LG Electronics USA C1300 Dual-Band GSM Phone User Manual
LG Electronics USA Dual-Band GSM Phone Users Manual
Users Manual
C1300
User Guide
Unpacking 8
For Your Safety 9
Your Phone 14
Phone Components 14
Your Phone’s Features 15
Display Information 17
Getting Started 18
Using the Battery,
Charger and SIM Card 18
Installing and
Removing the Battery 18
Installing the Battery 18
Removing the Battery 19
Charging the Battery 19
Disconnecting the Charger 20
Installing the SIM Card 21
Turning Your
Phone On and Off 22
Turning Your Phone On 22
Turning Your Phone Off 22
Access Codes 22
Security code 22
Barring Password 22
General Functions 23
Making and
Answering Calls 23
Making a Call 23
Making a Call by Send Key 23
Making International Calls 23
Ending a Call 23
Making a Call
From the Phonebook 24
Adjusting the Volume 24
Answering a Call 24
Manner Mode (Quick) 25
Signal Strength 25
Entering Text 25
Phonebook 29
In-Call Menu 30
During a Call 30
Making a Second Call 30
Swapping
Between Two Calls 30
Answering an Incoming Call 30
Rejecting an Incoming Call 31
Muting the Microphone 31
Switching DTMF
Tones on During a Call 31
Multiparty or
Conference Calls 32
Making a Second Call 32
Setting up a
Conference Call 33
Activate the
Conference Call on Hold 32
5
4
Adding Calls to the
Conference Call 33
Displaying Callers in a
Conference Call 33
Private Call in a
Conference Call 33
Ending a Conference Call 33
Menu Tree 34
Selecting
Functions and Options 37
Messages 38
Text Messages 38
Write Message 38
Inbox 39
Outbox 40
Draft 40
Settings 41
Delete All 41
Multimedia Messages 42
Write 42
Inbox 43
Outbox 44
Draft 45
Settings 46
Instant Message 47
Login 47
History 47
Settings 48
Set parameter 48
Voice Mall 49
Listen to Voice Messages 49
Voice Mailbox Number 49
Download messages 50
Inbox 50
Receive 50
Info Service 51
Receive 51
Inbox 51
Topics 51
Alert 51
Auto Display 51
Languages 52
Templates 52
Text 52
Multimedia 52
Name Card 53
Check Memory 53
Recent Calls 56
Missed Calls 56
Received Calls 56
Dialed Calls 57
Delete Recent Calls 57
Call Durations 57
Table of Contents
7
6
Last Call 57
Received Calls 57
Dialed Calls 57
All Calls 57
Call Costs 58
Last Call’s Cost 58
All Calls’ Cost 58
Cost Settings 58
Call Cost’s Limit 58
Set Tariff 59
Auto Display 59
Data Information 59
WAP Information 59
External Device 59
Total Data 59
Sounds 60
Shop Ringtones 60
My Ringtones 60
Volume 60
Message Alert 60
Tones 61
Key tones 61
Games & Apps 62
Shop Games 62
My Games and Apps 62
Bookmark 62
View Information 63
Memory status 63
Java version 63
Settings 64
Display 64
My Wallpaper 64
Backlight 64
Languages 64
LED indicator 64
Date & Time 65
Set date 65
Date format 65
Set time 65
Time format 65
Auto update 65
Call Settings 66
Call Divert 66
Answer Mode 67
Send My Number 67
Call Waiting 67
Minute Minder 67
Auto Redial 67
Closed User Group 68
TTY 68
Security Settings 69
PIN Code Request 69
Call Barring Service 69
Fixed Dial Number (FDN) 70
Change Codes 70
Connection Settings 71
Network Selection 71
Access Point 71
Attach 71
External Device 71
Reset Settings 73
Web Access 74
Home 76
Bookmarks 76
Profiles 78
Go to URL 79
Cache Settings 79
Clear Cache 79
Cache Check 79
Security Certificates 79
WAP Information 79
Tools 80
My Folder 80
Picture 80
Animation 80
Sound 81
Alarm Clock 82
Calendar 83
Calculator 84
Memo 85
World Time 86
Unit Converter 86
Phonebook 87
Contact list 87
Add New 88
Speed Dials 89
Caller Groups 89
Copy All 90
Delete All 90
Settings 91
Information 91
Q & A 92
Accessories 95
Safety Guidelines 97
Glossary 111
Index 114
9
8
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information carefully for
optimal performance and to prevent any damage to, or misuse of,
the phone. Any changes or modifications not expressly approved in
this user guide could void your warranty for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the bathroom,
swimming pool, etc.
Always store your phone away from heat. Never store
your phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during a snowstorm or
in your car on a hot day. Exposure to excessive cold or heat will
result in malfunction, damage and/or catastrophic failure.
Be careful when using your phone near other
electronic devices. RF emissions from your mobile phone may
affect nearby inadequately shielded electronic equipment. You
should consult with manufacturers of any personal medical devices
such as pacemakers and hearing aides to determine if they are
susceptible to interference from your mobile phone. Turn off your
phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will cause the
battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 103 before using your phone.
Check to make sure that you have all the parts shown below.
Unpacking For Your Safety
Handset Standard
Battery
User GuideTravel Adapter
11
10
Safety Information
Please read and observe the following information for the safe and
proper use of your phone and to prevent any unanticipated
damage. Also, keep the user’s manual in an accessible place at all
times after reading it.
]
Unplug the power cord and charger during a lightning storm to
avoid electric shock or fire.
]
Do not use your phone in high explosive areas as the phone may
generate sparks.
]
Do not put your phone in a place subject to excessive dust, and
keep the minimum required distance between the power cord
and heat sources.
]
Do not damage the power cord by bending, twisting, pulling, or
subjecting it to heat. Do not use the plug if it is loose as it may
cause fire or electric shock.
]
Hold the power cord plug firmly to plug and unplug the power
cord. Ensure the plug is firmly connected. If it is not firmly
connected, it may cause excessive heat or fire.
]
Do not place a heavy item on the power cord. Do not allow the
power cord to be crimped as it may cause fire or electric shock.
]
Be careful not to let the battery contact metal conductors such
as a necklace or coins. When shorted, it may cause an
explosion.
]
Do not disassemble or impact the battery as it may cause
electric shock, short-circuit, and fire. Store the battery in a place
out of reach of children.
]
Using a damaged battery or placing a battery in your mouth may
cause serious injury.
]
Do not place items containing magnetic components such as a
credit card, phone card, bank book or a subway ticket, near
your phone. The magnetic strip can be damaged by the phone.
]
Do not hold or let the antenna come in contact with your body
during a call.
]
Talking on your phone for a long period of time may reduce the
call quality due to heat generated during the use of the phone.
]
Do not allow excessive vibration or impact to the phone.
]
When you do not plan to use the phone for a long period of time,
store it in a safe area with the power cord unplugged.
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of the United
States, with its action in Report and Order FCC 96-326, adopted an
updated safety standard for human exposure to radio frequency
(RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety
standard previously set by both U.S. and international standards
bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
For Your SafetyFor Your Safety
13
12
CAUTION
Use only the supplied and approved antenna. Use of unauthorized
antennas or modifications could impair call quality, damage the
phone, void your warranty and/or result in violation of FCC
regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with skin, a minor burn may result.
Contact your local dealer for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with the
back of the phone kept 10mm between the use's body and the
back of the phone. To comply with FCC RF exposure requirements,
a minimum separation distance of 10mm must be maintained
between the user’s body and the back of the phone. Third-party
belt-clips, holsters, and similar accessories containing metallic
components should not be used. Body-worn accessories that
cannot maintain 3/4 inch (2 cm) separation distance between the
user’s body and the back of the phone, and have not been tested
for typical body-worn operations may not comply with FCC RF
exposure limits and should be avoided.
Vehicle Mounted External Antenna (optional,
if available)
A minimum separation distance of 8 inches (20 cm) must be
maintained between the user/bystander and the vehicle mounted
external antenna to satisfy FCC RF exposure requirements.
For more information about RF exposure, visit the FCC website at
www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC rules.
Operation is subject to the following two conditions: (1) This device
and its accessories may not cause harmful interference, and (2)
this device and its accessories must accept any interference
received, including interference that may cause undesired
operation.
Cautions for Battery
]
Do not disassemble.
]
Do not short-circuit.
]
Do not expose to high temperature: 60°C (140°F).
]
Do not incinerate.
Battery Disposal
]
Please dispose of your battery properly or bring to your local
wireless carrier for recycling.
]
Do not dispose in fire or with hazardous or flammable materials.
Adapter (Charger) Cautions
]
Using the wrong battery charger could damage your phone and
void your warranty.
]
The adapter or battery charger is intended for indoor use only.
Do not expose the adapter or battery charger to direct sunlight or
use it in places with high humidity, such as the bathroom.
For Your SafetyFor Your Safety
15
14
Your Phone
Your Phone
1. Earpiece
7. Active flip
8. Display screen
10. Navigation key
2. Left soft key
3. Side keys
4. Send key
9. Confirmation
key
11. Right soft key
12. Message key
14. Clear key
13. End / Power key
6. Microphone
5. Alpha numeric
keys
Your Phone’s Features
1. Earpiece
2,11. Left soft key / Right soft key: Each of these keys
perform the functions indicated by the text on the display
immediately above them.
3. Side keys: These keys are used to control the volume of key
tone in standby mode and speaker volume during a call.
4. Send key: You can dial a phone number and answer incoming
calls. Press this key in standby mode to quickly access the most
recent incoming, outgoing and missed calls.
5. Alphanumeric keys: These keys are used to dial a number in
standby mode and to enter number or characters in edit mode.
6. Microphone: Can be muted during a call for privacy.
7. Active flip: Open the flip to answer an incoming call and close
to end the call.
8. Display screen: Displays phone status icons, menu items,
Web information, pictures and more in full color.
9. Confirmation key: Long press will launch the WAP browser.
Allows you to select and confirm menu options.
10. Navigation key: Use for quick access to phone functions.
12. Message key: Use to retrieve or send voice and text
messages.
13. End/Power key: Allows you to power the phone on or off,
end calls, or return to Standby Mode.
14. Clear key: Allows you to delete the characters entered or
return you to the previous screen.
Phone Components
17
Icon Description
Indicates the strength of the network signal.
Indicates a call is in progress.
Indicates that you are roaming off the network.
Indicates that GPRS service is available.
Indicates the alarm has been set and is on.
Indicates the status of the battery charge.
Indicates the receipt of a text message.
Indicates the receipt of a MMS message.
Indicates the receipt of a voice message.
Indicates that the vibration ringer has been set.
Indicates the receipt of an e-mail message.
Indicates the Loud menu in Profiles.
Indicates the Quiet menu in Profiles.
Indicates the Headset menu in Profiles.
Indicates the Car menu in Profiles.
Indicates the General menu in Profiles.
Indicates that you can use the push message service.
Indicates the Schedule function.
16
SIM Card
Socket
Battery Lock
Antenna
Cable Connector/
Battery Charging Connector
Handstrap Hole
Battery
Battery
Terminals
Display Information
The table below describes various display indicators or icons that
appear on the phone’s display screen.
On-Screen Icons
Your Phone Your Phone
19
18
Using the Battery, Charger and SIM
Card
Installing and Removing the Battery
]
To install, insert the battery into the opening on the back of the
phone and gently press down until the latch snaps into place.
]
To remove, first make sure the power is off. Press the battery
release latch up and remove the battery from the phone at a 45-
degree angle.
Installing the Battery
To install the battery, insert the bottom of the battery into the
opening on the back of the phone. Then push the battery down
until the latch clicks.
Removing the Battery
Turn the power off. (If power is left on, there is a chance you could
lose the stored telephone numbers and messages.)
Pressing the release latch upwards will detach the battery from the
phone.
1
2
2
Getting Started
Getting Started
Charging the Battery
Use of unauthorized accessories could damage your phone and
invalidate your warranty.
To use the travel adapter provided with your phone:
1. With the battery in position on the phone, connect the lead from
the travel adapter to the bottom of the phone. Check that the
arrow on the lead connector is facing towards the front of the
phone.
2. Connect the adapter to a standard AC wall outlet. Only use the
travel adapter that comes included with the package.
Warning Do not force the connector as this may damage the phone
and/or the travel adapter.
21
20
Disconnecting the Charger
When charging is finished, disconnect the adapter from the power
outlet and from the phone by pressing on the gray tabs on both
sides of the connector while pulling the connector out.
Notice
]
The battery delivered with your phone has to be fully charged
before using it.
]
Do not remove the battery or the SIM card while charging.
]
If your phone is powered on while charging, you’ll see the bars in
the battery indicator icon cycle.
When the battery is fully charged, the bars in the battery indicator
icon will flash on and off
]
If your phone is powered off, the display will show the charging
status. ‘Charging’ or ‘Full’ will be displayed.
If the battery fails to charge completely:
]
After turning the phone on and off, please attempt to recharge the
battery.
]
After detaching and reattaching the battery, please attempt to
recharge the battery.
Getting StartedGetting Started
Notice When you need to remove the SIM card, slide it towards the
top of the phone and take it out of the holder.
Notice
]
Before installing always make sure that the phone is switched off
and remove the battery.
]
The metal contact of the SIM card can be easily damaged by
scratches. Pay special attention to the SIM card while handling and
installing. Follow the instructions supplied with the SIM card.
SIM
SIM
Installing the SIM Card
When you subscribe to a cellular network, you are provided with a
plug-in SIM card loaded with your subscription details (PIN,
optional services available and so on).
Locate the SIM card socket in the back of the phone. Follow the
steps below to install the SIM card.
1. Remove the battery if attached.
2. Slide the SIM card into the SIM card holder so that the holder
locks the card in position.
Full
Charging
23
22
Turning Your Phone On and Off
Turning Your Phone On
1. Install a charged battery pack or connect the phone to an
external power source such as the vehicle power adapter or car
kit.
2. Press for more than five seconds.
3. Depending on the status of the PIN Code Request setting you
may or may not need to enter it.
Turning Your Phone Off
1. Press for a few seconds.
Notice Like any other radio device, avoid any unnecessary contact
with the antenna while your phone is on.
Getting Started
Access Codes
You can use the access codes described in this section to avoid
unauthorized use of your phone. The access codes can be
changed by using the Change Codes feature [Menu 6.4.4].
Security code (4 to 8 digits)
The security code protects the unauthorized use of your phone.
The default security code is set to ‘0000’ and the security code is
required to delete all phone entries and to activate the Restore
Factory Settings menu. The security code default setting can be
modified from the Security Settings menu.
Barring Password
The barring password is required when you use the Call Barring
function. The password is obtained from the service provider when
you subscribe to this function. See page 65 for further details.
General Functions
Making and Answering Calls
Making a Call
1. Make sure your phone is powered on.
2. Enter a phone number including the area code. To edit a
number on the display screen, press the right/left navigation
keys to move the cursor to desired position or simply press
to erase one digit at a time.
]
Press and hold to erase the entire number.
3. Press to call the number.
4. When finished, press .
Making a Call by Send Key
1. Press , and the most recent incoming, outgoing and missed
phone numbers will be displayed.
2. Select the desired number by using the navigation key.
3. Press .
Making International Calls
1. Press and hold the key for the international prefix. The ‘+’
character can be replaced with the international access code.
2. Enter the country code, area code, and the phone number.
3. Press .
Ending a Call
When you have finished a call, press the key.
25
24
Making a Call From the Phonebook
You can store names and phone numbers dialed frequently in the
SIM card as well as the phone memory known as the Phonebook.
You can dial a number by simply looking up a name in the
phonebook. For more details on the Phonebook feature, please
refer to page 73.
Adjusting the Volume
During a call, if you want to adjust the earpiece volume, use the
side keys of the phone.
In idle mode with the flip cover open, you can adjust the key
volume using the side keys.
Answering a Call
When you receive a call, the phone rings and the flashing phone
icon appears on the screen. If the caller can be identified, the
caller’s phone number(or name if stored in your phonebook) is
displayed.
1. Open the flip and press the key or the left soft key to answer
an incoming call. If the Any key menu option(Menu 6.3.2) has
been set to , any key press will answer a call except for the
key or the right soft key.
2. End the call by closing the phone or pressing the key.
General Functions
Notice You can answer a call while using the phonebook or other
menu features.
Notice
]
To reject an incoming call, press and hold the side keys on the left
side of the phone without opening the flip.
]
If the Flip open menu option(Menu 6.3.2) is set to , you do not
need to press any key. You can answer the call simply by opening
the flip.
General Functions
Manner Mode (Quick)
When the flip is closed, Manner Mode can be activated by
pressing and holding down side keys.
Signal Strength
Since the antenna is fixed, it does not extend. If you are inside a
building, being near a window may give you better reception. You
can see the strength of your signal by the signal indicator ( )
on your phone’s display screen.
Entering Text
You can enter alphanumeric characters by using the phone’s
keypad. For example, storing names in the phonebook, writing a
message, creating a personal greeting or scheduling events in the
calendar all require entering text.
Following text input methods are available in the phone.
T9 Mode
This mode allows you to enter words with only one keystroke per
letter. Each key on the keypad has more than one letter. The T9
mode automatically compares your keystrokes with an internal
linguistic dictionary to determine the correct word, thus requiring
far fewer keystrokes than the traditional ABC mode.
ABC Mode
This mode allows you to enter letters by pressing the key labeled
with the required letter once, twice, three or four times until the
letter is displayed.
123 Mode(Numbers Mode)
Type numbers using one keystroke per number. To change to 123
mode in a text entry field, press key until 123 mode is
displayed.
27
26
General FunctionsGeneral Functions
Symbolic Mode
This mode allows you to enter special characters.
Changing the Text Input Mode
1. When you are in a field that allows characters to be entered, you
will notice the text input mode indicator in the upper right corner
of the display.
2. If you want to change modes, press the key. The available
modes are displayed.
Using the T9 Mode
The T9 predictive text input mode allows you to enter words easily
with a minimum number of key presses. As you press each key, the
phone begins to display the characters that it thinks you are typing
based on a built-in dictionary. As new letters are added, the word
changes to reflect the most likely candidate from the dictionary.
1. When you are in the T9 predictive text input mode, start entering
a word by pressing keys to . Press one key per letter.
]
The word changes as letters are typed - ignore what’s on the
screen until the word is typed completely.
]
If the word is still incorrect after typing completely, press the
down navigation key once or more to cycle through the other
word options.
Notice You can select a different T9 language from the menu option.
The default setting on the phone is T9 enabled mode.
To turn it off, select the T9 Off option from the menu.
Write message
OK Back
Subject
En T9
Write message
OK Back
Subject
en T9
Hi
Write message
914
Options Attach
1en T9
OK
]
If the desired word is missing from the word choices list, add it
by using the ABC mode.
2. Enter the whole word before editing or deleting any keystrokes.
3. Complete each word with a space by pressing the key.
To delete letters, press . Press and hold down to erase
entire words.
Using the ABC Mode
Use the to keys to enter your text.
1. Press the key labeled with the required letter:
]
Once for the first letter
]
Twice for the second letter
]
And so on
2. To insert a space, press the key once. To delete letters,
press the key. Press and hold down the key to clear
the display.
Notice To exit the text input mode without saving your input,
press .The phone returns to the previous menu level.
Example: Press to type Good
Press [down navigation key] to type
Home
29
28
Characters in the Order Display
Upper Case Lower Case
. , - ¿? ¡ ! @1 . , - ¿? ¡ ! @1
A B C Á Ã Ç 2 a b c á ã ç 2
D E F É 3 d e f é 3
G H I Í 4 g h i í 4
J K L 5 j k l 5
M N O Ó Ñ 6 m n o ó ñ 6
P Q R S 7 p q r s 7
T U V Ú Ü 8 t u v ú ü 8
W X Y Z 9 w x y z 9
Space Key Space Key
General FunctionsGeneral Functions
Notice Refer to the table below for more information on the
characters available using the keys.
Using the 123 (Numbers) Mode
The 123 Mode enables you to enter numbers in a text message
(a telephone number, for example).
Press the keys corresponding to the required digits before
manually switching back to the appropriate text entry mode.
Using the Symbol Mode
The Symbol Mode enables you to enter various symbols or special
characters.
To enter a symbol, press the key. Use the navigation keys to
select the desired symbol and press the [OK] key.
1
2
3
4
5
6
7
8
9
0
Key
Phonebook
You can store phone numbers and their corresponding names in
the memory of your SIM card.
In addition, you can store up to 255 numbers and names in the
phone memory.
The SIM card and phone memory, although physically separate,
are utilized like a single entity known as the Phonebook. (See page
73 for details)
31
30
General FunctionsGeneral Functions
In-Call Menu
Your phone provides a number of control functions that you can
use during a call. To access these functions during a call, press
the left soft key [Options].
During a Call
The menu displayed on the handset screen during a call is different
than the default main menu displayed when in idle screen, and the
options are described below.
Making a Second Call
You can get a number you wish to dial from the phonebook to
make a second call. Press the right soft key then select Search. To
save the dialed number into the phonebook during a call, press the
right soft key then select Add New.
Swapping Between Two Calls
To switch between two calls, press the left soft key, and then select
Swap.
Answering an Incoming Call
To answer an incoming call when the handset is ringing, simply
press the key. The handset is also able to warn you of an
incoming call while you are already on a call. A tone sounds in the
earpiece, and the display will show that a second call is waiting.
This feature, known as Call Waiting, is only available if your
network supports it. For details of how to activate and deactivate it
see Call Waiting [Menu 6.3.4].
If Call Waiting is on, you can put the first call on hold and answer
the second, by pressing or by pressing the left soft key, and
then selecting the Hold & Answer. You can end the current call and
answer the waiting call by pressing the left soft key and then
selecting Active call menu of End call.
Rejecting an Incoming Call
You can reject an incoming call without answering by simply
pressing the key.
During a call, you can reject an incoming call by pressing the left
soft key, which is the [Menu] key and selecting the
Conference/Reject or by pressing the key.
Muting the Microphone
You can mute the microphone during a call by pressing the
[Menu] key then selecting Mute on. The handset can be
unmuted by pressing the Mute off menu. When the handset is
muted, the caller cannot hear you, but you can still hear them.
Switching DTMF Tones on During a Call
To turn DTMF tones on during a call, press the left soft key, and
then select DTMF on. DTMF tones can be turned off the same
way. DTMF tones allow your phone to make use of an automated
switchboard.
33
32
Adding Calls to the Conference Call
To add a call to an existing conference call, press the left soft key,
and then select the Join menu of Conference call.
Displaying Callers in a Conference Call
To scroll through the numbers of the callers who make up a
conference call on the handset screen, press the up/down
navigation keys.
Private Call in a Conference Call
To have a private call with one caller from a conference call,
display the number of the caller you wish to talk to on the screen,
then press the left soft key. Select the Private menu of Conference
call to put all the other callers on hold.
Ending a Conference Call
Currently displayed caller from a conference call can be
disconnected by pressing the key.
Multiparty or Conference Calls
The multiparty or conference service provides you with the ability to
have a simultaneous conversation with more than one caller, if your
network service provider supports this feature. A multiparty call can
only be set up when you have one active call and one call on hold,
both calls having been answered. Once a multiparty call is set up,
calls may be added, disconnected or separated (that is, removed
from the multiparty call but still connected to you) by the person
who set up the multiparty call. These options are all available from
the In-Call menu. The maximum callers in a multiparty call are five.
Once started, you are in control of the multiparty call, and only you
can add calls to the multiparty call.
Making a Second Call
You can make a second call while currently on a call. Enter the
second number and press the . When the second call is
connected, the first call is automatically placed on hold. You can
swap between calls, by selecting the left soft key and then
selecting Swap.
Setting Up a Conference Call
To set up a conference call, place one call on hold and while the
active call is on, press the left soft key and then select the Join
menu of Conference call.
Activate the Conference Call on Hold
To activate a conference call on hold, press the left soft key, and
then select the Join menu of Conference call.
General FunctionsGeneral Functions
35
34
Menu Tree
The following illustration shows the available menu structure and
indicates the:
]
Number assigned to each menu option.
]
Page where you can find the feature description.
1. Messages (see page 39)
1.1 Text messages
1.1.1 Write message
1.1.2 Inbox
1.1.3 Outbox
1.1.4 Draft
1.1.5 Settings
1.1.6 Delete all
1.2 Multimedia messages
1.2.1 Write
1.2.2 Inbox
1.2.3 Outbox
1.2.4 Draft
1.2.5 Settings
1.3 Instant message
1.3.1 Login
1.3.2 History
1.3.3 Settings
1.3.4 Set Parameter
1.4 Voice Mail
1.4.1 Listen to voice messages
1.4.2 Voice mailbox number
1.5 Download messages
1.5.1 Inbox
1.5.2 Receive
1. Messages (continued)
1.6 Info service
1.6.1 Receive
1.6.2 Inbox
1.6.3 Topics
1.6.4 Alert
1.6.5 Auto display
1.6.6 Languages
1.7 Templates
1.7.1 Text
1.7.2 Multimedia
1.8 Name card
1.9 Check memory
1.9.1 Text
1.9.2 Multimedia
*:
Shown only if supported by CPHS(Common PCS Handset Specification)
*
*
Menu Tree
4. Games & Apps. (see page 62)
4.1 Shop Games
4.2 My Games and Apps
4.3 Bookmark
4.4 View information
4.4.1 Memory status
4.4.2 Java version
5. Settings (see page 64)
5.1 Display
5.1.1 My Wallpaper
5.1.2 Backlight
5.1.3 Languages
5.1.4 LED indicator
5.2 Date & Time
5.2.1 Set Date
5.2.2 Date Format
5.2.3 Set Time
5.2.4 Time Format
5.2.5 Auto Update
5.3 Call settings
5.3.1 Call Divert
5.3.2 Answer Mode
5.3.3 Send My Number
5.3.4 Call Waiting
5.3.5 Minute Minder
5.3.6 Auto Redial
5.3.7 Closed User Group
5.3.8 TTY
*
*
*
*
*
2. Recent Calls (see page 56)
2.1 Missed calls
2.2 Received calls
2.3 Dialed calls
2.4 Delete recent calls
2.5 Call durations
2.5.1 Last call
2.5.2 Received calls
2.5.3 Dialed calls
2.5.4 All calls
2.6 Call costs
2.6.1 Last call’s cost
2.6.2 All calls’ cost
2.7 Cost settings
2.7.1 Call cost’s limit
2.7.2 Set tariff
2.7.3 Auto display
2.8 Data Information
2.8.1 WAP information
2.8.2 External information
2.8.3 Total data
3. Sounds (see page 60)
3.1 Shop Ringtones
3.2 My Ringtones
3.3 Volume
3.4 Message Alert Tones
3.5 Key Tones
*
*
*
*:
Shown only if supported by CPHS(Common PCS Handset Specification)
7. Tools (see page 80)
7.1 My folder
7.1.1 Picture
7.1.2 Animation
7.1.3 Sound
7.2 Alarm Clock
7.3 Calendar
7.4 Calculator
7.5 Memo
7.6 World time
7.7 Unit converter
8. Phonebook(see page 86)
8.1 Contact list
8.2 Add new
8.3 Speed dials
8.4 Caller groups
8.5 Copy all
8.6 Delete all
8.7 Settings
8.8 Information
37
36
5. Settings (continued)
5.4 Security settings
5.4.1 PIN Code Request
5.4.2 Call Barring Service
5.4.3 Fixed Dial Number
5.4.4 Change Codes
5.5 Connection settings
5.5.1 Network Selection
5.5.2 Access Point
5.5.3 Attach
5.5.4 External Device
5.6 Reset Setting
6. Web Access (see page 74)
6.1 Home
6.2 Bookmarks
Inbox
Home
Tone Download
Graphic Downld
Delete all
6.3 Profiles
6.4 Go to URL
6.5 Cache settings
6.5.1 Clear cache
6.5.2 Cache check
6.6 Security certificates
6.7 WAP information
Menu Tree
*
Selecting Functions and Options
Your phone offers a set of functions that allow you to customize the
phone. These functions are arranged in menus and sub-menus,
accessed via the two soft keys marked and . Each menu
and sub-menu allows you to view and alter the settings of a
particular function.
The roles of the soft keys vary according to the current context; the
label on the bottom line of the display just above each key
indicates its current role.
Press the left soft key
to access the
available menu.
Press the right soft
key to access the
available names.
*:
Shown only if supported by CPHS(Common PCS Handset Specification)
39
38
Text Messages Menu 1.1
Your phone receives voice mail notification messages and Short
Message Service (SMS) messages.
Voice mail and SMS are network services. Please contact your
service provider for more information.
When the icon appears, you have received a new voice mail.
When the icon appears, you have received a new text
message. If the message memory is full, an error message is
displayed, the icon flashes and you cannot receive any new
messages. Use the Delete option in the Inbox (Menu 1.1.2) to
delete obsolete messages. Once there is space in the memory any
undelivered SMS messages will be received (provided sufficient
space is available).
Write Message (Menu 1.1.1)
You can write and edit text messages of up to 918 characters.
1. Type in a message using key presses. For details on how to
enter text, refer to page 26 (Entering Text).
2. After completing the message select the required option by
pressing the left soft key [Options].
The following options are available.
]
Send to number: Enter the phone number or select the
number from the phone book.
]
Send to email: Enter the email or select the email from the
phone book.
]
Save to draft: Save the message so that it can be sent later.
]
Edit Subject: Yon can edit the subject of a message.
]
T9 languages: Choose between English or Spanish T9
language. For details on how to enter text, refer to page 27
(Using the T9 Mode).
]
Clear text: Deletes the written message.
]
Exit: Exit the text editor.
Messages
*
*:Shown only if supported by SIM card
Messages
The following options are available. (Press the right soft key
[Attach])
• Symbol: Attach special characters.
• Picture: Send and receive text messages that contain
pictures, known as ‘picture messages’. Several preset pictures
are available in the phone and they can be replaced with new
ones received from other sources.
• Animation: Attaching an animation in a message can be
done through EMS(Enhanced Messaging Service).
• Sound: Attach sounds that are available for short message.
• Text template: Use the text templates already set in the
phone.
• Phone number: Attach a phone number.
• Name card: Attach your name card.
Inbox (Menu 1.1.2)
Received text messages, page messages, and email lists may be
searched and the contents may be viewed.
Received messages are displayed from newest to oldest.
1. Press the left soft key [Menu].
2. Press .
3. Select .
Icon directive
[ ] Read SIM email
[ ] Unread SIM email
[ ] Read email
[ ] Unread email
[ ] Read SIM message
[ ] Unread SIM message
[ ] Read message
[ ] Unread message
[ ] Read delivery report
[ ] Unread delivery report
41
40
The following options are available.
]
Reply: Replies to the received message.
]
Forward: Forwards a received message to other recipients.
After recipients are entered, the message can be forwarded.
]
Return call: Call back the sender.
]
Extract: Extract picture, sound, text webpage and email
address from the message. They will be saved in My Folder,
phonebook or bookmarks.
]
Delete: Deletes the selected message from the Inbox.
MessagesMessages
Outbox (Menu 1.1.3)
View lists and contents of sent messages in this menu and also
verify if transmission was successful.
The following options are available.
]
Forward: Forwards the current message to other recipients.
]
Delete: Deletes the selected message from the Outbox.
Draft (Menu 1.1.4)
This menu option shows the preset message list. Scroll through the
list using the up/down navigation keys.
The following options are available.
]
Send: Sends the current message to other recipients.
]
Delete: Deletes the selected preset message.
Icon directive
[ ] Sent SIM email
[ ] Sent email [ ] Sent SIM message
[ ] Sent message
Settings (Menu 1.1.5)
This menu allows you to set up default SMS information.
]
Message types: Allows you to set the default message type
(Text, Voice, Fax, Paging, X.400, E-mail, ERMES). The network
can convert the messages into the selected format. The type of
message you desire can be set to Text Type.
]
Valid period: Allows you to set the length of time for which
your text messages will be stored at the SMS center while
attempts are made to deliver them to the recipient. Possible
values are Maximum, 30minutes, 1hour, 6hours, 1day and
1week which can be authorized by your service provider.
]
Delivery reports: Allows you to activate or deactivate the
report function. When this function is activated, the network
informs you whether or not your message has been delivered.
]
Reply with same service: Allows the recipient of your SMS
message to send you a reply via your message center, if the
service is provided by the network.
]
Message center number: Allows you to store or change the
number of your email gateway required when sending text
messages. You must obtain this number from your service
provider.
]
Email gateway: Allows you to store or change the number of
your email gateway required when sending text messages.
]
Subject: If you set it to on, allows you to enter the subject.
]
Bearer setting: You can select GPRS or GSM. Contact your
network operator or service provider for information related to
setting a selected bearer, pricing and connection speed.
GSM Only/GPRS Only
Delete All (Menu 1.1.6)
Allows you to delete all messages.
***
*
*
*
*
*
*:Shown only if supported by SIM card
43
42
MessagesMessages
Multimedia Messages Menu 1.2
A multimedia message can contain text, images, and/or sound
clips. This feature can be used only if it is supported by your
network operator or service provider. Only devices that offer
compatible multimedia message or e-mail features can receive and
multimedia messages. Attach to add Symbol, Picture, Sound,
Recorded Voice, Text Template.
Write (Menu 1.2.1)
The following options are available.
• Send: Support mutiple number and email addresses.
• Preview: To see the multimedia message you wrote.
• Save: Allows you to save multimedia messages in draft or as
templates.
• Delete: Allows you to delete the image or sound.
• Settings: Allows you to set timer for slide and text. Or, allows
you to make the message contents aligned right, left, top and
bottom.
• Add Slide: Allows you to add a slide before or after current
slide.
• Remove Slide: Allows you to move to previous or next slide.
• Add Image: Allows you to add a image before or after current
image.
• Add Sound: Allows you to add a sound before or after current
sound.
Inbox (Menu 1.2.2)
You will be alerted when you have received messages. They will be
stored in the Inbox. In the Inbox, you can identify each message by
icons. For detail, see the icon directive below.
If the phone has ‘no space for message’, you can make space in
each repository by deleting messages, media and applications.
• Timer stop: Timer stop menu is displayed when you receive
the message including various pictures. Usually, the pictures
slide automatically. However, if you select this menu, you can see
the next picture by pressing the left soft key manually.
• Previous slide: View the previous page.
• Restart: Allows you to replay multimedia messages.
• Save Message: Allows you to save a multimedia message in
draft or as template.
• Save Items: Allows you to extract picture and sound. They will
be saved in My Folder or phonebook.
• Details: Allows you, to view information about received
messages; Sender’s address, Subject (only for multimedia
message), Message date & time, Message type, Message size.
• Reply: Allows you to reply to the sender.
• Reply all: Allows you to reply to the senders.
• Delete Message: Allows you to delete the current message.
• Forward: Allows you to forward the selected message to other
recipients.
Icon directive
[ ]
Read multimedia message
[ ]
Unread multimedia message
[ ]
Read notified multimedia message
[ ]
Unread notified multimedia message
45
44
MessagesMessages
Outbox (Menu 1.2.3)
Allows you to see sent messages here. For sent message, you can
see the delivery status.
• Timer stop: Timer stop menu is displayed when you receive
the message including various pictures. Usually, the pictures
slide automatically. However, if you select this menu, you can see
the next picture by pressing the left soft key manually.
• Previous slide: View the previous page.
• Restart: Allows you to replay current messages.
• Save Message: Allows you to save multimedia message in
draft or as template.
• Save Items: Save the item such as image or sound as an
attachment in a message.
• Details: Allows you to view information about outbox messages;
Subject (only for multimedia message), Message date & time,
Message type, Message size.
• Reply: Allows you to reply to the current message.
• Reply all: Allows you to reply to the all messages.
• Delete Message: Allows you to delete the current message.
• Forward: Allows you to forward the current message to other
recipients.
Icon directive
[ ] Sent
Draft (Menu 1.2.4)
Using this menu, you can preset up to five multimedia messages
that you use most frequently. This menu shows the preset
multimedia message list.
The following options are available.
• Send: Support mutiple number and email addresses.
• Preview: To see the multimedia message you wrote.
• Save: Allows you to save multimedia messages in draft or as
templates.
• Delete: Allows you to delete the image or sound.
• Settings: Allows you to set timer for slide or text. Or, allows you
to make the message contents aligned right, left, top and bottom.
• Add Slide: Allows you to add a slide before or after current
slide.
• Remove Slide: Allows you to move to previous or next slide.
• Add Image: Allows you to add a image before or after current
image.
• Add Sound: Allows you to add a sound before or after current
sound.
47
46
MessagesMessages
Settings (Menu 1.2.5)
Via this menu, you can set up default multimedia message
information.
The following options are available:
]
Message title: Allows you to enter the message title.
]
Slide duration: Display the duration of each page when
writing the message (MMS supports multi-message).
]
Alignment: Set the position of a message and text message.
• Image bottom
• Image top
• Image left
• Image right
]
Valid period: Set the duration to keep the message in server.
]
Auto download
• On: Download the message automatically on receiving it.
• Confirm: Download after confirmation of the receipt of a
message.
• Off: Defer receiving a message.
]
Message center url: Enter the address of MMS server to use
MMS service.
]
Profiles: For further details, see page 90.
Instant message Menu 1.3
Login (Menu 1.3.1)
History (Menu 1.3.2)
49
48
MessagesMessages
Voice Mail Menu 1.4
This menu provides you with a quick way of accessing your voice
mailbox (if provided by your network).
Before using this feature, you must enter the voice server number
obtained from your service provider.
When new voicemail is received, the symbol will be displayed on
the screen. Please check with your network service provider for
details of their service in order to configure the handset
accordingly.
Listen to Voice Messages (Menu 1.4.1)
Once this option has been selected, simply press the left soft key
[OK] to listen to voicemail messages. You may also hold down the
key in standby mode to listen to voicemail messages.
Voice Mailbox Number (Menu 1.4.2)
You can input and set the number of voice mail.
Settings (Menu 1.3.3)
Set Parameter (Menu 1.3.4)
*
*:Shown only if supported by SIM card
51
50
MessagesMessages
Info Service Menu 1.6
Info service messages are text messages sent by the network to
GSM phone users. They provide general information such as
weather reports, traffic news, taxis, pharmacies, and stock prices.
Each type of information is associated with a number, which can be
obtained from the service provider. When you receive an info
service message, a popup message will indicate a new message
receipt or the info service message will be displayed directly. In
standby mode, the following options are available when viewing the
info service message.
Receive (Menu 1.6.1)
Ability to enable or disable the reception of broadcast messages.
Inbox (Menu 1.6.2)
The list of received broadcast messages can be searched and the
contents viewed.
Topics (Menu 1.6.3)
To create new topics, press the left soft key[OK] and then select
the new topics menu by pressing the left soft key [Options].
You can Deactivate, Edit, Delete and Add New topics by
pressing the left soft key [OK].
Alert (Menu 1.6.4)
Ability to select the alert type for a new message.
Auto Display (Menu 1.6.5)
This option will automatically display all broadcast messages
received. Scroll through the messages using the up/down
navigation keys.
*
Download messages Menu 1.5
Inbox (Menu 1.5.1)
Receive (Menu 1.5.2)
*:Shown only if supported by SIM card
53
52
MessagesMessages
Languages (Menu 1.6.6)
This option allows you to select the language preferred. The cell
broadcast message will be displayed in the language selected.
If you use all languages supported by phone, select
‘Automatic’ at the bottom of the list.
Name Card Menu 1.8
This option allows you to make your own name card. Key in the
Name, Mobile number, Office number,Fax number and E-mail
address.
]
Edit: Allows you to write a new message or edit the selected
name card.
]
Delete: Allows you to delete the selected name card.
]
Send Via Text Message: Sends the selected name card by
SMS.
]
Send Via Multimedia Message: Sends the selected name
card by MMS.
Templates Menu 1.7
There are 6 predefined messages in the list. You can view and edit
the template messages or create new messages. Two options are
available: Text and Multimedia.
Text (Menu 1.7.1)
• Please call me back
• I’m late. I will be there at
• Where are you now?
• I’m on the way.
• Top urgent. Please contact.
• I love you
The following options are available.
]
Edit: Allows you to write a new message or edit the selected
template message.
]
Delete: Allows you to delete the selected template message.
]
Send Via Text Message: Sends the selected template
message by SMS.
]
Send Via Multimedia Message: Sends the selected
template message by MMS.
]
Add New: Allows you to create new messages.
Multimedia (Menu 1.7.2)
For further details, see page 43.
Check Memory Menu 1.9
You can check the current memory status for SMS. two options are
available: Text and Multimedia
• Send: Support mutiple number and email addresses.
• Preview: To see the multimedia message you wrote.
• Save: Allows you to save multimedia messages in draft or as
templates.
• Delete: Allows you to delete the image or sound.
• Settings: Allows you to set timer for slide or text. Or, allows you
to make the message contents aligned right, left, top and bottom.
• Add Slide: Allows you to add a slide before or after current
slide.
• Remove Slide: Allows you to move to previous or next slide.
• Add Image: Allows you to add a image before or after current
image.
• Add Sound: Allows you to add a sound before or after current
sound.
55
54
You can check the record of missed, received, and dialed calls
only if the network supports the Calling Line Identification (CLI)
within the service area.
The number and name (if available) are displayed together with the
date and time at which the call was made. You can also view call
times and costs.
Missed Calls Menu 2.1
This option lets you view the last 10 unanswered calls. You can
also:
• View the number if available and call it, or save it in the
phonebook
• Enter a new name for the number and save both in the
phonebook
• Send a message by this number
• Delete the call from the list
• Delete all missed calls from the list
Received Calls Menu 2.2
This option lets you view the last 10 incoming calls. You can also:
• View the number if available and call it, or save it in the
phonebook
• Enter a new name for the number and save both in the
phonebook
• Send a message by this number
• Delete the call from the list
• Delete all incoming calls from the list
Recent Calls
Dialed Calls Menu 2.3
This option lets you view the last 10 outgoing calls(called or
attempted). You can also:
• View the number if available and call it or save it in the phonebook
• Enter new name for the number and save both in the phonebook
• Send a message by this number
• Delete the call from the list
• Delete all incoming calls from the list
Recent Calls
Delete Recent Calls Menu 2.4
Allows you to delete Missed, Received and Dialed call lists.
You can delete all call lists at one time.
Call Durations Menu 2.5
Allows you to view the duration of your incoming and outgoing
calls. You can also reset the call times.
The following timers are available:
Last Call (Menu 2.5.1)
Length of the last call.
Received Calls (Menu 2.5.2)
Length of the incoming calls.
Dialed Calls (Menu 2.5.3)
Length of the outgoing calls.
All Calls (Menu 2.5.4)
Total length of all calls made and incoming calls since the timer
was last reset.
57
56
Recent CallsRecent Calls
Set Tariff (Menu 2.7.2)
You can set the currency type and the unit price. Contact your
service providers to obtain charging unit prices. To select the
Currency or 1 Unit in this menu, you need the PIN2 code.
Auto Display (Menu 2.7.3)
This network service allows you to see automatically the cost of
your last calls. If you select On in Auto Display menu, you can
see the cost of the last call when the call is released.
Call Costs Menu 2.6
Call costs allows you to check the cost of the last call or all calls.
The call costs are displayed separately for each SIM card. To reset
the cost, you need the PIN2 code.
The following options are available:
Last Call’s Cost (Menu 2.6.1)
Cost of the last call made.
All Calls’ Cost (Menu 2.6.2)
Total cost of all calls made since the cost counter was last reset. If
the total cost exceeds the maximum cost set, you will no longer be
able to make any calls, except calls to the emergency services,
until you reset the counter.
Cost Settings Menu 2.7
Call Cost’s Limit (Menu 2.7.1)
This network service allows you to limit the cost of your calls by
selected charging units. If you select Read, the number of
remaining unit is shown. If you select Change, you can change
your charge limit.
Notice The actual cost invoiced for calls by your service provider
may vary, depending upon network features, rounding-off
for billing, tax, and so forth.
Note When all units have been used, no calls can be made except
emergency calls. Depending on the SIM card, you need the
PIN2 code to set a call cost limit.
Data Information Menu 2.8
You can check the amount of data transferred over the network
through the GPRS information option. In addition, you can also view
how much time you are online.
WAP Information (Menu 2.8.1)
You can check the data volume and the duration through WAP.
External information (Menu 2.8.2)
You can check the data volume and the duration through GPRS by
using an external device such as a serial port.
Total Data (Menu 2.8.3)
You can check the total amount of data through WAP and an
external device.
Notice The actual time invoiced for calls by your service provider
may vary, depending upon network features, rounding-off
for billing, and so forth.
Notice GPRS General Packet Radio Service
*
*
*:Shown only if supported by SIM card
59
58
Sounds Sounds
Shop Ringtones Menu 3.1
My Ringtones Menu 3.2
To set the ringing tone for voice calls, choose one from the list.
Scroll through the list and listen to the desired tone prior to making
a selection. Press any key to stop the sound.
Volume Menu 3.3
To set the volume level for the ringing tones.
Message Alert Tones Menu 3.4
To set the alert tone for messages.
Key Tones Menu 3.5
To set the volume level for keypad tones.
61
60
Games & Apps. Games & Apps.
Shop Games Menu 4.1
My Games and Apps Menu 4.2
Bookmark Menu 4.3
View Information Menu 4.4
The downloaded programs using the WAP are stored in the phone
memory. There is a maximum memory capacity in a phone and
once you exceed this memory, you will not be able to store any
more programs. The View Information menu allows you to check
the available memory capacity in a phone.
Memory Status (Menu 4.4.1)
Displays maximum memory capacity and total available memory
information.
Java Version (Menu 4.4.2)
Displays current Java version.
63
62
Settings Settings
Display Menu 5.1
My Wallpaper (Menu 5.1.1)
You can set up the screen displayed on the LCD screen in the
standby mode.
Backlight (Menu 5.1.2)
You can select whether or not the phone uses the backlight. A
marginal increase in the standby/talk time can be achieved by
turning the backlight off.
• Main LCD
- Off means that the backlight is never on.
- 10 seconds turns the backlight off 10 seconds after the last
key was pressed.
- 30 seconds turns the backlight off 30 seconds after the last
key was pressed.
- 60 seconds turns the backlight off 60 seconds after the last
key was pressed.
- Always on turns the backlight always on while flip is opened.
Languages (Menu 5.1.3)
You can select the display language. When the language option is
set to Automatic, the language is automatically selected according to
the language of the SIM card used. English will be set if the
language on the SIM card is not supported in the phone.
LED indicator (Menu 5.1.4)
This option allows you to select whether or not the service light on
the top of the phone is used.
The following options are available.
]
Enable:
The service light flashes when the phone is ready for use.
]
Disable: The service light is not used
Date & Time Menu 5.2
This option allows you to change the current time and date
displayed.
The following options are available:
Set date (Menu 5.2.1)
Allows you to enter the day, month and year. You can change the
date format via the Date Format menu option.
Format : Allows you to change the time and date formats.
Date format (Menu 5.2.2)
YYYY/MM/DD(year/month/day)
DD/MM/YYYY(day/month/year)
MM/DD/YYYY(month/day/year)
Set time (Menu 5.2.3)
Allows you to enter the current time. You can choose the time
format via the Time Format menu option.
Time format (Menu 5.2.4)
24 hours/12 hours
Auto Update (Menu 5.2.5)
Select On to set the phone to automatically update the time and
date according to the current time zone.
65
64
SettingsSettings
Call Settings Menu 5.3
To change the settings for call diverting:
Call Divert (Menu 5.3.1)
When this network service is activated, you can direct your
incoming calls to another number, for example, to your voice
mailbox number. For details, contact your service provider. Select
one of the divert options, for example, select If busy to divert
voice calls when your number is busy or when you reject incoming
calls.
The following options are available:
]
All voice calls: Diverts voice calls unconditionally.
]
If busy: Diverts voice calls when the phone is in use.
]
If no reply: Diverts voice calls which you do not answer.
]
If out of reach: Diverts voice calls when the phone is
switched off or out of coverage.
]
All data calls: Diverts to a number with a PC connection
unconditionally.
]
All fax calls: Diverts to a number with a fax connection
unconditionally.
• Activate: Activates the corresponding service.
- To voice mail: Forwards to voice mail center. This function
does not include All Data Calls and All Fax Calls menus.
- To other number: Inputs the number for diverting.
• Cancel: Cancels the corresponding service.
• View status: Checks the status of the service.
]
Cancel all: Cancels all call divert service.
*
*:Shown only if supported by SIM card
Answer Mode (Menu 5.3.2)
Allows you to determine when to answer the phone.
]
Flip open: This option allows you to answer a call simply by
opening the flip.
]
Any key: You can answer an incoming call by pressing any
key, except the key.
]
Send Key Only: You can answer an incoming call by only
pressing the key.
Send My Number (Menu 5.3.3)
This network service allows you to set your phone number to be
displayed (On) or hidden (Off) from the person to whom you are
calling. Select Set by network to reset the phone to the setting
that you have agreed upon with your service provider.
Call Waiting (Menu 5.3.4)
The network will notify you of a new incoming call while you have a
call in progress. Select Activate to request the network to
activate call waiting, Cancel to request the network to deactivate
call waiting, or View status, to check if the function is active or
not.
Minute Minder (Menu 5.3.5)
This option allows you to specify whether the phone must beep
every minute during an outgoing call to keep you informed of the
length of the call.
Auto Redial (Menu 5.3.6)
Select On, and your phone will make a maximum of three attempts
to connect the call after an unsuccessful call attempt.
*
*
67
Settings
Security settings Menu 5.4
Various codes and passwords are used to protect the features of
your phone. They are described in the following sections (see
pages 22~23)
PIN Code Request (Menu 5.4.1)
When the PIN code request feature is enabled, you must enter your
PIN each time you switch the phone on. Consequently, any person
who does not have your PIN cannot use your phone without your
approval.
The following options are available:
• Enable: You must enter the PIN each time the phone is switched
on.
• Disable: The phone connects directly to the network when you
switch it on.
Call Barring Service (Menu 5.4.2)
Call barring allows you to restrict from making and receiving calls
with your phone. For this function, you need the barring password,
which you can obtain from your service provider.
The following options are available:
]
All outgoing: Calls cannot be made.
]
Outgoing international: International calls cannot be made.
]
Outgoing: When abroad, calls can be made only to numbers
within the current country and to your home country, which is
where your home network provider is located.
]
All incoming: Calls cannot be received.
]
Incoming when abroad: Calls cannot be received when you
are using your phone outside your home service area.
Note Before disabling the PIN code request feature, you must enter
your PIN
66
Settings
Closed User Group (Menu 5.3.7)
Closed user group is a network service that specifies the group of
people whom you can call and who can call you. For more
information contact your network operator or service provider. If a
group index is specified, it is used for all outgoing calls. If no group
index is specified, the network will use the preferential index
(a specific index that is stored in the network).
]
Preset: Setting the selected CUG Index.
]
On: Activating and editing the CUG Index.
]
Off: Deleting the selected CUG.
TTY (Menu 5.3.8)
The majority of users are Deaf, but commonly, a TTY is also used
by Hard of Hearing, Speech Impaired, and even Deaf and Blind
individuals. When you use a TTY, only one person can type at a
time, and you should not interrupt the other. Keep your sentences
short and right to the point. If at all possible, have a printer to
facilitate your life. Try to avoid asking too many questions at once.
]
TTY: Tele Type writer
]
TTD: Telecommunication Device for the Deaf
*
*:Shown only if supported by SIM card
Note TTY users must have a TTY/TDD device.
*
*
69
68
SettingsSettings
Connection settings Menu 5.5
Network Selection (Menu 5.5.1)
Access Point (Menu 5.5.2)
]
Cancel all barrings: All call barring settings are deactivated;
calls can be made and received normally.
]
Change password: You can set and change the call barring
password obtained from your service provider using this option.
You must enter the current password before you can specify a
new one.Once you have entered a new password, you are
asked to confirm it by entering it again.
Fixed Dial Number (FDN) (Menu 5.4.3)
Allows you to restrict your outgoing calls to selected phone
numbers, if this function is supported by your SIM card. The PIN2
code is required.
The following options are available:
]
Enable: You can only call phone numbers stored in the
phonebook. You must enter your PIN2.
]
Disable: You can call any number.
]
Number list: You can view the number list saved as fixed dial
number.
Change Codes (Menu 5.4.4)
The Change codes feature allows you to change your current
password to a new one. You must enter the current password
before you can specify a new one.
You can change the access codes: Security code, PIN1 code,
PIN2 code
Note To use Call Barring service, you must input the network
password. When calls are barred, calls may be possible to
certain emergency numbers in some networks.
Note Not all SIM cards have a PIN2. If your SIM card does not, this
menu option is not displayed.
Note PIN: Personal Identification Number.
*
*:Shown only if supported by SIM card
71
70
SettingsSettings
Attach (Menu 5.5.3)
If you select Power on and you are in a network that supports
packet data, the phone registers to the GPRS network and sending
short messages will be done via GPRS. Also, starting an active
packet data connection, for example, to send and receive e-mail, is
quicker. If you select When needed, the phone will use a packet
data connection only if you start an application or action that needs
it. The GPRS connection is closed after it is not used by any
application.
External Device (Menu 5.5.4)
When you use Internet via GPRS by using an external device, you
can set the following six profiles: Rename, APN, IP address,
DNS, User ID, and Password.
Reset Setting Menu 5.6
You can easily reset your phone to its default configuration. To do
so, proceed, as follows.
1. Select the Reset Settings menu option.
2. Enter the 4-digit phone password.
Note If there is no GPRS coverage and you have chosen Power
on, the phone will periodically try to establish a packet data
connection.
Note The password is preset to 0000.
73
72
Web Access Web Access
You can access various WAP(Wireless Application Protocol)
services such as banking, news, weather reports, and flight
information. These services are specially designed for mobile
phones and they are maintained by the WAP service providers.
Check the availability of WAP services, pricing and tariffs with your
network operator and/or the service provider whose service you
wish to use. Service providers will also give you instructions on how
to use their services.
Please contact your service provider to open an Internet account.
To use the Web Browser, you must indicate your phone number via
the Own number menu option (See page 78 for further details.)
To launch the browser in standby mode, press and hold down the
key.
Once connected, the homepage is displayed. The content
depends on the service provider.
You can open any WWW page by entering its URL address.
To exit the browser at any time, press the key. The idle screen
is displayed.
Navigating with the WAP Browser
You can surf the Internet using either the phone keys or the WAP
Browser menu.
Using the Phone Keys
When surfing the Internet, the phone keys function differently from
the phone mode.
Key Description
up/down navigation key Scroll each line of the content area
left navigation key Return to the previous page
Return to the startup homepage
Using the WAP Browser Menu
There are various menu options available when surfing the Wireless
Web.
]
Home: Connect the homepage which was set in active profile.
]
Bookmarks: Set the current homepage as a new bookmark or
move the established bookmark.
]
Forward: Move to previous page.
The following example shows the functionality of browser menu
‘Forward’.
1. Navigation Page A → Page B → Page C → Page D
2. On Page D, select a menu ‘Back’, it will place a user in Page C.
3. On Page C, if select a menu ‘Back’, move to Page B. else if
select a menu ‘Forward’, move to Page D again.
]
Go to URL: Connect to the specific URL after editing.
]
History: View all URL lists which have connected so far.
]
Save items: Save the item in current page which you connect.
]
Snapshots: Save current page.
]
Messages: Save the short message or push message.
]
Reload: Connect the server again and then bring back the
page.
]
Clear Cache: Remove all contexts saved in cache.
]
Mail server: Set or move to the mail server.
]
Advanced: Set the specific item related to connect or display
the browser.
]
About: View the information of S/W version.
Note The WAP Browser menus may vary, depending on your
version of the browser.
75
74
Web AccessWeb Access
Home Menu 6.1
Connect to a homepage. The homepage may be the site which is
defined in the activated profile. It will be defined by the Service
Provider if you have not defined it in the activated profile.
Bookmarks Menu 6.2
Your phone may have some pre-installed bookmarks for sites not
affiliated with LG. LG does not warrant or endorse these sites. If
you choose to access them, you should take the same precautions,
for security or content, as you would with any site.
Options in the Bookmarks view
Options available in the Bookmarks are: Open, New bookmark,
New folder, Connect, View, Edit, Move, Delete, New bookmark, and
New folder.
]
Inbox
A subfolder in which URLs extracted from SMS messages is saved.
• Open: View the list in inbox.
• New bookmark: Add new URL as a bookmark.
• New folder: Create new folder for bookmark.
]
Home
Home has URL information defined by At&t wireless. This menu is
set as a default. Each bookmark supports option menus as follows:
• Connect: Connect the bookmark.
• View: Check the bookmark setting.
• Edit: Modify the bookmark setting.
• Move: Move the bookmark to the other folder.
• Delete: Delete current bookmark.
• New bookmark: Create new bookmark in current folder.
• New folder: Create new sub-folder.
]
Tone Download: Download the ringtone from the selected
URL address.
• Connect: Connect to the URL address to download the
ringtone.
• View: Check the settings of profile.
• Edit: Modify the settings of profile.
• Move: Move the ringtone to the other folder.
• Delete: Delete the URL address.
• New bookmark: Create new bookmark in current folder.
• New folder: Create new sub-folder.
]
Graphic Download: Download the graphic from the selected
URL address.
• Connect: Connect to the URL address to download the
graphic.
• View: Check the settings of profile.
• Edit: Modify the settings of profile.
• Move: Move the graphic to the other folder.
• Delete: Delete the URL address.
• New bookmark: Create new bookmark in current folder.
• New folder: Create new sub-folder.
]
Delete all: Allows you to erase all bookmarks.
77
76
Web AccessWeb Access
Profiles Menu 6.3
A Profile is the network information used to connect to the internet.
At&t wireless supports three kinds of profiles: Express, Home and
Roam.
Express is used to connect to the internet using GPRS,
Home uses CSD (Circuit Switched Data) with At&t wireless
gateways, and Roam uses CSD without the At&t wireless network.
Because At&t wireless also selects a bearer automatically
according to the current network status, the user doesn’t need to
select any of them.
Each profile has submenus as follows:
]
Activate: Set a current profile as a default.
]
Settings: Edit the various items of the current profile.
]
Rename: Revise the name of profile.
]
Delete: Delete the profile.
]
New profile: Create new profile.
Express
1. Activate
2. Settings
3. Rename
4. Delete
5. New profile
Home
1. Activate
2. Settings
3. Rename
4. Delete
5. New profile
Roam
1. Activate
2. Settings
3. Rename
4. Delete
5. New profile
Go to URL Menu 6.4
You can directly connect to the site you want. You need to enter a
specific URL.
Cache Settings Menu 6.5
The information or services you have accessed are stored in the
cache memory of the phone.
Clear Cache (Menu 6.5.1)
Remove all contexts saved in cache.
Cache Check (Menu 6.5.2)
Set a value whether a connection attempt is made through cache
or not.
Security Certificates Menu 6.6
A list of the available certificates is shown.
WAP information Menu 6.7
The WAP Browser version is displayed.
Note A cache is a buffer memory, which is used to store data
temporarily.
79
78
Tools
My Folder Menu 7.1
Enables you to download pictures or sounds which can be used as
ringtone. You can view, listen, delete or rename downloaded data.
In the My folder menu, the following options are available:
Picture (Menu 7.1.1)
If you get a picture from a WAP site or camera, you can view the
sub-menus as follow:
1. Send via multimedia message
2. Set as wallpaper
3. Edit title
4. Delete
5. Delete all
If you get a picture from EMS, you can view the sub-menus as
follow:
1. Send via text message
2. Edit title
3. Delete
4. Delete all
Animation (Menu 7.1.2)
If you get an animation from WAP site, you can view the sub-menus
as follow:
1. Send via multimedia message
2. Edit title
3. Delete
4. Delete all
If you get an animation from EMS or SMS, you can view the sub-
menus as follow:
1. Send via text message
2. Edit title
3. Delete
4. Delete all
Sound (Menu 7.1.3)
If you get a sound from a WAP site, you can view the sub-menus as
follow:
1. Send via multimedia message
2. Set as ring tone
3. Edit title
4. Delete
5. Delete all
If you get a sound from EMS, you can view the sub-menus as
follow:
1. Send via text message
2. Send via multimedia message
3. Set as ring tone
4. Edit title
5. Delete
6. Delete all
Send via text message: You can send the title for each
downloaded content.
Send via multimedia message: You can send the title for
each downloaded content.
Set as wallpaper: You can set downloaded pictures as
wallpaper.
Set as ring tone: You can set downloaded sounds as ring tone.
Edit title: You can edit the title for each downloaded content.
Delete: You can delete each downloaded content.
Delete all: You can delete all downloaded content.
Tools
81
80
ToolsTools
Alarm Clock Menu 7.2
Set the alarm to ring at a specific time. In the Alarm Clock menu,
the following options are available:
On: Set the time(hour and minute) for activating the alarm.
1. Enter the menu.
2. Select [On] by pressing the right/left navigation keys.
3. If you want to set the time for activating the alarm, press the
down navigation key.
4. Enter the required time, press the down navigation key.
5. The following options are available.
• Once: The alarm rings only once and is then deactivated.
• Daily: The alarm rings every day at the same time.
• Weekly: The alarm rings every week on the same day and at
the same time.
• Monthly: The alarm rings every month on the same day and
at the same time.
6. Allows you to select the alarm melody by using the right/left
navigation keys.
7. Press the left soft key [Set].
Off: Cancel the alarm.
Notice If this option is set to On, the alarm will ring at the specified
time, even when the phone is switched off.
To stop the alarm when it rings, open the phone and press
the right soft key[Quit].
Calendar Menu 7.3
When you enter this menu a calendar will be displayed. Top of the
screen indicates sections for date. Square cursor is used to locate
a particular day. The under bar on the calendar indicates a
schedule or memo on that day. This function helps to remind you of
the schedule and memo. The phone will sound an alarm tone if it
has been set for a specific note.
For changing the day, month, and year.
Note Your phone should be switched on to use this function.
Key Description
up/down navigation key
left/right navigation key
Weekly
Daily
• View
Press [Options] to delete or edit the note you selected.
• Edit
Allows you to edit the schedule.
• Delete
Allows you to delete the schedule.
• Add new
You can edit maximum of 30 characters and create up to 30
notes.
• Calendar
Allows you to consult the calendar.
• Scheduler tone
The phone can sound an alarm tone when the scheduled date for
an event has been reached with this option.
83
82
Calculator Menu 7.4
Using this feature, you can use the phone as a calculator. The
calculator provides the basic arithmetic functions: addition,
subtraction, multiplication and division(Can enter numbers up to
the second decimal place).
Using the Calculator
1. Enter the first number using the numeric keys.
2. Use the navigation keys to select a sign for calculation.
3. To calculate the result, press the left soft key [Result]or
key.
Note To include a decimal point, press the key.
Tools Tools
• View all schedules
Shows the notes that are set for all days. Use the up/down
navigation keys to browse through the note lists. You can use the
menu by press the left soft key [Options].
• Go to date
Allows you to jump to a specific date.
• Delete past
Delete past schedule event that has already been notified.
• Delete all
Delete all schedules. You are asked to confirm your action.
Note You can see Edit, Delete,View all schedules, Delete
past, and Delete all menus dependent on setting of
the schedule.
Memo Menu 7.5
To write, edit and delete a memo on a specific date, proceed as
follows.
1. Scroll to highlight Memo.
2. Press the left soft key [Add].
3. Input the memo and press the left soft key [Options].
The following options are available.
]
Save: Allows you to save the memo.
]
T9 languages: Allows you to select the T9 language to use in
memo.
]
Exit editor: Allows you to exit in memo editor.
Or
1. Select a Memo.
2. Press the left soft key [Select].
3. Press the left soft key [Options].
The following options are available.
]
Edit: If you select a memo that already exists, you can press
the left soft key [Options → Edit] to edit the memo displayed.
]
Delete: Allows you to delete the memo. You can press the left
soft key [Options → Delete] to edit the memo displayed.
]
Add new: Add a new memo, up to 20 memos and 40
characters per each memo.
]
Delete all: Allows you to delete all memos. You are asked to
confirm your action.
85
84
Tools
World Time Menu 7.6
Allows you to check the current Greenwich Mean Time(GMT) and
51 major cities around the world, using the left/right navigation
keys.
The screen shows the city name, current date and time.
To select the time zone in which you are located, proceed as
follows:
1. Select the city corresponding to your time zone by pressing the
left/right navigation keys one or more times. The local date and
time are displayed.
2. Press the left soft key [Options].
3. If you want to set, press key.
4. If you want to set Summer time, press the key in
Options menu.
Note The time zone setting of each city in World time menu may be
affected by network condition.
Unit Converter Menu 7.7
This converts any measurement into a unit you want.
There are 4 types that can be converted into units: Length,
Surface, Weight, and Volume.
1. You can select one of four unit types by pressing the left soft key
[Unit].
2. Select the standard value by using the left/right navigation keys.
3. Select the unit you want to convert by pressing the up/down
navigation keys.
4. You can check the converted value for the unit you want. Also,
you can input a decimal number by pressing the key.
Phonebook
Contact list Menu 8.1
1. When the idle screen is displayed, press the right soft key
[Names]. You are asked to enter a name.
2. Enter the start of the name that you wish to find and press
the left soft key [Search].
3. If you want to edit, delete, copy an entry, or to add the voice to
one, select [Options].
4. Once you have found the required entry, press the to dial
the number.
• View detail: To view in detail the selected name.
• Edit: You can edit the name, number, E-mail group and memo
by press the left soft key [OK].
• Delete: You can delete an entry.
• Write text message: You can write a text message. For
further details, see page 39.
• Write multimedia message: You can write a multimedia
message. For further details, see page 43.
You can store phone numbers and their corresponding names in
the memory of your SIM card. In addition, you can store up to 255
numbers and names in the phone memory. The SIM card and
phone memories, although physically separate, are used as if they
were a single entity, called the phonebook.
1. To use the Phonebook, press the right soft key [Names] in
the standby mode.
2. To use the Phonebook, press the left soft key [Menu] in the
standby mode and select the Organizer.
Note You can also scroll through the phonebook from the
beginning, by pressing the left soft key [Search] directly.
Note To use the Phonebook, press the right soft key [Names] in
standby mode or press the left soft key [Menu], , .
• Copy: You can copy an entry from SIM to phone or from phone
to SIM.
• Voice: You can add voice to the entry or change the voice tag.
• Main number: You can select the main number out of your
mobile, home or office numbers. Choose the one that is most
often used. The main number will be displayed first, if you set
this.
Add New Menu 8.2
You can add a phonebook entry by using this function. Phone
memory capacity is 255 entries. SIM card memory capacity
depends on the cellular service provider. You can also save 20
characters of name in the phone memory, and save characters in
the SIM card. The number of characters is dependent on the SIM.
1. Open the phonebook first by pressing the right soft key
[Names] in standby mode.
2. Scroll to highlight Add New, and press the left soft key [OK].
3. Select the memory you want to save: SIM or Phone.
a. Enter a name and then press the down navigation key.
b. Enter a number and then press the down navigation key.
c. You can set a group for the entry by pressing the right/left
navigation key.
d. Press left soft key [Save].
You should say the words within 2 seconds, and the phone asks
you to say it again to ensure the accuracy of voice recognition.
87
86
Phonebook
Note The voice can only be attached to the main number which you
set. For example, if you change the main number, voice will be
automatically attached to the changed number. This means
that you cannot attach voice to mobile, office and home
numbers simultaneously. You can add a voice tag to a phone
number in the SIM card. The voice tag can be erased if you
remove or change the SIM card.
Phonebook
Speed Dials Menu 8.3
You can assign any of the keys, to with a name list entry.
You can call directly by pressing this key for 2-3 seconds.
1. Open the phonebook first by pressing the right soft key
[Names] in a standby mode.
2. Scroll to Speed Dials, then press the left soft key [OK].
3. If you want to add a number to speed dial, select <Empty>.
Then, you can search the name from the phonebook.
4. Select the name from the speed dial. You can change and
delete the name. In addition, you can call by this number, write
text message, and multimedia message.
Caller Groups Menu 8.4
There are 7 predefined groups as well as one additional group
labeled Others where you can create your own lists.
1. You can set the phone to ring in a specific way and display a
preselected graphic icon when a particular person calls you.
2. Scroll to Caller Groups then press the left soft key [OK] to
enter this menu.
3. Every Group list will be displayed : Family, VIP, Friends,
Colleague, Group 1, Group 2, Others.
4. Select the Group name that you want to manage by pressing
the left soft key [Options].
5. You will see the following submenus under the predefined
groups except for the Others group.
• Member list: Allows you to see the member list in the group.
• Group ring tone: Allows you to select the ring tone to be
used when you receive a voice phone call from a person in the
group.
• Group icon: Allows you to select the graphic icon to be
displayed when you receive a call from a person in the group.
• Add member: Allows you to add the member to the group.
• Delete member: Allows you to delete the member in the
group.
• Rename: Allows you to assign a name to the group.
Copy All Menu 8.5
You can copy or move entries from the SIM card memory to the
phone memory and vice versa.
]
SIM to Phone: You can copy the entry from the SIM card to
phone memory.
]
Phone to SIM: You can copy the entry from the phone
memory to the SIM card.
The following options are available:
• Keep original: When copying, Original Dial Number is kept.
• Delete original: When copying, Original Dial Number will
be erased.
Delete All Menu 8.6
You can delete all entries in the SIM, Phone and Voice list. This
function requires the security code except for Voice.
Press the key to return to the standby mode.
89
88
PhonebookPhonebook
Settings Menu 8.7
1. Set memory: Scroll to highlight the Set memory option,
then press the left soft key [OK].
• If you select Variable when adding entry, the phone will ask
where to store.
• If you select SIM or Phone, the phone will store an entry to
the SIM or the phone.
2. Search by: Scroll to highlight the Search by option, then
press the left soft key [OK].
• If you select Variable, the phone will ask how to search.
• If you select Name or Number, the phone will search an
entry by Name or the Number.
Information Menu 8.8
]
Service dial number: You can view the list of Service Dialing
Numbers (SDN) assigned by your network provider(If supported
by the SIM card). Such numbers include the emergency,
directory assistance and voice mail numbers.
1. Select the Service dial number option.
2. The names of the available services will be shown.
3. Use the up/down navigation keys to select a service. Press the
key
]
Check memory: You can check how many names and
numbers are stored in the phonebook (SIM card and phone
memories).
]
Own number: Allows you to display your phone number in the
SIM card.
*
*
91
90
Q&A
Please check to see if any problems you have encountered with the
phone are described in this section before taking the phone in for a
service or calling a service engineer.
Q How do I view the list of outgoing calls, incoming calls and
missed calls?
A Press the key.
Q How do I clear all call history?
A Press the left soft key[Menu] and then the key.
Q How do I view all numbers stored in memory?
APress right soft key[Names] and then .
Q Why is the connection abrupt or not audible in certain areas?
AWhen frequency environment is unstable in a certain area,
connection may be abrupt and not audible. Relocate to another
area and try again.
QWhy is the connection not consistent or abrupt even when
established?
A When frequency is unstable or weak or if there are too many
users, connection may be cut off even after it was established.
Please try again later or attempt after relocating to other areas.
QWhy does the LCD not turn on?
A Remove the battery and turn on the power after placing it back
on. If there is no change, fully charge the battery and try again.
Q&A
Q Why is there an echo when a connection is made with certain
telephones in a certain area?
AThis is called the ‘Echo Phenomenon’, where it occurs if
connection volume is too high or caused by special properties
(semi electronic telephone exchange) of the equipment on the
other end.
QWhy does the phone heat up?
AThe phone may get hot when there is a very long call duration or
when games are played or even when surfing the Internet for a
long time. This has no effect upon the life of the product or
performance.
QWhy is there no ring tone, but only a blinking LCD screen?
APhone may be set to ‘Vibrate only’ or in ‘Silent’ mode. In the
Profiles menu, please select ‘General’ or ‘Loud’.
Q Why does the battery life get shorter in standby mode?
A The battery is worn out. As time passes, the battery life
gradually becomes shorter. If the battery lasts about half the
amount of time as when first purchased, it’s time to purchase a
new battery.
QWhy does the battery run out so quickly during normal use?
AIt is due to the user environment or a large number of calls or
weak signal.
QWhy is no number dialed when you recall a phonebook entry?
A Check that the number has been stored correctly by using the
Phone book Search feature. Re-store them, if necessary.
93
92
Q&A
QWhy can’t my correspondent reach me?
A Is you phone switched on ( pressed for more than three
seconds)? Are you accessing the right cellular network? Or, you
may have set an incoming call barring option.
QI cannot find the lock, PIN, or PUK code. What is my password?
A The default lock code is ‘0000’. If you forget or lose the lock
code, contact your phone dealer. If you forget or lose a PIN or
PUK code, or if you have not received such a code, contact
your network service provider
Accessories
Travel Adapter
This adapter allows you to charge the
battery.
It supports standard U.S. 120 Volt 60Hz
outlets.
It takes 5 hours to charge a completely
discharged battery.
Battery
Standard battery is available.
Vehicle Power Adapter
You can operate the phone and trickle
charge the phone battery from your
vehicle by using the vehicle power
adapter.
It takes 5 hours to charge a completely
discharged battery.
Headset
Connects to your phone, allowing hands-
free operation. Includes earpiece,
microphone, and integrated call
answer/termination button.
There are a variety of accessories available for your mobile phone.
You can select these options according to your personal
communication requirements. Consult your local dealer for
availability.
95
94
Data Cable Kit
Connects your phone to a PC.
Accessories Safety Guidelines
TIA Safety Information
Provided herein is the complete TIA Safety Information for Wireless
Handheld phones. Inclusion of the text covering Pacemakers,
Hearing Aids, and Other Medical Devices is required in the owner’s
manual for CTIA Certification. Use of the remaining TIA language is
encouraged when appropriate.
Exposure to Radio Frequency Signal
Your wireless handheld portable telephone is a low-power radio
transmitter and receiver. When it is ON, it receives and also sends
out radio frequency (RF) signals.
In August, 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986)
ICNIRP (1996)
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. For example, over
120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available
body of research to develop the ANSI Standard (C95.1).
*American National Standards Institute; National Council on
Radiation Protection and Measurements; International Commission
on Non-Ionizing Radiation Protection
The design of your phone complies with the FCC guidelines (and
those standards).
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could
damage the phone and may violate FCC regulations.
97
96
Safety Guidelines
Phone Operation
NORMAL POSITION: Hold the phone as you would any other
telephone with the antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
]
Do not touch the antenna unnecessarily when the phone is in
use. Contact with the antenna affects call quality and may cause
the phone to operate at a higher power level than otherwise
needed.
Driving
Check the laws and regulations on the use of wireless phones in
the areas where you drive. Always obey them. Also, if using your
phone while driving, please:
]
Give full attention to driving — driving safely is your first
responsibility;
]
Use hands-free operation, if available;
]
Pull off the road and park before making or answering a call if
driving conditions so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6’) inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and recommendations
of Wireless Technology Research.
Persons with pacemakers:
]
Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
Safety Guidelines
]
Should not carry the phone in a breast pocket.
]
Should use the ear opposite the pacemaker to minimize the
potential for interference.
]
If you have any reason to suspect that interference is taking
place, turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids.
In the event of such interference, you may want to consult your
service provider.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer
or its representative regarding your vehicle.
You should also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so
require.
Aircraft
FCC regulations prohibit using your phone while in the air. Turn
your phone OFF before boarding an aircraft.
99
Safety Guidelines
98
Safety Guidelines
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF
when in a ‘blasting area’ or in areas posted: ‘Turn off two-way
radio’. Obey all signs and instructions.
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily injury or
even death.
Areas with a potentially explosive atmosphere are often, but not
always, marked clearly. Potential areas may include: fueling areas
(such as gasoline stations); below deck on boats; fuel or chemical
transfer or storage facilities; vehicles using liquefied petroleum gas
(such as propane or butane); areas where the air contains
chemicals or particles (such as grain, dust, or metal powders); and
any other area where you would normally be advised to turn off
your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects,
including either installed or portable wireless equipment, in the
area over the air bag or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed and the air bag inflates,
serious injury could result.
FDA Consumer Update
The U.S. Food and Drug Administration’s Center for Devices and
Radiological Health Consumer Update on Mobile Phones.
1.Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is no
proof, however, that wireless phones are absolutely safe.
Wireless phones emit low levels of radiofrequency energy (RF) in
the microwave range while being used. They also emit very low
levels of RF when in the standby mode. Whereas high levels of
RF can produce health effects (by heating tissue), exposure to
low level RF that does not produce heating effects causes no
known adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some studies
have suggested that some biological effects may occur, but such
findings have not been confirmed by additional research. In some
cases, other researchers have had difficulty in reproducing those
studies, or in determining the reasons for inconsistent results.
2.What is the FDA's role concerning the safety of
wireless phones?
Under the law, the FDA does not review the safety of radiation-
emitting consumer products such as wireless phones before they
can be sold, as it does with new drugs or medical devices.
However, the agency has authority to take action if wireless
phones are shown to emit radiofrequency energy (RF) at a level
that is hazardous to the user. In such a case, the FDA could
require the manufacturers of wireless phones to notify users of
the health hazard and to repair, replace, or recall the phones so
that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, the FDA has urged the wireless phone industry to take a
number of steps, including the following:
101
100
Safety GuidelinesSafety Guidelines
]
Support needed research into possible biological effects of RF
of the type emitted by wireless phones;
]
Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device function;
and
]
Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use
on human health.
The FDA belongs to an interagency working group of the federal
agencies that have responsibility for different aspects of RF safety
to ensure coordinated efforts at the federal level. The following
agencies belong to this working group:
o National Institute for Occupational Safety and Health
o Environmental Protection Agency
o Occupational Safety and Health Administration
o National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
The FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that
are sold in the United States must comply with FCC safety
guidelines that limit RF exposure. The FCC relies on the FDA and
other health agencies for safety questions about wireless phones.
The FCC also regulates the base stations that the wireless phone
networks rely upon. While these base stations operate at higher
power than do the wireless phones themselves, the RF exposures
that people get from these base stations are typically thousands of
times lower than those they can get from wireless phones. Base
stations are thus not the subject of the safety questions discussed
in this document.
3.What kinds of phones are the subject of this
update?
The term ‘wireless phone’ refers here to handheld wireless
phones with built-in antennas, often called ‘cell’, ‘mobile’, or ‘PCS’
phones. These types of wireless phones can expose the user to
measurable radiofrequency energy (RF) because of the short
distance between the phone and the user’s head.
These RF exposures are limited by FCC safety guidelines that
were developed with the advice of the FDA and other federal
health and safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is drastically lower
because a person's RF exposure decreases rapidly with
increasing distance from the source. The so-called ‘cordless
phones,’ which have a base unit connected to the telephone
wiring in a house, typically operate at far lower power levels, and
thus produce RF exposures far below the FCC safety limits.
4.What are the results of the research done
already?
The research done thus far has produced conflicting results, and
many studies have suffered from flaws in their research methods.
Animal experiments investigating the effects of radiofrequency
energy (RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have suggested that
low levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that showed
increased tumor development used animals that had been
genetically engineered or treated with cancer-causing chemicals
so as to be pre-disposed to develop cancer in the absence of RF
exposure. Other studies exposed the animals to RF for up to 22
hours per day. These conditions are not similar to the conditions
under which people use wireless phones, so we don’t know with
certainty what the results of such studies mean for human health.
Three large epidemiology studies have been published since
December 2000. Between them, the studies investigated any
103
102
Safety GuidelinesSafety Guidelines
possible association between the use of wireless phones and
primary brain cancer, glioma, meningioma, or acoustic neuroma,
tumors of the brain or salivary gland, leukemia, or other cancers.
None of the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term exposures,
since the average period of phone use in these studies was around
three years.
5.What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and epidemiological studies of
people actually using wireless phones would provide some of the
data that are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large numbers of animals
would be needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or more years
follow-up may be needed to provide answers about some health
effects, such as cancer. This is because the interval between the
time of exposure to a cancer-causing agent and the time tumors
develop — if they do — may be many, many years. The
interpretation of epidemiological studies is hampered by difficulties
in measuring actual RF exposure during day-to-day use of wireless
phones. Many factors affect this measurement, such as the angle
at which the phone is held, or which model of phone is used.
6.What is the FDA doing to find out more about
the possible health effects of wireless phone
RF?
The FDA is working with the U.S. National Toxicology Program and
with groups of investigators around the world to ensure that high
priority animal studies are conducted to address important
questions about the effects of exposure to radiofrequency energy
(RF).
The FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project
since its inception in 1996. An influential result of this work has
been the development of a detailed agenda of research needs
that has driven the establishment of new research programs
around the world. The project has also helped develop a series of
public information documents on EMF issues.
The FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research and
Development Agreement (CRADA) to do research on wireless
phone safety. The FDA provides the scientific oversight, obtaining
input from experts in government, industry, and academic
organizations. CTIA-funded research is conducted through
contracts with independent investigators. The initial research will
include both laboratory studies and studies of wireless phone
users. The CRADA will also include a broad assessment of
additional research needs in the context of the latest research
developments around the world.
7.How can I find out how much radio frequency
energy exposure I can get by using my
wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radio
frequency energy (RF) exposures. The FCC established these
guidelines in consultation with the FDA and the other federal
health and safety agencies. The FCC limit for RF exposure from
wireless telephones is set at a Specific Absorption Rate (SAR) of
1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with
the safety standards developed by the Institute of Electrical and
Electronic Engineering (IEEE) and the National Council on
Radiation Protection and Measurement. The exposure limit takes
into consideration the body’s ability to remove heat from the
tissues that absorb energy from the wireless phone and is set
well below levels known to have effects. Manufacturers of
wireless phones must report the RF exposure level for each
model of phone to the FCC. The FCC website
105
104
Safety GuidelinesSafety Guidelines
(http://www.fcc.gov/oet/ rfsafety) gives directions for locating the
FCC identification number on your phone so you can find your
phone’s RF exposure level in the online listing.
8.What has the FDA done to measure the radio
frequency energy coming from wireless
phones?
The Institute of Electrical and Electronic Engineers (IEEE) is
developing a technical standard for measuring the radio
frequency energy (RF) exposure from wireless phones and other
wireless handsets with the participation and leadership of FDA
scientists and engineers. The standard, ‘Recommended Practice
for Determining the Spatial-Peak Specific Absorption Rate (SAR)
in the Human Body Due to Wireless Communications Devices:
Experimental Techniques,’ sets forth the first consistent test
methodology for measuring the rate at which RF is deposited in
the heads of wireless phone users. The test method uses a
tissue-simulating model of the human head. Standardized SAR
test methodology is expected to greatly improve the consistency
of measurements made at different laboratories on the same
phone. SAR is the measurement of the amount of energy
absorbed in tissue, either by the whole body or a small part of the
body. It is measured in watts/kg (or milliwatts/g) of matter. This
measurement is used to determine whether a wireless phone
complies with safety guidelines.
9.What steps can I take to reduce my exposure
to radiofrequency energy from my wireless
phone?
If there is a risk from these products — and at this point we do
not know that there is — it is probably very small. But if you are
concerned about avoiding even potential risks, you can take a
few simple steps to minimize your exposure to radiofrequency
energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a
wireless phone will reduce RF exposure.
If you must conduct extended conversations by wireless phone
every day, you could place more distance between your body
and the source of the RF, since the exposure level drops off
dramatically with distance. For example, you could use a
headset and carry the wireless phone away from your body or
use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like those
described above to reduce your RF exposure from wireless
phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you want
to take steps to lower exposure to radiofrequency energy (RF),
the measures described above would apply to children and
teenagers using wireless phones. Reducing the time of wireless
phone use and increasing the distance between the user and
the RF source will reduce RF exposure.
Some groups sponsored by other national governments have
advised that children be discouraged from using wireless
phones at all. For example, the government in the United
Kingdom distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists that
using a wireless phone causes brain tumors or other ill effects.
Their recommendation to limit wireless phone use by children
was strictly precautionary; it was not based on scientific
evidence that any health hazard exists.
11.What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can interact
with some electronic devices. For this reason, the FDA helped
develop a detailed test method to measure electromagnetic
interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now
107
106
Safety GuidelinesSafety Guidelines
part of a standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI). The final draft,
a joint effort by the FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard
will allow manufacturers to ensure that cardiac pacemakers and
defibrillators are safe from wireless phone EMI.
The FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard
sponsored by the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and performance
requirements for hearing aids and wireless phones so that no
interference occurs when a person uses a ‘compatible’ phone
and a ‘compatible’ hearing aid at the same time. This standard
was approved by the IEEE in 2000.
The FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should harmful
interference be found to occur, the FDA will conduct testing to
assess the interference and work to resolve the problem.
12.Where can I find additional information?
For additional information, please refer to the following
resources:
FDA web page on wireless phones
(http://www.fda.gov/cdrh/phones/index.html)
Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-lonizing Radiation Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
National Radiological Protection Board (UK)
(http://www.nrpb.org.uk/)
Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s
Requirements for Exposure to Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government.
These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg. * Tests for SAR are
conducted using standard operating positions specified by the
FCC with the phone transmitting at its highest certified power level
in all tested frequency bands. Although SAR is determined at the
highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. Because
the phone is designed to operate at multiple power levels to use
only the power required to reach the network, in general, the closer
you are to a wireless base station antenna, the lower the power
output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by the FCC for each
model. The highest SAR value for this model phone when tested for
use at the ear is 0.714 W/kg and when worn on the body, as
109
108
Safety Guidelines
described in this user’s manual, is 0.482 W/kg. (Body-worn
measurements differ among phone models, depending upon
available accessories and FCC requirements.) While there may be
differences between SAR levels of various phones and at various
positions, they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after searching on
FCC ID BEJC1300.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications Industry Association
(CTIA) website at http://www.wow-com.com
*In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a substantial margin of safety
to give additional protection for the public and to account for any
variations in measurements.
To help you understand the main technical terms and abbreviations
used in this booklet and take full advantage of the feature on your
mobile phone, here are a few definitions.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Divert
Ability to reroute calls to another number.
Call waiting
Ability to inform users that they have an incoming call when
engaged on another call.
GPRS (General Packet Radio Service)
GPRS guaranties continuous connection to the Internet for mobile
phone and computer users. It is based on the Global System for
Mobile Communication (GSM) circuit-switched cellular phone
connections and the Short Message Service (SMS).
GSM (Global System for Mobile
Communication)
International standard for cellular communication, guaranteeing
compatibility between the various network operators. GSM covers
most European countries and many other parts of the world.
Java
Programming language generating applications that can run on all
hardware platforms, whether small, medium or large, without
modification. It has been promoted for and geared heavily to the
Web, both for public Web sites and Intranets. When a Java
program runs from a Web page, it is called a Java applet. When it
is run on a mobile phone or pager, it is called a MIDlet.
Glossary
111
110
Line Identification Services (Caller ID)
Service allowing subscribers to view or block the telephone
numbers of callers.
Multiparty Calls
Ability to establish a conference call involving up to five additional
parties.
Phone Password
Security code used to unlock the phone when you have selected
the option to lock it automatically each time it switches on.
Roaming
Use of your phone when you are outside your home area (when
traveling for example).
SDN (Service Dial Number)
Telephone numbers supplied by your network provider and giving
access to special services, such as voice mail, directory inquiries,
customer support and emergency services.
SIM (Subscriber Identification Module)
Card containing a chip with all the information required to operate
the phone (network and memory information, as well as the
subscriber's personal data). The SIM card fits into a small slot on
the back of the phone and is protected by the battery.
SMS (Short Message Service)
Network service sending and receiving messages to and from
another subscriber without having to speak to the correspondent.
The message created or received (up to 160 characters long) can
be displayed, received, edited or sent.
Glossary
P/N: DATE: 2003.12.08
Patent Information
This product was manufactured under one or more of the following U.S.
patents: 5276765 5749067 6061647
113
112
Index
F
FDN 70
Fixed dial number 70
Flip open 67
G
Game 62
Go to URL 75,79
GPRS 111
Group icon 90
Group ring tone 89
H
Headset 56,57,95
I
Inbox 39,43,51,76
In-call menu 30
L
Languages 52
Last call 57
Last call’s cost 58
Lower case 28
M
Making a Call 23
Making international calls 23
Manner Mode 25
Menu tree 34
Memo 85
Member list 89
Memory status
63
Message center url 46
Message key
14,
15
Message types 41
Microphone
14,
15
Minute minder 67
Missed calls 56
Mute off 31
Mute on 31
Muting the microphone 31
Multimedia messages 42
Mutiparty calls 32
N
Name card
39,
53
Navigation Key 14,15
Network settings 71
O
Outbox 40, 44
Own number 91
P
Phonebook 29, 87
Phone to SIM 90
Power key
14,
15
Index
A
Access codes 22
Accessories 95
Active flip 14,15
Add new 88
Add member 90
Adjusting the volume 24
Alarm clock 82
All calls’ cost 58
Answering a call 24
Answer mode 67
Auto display 51,59
Auto redial 67
B
Backlight 64
Barring password 22
Battery 8,13,16,18,19,95
Bearer setting 41
Bookmarks 76
C
Cache check 79
Calculator 84
Calendar 83
Caller groups 89
Call barring service 69
Call costs 58
Call cost’s limit 58
Call divert 66
Call durations 57
Call waiting 30,67,111
Cancel all barrings 70
Change password 66
Check memory
53,
91
Clear cache 79
Clear key
14,
15
Closed user group 68
Conference calls 32
Connection settings 71
Contact list 87
Copy all 90
CPHS
34,
35
D
Delete recent calls 57
Delivery reports 41
Dialed calls 57
Display screen
14,
15
Display information 17
E
End key
14,
15
Ending a call 23
Entering text 25
114
Index
Private call 33
R
Received Calls 56,57
S
Security code 22,70
Send
14,
15,40,42,45,53
Send my number 67
Set memory 91
Service dial number 91,112
Side keys
14,
15
Signal strength 25
SIM to phone 90
Speed dials 89
T
Templates 52
Text messages 38
Time format 64
Travel adapter 95
U
Unit converter 86
Upper case 28
V
Valid period 41
Voice mailbox number 49
Voice memo key
14,
15
Voice mail 49
W
Wallpaper 64
WAP browser 75
WAP information 79
Web access 74
World time 86
Write message 38
1. Press the left soft key [Menu].
2. Scroll with the up/down navigation keys through the list of
menus until you reach the required menu.
3. Press the left soft key [OK].
4. Scroll with the up/down navigation keys through the list of
options until the required one is selected.
5. Press the left soft key [OK] to confirm.
Power on/off Press and hold .
Making a Call 1. Key in the number.
2. Press the key.
End a Call Briefly press the key.
Answer a Call Open the flip and
press the key.
Adjust the Volume Press the Side keys of
the phone.
Store numbers 1. Key in the number.
2. Press the left soft key [Options].
3. Press the left soft key [OK], [Select].
4. Enter the name.
5. Press the left soft key [Save].
Choose the 1. In standby mode, press left navigation
key.
2. Select an option:
Vibrate only, Silent, General, Loud.
3. Press the left/right navigation keys.
4. Press the key.
Search 1. Press the right soft key [Names].
2. Press the left soft key [OK].
3. Press the left soft key [Search].
(During a call)
in the Phonebook
Alert Type
Quick Reference Card
Access the Menu Function
