LG Electronics USA G4050 Dual Band Mobile Phone User Manual G 4010 3
LG Electronics USA Dual Band Mobile Phone G 4010 3
Users Manual
G4010
User Guide
Unpacking 8
For Your Safety 9
Your Phone 14
Phone Components 14
Your Phone's Feature 15
Display Information 17
Getting Started 18
Using the Battery, Charger
and SIM Card 18
Installing the Battery 18
Removing the Battery 19
Charging the Battery 20
Disconnecting the Charger 21
Installing the SIM Card 22
Turning Your Phone
On and Off 23
Turing Your Phone On 23
Turning Your Phone Off 23
Access Codes 24
PIN code 24
PIN2 code 24
PUK code 24
PUK2 code 24
Security code 25
Barring Password 25
General Functions 26
Making and Answering
Calls 26
Making a Call 26
Making a call by Send key 26
Making International Calls 26
Ending a Call 27
Making a call from the
Phonebook 27
Adjusting the Volume 27
Answering a Call 27
Signal Strength 28
Entering Text 28
Phonebook 33
In-Call Menu 34
During a Call 34
Making a Second Call 34
Swapping Between
Two Calls 34
Answering an Incoming Call 35
Rejecting an Incoming Call 35
Muting the Microphone 35
Switching DTMF Tones
on During a Call 36
Multiparty or Conference
Calls 36
Making a Second Call 37
Setting up a Multiparty
Call 37
5
4
Putting the Multiparty
Call on Hold 37
Activate the Multiparty
Call on Hold 37
Adding Calls to the
Multiparty Call 37
Displaying Callers in a
Multiparty Call 37
A Private Call in a
Multiparty Call 38
Ending a Multiparty Call 38
Menu Tree 39
Message 42
Text Messages 42
Write message 42
Inbox 44
Outbox 45
Draft 45
Settings 46
Voice Messages 47
Listen to voice mail 47
Voice mailbox number 47
Info Messages 48
Receive 48
Inbox 48
Topics 48
Alert 49
Auto Display 49
Language 49
Templates 50
Name Card 50
Check memory 51
Text 51
Call Register 52
Missed Calls 52
Received Calls 53
Dialed Calls 53
Delete recent calls 54
Call durations 54
Last Call 54
Received Call 54
Dialed Calls 54
All Calls 54
Call Costs 55
Last Call’s Cost 55
All Call’s Cost 55
Cost Settings 56
Call cost’s limit 56
Set tariff 56
Auto display 56
GPRS information 57
WAP 57
External device 57
Total data 57
Table of Contents
7
6
Profiles 58
Settings 60
Alarm Clock 60
Date & Time settings 61
Date & Time 61
Auto update 61
Phone Settings 62
Display settings 62
Language 62
TTY 63
LED indicator 63
Call settings 64
Call divert 64
Answer mode 65
Send my number 65
Call waiting 65
Minute minder 66
Automatic redial 66
Select Line 66
Data transfer mode 66
Closed user group 67
Security settings 68
PIN Code Request 68
Call barring service 68
Fixed dial number 70
Change codes 70
Network settings 71
Automatic 71
Manual 71
Preferred 71
GPRS settings 72
Attach 72
External device 73
Reset settings 73
Organizer 74
Schedule 74
Memo 76
Phonebook 77
Search 77
Add New 79
Speed Dials 80
Caller Groups 81
Copy all 82
Delete all 82
Settings 83
Information 84
Fun & Tools 85
Game 85
Black Jack 85
My folder 86
Pictures 86
Animation 86
Sound 86
Unit converter 87
Calculator 87
World time 88
Internet 89
Home 91
Push message 91
Inbox 91
Receive 91
Profiles 92
Cache settings 94
Clear cache 94
Check cache 94
WAP information 94
Reset profiles 94
Q & A 95
Accessories 98
Safety Guidelines 100
Index 116
9
8
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your
warranty for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32。F or greater than 104。F, such as outside during a snowstorm
or in your car on a hot day. Exposure to excessive cold or heat
will result in malfunction, damage and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby inadequately shielded electronic equipment. You should
consult with manufacturers of any personal medical devices
such as pacemakers and hearing aides to determine if they are
susceptible to interference from your mobile phone. Turn off
your phone in a medical facility or at a gas station. Never place
your phone in a microwave oven as this will cause the battery to
explode.
IMPORTANT! Please read the TIA SAFETY
INFORMATION on page 123 before using your phone.
Check to make sure that you have all the parts shown below
Unpacking For Your Safety
Handset Standard
Battery
Warranty
Card User Guide
Travel
Adapter
Neckstrap Handsfree
portable
11
10
Safety Information
Please read and observe the following information for the safe
and proper use of your phone and to prevent any unanticipated
damage by accident. Also, keep the user’s manual in an
accessible place all the times after reading it.
▶Unplug the power cord and charger during a lightning storm
to avoid electric shock or fire.
▶Do not use your phone in high explosive areas as the phone
may generate sparks.
▶Do not put your phone in a place subject to excessive dust,
and keep the minimum required distance between the power
cord and heat sources.
▶Unplug the power cord prior to cleaning your phone, and
clean the power plug pin when it is dirty.
▶Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
fire or electric shock.
▶Hold the power cord plug firmly to plug and unplug the
power cord. Ensure the plug is firmly connected. If it is not
firmly connected, it may cause excessive heat or fire.
▶Do not place any heavy item on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
▶Be careful not to let the battery contact metal conductors
such as a necklace or coins. When shorted, it may cause an
explosion.
▶Do not disassemble or impact to the battery as it may cause
electric shock, short-circuit, and fire. Store the battery in a
place out of reach of children.
▶Using a damaged battery or placing a battery in your mouth
may cause serious injury.
▶Do not place items containing magnetic components such as
a credit card, phone card, bank book and a subway ticket,
near your phone. The magnetism of the phone may damage
the data stored in the magnetic strip.
▶Do not hold or let the antenna come in contact with your
body during a call.
▶Talking on your phone for a long period of time may reduce
the call quality due to heat generated during the use.
▶Do not allow excessive vibration or impact to the phone
▶When you do not use the phone for a long period time, store
it in a safe area with the power cord unplugged.
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of the
United States, with its action in Report and Order FCC 96-326,
adopted an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with the
safety standard previously set by both U.S. and international
standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
For Your SafetyFor Your Safety
13
12
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with skin, a minor burn may result.
Contact your local dealer for a replacement of antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 3/4 inch (2 cm) from the body. To
comply with FCC RF exposure requirements, a minimum
separation distance of 3/4 inches (2 cm) must be maintained
between the user’s body and the back of the phone, including
the antenna, whether extended or retracted. Third-party belt-
clips, holsters, and similar accessories containing metallic
components should not be used. Body-worn accessories that
cannot maintain 3/4 inch (2 cm) separation distance between the
user’s body and the back of the phone, and have not been tested
for typical body-worn operations may not comply with FCC RF
exposure limits and should be avoided.
Vehicle Mounted External Antenna (optional, if
available)
A minimum separation distance of 8 inches (20 cm) must be
maintained between the user/bystander and the vehicle mounted
external antenna to satisfy FCC RF exposure requirements.
For more information about RF exposure, visit the FCC website
at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions: (1)
This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must accept
any interference received, including interference that may cause
undesired operation.
Cautions for Battery
▶Do not disassemble.
▶Do not short-circuit.
▶Do not expose to high temperature: 60℃(140℉).
▶Do not incinerate.
Battery Disposal
▶Please dispose of your battery properly or bring to your local
wireless carrier for recycling.
▶Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
▶Using the wrong battery charger could damage your phone
and void your warranty.
▶The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.
For Your SafetyFor Your Safety
14 15
Your Phone
Your Phone
Phone Components
1. Earpiece
8. Active flip
9. Display screen
10. Navigation key
2. left soft key
3. Side keys
5. Send key
11. Confirm key
12. right soft key
4. Vibration key
13. Massage key
14. End / Power key
7. Microphone
6. Alpha numeric
keys
Your Phone’’
s Features
1. Earpiece
2.12 left soft key / right soft key: Each of these keys performs the function
indicated by the text on the display immediately above it.
3. Side keys: These keys are used to control the volume of key tone in
standby mode and speaker volume during a call.
4. Vibration key: Use to set the Manner Mode by pressing and holding the
< key for about 3 seconds while in standby mode.
5. Send key: You can dial a phone number and answer incoming calls.
Press this key in standby mode to quickly access the most recent
incoming, outgoing and missed calls.
6. Alphanumeric keys: These keys are used to dial a number in standby
mode and to enter number or characters in edit mode.
7. Microphone: Can be muted during a call for privacy.
8. Active flip: Open the flip to answer an incoming call and close to end the
call
9. Display screen: Displays phone status icons, menu items, Web
information, pictures and more in full color.
10. Navigation key:
11. Confirm key: Long press will launch the WAP browser. Lets you
select menu options and confirm actions.
13. Message key: Use to retrieve or send voice and text messages.
14. End/Power key: Lets you power the phone the phone no or off, end
calls or return to Standby mode.
17
16
Your Phone Your Phone
SIM Card
Socket
Battery Lock
Antenna
Cable Connector/
Battery Charging Connector/
Hands-Free Car kit Connector
Handstrap Hole
Battery
Battery
Terminals
Icon Description
Indicates the strength of the network signal.
Indicates a call is in progress.
Indicates that you are roaming off the network.
Indicates that GPRS service is available.
Indicates the alarm has been set and is on.
Indicates the status of the battery charge.
Indicates the receipt of a text message.
Indicates the receipt of a voice message.
Indicates that the vibration ringer has been set.
Indicates the receipt of an e-mail message.
Indicates the Loud menu in Profiles.
Indicates the Quiet menu in Profiles.
Indicates the Headset menu in Profiles.
Indicates the Car menu in Profiles.
Indicates the General menu in Profiles.
Indicates that you can use the push message service.
Indicates the Schedule function.
Display Information
The table below describes various display indicators or icons
that appear on the phone’s display screen.
On-Screen Icons
Using the Battery,
Charger and SIM Card
Installing and Removing the Battery
▶To install, insert the battery into the opening on the back of
the phone and gently press down until the latch snaps into
place.
▶To remove, first make sure the power is off. Press the battery
release latch up and remove the battery from the phone at a
45-degree angle.
Installing the Battery
To install the battery, insert the bottom of the battery into the
opening on the back of the phone. Then, push the battery down
until the latch clicks.
18 19
Removing the Battery
Turn the power off. (If power is on, a loss of stored numbers and
messages may occur.)
Lifting release latch detaches the battery from the phone.
Getting Started
Getting Started
21
20
Disconnecting the charger
When charging is finished, disconnect the adapter from the
power outlet and from the phone by pressing the gray tabs on
both sides of the connector and pulling the connector out.
Notice
▶The battery delivered with your phone has to be fully
charged before using it.
▶Do not remove the battery or the SIM card while
charging.
▶If your phone is powered on while charging, you’ll see
the bars in the battery indicator icon cycle.
When the battery is fully charged, the bars in the
battery indicator icon will flash on and off
▶If your phone is powered off, the display will show
charging status. “Battery Charging” or “Battery Full” will
be displayed.
If the battery fails to charge completely.
▶After turning the phone on and off, please attempt to
recharge the battery.
▶After detaching and reattaching the battery, please
attempt to recharge the battery.
Warning
Do not force the connector as this may
damage the phone and/or the travel adapter.
Charging the Battery
Use of unauthorized accessories could damage your phone and
invalidate your warranty.
To use the travel adapter provided with your phone.
1. With the battery in position on the phone, connect the lead
from the travel adapter to the bottom of the phone. Check that
the arrow on the lead connector is facing towards the front of
the phone.
2. Connect the adapter to a standard AC wall outlet. Only use
the travel adapter that comes included with the package.
Getting StartedGetting Started
23
22
Turning Your Phone On and Off
Turning Your Phone ON
1. Install a charged battery pack or connect the phone to an
external power source such as the cigarette lighter adapter or
car kit.
2. Press for more than five seconds.
▶Fully extend the antenna for the best performance.
3. Depending on the status of the PIN code Request setting you
may or may not need to enter it.
Turning Your Phone OFF
1. Press for a few seconds.
Installing the SIM Card
When you subscribe to a cellular network, you are provided
with a plug-in SIM card loaded with your subscription details
(PIN, optional services available and so on).
Locate the SIM card socket in the back of the phone. Follow the
steps below to install the SIM card.
1. Remove the battery if attached.
2. Slide the SIM card into the SIM card holder so that the holder
locks the card in position.
SIM
SIM
Notice
▶Before installing always make sure that the phone is
switched off and remove the battery.
▶The metal contact of the SIM card can be easily
damaged by scratches. Pay special attention to the
SIM card when you handle and install. Follow the
instructions supplied with the SIM card.
Notice
When you need to remove the SIM card, slide it
towards the top of the phone and take it out of
the holder.
Notice
Like any other radio device, avoid any unnecessary
contact with the antenna while your phone is on.
Getting StartedGetting Started
25
24
Access Codes
You can use the access codes described in this section to avoid
unauthorized use of your phone. The access codes (except
PUK and PUK2 codes) can be changed by using the Change
Codes feature [Menu 4-5-4].
PIN code (4 to 8 digits)
The PIN (Personal Identification Number) code protects you
SIM card against unauthorized use. The PIN code is usually
supplied with the SIM card. When the PIN Code Request is set
to Enable, your phone will request the PIN code every time it is
switched on. When the PIN Code Request is set to Disable,
you phone connects to the network directly without the PIN
code.
PIN2 code (4 to 8 digits)
The PIN2 code, supplied with some SIM cards, is required to
access functions such as Advice of Call Charge and Fixed Dial
Number. These functions are only available if supported by your
SIM card.
PUK code (4 to 8 digits)
The PUK (PIN Unblocking Key) code is required to change a
blocked PIN code. The PUK code may be supplied with the
SIM card. If not, contact your local service provider for the
code. If you lose the code, also contact your service provider.
Barring Password
The barring password is required when you use the Call
Barring function. You obtain the password from your service
provider when you subscribe to this function. See page68 for
further details.
PUK2 code (4 to 8 digits)
The PUK2 code, supplied with some SIM cards, is required to
change a blocked PIN2 code. If you lose the code, also contact your
service provider.
Security code (4 to 8 digits)
The security code protects the unauthorized use of your phone.
The default security code is set to “0000” and the security code
is required to delete all phone entries and to activate the Restore
Factory Settings menu. The security code default setting can be
modified from the Security Settings menu.
Getting StartedGetting Started
Making a Call
1. Make sure your is on.
2. Enter a phone number including the area code. To edit a
number on the display screen, press the right/left navigation
keys to move the cursor to desired position. Or, press right soft
key(Clear key) to erase one digit at a time.
▶Press and hold right soft key to erase the entire number.
3. Press to call the number.
4. When you are finished, press .
Making a call by Send key
1. Press , and the most recent incoming, outgoing and
missed phone numbers will be displayed.
2. Select the desired number by using the navigation keys.
3. Press .
Making International Calls
1. Press and hold the key for the international prefix. The
“+” character can be replaced with the international access
code.
2. Enter the country code, area code, and the phone number.
3. Press .
26
Ending a Call
When you have finished your call, briefly press the key.
Making a call from the Phonebook
You can store the names and phone numbers dialled regularly in
the SIM card and phone memory, called the phonebook.
You then simply select the reguired name to recall the
associated number. For further details on the Phonebook feature,
refer to page??
Adjusting the Volume
During a call, if you want to adjust the earpiece volume, use the
Side keys on the Side keys of the phone.
Press the up navigation key to increase and the down navigation
key to decrease the volume.
In idle mode with the flip cover open, you can adjust the Side
keys volume using the up/down navigation keys.
Answering a Call
When somebody calls you, the phone rings and the phone icon
in the middle of the screen flashes. If the caller can be
identified, the caller’s phone number(or name if stored in your
phonebook) is displayed.
1. If necessary, open the flip. Press the key and left soft key
to answer the incoming call. If the Press any key menu
option(Menu 4.4.2)is set to Yes, you can press any key to
answer a call except for the key and right soft key.
Making and Answering Calls
General Functions
27
General functions
2. End the call by closing the phone or pressing the key.
Signal Strength
Call quality is always best when the antenna is fully raised. If
you’re inside a building, being near a window may give you
better reception. You can see the strength of your signal by the
signal indicator ( ) on your phone’s display screen.
Entering Text
When using your phone, you will need to enter text. For
example, when storing a name in the phonebook and write
message, creating your personal greeting or scheduleing events
in your calendar. You can enter alphanumeric characters by
using your phone’s keypad.
You are provided with the following text input modes.
T9 mode
This mode allows you to enter words with only one keystroke
per letter. Each key on the keypad has more than one letter. The
29
28
T9 mode automatically compares your keystrokes with an
internal linguistic dictionary to determine the correct word, thus
requiring far fewer keystrokes than the traditional ABC mode.
ABC mode
This mode allows you to enter letters by pressing the key
labelled with the required letter once, twice, three or four times
until the letter is displayed.
123 mode(Number mode)
Type numbers using one keystroke per number. To change to
123 mode in a text entry field, press key until 123 mode is
displayed.
Symbolic mode
This mode allows you to enter special character.
Changing the Text input Mode
1. When you are in a field that allows characters to be entered,
you will notice the text input mode indicator in the upper
right corner of the display.
2. If you want to change mode, press the key. The modes
available are displayed.
Notice
▶
To reject an incoming call, press and hold the Side Keys
on the left side of the phone without opening the flip.
▶
If the Flip open menu option(Menu 4.4.2) is set to Yes,
you do not need to press any key. You can answer the call
simply by opening the flip.
Notice
You can answer a call while using the phonebook
or menu features.
Notice
You can select T9 languages by selecting menu.
In T9 mode, you can also select T9 Off menu.
(Default is T9 On)
General functionsGeneral functions
Options Back
Using the T9 Mode
The T9 predictive text input mode allows you to enter words
easily with a minimum of key presses. As you press each key,
the phone selects a letter that makes on the word that it thinks
you are typing, based on a built-in dictionary. As a new letter is
added, the word changes based on the key that you have
pressed.
1. When you are in the T9 predictive text input mode, start
entering a word by pressing keys to . Press each key
only once for one letter.
▶The word changes as letters are typed - ignore what,s on
the screen until the word is typed completely.
▶If the word is still incorrect after typing is completely,
press the Right navigation key one or more times to cycle
through other word options.
Example: Press [4] [6] [6] [3] to type Good
Press [4] [6] [6] [3] [Right navigation key] to type
Home
▶If the desired word is missing from the choices, add it
using the ABC mode.
2. Enter the whole word before editing or deleting any
keystrokes.
3. Complete each word with a space by pressing the key.
To delete letters, press right soft key. Press and hold down right
soft key to erase entire words.
31
30
Using the ABC Mode
Use the to keys to enter your text.
1.Press the key labelled with the required letter:
▶Once for the first letter
▶Twice for the second letter
▶And so on
2.To insert a space, press the key once. To delete letters,
press the right soft key. Press and hold down the right soft key
to clear the display.
Notice
To exit the text input mode without saving your
input, press . The phone returns to the
previous menu level.
Notice
Refer to the table below for more information on
the characters available using the keys.
Key Characters in the Order Display
. , ' ? ! - & 1
A B C 2 Ä Å Æ Ç a b c à ä å ß
D E F 3 É d e f è é
G H I 4 g h i ì
J K L 5 j k l
MM N O 6 Ñ Ö Ø m n o ñ ò ö Ø
P Q R S 7 p q r s
T U V 8 Ü t u v ù ü
W X Y Z 9 w x y z
0 [Space Key]
4 6 6 3
4 6 6 3
General functionsGeneral functions
33
32
Using the 123(Number) Mode
The 123 mode enables you to enter numbers in a text message
(a telephone number, for example).
Press the keys corresponding to the required digits before
manually switching back to the appropriate text entry mode.
Using the Symbol Mode
The Symbol mode enables you to enter various symbols.
To enter a symbol, press key then use the mavigation keys
to select the desired symbol. Press [OK] key.
You can store phone numbers and their corresponding names in
the memory of your SIM card.
In addition, you can store up to 100 numbers and names in the
phone memory.
The SIM card and phone memories, althrough physically
separate, are used as if they were a single entity, called the
phonebook. (see page 77 in detail)
▶Search: Allows you to search for a specific name and number.
▶Add new: Allows you to add new names and numbers.
▶Speed dials: Allows you to assign up to 8 speed dial numbers.
▶Caller groups: Allows you to display group list, select it, edit
the name, set ring type and icon for each group.
▶Copy all: Allows you to copy entries from your Phone
memory to SIM card or from SIM card to Phone memory.
▶Delete all: Allows you to erase all data in SIM, Phone or
Voice list memory.
▶Settings: Allows you to settings memory and search.
▶Information: Allows you to check the status of memory,
SDN(Service Dial Number), and Own number.
Phonebook
General functionsGeneral functions
35
Your phone provides a number of control functions that you can
use during a call. To access these functions during a call, press
the left soft key [Options].
During a Call
The menu displayed on the handset screen during a call is
different to the default main menu reached from the idle screen,
and the options are described here.
Making a Second Call
You can get a dial number from phonebook to make a second
call. Press right soft key then select Search. To save the dial
number into phonebook during call, press right soft key then
select Add Entry.
Swapping Between Two Calls
To switch between two calls, select left soft key, then select
Swap. You can make one of two calls focused by pressing
up/down arrow key. If you want to end one of two calls, make
the call you want to end focused, then press key when the
call you want to end is focused.
34
In-Call Menu Answering an Incoming Call
To answer an incoming call when the handset is ringing, simply
press the key. The handset is also able to warn you of an
incoming call while you are already in a call. A tone sounds in
the earpiece, and the display will show that a second call is
waiting. This feature, known as Call Waiting, is only available if
your network supports it. For details of how to activate and
deactivate it see Call waiting [Menu 4-4-4].
If Call Waiting is on, you can put the first call on hold and
answer the second, by pressing or by selecting left soft key,
then Hold & Answer. You can end the current call and answer
the waiting call by selecting left soft key, then End & Answer.
Rejecting an Incoming Call
When not in a call you can reject an incoming call without
answering it by simply pressing the key.
When in a call you can reject an incoming call by pressing the
left soft key [Menu] key and selecting Multiparty/Reject or by
pressing key.
Muting the Microphone
You can mute the microphone during a call by pressing the
[Menu] key then selecting Mute on. The handset can be
unmuted by pressing the must off menu. When the handset is
muted, the caller cannot hear you, but you can still hear them.
General functionsGeneral functions
37
36
Switching DTMF Tones on During a Call
To turn DTMF tones on during a call, for example, to allow
your handset to make use of an automated switchboard, select
left soft key, then DTMF On. DTMF tones can be turned off the
same way.
Multiparty or Conference Calls
The multiparty or conference service provides you with the
ability to have a simultaneous conversation with more than one
caller, if your network service provider supports this feature. A
multiparty call can only be set up when you have one active call
and one call on hold, both calls having been answered. Once a
multiparty call is set up, calls may be added, disconnected or
separated (that is, removed from the multiparty call but still
connected to you) by the person who set up the multiparty call.
These options are all available from the in-call menu and are
listed in Section. The maximum callers in a multiparty call are
five. Once started, you are in control of the multiparty call, and
only you can add calls to the multiparty call.
Making a Second Call
You can make a second call while you are already in a call. To
do this, enter the second number and press . When you get
second call the first call is automatically put on hold. You can
swap between calls by selecting left soft key then Swap.
Setting up a Multiparty Call
You can connect a call on hold to the currently active call to
form a multiparty call by selecting left soft key then
Multiparty/Join all.
Putting the Multiparty Call on Hold
To put a multiparty call on hold, select left soft key then
Multiparty/Hold all.
Activate the Multiparty Call on Hold
To make a multiparty call on hold active, select left soft key
then Multiparty/Join all.
Adding Calls to the Multiparty Call
To join an active call to the held multiparty call, select left soft
key then Multiparty/Join all.
Displaying Callers in a Multiparty Call
To scroll through the numbers of the callers who make up a
multiparty call on the handset screen, press Up/Down
Navigation keys.
General functionsGeneral functions
1. Messages (see page 42)
1.1 Text Messages
1.1.1 Write Message
1.1.2 Inbox
1.1.3 Outbox
1.1.4 Draft
1.1.5 Settings
1.1.6 Delete all
1.2 Voice messages
1.2.1 Listen to voice mail
1.2.2 Voice mailbox number
1.3 Info service
1.3.1 Receive
1.3.2 Inbox
1.3.3 Topics
1.3.4 Alert
1.3.5 Auto display
1.3.6 Languages
1.4 Template
1.4.1 Text
1.5 Name card
1.6 Check memory
1.6.1 Text
2. Call Register (see page 52)
2.1 Missed calls
2.2 Received calls
2.3 Dialled calls
2.4 Delete recent calls
2.4.1 Missed call
2.4.2 Received calls
2.4.3 Dialled calls
2.4.4 All calls
2.5 Call Durations
2.5.1 Last call
2.5.2 Received calls
2.5.3 Dialled calls
2.5.4 All calls
2.6 Call Costs
2.6.1 Last Call’s Cost
2.6.2 All Call’s Cost
2.7 Cost Settings
2.7.1 Call Cost’s Limit
2.7.2 Set tariff
2.7.3 Auto Display
2.8 GPRS information
2.8.1 WAP
2.8.2 External Device
2.8.3 Total Data
39
Menu Tree
The following illustration shows the menu structure available
and indicates the:
▶Number assigned to each option.
▶Page on which you can find a description of each feature.
38
A Private Call in a Multiparty Call
To have a private call with one caller of a multiparty call,
display the number of the caller you wish to talk to on the
screen, then select left soft key and Multiparty/Private to put all
the other callers on hold.
Ending a Multiparty Call
The currently displayed caller of a multiparty call can be
disconnected by pressing the key. To end a multiparty call,
press left soft key then select Multiparty/End multiparty.
Selecting left soft key then Multiparty/End all, will end all the
active and held calls.
General functions
41
40
3. Profiles (see page 58)
3.1 Vibrate only
3.1.1 Activate
3.2 Silent
3.2.1 Activate
3.2.2 Personalize
3.2.3 Rename
3.3 General
3.3.1 Activate
3.3.2 Personalize
3.3.3 Rename
3.4 Loud
3.4.1 Activate
3.4.2 Personalize
3.4.3 Rename
3.5 Headset
3.5.1 Personalize
3.6 Car
3.6.1 Personalize
4 Settings (see page 60)
4.1 Alarm clock
4.2 Date & Time settings
4.2.1 Date & time
4.2.2 Auto update
4.3 Phone settings
4.3.1 Display settings
4.3.2 Power on sound
4.3.3 Languages
4.3.4 TTY
4.3.5 LED indicator
4. Settings (continued)
4.4 Call settings
4.4.1 Call divert
4.4.2 Answer mode
4.4.3 Send my number
4.4.4 Call waiting
4.4.5 Minute minder
4.4.6 Auto redial
4.4.7 Select line
4.4.8 Closed user group
4.5 Security settings
4.5.1 PIN code request
4.5.2 Call barring service
4.5.3 Fixed dial number
4.5.4 Change codes
4.6 Network settings
4.6.1 Automatic
4.6.2 Manual
4.6.3 Preferred
4.7 GPRS settings
4.7.1 Attach
4.7.2 External device
4.8 Reset settings
5. Organizer (see page 74)
5.1 Scheduler
5.2 Memo
5.3 Phone book
5.3.1 Search
5.3.2 Add new
5.3.3 Speed dials
5.3.4 Caller groups
5.3.5 Copy all
5.3.6 Delete all
5.3.7 Settings
5.3.8 Information
6. Fun & Tools (see page 85)
6.1 Games
6.1.1 Black Jack
6.2 My folder
6.2.1 Picture
6.2.2 Animation
6.2.3 Sound
6.3 Unit converter
6.4 Calculator
6.5 World time
7. Internet (see page 89)
7.1 Home
7.2 Push messages
7.2.1 Inbox
7.2.2 Receive
7.3 Profiles
7.4 Cache settings
7.4.1 Clear cache
7.4.2 Cache check
7.5 WAP information
7.6 Reset profiles
Menu TreeMenu Tree
*
*
*
*:Shown only if supported by CPHS
Text Messages
Your phone receives voice mail notification messages, and the
Short Message Service(SMS) messages.
Voice mail and SMS are network services. Please contact your
service provider for more information.
When the icon appears, you have received voice mail.
When the icon appears, you have received a new text
message. If the message memory is full, an error message is
displayed, the icon flashes and you cannot receive any new
messages. Use the Delete option in the Read Messages menu (1-
1-2) to delete obsolete messages. Once there is space in the
memory any undelivered SMS messages will be received
(provided sufficient space is available).
Write message
Via this menu, you can write and edit text messages of up to
about 918 characters.
1. Key in a message. For details on how to enter text, refer to
page 28(Entering Text).
2. After you complete the message, you can select the required
option, press the left soft key [Options].
The following options are available.
▶
Send to number:
Enter the phone number and select the
number from the phone book.
43
42
Messages
Menu 1.1
(Menu 1.1.1)
▶
Send to email:
Enter the email and select the email from
the phone book
▶
Save to draft:
Allows you to save the message so that it can
be sent later.
▶
Attach
(The following options are available.)
•
Symbol:
You can attach special characters.
•
Picture:
The phone allows you to send and receive text messages
that contain pictures.These messages are called ‘Picture
Messages’, several of which are preset in the phone and can be
replaced with new one received from other sources.
•
Animation:
Attaching an animation in a ,message can be done
through EMS(Enhanced Messaging Service).
You can select one of 15 animation in the phone.
•
Sound:
You can attach the Sounds that are available for short
message.
•
Text template:
You can use Text templates already set in the
phone.
•
Phone number:
You can add phone numbers.
•
Name card:
You can attach your name card.
▶
T9 languages:
For details on how to enter text, refer to
page 30(Using the T9 Mode). Choose between English and
Spanish.
▶
Clear text:
Allows you to deldte the writing message.
▶
Exit:
Allows you to exit in editor.
Messages
Inbox
Received text messages, page messages, and email lists may be
searched and the contents may be viewed.
Received messages are displayed from newest to oldest.
1. Press light soft key [Menu].
2. Press .
3. Select Inbox.
The following options are available.
▶
Reply:
Replies to the SMS with the original message
attached.
▶
Forward:
Forwards a received message to other recipients.
After recipients are entered, the message can be forwarded.
▶
Return call:
You can call back to the sender.
▶
Extract:
You can extract picture, sound, text webpage and
email address. They will be saved in My folder, phonebook
or bookmarks.
▶
Delete:
Deletes the selected message from the Inbox.
45
44
Outbox
You may view lists and contents of sent messages in this menu
and may also verify if the transmission was successful.
The following options are available.
▶
Forward:
You can forward the current message to other
recipients.
▶
Delete:
Deletes the selected message from the Outbox.
(Menu 1.1.2) (Menu 1.1.3)
Notice
Icon directive
[ ] Read SIM email
[ ] Unread SIM email
[ ] Read email
[ ] Unread email
[ ] Read SIM message
[ ] Unread SIM message
[ ] Read message
[ ] Unread message
[ ] Read delivery report
[ ] Unread delivery report
Notice
Icon directive
[ ] Sent SIM email
[ ] Sent email
[ ] Sent SIM message
[ ] Sent message
MessagesMessages
Draft
Using this menu, you can preset that you use most frequently.
This menu shows the preset message list. Scroll through the list
using the Up/Down navigation keys. When the required
message number appears, press the left soft key [Options].
The following options are available.
▶
Forward:
Allows you to forward the current message to
other recipients.
▶
Delete:
Allows you to delete the selected preset message.
(Menu 1.1.4)
47
46
MessagesMessages
Settings
Via this menu, you can set up default SMS information.
▶
Message types:
Allows you to set the default message
type (Text, Voice, Fax, Paging, X.400, E-mail, ERMES). The
network can convert the messages into the selected format.
TheThe type of message you desire can be set to Text type.
▶
Validity period:
Allows you to set the length of time for
which your text messages will be stored at the SMS center
while attempts are made to deliver them to the recipient.
Possible values are 1 hour, 12 hours, 1 day, 1 week and the
maximum authorized by your service provider.
▶
Delivery reports:
Allows you to activate or deactivate the
report function. When this function is activated, the network
informs you whether or not your message has been delivered.
▶
Reply with same service:
Allows the recipient of your
SMS message to send you a reply via your message center, if
the service is provided by the network.
▶
Message center number:
Allows you to store or change
the number of your SMS center required when sending text
messages. You must obtain this number from your service
provider.
▶
Email gateway:
Allows you to store or change the number
of your SMS center required when sending text messages.
▶
Subject:
If you set it to on, allows you to enter the subject.
▶
Bearer setting:
Select Dual, GPRS and GSM. For settings
for the selected bearer.
For pricing, connection speed and other information, contact your
network operator or service provider.
Dual/GPRS Only/GSM Only
(Menu 1.1.5)
(Menu 1.2.1)
(Menu 1.2.2)
Voice Messages
This menu provides you with a quick way of accessing your
voice mailbox (if provided by your network).
Before using this feature, you must enter the voice server
number obtained from your service provider.
Listen to voice mail
You can then select this option and simply press the left soft key
[Ok] to listen to your messages.
Voice mailbox number
You can get the voicemail if this feature is supported by the
network service provider.When new voicemail is arrived, the
symbol will be displayed on the screen. Please check with your
network service provider for details of their service in order to
configure the handset accordigly.
1. Hold down key in standby mode.
2. You can check the following submenus.
Menu 1.2
49
48
MessagesMessages
Info service
(Dependent to network and subscription)
Info service messages are text messages by the network to GSM
phone users. They provide general information such as weather
reports, traffic news, taxis, pharmacies, and stock prices. Each
type of information has the number; therefore, you can contact
service provider, as long as you have input the certain number
for the information. When you have received an info service
message, you can see the popup message to show you that you
have received a message or the info service message is directly
displayed. To view the message again or not in the standby
mode, follow the sequence as shown below;
Receive
Allows you to enable or disable the reception of broadcast
messages.
Inbox
Received broadcast messages lists may be searched and
contents may be viewed.
Topics
(Dependent to network and subscription)
If you want to create new topics, press left soft key[OK]. Then,
you select new topics menu by left soft key[Options].
If you have already topics, you can activate, edit, delete and add
new by pressing left soft key[Ok].
Menu 1.3
(Menu 1.3.1)
(Menu 1.3.2)
(Menu 1.3.3)
Alert
Allows you to select the alert type for a new message.
Auto Display
Allows you to receive broadcast message, it is automatically
displayed on the window. Scroll through the message using
Up/Down navigation keys.
Language
(Dependent to network and subscription)
Allows you to select the language you want. Then, the cell
broadcast message will be displayed in the language that you
selected. If you use all languages supported by phone, select
“Automatic”at the bottom of the list.
(Menu 1.3.5)
(Menu 1.3.4)
(Menu 1.3.6)
51
50
MessagesMessages
Templates
There are 10 predefined messages in the list. You can view and
edit the template messages or create new messages in the open
<Empty> slots.
•
Please call me back
•
I’m late. I will be there at
•
Where are you now?
•
I am on the way
•
Top urgent. Please contact
•
I love you
The following options are available.
▶
Edit:
Allows you to write a new message or edit the selected
template message.
▶
Delete:
Allows you to delete the selected template message.
▶
Send:
Allows you to call the selected template message.
▶
Add new:
Allows you to create new messages in the open
<Empty> slots.
Name card
You can make your name card. Key in Name, Phone number,
Office number,Fax number and email.
▶
Edit:
Allows you to write a new message or edit the selected
template message.
▶
Delete:
Allows you to delete the selected template message.
▶
Send:
Allows you to call the selected template message.
Menu 1.4
Menu 1.5
Check memory
You can check how many free location remain are stored in the
phonebook (card and phone memories), two options are
available : Text
Text
In this menu, you can view how many text messages
downloaded from the server.
Menu 1.6
(Menu 1.6.1)
53
52
Call Register
(Dependent on the network service)
You can check the record of missed, received, and dialled calls
only if the network supports the Calling Line Identification
(CLI) within the service area.
The number and name (if available) are displayed together with
the date and time at which the call was made. You can also view
call times and costs.
Missed Calls
This option lets you view the last 10 unanswered calls. You can
also:
•View the number if available and call it or save it in the
phonebook
• Enter new name for the number and save both in the
phonebook
• Send a message by this number
• Delete the call from the list
• Delete all missed calls from the list
Menu 2.1
Call Register
Received Calls
This option lets you view the last 10 incoming calls. You can also:
• View the number if available and call it or save it in the
phonebook
• Enter new name for the number and save both in the phonebook
• Send a message by this number
• Delete the call from the list
• Delete all incoming calls from the list
Menu 2.2
Dialed Calls
This option lets you view the last 10 outgoing calls(called or
attempted). You can also:
• View the number if available and call it or save it in the
phonebook
• Enter new name for the number and save both in the
phonebook
• Send a message by this number
• Delete the call from the list
• Delete all incoming calls from the list
Menu 2.3
55
54
Call RegisterCall Register
Call durations
Allows you to view the duration of your incoming and outgoing
calls. You can also reset the call times.
The following timers are available.
Last Call
Length of the last call.
Received Calls
Length of the incoming calls.
Dialed Calls
Length of the outgoing calls.
All Calls
Total length of all calls made and incoming calls since the timer
was last reset.
Menu 2.5
Notice
The actual time invoiced for calls by your service
provider may vary, depending upon network
features, rounding-off for billing, and so forth.
Delete recent calls
Allows you to delete Missed, Received and Dialed call list. You
can delete all call lists at a time.
Menu 2.4 Call costs (Network Service)
Call costs allows you to check the cost of the last call or all
calls. The call costs are displayed separately for each SIM card.
To reset the cost, you need to PIN2 code.
The following options are available.
Last Call’s Cost
Cost of the last call made.
All Call’s Cost
Total cost of all calls made since the costcounter was last reset.
If the total cost exceeds the maximum cost set, you will no
longer be able to make any calls, except calls to the emergency
services, until you reset the counter.
Notice
The actual cost invoiced for calls by your service
provider may vary, depending upon network
features, rounding-off for billing, tax, and etc.
Menu 2.6
(Menu 2.5.1)
(Menu 2.6.1)
(Menu 2.6.2)
(Menu 2.5.2)
(Menu 2.5.3)
(Menu 2.5.4)
57
56
Call RegisterCall Register
Cost Settings(SIM Dependent)
Call cost’s limit
This network service allows you to limit the cost of your calls by
selected charging units. If you select Read, the number of
remaining unit is shown. If you select Change, you can change
your charge limit.
Set tariff
You can set the currency type and the unit price. Contact your
service providers to obtain charging unit prices. To select the
currency or unit in this menu, you need the PIN2 code.
Auto display
This network service allows you to see automatically the cost of
your last calls. If you select Yes in Auto display menu, you can
see the last cost when the call is released.
Note
When all units have been used, no calls can be
made except emergency calls. Depending on the
SIM card, you need the PIN2 code to set a call cost
limit.
Menu 2.7 GPRS information
You can check the amount of data transferred over the network
through GPRS. In addition, you can also view how much time
you are online.
WAP
GPRS call duration scroll to check the duration of the last
GPRS connection or the total GPRS connection.
You can also clear the timers. To clear the timers, the security
code is needed.
External device
GPRS data volume and scroll to check the amounts of sent and
received data in last session, datasent and received in total, and
to clear the counters. The counters units is a byte. To clear the
counters,the security code is needed.
Total data
GPRS data volume and scroll to check the amounts of sent and
received data in last session, datasent and received in total, and
to clear the counters. The counters units is a byte. To clear the
counters,the security code is needed.
Menu 2.8
(Menu 2.8.1)
(Menu 2.8.2)
(Menu 2.8.3)
(Menu 2.7.1)
(Menu 2.7.2)
(Menu 2.7.3)
Notice GPRS
General Packet Radio Service
59
58
In Profiles, you can adjust and customize the phone tones for
different events, environments, or caller groups.
There are five preset profiles: Vibrate Only, Silent, General,
Loud, Headset and Car. Silent, General and Loud which you
can customize to meet your needs.
Changing the profile
1. A list of profiles opens.
2. In the Profiles list, scroll to a profile and select “Activate”.
Customizing profiles (Personalize)
1. To modify a profile, scroll to the profile in the Profiles list
and select “Personalize”. A list of profile settings opens.
2. Scroll to the setting you want to change and press the
Up/Down navigation key to open the choices:
• Incoming call alert:
• Ringing tone:
To set the ringing tone for voice calls,
choose a ringing tone from the list. When you scroll through
the list, you can stop on a tone to listen to it before you make
your selection. Press any key to stop the sound.
• Ringing volume:
To set the volume level for the ringing
tones.
• Message alert type:
To set the type for messages.
• Message alert tone:
To set the tone for messages.
• Key volume:
To set the volume level for keypad tones.
Profiles
• Automatic answer:
This function will be activated only
when your phone is connected to the handsfree kit or headset.
The following options are available
Off: The phone will not answer automatically.
After 5 sec: After 5 seconds, the phone will answer
automatically.
After 10 sec: After 10 seconds, the phone will answer
automatically.
Customizing profiles (Rename)
1. To modify a profile, scroll to the profile in the Profiles list
and select “Rename”.
2. You can rename a profile and give it any name you want. The
Vibrate Only, Headset and Car profile cannot be renamed.
Profiles
61
60
Settings
Alarm Clock
Set the alarm to ring at a specific time. In the Alarm Clock
menu, the following options are available.
The following options are available.
On:
Set the time(hour and minute) for activating the alarm.
1. Enter the menu.
2. Select [On] by pressing Right/Left navigation keys.
3. If you want to set the time for activating the alarm, press
Up/Down navigation keys.
• Once:
The alarm rings only once and is then deactivated.
• Daily:
The alarm rings every day at the same time.
• Weekly:
The alarm rings every week on the same day and at
the same time.
• Monthly:
The alarm rings every month on the same day and
at the same time.
Off:
Disabling the alarm.
Menu 4.1 Date & Time settings
Date & Time
This oprions allows you to change the current time and date
displayed.
The following options are available.
▶
Set date:
Allows you to enter the day, month and year. You
can change the date format via the Date format menu
option.
Format : Allows you to change the time and date formats.
▶
Date format
YYYY/MM/DD(year/month/day)
DD/MM/YYYY(day/month/year)
MM/DD/YYYY(month/day/year)
▶
Set time:
Allows you to enter the current time. You can
choose the time format via the Time format menu option.
▶
Time format
24 hours/12 hours
Auto update
To set the phone to automatically update the time and date
according to the current time zone, select on.
(Menu 4.2.1)
(Menu 4.2.2)
Menu 4.2
Settings
63
62
Phone Settings
Many different feature of your phone can be customized to suit
your preferences. All of these features are accessed via the
Phone Settings menu.
Display settings
▶
Wallpaper:
You can set up the screen displayed on the
LCD screen in the standby mode.
Power on sound
▶
Backlight:
You can select whether or not the phone uses
the backlight. A marginal increase in stabdby/talk time can
be achieved by turning the backlight off.
▶
Contrasts:
This option allows you to adjust the contrast of
the LCD screen by pressing the Navigatio key.
Language
You can select a display language. When the language option is
set to Automatic, the language is automatically selected
according to the language of the SIM card used. English will be
set if the language on the SIM card is not supported in the
phone.
(Menu 4.3.1)
(Menu 4.3.2)
(Menu 4.3.3)
Menu 4.3 TTY
The majority of users are Deaf, but commonly, a TTY is also
used by Hard of Hearing, Speech Impaired, and even Deaf and
Blind individuals. When you use a TTY, only one person can
type at a time, and you should not interrupt the other. Keep your
sentences short and right to the point. If at all possible, have a
printer to facilitate your life. Try to avoid asking too many
questions at once.
(Menu 4.3.4)
LED indicator
This option allows you to select whether or not the service light
on the top of the phone is used.
The following options are available.
▶
Enable:
The service light flashes when the phone is ready
for use.
▶
Disable:
The service light is not used
(Menu 4.3.5)
Note
TTY users must have a TTY/TDD device.
TTY : Tele Typewriter
TDD : Telecommunication Device for the Deaf
SettingsSettings
65
64
Call settings
To change the settings for call diverting.
Call divert
When this network service is activated, you can direct your
incoming calls to another number, for example, to your voice
mailbox number. For details, contact your service provider.
Select one of the divert options, for example, select If busy to
divert voice calls when your number is busy or when you reject
incoming calls.
The following options are available.
▶
All voice calls:
Diverts voice calls unconditionally.
• Activte:
Activating the corresponding service.
- To voice mail centre: Forwards to message centre. This
function does not include All data calls and All fax calls
menus.
- To other number: Inputs the number for diverting.
- To favourite number: You can check 5 diverted numbers.
▶
If busy:
Diverts voice calls when the phone is in use.
▶
If no reply:
Diverts voice calls which you do not answer.
▶
If out of reach:
Diverts voice calls when the phone is
switched off or out of coverage.
▶
All data calls:
Diverts to a number with a PC connection
unconditionally.
Menu 4.4
(Menu 4.4.1)
▶
All fax calls:
Diverts to a number with a fax connection
unconditionally.
▶
Cancel all:
Cancels all call divert service.
Answer mode
Allows you to determine when to answer the phone.
▶
Folder open:
This option allows you to answer a call
simply by opening the flip. Select Yes, to answer a call, you
simply open the flip. Select No, to answer a call, you must
open the flip and press a key, depending on the setting of the
Any key or Only send key menu option.
▶
Any key:
Select Yes, and you can answer an incoming call
by briefly pressing any key, except key.
▶
Only send key:
You can receive a call by only pressing
key.
Send my number
This network service allows you to set your phone number to be
displayed (On) or hidden (Off) from the person to whom you
are calling. Select by network to reset the phone to the setting
that you have agreed upon with your service provider.
Call waiting (Network Service)
The network will notify you of a new incoming call while you
have a call in progress. Select Activate to request the network
to activate call waiting, Cancel to request the network to
deactivate call waiting, or Check status, to check if the function
is active or not.
(Menu 4.4.2)
SettingsSettings
(Menu 4.4.3)
(Menu 4.4.4)
67
66
Minute minder
This option allows you to specify whether the phone must beep
every minute during an outgoing call to keep you informed of
the length of your call.
Automatic redial
Select On, and your phone will make a maximum of three
attempts to connect the call after an unsuccessful call attempt.
Select Line (Network service)
This setting is shown only if the SIM card supports two
subscriber numbers, that is, two phone lines. Select which
phone line (Line 1 or Line 2) you want to use for making calls
and sending short messages. Calls on both lines can be
answered irrespective of the selected line.
(Menu 4.4.5)
(Menu 4.4.6)
(Menu 4.4.7)
Note
You will not be able to make calls if you select Line
2 and have not subscribed to this network service.
SettingsSettings
Closed user group (Network service)
Closed uesr group is a network service that specifies the group
of people whom you can call and who can call you. For more
information contact your network operator or service provider.
If a group index is specified, it is used for all outgoing calls. If
no group index is specified, the network will use the preferential
index (a specific index that is stored in the network).
▶
On:
Activating and editing the CUG Index.
▶
Off:
Deleting the selected CUG.
▶
Dafault:
Setting the selected CUG Index.
(Menu 4.4.8)
69
68
Security settings
Various codes and passwords are used to protect the features of
your phone. They are described in the following sections (see
pages 24 ~ 25).
PIN Code Request
When the PIN code request feature is enabled, you must enter
your PIN each time you switch the phone on.Consequently, any
person who does not have your PIN cannot use your phone
without your approval.
The following options are available:
• Enable:
You must enter the PIN each time the phone is
switched on.
• Disable:
The phone connects directly to the network when you
switch it on.
Call barring service (Network dependent)
Call barring allows you to restrict the making and receiving of
calls with your phone. For this function, you need the barring
password, which you can obtain from your service provider.
The following options are available:
▶
All outgoing calls:
Calls cannot be made.
▶
Outgoing international:
International calls cannot be
made.
Menu 4.5
(Menu 4.5.1)
(Menu 4.5.2)
Note
Before disabling the PIN code request feature, you
must enter your PIN.
SettingsSettings
▶
Outgoing international when roam:
When abroad,
calls can be made only to numbers within the current country
and to your home country, that is the country where your
home network provider is located.
▶
Incoming calls:
Calls cannot be received.
▶
Incoming when roam:
Calls cannot be received when
you are using your phone outside your home service area.
▶
Cancel all barrings:
All call barring settings are
deactivated; calls can be made and received normally.
▶
Barring password:
You can set and change the call
barring password obtained from your service provider using
this option. You must enter the current password before you
can specify a new one.Once you have entered a new
password, you are asked to confirm it by entering it again.
Note
To use Call barring service, you must input the
network password. When calls are barred, calls
may be possible to certain emergency numbers in
some networks.
71
70
Note
PIN: Personal Identification Number.
SettingsSettings
Fixed dial number(FDN) (SIM dependent)
Allows you to restrict your outgoing calls to selected phone
numbers, if this function is supported by your SIM card. The
PIN2 code is required.
The following options are available:
▶
Activate:
You can only call phone numbers stored in the
phonebook. You must enter your PIN2.
▶
Cancel:
You can call any number.
▶
Number list:
You can view the number list saved as fixed
dial number.
Change codes
The Change codes feature allows you to change your current
password to a new one. You must enter the current password
before you can specify a new one.
You can change the access codes: Security code, PIN1 code,
PIN2 code.
(Menu 4.5.3)
(Menu 4.5.4)
Note
Not all SIM cards have a PIN2. If your SIM card
does not, this menu option is not displayed.
Network settings
The Network Settings feature enables you to indicate whether
the network used when roaming(outside your home area) is
selected automatically or manually.
Automatic
Allows you to set the phone to automatically search for and
select one of the cellular networks available in your area.
The phone will be set to Automatic even though the power is
off and on.
Manual
If you want to select the desired network manually from a list of
network. If the connection to the manually selected network is
lost, the phone will sound an error tone and ask you to select a
network again. The selected network must have a roaming
agreement with your home network, that is, the operator whose
SIM card is in your phone. The phone let you select another
network if the phone fails to access the selected network. If you
switch off the phone, the phone will be reset to Automatic.
Preferred
You can set a list of preferred networks the handset should
attempt to register with first, before attempting to register to any
other networks. This list is created from the handset’s
predefined list of known networks.
Menu 4.6
(Menu 4.6.1)
(Menu 4.6.2)
(Menu 4.6.3)
Note
You can select a network other than your home
network only if it has a valid roaming agreement
with your home network.
73
72
GPRS settings
GPRS(General Packet Radio Service) is a technology that
allows mobile phones to be used for sending and receiving data
over the mobile network. GPRS is a data bearer that enables
wireless access to data network such as the internet.
The applications which use GPRS are WAP, MMS and SMS
messages.
Before you can use GPRS technology
•
You need to subscribe to the GPRS service. For availability
and subscription to GPRS service, contact your network
operator or service provider.
•
You need to save the GPRS settings for the applications used
over GPRS.
Fees for GPRS and applications:
Both the active GPRS connection and the applications used over
GPRS, for example WAP service, sending and receiving data
and SMS messages, require a fee. For more detailed information
on fees, contact your network operator or service provider.
Attach
If you select Power on and you are in a network that supports
packet data, the phone registers to the GPRS network and
sending short messages will be done via GPRS. Also, starting
an active packet data connection, for example, to send and
receive e-mail, is uicker. If you select When needed, the phone
Menu 4.7
(Menu 4.7.1)
SettingsSettings
will use a packet data connection only if you start an application
or action that needs it. The GPRS connection is closed after it is
not used by any application.
External device
When you use Internet via GPRS by using external device, you
can set APN, IP address, DNS, User ID, and Password as to 5
profiles. Otherwise, you may be differed those information by
network.
(Menu 4.7.2)
Note
If there is no GPRS coverage and you have chosen
Automatic, the phone will periodically try to
establish a packet data connection.
Reset settings
You can easily reset your phone to its default configuration. To
do so, proceed, as follows.
1. Select the Reset Settings menu option.
2. Enter the 4-digit phone password.
Menu 4.8
Note
The password is preset to 0000.
To change this password, refer to page 70
Organizer
75
74
Schedule
When you enter this menu a Calendar will show up. On top of
the screen there are sections for date. Also on bottom of the
screen there are sections for icons (schedule, memo). Whenever
you change the date, the calendar will be updated according to
the date. And square cursor will be used to locate the certain
day. If you see under bar on the calendar, it means that there is a
schedule or memo that day. This function helps to remind you
of your schedule and memo. The phone will sound an alarm
tone if you set this for the note.
For changing the day, month, and year.
Menu 5.1
Note
Your phone should be switched on to use this
function.
Key Description
Up/Down Navigation key
Left/Right Navigation key
Weekly
Daily
• View
Shows the note for the chosen day. Use Up/Down navigation
key to browse through the note lists. If you set alarm for the
note, Alarm watch is displayed. At that time, if you press
[Select], you can see the note in detail. Press [Options] to
delete, edit the note you selected.
• Edit
Allows you to edit the schedule.
• Delete
Allows you to delete the schedule.
• Add new
You can edit maximum 39 characters and take up to 20 notes.
• Calendar
Allows you to cunsult the calendar.
• Scheduler tone
The phone can sound an alarm tone when the set date for an
event is reached, if you have set an alarm for the note.
• View all Schedules
Shows the notes that are set for all days. Use Up/Down
navigation key to browse through the note lists. You can use
the same menu as “View” by pressing [Options].
• Go to Date
Allows you to jump to a specific date.
• Delete past
You can delete for the past schedule already is notified you.
• Delete all
Allows you to delete all schedules. You are asked to confirm
your action.
Organizer
77
76
Memo
To write, edit and delete a memo on a specific date, proceed as
follows.
1. Scroll to highlight Memo.
2. Press left soft key [Add].
3. Input the memo and then press left soft key [Options].
The following options are available.
▶
Save:
Allows you to save the memo.
▶
T9 languages:
Allows you to select the T9 language to
use in memo.
▶
Exit editor:
Allows you to exit in memo editor.
Or
1. Select a Memo.
2. Press left soft key [Select].
3. Press left soft key [Options].
The following options are available.
▶
Edit:
If you select a day for which a memo already exists,
you can press the left soft key [Options →Edit] to edit the
memo displayed.
▶
Delete:
Allows you to delete the memo. You can press the
left soft key [Options →Delete] to edit the memo displayed.
▶
Add New:
Add a new memo, up to 20 memos and 40
characters per each memo.
▶
Delete All:
Allows you to delete all memos. You are asked
to confirm your action.
Menu 5.2
OrganizerOrganizer
Phonebook
You can store phone numbers and their corresponding names in
the memory of your SIM card. In addition, you can store up to
255 numbers and names in the phone memory. The SIM card
and phone memories, although physically separate, are used as
if they were a single entity, called the phonebook.
1. To use Phonebook, press [Names] in the standby mode.
2. To use Phonebook, press [Menu] in the standby mode and
select Organiser.
Search (Calling from phonebook)
1. When the idle screen is displayed, press right soft key
[Names]. You are asked to enter a name.
2. Enter the start of the name that you wish to find and press
left soft key [Search].
3. If you want to edit, delete, copy an entry, or to add the voice
to one, select [Options]. The following menu will be
displayed.
Menu 5.3
(Menu 5.3.1)
Note
To use Phonebook, press right soft key [Names] in
standby mode. Or, press left soft key [Menu], , .
Note
You can also scroll through the phonebook from
the beginning, by pressing the right soft key
[Search] directly.
5 3
79
78
4. Once you have found the required entry, press to dial the
number.
• View detail: To view detail the selected a name.
• Edit: You can edit the name, number, E-mail and fax by
pressing [OK].
• Delete: You can delete an entry.
• Call: To call by chosen entry.
• Write message: Write text message/write multimedia message.
• Copy: You can copy an entry from SIM to phone or from
phone to SIM.
• Voice: You can add the voice to the entry or change the voice
tag.
• Main number: You can select the one out of mobile, home,
office that you often use. The main number will be displayed
first, if you set this.
OrganizerOrganizer
Add New
You can add phonebook entry by using this function. Phone
memory capacity is 255 entries. SIM card memory capacity
depends on the cellular service provider. You can also save 20
characters of name in the Phone memory, and save characters in
the SIM card. The number of character is SIM dependent
feature.
1. Open the phonebook first by pressing right soft key [Names]
in standby mode.
2. Scroll to highlight Add new, and press left soft key [Ok].
3. Select the memory you want to save: SIM or Phone.
a. Enter a name and then press down navigation key.
b. Enter a number and then press down navigation key.
c. You can set a group for the entry by pressing Left/Right
navigation key.
e. Press left soft key [Ok].
You should speak words within 2 seconds, and the phone asks
you to speak it again to ensure the accuracy of voice
recognition. After voice recognition has finished, voice is
attached automatically.
(Menu 5.3.2)
81
80
Note
The voice can only be attached to the main number
which you set. For example, if you change the main
number, voice will be automatically attached to the
changed number. This means that you cannot attach
voice to mobile, office, home number simultaneously.
You can add voice tag to phone number in SIM card. The
voice tag can be erased if you remove or change SIM
card.
Speed Dials
You can assign any of the keys, to with a Name list entry.
You can call directly by pressing this key for 2-3 seconds.
1. Open the phonebook first by pressing [Names] in a standby
mode.
2. Scroll to Speed dial, then press left soft key [Ok].
3. If you want to add Speed dial, select (Empty). Then, you can
search the name in phonebook.
4. Select allocated a name by speed dial, and choose Change or
Delete to edit the name.
(Menu 5.3.3)
OrganizerOrganizer
Caller Groups
There are 6 predefined groups as well as one additional group
labeled Others where you can create the lists under.
1. You can set the phone to ring in a specific way and display a
preselected graphic icon when a particular person calls you.
2. Scroll to Caller Group item then press left soft key [OK] to
enter this menu.
3. Every Group list will be displayed : Family, VIP, Friends,
Colleague, Group 1, Group 2, Others.
4. Select Group name that you want to manage by pressing
left soft key [Options].
5. Then submenus below will be displayed except Others.
• Member list:
Allows you to see the member list in the group.
• Group ring tone:
Allows you to select the ring tone to be
used when you receive a voice phone call from a person in the
group.
• Group icon:
Allows you to select the graphic icon to be
displayed when you receive a call from a person in the group.
• Add member:
Allows you to add the member to the group.
• Delete member:
Allows you to delete the member in the
group.
• Rename:
Allows you to assign a name to the group.
(Menu 5.3.4)
2 9
83
82
Copy all
You can copy/move entries from SIM card memory to Phone
memory and vice versa.
▶
SIM to Phone:
You can copy the entry from SIM Card to
Phone memory.
▶
Phone to SIM:
You can copy the entry from Phone
memory to SIM Card.
The following options are available.
• Keep original: When copying, Original Dial Number is kept.
• Delete original: When copying, Original Dial Number will
be erased.
(Menu 5.3.5)
OrganizerOrganizer
Delete all
You can delete all entries in SIM, Phone, and Voice list. This
function requires Security code except for voice.
Press to return to the in standby mode.
Settings
1. Set memory: Scroll to highlight Set memory, then press left
soft key [OK].
2. Search by: Scroll to highlight Search by, then press left soft
key [Ok].
▶
Set memory:
Scroll to highlight Set memory, then press
left
soft key
.
• If you select Variable, when adding entry, the phone will ask
where to store.
• If you select SIM or Phone, the phone will store an entry to
SIM or phone.
▶
Search by:
Scroll to highlight Search by, then press left
soft key [Ok].
• If you select Variable, the phone will ask how to search.
• If you select Name or Number, the phone will search an entry
by Name or Number.
(Menu 5.3.6)
(Menu 5.3.7)
85
84
Information
▶
Service dial Number:
You can view the list of Service
Dialing Numbers (SDN) assigned by your network
provider(If supported by the SIM card). Such numbers
include the emergency, directory enquiries and voice mail
numbers.
1. Select the Service dial number option.
2. The names of the available services will be shown.
3. Use Up/Down navigation key to select a service. Press
▶
Memory status:
You can check how many names and
numbers are stored in the phonebook (card and phone
memories).
1. Select the Memory status option.
2. You can see memory status.
▶
Own number (SIM dependent):
Allows you to display
your phone number in SIM card.
(Menu 5.3.8)
Organizer Fun & Tools
Game
Black Jack
You have selected the game, the following options are available.
The control keys are different depending on a game. However,
each one has an introduction to explain the main control keys.
The rest ones are as follows.
New game:
Allows you to start a game.
High score:
Enables you to view the highest score recorded for
the selected game.
Instruction:
To select a help text on how to play the game.
Key Info:
Describes the buttons used by the game.
Continue:
Allows you to continue play a game.
Note
The control keys are different depending on a
game. However, each one has an introduction to
explain the main control keys. The rest ones are as
follows.
Menu 6.1
(Menu 6.1.1)
87
86
Fun & Tools
Animation
1. Send Via test message
2. Edit title
3. Delete
4. Delete all
Sound
1. Edit title
2. Delete
3. Delete all
Send:
You can send the title for each download contents.
Edit title:
You can edit the title for each download content.
Delete:
You can delete each download content.
Delete all:
You can delete all download contents.
(Menu 6.2.2)
(Menu 6.2.3)
My folder
Enables you to download pictures or sounds which can be used
as Wallpaper or Ringtone. You can view, listen, delete or
rename downloaded data.
In the My folder menu, the following options are available.
Pictures
1. Edit title
2. Delete
3. Delete all
Menu 6.2
(Menu 6.2.1)
Fun & Tools
Unit converter
This converts any measurement into a unit you want.
1. You can select one of four unit types by pressing left soft key
[Options].
2. Select the standard value by using left/right navigation keys.
3. Select the unit you want to convert by pressing up/down
navigation keys.
4. You can check the converted value for the unit you want. Also,
you can input the prime number by pressing .
Menu 6.3
Calculator
Using this feature, you can use the phone as a calculator. The
calculator provides the basic arithmetic functions: addition,
subtraction, multiplication and division(Can enter numbers up
to the second decimal place).
Using the Calculator
1. Enter the first number using the numeric keys.
2. Use a navigation key to select a sign for calculation.
3. To calculate the result, press left soft key [Result].
Menu 6.4
Note
To include a decimal point, press the key.
89
88
World time
Allows you to check the current time for Greenwich Mean Time
(GMT) and 61 major cities around the world, using the left/right
navigation keys.
The screen shows the City name, Current date and time.
To select the time zone in which you are located, proceed as
follows:
1. Select the city corresponding to your time zone by pressing the
Left/Right navigation keys one or more times. The local date
and time are displayed.
2. Press the left soft key [Set].
Menu 6.5
Fun & Tools Internet
You can access various WAP(Wireless Application Protocol)
services such as banking, news, weather reports and flight
times. These services are specially designed for mobile phones
and they are maintained by WAP service providers.
Check the availability of WAP services, pricing and tariffs with
your network operator and/or the service provider whose
service you wish to use. Service providers will also give you
instructions on how to use their services.
Please contact your service provider to open your internet
account. To use the Web Browser, you must indicate your phone
number via the Own Number menu option (Menu 5.3.9.2).
To launch the browser in standby mode, press hold down
key.
Once connected, the homepage is displayed. The content
depends on the service provider.
You can open any WWW page by entering its URL address.
To exit the browser at any time, press the key. The idle
screen is displayed.
Navigating with the WAP Browser
You can surf the Internet using either the phone keys or the
WAP Browser menu.
Using the Phone Keys
When surfing the Internet, the phone keys function differently
from the phone mode.
Key Description
up/down navigation key Scroll each line of the content area
left navigation key Return to the previous page
무슨버튼인지?Return to the startup homepage
(위에서 key는key 그림을 글 옆에 처리할 것임)
Using the WAP Browser Menu
There are various menu options available when surfing the
Wireless Web.
91
90
Note
The WAP Browser menus may vary, depending on
your version of the browser.
Home
Connect to a homepage. The homepage may be the site which is
defined in the activated profile. It will be defined by Service
Provider if you do not make in activated profile.
Menu 7.1
WAP ServicesWAP Services
Menu 7.2
Push messages
Inbox
You can order Push messages from WAP service providers.
Push messages are notifications of, for example, news headlines
and they may contain a text message or address of a WAP
service. For availability and subscription, contact your WAP
service provider.
Service providers can update an existing Push message every
time a new Push message is received. Messages can be updated
even if you have moved them to another folder than Inbox. Push
messages expire, they are deleted automatically.
•
Information
: Show the information of received push
messages.
• Load: Allow you connect to a specific site using the
information in the received push message.
• Delete: Delete the selected push message.
Receive
You can set the option whether you will receive the message or not.
(Menu 7.2.1)
(Menu 7.2.2)
93
92
Profiles
You can make up to 10 profiles and activate only one out of
them. Scroll to desired profile and press left navigation key to
access available options.
▶
Activate:
You can activate the profile you want.
▶
Settings:
You can edit and change WAP settings of the
selected profile.
• Homepage
:
This setting allows you to enter the address
(URL) of a site you want to use as homepage. You do not
need to type “http://” at the front of each URL as the WAP
Browser will automatically add it.
• Display image:
You can select whether images on WAP
cards are displayed or not.
- Yes: Images are displayed.
- No: Images are not displayed.
• Connect type :
The options for connection type are
Temporary or Continuous and depend on the gateway you are
using.
- Continuous: A confirmed delivery mechanism but generates
more network traffic.
- Temporary: A non-confirmed (connectionless) service.
Menu 7.4
WAP ServicesWAP Services
• Secure settings:
According to the used gateway port, you
can choose this option as On or Off.
- Secure: Secure option is On.
- None: Secure option is Off.
▶
Rename:
Edit the Profile Name.
▶
E-mail server
• Connect :
Connect to the E-mail server that you configured.
• Edit address :
Edit the E-mail address.
95
94
WAP Services
Cache settings
The information or services you have accessed are stored in the
cache memory of the phone.
Clear cache
If you have tried to access or have accessed confidential
information requiring passwords (for example, your bank
account), empty the cache of your phone after each use.
Check cache
You can change the time for checking the Cache memory.
WAP information
The WAP Browser version is displayed.
Reset profiles
You can reset profiles to return to original settings.
Menu 7.4
Menu 7.6
Menu 7.5
(Menu 7.4.1)
(Menu 7.4.2)
Note
A cache is a buffer memory, which is used to store
data temporarily.
Q&A
Please check to see if any problem which you may have with
your phone is described here before taking it for service or
calling a service engineer.
Q
How do I view the list of outgoing calls, incoming calls and
missed calls?
A
Press [Send].
Q
How do I clear all call history?
A
Press left soft key and then .
Q
How do I view all numbers stored in memory?
A
Press right soft key and then , .
Q
When does not disappear from the screen.
A
Check whether it is service area, and if you continue to see
“☎”
please turn off the power and wait for approximately 2
minutes to turn it back on. If there is no change, check again
after relocating to other areas.
Q
When connection is abrupt or is not audible in certain areas.
A
When frequency environments is unstable in a certain area,
connection may be abrupt and not audible. Relocate to other
areas and try again.
Q
When connection is not made well or abrupt even when
established.
244
3 1
97
96
A
When frequency is unstable or weak, or if there are too many
users, connection may be cut off even after it was
established. Please try again a little later or try after
relocating to other areas.
Q
When LCD does not turn on.
A
Remove battery and turn on the power after placing it back
on. If there is no change even then, sufficiently charge the
battery and try again.
Q
: When it echoes while connection is made with a certain
telephone in a certain area.
A
Called
“Echo Phenomenon”
, it occurs if connection volume
is too high or caused by special properties(semi electronic
telephone exchange) of the machine on the other end.
Q
When the phone is heated.
A
If connection is made for a significantly long duration, or
game and Internet and others are used for a long time, the
phone may become hot. This has no effect upon the life of
the product or performance.
Q
When the bell does not ring, or when lamp or LCD blinks
only.
A
May be set as
“Vibrate”
or
“Quiet”
in the Profiles menu.
Please select
“General”
or
“Loud”
Q&AQ&A
Q
Standby duration for battery gradually becomes shorter.
A
Because battery wear out, its life gradually becomes shorter.
If its life becomes shorter over half of that at the time of
purchase, you must purchase a new one.
Q
When usage time of battery becomes shorter.
A
If time for use of battery is short, it may be due to the user
environment, or large volume of calls, or weak signals.
Q
No number is dialed when you recall a phonebook entry.
A
Check that the number have been stored correctly, by using
the Phone book Search feature. Re-store them, if necessary.
Q
Your correspondent cannot reach you.
A
Is you phone switched on ( pressed for more than three
seconds)? Are you accessing the right cellular network? Or,
you may have set an incoming call barring option.
Q
I cannot find the lock, PIN, or PUK code. What is my
password?
A
The default lock code is
“0000”
. If you forget or lose the
lock code contact your phone dealer. If you forget or lose a
PIN or PUK code, or if you have not received such a code,
contact your network service provider
99
98
Travel Adapter
This adapter, model ??-??, allows you to charge
the battery. It supports standard U.S. 120 Volt
60Hz outlets. It takes 5 hours to charge a
completely discharged battery.
Battery
Standard battery and extended battery are
available.
Cigar Lighter Adapter (optional)
You can operate the phone and trickle
charge the phone battery from your vehicle
by using the vehicle power adapter, model
???-??. It takes 5 hours to charge a
completely discharged battery.
Headset
Connects to your phone, allowing hands-
free operation. Includes earpiece,
microphone, and integrated call
answer/termination button.
There are a variety of accessories available for your mobile
phone. You can select these options according to your personal
communication requirements. Consult your local dealer for
availability.
Accessories
Data Cable Kit(optional)
Connects your phone to PC
Handsfree Kit(optional)
Accessories
101
100
TIA Safety Information
Provided herein is the complete TIA Safety Information for Wireless
Handheld phones. Inclusion of the text covering Pacemakers, Hearing
Aids, and Other Medical Devices is required in the owner’s manual for
CTIA Certification. Use of the remaining TIA language is encouraged
when appropriate.
Exposure to Radio Frequency Signal
Your wireless handheld portable telephone is a low-power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August, 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standards
bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986)
ICNIRP (1996)
Those standards were based on comprehensive and periodic
evaluations of the relevant scientific literature. For example, over 120
scientists, engineers, and physicians from universities, government
health agencies, and industry reviewed the available body of research
to develop the ANSI Standard (C95.1).
*American National Standards Institute; National Council on
Radiation Protection and Measurements; International Commission
on Non-Ionizing Radiation Protection
The design of your phone complies with the FCC guidelines (and
those standards).
Antenna Care
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the phone and may violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would any other
telephone with the antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
▶Extend your antenna fully.
▶Do not touch the antenna unnecessarily when the phone is in use.
Contact with the antenna affects call quality and may cause the
phone to operate at a higher power level than otherwise needed.
Driving
Check the laws and regulations on the use of wireless phones in the
areas where you drive. Always obey them. Also, if using your phone
while driving, please:
▶Give full attention to driving — driving safely is your first
responsibility;
▶Use hands-free operation, if available;
▶Pull off the road and park before making or answering a call if
driving conditions so require.
Safety Guidelines
103
102
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against the
RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a
handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and recommendations of
Wireless Technology Research.
Persons with pacemakers:
▶Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
▶Should not carry the phone in a breast pocket.
▶Should use the ear opposite the pacemaker to minimize the
potential for interference.
▶If you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In
the event of such interference, you may want to consult your service
provider.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer
of your device to determine if they are adequately shielded from
external RF energy. Your physician may be able to assist you in
obtaining this information.
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to external
RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or
its representative regarding your vehicle.
You should also consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so require.
Aircraft
FCC regulations prohibit using your phone while in the air. Turn your
phone OFF before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF
when in a “blasting area” or in areas posted: “Turn off two-way
radio”. Obey all signs and instructions.
Satety GuidelinesSatety Guidelines
105
104
Potentially Explosive Atmosphere
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even
death.
Areas with a potentially explosive atmosphere are often, but not
always, marked clearly. Potential areas may include: fueling areas
(such as gasoline stations); below deck on boats; fuel or chemical
transfer or storage facilities; vehicles using liquefied petroleum gas
(such as propane or butane); areas where the air contains chemicals or
particles (such as grain, dust, or metal powders); and any other area
where you would normally be advised to turn off your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including
either installed or portable wireless equipment, in the area over the air
bag or in the air bag deployment area. If in-vehicle wireless equipment
is improperly installed and the air bag inflates, serious injury could
result.
Satety GuidelinesSatety Guidelines
107
106
FDA Consumer Update
The U.S. Food and Drug Administration’s Center for Devices and
Radiological Health Consumer Update on Mobile Phones.
1.Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using wireless phones. There is no
proof, however, that wireless phones are absolutely safe. Wireless
phones emit low levels of radiofrequency energy (RF) in the
microwave range while being used. They also emit very low levels
of RF when in the standby mode. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures have not
found any biological effects. Some studies have suggested that some
biological effects may occur, but such findings have not been
confirmed by additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in determining
the reasons for inconsistent results.
2.What is the FDA's role concerning the safety of wireless phones?
Under the law, the FDA does not review the safety of radiation-
emitting consumer products such as wireless phones before they can
be sold, as it does with new drugs or medical devices. However, the
agency has authority to take action if wireless phones are shown to
emit radiofrequency energy (RF) at a level that is hazardous to the
user. In such a case, the FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair,
replace, or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, the FDA has urged the wireless phone industry to take a
number of steps, including the following:
▶Support needed research into possible biological effects of RF of
the type emitted by wireless phones;
▶Design wireless phones in a way that minimizes any RF exposure
to the user that is not necessary for device function; and
▶Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use on
human health.
The FDA belongs to an interagency working group of the federal
agencies that have responsibility for different aspects of RF safety to
ensure coordinated efforts at the federal level. The following agencies
belong to this working group:
o National Institute for Occupational Safety and Health
o Environmental Protection Agency
o Occupational Safety and Health Administration
o National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
The FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are
sold in the United States must comply with FCC safety guidelines that
limit RF exposure. The FCC relies on the FDA and other health
agencies for safety questions about wireless phones.
The FCC also regulates the base stations that the wireless phone
networks rely upon. While these base stations operate at higher power
than do the wireless phones themselves, the RF exposures that people
get from these base stations are typically thousands of times lower
than those they can get from wireless phones. Base stations are thus
not the subject of the safety questions discussed in this document.
3.What kinds of phones are the subject of this update?
Satety GuidelinesSatety Guidelines
109
108
The term “wireless phone” refers here to handheld wireless phones
with built-in antennas, often called “cell”, “mobile”, or “PCS”
phones. These types of wireless phones can expose the user to
measurable radiofrequency energy (RF) because of the short
distance between the phone and the user’s head.
These RF exposures are limited by FCC safety guidelines that were
developed with the advice of the FDA and other federal health and
safety agencies. When the phone is located at greater distances from
the user, the exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a base unit
connected to the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures far below the
FCC safety limits.
4.What are the results of the research done already?
The research done thus far has produced conflicting results, and
many studies have suffered from flaws in their research methods.
Animal experiments investigating the effects of radiofrequency
energy (RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have suggested that
low levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that showed
increased tumor development used animals that had been genetically
engineered or treated with cancer-causing chemicals so as to be pre-
disposed to develop cancer in the absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours per day. These
conditions are not similar to the conditions under which people use
wireless phones, so we don’t know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been published since
December 2000. Between them, the studies investigated any possible
association between the use of wireless phones and primary brain
cancer, glioma, meningioma, or acoustic neuroma, tumors of the
brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects
from wireless phone RF exposures. However, none of the studies
can answer questions about long-term exposures, since the average
period of phone use in these studies was around three years.
5.What research is needed to decide whether RF exposure from
wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of
people actually using wireless phones would provide some of the
data that are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large numbers of animals
would be needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more years
follow-up may be needed to provide answers about some health
effects, such as cancer. This is because the interval between the time
of exposure to a cancer-causing agent and the time tumors develop
— if they do — may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in measuring
actual RF exposure during day-to-day use of wireless phones. Many
factors affect this measurement, such as the angle at which the phone
is held, or which model of phone is used.
6.What is the FDA doing to find out more about the possible
health effects of wireless phone RF?
The FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to ensure that high
priority animal studies are conducted to address important questions
about the effects of exposure to radiofrequency energy (RF).
The FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project since
Satety GuidelinesSatety Guidelines
111
110
its inception in 1996. An influential result of this work has been the
development of a detailed agenda of research needs that has driven the
establishment of new research programs around the world. The project
has also helped develop a series of public information documents on
EMF issues.
The FDA and the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development
Agreement (CRADA) to do research on wireless phone safety. The
FDA provides the scientific oversight, obtaining input from experts in
government, industry, and academic organizations. CTIA-funded
research is conducted through contracts with independent
investigators. The initial research will include both laboratory studies
and studies of wireless phone users. The CRADA will also include a
broad assessment of additional research needs in the context of the
latest research developments around the world.
7.How can I find out how much radio frequency energy exposure I
can get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit radio
frequency energy (RF) exposures. The FCC established these
guidelines in consultation with the FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wireless
telephones is set at a Specific Absorption Rate (SAR) of 1.6 watts
per kilogram (1.6 W/kg). The FCC limit is consistent with the safety
standards developed by the Institute of Electrical and Electronic
Engineering (IEEE) and the National Council on Radiation
Protection and Measurement. The exposure limit takes into
consideration the body’s ability to remove heat from the tissues that
absorb energy from the wireless phone and is set well below levels
known to have effects. Manufacturers of wireless phones must report
the RF exposure level for each model of phone to the FCC. The FCC
website (http://www.fcc.gov/oet/ rfsafety) gives directions for
locating the FCC identification number on your phone so you can
find your phone’s RF exposure level in the online listing.
8.What has the FDA done to measure the radio frequency energy
coming from wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is
developing a technical standard for measuring the radio frequency
energy (RF) exposure from wireless phones and other wireless
handsets with the participation and leadership of FDA scientists and
engineers. The standard, “Recommended Practice for Determining
the Spatial-Peak Specific Absorption Rate (SAR) in the Human
Body Due to Wireless Communications Devices: Experimental
Techniques,” sets forth the first consistent test methodology for
measuring the rate at which RF is deposited in the heads of wireless
phone users. The test method uses a tissue-simulating model of the
human head. Standardized SAR test methodology is expected to
greatly improve the consistency of measurements made at different
laboratories on the same phone. SAR is the measurement of the
amount of energy absorbed in tissue, either by the whole body or a
small part of the body. It is measured in watts/kg (or milliwatts/g) of
matter. This measurement is used to determine whether a wireless
phone complies with safety guidelines.
9.What steps can I take to reduce my exposure to radiofrequency
energy from my wireless phone?
If there is a risk from these products — and at this point we do not
know that there is — it is probably very small. But if you are
concerned about avoiding even potential risks, you can take a few
simple steps to minimize your exposure to radiofrequency energy
(RF). Since time is a key factor in how much exposure a person
receives, reducing the amount of time spent using a wireless phone
will reduce RF exposure.
If you must conduct extended conversations by wireless phone every
day, you could place more distance between your body and the
source of the RF, since the exposure level drops off dramatically
Satety GuidelinesSatety Guidelines
113
112
with distance. For example, you could use a headset and carry the
wireless phone away from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones
are harmful. But if you are concerned about the RF exposure from
these products, you can use measures like those described above to
reduce your RF exposure from wireless phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless
phones, including children and teenagers. If you want to take steps
to lower exposure to radiofrequency energy (RF), the measures
described above would apply to children and teenagers using
wireless phones. Reducing the time of wireless phone use and
increasing the distance between the user and the RF source will
reduce RF exposure.
Some groups sponsored by other national governments have
advised that children be discouraged from using wireless phones at
all. For example, the government in the United Kingdom
distributed leaflets containing such a recommendation in December
2000. They noted that no evidence exists that using a wireless
phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was
strictly precautionary; it was not based on scientific evidence that
any health hazard exists.
11.What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can interact
with some electronic devices. For this reason, the FDA helped
develop a detailed test method to measure electromagnetic
interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now
part of a standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI). The final draft,
a joint effort by the FDA, medical device manufacturers, and many
other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators
are safe from wireless phone EMI.
The FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored
by the Institute of Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance requirements for
hearing aids and wireless phones so that no interference occurs
when a person uses a “compatible” phone and a “compatible”
hearing aid at the same time. This standard was approved by the
IEEE in 2000.
The FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should harmful
interference be found to occur, the FDA will conduct testing to
assess the interference and work to resolve the problem.
12.Where can I find additional information?
For additional information, please refer to the following resources:
FDA web page on wireless phones
(http://www.fda.gov/cdrh/phones/index.html)
Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-lonizing Radiation Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
National Radiological Protection Board (UK)
(http://www.nrpb.org.uk/)
Satety GuidelinesSatety Guidelines
115
114
Consumer Information on SAR
(Specific Absorption Rate)
This Model Phone Meets the Government’s Requirements for
Exposure to Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6W/kg. * Tests for SAR are conducted
using standard operating positions specified by the FCC with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although SAR is determined at the highest certified
power level, the actual SAR level of the phone while operating can be
well below the maximum value. Because the phone is designed to
operate at multiple power levels to use only the power required to
reach the network, in general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government-adopted requirement for safe exposure.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is 0.689
W/kg and when worn on the body, as described in this user’s manual,
is 0.931 W/kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements.) While
there may be differences between SAR levels of various phones and at
various positions, they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after searching on FCC
ID BEJG4010.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications Industry Association
(CTIA) website at http://www.wow-com.com
*In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a substantial margin of safety to
give additional protection for the public and to account for any
variations in measurements.
Satety GuidelinesSatety Guidelines
117
116
Index (sample) Index
A
Accessories 120
Adaptor 13
Adding Entry 81
Alerts 48
- Fade 48
- Minute 48
- Service 48
- Call Connect 48
Audio AGC 57
Auto Answer 55
Auto Retry 56
Appendix 122
Accessories 120
Adaptor 13
Adding Entry 81
Alerts 48
- Fade 48
- Minute 48
- Service 48
- Call Connect 48
Audio AGC 57
Auto Answe 55
Auto Retry 56
Appendix 122
B
Backlight 49
Banner 50
Battery 11
Browser 72
C
Calculator 101
Caller ID 30
CALL HISTORY 83
- Outgoing 83
- Incoming 83
- Missed 84
- Call Info 85
Calls
- Making a Call 25
- Receiving Calls 26
- Redialing Calls 30
Call Waiting 29
Contrast 50
Clear Call 62
Clear Data 63
D
Data Setting 53
- Data/Fax 53
- Data Baud 54
Dial
- Correcting Dialing
Mistakes 26
- Speed Dialing 38
- One touch 56
Display 49
E
Emergency # 63
Entering Information
Using T9 Text Inpu 19
- Input Mode 21
F
Features 53
Find
- Find Email 82
- Find Entry 79
- Finding a Bookmark 76
- Find Name 80
G
GPS mode 78,119
H
How to use buttons 87
I
Icons
- Onscreen Icons 18
- Phone Type icons 81
Inbox 110
J
Key Tone 45,118
Key Volume 46
L
Lock Mode 28,61
- New Lock Code 64
Language 51
119
118
IndexIndex
M
Manner Mode 27
Making a Call 25
Memo 118
Message Features 102
- Status 114
Mute 29, 118
N
Navigation Keys 73
O
Onscreen Icons 18
Outbox 113
Overview 71
P
Password
- see Lock Mode 28
Phone Book 79
Phone Book Features 31
Phone Components 15
Phone On & Off 24
Phone Overview 16
Q
Quick
- Manner Mode 27
- Keypad Lock Mode 28
R
Receiving Calls 26
Redialing Calls 30
Restrict 62
Retrieving Numbers 35
Ringer
- Ring Sound 43
- Ring Type 44
- Ring Volume 44
S
Safety Guidelines 123
Scheduler 86
- Add Event 88
- Erase All 90
- Erase Old 91
- View All 90
- View Daily 89
Security 61
Setting 116
Soft Keys 74
Sound
- Ring Sound 43
Speed Dialing 38
System 58
T
Theme 51
TTY Mode 60
Turning the
Phone On & Off 24
V
Voice Privacy 57, 119
Voice Service 65
Volume
- Key Volume 46
- Ear Volume 46
W
Wake Up 92
Memo Memo
MemoMemo
Memo Memo
Memo
