraft 70
Blasting Areas 70
Potentially Explosive Atmosphere 71
For Vehicles Equipped with an Air Bag 71
Charger and Adapter Safety 71
Battery Information and
Care 71
Safety Information 72
Explosion, Shock, and Fire Hazards 72
General Warnings and Cautions 73
FDA Consumer Update 74
Consumer Information on
SAR 81
Warranty Information 84
WELCOME
Thank you for choosing the advanced and compact
LG 490 cellular phone, designed to operate with the
latest digital mobile communication technology, Code
Division Multiple Access (CDMA). Along with the many
advanced features of the CDMA system, such as greatly
enhanced voice clarity, this phone offers:
1. Large, easy-to-read, 8-line backlit LCD with status
icons.
2. Paging, messaging, Voice Mail and Caller ID.
3. 27-key keypad.
4. Long battery standby and talk time.
5. Menu-driven interface with prompts for easy operation
and configuration.
6. Any Key Answer, Auto Answer, Auto Retry, One-Touch
Dial and speed dialing with 99 memory locations.
7. Bluetooth and Music & Media functionalities
8. Bilingual capabilities (English and French)
9. Fastap board
10. Compact Car Porsche Design
Important Information
This user’s guide provides important information on
the use and operation of your phone. Please read all
the information carefully prior to using the phone for
the best performance and to prevent any damage to
or misuse of the phone. Any unapproved changes or
modifications will void your warranty.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15
of FCC rules. Operation is subject to the following
two conditions: (1) This device and its accessories
may not cause harmful interference, and (2) this
device and its accessories must accept any
interference received, including interference that
causes undesired operation.
Industry Canada Compliance
This phone complies with Industry Canada RSS 133.
This phone complies with the Class B limits for radio
noise emissions as set out in the interference causing
standard entitled "Digital Apparatus" ICES-003 of
Industry Canada.
WELCOME
9
10
WELCOME
WELCOME
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and
inter-band operations
IS-95 adapted for PCS frequency
band CDMA2000 1xRTT Air
Interface
MAS-BS
PCSC-RS
Intersystem operations
Nom-signaling data comm.
Cellular base station
Cellular mobile station
PCS personal station
PCS base station
Speech CODEC
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-97
TIA/EIA/IS-98
ANSI J-STD-018
ANSI J-STD-019
TIA/EIA/IS-125
TIA/EIA/IS-96-B
TIA/EIA/IS-99
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Async Data and Fax
Short message service
Packet Data
Position Determination Service
High Speed Packet Data
Network
Service
Performance
Designator Description
Technical Details
The LG 490 is an all digital phone that operates on
both Code Division Multiple Access (CDMA)
frequencies: cellular services at 800 Mhz and
Personal Communication Services (PCS) at 1.9 Ghz.
CDMA technology uses a feature called DSSS
(Direct Sequence Spread Spectrum) that enables
the phone to keep communication from being
crossed and to use one frequency channel by
multiple users in the same specific area. This results
in a 10-fold capacity increase when compared with
analog mode. In addition, features such as soft /
softer handoff, hard Handoff, and dynamic RF power
control technologies combine to reduce call
interruptions.
The Cellular and PCS CDMA networks consist of
MSO (Mobile Switching Office), BSC (Base Station
Controller), BTS (Base Station Transmission
System), and MS (Mobile Station). The following
table lists some major CDMA standards.
* TSB -74: Protocol between an IS-95A system and
ANSI J-STD-008
1xRTT system receives twice as many subscribers in
the wireless section as IS-95. Its battery life is twice
as long as IS-95. High-speed data transmission is
also possible.
WELCOME
FCC RF Exposure Information
WARNING! Read this information before operating
the phone.
In August 1996, the Federal Communications
Commission (FCC) of the United States, with its action in
Report and Order FCC 96-326, adopted an updated
safety standard for human exposure to Radio Frequency
(RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the
safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC
guidelines and these international standards.
Bodily Contact During Operation
This device was tested for typical use with the back of the
phone kept 0.6 inches (1.5 cm) from the body. To
comply with FCC RF exposure requirements, a minimum
separation distance of 0.6 inches (1.5 cm) must be
maintained between the user’s body and the back of the
phone, including the antenna, whether extended or
retracted. Third-party belt-clips, holsters and similar
accessories containing metallic components should not
be used. Avoid the use of accessories that cannot
maintain 0.6 inches (1.5 cm) distance between the user’s
body and the back of the phone and have not been
tested for compliance with FCC RF exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.)
A minimum separation distance of 8 inches (20 cm) must
be maintained between the user / bystander and the
vehicle-mounted external antenna to satisfy FCC RF
exposure requirements. For more information about RF
exposure, visit the FCC website at www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or
result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a
damaged antenna comes into contact with the skin a
minor burn may result. Contact your local dealer for a
replacement antenna.
11
12
PHONE OVERVIEW
PHONE OVERVIEW
Earpiece
Navigation Keys
Right Soft Key
END Key
Side Camera Key
BACK/Speaker Key
Microphone
Lock Mode Key
Fastap Keypad
Flip
LCD Screen
Headset Jack
Left Soft Key
Side Keys
SEND Key
Voice Dial/Voice Memo Key
Vibrate Mode Key
Camera Lens
Flash
External Display
PHONE OVERVIEW
13
Earpiece
Flip
Open the case to answer an incoming call and
close to end the call.
LCD Screen
Displays messages and indicator icons.
Left Soft Key
Use to access the menu assigned to
the left screen of the phone.
Headset Jack
BACK/Speaker Key
Press to delete a single space or
character. Press and hold to delete entire words. Press
this key once in a menu to go back one level. Use for
quick access to Speakerphone Mode(from standby
mode press and hold for about 3 seconds)
SEND Key
Use to place or answer calls.
Side Keys
Use to adjust the ringer volume in standby
mode and the earpiece volume during a call.
Voice Dial/Voice Memo Key
Press once to access
the Voice Dial. Press and hold for two seconds or
more to access Voice Memo.
Vibrate Mode Key
Use to set the mode (from
standby mode press and hold for about 3
seconds).
Navigation Keys
Use for quick access to Messaging,
All Calls.
Right Soft Key
Use to access the menu assigned to
the right screen of the phone.
Side Camera Key
Use for quick access to Camera
function (Press and hold for about 3 seconds to use
camera function on the outside/inside display).
END Key
Use to turn the power on/off and to end a
call. Also use to return to the main menu display
screen.
Fastap Keypad
Use to enter numbers, characters and
symbols much faster than any other keyboard we
have offered.
Lock Mode Key
Use to set the lock function (from
standby mode press and hold for about 3
seconds).
Microphone Camera Lens
Flash External Display
14
MENUS OVERVIEW
MENUS OVERVIEW
1. Contacts
1. List Entries
2. New Entry
3. Groups
4. Speed Dials
5. Voice Dials
6. Erase All Contacts
2. Call History
1. All Calls
2. Incoming Calls
3. Outgoing Calls
4. Missed Calls
5. Erase History
1. All Calls
2. Dialed Calls
3. Received Calls
4. Missed Calls
6. Call Timers
1. Last Calls
2. All Calls
3. Life Time
4. Data Transferred
5. Connection Time
6. Reset Timer
3. Messaging
1. Voice Mail
2. Text and Multimedia
1. Send New
2. Inbox
3. Outbox
4. Templates
5. Drafts
6. Saved
7. Erase Messages
8. Settings
9. Memory Info
3. E-mail
4. IM & Chat
5. Web Alerts
6. Short Codes
4. Wireless Web
5. Media
1. Ringtones
2. Wallpaper
3. Camera
1. Take Photo
2. Take Video
4. My Albums
1. Sound Album
2. Picture Album
3. Online Album
MENUS OVERVIEW
15
6. Shop
7. Games
Get New
8. Tools & Apps
Get New
GPS Services
Calculator
Alarm Clock
Scheduler
Notepad
EZ Tip Calc
World Clock
Voice Memo
9. Settings
1. Sound
1. Ringers
2. Keypad
3. Volume
4. Alerts
2. Display
1. Banner
2. Wallpaper
3. Backlight
4. Keypad light
5. Time and Date
6. Menu Style
7. Dialing font
8. Theme Color
3. Games / Tools
1. Backlight
2. Volume
3. Notification
4. Bluetooth
1. Power
2. Device List
3. Discovery Mode
4. Device Scan
5. Device Name
5. GPS
1. GPS Status
2. GPS Privacy
6. Others
1. Nav. Key
2. Call Setup
3. Language
4. TTY Mode
5. Data Setup
6. Memory Info
7. System
1. Phone Info
2. System
3. Security
8. Airplane Mode
16
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
The Battery
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time. The battery charge
level is shown at the top of the LCD screen.
Installing the Battery
To install the battery, insert the battery into the
opening on the back of the phone. Put the battery
cover on the battery and push it slightly upwards.
Removing the Battery
Turn the power off. Pull the battery cover downward
and remove it. Then remove the battery by pressing
the upper area of it.
Charging the Battery
To use the charger provided with your phone:
WARNING! Use only the charger provided with the
phone. Using any charger other than the one included
with the LG 490 may damage your phone or battery.
1. Plug the end of the adapter into the phone's
charger port and the other end into an electrical
outlet.
2. The charge time varies depending upon the
battery level.
Battery Charge Level
The battery charge level is shown at the top right of
the LCD screen. When the battery charge level
becomes low, the low battery sensor alerts you in
three ways: sounding an audible tone, blinking the
battery icon, and displaying
Battery Low.
If the
battery charge level becomes exceedingly low, the
phone automatically switches off and any function in
progress is not saved.
Note
It is important to fully charge the battery before
initial use of the phone.
17
GETTING STARTED WITH YOUR PHONE
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery or connect the phone to
an external power source such as a cigarette lighter
charger or hands-free car kit.
2. Press for a few seconds until the LCD screen
lights up.
Turning the Phone Off
1. Press and hold until the display turns off.
Signal Strength
Call quality depends on the signal strength in your
area. The signal strength is indicated on the screen
as the number of bars next to the signal strength
icon: The more bars, the better the signal strength. If
the signal quality is poor, move to an open area. If
you are in a building, the reception may be better
near a window.
Fully DischargedFully Charged
Note
Like any other radio device, avoid any
unnecessary contact with the antenna while your
phone is on.
18
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
Screen Icons
When the phone is powered on, the top line of the LCD screen displays icons indicating the status of the phone.
To see the icons below, go to Menu->Settings->System->Phone Info->Icon Glossary.
Signal Strength indicator. The strength of the
signal received by the phone is indicated by the
number of bars displayed.
Roaming indicator.
The phone is outside of the home service area.
1X Service indicator.
New Message.
Battery Strength.
Indicates battery charge level.
New Voice Mail.
In Call State. A call is in progress.
* No icon indicates the phone is in standby mode.
No Service indicator.
The phone is not receiving a system signal.
Voice Privacy.
Data Session.
Vibrate Mode.
Ring Mode.
Silent Mode.
Alarm.
GPS On.
Bluetooth Audio Device Connected
Airplane Mode.
Voice Only.
Schedule.
Speaker Mode.
TTY.
SSL.
Bluetooth On.
Shown To All
Digital indicator. Digital service is available.
19
GETTING STARTED WITH YOUR PHONE
Making Calls
1. Make sure the phone is turned on. If not, press
for about 3 seconds.
2. Enter the phone number (include the area code if
needed).
3. Press .
lf the phone is locked, enter the lock code.
Call Failed - indicates the call did not go through.
4. Press to end the call.
Correcting Dialing Mistakes
If you make a mistake while dialing a number, press
once to Delete the last digit entered or hold
down for at least 2 seconds to delete all digits.
Redialing Calls
1. Press twice to redial the last number you
dialed. The last 90 numbers are stored in the call
history list and you can also select one of these to
redial.
Receiving Calls
1. When the phone rings or vibrates, press to
answer.
2. Press to end the call.
Note
If you press Left Soft Key [Quiet] while the
phone is ringing, the ringing or vibration is muted
for that call.
Note
If you press Right Soft Key [Ignore] while the
phone is ringing, the call will end.
20
QUICK ACCESS TO CONVENIENT FEATURES
QUICK ACCESS TO CONVENIENT FEATURES
Manner Mode
Sets the phone to shake instead of ring ( is
displayed). To quickly set Manner Mode press and
hold . To return to Normal Mode, press and
hold .
Lock Mode
Sets your phone to require your 4-digit password in
order to use the phone.
To quickly lock your phone press for three
seconds. To cancel, press Right Soft Key
[Unlock]
and enter the password.
Mute Function
The Mute Function doesn’t transmit your voice to
the caller. To quickly activate Mute press Left Soft
Key
[Mute]
, then to cancel press Left Soft Key
[Unmute]
.
Volume Quick Adjustment
Quickly adjust ringer and earpiece volumes by
pressing the upper side key to increase and lower key
to decrease.
Note
Until you change it, the lock code/password is
the last 4 digits of your phone number.
Note
The earpiece volume can only be adjusted during
a call and Key Beep volume can only be adjusted
through the Menu.
21
QUICK ACCESS TO CONVENIENT FEATURES
Call Waiting
During a call, one beep indicates another incoming
call. Check with your service provider for information
about this function. Press to receive the waiting
call then press again to switch between calls.
Caller ID
Caller ID displays the number and/or name of the
person calling when your phone rings. Check with
your service provider to ensure they offer this
feature.
Speed Dialing
Speed Dialing allows you to make phone calls
quickly and easily with a few key presses. Speed
Dial number 1 is set to call your Voicemail.
To dial Speed Dials
For Speed Dials 1 to 9 press and hold the Speed Dial
number.
For Speed Dials 10 to 99 press the first digit, then
press and hold the key of the last digit.
Note
Another way to Speed Dial is to enter the speed
dial number(s), then press .
22
ENTERING AND EDITING INFORMATION
ENTERING AND EDITING INFORMATION
Text Input
The following key functions are available to help with
text entry:
Key Functions
●
Left Soft Key
: Press to change text input mode.
Abc
>
ABC
>
abc
●
Shift
: Use to change case.
●
Space
: Press to complete a word and insert
a space.
●
BACK
: Press to delete a single space
character. Hold to delete words.
●
Symbols
: Use to insert special characters or
punctuation.
●
Smiley
: Press key twice to insert smiley
symbols.
●
- Use to type text.
●
- Use to type numbers.
Text Input Examples
Display the text modes and select a text mode:
1. In a text entry field, press Left Soft Key to
display text modes.
2. Press to highlight the text input mode you
want to use.
3. Press to select the highlighted text input
mode.
Using Text Input
1. Press Left Soft Key to change to Abc mode.
2. Press
.
3.
Call the office
is displayed.
Note
The number keys have the patented
Thumb-Friendly
™
software, so even if you hit a
few letters by mistake, you will still get the
number you want.
23
ENTERING AND EDITING INFORMATION
Initial Cap (Abc)
Only the first letter is capitalized. All subsequent
letters are lower case.
Caps Lock (ABC)
All letters are capitalized.
1. Press Left Soft Key to change to ABC mode.
2. Press .
LG
is displayed.
Capitalizing Characters
Press to capitalize your next letter.
Lower Case (abc)
All letters are in lower case.
French Accented Characters
When in French mode, the phone will provide
accented characters by pressing the base letter key
multiple times.(e.g. Press once for e, twice for è, 3
times for é, etc.).
24
CONTACTS IN YOUR PHONE’S MEMORY
CONTACTS IN YOUR
PHONE’S MEMORY
Contacts Entries
Store up to 300 entries with up to 5 phone numbers
each.
Storing Basics
1. Enter a number (max. 48 digits), then press Left
Soft Key
[Save]
.
2. Use to select where to save, then press .
Save New Contact
/
Update Existing Contact
3. Use to select a Label and press .
Mobile 1 / Home / Work / Mobile 2 / Fax
4. Enter a name (max. 22 characters), then press .
5. Press
[Save]
to exit.
Customizing Individual Entries
1. Press Right Soft Key
[Contacts]
.
2. Use to select an entry, then press .
3. Press Left Soft Key
[Edit]
.
4. Use to select the information to customize.
5. Change the entry as you want, then press to
save your changes.
Email
Allows you to enter an email address to the Contact
entry.
Group
Allows you to organize your Contacts into groups.
Picture ID
Sets a picture to display to identify the caller when
they call your phone.
Call Ringtone
Sets the phone to play a specific ringtone when the
Contact calls your phone.
Speed Dial
Allows you to set up your Speed Dials.
1. Press Right Soft Key
[Contacts]
.
2. Use to select an entry, then press .
3. Press Left Soft Key
[Edit]
.
4. Press Right Soft Key [Options].
5. Use to select
Set Speed Dial
, then press
.
6. Enter a Speed Dial digit.
●
Use to select the Speed Dial digit, then
press .
Storing a Number with Pause
Pauses allow you to enter additional series of
numbers to access automated systems such as
Voicemail or credit billing numbers. Pause types are:
Hard Pause (P)
The phone stops dialing until you
press Left Soft Key
[Release]
to send the next string
of digits.
2-sec Pause (T)
The phone waits 2
seconds before sending the next string of digits.
1. Enter the number, then press Right Soft Key
[Options]
.
2. Use to select
Hard Pause
/
2-sec Pause
,
then press .
3. Enter additional number(s) (e.g., pin number,
credit card number, etc.).
4. Press Left Soft Key
[Save]
and continue
saving the Contact entry as needed.
Adding Another Phone Number
From Standby Mode
1. Enter a phone number, then press Left Soft Key
[Save]
.
2. Use to select
Update Existing Contact
,
then press .
3. Use to select an existing entry, then press
.
2. Use to select Mobile1 / Home / Work /
Mobile2 / Fax / Fax2 / None, then press .
5. Press to save.
25
CONTACTS IN YOUR
PHONE’S MEMORY
Note
If you've saved more than one number in the
Contact entry, you have to use to highlight
the phone number first.
26
CONTACTS IN YOUR PHONE’S MEMORY
CONTACTS IN YOUR
PHONE’S MEMORY
From the Contact List Screen
1. Press Right Soft Key
[Contacts]
.
2. Select an entry, then press .
3. Press Left Soft Key
[Edit]
.
4. Use to to highlight the phone number field
you want to add, then enter the number and press
to save
Adding a Pause to a Contact Entry
1. Press Right Soft Key
[Contacts]
.
2. Use to select a Contact entry and press ,
then press
[Edit]
.
3. Use to select the number, then press Right
Soft Key [Options].
4. Use to select pause type and press .
Hard Pause / 2-sec Pause
5. Enter additional number(s), then press .
6. Continue saving the Contact entry as needed.
Changing Saved Information
To change any information you stored, access the
Edit Entry screen:
1. Press Right Soft Key
[Contacts]
.
2. Use to select an entry and press , then
press
[Edit]
.
3. Use to select the information you want to
change.
4. Make the changes, then press .
Changing the Default Number
The Default Number is the phone number you
entered when you created the Contact. Another
number can be saved as the Default Number.
1. Press Right Soft Key
[Contacts]
.
Note
The Set as Default option only appears if the
Contact has at least two phone numbers and you
select any phone number other than the first one.
27
CONTACTS IN YOUR
PHONE’S MEMORY
2. Use to highlight the Contact entry you want
to edit, then press .
3. Press Left Soft Key
[Edit]
.
4. Use to highlight the phone number you
want to set as the Default Number and press Right
Soft Key
[Options]
.
5. Press
Set as Default
.
6. Press to set the new number as the default.
7. Press again to save.
Deleting
Deleting a Phone Number
1. Select an entry to edit.
2. Use to select a phone number.
3. Press and hold to delete the number.
4. Press to save.
Deleting a Contact Entry
1. Select the entry from your Contacts.
2. Press Right Soft Key
[Options]
, then press
Delete
.
3. Press
Yes
.
Deleting a Speed Dial
1. Press Left Soft Key
Menu
, select
Contacts
,
and select
Speed Dials
.
2. Highlight the Speed Dial you want to delete, then
press Right Soft Key
[Options]
.
3. Press
Remove
.
4. Press
Yes
.
Note
If you try to delete the default number, an error
message will pop up.
28
CONTACTS IN YOUR PHONE’S MEMORY
CONTACTS IN YOUR
PHONE’S MEMORY
Searching Your Phone’s Memory
You can search for information you stored in your
LG 490 phone. Scroll through your contents from A
to Z, or jump directly to a specific letter of the
alphabet.
Scrolling Through Your Contacts
1. Press Right Soft Key
[Contacts]
.
Contacts list is displayed alphabetically.
2. Use to scroll through the list.
Searching by Letter
1. Press Right Soft Key
[Contacts]
.
Contacts list is displayed alphabetically.
2. Press (or press repeatedly) the key on the keypad
that corresponds with the search letter.
Calling From Your Phone’s Memory
Place calls quickly and easily to numbers stored in
your phone.
From Contacts
1. Press Right Soft Key
[Contacts]
.
2. Use to highlight the Contact entry.
3. Press to place the call.
From Recent Calls
1. Press Left Soft Key
[Menu]
.
2. Press
Call History
.
3. Use to select the type of recent call and
press .
Note
When you press the Default Number is
dialed. If multiple numbers are saved in the entry,
press to view the Contact entry contents,
highlight the one you want to call and press .
29
CONTACTS IN YOUR
PHONE’S MEMORY
All Calls / Incoming Calls / Outgoing Calls /
Missed Calls
4. Use to highlight the one you want to call,
then press to dial it.
Speed Dialing
Allows you to make phone calls quickly and easily to
numbers stored in Contacts. You need to set Speed
Dials in your Contacts and enable One-Touch Dial
before using this feature.
Speed Dials From 1 to 9.
Press and hold the Speed Dial digit. Your phone
recalls the phone number from your Contacts,
displays it briefly, and then dials it.
Speed Dials From 10 to 99
Press the first Speed Dial digit, then press and hold
the key of the last Speed Dial digit.
Note
You can also enter the Speed Dial digit(s), then
press .
Note
Speed Dial 1 is for Voicemail.
USING PHONE MENUS
30
USING PHONE MENUS
Menu Access
Press Left Soft Key
[Menu]
to have access to
nine phone menus. There are two methods of
accessing menus and submenus:
●
Use the navigation key to highlight and select, or
●
Press the number key that corresponds to the
submenu.
Contacts
The Contacts menu allows you to store names,
phone numbers and other information in your
phone’s memory.
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Contacts
.
3. Select a sub-menu.
1. List Entries
2. New Entry
3. Groups
4. Speed Dials
5. Voice Dials
6. Erase All Contacts
1. List Entries
Allows you to view your Contacts list.
1. Press
,, .
2. Options from here:
●
Press to scroll through your Contacts
alphabetically.
●
Press Right Soft Key
[
Options]
to select one
of the following:
New Message
/
Delete
/
Edit
/
Delete All
●
Press Left Soft Key
[New]
to store a New
Entry.
●
Press
[View]
to view the contact information.
2. New Entry
Allows you to add a new number to your Contacts.
1. Press
,, .
2. Enter the name and press .
3. Use to select the phone number type.
4. Enter the number and press .
3. Groups
Allows you to view your grouped Contacts, add a new
group, change the name of a group, delete a group,
or send a message to everyone in the selected group.
1. Press
,, .
2. Press to highlight a group to view, then
press .
●
Press Left Soft Key
[New]
to add a new group
to the list.
●
Use to highlight a group then press Right
Soft Key
[Options]
to change the name of the
group or delete the group.
Delete
/
Message
/
Rename Group
/
Set Group
Ringtone
/
Delete All
●
Press
[View]
to view the contact information.
31
USING PHONE MENUS
Note
Using this submenu, the number is saved as a new
Contact. To save the number into an existing
Contact, edit the Contact entry.
Note
For more detailed information, see page 24.
4. Speed Dials
Allows you to view your list of Speed Dials or
designate Speed Dials for numbers entered in your
Contacts.
1. Press
,, .
2. Use to highlight the Speed Dial position,
and press .
3. Use to highlight the Contact then press
.
5. Voice Dials
Allows you to view the list of numbers programmed
with voice dialing or add a Voice Dial command to a
number stored in your Contacts.
1. Press
,, .
2. Options from here:
●
Press Left Soft Key
[New]
to record a new
Voice Dial command. Follow the phone’s prompts.
●
Select if you want to start recording when
the pop up message is displayed.
6. Erase All Contacts
Allows you to erase all of your Contacts at once.
1. Press
,, .
2. Press
Yes
.
USING PHONE MENUS
32
USING PHONE MENUS
Note
Recordings should be made in a normal use
position (speaker by your ear and microphone
near your mouth) while using a clear voice.
Hands-free car kits or headsets should be used if
the phone is primarily used with them.
33
USING PHONE MENUS
Call History
The Call History menu is a list of the last phone
numbers or Contact entries for calls you placed,
accepted, or missed. It is continually updated as new
numbers are added to the beginning of the list and
the oldest entries are removed from the bottom of
the list.
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Call History
.
3. Select a sub-menu.
1. All Calls
2. Incoming Calls
3. Outgoing Calls
4. Missed Calls
5. Erase History
6. Call Timers
1. All Calls
Allows you to view the list of all calls; up to 90
entries.
1. Press
,, .
2. Use to highlight an entry, then
●
Press to view the entry.
●
Press to place a call to the number.
●
Press Right Soft Key
[Options]
to select:
Save Contact
/
Dial1+Number
/
Delete
/
Delete All
●
Press Left Soft Key
[Message]
to send a
message.
Shortcut
To view a quick list of all your recent calls,
press from the standby mode.
2. Incoming Calls
Allows you to view the list of incoming calls; up to 30
entries.
1. Press
,, .
2. Use to highlight an entry, then
●
Press to view the entry.
●
Press to place a call to the number.
●
Press Right Soft Key
[Options]
to select:
Save Contact
/
Dial 1 + Number
/
Delete
/
Delete All
●
Press Left Soft Key
[Message]
to send a
message.
2. Outgoing Calls
Allows you to view the list of outgoing calls; up to 30
entries.
1. Press
,, .
2. Use to highlight an entry, then
●
Press to view the entry.
●
Press to place a call to the number.
●
Press Right Soft Key
[Options]
to select:
Save Contact
/
Dial1+Number
/
Delete
/
Delete All
●
Press Left Soft Key
[Message]
to send a
message.
4. Missed Calls
Allows you to view the list of missed calls; up to 30
entries.
1. Press , , .
2. Use to highlight an entry, then
●
Press to view the entry.
●
Press to place a call to the number.
●
Press Right Soft Key
[Options]
to select:
Save Contact
/
Dial1+Number
/
Delete
/
Delete All
●
Press Left Soft Key
[Message]
to send a
message.
USING PHONE MENUS
34
USING PHONE MENUS
35
USING PHONE MENUS
5. Erase History
Allows you to erase selected call list(s).
1. Press , , .
2. Use to highlight the list of calls to erase,
then press .
All Calls
/
Incoming Calls
/
Outgoing Calls
/
Missed Calls
3. Press
Yes
.
6. Call Timers
Allows you to view the duration. Allows you to view
the list of received and transmitted data calls.
1. Press , , .
2. Use to highlight a list.
Last Call
/
All Call
/
Life Time
/
Data
Transferred
/
Connection Time
/
Reset Timer
Messaging
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Messaging
.
3. Select a sub-menu.
1. Voice Mail
2. Text and Multimedia
3. E-mail
4. IM & Chat
5. Web Alerts
6. Short Codes
Text messages, picture messages, and the voice mail
box become available as soon as the phone is
powered on.
●
Check types of messages by pressing the message
key .
●
Make a call to the callback number by pressing
during an Inbox message check.
The phone can store up 521 messages(1 voice mail, 50
inbox text messages, 100 inbox picture messages, 100
inbox picture notification messages, 50 outbox/sent text
messages, 50 outbox/sent picture messages, 50
template messages, 50 draft messages, 20 saved text
messages, 50 saved picture messages). The information
stored in the message is determined by phone mode and
service capability. Other limits to available characters per
message may exist. Please check with your service
provider for system features and capabilities.
New Message Alert
There are three ways your phone alerts you to new
messages.
1. The phone displays a message on the screen.
2. One of 14 ring types is heard, if selected.
3. The message icon ( ) is displayed on the
screen.
1. Voice Mail
Allows you to view new voice messages recorded in
the Voicemail box. When you have a new voice
message, your phone will alert you.
Checking Your Voicemail Box
1. Press , , .
2. Options from here:
●
Press Left Soft Key
[Clear]
to delete
information, and then press
Yes
.
●
Press to listen to the message(s).
2. Text and Multimedia
1. Send New
Allows you to send text messages and picture
messages. Each message has a destination and
information. These are dependent upon the type of
message you want to send.
The Basics of Sending a Message
1. Press , , , .
USING PHONE MENUS
36
USING PHONE MENUS
Note
If you receive the same message twice, your
phone deletes the older one and the new one is
stored as a Duplicate.
37
USING PHONE MENUS
2. Enter the phone number of the recipient or the
email address.
Press Right Soft Key
[Options]
.
Select the option(s) to customize.
●
Contacts
to select a recipient from your Contacts
list.
●
Call History
to select a recipient from your Call
History.
●
Group
to select a recipient from your Group.
●
Set as Cc
●
Set as Bcc
3. Press .
4. Enter the subject and press .
5. Type your message.
Press Right Soft Key
[Options]
.
Select the option(s) to customize.
●
Add
to select Quick Text or Signature.
●
Save As
to select Draft or Template.
●
Settings
to select Priority Level or Callback
Number.
●
Save Quick Text
6. Use to highlight Picture or Video and Left
Soft Key
[Add]
.
Use to select Picture Album or Video Album.
Select Picture or Video and press Left Soft Key
[Select]
.
7. Use to highlight Sounds and Left Soft Key
[Add]
.
Use to select Sound Album.
Select Sound and press Left Soft Key
[Select]
.
Note
To send a message, press .
Note
A disclaimer is displayed
"Cannot insert Video and Picture in the Same
Message." when you try to add video and picture
in one message.
Press Right Soft Key
[Options]
.
Select the option(s) to customize.
●
Preview
to take a look at your message before
sending.
●
Remove
to select Picture, Video, Sound or Slide.
●
Save As
to select Draft or Template.
●
Settings
to select Priority Level, Delivery Report,
Read Report or Slide Timer.
●
Add Slide
to add slide to your message.
8. Press
[Send]
.
A sending screen is displayed.
2. Inbox
The phone alerts you in 3 ways when you receive a
new message:
●
By displaying a message notification on the
screen.
●
By sounding a beep or vibrating, if set.
●
By displaying .
Received text messages and picture messages may be
searched and the contents viewed. Received
messages are displayed from newest to oldest.
Out of Memory Warning
If the memory is full, no more messages can be
received until enough memory space becomes
available. The warning message is displayed and new
messages are not accepted.
Viewing Your Inbox
1. Press , , , .
2. Use to highlight a message and press .
3. Options from here:
●
Left Soft Key
[Reply]
.
●
Right Soft Key
[Options]
.
Delete
Deletes the selected message
from the Inbox.
Forward
Forwards a received message to
other destination address(es).
Save
Stores the callback number,
e-mail address, and numbers
USING PHONE MENUS
38
USING PHONE MENUS
39
USING PHONE MENUS
in user data included in the
received message into your
Contacts.
Move to Saved
Saves the message into the
Saved folder.
Detail
Allows you to check the
received message information.
Lock/Unlock
Locks or unlocks the selected
message.
3. Outbox
Up to 50 sent messages can be stored in Outbox View
lists and contents of sent messages and verify whether
the transmission was successful or not.
1. Press , , , .
2. Use to highlight an Outbox message.
3. Options from here:
●
Left Soft Key
[Resend]
.
●
Right Soft Key
[Options]
.
Delete
Deletes the selected message.
Forward
Forwards a received message
to other destination
address(es).
Save
Stores the callback number,
e-mail address, and numbers
in user data included in the
sent message into your
Contacts.
Move to Saved
Saves the message into the
Saved folder.
Detail
Allows you to check the
selected message information.
Lock/Unlock
Locks or unlocks the selected
message.
4. Templates
1. Press , , , .
2. Press Left Soft Key
[Add]
to create a new
template.
3. Use to highlight a message.
Options from here:
●
Right Soft Key
[Options]
.
Delete
Deletes the selected message
from the Templates.
Lock/Unlock
Locks or unlocks the selected
message.
4. Press to send the selected message.
5. Drafts
Displays draft messages.
1. Press , , , .
2. Use to highlight a message.
Options from here:
●
Press Right Soft Key
[Options]
.
Delete
Deletes the selected message
from the Drafts.
Lock/Unlock
Locks or unlocks the selected
message.
3. Press to send the selected message.
6. Saved
Displays saved messages.
1. Press , , , .
2. Use to highlight a message.
Options from here:
●
Press Right Soft Key
[Options]
.
Delete
Deletes the selected message
from the Saved.
Forward
Forwards a message to other
destination address(es).
Detail
Allows you to check the
selected message information.
Lock/Unlock
Locks or unlocks the selected
message.
3. Press to view the message.
USING PHONE MENUS
40
USING PHONE MENUS
41
USING PHONE MENUS
7. Erase Messages
Allows you to erase all messages stored in your Inbox,
Outbox, Templates, Drafts or Saved messages. You
can also erase all messages at the same time.
1. Press , , , .
●
Press
[Inbox]
to erase all messages stored
in the Inbox.
●
Press
[Outbox]
to erase all messages
stored in Outbox.
●
Press
[Templates]
to erase all messages
stored in the Templates.
●
Press
[Drafts]
to erase all messages
stored in the Drafts.
●
Press
[Saved]
to erase all messages
stored in the Saved messages.
●
Press
[All Messages]
to erase all
messages stored in the Inbox, Outbox/Sent,
Templates, Drafts or Saved messages.
2. Press
Yes
.
8. Settings
Allows you to configure ten settings for messages.
1. Press , , , .
2. Use to highlight a setting, then press .
Save To Outbox Auto Save / Prompt /
Do Not Save
Auto Delete Inbox On / Off
Quick Text 12 predefined phrases
Default Entry Mode Abc / abc / ABC
Auto Download On / Off
Message Priority High / Normal / Low
Delivery Report On / Off
Read Report On / Off
Callback # Set your callback number.
Signature Enter your signature.
Message Settings Sub-Menu Descriptions
Save to Outbox
Allows you to automatically save sent messages in
Outbox when transmitted.
Auto Delete Inbox
Allows you to automatically delete read messages
when you exceed the storage limit.
Quick-Text
Allows you to display, edit and add text phrases.
These text strings allow you to reduce manual text
input into messages.
Default Entry Mode
Allows you to select the default input method
including Abc,
abc
,
ABC
.
Auto Download
Allows you to auto display the content when
receiving a message.
Message Priority
Gives priority to the message.
Delivery Report
Set delivery report to let you know if your message is
delivered to the recipient.
Read Report
Set read report, and you can check out if your
message has been read by the recipient.
Callback #
Allows you to automatically send a designated
callback number when you send a message.
Signature
Allows you to create and/or edit the signature.
USING PHONE MENUS
42
USING PHONE MENUS
43
USING PHONE MENUS
9. Memory Info
Provides you with the memory information of the all
messages stored in each folder.
1. Press , , , .
2. Use .
3. E-mail
Allows you to send an E-mail by
Get New
or by
Online e-mail
. Contact your service provider for
availability.
1. Press , , .
2. Use to select
Get New
or
Online e-mail
then press .
4. IM & Chat
Allows you to send and receive instant message at
any time. Allows you to chat with internet messanger
users.
1. Press , , .
3. Web Alerts
Web Alert is special links or message provided from
the carrier to inform you of special offers, bulletins
and announcements.
1. Press , , .
6. Short Codes
Shows you the Short Codes List
1. Press , , .
Directory
/
Templates
Wireless Web
The MacroBrowser feature allows you to view internet
content, especially designed for your mobile phone.
Access and selections within this feature are
dependent upon your service provider. For specific
information on MacroBrowser access through your
phone, contact your service provider.
Access and Options
Allows you to initiate a MacroBrowser session.
1. Press Left Soft Key
[Menu]
.
2. Press
Wireless Web
.
After a few seconds, you see
the Home Page.
Overview
The MacroBrowser allows the user to use a variety of
Internet services. Using the MacroBrowser on the
phone allows you to:
Send and receive Internet e-mail.
●
Browse and search the World Wide Web via web
pages especially designed for wireless phone
customers.
●
Set bookmarks to directly access your favorite
sites.
●
Retrieve information, such as stock quotes and
flight schedules from the Internet.
Quality of Browser
Browsing the web via the phone is not like using your
home computer. Site providers have selected only the
critical aspects of their site to present to wireless
phone users and have removed most graphics.
Ending the MacroBrowser Session
You can end a MacroBrowser session by pressing
.
USING PHONE MENUS
44
USING PHONE MENUS
Navigating through the Browser
While using the MacroBrowser, you will find the
following content:
●
Numbered options (some options may not be
numbered);
●
Links embedded in content;
●
Text or numeric input;
●
Simple text.
You can act on the options or the links by using the
Soft Keys.
Music
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Music & Media
.
3. Select a sub-menu.
1. Ringtones
2. Wallpaper
3. Camera
4. My Albums
45
USING PHONE MENUS
USING PHONE MENUS
46
USING PHONE MENUS
1. Ringtones
Allows you to download new Ringtones.
1. Press , , .
2. Press to Get New.
2. Wallpaper
Allows you to download new Wallpaper.
1. Press , , .
2. Press to Get New.
3. Camera
View, take and trade your digital pictures and video
right from your wireless phone.
3.1 Take Photo
1. Press , , , .
2. Set the brightness , zoom , flash ,
and press Right Soft Key
[Options]
to change
other settings.
●
Select the option(s) to customize.
Resolution
640X480 / 320X240 /
160X120
Quality
Economy / Normal / Fine
Zoom
x1 to x10
Brightness
-2.0 to +2.0
Flash
On / Off
Multishot
1 Shots / 3 Shots
Self-timer
None / 3 Seconds /
5 Seconds
White Balance
Auto / Sunny / Cloudy /
Tungsten / Fluorescent
Night mode
On / Off
Filter Effects
Normal / Sepia /
Black&White / Negative /
Solari
Note
From Take Photo mode, you can change to Take
Video mode by pressing the Side Camera Key .
Note
Press and holding the Side Camera Key from
standby mode is a hot key to Take Photo.
Shutter Sound
Shutter1 / Shutter2
3. Take a picture by pressing .
4. Press .
The picture is stored in Picture Album.
Using the Side Camera Key
You can use the Side Camera Key to use the sub
menu list when the flip is closed. The picture and the
exit menu are shown on the outside display.
1. Press the Side Camera Key for about 3
seconds to enter the Take Photo mode.
2. Take a picture by pressing Side Camera Key .
3. Press the Side Camera Key for about 3
second to exit camera mode.
4. My Albums
4.1 Sound Album
1. Press , , , .
2. Select your desired sound with and press
Right Soft Key
[Options]
.
3. Select one of the following options:
Send Message
Sends a message.
Delete
Yes / No
Rename
Rename the selected Sound.
Move
Yes / No
Copy
Yes / No
Delete All
Yes / No
Details
Name / Size / Type
Upload Online Album
Accesses the Online Album.
47
USING PHONE MENUS
Note
When the Flash is On, take the photo within 12
inches of the subject.
4.2 Picture Album
Allows you to view pictures stored in the phone.
1. Press , , , .
2. Select your desired picture with and press
Right Soft Key
[Options]
.
Send Message
Sends a message.
Delete
Yes / No
Rename
Rename the selected picture.
Move
Yes / No
Copy
Yes / No
Delete All
Yes / No
Icon View(List View)
Details
Name / Size / Resolution /
Type
Set As
Main wallpaper /
sub wallpaper / Picture ID
Upload Online Album
Accesses the Online Album.
4.3 Online Album
Access the Online Album.
1. Press , , , .
USING PHONE MENUS
48
USING PHONE MENUS
Shop
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Shop
.
After a few seconds, you see
the Home Page.
Games
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Games
.
3. Select a sub-menu.
Get New
49
USING PHONE MENUS
Tool & App
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Tools & Apps
.
3. Select a sub-menu.
Get New
GPS Services
Calculator
Alarm Clock
Scheduler
Notepad
EZ Tip Calc
World Clock
Voice Memo
1. Get New
1. Press , .
2. Scroll to
Get New
and press .
After a few seconds, you will see the Home Page.
2. GPS Services
1. Press , .
2. Scroll to
GPS Services
and press .
3. Press to Get New.
After a few seconds, you will see the Home Page.
3. Calculator
You can enter numbers up to the second decimal
place.
1. Press , .
2. Scroll to
Calculator
and press .
3. Enter data.
●
Use keypad to enter numbers.
●
Use to enter decimals.
●
Use to enter brackets.
●
Press Left Soft Key to clear the entry.
●
Press Right Soft Key to enter algebraic operators.
●
Use Navigation Key to enter operators.
●
Press to complete equation.
USING PHONE MENUS
50
USING PHONE MENUS
51
USING PHONE MENUS
4. Alarm Clock
Your phone comes with a built-in alarm clock with
multiple alarm capabilities.
1. Press , .
2. Scroll to
Alarm Clock
and press .
3. Press Left Soft Key
New
to add a new alarm.
4. Use to select
Off
/
Manual
/
10 Min Later
/
20 Min Later
/
30 Min Later
/
1 Hour Later
then press .
5. Set the time for alarm and press .
6. Press to select one of the following:
Once
/
Daily
/
Mon~Fri
/
Sat~Sun
7. Use to highlight Ring (ring type setting),
press Left Soft Key
List
, and select your
desired ring.
8. Use to select Note then type your note
using the numeric keypad .
9. Press .
5. Scheduler
Allows you to conveniently keep and access your
agenda(s). Simply store your appointments and your
phone will alert you with a reminder of your
appointment.
1. Press , .
2. Scroll to
Scheduler
and press .
3. Using your navigation key, highlight the day to
which you would like to add an event and press
Left Soft Key
New
.
4. Enter your schedule information including:
●
Date
●
Time
●
Subject
●
Reminder(On Time / 15 minutes before /
30 minutes before / 1 hour before / 1 day
before / 3 days before / 1 week before /
No Reminder)
●
Repeat
●
Expiration(No Expiration / Set Expiration)
5. Press .
USING PHONE MENUS
52
USING PHONE MENUS
6. Notepad
Allows you to add, read, edit, and erase notes to
yourself.
1. Press , .
2. Scroll to
Notepad
and press .
3. Press Left Soft Key
New
to write a new note.
4. Type your note using the numeric keypad and
press .
7. EZ Tip Calc
Allows you to quickly and easily calculate the amounts
for a bill with the amount of the bill, the amount of
the tip, and the number of people as variables.
1. Press , .
2. Scroll to
EZ Tip Calc
and press .
3. Use your keypad and navigation key to enter the
bill amount and desired tip percentage. The
correct tip will be calculated instantly.
4. If you’re splitting the check, highlight Split and
enter the number of people in your party. (An
equal split of the bill will be calculated and
displayed.)
8. World Clock
Allows you to determine the current time in another
time zone or country.
1. Press , .
2. Scroll to
World Clock
and press .
3. Use to move the cross hairs across the map
or press Right Soft Key
[Cities]
to enter a
specific city.
4. Press Left Soft Key
[Set DST]
to set Daylight
Saving Time for the selected city.
53
USING PHONE MENUS
9. Voice Memo
Allows you to add, listen to, and erase short verbal
reminders.
Recording a Voice Memo
To record a memo:
1. Press , .
2. Scroll to
Voice Memo
and press .
3. Press to record a new Voice Memo. (The
phone prompts you to start recording after the
beep.)
4. To finish recording, press Save.
Playing a Voice Memo
To play the voice memos you have recorded:
1. Press , .
2. Scroll to
Voice Memo
and press .
3 Press Left Soft
[List]
.
Options from here:
Select your desired Voice Memo with and
press Right Soft Key
[Options]
.
Send Message
Sends a message
Delete
Yes / No
Rename
Rename the selected Sound
Move
Yes / No
Copy
Yes / No
Delete All
Yes / No
Details
Name / Size / Type
Upload Online
Accesses the Online Album
Album
Shortcut
Press the Side Key for Voice Memo for 3 seconds.
USING PHONE MENUS
54
USING PHONE MENUS
Settings
The Settings menu has options to customize your
phone.
Access and Options
1. Press Left Soft Key
[Menu]
.
2. Press
Settings
.
3. Select a sub-menu.
1. Sound
2. Display
3. Games / Tools
4. Bluetooth
5. GPS
6. Others
7. System
8. Airplane Mode
1. Sound
Options to customize various sounds emitted from
the phone.
1.1 Ringers
1.1.1 Voice Calls
Allows you to set ringtones for different types of
incoming calls.
1. Press
, , , , .
2. Select an incoming call type.
Caller ID / Unknown Calls / Roaming
3. Use to select a ringer, then press Left Soft
Key
Set
to save the sound.
1.1.2 Messages
1. Press
, , , , .
2. Select an incoming call type.
Voice Mail / Text and Multimedia / Web-Alerts /
Reminder
55
USING PHONE MENUS
3. Use to select a ringer, then press Left Soft
Key
Set
to save the sound.
1.1.3 Meeting / Silent Mode
1. Press , , , , .
2. Use to set the setting, then press to
save the change.
On / Off
1.2 Keypad
1.2.1 Keypad Sound
1. Press , , , , .
2. Use to adjust the volume of the keypad, then
press to save the change.
1.2.2 DTMF Length
Allows you to set the DTMF Length and touch tone
playback speed.
1. Press
, , , , .
2. Use to select a length, then .
Short
Sends out a tone for a fixed period of
time even if you keep the key pressed.
Long
Sends out a continuous tone for as long
as you keep the key pressed.
1.3 Volume
1.3.1 Master
Allows you to set master volume settings.
1. Press , , , , .
2 Use to adjust the volume, then press to
save the change.
1.3.2 Earpiece
Allows you to set earpiece volume settings.
1. Press , , , , .
2 Use to adjust the earpiece volume, then
press to save the change.
USING PHONE MENUS
56
USING PHONE MENUS
1.3.3 Power On/Off
Allows you to set the phone to sound a tone when
the phone is powered on and off.
1. Press , , , , .
2. Use to set the alert tone, then press to
save the change.
On / Off
1.4 Alerts
1. Press , , , .
1.4.1 Service Change
Alerts you when service changes. Phone displays
Entering Service Area or Leaving Service Area
message.
1.4.2 Minute Beep
Alerts you 10 seconds before the end of every
minute during a call.
1.4.3 Call Connect
Alerts you when the call is connected.
1.4.4 Call Lost
Alerts you when the call is disconnected.
1.4.5 No Service
No service is supported.
2. Use to set the alert setting, then press
to save the change.
On
/
Off
2. Display
Options to customize the phone's display screen.
2.1 Banner
Allows you to enter a string of up to 13 characters
which display on the LCD screen.
1. Press , , , .
2. Use to select
On
, then press .
3. Enter your banner text, then press .
57
USING PHONE MENUS
2.2 Wallpaper
Allows you to choose the kind of background to be
displayed on the phone.
1. Press , , , .
2. Select a sub-menu and press .
Main Display
/
Front Display
3. Select from different images, then press .
4. Press Left Soft Key
[Set]
.
2.3 Backlight
Allows you to set the duration for illuminating the
LCD backlight.
1. Press , , , .
2. Select a sub-menu and press .
Main Display
/
Front Display
3. Use to select a setting, then press to
save the change.
7 Seconds / 15 Seconds / 30 Seconds /
Always On / Always Off
2.4 Keypad light
Allows you to set the duration for illuminating the
phone's keypad.
1. Press , , , .
2. Use to select a setting, then press to
save the change.
7 Seconds / 15 Seconds / 30 Seconds /
Always On / Always Off
2.5 Clock Format
Allows you to choose the clock format displayed on
the LCD screen.
1. Press , , , .
2. Select a sub-menu and press .
Main Display
/
Front Display
2. Use to select the clock format, then press
.
Main Display
: Off / Small Digital / Big Digital /
Analog
Front Display
: Normal / Analog / Minimize
2.6 Menu Style
Allows you to view the Menus as icons or in a list
format.
1. Press , , , .
2. Use to select a menu format, then press .
Icon
/
List
2.7 Dialing font
Allows you to set the size and color of the font for
calling digits.
1. Press , , , .
2. Use to choose a setting, then press .
Normal
/
Large
3. Games / Tools
3.1 Backlight Settings
Allows you to set the duration for illuminating the
backlight.
1. Press , , , .
2. Use to select a setting, then press to
save the change.
7 Seconds / 15 Seconds / Always On / Always
Off
3.2 Volume
Allows you to set volume settings.
1. Press , , , .
2 Use to adjust the volume, then press to
save the change.
3.3 Notifications
Allows you to set notification settings.
1. Press , , , .
2. Select a sub-menu and press .
Voice Mail
/
Messages
3. Use to set the alert setting, then press
to save the change.
On / Off
USING PHONE MENUS
58
USING PHONE MENUS
59
USING PHONE MENUS
4. BluetoothTM
The LG 490 is compatible with devices that support
the Bluetooth headset and hands-free profile(s)*.
You may create and store 20 pairings within the
LG 490 and connect to one device at a time. The
approximate communication range for Bluetooth
wireless technology is up to 30 feet (10 meters).
4.1 Power
Allows you to set the power On/Off.
1. Press , , , .
2. Use to select a setting, then press .
On / Off
4.2 Device List
Pairing is the process that allows the handset to
locate, establish and register 1-to-1 connection with
the target device.
For pairing new Bluetooth device
1. Press , , , .
2. Follow the Bluetooth accessory instructions to set
the device to pairing mode.
3. Press Right Soft Key for New. Select
Search
New
.
4. If Bluetooth is set to off, you will be prompted to
turn power on. Select
Yes
.
5. The device will appear in the Found Devices menu
once it has been located. Highlight the device and
press .
6. The handset will prompt you for the passkey.
Consult the Bluetooth accessory instructions for
the appropriate passkey (typically “0000”). Enter
the passkey and press .
NOTE
Read user guide of each bluetooth accessory that
you are trying to pair with your phone because
the instructions may be different.
NOTE
If you turn on My Visibility, your device is able to
be searched by other in-range Bluetooth devices.
7. Once pairing is successful, select
Yes
to
connect with the device.
8. Once connected, you will see the device listed in
the Paired Devices menu and the Bluetooth
connected icon will show at the top of the
LCD screen.
4.3 Discovery Mode
Allows you to set On (60 secs) / Off.
1. Press , , , .
2. Use to select a setting, then press .
On(60 secs) / Off
4.4 Device Scan
1. Press , , , .
2. Use to select a menu, then press .
Scan Now
/
Always ON
4.5 Device Name
Allows you edit the name of the bluetooth name.
1. Press , , , .
2. Press to clear the existing name.
3. Use the numeric keypad to enter a new custom
name.
4. Press to save and exit.
5. GPS
5.1 GPS Status
1. Press , , , .
2. Use to select a setting, then press .
On / Emergency
5.2 GPS Privacy
1. Press , , , .
USING PHONE MENUS
60
USING PHONE MENUS
NOTE
By default, your device’s Bluetooth functionality
is turned off.
61
USING PHONE MENUS
2. Use to select a setting, then press .
By Permission / Restricted / Unrestricted
6. Others
6.1 Nav. Key Shortcuts
Assign a shortcut to your favorite and most
frequently used function. Select it from the list, and
then access it directly by pressing in standby
mode.
1. Press , , , .
2. Read the disclaimer and press .
3. Select a menu and press .
Left Nav. Key / Right Nav. Key
6.2 Call Setup
6.2.1 Call Answer
Allows you to determine how to handle an answered
call.
1. Press , , , , .
2. Use to select a setting, then press .
Send Key / Any Key / Flip Open
6.2.2 Auto Answer
Allows you to set the length of the time before the
phone automatically answers a call. This feature is
intended for use with hands free devices, but is an
independent feature of the phone and must be
manually turned on/off when connected or
disconnected from the device.
1. Press , , , , .
2. Use to select a setting, then press .
Off / 2 Seconds / 4 Seconds / 8 Seconds
6.2.3 Auto Prepend
Allows you to add Dial 1+ Number to Options in
recent calls list. If you choose Dial 1+ Number in
recent calls list, Terminal displays dialing screen and
shows 1+ Number on the screen regardless of calling
digits condition.
1. Press , , , , .
USING PHONE MENUS
62
USING PHONE MENUS
2. Use to select a setting, then press .
On / Off
6.2.4 Auto Redial
Allows you to set the length of time the phone waits
before automatically redialing a number when the
attempted call fails.
1. Press , , , , .
2. Use to select a setting, then press .
Off / Every 10 Seconds / Every 30 Seconds /
Every 60 Seconds
6.3 Language
Allows you to set the bilingual feature according to
your preference. Choose between English and French.
1. Press , , , .
2. Use to select
English
or
French
, then press
.
6.4 TTY Mode
Allows you to attach a TTY device enabling you to
communicate with parties also using a TTY device. A
phone with TTY support is able to translate typed
characters to voice. Voice can also be translated into
characters and then displayed on the TTY.
* TTY : Text Telephone. (or Teletypewriter for Deaf).
1. Press , , , .
2. Read the disclaimer and press .
3. Use to select a setting, then press .
TTY Full / TTY + Talk / TTY + Hear / TTY Off
1. TTY Full :
Users who cannot talk and hear send and receive
a text message through TTY equipment.
2. TTY + Talk :
Users who can talk but cannot hear receive a text
message and send voice through TTY equipment.
3. TTY + Hear :
Users who can hear but cannot talk send a text
message and receive voice through TTY equipment.
4. TTY Off :
Normal users send and receive without TTY
equipment.
Connecting TTY Equipment and a Terminal
1. Connect a TTY cable to TTY connection on the
terminal. (TTY connection location is same as the
hands free ear jack)
2. Enter the phone menu and set up the desired TTY
mode. (For a TTY mode, see the following)
3. After setting a TTY mode, check the LCD screen of
the phone for the TTY icon.
4. Connect the TTY equipment to the power source
and turn it on.
5. Make a phone connection to the desired number.
6. When connection is made, use the TTY equipment
to type in and send a text message or send voice.
7 The voice or text message from the receiver end
displays on the TTY equipment display.
63
USING PHONE MENUS
Menu User Feature
Transmission/
Receiving
Mode
When making
communications
with a normal
terminal
TTY
Full
For
hearing-
/verbally-
impaired
text message
transmission,
text message
receiving
operator
required
TTY+
Talk
For
hearing-
impaired
Verbal
voice
transmission,
text message
receiving
TTY+
Hear
For
verbally-
impaired
audible
text message
transmission,
voice
receiving
operator
required
TTY
Off
For
regular
users
voice
transmission,
voice
receiving
6.5 Data Setup
6.5.1 Data/Fax
Allows you to use your phone to transmit data and
faxes.
1. Press , , , , .
2. Use to select a setting, then press .
Off / Fax In Once / Fax In Always / Data In Once
/ Data In Always
6.5.2 PC Connection
Allows you to select the data port.
1. Press , , , , .
2. Use to select a setting, then press .
USB / Bluetooth / Closed
6.6 Memory Info
Shows you the memory information of the phone.
6.6.1 Common Memory
1. Press , , , , .
6.6.2 Reserved Memory
1. Press , , , , .
7. S y s t e m
Options for specific system network settings.
7.1 Phone Info
The Phone Info menu provides you with specific
information pertaining to your phone model.
7.1.1 NAM
Allows you to view your phone number.
1. Press , , , , .
USING PHONE MENUS
64
USING PHONE MENUS
NOTE
The Data Connection Kit allows you to connect
your PC or PDA to your LG wireless phone,
freeing you from having to locate a telephone
outlet. You can send or receive an e-mail, a fax, or
access the Internet anytime, anywhere.
NOTE
When using the 1X HSPD data service via a USB
data cable, you may get better port speed if the
port speed is set to 230,400 rather than 115,200.
7.1.2 Software Version
Allows you to view the SW Version.
1. Press , , , , .
7.1.3 Hardware Version
Allows you to view the
Hardware
Version.
1. Press , , , , .
7.1.4 4ESN
Allows you to view the ESN.
1. Press , , , , .
7.1.5 PRL
Allows you to view the
PRL
Version.
1. Press , , , , .
7.1.6 Browser Version
Allows you to view the
Browser
Version.
1. Press , , , , .
7.1.7 Serving System
Identifies the channel number of a system that is
served and a SID Number. This information is only for
technical support.
1. Press , , , , .
7.1.8 Icon Glossary
Allows you to view all the icons and their meanings.
1. Press , , , , .
7.1.9 Brew Version
Allows you to view the
Brew
Version.
1. Press , , , , .
7.2 System
The System menu allows you to designate specific
system network settings.
7.2.1 Set Mode
Allows you to set up the phone producer’s
management environment. Leave the default setting
65
USING PHONE MENUS
unless you want to alter the system selection as
instructed by your service provider.
1. Press , , , , .
2. Use to select a setting, then press .
Home Only / Automatic A / Automatic B
7.2.2 Set NAM
Allows you to select the phone's NAM (Number
Assignment Module) if the phone is registered with
multiple service providers.
1. Press , , , , .
2. Use to select a NAM, then press .
NAM 1 / NAM 2
7.2.3 Call Guard
Call Guard alerts you when roaming charges apply.
1. Press , , , , .
2. Use to select a setting, then press .
On / Off
7.3 Security
Allows you to secure the phone electronically.
7.3.1 Lock Phone
Keeps your phone from unauthorized use. Once the
phone is locked, it is in restricted mode until the lock
code is entered. You can receive phone calls and still
make emergency calls. You can modify the lock code
using the New Lock code within the Security menu.
1. Press , , , .
2. Enter the 4-digit password.
The lock code is commonly the last 4 digits of
your phone number.
3. Press
Lock Phone
.
4. Use to select a setting, then press .
Unlock
The phone is never locked.
Lock
The phone is always locked. When
locked, you can only receive incoming
calls or make emergency calls.
On Power Up
The phone is locked when it is
turned on.
USING PHONE MENUS
66
USING PHONE MENUS
7.3.2 Change Lock Code
Allows you to change to a new four-digit lock code.
1. Press , , , .
2. Enter the 4-digit password.
The lock code is commonly the last 4 digits of
your phone number.
3. Press
Change Lock Code
.
4. Enter a old four-digit lock code.
5. Enter a new four-digit lock code.
6. Enter the new lock code again to confirm the
original entry.
7.3.3 Reset Defaults
Allows you to reset your phone to the factory default
settings.
1. Press , , , .
2. Enter the 4-digit password.
The lock code is commonly the last 4 digits of
your phone number.
3. Press
Reset Defaults
.
4. Read the screen message, then press .
5. Press Revert to change your phone settings
back to the factory defaults or press Cancel
to exit without changing.
8. Airplane Mode
Airplane Mode allows you to use many of your
phone’s features, such as Games, Notepad, Voice
Memos, etc., when you are in an airplane or in any
other area where making or receiving calls or data is
prohibited. When your phone is in Airplane Mode, it
cannot send or receive any calls or access online
information.
1. Press , , .
2. Use to select a setting, then press .
On / Off
67
USING PHONE MENUS
SAFETY
68
SAFETY
TIA(Telecommunications Industry
Association) Safety Information
The following is the complete TIA Safety Information
for wireless handheld phones.
Exposure to Radio Frequency Signal
Your wireless handheld portable phone is a low power
radio transmitter and receiver. When it is ON, it
receives and also sends out Radio Frequency (RF)
signals. In August, 1996, the Federal Communications
Commissions (FCC) adopted RF exposure guidelines
with safety levels for handheld wireless phones.
Those guidelines are consistent with the safety
standards previously set by both U.S. and
international standards bodies:
●
ANSI C95.1 (1992) *
●
NCRP Report 86 (1986)
●
ICNIRP (1996)
●
Health Canada, Safety Code 6, 1999.
Those standards were based on comprehensive and
periodic evaluations of the relevant scientific
literature. For example, over 120 scientists, engineers,
and physicians from universities, government health
agencies, and industry reviewed the available body of
research to develop the ANSI Standard (C95.1).
The design of your phone complies with the FCC
guidelines, IC Regulations (and those standards).
Antenna Care
Use only the supplied or an approved replacement
antenna. Unauthoriaed antennas, modifications, or
attachments could damage the phone and may
violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would
any other telephone with the antenna pointed up
and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
Do not touch the antenna unnecessarily when the
phone is in use. Contact with the antenna affects call
quality and may cause the phone to operate at a
higher power level than otherwise needed.
Driving
Check the laws and regulations on the use of wireless
phones in the areas where you drive and always obey
them. Also, if using your phone while driving, please
observe the following:
●
Give full attention to driving -- driving safely is
your first responsibility;
●
Use hands-free operation, if available;
●
Pull off the road and park before making or answering
a call if driving conditions or the law so require.
Electronic Devices
Most modern electronic equipment is shielded from
RF signals. However, certain electronic equipment
may not be shielded against the RF signals from your
wireless phone.
Pacemakers
The Health Industry Manufacturers Association
recommends that a minimum separation of six inches
be maintained between a handheld wireless phone
and a pacemaker to avoid potential interference with
the pacemaker. These recommendations are
consistent with the independent research by and
recommendations of Wireless Technology Research.
Persons with Pacemakers:
●
Should ALWAYS keep the phone more than six
inches from their pacemaker when the phone is
turned ON;
●
Should not carry the phone in a breast pocket;
●
Should use the ear opposite the pacemaker to
minimize the potential for interference;
●
Should turn the phone OFF immediately if there is
any reason to suspect that interference is taking
place.
69
SAFETY
SAFETY
70
SAFETY
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may want to consult your service provider (or call the
customer service line to discuss alternatives.)
Optional for each phone manufacturer.
Other Medical Devices
If you use any other personal medical device, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information.
Health Care Facilities
Turn your phone OFF in health care facilities when
any regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may use
equipment that could be sensitive to external RF
energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted
notices so require.
Aircraft
FCC and Transport Canada regulations prohibit using
your phone while in the air. Switch OFF your phone
before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn
your phone OFF when in a “blasting area” or in areas
posted: “Turn off two-way radio”. Obey all signs and
instructions.
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Areas with a potentially explosive atmosphere are
often, but not always marked clearly. Potential areas
may include: fueling areas (such as gasoline stations);
below deck on boats; fuel or chemical transfer or
storage facilities; vehicles using liquefied petroleum
gas (such as propane or butane); areas where the air
contains chemicals or particles (such as grain, dust,
or metal powders); and any other area where you
would normally be advised to turn off your vehicle
engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place
objects, including either installed or portable wireless
equipment, in the area over the air bag or in the air
bag deployment area. If in-vehicle wireless equipment
is improperly installed and the air bag inflates, serious
injury could result.
Charger and Adapter Safety
●
The charger and adapter are intended for indoor
use only.
●
Do not expose the battery charger or adapter to
direct sunlight or use it in places with high
humidity, such as a bathroom.
Battery Information and Care
●
Please dispose of your battery properly or take it
to your local wireless carrier for recycling.
●
Do not dispose of your battery by fire or with
hazardous or flammable materials..
●
Never use an unapproved battery since this could
damage the phone and/or battery and could
cause the battery to explode.
●
The battery does not need to be fully discharged
before recharging.
●
Use only LG-approved chargers specific to your
phone model since they are designed to maximize
battery life.
●
Do not disassemble or short-circuit the battery.
71
SAFETY
●
Keep the battery’s metal contacts clean.
●
Replace the battery when it no longer provides
acceptable performance. The battery can be
recharged several hundred times before
replacement.
●
Recharge the battery after long periods of non-use
to maximize battery life.
●
Battery life will vary due to usage patterns and
environmental conditions.
●
Use of extended backlighting, MiniBrowser, and
data connectivity kits affect battery life and
talk/standby times.
Safety Information
Please read and observe the following information for
safe and proper use of your phone and to prevent
damage. Also, keep the user’s guide in an accessible
place at all the times after reading it.
Explosion, Shock, and Fire Hazards
●
Unplug the power cord and charger during
lightning storms to avoid electric shock or fire.
●
Make sure that no sharp-edged items such as
animal’s teeth, nails, come into contact with the
battery. There is a risk of this causing a fire.
●
Do not use harsh chemicals(such as alcohol,
benzene, thinners, etc.) or detergents to clean
your phone. There is a risk of this causing a fire.
●
When riding in a car, do not leave your phone or
set up the hands-free kit near to the air bag. If
wireless equipment is improperly installed and the
air bag is activated, you may be seriously injured.
●
Do not handle the phone with wet hands while it
is being charged. It may cause an electric shock or
seriously damage your phone.
●
Do not drop, strike, or shake your phone severely.
Such actions may harm the internal circuit boards
of the phone.
●
Be careful that children do not swallow any parts
such as rubber plugs (earphone, connection parts
of the phone, etc.). This could cause asphyxiation
or suffocation.
●
Do not use your phone in high explosive areas as
the phone may generate sparks.
SAFETY
72
SAFETY
●
Do not put your phone in a place subject to
excessive dust and keep the minimum required
distance between the power cord and heat sources.
●
Unplug the power cord prior to cleaning your
phone, and clean the power plug pin when it is dirty.
●
Do not damage the power cord by bending,
twisting, pulling, or heating. Do not use the plug if
it is loose as it may cause a fire or electric shock.
●
When using the power plug, ensure that it is firmly
connected. If it is not, it may cause excessive heat
or fire.
●
Do not place any heavy items on the power cord.
Do not allow the power cord to be crimped as it
may cause fire or electric shock.
●
Do not disassemble the phone.
●
Do not place or answer calls while charging the
phone as it may short-circuit the phone and/or
cause electric shock or fire.
●
If you put your phone in a pocket or bag without
covering the receptacle of the phone (power plug
pin), metallic articles (such as a coin, paperclip or
pen) may short-circuit the phone. Always cover the
receptacle when not in use.
●
Do not short-circuit the battery. Metallic articles
such as a coin, paperclip or pen in your pocket or
bag may short-circuit the + and – terminals of the
battery (metal strips on the battery) upon moving.
Short-circuit of the terminal may damage the
battery and cause an explosion.
●
Never place your phone in a microwave oven as it
will cause the battery to explode.
General Warnings and Cautions
●
Only use the batteries, antennas, and chargers
provided by LG. The warranty will not be applied
to products provided by other suppliers.
●
Store the battery in a place out of reach of
children.
●
Using a damaged battery or placing a battery in
your mouth may cause serious injury.
●
Do not place items containing magnetic
components such as a credit card, phone card,
bank book or subway ticket near your phone. The
magnetism of the phone may damage the data
stored in the magnetic strip.
●
Do not hold or let the antenna come in contact
with your body during a call.
73
SAFETY
●
Talking on your phone for a long period of time
may reduce call quality due to heat generated
during use.
●
When the phone is not used for a long period
time, store it in a safe place with the power cord
unplugged.
●
Using the phone in proximity to receiving
equipment (i.e., TV or radio) may cause
interference to the phone.
●
Only authorized personnel should service the
phone and its accessories. Faulty installation or
service may result in accidents and consequently
invalidate the warranty.
●
Do not use the phone if the antenna is damaged.
If a damaged antenna contacts skin, it may cause a
slight burn. Please contact an LG Authorized
Service Center to replace the damaged antenna.
●
Do not use the phone in areas where its use is
prohibited. (For example: aircraft).
●
Do not immerse your phone in water. If this
happens, turn it off immediately and remove the
battery. If the phone does not work, take it to an
LG Authorized Service Center.
FDA Consumer Update
The U.S. Food and Drug Administration’s
Center for Devices and Radiological
Health Consumer Update on Mobile
Phones:
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radiofrequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the Main Menu Screen.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that
does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects.
Some studies have suggested that some biological
effects may occur, but such findings have not been
confirmed by additional research. In some cases,
other researchers have had difficulty in reproducing
those studies, or in determining the reasons for
inconsistent results.
SAFETY
74
SAFETY
2. What is the FDA's role concerning the safety of
wireless phones?
Under the law, the FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, the FDA could
require the manufacturers of wireless phones to
notify users of the health hazard and to repair,
replace, or recall the phones so that the hazard no
longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, the FDA has urged the
wireless phone industry to take a number of steps,
including the following:
●
Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
●
Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
●
Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
The FDA belongs to an interagency working group of
the federal agencies that have responsibility for
different aspects of RF safety to ensure coordinated
efforts at the federal level. The following agencies
belong to this working group:
●
National Institute for Occupational Safety and
Health
●
Environmental Protection Agency
●
Occupational Safety and Health Administration
●
National Telecommunications and Information
Administration
The National Institutes of Health participates in
some interagency working group activities, as well.
The FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure.
The FCC relies on the FDA and other health agencies
for safety questions about wireless phones.
75
SAFETY
The FCC also regulates the base stations that the
wireless phone networks rely upon. While these base
stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get
from these base stations are typically thousands of
times lower than those they can get from wireless
phones. Base stations are thus not the subject of the
safety questions discussed in this document.
3. What kinds of phones are the subject of this
update?
The term “wireless phone” refers here to handheld
wireless phones with built-in antennas, often called
“cell”, “mobile”, or “PCS” phones. These types of
wireless phones can expose the user to measurable
radiofrequency energy (RF) because of the short
distance between the phone and the user’s head.
These RF exposures are limited by FCC safety
guidelines that were developed with the advice of the
FDA and other federal health and safety agencies.
When the phone is located at greater distances from
the user, the exposure to RF is drastically lower
because a person's RF exposure decreases rapidly
with increasing distance from the source. The
socalled “cordless phones,” which have a base unit
connected to the telephone wiring in a house,
typically operate at far lower power levels, and thus
produce RF exposures far below the FCC safety
limits.
4. What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radiofrequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with
ancercausing chemicals so as to be pre-disposed to
develop cancer in the absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours
per day. These conditions are not similar to the
conditions under which people use wireless phones,
so we don’t know with certainty what the results of
SAFETY
76
SAFETY
such studies mean for human health. Three large
epidemiology studies have been published since
December 2000. Between them, the studies
investigated any possible association between the
use of wireless phones and primary brain cancer,
glioma, meningioma, or acoustic neuroma, tumors of
the brain or salivary gland, leukemia, or other
cancers. None of the studies demonstrated the
existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies
can answer questions about long-term exposures,
since the average period of phone use in these
studies was around three years.
5. What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could
be completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10
or more years follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop — if they do — may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
6. What is the FDA doing to find out more about
the possible health effects of wireless phone RF?
The FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
The FDA has been a leading participant in the World
Health Organization International Electromagnetic
Fields (EMF) Project since its inception in 1996. An
influential result of this work has been the
development of a detailed agenda of research needs
77
SAFETY
that has driven the establishment of new research
programs around the world. The project has also
helped develop a series of public information
documents on EMF issues. The FDA and the Cellular
Telecommunications & Internet Association (CTIA)
have a formal Cooperative Research and
Development Agreement (CRADA) to do research on
wireless phone safety. The FDA provides the scientific
oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through
contracts with independent investigators. The initial
research will include both laboratory studies and
studies of wireless phone users. The CRADA will also
include a broad assessment of additional research
needs in the context of the latest research
developments around the world.
7. How can I find out how much radio frequency
energy exposure I can get by using my wireless
phone?
All phones sold in the United States must comply
with Federal Communications Commission (FCC)
guidelines that limit radio frequency energy (RF)
exposures. The FCC established these guidelines in
consultation with the FDA and the other federal
health and safety agencies. The FCC limit for RF
exposure from wireless telephones is set at a Specific
Absorption Rate (SAR) of 1.6 watts per kilogram
(1.6 W/kg). The FCC limit is consistent with the
safety standards developed by the Institute of
Electrical and Electronic Engineering (IEEE) and the
National Council on Radiation Protection and
Measurement. The exposure limit takes into
consideration the body’s ability to remove heat from
the tissues that absorb energy from the wireless
phone and is set well below levels known to have
effects. Manufacturers of wireless phones must report
the RF exposure level for each model of phone to the
FCC. The FCC website (http://www.fcc.gov/oet/
rfsafety) gives directions for locating the FCC
identification number on your phone so you can find
your phone’s RF exposure level in the online listing.
SAFETY
78
SAFETY
8. What has the FDA done to measure the radio
frequency energy coming from wireless phones?
The Institute of Electrical and Electronic Engineers
(IEEE) is developing a technical standard for
measuring the radio frequency energy (RF) exposure
from wireless phones and other wireless handsets
with the participation and leadership of FDA
scientists and engineers. The standard,
“Recommended Practice for Determining the Spatial-
Peak Specific Absorption Rate (SAR) in the Human
Body Due to Wireless Communications Devices:
Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate
at which RF is deposited in the heads of wireless
phone users. The test method uses a tissuesimulating
model of the human head. Standardized SAR test
methodology is expected to greatly improve the
consistency of measurements made at different
laboratories on the same phone. SAR is the
measurement of the amount of energy absorbed in
tissue, either by the whole body or a small part of
the body. It is measured in watts/kg (or milliwatts/g)
of matter. This measurement is used to determine
whether a wireless phone complies with safety
guidelines.
9. What steps can I take to reduce my exposure to
radio frequency energy from my wireless
phone?
If there is a risk from these products — and at this
point we do not know that there is — it is probably
very small. But if you are concerned about avoiding
even potential risks, you can take a few simple steps
to minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure. If you
must conduct extended conversations by wireless
phone every day, you could place more distance
between your body and the source of the RF, since
the exposure level drops off dramatically with
distance. For example, you could use a headset and
carry the wireless phone away from your body or use
a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
79
SAFETY
10. What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radio frequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing the
time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure. Some groups sponsored by
other national governments have advised that
children be discouraged from using wireless phones
at all. For example, the government in the United
Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted
that no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by
children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
11. What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones
can interact with some electronic devices. For this
reason, the FDA helped develop a detailed test
method to measure electromagnetic interference
(EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test
method is now part of a standard sponsored by the
Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort
by the FDA, medical device manufacturers, and many
other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. The FDA has tested hearing aids
for interference from handheld wireless phones and
helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when
a person uses a “compatible” phone and a
“compatible” hearing aid at the same time. This
standard was approved by the IEEE in 2000. The
SAFETY
80
SAFETY
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, the
FDA will conduct testing to assess the interference
and work to resolve the problem.
12. Where can I find additional information?
For additional information, please refer to the
following resources:
FDA web page on wireless phones
(http://www.fda.gov/cdrh/phones/index.html)
Federal Communications Commission (FCC) RF
Safety Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-lonizing Radiation
Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF
Project
(http://www.who.int/emf)
National Radiological Protection Board (UK)
(http://www.nrpb.org.uk/)
Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s
Requirements for Exposure to Radio Waves. Your
wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications
Commission of the U.S. Government. These limits
are part of comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on standards
that were developed by independent scientific
organizations through periodic and thorough
evaluation of scientific studies. The standards
include a substantial safety margin designed to
assure the safety of all persons, regardless of age
and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set
by the FCC is 1.6 W/kg. Tests for SAR are
conducted using standard operating positions
specified by the FCC with the phone transmitting at
81
SAFETY
its highest certified power level in all tested
frequency bands. AlthoughSAR is determined at the
highest certified power level, the actual SAR level of
the phone while operating can be well below the
maximum value. Because the phone is designed to
operate at multiple power levels to use only the
power required to reach the network, in general, the
closer you are to a wireless base station antenna,
the lower the power output.
Before a phone model is available for sale to the
public, it must be tested and certified to the FCC
that it does not exceed the limit established by the
government-adopted requirement for safe exposure.
The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required
by the FCC for each model.
The highest SAR value for this model phone when
tested for use at the ear is 1.16 W/kg and when
worn on the body, as described in this user guide, is
0.936 W/kg (body-worn measurements differ
among phone models, depending upon available
accessories and FCC/IC requirements). While there
may be differences between SAR levels of various
phones and at various positions, they all meet the
government requirement for safe exposure. The
FCC has granted an Equipment Authorization for
this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on
FCC ID BEJAX490. Additional information on
Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications Industry
Association (CTIA) website at http://www.wow-
com.com.
* In the United States and Canada, the SAR limit
for mobile phones used by the public is 1.6
watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of
safety to give additional protection for the public
and to account for any variations in measurements.
SAFETY
82
SAFETY
ACCESSORIES
83
SAFETY
Battery Charger
The battery charger allows you to
charge your phone.
Battery
Standard battery is available.
Vehicle Power Charger
The vehicle power charger
allows you to operate the phone
and trickle charge the phone’s
battery from your vehicle.
Hands-Free Car Kit (Portable)
The hands-free car kit enables you
to attach the phone to the power
jack in your car, providing you with
hands-free operation.
Headset
Connects to your phone,
allowing hands-free operation.
Includes earpiece, microphone,
and integrated call answer /
termination button. You can use this stereo handset
to listen to music through music player.
Holster
There are a variety of accessories available for your mobile phone. Consult your local dealer for availability.
Optional items are sold seperately.
1. WHAT THIS WARRANTY COVERS :
LG offers you a limited warranty that the enclosed
subscriber unit and its enclosed accessories will be
free from defects in material and workmanship,
according to the following terms and conditions:
(1) The limited warranty for the product extends
for ONE (1) year beginning on the date of
purchase of the product by the original end
user.
(2) The limited warranty extends only to the
original end user of the product and is not
assignable or transferable to any subsequent
purchaser/end user.
(3) This warranty is good only to the original end
user of the product during the warranty period
as long as it is in Canada.
(4) Upon request from LG, the consumer must
provide information to reasonably prove the
date of purchase.
(5) During the applicable warranty period, LG will
repair or replace at LG’s sole option, without
charge to the original end user, any defective
component part of the phone or accessory.
(6) LG may, use rebuilt, reconditioned, or new parts
or components when repairing any product or
replace a product with a rebuilt, reconditioned
or new product.
2. WHAT THIS WARRANTY DOES NOT COVER :
(1) Defects or damages resulting from use of the
product in other than its normal and customary
manner.
(2) Defects or damages from abnormal use,
abnormal conditions, improper storage,
exposure to moisture or dampness,
unauthorized modifications, unauthorized
connections, unauthorized repair, misuse,
neglect, abuse, accident, alteration, improper
installation, or other acts which are not the
fault of LG, including damage caused by spills of
food or liquids.
(3) Breakage or damage to antennas unless caused
directly by defects in material or workmanship.
(4) If the carrier’s or manufacturer’s Customer
Service Centre was not notified by the end user
of the alleged defect or malfunction of the
product, during the warranty period.
WARRANTY INFORMATION
84
WARRANTY INFORMATION
85
WARRANTY INFORMATION
(5) Products which have had their serial numbers
removed or made illegible.
(6) Damage resulting from use of non-LG approved
accessories.
(7) All plastic surfaces and all other externally
exposed parts that are scratched or damaged
due to normal customer use.
(8) Products serviced by non-authorized persons or
companies.
Notes:
(1) This limited warranty is in lieu of all other
warranties, express or implied either in fact or
by operations of law, statutory or otherwise,
including, but not limited to any implied
warranty of merchantability or fitness for a
particular purpose.
(2) Shipping damage is the sole responsibility of
the shipping company.
3. EXCLUSION OF LIABILITY :
No other express warranty is applicable to this
product. THE DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE IMPLIED
WARRANTY OF MARKETABILITY, IS LIMITED TO
THE DURATION OF THE EXPRESS WARRANTY
HEREIN. LG ELECTRONICS CANADA, INC. SHALL
NOT BE LIABLE FOR THE LOSS OF THE USE OF
THE PRODUCT, INCONVENIENCE, LOSS OR ANY
OTHER DAMAGES, DIRECT OR
CONSEQUENTIAL, ARISING OUT OF THE USE
OF, OR INABILITY TO USE, THIS PRODUCT OR
FOR ANY BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY APPLICABLE
TO THIS PRODUCT.
4. HOW TO GET WARRANTY SERVICE :
To obtain warranty service, please call the
following telephone number from anywhere in
Canada:
LG Electronics Canada, Inc.
Tel. 1-888-542-2623
