LG Electronics USA CU500 Dual-Band Dual-Mode GSM/ WCDMA Phone with BT User Manual CU500 ENG 0111
LG Electronics USA Dual-Band Dual-Mode GSM/ WCDMA Phone with BT CU500 ENG 0111
Users Manual
CU500
User Guide
2
For Your Safety......................................................... 7
Your Phone ............................................................. 11
Phone Components .......................................................... 11
Your Phone’s Features..................................................... 12
Display Information.......................................................... 13
Getting Started....................................................... 15
Installing the SmartChip ................................................. 15
Charging the Battery........................................................ 16
Memory card slot ............................................................. 17
Inserting the memory card.............................................. 18
Removing the memory card............................................ 18
Turning Your Phone On and Off ..................................... 19
Access Codes.................................................................... 19
Barring Password ............................................................ 19
General Functions ................................................. 20
Making a Call.................................................................... 20
Making a Call by Send Key.............................................. 20
Making International Calls .............................................. 20
Ending a Call ...................................................................... 20
Making a Call From the Contacts ................................... 20
Adjusting the Volume ...................................................... 21
Answering a Call.............................................................. 21
Vibrate Mode (Quick) ....................................................... 21
Signal Strength.................................................................. 21
Entering Text ..................................................................... 21
Selecting Functions and Options ....................... 25
Address Book......................................................... 26
In-Call Menu........................................................... 27
During a Call...................................................................... 27
Making a Second Call ...................................................... 27
Swapping Between Two Calls........................................ 27
Answering an Incoming Call........................................... 27
Rejecting an Incoming Call ............................................. 27
Muting the Microphone................................................... 27
Conference Calls .............................................................. 28
Table of Contents
3
Making a Second Call ...................................................... 28
Setting Up a Conference Call.......................................... 28
Activate the Conference Call on Hold ........................... 28
Adding Calls to the Conference Call.............................. 28
Private Call in a Conference Call.................................... 28
Ending a Conference Call ................................................ 28
Menu Tree............................................................... 29
IM ............................................................................. 33
Messaging .............................................................. 37
IM ........................................................................................ 37
New Message................................................................... 37
Message............................................................................. 37
Email.................................................................................... 39
Inbox ................................................................................... 40
Email Inbox........................................................................ 41
Drafts .................................................................................. 42
Outbox ................................................................................ 42
Sent ..................................................................................... 43
Voice Mail ......................................................................... 43
Chat ..................................................................................... 44
Templates .......................................................................... 44
Text Templates.................................................................. 44
Multimedia Templates ..................................................... 44
Signature............................................................................ 44
Message Settings............................................................. 44
Text Message.................................................................... 44
Multimedia Message ....................................................... 45
Email.................................................................................... 45
Voicemail............................................................................ 46
Download Messages ....................................................... 46
Recent Calls ........................................................... 47
Missed Calls...................................................................... 47
Dialed Calls ....................................................................... 47
Received Calls .................................................................. 47
All Calls.............................................................................. 47
Call Timer........................................................................... 47
Last Call .............................................................................. 47
Received Calls................................................................... 47
4
Dialed Calls ........................................................................ 48
All Calls............................................................................... 48
Data Count ......................................................................... 48
Data Time ........................................................................... 48
Data Volume ...................................................................... 48
MEdia Net ............................................................... 49
MEdia Net Home............................................................... 49
Bookmarks......................................................................... 49
Saved Pages...................................................................... 50
Go to URL............................................................................ 50
Security .............................................................................. 50
Browser Settings.............................................................. 50
Accounts ............................................................................ 50
Cache Settings .................................................................. 51
Cookie Settings ................................................................. 52
Character Encoding.......................................................... 52
Scrolling Control ............................................................... 52
Show Image....................................................................... 52
AuthWallet ......................................................................... 52
Cingular Mall ......................................................... 53
Shop Tones ........................................................................ 53
Shop Games....................................................................... 53
Shop Graphics................................................................... 53
Shop Multimedia .............................................................. 53
Shop Applications............................................................ 53
MEdia Net Home............................................................... 53
Cingular Video ....................................................... 54
My Stuff ................................................................... 55
Games & Apps................................................................... 55
Audios................................................................................. 55
MP3 Player ........................................................................ 55
Graphics............................................................................. 56
Videos................................................................................. 56
Tools ................................................................................... 56
Alarm Clock........................................................................ 56
Calendar ............................................................................. 57
Notepad.............................................................................. 57
Calculator........................................................................... 58
5
Tip Calculator .................................................................... 58
World Clock ....................................................................... 58
Tasks................................................................................... 58
Stop Watch ........................................................................ 59
Unit Converter ................................................................... 59
Date Finder......................................................................... 59
D-Day Counter................................................................... 59
Camera and Recordings.................................................. 60
Take Photo ......................................................................... 60
Record Video ..................................................................... 61
Record Voice ..................................................................... 62
Other Files.......................................................................... 62
Bluetooth Files.................................................................. 62
Memory Card..................................................................... 62
Address Book......................................................... 63
Contact List........................................................................ 63
New Contact...................................................................... 63
Caller Groups .................................................................... 63
Speed Dial List.................................................................. 63
Copy All Contacts ............................................................. 63
Delete All Contacts .......................................................... 64
Service Dial Numbers ..................................................... 64
My Numbers ...................................................................... 64
Settings ................................................................... 65
Audio................................................................................... 65
Display................................................................................ 65
Bluetooth............................................................................ 66
Date & Time....................................................................... 67
Security .............................................................................. 68
Call ...................................................................................... 69
Network Profiles .............................................................. 71
Software Update............................................................... 71
Check Memory.................................................................. 71
Others ................................................................................. 72
Handset Information ........................................................ 73
Reset Settings ................................................................... 73
6
Q&A.......................................................................... 74
Accessories............................................................ 76
Safety Guidelines .................................................. 78
Glossary .................................................................. 91
Index ........................................................................ 93
7
For Your Safety
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your warranty
for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during extreme
weather conditions or in your car on a hot day. Exposure to
excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby in adequately shielded electronic equipment. You
should consult with manufacturers of any personal medical
devices such as pacemakers and hearing aides to determine if
they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will
cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 78 before using your phone.
Safety Information
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in this
user guide.
]Never use an unapproved battery since this could damage
the phone and/or battery and could cause the battery to
explode.
]Never place your phone in a microwave oven as it will
cause the battery to explode.
]Do not dispose of your battery by fire or with hazardous or
flammable materials.
]Make sure that no sharp-edged items come into contact
with the battery. There is a risk of this causing a fire.
]Store the battery in a place out of reach of children.
]Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.). This could cause asphyxiation or suffocation.
8
For Your Safety
]Unplug the power cord and charger during lightning storms
to avoid electric shock or fire.
]When riding in a car, do not leave your phone or set up the
hands-free kit near to the air bag. If wireless equipment is
improperly installed and the air bag is activated, you may be
seriously injured.
]Do not use a hand-held phone while driving.
]Do not use the phone in areas where its use is prohibited.
(For example: aircraft).
]Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as a
bathroom.
]Never store your phone in temperatures less than- 4°F or
greater than 122°F.
]Do not use harsh chemicals(such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. There is a
risk of this causing a fire.
]Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
]Do not use your phone in high explosive areas as the phone
may generate sparks.
]Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
a fire or electric shock.
]Do not place any heavy items on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
]Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously
damage your phone.
]Do not disassemble the phone.
]Do not place or answer calls while charging the phone as it
may short-circuit the phone and/or cause electric shock or
fire.
]Only use the batteries, antennas, and chargers provided by
LG. The warranty will not be applied to products provided by
other suppliers.
]Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
]Do not hold or let the antenna come in contact with your
body during a call.
]An emergency call can be made only within a service area.
For an emergency call, make sure that you are within a
service area and that the phone is turned on.
9
For Your Safety
Memory card information and care
]Always insert/ remove the memory card while the handset
power is off. If you remove it while the power is on, it may
be damaged.
]If a damage cannot be fixed, format the memory card.
]The memory card cannot be used for recording copyright-
protected data.
]Do not write forcefully on the memo area.
]Carry and store the memory card in its case.
]Do not allow the memory card to get wet.
]Do not leave the memory card in extremely hot location.
]Do not disassemble or modify the memory card.
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of he United
States, with its action in Report and Order FCC 96-326, adopted
an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with
the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact
with skin, a minor burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 0.6 inches (1.5cm) between the
user’s body and the back of the phone. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.6
inches(1.5cm) must be maintained between the user s body
and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components should not
be used. Body-worn accessories that cannot maintain 0.6
inches(1.5cm) separation distance between the user's body
and the back of the phone, and have not been tested for typical
body-worn operations may not comply with FCC RF exposure
limits and should be avoided.
10
For Your Safety
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20cm) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference that
may cause undesired operation.
Cautions for Battery
]Do not disassemble.
]Do not short-circuit.
]Do not expose to high temperature: 60°C (140°F).]
]Do not incinerate.
Battery Disposal
]Please dispose of your battery properly or bring to your
local wireless carrier for recycling.
]Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
]Using the wrong battery charger could damage your phone
and void your warranty.
]The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.
11
Your Phone
Phone Components
8. Display screen
12. Camera key
10. Right soft key
13. End /Power key
9. Message key
11. OK key
14. Clear key
1. Earpiece
4. Side keys
3. Left soft key
5. Send key
6. Alpha numeric keys
7. Microphone
2. Navigation key
Menu Options
Oct 25 [Mon] 12:00am
12
Your Phone
Your Phone’s Features
1. Earpiece
2. Navigation key: Use for quick access to phone
functions.
3,10. Left soft key/Right soft key: Each of these keys
perform the functions indicated by the text on the
display immediately above them.
4. Side keys: These keys are used to control the
volume of ringtone in standby mode and speaker
volume during a call.
5. Send key: You can dial a phone number and answer
incoming calls. Press this key in standby mode to
quickly access the most recent incoming, outgoing
and missed calls.
6. Alphanumeric keys: These keys are used to dial a
number in standby mode and to enter numbers or
characters in edit mode.
7. Microphone: Can be muted during a call for privacy.
8. Display screen: Displays phone status icons, menu
items, Web information, pictures and more in full
color.
9. Message key: Use to retrieve or send text
messages.
11. OK key: Long press will launch the WAP browser.
Allows you to select and confirm menu options.
12. Camera key: Press this key to use the camera
feature or to go directly to the camera mode.
13. End/Power key: Allows you to power the phone on
or off, end calls, or return to Standby Mode.
14. Clear key: Allows you to delete the characters
entered or return you to the previous screen.
13
Your Phone
Backlight
A backlight illuminates the display and the keypad.
When you press any key or open the flip, the backlight
turns on. It turns off if no key is pressed within a given
period of time, depending on the Backlight Timeout
menu option. To specify the length of time the
backlight is active, set the Backlight Timeout menu
option (Menu 9.2.3).
Display Information
Headset jack
Camera
Side key
Icon area
Soft key indications
Text and graphic area
Area Description
First line
Middle lines
Displays various icons. See page 14
Dispaly messages, instructions and any
information that you enter, such as number
to be dialed.
Last line Shows the functions currently assigned to
the two soft keys.
Menu Options
Oct 25 [Mon] 12:00am
Task menu key
14
Your Phone
On-Screen Icons
The table below describes various display indicators
or icons that appear on the phone’s display screen.
Icon Description
Indicates the strength of the 3G network signal.
Indicates that GPRS service is available.
Indicates the alarm has been set and is on.
Indicates Ring has been set for alert.
Indicates the Schedule function.
Indicates the receipt of a message.
Indicates the receipt of a voice mail.
Indicates a call is in progress.
Indicates the status of the battery charge.
Indicates Silent has been set for alert.
Indicates that Vibration has been set for alert.
Indicates the speakerphone has been activated.
Indicates the Bluetooth function has been activated.
Indicates the strength of the network signal.
Indicates activation of the Multitasking function.
15
Getting Started
Installing the SmartChip
When you subscribe to a cellular network, you are
provided with a plug-in SmartChip loaded with your
subscription details, such as your PIN, any optional
services available and many others.
nImportant!
The plug-in SmartChip and its contacts can be easily
damaged by scratches or bending, so be careful when
handling, inserting or removing the card. Keep all
SmartChips out of the reach of small children.
1. If necessary, switch off the phone by holding down
the [END] key until the power-off image
displays.
2. Remove the battery. To do so:
3. Slide the SmartChip into the SmartChip socket so
that it locks the card into place. Make sure that the
notched corner is bottom left and the gold contacts
of the card face into the phone.
nNote
When you need to remove the SmartChip, slide it, as shown,
and take it out of the socket.
16
Getting Started
4. To insert the battery, align the golden contacts of the
battery with the corresponding connectors on the
battery compartment. Press down on the opposite
end of the battery until it snaps into place.
5. Attach back cover by sliding up into position until it
clicks.
Charging the Battery
Use of unauthorized accessories could damage your
phone and void your warranty.
To use the travel charger provided with your phone:
1. With the battery in position on the phone, connect
the lead from the travel charger to the bottom of the
phone. Check that the arrow on the lead connector
is facing towards the front of the phone.
2. Connect the travel charger to a standard AC wall
outlet. Only use the travel charger that comes
included with the package.
nWarning
The travel charger must be unplugged before you remove
the battery, otherwise, the phone could the damaged.
17
Getting Started
3. When charging is finished, disconnect the travel
charger from the phone by pressing on the gray tabs
on both sides of the connector while pulling the
connector out.
nNotice
]If your phone is powered on while charging, you’ll see the
bars in the battery indicator icon cycle.
When the battery is fully charged, the bars in the battery
indicator icon will flash on and off.
If the battery fails to charge completely:
]After turning the phone on and off, please attempt to
recharge the battery.
]After detaching and reattaching the battery, please
attempt to recharge the battery.
Memory card slot
The CU500 supports the TransFlash memory card. The
memory card can be inserted on the side of the CU500
device. You can use this card to save data files such
as MP3 songs.
nNote
Always insert/remove the memory card with the handset
power off.
The gold connectors must be face down and inserted first
into the TransFlash memory card slot.
Use only memory cards that have been approved by the
manufacturer. Some memory cards might not be compliant
with the handset.
2
1
1
18
Getting Started
Turning Your Phone On and Off
1. Hold down the [END] key until the phone
switches on.
2. If the phone asks for a PIN, enter the PIN and press
the key.
The phone searches for your network and after finding
it goes to the idle screen as illustrated below. From the
idle screen, you can make or receive a call.
nNote
The display language is preset to Automatic at the factory.
To change the language, use the Language menu option
(Menu 9.2.5).
3. When you wish to switch the phone off, hold down the
[END] key until the power-off image displays.
Access Codes
You can use the access codes described in this
section to avoid unauthorized use of your phone. The
access codes can be changed by using the Change
Codes feature (Menu 9.5.3).
Security code (4 digits)
The security code protects the unauthorized use of
your phone. The default security code is set to ‘0000’
and the security code is required to delete all phone
entries and to activate the Restore Factory Settings
menu. The security code default setting can be
modified from the Security Settings menu.
Barring Password
The barring password function is required when you
use the Call Barring function.
The password is obtained from the service provider
when you subscribe to this function.
Menu Options
Oct 25 [Mon] 12:00am
19
General Functions
Making a Call
1. Make sure your phone is powered on.
2. Enter a phone number including the area code. To
edit a number on the display screen, simply press
the key to erase one digit at a time.
]
Press and hold the key to erase the entire
number.
3. Press the [SEND] key to call the number.
4. When finished, press the [END] key.
Making a Call by Send Key
1. Press the [SEND] key, and the most recent
incoming, outgoing and missed phone numbers will
be displayed.
2. Select the desired number by using the navigation
key.
3. Press the [SEND] key.
Making International Calls
1. Press and hold the key and the international
access character ‘+’ will appear.
2. Enter the country code, area code, and the phone
number.
3. Press the [SEND] key.
Ending a Call
When you have finished a call, press the [END]
key.
Making a Call From the Contacts
You can store names and phone numbers dialed
frequently in the SmartChip as well as in the phone
memory known as the Contacts.
You can dial a number by simply selecting a name in
the contacts and pressing the [SEND] key.
20
General Functions
Adjusting the Volume
During a call, if you want to adjust the earpiece
volume, use the side keys of the phone.
In idle mode, you can adjust the ring volume using the
side keys.
Answering a Call
When you receive a call, the phone rings and the
flashing phone icon appears on the screen. If the
caller can be identified, the caller’s phone number (or
name if stored in your Address Book) is displayed.
1. Open the flip and press the [SEND] key or the
left soft key to answer an incoming call. If Any Key
has been set as the answer mode (Menu 9.6.4), any
key press will answer a call except for the
[END] key or the right soft key.
nNotice
]
To reject an incoming call, press and hold the side keys
on the left side of the phone.
]
If Flip Open has been set as the Answer Mode (Menu
9.6.4), you do not need to press any key. You can answer
the call simply by opening the flip.
2. End the call by closing the phone or pressing the
[END] key.
nNotice
You can answer a call while using the Address Book or other
menu features.
Vibrate Mode (Quick)
Vibrate Mode can be activated by pressing and
holding down the [Star] key.
Signal Strength
If you are inside a building, being near a window may
give you better reception. You can see the strength of
your signal by the signal indicator on your phone’s
display screen.
Entering Text
You can enter alphanumeric characters by using the
phone’s keypad. For example, storing names in the
Address Book, writing a message, or creating scheduling
events in the calendar all require entering text.
The following text input methods are available in the
phone.
21
General Functions
T9 Mode
This mode allows you to enter words with only one
keystroke per letter. Each key on the keypad has more
than one letter. The T9 mode automatically compares
your keystrokes with an internal linguistic dictionary to
determine the correct word, thus requiring far fewer
keystrokes than the traditional ABC mode.
ABC Mode
This mode allows you to enter letters by pressing the
key labeled with the required letter once, twice, three
or four times until the letter is displayed.
123 Mode (Numbers Mode)
Type numbers using one keystroke per number.
To change to 123 mode in a text entry field, press
key until 123 mode is displayed.
A long press changes mode to 123.
Symbolic Mode
This mode allows you to enter special characters.
nNotice
You can select a different T9 language from the menu option.
The default setting on the phone is T9 disabled mode.
Changing the Text Input Mode
Change the text input mode by pressing . You can
check the current text input mode in the upper right
corner of the screen.
Using the T9 Mode
The T9 predictive text input mode allows you to enter
words easily with a minimum number of key presses. As
you press each key, the phone begins to display the
characters that it thinks you are typing based on a built-in
dictionary. As new letters are added, the word changes
to reflect the most likely candidate from the dictionary.
1. When you are in the T9 predictive text input mode,
start entering a word by pressing keys to
Press one key per letter.
]The word changes as letters are typed - ignore
what’s on the screen until the word is typed
completely.
]If the word is still incorrect after typing completely,
press the [Star] key once or more to cycle
through the other word options.
]If the desired word is missing from the word
choices list, add it by using the ABC mode.
22
General Functions
2. Enter the whole word before editing or deleting any
keystrokes.
3. Complete each word with a space by pressing the
key or the right navigation key.
To delete letters, press . Press and hold down
to erase the letters continuously.
nNotice
To exit the text input mode without saving your input, press the
[END] key.
Using the ABC Mode
Use the keypad keys to enter your text.
1. Press the key labeled with the required letter:
]
Once for the first letter
]
Twice for the second letter
]
And so on
2. To insert a space, press the key once. To
delete letters, press the key. Press and hold
down the key to erase the letters continuously.
nNotice
Refer to the table below for more information on the
characters available using the keys.
Key Characters in the Order Display
Upper Case Lower Case
1 . , ' @ ? ! - : / 1 . , ' @ ? ! - : / 1
2 A B C 2 a b c 2
3 D E F 3 d e f 3
4 G H I 4 g h i 4
5 J K L 5 j k l 5
6 M N O 6 m n o 6
7 P Q R S 7 p q r s 7
8 T U V 8 t u v 8
9 W X Y Z 9 w x y z 9
0 Space Key, 0 (Long press) Space Key, 0 (Long press)
23
General Functions
Using the 123 (Numbers) Mode
The 123 Mode enables you to enter numbers in a text
message (a telephone number, for example) more
quickly.
Press the keys corresponding to the required digits
before manually switching back to the appropriate text
entry mode.
Using the Symbol Mode
The Symbol Mode enables you to enter various
symbols or special characters.
To enter a symbol, press the [Star] key. Use the
navigation keys to select the desired symbol and press
the [OK] key.
T9 dictionary
The T9 dictionary is a feature that allows the user to
add any unique or personal words to the T9 standard
language database. The T9 dictionary function can be
selected from the Text Entry Settings sub menu under
the Options soft key menu. Within the T9 dictionary
function, the user can add, modify, delete or reset the
personal words.
24
Selecting Functions and Options
Your phone offers a set of functions that allow you to customize the phone. These functions are arranged in menus
and sub-menus, accessed via the two soft keys marked the left soft key and the right soft key. Each menu
and sub-menu allows you to view and alter the settings of a particular function.
The soft key functions vary depending on the mode of the phone. The label on the bottom of the display screen
immediately above the soft keys indicates current function.
Press the left soft key to
access the available
Menu.
Press the right soft key
to access the available
Options.
Long press will launch the WAP
browser. Short press allows you to
select and confirm menu options.
Menu Options
Oct 25 [Mon] 12:00am
25
Address Book
You can store phone numbers and their corresponding names in the memory of your SmartChip.
In addition, you can store up to 500 numbers and names in the phone memory.
The SmartChip and phone memory, although physically separate, are utilized like a single entity known as the
Contacts.
26
In-Call Menu
Your phone provides a number of control functions that
you can use during a call. To access these functions
during a call, press the right soft key [Options].
During a Call
The menu displayed on the handset screen during a
call is different than the default main menu displayed
when in idle screen, and the options are described
below.
Making a Second Call
You can select a number you wish to dial from the
Address Book to make a second call. Press the right
soft key then select Contacts.
Swapping Between Two Calls
To switch between two calls, press the right soft key
or the [SEND] key, and then select Swap.
Answering an Incoming Call
To answer an incoming call when the handset is
ringing, simply press the [SEND] key. The
handset is also able to warn you of an incoming call
while you are already on a call. A tone sounds in the
earpiece, and the display will show that a second call
is waiting. This feature, known as Call Waiting, is only
available if your network supports it.
If Call Waiting is on, you can put the first call on hold
and answer the second call, by pressing the
[SEND] key.
Rejecting an Incoming Call
You can reject an incoming call without answering by
simply pressing the [END] key.
During a call, you can reject an incoming call by
pressing the [END] key.
Muting the Microphone
You can mute the microphone during a call by pressing
the [Options] key then selecting Mute or the left soft
key [Mute]. The handset can be unmuted by pressing
the Unmute menu or the left soft key [Unmute]. When
the handset is muted, the caller cannot hear you, but
you can still hear the caller.
27
In-Call Menu
Conference Calls
The conference service provides you with the ability to
have a simultaneous conversation with more than one
caller. The conference call feature can be used only if
your network service provider supports this feature.
The conference call can only be set up when you have
one call active and one call on hold, meaning both
calls must have been answered. Once a conference
call is set up, calls may be added, disconnected or
separated (that is, removed from the conference call
but still connected to you) by the person who set up
the conference call. These options are all available
from the In-Call menu. The maximum number of callers
in a conference call is five. Once started, you are in
control of the conference call, and only you can add
calls to the conference call.
Making a Second Call
You can make a second call while currently on a call
simply by entering the second number and pressing
the [SEND] key. When the second call is
connected, the first call is automatically placed on
hold. You can swap between calls, by pressing the
[SEND] key.
Setting Up a Conference Call
To set up a conference call, place one call on hold,
conference in the second active call by pressing the
right soft key and select the Join Calls sub menu option
from the Conference Call menu.
Activate the Conference Call on Hold
To activate a conference call on hold, press the
[SEND] key.
Adding Calls to the Conference Call
To add a call to an existing conference call, press the
right soft key, and then select the Join Calls sub menu
from the Conference Call option.
Private Call in a Conference Call
To have a private call with one caller from a
conference call, press the right soft key and select the
Private Menu from the Conference Call option. When
the numbers of the callers are displayed, select the
one you wish to speak in private.
Ending a Conference Call
Currently active conference call can be disconnected
by pressing the [END] key.
28
Menu Tree
The following illustration shows the available menu structure and indicates the:
]Number assigned to each menu option.
]Page where you can find the feature description.
1. IM (see page 33)
2. Messaging (see page 37)
2.1 IM
2.2 New Message
2.2.1 Message
2.2.2 Email
2.3 Inbox
2.4 Email Inbox
2.5 Drafts
2.6 Outbox
2.7 Sent
2.8 Voice Mail
2.9 Chat
2.0 Templates
2.0.1 Text Templates
2.0.2 Multimedia Templates
2.0.3 Signature
2. Messaging (continued)
2.*Message Settings
2.*.1 Text Message
2.*.2 Multimedia Message
2.*.3 Email
2.*.4 Voicemail
2.*.5 Download Messages
3. Recent Calls (see page 47)
3.1 Missed Calls
3.2 Dialed Calls
3.3 Received Calls
3.4 All Calls
3.5 Call Timer
3.5.1 Last Call
3.5.2 Received Calls
3.5.3 Dialed Calls
3.5.4 All Calls
29
Menu Tree
3. Recent Calls (continued)
3.6 Data Count
3.6.1 Data Time
3.6.2 Data Volume
4. MEdia Net (see page 49)
4.1 MEdia Net Home
4.2 Bookmarks
4.3 Saved Pages
4.4 Go to URL
4.5 Security
4.6 Browser Settings
4.6.1 Accounts
4.6.2 Cache Settings
4.6.3 Cookie Settings
4.6.4 Character Encoding
4.6.5 Scrolling Control
4.6.6 Show Image
4.6.7 AuthWallet
5. Cingular Mall (see page 53)
5.1 Shop Tones
5.2 Shop Games
5.3 Shop Graphics
5.4 Shop Multimedia
5.5 Shop Applications
5.6 Shop Videos
5.7 MEdia Net Home
6. Cingular Video (see page 54)
7. My Stuff (see page 55)
7.1 Games & Apps
7.2 Audios
7.3 MP3 Player
7.4 Graphics
7.5 Videos
7.6 Tools
7.6.1 Alarm Clock
7.6.2 Calendar
7.6.3 Notepad
7.6.4 Calculator
7.6.5 Tip Calculator
7.6.6 World Clock
30
Menu Tree
7. My Stuff (continued)
7.6.7 Tasks
7.6.8 Stop Watch
7.6.9 Unit Converter
7.6.0 Date Finder
7.6.*D-Day Counter
7.7 Camera and Recordings
7.7.1 Take Photo
7.7.2 Record Video
7.7.3 Record Voice
7.8 Other Files
7.9 Memory Card
8. Address Book (see page 63)
8.1 Contact List
8.2 New Contact
8.3 Caller Groups
8.4 Speed Dial List
8.5 Copy All Contacts
8.6 Delete All Contacts
8.7 Service Dial Numbers
8.8 My Numbers
9. Settings (see page 65)
9.1 Audio
9.1.1 Shop Tones
9.1.2 Ringtones
9.1.3 Volume
9.1.4 Ring Alert Type
9.1.5 Key Tones
9.1.6 Message Alert Tones
9.1.7 Flip Tones
9.2 Display
9.2.1 Shop Graphics
9.2.2 Wallpapers
9.2.3 Backlight Timeout
9.2.4 Menu Styles
9.2.5 Language
9.2.6 Dialing Fonts
9.2.7 Clocks & Calendar
9.2.8 Color Schemes
9.3 Bluetooth
9.3.1 Device List
9.3.2 Bluetooth On/Off
9.3.3 Bluetooth Settings
31
Menu Tree
9. Settings (continued)
9.4 Date & Time
9.4.1 Set Date
9.4.2 Date Format
9.4.3 Set Time
9.4.4 Time Format
9.4.5 Auto Update
9.5 Security
9.5.1 Lock Phone
9.5.2 PIN Code Request
9.5.3 Change Codes
9.6 Call
9.6.1 Call Forwarding
9.6.2 Send My Number
9.6.3 Auto Redial
9.6.4 Answer Mode
9.6.5 Minute Minder
9.6.6 Fixed Dial Number
9.6.7 Call Waiting
9.6.8 Call Reject
9.6.9 Send DTMF Tones
9. Settings (continued)
9.7 Network
9.7.1 Flight Mode
9.7.2 Network Profiles
9.8 Software Update
9.9 Check Memory
9.9.1 Common
9.9.2 Reserved
9.9.3 SmartChip
9.9.4 Memory Card
9.0 Others
9.0.1 TTY
9.*Handset Information
9.# Reset Settings
9.#.1 Clear Memory
9.#.2 Reset Default
32
IM
The Instant Messaging feature can only be used with
the support of the network operator or communities
such as AIM, ICQ, and YAHOO! Messenger. For Instant
Messaging users, a valid User ID and Password will be
required in order to login and exchange messages as
well as checking the online status.
There are two ways to use the Instant Messaging
feature.
1. Through the Main Menu.
2. Through the IM hotkey (the right navigation key).
Short pressing the hotkey will bring up the available
IM clients. The menu items below might not appear
since not all IM communities support the various
options. Also the menu strings may appear
differently based on the selected IM communities.
The keywords such as User ID, Login and Contact
will be used as general terms in IM menus
according to the currently selected communities
such as AIM, ICQ and YAHOO! Messenger.
Offline Menu
Sign In
This allows users to login by filling in the User ID and
Password.
nNote
If your phone number is not registered on SmartChip, you
would not be able to log into the IM client
You can check your phone number in My numbers menu
(Menu 8.8)
nNote
Once the User ID and Password are saved, you will not be
required to type them in again during Login process. This
feature is optional.
Saved Conversations
This is where a user can view saved conversations.
Settings
]My Status: Allows you to set your status to
Available, Busy or Invisible.
]Status Text: You may set your current status in free
text format.
]Set Sound: Allows you to set an alert for the Contact
when they have activity on their session.
]Default Provider: Allows you to set the default IM
community to login.
33
IM
]Automatic Sign On: You may set the automatic IM
Login process by choosing between the 'When
Power On' or 'When IM Start' options.
]Network: You may set your IM Network Profiles or
Server Address information. Please check with your
network provider before making any changes.
IM Information
This indicates the Instant Messaging Client Information
such as Client Name and Version Number.
Online Menu / 1 to 1 conversation
After successful Login, a list of contacts with Screen
Names will appear on screen. Depending on the
cursor location in the contacts, following menu options
will be available.
When cursor is located on a Conversations List
nNote
Conversations List contains both the active contact where a
conversation has taken place as well as unknown contact.
nNote
When you select the left/right navigation key or the Confirm
key on the Conversation List, it offers the ability to view or
hide conversations.
]Send to Others: This offers the ability to send a
message to an unknown contact. When selected,
User ID must be typed in prior to starting an IM
session or conversation.
]Saved Conversations: You may view or delete the
stored conversation session.
]Search: This allows you to search for the contact by
Email address or name.
]Settings
zMy Status: Allows you to set your status to
Available, Busy or Invisible.
zStatus Text: You may set your current status in
free text format.
zSet Sound: Allows you to set an alert for the
Contact when they have activity on their session.
zAutomatic Sign On: You may Login to an IM client
automatically with the 'When Power On' or
'When IM Start' options.
34
IM
]Log Out: This begins the Logout process.
When cursor is located on a Conversation
]End Conversation: This closes the selected
conversation. If an unknown contact was selected,
that contact is deleted.
]Block/Unblock Contact: This allows you to
block/unblock the selected Conversations Contact.
]View Information: This allows you to view the User
ID and Status Text information.
]Search: This allows you to search for the contact by
Email address or name.
]Settings: Please refer to the previous Settings Menu.
]Log Out: This begins the Logout process.
When cursor is located on a Contact List
]Add Contact: This adds a new contact to the selected
contacts list; in the meantime this searches for the
contact on the basis of E-mail Address, First Name,
or Last Name.
]Refresh List: This refreshes the presence
information of the contacts within the contacts.
]Send to Others: This offers the ability to send a
message to an unknown contact. When selected,
the User ID must be typed in prior to starting an IM
session or conversation.
]Saved Conversations: This is where a user can view
saved conversations.
]Search: This allows you to search for the contact by
Email address or name.
]Settings: Please refer to the previous Settings
Menu.
]Log Out: This begins the Logout process.
When cursor is located on a Contact
]Add Contact: This adds a new contact to the
selected contacts list; in the meantime this
searches for the contact on the basis of E-mail
Address, First Name, or Last Name.
]Delete Contact: This deletes the selected Contact.
]Set/Clear Alert: When the user sets this contact as
“Set Alert”, if presence information of the selected
contact is changed to online from offline afterwards,
it alerts as the icon and sound. This option will be
shown if your network provider supports this service.
35
IM
]Block/Unblock Contact: This allows or blocks
conversation with the selected Contact.
]Refresh Contact: This refreshes the presence
information of the selected contact.
]View Information: This allows you to view
information. It provides User ID, Status Text.
]Search: This allows you to search for the contact by
Email address or name.
]Settings: Please refer to the previous Settings Menu.
]Log Out: This begins the Logout process.
Menu options available in the Conversation
screen
]Back To List: This brings the screen back to the
contacts.
]Insert: You can insert Symbol, Template and
emoticons in the conversation screen.
]Block/Unblock Contact: This allows or blocks
conversation with the selected Contact.
]Save Conversation: Stores currently active
conversation.
]End Conversation: This ends the active conversation
and clears the conversation buffer.
]Settings: Please refer to the previous Settings Menu.
]Text Entry Mode: Sets the text input mode such as
abc, Abc, ABC, T9 abc, T9 Abc, T9 ABC and 123.
]Text Entry Mode Settings: This selects the T9
predictive mode Language.
nNote
zIn the conversation window, you can use the up/down
navigation key for scrolling through the conversation.
zMaximum number of characters supported by a message is
400 characters for receiving and 128 characters for sending.
zThe presence information might not update in real time so
the “Refresh List”/“Refresh Contact” option can be used
for most up to date status.
36
Messaging
This menu includes functions related to SMS (Short
Message Service), MMS (Multimedia Message Service),
voice mail, as well as the network’s service messages.
IM Menu 2.1
Instant Messaging feature can only be used with the
support of the network operator or communities. For
Instant Messaging users, a valid User ID and
Password will be required in order to login and
exchange messages as well as checking the online
status. For further details, see page 33.
New Message Menu 2.2
nNote
If you select a graphic or an audio file while writing a
multimedia message, the file loading time will take about 5
seconds. You will not be able to activate any key during the
file loading time. When the file loading is complete, you will
be able to write a multimedia message.
Message (Menu 2.2.1)
This allows you to send a new text message up to 160
characters.
Editing a message
The following options are available for Editing a
Message. (Press the left soft key [Insert])
]Symbol: You can insert symbols ranging from
sentence notes to emoticons. Select the one you
want by navigating the left/soft keys [Previous/Next].
]Templates
- Text Templates: You can easily insert the
frequently used sentences in the text message.
- Multimedia Templates: The preset multimedia
templates are available.
- Signature: Input your own signature created in
(Menu 2.0.3). For further details, see page 44.
]Audio: You can insert various ringtones.
nNote
vCard, vCalendar, vNote and vTask are created by Address
Book, Calendar, NotePad and Tasks respectively. Go to the
Tools and Address Book sections for more detailed
information.
]New Audio: You can record a new audio by
pressing the center key [Record]. While recording a
new audio, you can cancel it by pressing the left key
[Cancel].
37
Messaging
To control the new audio menu, choose [Options] by
pressing the right key. Under [Options], choose one
of following
zRecord Mode: Set as Multimedia Message Audio
Mode or General Mode.
zQuality: Set the audio’s quality to Fine, Normal or
Economy.
zPrimary Storage: You can assign the primary
storage to Handset Memory or Memory Card.
]Graphic: You can select a graphic image by using
the left/right navigation keys. You can preview the
selected picture by pressing the center key [View].
If you press [Cancel] on the right key, it allows you
to go back to the previous screen.
]New Photo: You can insert a new image taken from
the camera by pressing [Capture]. The following
camera options are available when you press
[Options]:
zResolution: The resolution of the image can be
captured in 1280*960/640*480/320*240
zQuality: Quality of the captured image can be
Normal/Fine/Super Fine
zReverse View: You can view the photo upside
down
zView Full Screen: Extends the photo screen to full.
zFlash: Sets the flash to Off/Always On/When Take
zSelf Timer: Camera timer can be set to Off/
3 Seconds/5 Seconds/10 Seconds
zOthers: Set the White Balance as
Auto/Daylight/Incandescent/Cloudy/Fluorescent/
Night mode. Color Effect includes options such as
Color/ Sepia/ Mono/Negative. Shutter Tones can
be set to Tone 1/ Tone 2/ Tone 3/ Off.
zDefault Settings: Allows you to set to the default
settings.
]Video: You can insert a video clip by using the left
soft key [Insert].
]New Video: You can record new video by pressing
the center key [Record].
]Contact: You can browse one of your contacts and
insert it.
]Subject: Type in a subject into the message.
]Slide: You can insert a slide and place it to Insert
Slide Before or Insert Slide After.
]Others: Allows you to insert vCard, vCalendar, vNote
or vTask.
38
Messaging
Using Options
Press right soft key [Options].
zPreview: Shows the created multimedia message
before sending it.
zRemove: Removes the selected multimedia or vObject.
zSave to Drafts: Saves the selected slide to draft.
zSave as Template: Saves the selected slide as
template.
zSet Slide: Sets the Duration, Text color and
Background Color of the selected slide.
zSelect Slide: If the message has more than one
slide, you can select and move to the desired slide.
zSettings: Allows you to set message settings in your
created message.
zText Entry Mode: Sets the text input mode. For more
details, refer to the Entering Text (page 21).
zText Entry Settings: Text Entry Languages allows
you to set the text entry language to English,
Spanish or French. T9 Next Word Prediction is
available when it is set to On. Use T9 Dictionary to
add words or delete/reset/modify words.
zCancel: Select Yes/No whether you want to save the
selected message as draft.
Sending a Message
After completing a message using the Insert/Options,
select Send To to send a message.
zEnter the recipient(s) as To, Cc and Bcc. You can
use the Contacts option to choose a recipient.
zPress the right soft key [Options].
You can insert symbols, refer to recent messages or
recent calls to set as a recipient, and edit your
message. For the options Save to Drafts, Text Entry
Mode, Text Entry Settings and Cancel, see the
descriptions above.
Email (Menu 2.2.2)
To activate the Email function of this phone, you should
first set up an email account.
See the Email (Menu 2.*.3) of the Message Settings
menu. For more detailed information, contact your
service provider.
Editing an Email Message
1. Select Email from the New Message menu.
2. Input the title of the email to be sent in the Subject
field.
39
Messaging
zInsert: You can insert Text Templates, Signature,
Contacts and vNote.
zSave to Drafts: Saves the message as draft.
zPreview: You can see the message you wrote in
advance.
zSettings: You can set Priority and Request Read
Receipt of the message.
zAttachment: You can attach your desired
attachment to the email message.
zText Entry Mode: See the above description.
zText Entry Settings: See the above description.
zCancel: Cancels the message.
3. Write the message to be sent in the Message field.
4. Input the recipient’s address in the field.
zInsert Symbol: You can insert various symbols.
zRecent Emails: Recent Email addresses list is
displayed. You can select or cancel all the
massages by using the options.
zSet as To/Cc/Bcc: You can assign the selected
recipient as To/Cc/Bcc.
zEdit Message: Goes to previous screen where you
can edit the subject and message again.
zSave to Drafts: Saves the message as draft.
zText Entry Mode: See the above description.
zText Entry Settings: See the above description.
zCancel: Select Yes/No to cancel the edited
message.
Inbox Menu 2.3
You will be alerted when you receive a message. They
will be stored in the Inbox.
In the Inbox, you can identify each message by icons.
If you are notified that you have received a multimedia
message, you can download the whole multimedia
message by selecting it in the Receive menu.
For download settings, see (Menu 2.*.2) for details.
The following [Options] are available in the Inbox list.
]Save Contact Info: You can save the sender's phone
number in Contact List.
]Delete: You can delete the current message.
]Forward: You can forward the selected message to
another party.
]Information: You can view information about received
messages; Message type, Subject, Sender's address,
Message date & time, Priority, Message size,
Attached Files (only for Multimedia message).
40
Messaging
]Multi Delete: Deletes the several messages you
choose in the folder.
]Delete All Read Messages: You can delete all read
messages.
]Delete All: You can delete all messages.
Email Inbox Menu 2.4
Displays the received emails list. The emails are sorted
by each server that receives the messages and you
can see the number of the messages in this menu.
]Retrieve: You can retrieve messages from the
server. To retrieve a message, you need a user
name and a password for authentication.
zPOP3 (Post Office Protocol) Account Email
]Reply: You can reply the received email.
]Delete: You can delete the selected email from
the handset.
]Delete from Server: You can delete the selected
email from the server and handset permanently.
]Purge* (*only available in IMAP4 Account Email):
You can get rid of deleted email permanently
from the server and handset.
]Copy* (*only available in IMAP4 Account Email):
You can copy email from one folder to another.
]Reply to All: You can reply to every address on
the selected email.
]Forward: You can forward email to others.
]New Email: Creates new email.
]Information: Shows email information.
]Multi Delete: You can delete multiple emails at
one time.
]Delete All Read: Deletes all the emails already
read.
]Delete All: Deletes all the emails.
nNote
Options for IMAP4 account email are the same as POP3
other than the Purge and Copy options.
zIMAP4 (Internet Messaging Access Protocol version
4) Account Folder
]Delete: You can delete the selected IMAP4
account folder.
]Rename: You can rename the account folder.
]New Folder: You can create a new IMAP4
account folder.
41
Messaging
zTrash
]When the cursor is on the trash folder list: You
can empty the trash folder or restore all the deleted
messages by using the options or the right soft key.
]When you are in the trash folder, the options are
as follows:
zEmpty Trash: Makes your trash folder empty.
zRestore All: Restores email in Trash folder to
their account folders.
zMulti Selection: You can restore multiple emails
at one time to their account folders. Through
this option, we can select all or cancel all
selection.
Drafts Menu 2.5
You can view the messages saved as a draft. The draft
messages are listed with the date and time of when
the messages were saved.
The following [Options] are available.
]Delete: Deletes the message you choose.
]Information: Allows you to view the information of
the message.
]Multi Delete: Allows you to delete multiple
messages you choose in the folder.
]Delete All: Deletes all messages in the folder.
Outbox Menu 2.6
Outbox is a temporary storage place for messages
waiting to be sent.
When you press the [SEND] key, the message
moves to the Outbox and from there the message is
sent.
If the message fails to be
sent from the Outbox, you
will receive a sound alert
along with a Message
Sending Fail notice on the
screen. Another attempt
will be made to send the
failed message and after
two unsuccessful attempts,
the message will no longer
be sent automatically
(except Email). In order to send the message that has
failed, you must press Resend from the Options menu.
42
Messaging
After the maximum number of Send attempts has been
reached the Send function has failed.
If you were trying to send a text message, open the
message and check that the Sending options are correct.
When the message Send has failed, the following
[Options] are available.
]Resend: Allows you to send the message again after
a time-out period.
]Delete: Deletes the selected message which has
been failed to send.
]Information: Allows you to view the information of
the message.
]Delete All: Deletes all messages in the folder.
Sent Menu 2.7
This is where you can view the lists and contents of
sent messages and also verify if transmission was
successful.
The following [Options] are available.
]Delete: Deletes the selected message from the Sent
list.
]Information: Allows you to view the information of
the message.
]Delete All: Deletes all messages in the folder.
Voice Mail Menu 2.8
This menu provides you with a quick way of accessing
your voice mailbox (if provided by your network).
Before using this feature, you must enter the voice
server number obtained from your service provider.
This may already be available; to check the voicemail,
press and hold the key
When new voicemail is received, the symbol will
be displayed on the screen.
nNote
Please check with your network service provider for details
of their service in order to configure the handset
accordingly.
43
Messaging
Chat Menu 2.9
This menu option connects to Cingular’s chat site.
Templates Menu 2.0
Text Templates (Menu 2.0.1)
There are 6 predefined messages in the list. You can
view and edit the template messages or create new
messages.
The following [Options] are available.
]Send: Allows you to send the selected template via
Message or Email.
]Delete: Allows you to delete the selected template
message.
]Edit: Allows you to write a new message or edit the
selected template message.
]Delete All: Deletes all messages in the folder.
Multimedia Templates (Menu 2.0.2)
1. You can add new multimedia templates by pressing
the left soft key [New].
2. The following choices are available under Options.
]Preview: You can preview multimedia messages
you have created.
]Remove: You can remove the attached item such as
audio and graphic files in this template.
]Text Entry Mode: Sets the text input mode as abc,
Abc, ABC, T9 abc, T9 Abc, T9 ABC and 123.
]Text Entry Settings: Allows you to set the text entry
language to English, Spanish or French.
]Cancel: If you cancel the current template, the pop-
up window will be displayed to indicate whether or
not the template has been saved.
Signature (Menu 2.0.3)
This feature allows you to create your Textual
signature. You can use symbols, templates and
contacts as part of the signature.
Message Settings Menu 2.*
Text Message (Menu 2.*.1)
]Message Center Number: If you want to send the
text message, you can receive the address of the
SMS center through this menu.
44
Messaging
]Email Gateway: You can send the text message to
an Email Address via this gateway.
]Message Subject: You can enter the SMS Subject
from this menu.
]Insert Signature: You can insert your own signature
(Menu 2.0.3) you made.
Multimedia Message (Menu 2.*.2)
]Priority: You can set the priority of the message you
choose.
]Message Subject: You can enter MMS Subject
when this menu is on.
]Validity Period: This network service allows you to
set how long your multimedia messages will be
stored at the message center.
]Request Delivery Receipt: Allows you to request a
delivery confirmation mail for a Multimedia message.
]Send Delivery Receipt: Allows you to send a
delivery confirmation mail for a Multimedia
Message.
]Request Read Receipt: Allows you to request a
message read confirmation mail for a Multimedia
Message
]Send Read Receipt: Allows you to send a message
read confirmation mail for a Multimedia Message.
]Automatic Download:
- On: You can always receive multimedia messages
automatically.
- Off: You receive only notification messages in the
inbox and then you can check the notifications.
]Message Center: The details for the Multimedia
gateway are pre-loaded onto your handset and
should not be changed.
]Message Size: This menu allows you to determine
the maximum size of a Multimedia message when
writing the message.
Email (Menu 2.*.3)
]Email Account: This menu allows you to edit, delete
and add an Email account.
To set up an Email account, do the following;
1. Press the left soft key [Edit].
2. Enter User name, Password, Email Address, Reply
Email Address, etc.
3. You can save your account by pressing the left soft
key [Save].
45
Messaging
]Insert Signature: You can insert your own signature
you made in (Menu 2.0.3).
]Send Read Receipt: Allows you to send a message
read confirmation mail for an Email request.
]Auto Retrieve: This menu allows you to determine
whether to automatically download an Email when
new Email is available in the server.
Voicemail (Menu 2.*.4)
This menu allows you to get the voice mail if this
feature is supported by the network service provider.
Please check with your network service provider for
details of their service in order to configure the
handset accordingly.
Download Messages (Menu 2.*.5)
You can set the Service option to determine whether
you will receive the service messages or not.
You can set the Automatic Download option to
determine whether you will automatically connect to
the service or not.
]Service
- On: You can always receive service messages.
- Off: You will not receive any service messages.
]Automatic Download
- On: You can connect to the service automatically.
- Off: You can select the option whether you will
connect to the service or not.
46
Recent Calls
You can check the record of missed, received, and
dialed calls only if the network supports the Calling
Line Identification (CLI) within the service area.
The number and name (if available) are displayed
together with the date and time of the call. You can
also view call times.
Missed Calls Menu 3.1
• View the number, if available, and call it or save it in
the Address Book
• Enter a new name for the number and save both in
the Address Book
• Send a message by this number
• Delete the call from the list
Dialed Calls Menu 3.2
• View the number, if available, and call it or save it in
the Address Book
• Enter new name for the number and save both in the
Address Book
• Send a message by this number
• Delete the call from the list
Received Calls Menu 3.3
• View the number, if available, and call it or save it in
the Address Book
• Enter a new name for the number and save both in
the Address Book
• Send a message by this number
• Delete the call from the list
All Calls Menu 3.4
Allows you to view all of the missed, received, and
dialed call records.
Call Timer Menu 3.5
This allows you to view the duration of the incoming
and outgoing calls. You can also reset the call times.
The following timers are available:
Last Call (Menu 3.5.1)
Length of the last call.
Received Calls (Menu 3.5.2)
Length of the incoming calls.
47
Recent Calls
Dialed Calls (Menu 3.5.3)
Length of the outgoing calls.
All Calls (Menu 3.5.4)
Total length of all calls made and incoming calls
received since the timer was last reset.
Data Count Menu 3.6
You can check the amount of data transferred over the
network through the GPRS (General Packet Radio
Service) information option. In addition, you can also
view how much time you are online.
Data Time (Menu 3.6.1)
You can check the duration of Last Calls and All Calls.
You can also reset the call timers.
Data Volume (Menu 3.6.2)
You can check the Sent, Recevied or All data volumes
and Reset all.
48
MEdia Net
You can access various WAP (Wireless Application
Protocol) / Web services such as news, and weather.
These services are specially designed for mobile
phones and they are maintained by the service
providers.
nNote
Check the availability of WAP services, pricing and tariffs
with your network operator and/or the service provider
whose service you wish to use. Service providers will also
give you instructions on how to use their services.
Please contact your service provider to open an Internet
account.
To launch the browser in standby mode, press and
hold down the key.
Once connected, the homepage is displayed. The
content depends on the service provider.
To exit the browser at any time, press the [END]
key. The idle screen is displayed.
Menus for the Browser
You can surf the Internet using either the phone keys
or the WAP Browser menu.
Using the Navigation Keys
When surfing the Internet, the keys function differently
than when in the phone mode.
Using the WAP Browser Menu
There are various menus available when surfing the
Internet.
MEdia Net Home Menu 4.1
Connect to Cingular’s homepage. The homepage is
defined in the activated account and cannot be changed.
Bookmarks Menu 4.2
This function allows you to store and edit frequently
accessed sites. The following [Options] are available.
nNote
Your phone may have some pre-installed bookmarks for sites
not affiliated with LG. LG does not warrant or endorse these
sites. If you choose to access them, you should take the same
precautions for security or content as you would with any site.
Key Description
Scroll each line of the content areaup/down navigation key
49
MEdia Net
]View: Display the bookmark title and URL
]Connect: Connect to the selected bookmark site
]New: Add a new bookmark manually
]Delete: Allow you to erase the selected bookmark
]Send URL: Allows the bookmark information to be
sent via SMS to another person
]Edit: Modify the existing bookmark item
]Delete All: Allows you to erase all bookmarks
nNote
Pre-installed bookmarks cannot be deleted or edited by
users. In order to change the text input mode for symbol
input, please refer to the General Functions section.
Saved Pages Menu 4.3
This saves the page on display as an off-line file.
A maximum of 20 pages can be saved.
Go to URL Menu 4.4
You can directly connect to the site you want by
entering a specific URL.
]Enter URL: Input URL Address and allow to connect
to the Internet by pressing the key.
]Recent Pages: You can manage the list of the
Internet pages you visited.
Security Menu 4.5
A list of the available certificates is shown.
]Certificates: You can see the list of certificates and
view them in detail.
]Clear Session: Removes the secure session.
Browser Settings Menu 4.6
Accounts (Menu 4.6.1)
This feature is the network information used to
connect to the browser.
There are predefined accounts and one of them is set
as default.
Select the desired account by pressing the left soft
50
MEdia Net
key. This will activate the account to initiate browser
launch.
]Activate: Select the network information among the
items, so it can be used during your next connection.
]View: Allows you to see the specific network
information.
]Edit: Allows you to change the network information.
]Delete: Allows you to delete network information.
]New: Allows you to create a maximum of 20 new
network accounts.
nNote
You cannot edit and delete pre-installed accounts.
In order to create new account, please fill in the
network information.
1. Account Name: Name associated with new account.
2. Homepage: Homepage URL
3. Connection Mode: Select among
UDP(CO),UDP(CL),TCP with Proxy, TCP without Proxy
4. Proxy Address: Proxy server address
5. Proxy Port Number: Proxy server’s port number
6. Security: Select the secure or non-secure mode.
7. Time Out: Values between 10 to 600 seconds
8. Network Profiles: You can choose the one among
the network profiles. Note you can create a new
network profile by selecting list option at center key
nNote
1. The account information will be available from your
operator.
2. Creating or editing an account requires care. The browser
cannot connect to the Internet if the account information
is wrong.
Cache Settings (Menu 4.6.2)
The web pages you have accessed are stored in the
memory of the phone.
]Clear Cache: Remove all cached data in the
memory.
]Allow Cache: Set a value whether a connection
attempt is made through cache or not.
nNote
A cache is a buffer memory, which is used to store data
temporarily.
51
MEdia Net
Cookie Settings (Menu 4.6.3)
The information or services you have accessed are
stored in the cookie.
]Delete Cookies: Remove all cookies.
]Allow Cookies: Set a value whether a connection
attempt is made through the cookie or not.
Character Encoding (Menu 4.6.4)
Select the character set from one of the following list:
1 Automatic 2 English(ASCII)
3 English(ISO) 4 English(LATIN)
5 Unicode(UCS2 BE) 6 Unicode(UCS2 LE)
7 Unicode(UCS2 Auto) 8 Unicode(UTF-16 BE)
9 Unicode(UTF-16 LE) 0 Unicode(UTF-16 Auto)
* Unicode(UTF-8)
Scrolling Control (Menu 4.6.5)
This allows you to determine the scroll speed and
select from 1 Line, 2 Lines or 3 Lines.
Show Image (Menu 4.6.6)
This allows you to view pictures when browsing.
AuthWallet (Menu 4.6.7)
If set to On, the user’s personal information such as ID
and Password used to access the Internet site will be
saved automatically for future use.
Online menu
Once you are connected to the Internet, the following
menu options are available:
]Back: Moves to the previous page.
]Forward: Moves to the next page.
]Reload: Loads the current page again.
]Home: Moves to the initial homepage.
]Go to URL: Connects to the specific URL after editing.
]Bookmarks: You can add or save the current page to
the Bookmark or view the list saved under Bookmark.
]Settings: You can set the Browser related options
such as Clear cache, Clear cookies, etc.
52
Cingular Mall
Shop Tones Menu 5.1
This menu option connects to Cingular’s ringtone
download site.
nNote
Additional charges may incur when downloading ringtones.
Contact your service provider for further information.
Shop Games Menu 5.2
This menu option connects to Cingular’s game
download site. This allows users to download the
various games by connecting to the Internet.
nNote
Additional charges may incur when downloading games.
Contact your service provider for further information.
Shop Graphics Menu 5.3
This menu option connects to Cingular’s graphic
download site.
nNote
Additional charges may incur when downloading graphics.
Contact your service provider for further information.
Shop Multimedia Menu 5.4
This allows you to connect to
http://mmsstore.cingular.com URL and download
multimedia contents.
Shop Applications Menu 5.5
This menu option connects to Cingular’s application
download site. This allows users to download the
various applications by connecting to the Internet.
Shop Videos Menu 5.6
This menu option connects to Cingular’s video
download site. This allows users to download the
various applications by connecting to the Internet.
MEdia Net Home Menu 5.7
This connects to the homepage. The homepage may
be the site which is defined in the activated profile. It
will be defined by the Service Provider if you have not
defined it in the activated profile.
53
Cingular Video
Cingular Video brings you quick, on-demand access to
crystal clear news, sports, weather and entertainment
video clips. You can even personalize your homepage
for quick access to your favorites. Look for the 3G
network icon beside the signal bars on your phone to
determine if you are in the Cingular Video coverage
area.
To access Cingular Video:
1. From standby mode, press the Left Soft Key to
access the Menu.
2. Scroll to and select Cingular Video (option 6).
3. Select a category and play a clip.
54
My Stuff
Games & Apps Menu 7.1
Java is a technology developed by Sun Microsystems.
Similar to the way you would download the Java
Applet using the standard Netscape or MS Internet
Explorer browsers, Java MIDIet can be downloaded
using a WAP enabled phone. Depending on the service
provider, Java based programs such as Java games
can be downloaded and run on a phone. Once
downloaded, the Java program can be viewed within
the Games & Apps menu where you can select,
execute or delete. The Java program files saved in the
phone are in .JAD and .JAR formats.
nNote
The JAR file is a compressed format of the Java program
and the JAD file is a description file that includes all detailed
information. From the network, prior to download, you can
view all detailed file descriptions from the JAD file.
nWarning
Only J2ME (Java 2 Micro Edition) based programs will run in
a phone environment.
The J2SE (Java 2 Standard Edition) based programs will only
run in a PC environment.
Audios Menu 7.2
]Shop Tones: This menu option connects to
Cingular’s ringtone download site.
]Record Audio: You can record your own audio by
pressing the center key [Start].
]Files: You can view the audio files in the list.
MP3 Player Menu 7.3
]My Playlist: You can create your own play list with
the selected songs that you want from the list of All
Songs menu.
]All Songs: You can view the entire play list in the
external memory.
]Shuffle Songs: Plays the audio files in random order.
]Settings
zSet Shuffle: Random plays all the tracks.
zSet Repeat: This menu allows you to set the play
mode such as Repeat One, All and Off.
zVisualization: You can select the desired
equalizer picture on the main screen.
55
My Stuff
nNote
The copyright of music files can be protected under the
international treaties and national copyright laws. Therefore,
it may be necessary to obtain a permission or a license to
reproduce or copy music. In some countries national law
prohibits private copying of copyrighted material. Before
downloading or copying the file, please check the national
legislation of the applicable country concerning the use of
such material.
Graphics Menu 7.4
]Shop Graphics: This menu option connects to
Cingular’s graphic download site.
nNote
Additional charges may incur when downloading graphics.
Contact your service provider for further information.
]Take Photo: You can take your own photo by
pressing the center key [Start].
]Files: You can view the graphic files in the list.
Videos Menu 7.5
]Shop Videos: This menu option connects to
Cingular’s video download site.
]Record Video: You can record your own video by
pressing the center key [Start].
]Files: You can view the video files in the list.
nNote
DRM (Digital Rights Management) Contents Copyright
protected contents.
DRM sometimes restricts some functions, such as send, and
edit. The indicates content controlled by DRM
protections.
Tools Menu 7.6
Alarm Clock (Menu 7.6.1)
The alarm function allows you to set up multiple
separate alarms. You can also set the time, repetition
interval and alarm sound.
Select your desired alarm setting to configure in the
alarm list. If there is no alarm setting, press the left soft
key [New] to add a new alarm.
]Time: Select the desired set time mode using the
navigation key. Input your desired alarm time by
specifying the hour and minute. If the time is in 12
hours-based format, you have to select either ‘am’
or ‘pm’ using the center soft key.
56
My Stuff
]Repeat: Select desired repeat mode using the
navigation key.
]Alarm Tone: Select the alarm sound to use for the
alarm using the key.
]Memo: Input alarm name.
Calendar (Menu 7.6.2)
When you enter this menu a calendar will be displayed.
The square cursor is used to locate a particular day.
The under bar on the calendar indicates schedule(s)
on for that day. This function helps to remind you of the
schedule. The phone will sound an alarm tone if it has
been set for a specific schedule item.
The following [Options] are available:
]Search: Allows you to search a saved schedule by
pressing the character keys.
]Set Holiday: Allows you to set your personal
holidays for the selected date.
]View All: Allows you to view all saved schedules.
]Weekly View: Allows you to view the calendar by
weeks.
]Go to Date: Allows you to jump to a specific date.
]Delete Schedules: Deletes the defined schedules
such as Old Schedules, Daily, Weekly, Monthly or
All Schedules.
Notepad (Menu 7.6.3)
You can create up to maximum of 30 memos.
1. Select a memo pad you would edit.
2. Press the left soft key [New] to create a new memo.
3. Input the memo and press the center key [Save] to
save.
Key Description
up/down navigation key Weekly
left/right navigation key Daily
key/ key Yearly
key/ key Monthly
57
My Stuff
Calculator (Menu 7.6.4)
The calculator function allows you to add, subtract,
multiply and divide. You can input numbers using the
number keys, and input operators using the up, down,
left, and right navigation keys.
You can input a decimal point by pressing the
[Star] key.
Whenever you press the key, characters are
sequentially deleted in reverse direction.
Tip Calculator (Menu 7.6.5)
This feature allows you to quickly and easily calculate
the tip amount based on the total bill as well as the
split of the total bill based on the number of people.
World Clock (Menu 7.6.6)
The World clock function provides time information on
major cities worldwide.
1. You can view the time of desired city using the
navigation or the right soft key [Cities].
2. You can select a desired city as a base using the left
soft key [Homezone].
Tasks (Menu 7.6.7)
This feature allows you to save and manage a task.
1. To add a new To do item, select the left soft key
[New] in the Task enquiry screen.
2. Input Due date, notes, priority and Status for the new
Task.
3. Press the left soft key [Save] to save the Task item.
The following [Options] are available in the Task list.
]Status: Allows you to change the status of the
selected task as In Progress or Completed.
]Delete: Deletes the selected task.
]Send Via: Enables the selected task to be sent via
Message, Email and Bluetooth.
]Edit: Allows you to edit a saved task.
]View Calendar: The calendar pop-up window is
displayed.
]Delete Tasks: Deletes All Completed, All Past Tasks
or All Tasks.
58
My Stuff
Stop Watch (Menu 7.6.8)
This menu allows you to record the elapsed time of an
event. The duration of an individual lap time (up to 20
times) and the total time can be displayed.
]Show Last: You can see the last recorded time.
]New Time
1. To start timing, press the center key [Start]. The
running time is displayed as HH.MM.SS.hh (hours,
minutes, seconds, hundredths of a second).
2. During the timing, you can record an individual lap
time by pressing the right soft key [Lap]. Up to 20
lap times can be recorded.
3. You can stop or restart timing by pressing the
key.
4. To reset the stop watch, press the left soft key
[Reset].
]Saved Times: You can see the saved record time
which in the lap time list of the New Time option.
Unit Converter (Menu 7.6.9)
This function converts any measurement into a unit
you want.
There are 6 types of units that can be converted: Area,
Length, Weight, Temperature, Volume, and Velocity.
nNote
You can input a decimal number by pressing the [Star]
key.
Date Finder (Menu 7.6.0)
The date finder shows the start date, the target date
and the number of remaining days.
D-Day Counter (Menu 7.6.*)
1. To add a new D-Day Counter item, select the left soft
key [New].
2. Input the Date and notes when you add an item.
3. Press the left soft key [Save] to save the item.
]Edit: You can edit the selected item.
]Delete: You can delete the selected item.
]Show at Idle Screen: You can see the Remaining
days for this item (D-Day) on Idle screen top right
corner.
]Delete All: Deletes all saved items.
59
My Stuff
Camera and Recordings Menu 7.7
Take Photo (Menu 7.7.1)
Using the camera module built in your phone, you can
take pictures of people or events while on the move.
Additionally, you can send photos to other people in a
picture message.
The right soft key [Options] will bring up the following
options.
]Record Video: Go to the video application, enables
you to record a video clip.
]Resolution: Sets the image size to 1280*960
(default), 640*480 or 320*240. The selected image
size displays on the capture screen.
]Quality: You can select the desired quality of photo
by selecting either in Normal, Fine or Super Fine
mode by using the navigation keys.
]Reverse View: Allows you to reverse the image by
using the Side Keys.
]View Full Screen: Allows you to view the subject in
full size of the screen. You can select the View Full
Screen or View Full Image.
]Flash: Turns the flash feature on and off.
]Multishot: This feature enables the amount of
continuous frames that can be taken at one time.
The number of frames is determined by the image
size setting.
]Self Timer: Determines the camera timer.
]Others
- White Balance: This adjusts the Light Effect level
and you can select from the following options:
Auto /Daylight / Incandescent / Cloudy /
Fluorescent/Night Mode
- Color Effect: Allows you to apply special effects to
the picture. Press the left or right navigation key to
find the tone you want to use from the following
options: Color, Sepia, Mono and Negative.
- Shutter Tones: Allows you to select a sound when
you press the shutter. Tone 1 / Tone 2 / Tone 3 /Off
]Default Settings: This restores the default camera
settings (Size, Brightness, Zoom, etc.).
nNote
In Take Photo mode, you can adjust the zoom scale by using
the up/down navigation keys. The maximum zoom scale
depends on the resolution as follows.
60
My Stuff
In Take Photo mode, you can adjust the brightness by using
the left/right navigation key.
Record Video (Menu 7.7.2)
You can record a video clip in this menu by pressing
the Camera key. Before starting to record, press the
right soft key [Options] to set the following values.
Select the desired value and press the key to
confirm.
]Take Camera: Go to the camera application which
enables you to take a still picture.
]Video Record Mode: Sets the recording mode to
one of MMS Video Mode or General Mode.
]Resolution: Sets the image size to either 320*240 or
176*144. The selected image size displays on the
capture screen.
]Quality: Determines the quality of a video clip.
]Reverse View: Allows you to reverse the image.
]Flash: Allows you to set the flash to Off/Always On/
When Record.
]White Balance: This adjusts the light effect level
and you can select from the following options:
Auto / Daylight / Incandescent / Cloudy /
Fluorescent/ Night mode.
]Color Effects: Allows you to apply special effects to
the video clip. Press the Left/Right Navigation Keys
to find the tone you want to want to use from the
following options: Color, Sepia, Mono and Negative.
]Default Settings: This restores the default camera
settings (Size, Brightness, Zoom, etc.).
nNote
In Record Video mode, you can adjust the zoom scale by
using the up/down navigation keys. The maximum zoom
scale depends on the resolution as follows.
In Record Video mode, you can adjust the brightness by
using the left/right navigation keys.
Resolution Zoom scale
1280*960 x1
640*480 x1~x10
320*240 x1~x10
Resolution Zoom scale
176*144 x1~x10
61
My Stuff
Record Voice (Menu 7.7.3)
You can record an audio clip in this menu. The
recorded audio file is saved automatically in Audios
menu (Menu 7.2).
The right soft key [Options] will bring up the following
options.
]Record Mode: Sets the recording mode to one of
MMS Audio and General.
]Quality: Determines the quality of a audio clip.
]Primary Storage: You can set the primary storage of
the recorded audio in the Handset Memory or the
memory Card.
Other Files Menu 7.8
When you receive files of an undefined format (such
as .vcs, .vcf, etc.) via E-mail, the files are saved in this
folder.
The following [Options] are available.
]New Folder: You can create a new folder.
]Sort By: You can sort the folders by name, date and
type.
]Delete All: You can delete all the folders.
]Multi Delete: You can delete several folders you
selected at once.
]Information: You can view the information about the
selected folder.
Memory Card Menu 7.9
This function shows the status of the external card
memory.
62
Address Book
Contact List Menu 8.1
This menu allows you to save and manage contact
address information. The Contacts functions allow you
to add a new address or search saved contact
addresses by name.
New Contact Menu 8.2
This menu allows you to add a new contact address.
You can input contact address information including
name, phone numbers, email addresses, group
information items, memos, ringtones, and image
(photograph).
You have to select the Handset or the SmartChip
memory using the left and right navigation keys.
Caller Groups Menu 8.3
This menu allows you to manage group the information.
By default, there are 4 groups: family, friends,
colleagues and school. You can also configure a
ringtone for a group so that the group ringtone sounds
when a call from a specific contact address within that
group arrives and there is no ringtone configured for
the specific contact address.
Speed Dial List Menu 8.4
This menu allows you to configure the speed dial
numbers. You can select a number as a speed dial
from 2 to 9. You can configure speed dial numbers for
any of the 8 numbers for a specific contact address so
that a contact address may have multiple speed dial
numbers.
Copy All Contacts Menu 8.5
This menu allows you to copy all of the information
from your SmartChip, e.g. name, handset number, etc.,
to your handset. If a name is duplicated during the
copying operation, the information is also duplicated.
]SmartChip to Handset: You can copy the entry from
the SmartChip card to the phone memory.
]Handset to SmartChip: You can copy the entry from
the handset memory to the SmartChip card (not all
the data will be copied).
63
Address Book
Delete All Contacts Menu 8.6
You can delete all entries in the SmartChip and the
Handset.
Press the [END] key to return to standby mode.
Service Dial Numbers Menu 8.7
You can view the list of Service Dialing Numbers (SDN)
assigned by your network provider. Such numbers
could include the emergency, directory assistance and
voice mail numbers.
1. Select the Service dial number option.
2. The names of the available services will be shown.
3. Use the up/down navigation keys to select a service.
Press the [SEND] key.
My Numbers Menu 8.8
This displays your phone numbers stored in the
SmartChip.
64
Settings
Audio Menu 9.1
There can be 4 sound modes: General, Vibrate All,
Silent and Ear Mic. General, Vibrate, and All Silent
modes can be changed from the Volume menu under
Ringtone. In addition, pressing and holding the
[Star] key on idle screen mode can swap Normal and
Manner mode. Ear Mic is available when respective
instruments are attached.
Shop Tones (Menu 9.1.1)
Connects to Cingular Ringtone Shops.
Ringtones (Menu 9.1.2)
Shows and plays ringtones. These can be downloaded
ringtones from Ringtone shops.
Volume (Menu 9.1.3)
This menu controls Ringtone, Key Tone, Call, Slider
Tone and Multimedia volume. It is available on
Ringtone volume level 1~7.
Ring Alert Type (Menu 9.1.4)
Supports 3 ring alert types. Ring, Ring and Vibration,
and Ring after Vibration.
Key Tones (Menu 9.1.5)
This menu option allows you to select a tone that the
phone sounds when a key is pressed. You can set the
key tone to on or off.
Message Alert Tones (Menu 9.1.6)
Allows you to select an alert tone which is played
when a message is received. You can select any one
from 10 message alert tones.
Flip Tones (Menu 9.1.7)
Allows you to select the flip tone which will play when
the flip is opened or closed. You can select any one
from 5 flip tones. You can also set the flip tone to Off.
Display Menu 9.2
Shop Graphics (Menu 9.2.1)
Connects to Cingular’s graphic download site.
Wallpapers (Menu 9.2.2)
You can select the background picture in standby
mode.
65
Settings
Backlight Timeout (Menu 9.2.3)
Use this to select whether or not the phone uses the
backlight.
Menu Styles (Menu 9.2.4)
You can configure the menu style to Icon style or List
style.
Language (Menu 9.2.5)
You can change the language for the the display text in
your phone. This change will also affect the Language
Input mode.
Dialing Fonts (Menu 9.2.6)
You can configure the font size and color of the
numbers which appear in the home screen when you
make a call.
Clocks & Calendar (Menu 9.2.7)
This feature allows you to select the external LCD
clock or Calendar display in standby screen.
Color Schemes (Menu 9.2.8)
You can change the color of the menu, soft key area,
title bar area, and cursor by changing the Color
Schemes.
You can select the Color Schemes from Orange, Metal,
and Sky.
Bluetooth Menu 9.3
Your phone has built-in Bluetooth wireless technology,
which makes it possible for you to connect your phone
wirelessly to other Bluetooth devices such as a
handsfree, PC, PDA, a remote screen, or other phones.
You can have a conversation via a cordless Bluetooth
handsfree or browse the Internet, wirelessly
connected via a mobile phone.
You can also exchange, for example, business cards,
calendar items and pictures.
nNote
We recommend that your phone and the Bluetooth device
you are communicating with be within a range of 10 meters.
The connection may be improved if there are no solid
objects in between your phone and the other Bluetooth
device.
66
Settings
Device List (Menu 9.3.1)
This function allows you to view the list of all devices
that are paired with your phone at once.
To add a new device, press the right soft key [New]
1. Select the [New] key to search the device that can
be connected and within range.
2. If you want to stop searching, press the right soft
key [Cancel].
3. All of the searched devices are displayed in the
pop-up menu.
Select the desired device by pressing the OK key, and
entering the password.
Bluetooth On/Off (Menu 9.3.2)
This menu sets the Bluetooth on or off using the
navigation key.
Bluetooth Settings (Menu 9.3.3)
This menu allows you to configure the profile for a
Bluetooth.
]My Visibility
1. Selecting the Show option exposes your phone to
other Bluetooth devices.
2. Selecting Hide shows your phone only to already
paired devices.
]My Name: Allows you to change the handset's
name that can be seen by other bluetooth devices.
]My Address: You can check your Bluetooth
Address. You could not change the default setting.
Date & Time Menu 9.4
Set Date (Menu 9.4.1)
This allows you to enter the day, month and year. You
can change the date format via the Date Format menu
option.
Date Format (Menu 9.4.2)
MM/DD/YYYY(month/day/year)
DD/MM/YYYY(day/month/year)
YYYY/MM/DD(year/month/day)
Set Time (Menu 9.4.3)
This allows you to enter the current time. You can
choose the time format via the Time Format menu
option.
67
Settings
Time Format (Menu 9.4.4)
12 Hours/24 Hours
Auto Update (Menu 9.4.5)
Select On to set the phone to automatically update the
time and date according to the current local time zone.
Security Menu 9.5
Various codes and passwords are used to protect the
features and settings of your phone. They are
described in the following sections.
Lock Phone (Menu 9.5.1)
You can use a security code to avoid unauthorized use
of the phone.
If you set phone lock to When Power On, the phone
will request security code whenever you switch on the
phone. If you set phone lock to When SmartChip
Changed, your phone will request security code only
when you change your SmartChip. If you set phone
lock to Immediately, your phone will lock immediately.
PIN Code Request (Menu 9.5.2)
When the PIN code request feature is set to ‘On’, you
must enter your PIN each time you switch the phone
on. Consequently, any person who does not have your
PIN cannot use your phone without your approval.
nNote
Before setting to Off the PIN code request feature, you must
enter your PIN
The following [Options] are available:
]On: You must enter the PIN each time the phone is
switched on.
]Off: The phone connects directly to the network
when you switch it on.
Change Codes (Menu 9.5.3)
The Change codes feature allows you to change your
current password to a new one. You must enter the
current password before you can specify a new one.
You can change the access codes for: Security Code,
PIN1, PIN2
nNote
PIN: Personal Identification Number.
68
Settings
Call Menu 9.6
Call Forwarding (Menu 9.6.1)
When this network service is activated, you can direct
your incoming calls to another number, for example, to
your voice mailbox number. For details, contact your
service provider. Select one of the divert options, for
example, select If busy to divert voice calls when your
number is busy or when you reject incoming calls.
The following options are available:
]All Voice Calls: Diverts voice calls unconditionally.
]If Busy: Diverts voice calls when the phone is in use.
]If No Answer: Diverts voice calls which you do not
answer.
]If Out of Reach: Diverts voice calls when the phone
is switched off or out of coverage.
]All Data Calls: Diverts to a number with a PC
connection unconditionally.
]All Fax Calls: Diverts to a number with a fax
connection unconditionally.
Send My Number (Menu 9.6.2)
This network service allows you to set your phone
number to be displayed (On) or hidden (Off) from the
person to whom you are calling. You can select Set by
Network if you prefer to have different settings for
different service provider.
Auto Redial (Menu 9.6.3)
Select On, your phone redials the number you're trying
to call up to 10 times after you hear a quick, busy
signal. Press [END] to stop the call attempts.
This feature attempts to redial numbers that are busy
due to the wireless network. It does not redial numbers
to a busy party.
nNote
There will be no alert indicating the call has been connected.
You must stay on the line to hear when the call is connected.
Answer Mode (Menu 9.6.4)
This allows you to determine when to answer the
phone.
]Any Key: You can answer an incoming call by
pressing any key, except the [END] key.
69
Settings
]Send Key Only: You can answer an incoming call by
only pressing the [SEND] key.
]Flip Open: When the phone rings, you can answer a
call simply by sliding down the keypad.
Minute Minder (Menu 9.6.5)
This option allows you to specify whether the phone
will beep every minute during an outgoing call to keep
you informed of the length of the call.
Fixed Dial Number (Menu 9.6.6)
This allows you to restrict your outgoing calls to select
phone numbers, if this function is supported by your
SmartChip. The PIN2 code is required.
The following [Options] are available:
]On: You can only call phone numbers stored in the
Address Book. You must enter your PIN2.
]Off: You can call any number.
nNote
Not all SmartChips have a PIN2. If your SmartChip does not,
this menu option is not displayed.
Call Waiting (Menu 9.6.7)
The network will notify you of a new incoming call
while you have a call in progress. Select Activate to
request the network to activate call waiting, Deactivate
to request the network to deactivate call waiting, or
View Status, to check if the function is active or not.
Call Reject (Menu 9.6.8)
This menu allows you to enable or disable call reject
for all numbers or a specific number.
]Off
]Reject on List: Configures conditional call reject
mode. Press the left soft key [List] to add the phone
number to the list to be rejected. When you add a
number to the list, you can add the number by
entering it directly or by searching for the number in
the Contact List.
]Reject All Calls: This feature allows you to reject all
arriving calls unconditionally by disconnecting.
When the Reject All Calls option is set, all received
calls are directly routed to Voice Mail.
70
Settings
Send DTMF Tones (Menu 9.6.9)
You can send the DTMF (dual tone multi-frequency)
tones of the number on the display during a call.
This option is helpful for entering a password or
account number when you call an automated system,
like a banking service.
Network Menu 9.7
Flight Mode (Menu 9.7.1)
This menu shows the Network Profile. You can
register, delete and edit by using the Option Menu.
However, you cannot delete or edit default
configurations provided by Cingular.
Software Update Menu 9.8
This menu is used to resume the postponed software
update.
If new software exists, the Cingular server notifies
devices using the WAP push message.
Before downloading new software update packages
from the Cingular server and updating software, users
will be asked if they would postpone these operations.
Reminder times can be set to 30 minutes, 1 hour, and 3
hours. When time expires, users are prompted again or
users can resume the postponed operation using this
menu at any time.
Check Memory Menu 9.9
Common (Menu 9.9.1)
This function shows the status of the user memory of
the handset.
Reserved (Menu 9.9.2)
This function shows the status of the reserved memory
for the user (Text Message, Contact List, Calendar,
Tasks, Memo).
SmartChip (Menu 9.9.3)
This function shows the status of the SmartChip card
user memory.
Memory Card (Menu 9.9.4)
If your phone has a multimedia memory card in the
card slot, you can save images, sounds, and videos on
the memory card. You can check the current status of
the external memory card in Memory status menu.
71
Settings
Others Menu 9.0
TTY (Menu 9.0.1)
Allows you to attach a TTY device enabling you to
communicate with parties also using a TTY device.
A phone with TTY support is able to translate typed
characters to voice. Voice can also be translated into
characters and then displayed on the TTY.
TTY mode (Tele Type writer)
TTY modes are as follows :
1. TTY Full:
- Users who cannot talk and hear send and receive a
text message through TTY equipment.
2. TTY Talk:
- Users who can talk but cannot hear receive a text
message and send voice through TTY equipment.
3. TTY Hear:
- Users who can hear but cannot talk send a text
message and receive voice through TTY equipment.
Connecting TTY Equipment and a Terminal
1. Connect a TTY cable to TTY connection on the
terminal. (TTY connection location the same as a
hand free ear jack)
2. Enter the phone menu and set up the desired TTY
mode. (For a TTY mode, see the following)
3. After setting a TTY mode, check the LCD screen of
the phone for the TTY icon.
Menu User Feature Transmission When making communications
/Receiving Mode with a normal terminal
TTY Full For hearing- text message transmission, operator required
/verbally- impaired text message receiving
TTY+TALK For hearing-impaired talkable voice transmission, operator required
text message receiving
TTY+HEAR For verbally-impaired audible text message transmission, operator required
voice receiving
72
Settings
4. Connect the TTY equipment to the power source and
turn it on.
5. Make a phone connection to the desired number.
6. When connection is made, use the TTY equipment to
type in and send a text message or send voice.
7. The voice or text message from the receiver end
displays on the TTY equipment display.
Handset Information Menu 9.*
This menu is used to view My Numbers, Manufacturer
and Model Name information etc.
Reset Settings Menu 9.#
This function allows you to restore factory settings. To
do this, you need the security code.
Clear Memory (Menu 9.#.1)
Deletes downloaded/user created contents (e.g.:
images, videos) from Handset content and External
Memory card.
]Handset Contents: Deletes all downloaded/user
created Images, Videos & Sounds from Handset
Memory.
]Handset Personal info.: Restores Personal
Information stored in handset memory (e.g.: address
book, messages, tasks, alarm, Calendar schedules)
to default values.
]Memory Card: Deletes all contents from External
Memory Card.
Reset Default (Menu 9.#.2)
Restores the settings (e.g.: Audio, Display, Language,
Date & Time, Bluetooth Settings) stored in handset
memory to default values.
73
Q&A
Please check to see if any problems you have encountered with the phone are described in this section before taking
the phone in for a service or calling a service engineer.
QHow do I view the list of outgoing calls, incoming
calls and missed calls?
APress the [SEND] key.
QHow do I view all numbers stored in memory?
APress the down navigation key.
QWhy is the connection inconsistent or not audible in
certain areas?
AWhen frequency environment is unstable in a
certain area, connection may be inconsistent and
not audible. Relocate to another area and try again.
QWhy is the connection not consistent abruptly
disconnects even when established?
AWhen frequency is unstable or weak or if there are
too many users, connection may be cut off even
after it was established. Please try again later or
attempt after relocating to other areas.
QWhy does the LCD not turn on?
ARemove the battery and turn on the power after
placing it back on. If there is no change, fully charge
the battery and try again.
QWhy is there an echo when a connection is made
with certain telephones in a certain area?
AThis is called the ‘Echo Phenomenon’, where it
occurs if connection volume is too high or caused by
special properties (semi electronic telephone
exchange) of the equipment on the other end.
QWhy does the phone heat up?
AThe phone may get hot when there is a very long
call duration or when games are played or even
when surfing the Internet for a long time. This has
no effect upon the life of the product or
performance.
74
Q&A
QWhy does the battery life get shorter in standby mode?
AThe battery is worn out. As time passes, the battery
life gradually becomes shorter. If the battery lasts
about half the amount of time as when first
purchased, it’s time to purchase a new battery.
QWhy does the battery run out so quickly during
normal use?
AIt is due to the user environment or a large number
of calls or weak signal.
QWhy is no number dialed when you recall a Address
Book entry?
ACheck that the number has been stored correctly by
using the Address book Search feature. Re-store
them, if necessary.
QI cannot find the lock, PIN, or PUK code. What is my
password?
AThe default lock code is ‘0000’. If you forget or lose
the lock code, contact your phone dealer. If you
forget or lose a PIN or PUK code, or if you have not
received such a code, contact your network service
provider.
75
Accessories
Travel Adapter
This adapter allows you to
charge the battery. It supports
standard U.S. 120 Volt 60Hz
outlets.
It takes under 4 hours to charge
a completely discharged battery.
Battery
Standard battery is available.
Vehicle Power Adapter
You can operate the phone and
trickle charge the phone battery
from your vehicle by using the
vehicle power adapter.
It takes 5 hours to charge a
completely discharged battery.
Stereo headset
Allows hands-free operation.
Includes earpiece and
microphone.
Data Cable Kit
The Data Kit consists of a USB
Data Cable and a CD-ROM, it
allows you to connect your
phone to a PC.
On the CD-Rom, there are
programs like:
- PC-Sync: to synchronize phonebook with PC and
Outlook (To use PC-sync, the handset should be set in
idle mode).
- Phone Manager: to download wallpapers, ring tones
and video clips on the phone.
There are a variety of accessories available for your mobile phone. You can select these options according to your
personal communication requirements. Consult your local dealer for availability.
76
Accessories
* When installing, make sure to connect to the PC after
your phone and the cable have been connected.
Otherwise, your PC may have a problem.
nNote
The programs listed above may vary depending on the
version of the CD and the market.
nNote
• Always use genuine LG accessories. Failure to do this may
invalidate your warranty.
• Accessories may be different in different regions; please
check with our regional service company or agent for
further enquiries.
77
Safety Guidelines
TIA Safety Information
Provided herein is the complete TIA Safety Information for
Wireless Handheld phones. Inclusion of the text covering
Pacemakers, Hearing Aids, and Other Medical Devices is
required in the owner’s manual for CTIA Certification. Use of
the remaining TIA language is encouraged when appropriate.
Exposure to Radio Frequency Signal
Your wireless handheld portable telephone is a lowpower
radio transmitter and receiver. When it is ON, it receives and
also sends out radio frequency (RF) signals.
In August, 1996, the Federal Communications Commissions
(FCC) adopted RF exposure guidelines with safety levels for
handheld wireless phones. Those guidelines are consistent
with the safety standards previously set by both U.S. and
international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986)
ICNIRP (1996)
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. For example,
over 120 scientists, engineers, and physicians from
universities, government health agencies, and industry
reviewed the available body of research to develop the ANSI
Standard (C95.1).
*American National Standards Institute;National Council on
Radiation Protection and Measurements;International
Commission on Non-Ionizing Radiation Protection
The design of your phone complies with the FCC guidelines
(and those standards).
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could
damage the phone and may violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would any other
telephone with the antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
]Do not touch the antenna unnecessarily when the phone is
in use. Contact with the antenna affects call quality and may
cause the phone to operate at a higher power level than
otherwise needed.
Driving
Check the laws and regulations on the use of wireless phones
in the areas where you drive. Always obey them. Also, if using
your phone while driving, please:
78
Safety Guidelines
]Give full attention to driving - driving safely is your first
responsibility;
]Use hands-free operation, if available;
]Pull off the road and park before making or answering a call
if driving conditions so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends
that a minimum separation of six (6’) inches be maintained
between a handheld wireless phone and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the independent
research by and recommendations of Wireless Technology
Research.
Persons with pacemakers:
]Should ALWAYS keep the phone more than six inches from
their pacemaker when the phone is turned ON;
]Should not carry the phone in a breast pocket.
]Should use the ear opposite the pacemaker to minimize the
potential for interference.
]If you have any reason to suspect that interference is taking
place, turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to
consult your service provider.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are
adequately shielded from external RF energy. Your physician
may be able to assist you in obtaining this information.
Health Care Facilities
Turn your phone OFF in health care facilities when any
regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may use equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with the
manufacturer or its representative regarding your vehicle.
You should also consult the manufacturer of any equipment
that has been added to your vehicle.
79
Safety Guidelines
Posted Facilities
Turn your phone OFF in any facility where posted notices so
require.
Aircraft
FCC regulations prohibit using your phone while in the air. Turn
your phone OFF before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone
OFF when in a ‘blasting areas or in areas posted: ‘Turn off two-
way radio’. Obey all signs and instructions.
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire resulting
in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but
not always, marked clearly. Potential areas may include:
fueling areas (such as gasoline stations); below deck on boats;
fuel or chemical transfer or storage facilities; vehicles using
liquefied petroleum gas (such as propane or butane); areas
where the air contains chemicals or particles (such as grain,
dust, or metal powders); and any other area where you would
normally be advised to turn off your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects,
including either installed or portable wireless equipment, in the
area over the air bag or in the air bag deployment area. If in-
vehicle wireless equipment is improperly installed and the air
bag inflates, serious injury could result.
Safety Information
Please read and observe the following information for safe and
proper use of your phone and to prevent damage. Also, keep
the user guide in an accessible place at all the times after
reading it.
Charger and Adapter Safety
]The charger and adapter are intended for indoor use only.
Battery Information and Care
]Please dispose of your battery properly or take it to your
local wireless carrier for recycling.
]The battery does not need to be fully discharged before
recharging.
]Use only LG-approved chargers specific to your phone
model since they are designed to maximize battery life.
]Do not disassemble or impact the battery as it may cause
electric shock, short-circuit, and fire. Store the battery in a
place out of reach of children.
80
Safety Guidelines
]Keep the battery’s metal contacts clean.
]Replace the battery when it no longer provides acceptable
performance. The battery can be recharged several
hundred times before replacement.
]Recharge the battery after long periods of non-use to
maximize battery life.
]Battery life will vary due to usage patterns and
environmental conditions.
]Use of extended backlighting, MEdia Net Browsing, and
data connectivity kits affect battery life and talk/standby
times.
]The self-protection function of the battery cuts the power of
the phone when its operation is in an abnormal state. In this
case, remove the battery from the phone, reinstall it, and
turn the phone on.
Explosion, Shock, and Fire Hazards
]Do not put your phone in a place subject to excessive dust
and keep the minimum required distance between the
power cord and heat sources.
]Unplug the power cord prior to cleaning your phone, and
clean the power plug pin when it is dirty.
]When using the power plug, ensure that it is firmly
connected. If it is not, it may cause excessive heat or fire.
]If you put your phone in a pocket or bag without covering
the receptacle of the phone (power plug pin), metallic
articles (such as a coin, paperclip or pen) may short-circuit
the phone. Always cover the receptacle when not in use.
]Do not short-circuit the battery. Metallic articles such as a
coin, paperclip or pen in your pocket or bag may short-
circuit the + and – terminals of the battery (metal strips on
the battery) upon moving. Short-circuit of the terminal may
damage the battery and cause an explosion.
General Notice
]Using a damaged battery or placing a battery in your mouth
may cause serious injury.
]Do not place items containing magnetic components such
as a credit card, phone card, bank book or subway ticket
near your phone. The magnetism of the phone may damage
the data stored in the magnetic strip.
]Talking on your phone for a long period of time may reduce
call quality due to heat generated during use.
]When the phone is not used for a long period time, store it in
a safe place with the power cord unplugged.
]Using the phone in proximity to receiving equipment (i.e., TV
or radio) may cause interference to the phone.
]Do not use the phone if the antenna is damaged. If a
damaged antenna contacts skin, it may cause a slight burn.
Please contact an LG Authorized Service Center to replace
81
Safety Guidelines
the damaged antenna.
]Do not immerse your phone in water. If this happens, turn it
off immediately and remove the battery. If the phone does
not work, take it to an LG Authorized Service Center.
]Do not paint your phone.
]The data saved in your phone might be deleted due to
careless use, repair of the phone, or upgrade of the
software. Please backup your important phone numbers.
(Ring tones, text messages, voice messages, pictures, and
videos could also be deleted.) The manufacturer is not liable
for damage due to the loss of data.
]When you use the phone in public places, set the ring tone
to vibration so as not to disturb others.
]Do not turn your phone on or off when putting it in your ear.
FDA Consumer Update
The U.S. Food and Drug Administration Center for Devices and
Radiological Health Consumer Update on Mobile Phones.
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless phones.
There is no proof, however, that wireless phones are
absolutely safe. Wireless phones emit low levels of
radiofrequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in the
standby mode. Whereas high levels of RF can produce health
effects (by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse health
effects. Many studies of low level RF exposures have not
found any biological effects. Some studies have suggested
that some biological effects may occur, but such findings
have not been confirmed by additional research. In some
cases, other researchers have had difficulty in reproducing
those studies, or in determining the reasons for inconsistent
results.
2. What is the FDA’s role concerning the safety of wireless
phones?
Under the law, the FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to take
action if wireless phones are shown to emit radiofrequency
energy (RF) at a level that is hazardous to the user. In such a
case, the FDA could require the manufacturers of wireless
phones to notify users of the health hazard and to repair,
replace, or recall the phones so that the hazard no longer
exists.
Although the existing scientific data do not justify FDA
regulatory actions, the FDA has urged the wireless phone
industry to take a number of steps, including the following:
82
Safety Guidelines
]Support needed research into possible biological effects
of RF of the type emitted by wireless phones;
]Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function; and
]Cooperate in providing users of wireless phones with the
best possible information on possible effects of wireless
phone use on human health.
The FDA belongs to an interagency working group of the
federal agencies that have responsibility for different aspects
of RF safety to ensure coordinated efforts at the federal level.
The following agencies belong to this working group:
]National Institute for Occupational Safety and Health
]Environmental Protection Agency
]Occupational Safety and Health Administration
(Administración de la seguridad y salud laborales)
]Occupational Safety and Health Administration
]National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
The FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission (FCC).
All phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. The FCC
relies on the FDA and other health agencies for safety
questions about wireless phones.
The FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations operate
at higher power than do the wireless phones themselves, the
RF exposures that people get from these base stations are
typically thousands of times lower than those they can get
from wireless phones. Base stations are thus not the subject
of the safety questions discussed in this document.
3. What kinds of phones are the subject of this update?
The term ‘wireless phone’ refers here to handheld wireless
phones with built-in antennas, often called ‘cell’, ‘mobile’, or
‘PCS’ phones. These types of wireless phones can expose
the user to measurable radiofrequency energy (RF) because
of the short distance between the phone and the user’s head.
These RF exposures are limited by FCC safety guidelines that
were developed with the advice of the FDA and other federal
health and safety agencies. When the phone is located at
greater distances from the user, the exposure to RF is
drastically lower because a person’s RF exposure decreases
rapidly with increasing distance from the source. The so-
called ‘cordless phones,’ which have a base unit connected
to the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures far
below the FCC safety limits.
83
Safety Guidelines
4. What are the results of the research done already?
The research done thus far has produced conflicting results,
and many studies have suffered from flaws in their research
methods. Animal experiments investigating the effects of
radiofrequency energy (RF) exposures characteristic of
wireless phones have yielded conflicting results that often
cannot be repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could accelerate
the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor development
used animals that had been genetically engineered or treated
with cancer causing chemicals so as to be pre-disposed to
develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These
conditions are not similar to the conditions under which people
use wireless phones, so we don’t know with certainty what the
results of such studies mean for human health. Three large
epidemiology studies have been published since December
2000. Between them, the studies investigated any possible
association between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic neuroma, tumors
of the brain or salivary gland, leukemia, or other cancers. None
of the studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However, none of
the studies can answer questions about long-term exposures,
since the average period of phone use in these studies was
around three years.
5. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed to
provide reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more
years follow-up may be needed to provide answers about
some health effects, such as cancer. This is because the
interval between the time of exposure to a cancer-causing
agent and the time tumors develop - if they do- may be many,
many years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF exposure
during day-to-day use of wireless phones. Many factors
affect this measurement, such as the angle at which the
phone is held, or which model of phone is used.
6. What is the FDA doing to find out more about the possible
health effects of wireless phone RF?
The FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the world
to ensure that high priority animal studies are conducted to
address important questions about the effects of exposure to
radiofrequency energy (RF). The FDA has been a leading
84
Safety Guidelines
participant in the World Health Organization International
Electromagnetic Fields (EMF) Project since its inception in
1996. An influential result of this work has been the
development of a detailed agenda of research needs that has
driven the establishment of new research programs around
the world. The project has also helped develop a series of
public information documents on EMF issues. The FDA and
the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development
Agreement (CRADA) to do research on wireless phone
safety. The FDA provides the scientific oversight, obtaining
input from experts in government, industry, and academic
organizations. CTIA-funded research is conducted through
contracts with independent investigators. The initial
research will include both laboratory studies and studies of
wireless phone users. The CRADA will also include a broad
assessment of additional research needs in the context of
the latest research developments around the world.
7. How can I find out how much radio frequency energy
exposure I can get by using my wireless phone?
All phones sold in the United States must comply with
Federal Communications Commission (FCC) guidelines that
limit radio frequency energy (RF) exposures. The FCC
established these guidelines in consultation with the FDA
and the other federal health and safety agencies. The FCC
limit for RF exposure from wireless telephones is set at a
Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6
W/kg). The FCC limit is consistent with the safety standards
developed by the Institute of Electrical and Electronic
Engineering (IEEE) and the National Council on Radiation
Protection and Measurement. The exposure limit takes into
consideration the body’s ability to remove heat from the
tissues that absorb energy from the wireless phone and is
set well below levels known to have effects. Manufacturers
of wireless phones must report the RF exposure level for
each model of phone to the FCC. The FCC website
(http://www.fcc.gov/oet/rfsafety) gives directions for locating
the FCC identification number on your phone so you can find
your phone’s RF exposure level in the online listing.
8. What has the FDA done to measure the radio frequency
energy coming from wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is
developing a technical standard for measuring the radio
frequency energy (RF) exposure from wireless phones and
other wireless handsets with the participation and leadership
of FDA scientists and engineers. The standard,
‘Recommended Practice for Determining the Spatial- Peak
Specific Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental
Techniques,’ sets forth the first consistent test methodology
for measuring the rate at which RF is deposited in the heads
of wireless phone users. The test method uses a
tissuesimulating model of the human head. Standardized SAR
test methodology is expected to greatly improve the
85
Safety Guidelines
consistency of measurements made at different laboratories
on the same phone. SAR is the measurement of the amount
of energy absorbed in tissue, either by the whole body or a
small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to
determine whether a wireless phone complies with safety
guidelines.
9. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products - and at this point we do
not know that there is - it is probably very small. But if you
are concerned about avoiding even potential risks, you can
take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how
much exposure a person receives, reducing the amount of
time spent using a wireless phone will reduce RF exposure. If
you must conduct extended conversations by wireless phone
every day, you could place more distance between your body
and the source of the RF, since the exposure level drops off
dramatically with distance. For example, you could use a
headset and carry the wireless phone away from your body
or use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radiofrequency
energy (RF), the measures described above would apply to
children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure. Some groups sponsored by other national
governments have advised that children be discouraged
from using wireless phones at all. For example, the
government in the United Kingdom distributed leaflets
containing such a recommendation in December 2000. They
noted that no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children
was strictly precautionary; it was not based on scientific
evidence that any health hazard exists.
11. What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, the
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones. This
test method is now part of a standard sponsored by the
86
Safety Guidelines
Association for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by the FDA, medical
device manufacturers, and many other groups, was
completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and
defibrillators are safe from wireless phone EMI. The FDA has
tested hearing aids for interference from handheld wireless
phones and helped develop a voluntary standard sponsored
by the Institute of Electrical and Electronic Engineers (IEEE).
This standard specifies test methods and performance
requirements for hearing aids and wireless phones so that no
interference occurs when a person uses a ‘compatible’
phone and a ‘compatible’ hearing aid at the same time. This
standard was approved by the IEEE in 2000. The FDA
continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful
interference be found to occur, the FDA will conduct testing
to assess the interference and work to resolve the problem.
12. Where can I find additional information?
For additional information, please refer to the following
resources:
FDA web page on wireless phones
(http://www.fda.gov/cdrh/phones/index.html)
Federal Communications Commission (FCC) RF Safety
Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-lonizing Radiation
Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
National Radiological Protection Board (UK)
(http://www.nrpb.org.uk/)
10 Driver Safety Tips
Your wireless phone gives you the powerful ability to
communicate by voice almost anywhere, anytime. An
important responsibility accompanies the benefits of wireless
phones, one that every user must uphold.
When operating a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a car,
practice good common sense and remember the following tips:
1. Get to know your wireless phone and its features such as
speed dial and redial. Carefully read your instruction manual
and learn to take advantage of valuable features most
phones offer, including automatic redial and memory. Also,
work to memorize the phone keypad so you can use the
speed dial function without taking your attention off the
road.
2. When available, use a hands-free device. A number of
hands-free wireless phone accessories are readily available
87
Safety Guidelines
today. Whether you choose an installed mounted device for
your wireless phone or a speaker phone accessory, take
advantage of these devices if available to you.
3. Position your wireless phone within easy reach. Make sure
you place your wireless phone within easy reach and where
you can reach it without removing your eyes from the road.
If you get an incoming call at an inconvenient time, if
possible, let your voicemail answer it for you.
4. Suspend conversations during hazardous driving conditions
or situations. Let the person you are speaking with know you
are driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow and ice can
be hazardous, but so is heavy traffic. As a driver, your first
responsibility is to pay attention to the road.
5. Do not take notes or look up phone numbers while driving. If
you are reading an address book or business card, or writing
a “to-do” list while driving a car, you are not watching
where you are going. It is common sense. Don’t get caught
in a dangerous situation because you are reading or writing
and not paying attention to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place calls
when you are not moving or before pulling into traffic. Try to
plan your calls before you begin your trip or attempt to
coincide your calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if you need to dial
while driving, follow this simple tip— dial only a few
numbers, check the road and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that
may be distracting. Stressful or emotional conversations and
driving do not mix; they are distracting and even dangerous
when you are behind the wheel of a car. Make people you
are talking with aware you are driving and if necessary,
suspend conversations which have the potential to divert
your attention from the road.
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to protect
yourself and your family in dangerous situations — with your
phone at your side, help is only three numbers away. Dial
911 or other local emergency number in the case of fire,
traffic accident, road hazard or medical emergency.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in emergencies. Your
wireless phone provides you a perfect opportunity to be a
“Good Samaritan” in your community. If you see an auto
accident, crime in progress or other serious emergency
where lives are in danger, call 911 or other local emergency
number, as you would want others to do for you.
10. Call roadside assistance or a special wireless non-
emergency assistance number when necessary. Certain
situations you encounter while driving may require
attention, but are not urgent enough to merit a call for
emergency services. But you can still use your wireless
phone to lend a hand. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a minor
88
Safety Guidelines
traffic accident where no one appears injured or a vehicle.
you know to be stolen, call roadside assistance or other
special non-emergency wireless number.
For more information, please call to 888-901-SAFE, or visit our
website www.wow-com.com
Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s Requirements for
Exposure to Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits
for exposure to radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government.
These limits are part of comprehensive guidelines and
establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were
developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit set by the FCC is 1.6W/kg. * Tests for
SAR are conducted using standard operating positions
specified by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands. Although
SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well
below the maximum value. Because the phone is designed to
operate at multiple power levels to use only the power
required to reach the network, in general, the closer you are to
a wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must
be tested and certified to the FCC that it does not exceed the
limit established by the government-adopted requirement for
safe exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as required by
the FCC for each model. The highest SAR value for this model
phone when tested for use at the ear is 1.06 W/kg and when
worn on the body, as described in this user’s manual, is 1.27
W/kg. (Body-worn measurements differ among phones
models, depending upon available accessories and FCC
requirements.) While there may be differences between SAR
levels of various phones and at various positions, they all meet
the government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance
with the FCC RF emission guidelines. SAR information on this
model phone is on file with the FCC and can be found under the
Display Grant section of http://www.fcc.gov/oet/fccid after
searching on FCC ID BEJCU500.
Additional information on Specific Absorption Rates (SAR) can
89
Safety Guidelines
be found on the Cellular Telecommunications Industry
Association (CTIA) website at http://www.wow-com.com
*In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg) averaged
over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional protection for
the public and to account for any variations in
measurements.
90
Glossary
To help you understand the main technical terms and abbreviations used in this booklet and take full advantage of the
feature on your mobile phone, here are a few definitions.
Call Barring
Ability to restrict outgoing and incoming calls.
Call Divert
Ability to reroute calls to another number.
Call Waiting
Ability to inform users that they have an incoming call
when engaged on another call.
GPRS (General Packet Radio Service)
GPRS guaranties continuous connection to the
Internet for mobile phone and computer users. It is
based on the Global System for Mobile Communication
(GSM) circuit-switched cellular phone connections
and the Short Message Service (SMS).
GSM (Global System for Mobile Communication)
International standard for cellular communication,
guaranteeing compatibility between the various
network operators. GSM covers most European
countries and many other parts of the world.
Java
Programming language generating applications that
can run on all hardware platforms, whether small,
medium or large, without modification.
It has been promoted for and geared heavily to the
Web, both for public Web sites and Intranets. When a
Java program runs from a Web page, it is called a
Java applet. When it is run on a mobile phone or
pager, it is called a MIDlet.
Line Identification Services (Caller ID)
Service allowing subscribers to view or block the
telephone numbers of callers.
Conference Calls
Ability to establish a conference call involving up to
five additional parties.
Phone Password
Security code used to unlock the phone when you
have selected the option to lock it automatically each
time it switches on.
91
Glossary
Roaming
Use of your phone when you are outside your home
area (when traveling for example).
SDN (Service Dial Number)
Telephone numbers supplied by your network provider
and giving access to special services, such as voice
mail, directory inquiries, customer support and
emergency services.
SmartChip
Card containing a chip with all the information required
to operate the phone (network and memory
information, as well as the subscriber’s personal data).
The SmartChip fits into a small slot on the back of the
phone and is protected by the battery.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to speak
to the correspondent. The message created or
received (up to 160 characters long) can be displayed,
received, edited or sent.
Patent Information
This product was manufactured under one or more of
the following U.S.
patents: 5276765 5749067 6061647
92
Index
A
Access Codes ................................................................... 19
Address Book ............................................................. 26, 63
Alarm Clock ....................................................................... 56
Answer Mode ................................................................... 69
Answering a Call .............................................................. 21
Audio(s) ....................................................................... 55, 65
Auto Redial ........................................................................ 69
B
Backlight Timeout ............................................................ 66
Battery Disposal ............................................................... 10
Bluetooth ........................................................................... 66
C
Calculator .......................................................................... 58
Calendar ............................................................................ 57
Call ...................................................................................... 69
Caller Groups .................................................................... 63
Call Forwarding ................................................................ 69
Camera key ................................................................. 11, 12
Charging the Battery ....................................................... 16
Changing the Text Input Mode ...................................... 22
Chat .................................................................................... 44
Cingular Video .................................................................. 54
D
Date Format ...................................................................... 67
Display Information ..........................................................13
During a Call ..................................................................... 27
E
Email ............................................................................. 39, 45
Email Inbox ........................................................................ 41
Entering Text ..................................................................... 21
F
Fixed Dial Number ........................................................... 70
93
Index
G
GPRS .................................................................................. 91
I
Inbox .................................................................................. 40
Inserting the memory card ............................................. 18
Installing the SmartChip ................................................. 15
K
Key Tones .......................................................................... 65
L
Language ........................................................................... 66
Lock Phone ....................................................................... 68
M
Making a Call .................................................................... 20
Memory Card .............................................................. 62, 71
Messaging ........................................................................ 37
Minute Minder .................................................................. 70
MP3 Player ........................................................................ 55
Multishot ........................................................................... 60
My Numbers ..................................................................... 64
N
Network Profiles .............................................................. 71
Notepad ............................................................................. 57
O
Outbox ................................................................................ 42
P
Phone Components ......................................................... 11
R
Record Video .................................................................... 61
Removing the memory card ........................................... 18
Ringtones .......................................................................... 65
94
Index
S
Security ....................................................................... 50, 68
Security code ................................................................... 19
Service Dial Numbers ..................................................... 64
Shop Games ...................................................................... 53
Speed Dial List .................................................................. 63
T
Take Photo ........................................................................ 60
Templates .......................................................................... 44
U
Unit Converter .................................................................. 59
V
Vibrate Mode .................................................................... 21
Videos ................................................................................ 56
Voice Mail ......................................................................... 43
W
Wallpapers ........................................................................ 65
World Clock ...................................................................... 58
