Users Manual
Part 15.21 statement
" Change or Modifications that are not expressly approved by the manufacturer could void
the user's authority to operate the equipment. “
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device is not intended for sale in the U.S.A.
Part 15 Class B Compliance
This device and its accessories comply with part15 of FCC rules.
Operation is subject to the following two conditions:
(1) This device & its accessories may not cause harmful interference.
(2) This device & its accessories must accept any interference received,
including interference that may cause undesired operation.
Body-worn Operation
This device has been tested for typical body-worn operations
with the distance of 0.79inches (2.0cm) from the user’s body.
To comply with FCC RF exposure requirements, a minimum separation distance
of 0.79inches(2.0cm) must be maintained from the user's body.
Additionally, Belt clips, holsters & other body-worn accessories may not contain
metallic components.
6
Your Phone
Phone Components
1
4
2
3
5
7
6
8
1. EARPIECE: Lets you hear the caller and
automated prompts.
2. MAIN LCD: Displays phone status icons,
menu items, web items, web information,
pictures and more in full color. You can
choose menu on touch pad by touching the
icon slightly.
3. SEND KEY: Press this key in standby mode
to quickly access the most recent incoming,
outgoing and missed calls.
4. End/Power key: Ends or rejects a call.
Turns the phone on/off. Press once to return
to the home screen.
5. Micro SD memory card socket
6. Hold key
7. Capture button
8. Side keys
• When the screen is idle: volume of key
tone.
• During a call: volume of the earpiece.
• When playing a BGM track: controls
volume continuously.
Your Phone
7
Rear view
Battery cover
External
camera lens
Micro SD memory
card socket
Battery
Flash
SIM card socket
8
Getting Started
Installing the SIM card and
battery
1. Remove the battery cover
Press and hold down the battery release
button at the top of the phone, and lift off
the battery cover.
2. Remove the battery
Hold the top edge of the battery and, using
the battery cover, lift it from the battery
compartment.
• Using fingernail
Getting Started
9
• Using battery cove
n
Warning
• We do recommend not to user your fingernail
to remove the battery not to be hurt.
• Do not remove the battery when the phone is
switched on, as this may damage the phone.
3. Install the SIM card
Slide the SIM card into the SIM card
holder. Make sure that the gold contact
area on the card is facing downwards. To
remove the SIM card, pull it gently in the
opposite direction.
Getting Started
10
4. Install the battery
Insert the top of the battery first into the
top edge of the battery compartment.
Ensure that the battery contacts align
with the terminals on the phone. Press the
bottom of the battery down until it clips
into place.
5. Charging your phone
Slide back the cover of the charger socket
on the side of your LG Secret. Insert the
charger connector to the phone (‘B’ side
of the connector has to be facing up when
connecting to the phone) and then plug
into the wall socket. Your LG Secret will
need to be charged until a message reading
“Battery full. Please unplug charger to save
energy” appears on the screen.
Important!
You should insert the battery before
charging.
Getting Started
11
n
Warning
Use of unauthorized accessories could damage
your phone and void your warranty.
To use the travel charger provided with your
phone:
Installing a memory card
You can expand the memory available on
your phone by using a microSD™ memory
card. The LG Secret will support up to a 16GB
microSD™ memory card.
n
Tip
A memory card is an optional accessory.
1. Remove the battery cover as before.
2. Information is missing describing the
locking mechanism for the MicroSD slot.
Please revise and include this information
and instructions.
3. Lift the memory card cover and insert a
microSD™ card with the gold contact area
facing downwards. Close the memory card
cover so that it clicks shut.
3. Remove the battery cover as before.
n
Note
If your memory card has existing content it will
automatically be filed in the correct folder. For
example, videos will be accessible from the My
Videos folder.
Getting Started
12
On-Screen Icons
The table below describes various display indicators or icons
that appear on the phone's display screen.
ICON/
INDICATOR DESCRIPTION
Multitasking
Network signal strength
(number of bars will vary)
No network signal
Battery empty
New text message
New email
An alarm is set
Normal profile in use
Silent profile in use
ICON/
INDICATOR DESCRIPTION
EDGE available
Bluetooth® is active
The browser is active
Vibrate mode
Speakerphone
Call in Progress
Voicemail
Battery Full
Battery Charging
Airplane Mode
13
General Functions
Making a Call
1. Make sure your phone is powered on.
2. Touch Dial icon and press slightly a phone
number on the touch pad. Or slide open
the qwerty pad and enter a phone number
including the area code. To edit a number
on the display screen, simply press the
key to erase one digit at a time.
]
Press and hold the key to erase the
entire number.
3. Press the [SEND] key to call the
number.
4. When finished, press the [END] key.
Making a Call with the Send Key
1. Press the [SEND] key, and the most
recent incoming, outgoing and missed
phone numbers will be displayed.
2. Select the desired number by using the
navigation touch pad.
3. Press the [SEND] key.
Making International Calls
1. Touch and hold the key
and the international access character ‘+’
will appear.
2. Enter the country code, area code and the
phone number.
3. Touch .
Ending a Call
When you have finished a call, press the
[END] key.
Making a Call from the Contacts
You can store frequently called names and
phone numbers in the SIM card as well as in
the phone memory known as the Contacts.
You can dial a number by simply selecting a
name in the contacts and pressing the
[SEND] key.
General Functions
14
Adjusting the Volume
During a call, if you want to adjust the
earpiece volume, use the side volume keys
of the phone.
In idle mode, you can adjust the ring volume
using the side volume keys.
Answering a Call
When you receive a call, the phone rings and
the phone icon appears on the screen. If the
caller can be identified, the caller’s phone
number (or name if stored in your Address
Book) is displayed.
1. Press the [SEND] touch Accept.
If Any Key has been set as the Answer
Mode, any key press will answer a call
except for the [END] key or the right
soft key.
2. End the call by pressing the [END]
key.
n
Note
You can answer a call while using the Address
Book or other menu features.
Vibrating Mode (Quick)
Vibrating Mode can be activated by pressing
and holding down the [Star] key.
Signal Strength
If you are inside a building, being near a
window may give you better reception. You
can see the strength of your signal by the
signal indicator on your phone’s display
screen.
General Functions
15
Entering Text
You can enter alphanumeric characters by
using the phone’s keypad. For example,
storing names in the Address Book, writing a
message or scheduling events in the calendar
all require text to be entered.
The following text input modes are available
on the phone.
Changing the Text Input Mode
Change the text input mode by touching .
You can check the current text input mode in
the upper right corner of the screen.
Using the Symbol Mode
The Symbol Mode enables you to enter
various symbols or special characters. To
enter a symbol, touch . Select the
desired symbol.
ABC Mode
This mode allows you to enter letters by
pressing the key labeled with the required
letter once, twice, three or four times until the
letter is displayed.
123 Mode (Numbers Mode)
Type numbers using one keytouch per number.
To change to 123 mode in a text entry field,
touch .
Using the T9 Mode
The T9 predictive text input mode allows
you to enter words easily with a minimum
number of key presses. As you touch or press
each key, the phone begins to display the
characters that it thinks you are typing based
on a built-in dictionary. As new letters are
added, the word changes to reflect the most
likely candidate from the dictionary.
General Functions
16
1. When you are in the T9 predictive text
input mode, and touch and .
It will be a word ‘Be’.
Touch one key per letter.
]
The word changes as letters are typed
- ignore what is displayed on the screen
until the word is typed completely.
]
If the desired word is missing from the
word choices list, add it by using the ABC
mode.
2. Enter the whole word before editing or
deleting any keytouches.
3. Complete each word with a space by
touching .
To delete letters, touch . Touch and hold
down to continuously erase the whole
letters.
n
Note
Pressing the [END] key will save your
unsaved message in the Drafts folder.
Using the ABC Mode
Use the keypad keys to enter your text.
1. Touch the key labeled with the required
letter:
]
Once for the first letter
]
Twice for the second letter
]
And so on
2. To insert a space, touch . To delete
letters, touch . Touch and hold down
to continuously erase the whole
letters.
General Functions
17
n Note
Refer to the table below for more information
on the characters available using the keys.
Key Characters in the Order Display
Upper Case Lower Case
1 . , ' @ ? ! - : / 1 . , ' @ ? ! - : / 1
2 A B C 2 a b c 2
3 D E F 3 d e f 3
4 G H I 4 g h i 4
5 J K L 5 j k l 5
6 M N O 6 m n o 6
7 P Q R S 7 p q r s 7
8 T U V 8 t u v 8
9 W X Y Z 9 w x y z 9
0Space Key,
0 (Long press)
Space Key,
0 (Long press)
Using the 123 (Numbers) Mode
The 123 Mode enables you to enter numbers
in a text message (a telephone number,
for example) more quickly. Touch the keys
corresponding to the required digits before
manually switching back to the appropriate
text entry mode.
T9 dictionary
The T9 dictionary is a feature that allows the
user to add any unique or personal words to
the T9 standard language database. The T9
dictionary function can be selected from the
Text Entry Settings by using Options .
Within the T9 dictionary function, the user can
add, modify, delete or reset personal words.
General Functions
18
Using the Korean Mode
Allows you to type in Korean when you set
the language to Korean.
When you use Touch Keypad
Allows you easily input the letters. To input ,
touch and touch . To input , touch
and touch .
When you use Qwerty Keypad
Touch and select Show Key Guide. You
can see the Korean key guide on the monitor.
To input numbers, touch .
Touch once, and you can see the
Korean key guide as below. To return its
normal input mode, touch again.
General Functions
19
T9 Mode
This mode allows you to enter words with
only one keystroke per letter.
Each key on the keypad has more than one
letter. The T9 mode automatically compares
your keystrokes with an internal linguistic
dictionary to determine the correct word,
thus requiring far fewer keystrokes than the
traditional ABC mode.
n
Note
You can select a different T9 language from the
Options menu. The default setting on the phone
is the T9 disabled mode.
Qwerty Keypad
Entering text
You can enter alphanumeric characters using
the phone’s keypad. For example, storing
names in Contacts, writing a message and
creating scheduling events in the calendar all
require entering text. The following text input
methods are available in the phone: ABC
manual mode and 123 mode.
n
Note
Some fields may allow only one text input mode
(e.g. telephone number in address book fields).
To input a symbol in the text entry field, press
the key and select a symbol from touch
screen, then select OK. Or for simple symbol,
just press and press the symbol. To
return ABC mode, press again.
Scroll using the navigation keys to show more
symbol options.
Complete each word with a space by pressing
. To delete a character, press
key.
General Functions
20
Text input mode using the
keypad
When you are required to enter text, for
example when writing a message, the keypad
will default to ABC mode. If you are entering
a number, for example when making a call,
the keypad number keys will default to
numbers.
In ABC mode you can enter numbers by first
pressing and then the number you
require.
21
In-Call Menu
Your phone provides a number of control
functions that you can use during a call. To
access these functions during a call, press the
right soft key [Options].
During a Call
The menu displayed on the handset screen
during a call is different from the default main
menu displayed when in the idle screen, and
these options are described below.
Making a Second Call
You can select a number you wish to dial from
the Address Book, to make a second call.
Touch Contact on the screen. Then, you can
press SEND key to make a second call.
Swapping Between Two Calls
By using one of three methods, you can
switch between two calls.
1. Touch [SEND] key.
2. Press the right soft key and then select
“Swap Calls.”
Answering an Incoming Call
To answer an incoming call when the handset
is ringing, simply press the [SEND] key.
The handset is also able to warn you of an
incoming call while you are already on a call.
A tone sounds in the earpiece, and the display
will show that a second call is waiting. This
feature, known as Call Waiting, is only
available if your network supports it.
If Call Waiting is turned on, you can put the
first call on hold and answer the second call
by pressing the [SEND] key.
Rejecting an Incoming Call
You can reject an incoming call without
answering by simply pressing the
[END] key.
Muting the Microphone
You can mute the microphone during a call by
touching . The handset can be unmuted
by touching . When the handset is muted,
the caller cannot hear you, but you can still
hear the caller.
In-Call Menu
22
Using the Speakerphone
You can use the integrated Speakerphone
during a call by touching . The loudspeaker
is automatically deactivated when you end
the call.
n
Warning
Due to increased volume levels, do not place
the phone near your ear while the speakerphone
is enabled.
Video Share Calling
Making and Answering a Video
Share Call
You can make or answer a Video Share call
with other 3G video phones. In order to start
a Video Share call, both sides must have a 3G
Video Share capable phone and both must be
in a 3G coverage area.
n
Note
Before you start a Video Share Call you must
check the following:
• Phone must be in an AT&T 3G service area.
To initiate Video Share follow these
steps:
1. Make a phone call by dialing a number,
or selecting a number from Address book.
From the Recent Call or Contact List, you
can also directly make a Video Share call
by selecting [Options] > [Video Share] and
selecting Video Type (Live or Recorded). In
this case skip steps 2-3.
2. A few seconds after the connection is
established, a "Video Share Ready" prompt
will appear on the screen once the other
party is ready to use the Video Share
service. If Audio alert in Video Share
setting (See Application Setting) is set to
‘ON’, auditory alert will sound along with
prompt.
3. To Share Video with other party, you can
press left soft key [Video] or Camera key
and select Video type (Live or Recorded).
In-Call Menu
23
n
Note
The Speakerphone will be automatically
activated when a Video Share session begins,
unless a hands-free device (Bluetooth® or stereo
headset) is connected.
• Live: You can share a real-time video
stream with the other party while having a
conversation.
• Recorded: You can share a pre-recorded
video clip with the other party while having a
conversation. (Note that H.263 video format
in 176x144 size is supported)
4. If the other party accepts the Video Share
invitation, the Video Share session will
begin. (After accepting, it may take several
seconds before actual Video Share starts)
During the Video Share, you can do
followings via the [Options].
During the Video Share session, you can
choose the [Options] menu items.
]
Spk. On: You can turn the integrated
Speakerphone on while you are using
Bluetooth.
]
Mute/Unmute: You can mute/unmute the
microphone by selecting mute/unmute.
]
Stop Video Share: You can stop video
sharing and proceeds with voice call only by
selecting Stop Video Share.
]
Brightness: You can adjust the brightness
of the screen by selecting Brightness.
]
Zoom: You can zoom in/out the video by
selecting Zoom.
]
Audio to Bluetooth®/Audio to Phone:
When Audio to Bluetooth® is selected, you
can have a conversation using Bluetooth®.
When Audio to Phone is selected, you
can have a conversation using either
speakerphone or headset.
In-Call Menu
24
]
Record Video Share/Stop Recording:
You can start recording the live video
by selecting ‘Record Video Share’. Once
you are recording the video, you can stop
recording by selecting ‘Stop Recording’.
]
End Call: You can end phone call by
selecting ‘End Call’. (Note: Video Share will
stop as well)
]
Hold Call: You can hold phone call by
selecting ‘Hold Call’. (Note: Video Share
will stop when you select ‘Hold Call’)
During the Video Share session, you can turn
speakerphone on/off using the 'Spk. off' /
'Spk. on' key (OK key).
You can record a current video clip via Options
menu, and the recorded video will be saved in
[My stuff] - [More].
5.1. You can stop a Video Share call and
proceed to a voice call by
1. Press [Stop] Key (Left soft key)
2. Selecting [Option] > [Stop Video share]
5.2. You can end a voice call along with the
Video Share call by
1. Press [End] Key
2. Selecting [Option] > [End Call]
n
Note
1. A Video Share Call will be terminated in the
following cases:
• When trying to make a conference call/
second call during a Video Share Call.
• When the voice call is placed on hold.
• When the voice call is disconnected.
• When moving out of an AT&T 3G service
area.
• When the network connection is poor.
2. A Video Share Call will be unavailable in
the following cases (“Video Share Ready”
message will not appear).
• When trying to make a conference call/
second call during a Video Share Call.
• When the voice call is placed on hold.
• When moving out of an AT&T 3G service
area.
In-Call Menu
25
1. If you receive a Video Share request during
a call, select the left soft key [Accept] to
start the Video Share Call. If you don’t want
to accept the request, press the right soft
key [Decline] to decline the request. (Note
that after accepting the call, it may take
several seconds before the Video Share
session starts.) When you are a recipient of
a Video Share call, the following [Option]
menu items are available:
]
Spk. On: You can turn the integrated
Speakerphone on while you are using
Bluetooth.
]
Mute/Unmute: You can mute/unmute the
microphone by selecting mute/unmute.
]
Stop Video Share: You can stop video
sharing and proceeds with voice call only by
selecting Stop Video Share.
]
Landscape mode: When Landscape mode
is selected you can watch shared video in
landscape mode.
]
Audio to Bluetooth®/Audio to Phone:
When Audio to Bluetooth® is selected, you
can have a conversation using Bluetooth®.
When Audio to Phone is selected, you
can have a conversation using either
speakerphone or headset.
]
End Call: You can end phone call by
selecting ‘End Call’. (Note: Video Share will
stop as well)
]
Hold Call: You can hold phone call by
selecting ‘Hold Call’. (Note: Video Share
will stop when you select ‘Hold Call’)
n
Note
The speakerphone will be automatically turned
on when a Video Share Call begins, and
automatically reverts back to the previous mode
when a Video Share Call ends.
In-Call Menu
26
Making a Video Share Call from
the Camera, Camcorder or Video
Gallery
When you are in the Camera or Video
Recording mode, you can easily make a Video
Share Call to a person in your Contact List.
1. Start Video Share call as follows:
]
In Record Video mode, select the first
icon from the bottom [Video Share].
]
There is no right soft key when My Stuff
> Video is selected. Once the Video
Gallery is opened the right soft key does
NOT lead to [Video Share Call], it leads
to [Options] and the [Video Share Call]
option is not there at all!
n
Note
This menu item is active only in 3G coverage
and video share capable.
n
Note
If the other party is not ready for Video Share,
the call will proceed to an ordinary voice call.
Saving your Video Share
The sender can record video during the Video
Share session by
1. Selecting [Option] > [Record Video Share]
during a live Video Share call.
2. Setting Auto Record to ‘ON’
(See Application Settings).
Sender can save the recorded video by
1. Selecting [Option] > [Stop Recording] during
a live Video Share call.
2. Ending Video Share call.
Recorded video will be saved in [My Stuff] >
[Videos] folder in the phone.
In-Call Menu
27
Conference Calls
The conference service provides you with the
ability to have a simultaneous conversation
with more than one caller. The conference
call feature can be used only if your network
service provider supports this feature.
A conference call can only be set up when
you have one call active and one call on hold,
meaning both calls must have been answered.
Once a conference call is set up, calls may
be added, disconnected or separated (that
is, removed from the conference call but still
connected to you) by the person who set up
the conference call. These options are all
available from the In-Call menu.
The maximum number of callers in a
conference call is five. Once started, you are
in control of the conference call, and only you
can add calls to the conference call.
Making a Second Call
You can make a second call while currently
on a call simply by entering the second
number and pressing the [SEND] key.
When the second call is connected, the first
call is automatically placed on hold. You can
swap between calls by pressing the
[SEND] key.
Setting Up a Conference Call
To set up a conference call, place one call on
hold, then conference in the second active call
by pressing the right soft key [Options] and
select the Join Calls sub menu option from
the Conference Call menu.
Activate the Conference Call
on Hold
To activate a conference call on hold, press
the [SEND] key.
In-Call Menu
28
Adding Calls to the Conference
Call
To add a call to an existing conference call,
press the right soft key, and then select the
Join Calls sub menu from the Conference
Call option.
Private Call in a Conference Call
To have a private call with one caller from a
conference call, press the right soft key and
select Private Call from the Conference Call
option. When the numbers of the callers are
displayed, select the one you wish to speak
in private with.
Ending a Conference Call
The currently active conference call can be
disconnected by pressing the [END]
key.
29
Menu Tree
Phone
Dialing
Address Book
Recent Calls
Messaging
Mobile Email
IM
AT&T GPS
YELLOWPAGES.COM
Multimedia
MEdia Net
MEdia Mall
AT&T Music
CV
Applications
Games
Camera
Web Pages
My stuff
Audio
Pcitures
Video
Tools
Calendar
Alarm Clock
Calculator
More
Settings
Call
Date & Time
Sound
Display
Touch
Phone
Bluetooth
More
Touch in the home screen to open a Top menu. From here you can access further menus:
Phone, Multimedia, My stuff and Settings
30
Your home screen
Whenever your GR500 is not in use it will
return to your home screen. From here you
can access all menu options, make a quick
call and view the status of your phone - as
well as many other things.
Touch screen tips
The home screen is also a great place to get
accustomed to the touch screen.
To select an item, touch the icon accurately.
Your GR500 will vibrate slightly when it
recognises you’ve touched an option.
To scroll through lists, touch the last item
visible and slide your finger up the screen.
The list will move up so more items are
visible.
]
There’s no need to press too hard, the
touchscreen is sensitive enough to pick up
on a light yet firm touch.
]
Use the tip of your finger to touch the
option you require. Be careful not to touch
any other keys.
]
When the screen light is off, press and
hold the on the right hand side to
restore the home screen.
]
Don’t cover the phone with a case or cover
as the touch screen will not work with any
material covering it.
]
When the home screen is Widget mode,
you can drag and click what you need
right away.
Widget
31
The quick keys
The quick keys on your home screen provide easy, one-touch access to your most used functions.
Touch to bring up the touch
dialling pad to make a call. Input
the number as you would using a
normal key pad and touch Call or
press the hard key.
To initiate a video call with
the number, press after
inputting the number and choose
Make Video call.
See page 21 for details.
Touch to open your contacts. To
search for the number you want
to call. Enter the name of the
contact using the touchpad. You
can also create new contacts and
edit existing ones. See page 29
for details.
Touch to access the Messaging
options menu. From here you can
create a new SMS. See page 34
for details.
Touch to open the full Top menu
which is separated into four sub-
menus. Touch the vertical tabs to
view further options.
Your home screen
32
AT&T GPS
The AT&T Navigator application on your
device uses GPS position determination
technology and access to your carrier’s data
network to provide you with driving directions
and a host of other services, including:
]
GPS navigation that gives you turn-by-turn
directions to any destination address in
the continental United States. If you miss
a turn or get off-track, AT&T Navigator
will calculate a new route for you. You can
enter a destination address by using AT&T
Navigator’s automatic voice recognition
system or by typing on the device’s keypad.
]
Audio and visual traffic alerts while driving
or viewing maps, as well as traffic re-
routing capabilities to minimize delays on
your trip.
]
A Search feature that allows you to find
businesses or points of interest near your
current location, an airport, a waypoint, or
any other entered address. You can read
ratings and reviews for businesses and
easily call the business that you have found
to check on the availability of an item or to
make a reservation. You can navigate to the
business location now or save the address
for later use.
]
Maps of the area around your current
location, around a marked waypoint, or
around an address that you had previously
entered. You can pan the map (adjust left,
right, up, or down) and zoom in or out.
You can also mark a point under the cursor
as a waypoint.
]
A compass-like indicator presenting your
direction of travel, location, and speed.
]
The ability to personalize your application
preferences by selecting U.S. customary
or metric distance units, the language for
audible guidance, and so on.
You can also use many of AT&T Navigator’s
features on the TeleNav website, such as
getting driving directions (Route Planning) and
using the Search function to find businesses,
churches, schools, and government offices.
You can also use the TeleNav website to add
an address to your My Favorites list, manage
your My Favorites and Recent Places lists, and
shop at the TeleNav Store.
AT&T GPS
33
n
Note
For best GPS performance
• In order to improve GPS antenna sensitivity,
do not cover the GPS antenna area of the
device.
• Your GPS antenna sensitivity might be
weakened if you are in a high rising building,
underground, or location surrounded by metal
or concrete.
• Use near the window indoors for better GPS
antenna sensitivity.
• For battery durability, please use vehicle
power adapter in your car.
• It could take 2~3 minutes to get your GPS
position depending on the condition of the
environment or network.
34
Messaging
This menu includes functions related to SMS
(Short Message Service), MMS (Multimedia
Message Service), voice mail as well as the
network's service messages.
New Message
In the Standby screen, Touch and touch
.Touch Create Message. Or, you can
simply press the top select from the Standby
screen to create a new message.
n
Note
If you select a graphic or an audio file while
writing a multimedia message, the file loading
time will take about 5 seconds. You will not be
able to activate any key during the file loading
time. When the file loading is complete, you
will be able to write a multimedia message.
Editing a message
The following options are available when
Editing a Message.
]
Symbol: You can insert symbols ranging
from sentence notes to emoticons. Touching
the twice, and you can select the
symbols you want. You can use and
to find a icon.
]
Picture: Touch and choose Picture.
You can select a graphic image. You can
preview the selected picture by choosing
Icon View.
]
Audio: You can insert various ringtones.
]
Video: You can insert a video clip.
]
Take New Picture: You can insert a new
image taken from the camera by pressing
[Capture]. The following camera options
are available when you press [Settings].
Messaging
35
The following options are available through
the .
Preview tab
• View Mode: Choose between Full Image
and Full Screen.
• Image Size: The resolution of the
image can be captured in 1600*1200 /
1280*960 / 640*480 / 320*240.
• Brightness: Adjust brightness by
adjusting slider.
• Color Effects: Includes options of Color/
Mono/Sepia/Negative/Blue.
• White Balance: Set the White Balance
as Auto/Daylight/Cloudy/Illuminate/
Indoors.
• Timer: Set the Timer can be set to Off/3
Seconds/5 Seconds/10 Seconds.
• Night Mode: This is useful to take a
photo at dark place.
• Continuous Shot: This is great for
taking photos of moving objects or at
sporting events. Allows you to set 3
shots, 6 shots or 9 shots continuously.
Others tab
• Video Share: You can make a Video
Share Call.
• Save to: Phone Memory or Memory
Card.
• Shutter Tones: Can be set to Tone 1 /
Tone 2 / Tone 3 / Off.
• Reset Settings: Allows you to set to the
default settings.
]
Record New Audio: You can record a new
audio clip by touching .
• Quality: Set the audio's quality to
Fine, Normal or Economy.
• Select Storage Defaults: You can
assign the default storage to Phone
Memory or Memory Card.
• Record Mode: MMS mode
record time is about 6 minutes
and General mode provides longer
recording time.
]
Record New Video: You can record a
new video.
Messaging
36
]
Template
- Text: You can easily insert frequently used
sentences in the text message.
- Multimedia: Preset multimedia templates
are available.
- Signature: Input your own created
signature. For further details, see page 50.
]
More: Allows you to insert Subject, vCard,
vCalendar, vNote, vTask or Contact.
n
Note
vCard, vCalendar, vNote, vTask and Contact are
created by Address Book, Calendar, Notepad
and Tasks respectively. Go to the menu paths
sections for more detailed information.
Using Options
Touch to use options below.
• Text Entry Settings: Text Entry
Language allows you to set the text entry
language to English, Français, Español
or Korean. You can set to use Show
Word Candidate List. Also, Next Word
Prediction is available when it is set to
On. Use T9 Dictionary to add words or
delete/reset/modify words.
• Delivery Options
- Delivery Receipt: If this is set to On
in this menu, you can check whether
your message was sent successfully.
- Reply via Same Message Center:
You can set On or Off.
• Save to Drafts: Saves the selected
message to Drafts.
• Writing Font Size: Sets the Writing
Font size from Small, Medium and Large.
• Cancel Message: Allows you to exit
the text input mode without saving your
input message.
Sending a Message
After completing a message using the Insert/
Options, select Send To to send a message.
• Enter the recipient(s). From , you can
choose an option item below.
- Enter Number: You can input the
recipient(s) number using Touch keypad
or Qwerty keypad.
- Enter Email: You can enter Email
address instead of phone number.
Messaging
37
- Caller Groups: Shows Contacts in
Group.
- Recent Messages: Choose a contact
from recent messages.
- Recent Calls: Choose a contact from
recent calls.
- Delivery Options: Options of Delivery
Receipt, Reply via Same Message
Center, Add Cc, and Add Bcc.
- Edit Message: Go back to the
message editing mode.
- Save to Draft: Saves the selected
message to Drafts.
- Cancel Message: You can cancel the
message.
n
Tip
Text messages can be copied from the SIM card
to the phone and vice versa.
Message folders
You’ll recognise the folder structure used on
your GR500, which is fairly selfexplanatory.
]
Inbox: All the messsages you receive are
placed into your inbox From here you can
view, delete and more, see Managing
your messages below for details. You can
enter this menu through Message box.
]
Drafts: If you don’t have time to finish
writing a message, you can save what
you’ve done so far here.
]
Outbox: This is a temporary storage folder
while messages are being sent.
n
Note
If you see the message No space for USIM
messages you should delete some messages
from your inbox. If you see the message No
space for messages you can delete either
messages or saved files to create space.
Messaging
38
Inbox
You will be alerted when you receive a
message. They will be stored in the Inbox.
In the Inbox, you can identify each message
by icons. If you are notified that you have
received a multimedia message, you can
download the whole multimedia message by
selecting it in the Inbox menu. To reach the
Inbox, from the standby screen, Touch
and touch . Touch Inbox.
The following [Options] when you select a
message and touch.
]
Add to Address Book: You can save the
sender's phone number in the Contact List.
]
Extract Data: You can make a voice call or
send message. You can save the number As
New contact or Updating Existing.
]
Copy to SIM/Move to SIM: You can copy
or move the message SIM depending on
where the text message is stored.
]
Message Details: You can view
information about received messages;
message Type, Subject, Sender's address,
and message Time.
The following Options are available in Inbox
folder.
]
Delete: You can tick a message and
delete it.
]
Conversation view
]
Sort by: You can sort all messages by
Name, Title, Date and Read/Unread.
]
Delete all read:
]
Delete All Read Messages: You can
delete all read messages.
IM
The Instant Messaging feature can only be
used with the support of the network operator
or communities such as AIM, Windows Live
and Y! Messenger. For Instant Messaging
users, a valid User ID and Password will
be required in order to login and exchange
messages as well as checking the online
status.
Messaging
39
To access the IM feature
1. Touch and touch .
2. You can see available IM clients. The menu
items below might not appear as not all IM
communities support the various options.
In addition, the menu strings may appear
differently. This depends on the selected
IM communities. The keywords such as
User ID, Login and Contact will be used as
general terms in IM menus according to
the currently selected communities such as
AIM, Windows Live and Yahoo! Messenger.
Offline Menu
Sign In
This allows users to login by filling in the User
ID and Password.
n
Note
Once the User ID and Password are saved, you
will not be required to type them in again during
the Login process. This feature is optional.
Saved Conversations
This is where a user can view saved
conversations.
Settings
]
Set Sound: Allows you to turn On/Off
an alert for the Contact when they have
activity on their session.
]
Network: You may check your Network
Profiles or Server Address information.
IM Information
This displays the Instant Messaging Client
Information such as Client Name and Version
Number.
Online Menu /
1-to-1 conversation
After a successful Login, a list of contacts
with Screen Names will appear on screen.
Depending on the cursor location in the
contacts, the following menu options will be
available.
Messaging
40
When cursor is located on a
Conversations List
]
Send Message to: Allows you to send a
message to someone by inputting an email
address.
]
Saved Conversations: This is where a
user can view saved conversations.
]
Settings:
- My Status: Allows you to set your status
to Available, Busy or Invisible.
- Set Sound: Allows you to turn on/off
an alert for the Contact when they have
activity on their session.
]
Sign Out: This begins the Logout process.
n
Note
The Conversations List contains both the active
contact where a conversation has taken place,
as well as an unknown contact.
When cursor is located on a
Conversation
]
End Conversation: This closes the
selected conversation. If an unknown
contact was selected, that contact is
deleted.
]
Block/Unblock Contact: This allows you
to block/unblock the selected Conversations
Contact.
]
Contact Info: This allows you to view the
User ID and Status Text information.
]
Settings:
- My Status: Allows you to set your status
to Available, Busy or Invisible.
- Set Sound: Allows you to turn on/off
an alert for the Contact when they have
activity on their session.
]
Sign Out: This begins the Logout process.
Messaging
41
When cursor is located on a
Contact List
]
Add a Contact: This adds a new contact
to the selected contacts list; contacts are
searched on the basis of Email Address,
First Name or Last Name.
]
Send Message to: Allows you to send a
message to someone by inputting an email
address.
]
Refresh Contact List: This refreshes the
current information on the contacts within
the list.
]
Block List: Displays the list of all blocked
Contacts.
]
Saved Conversations: This is where a
user can view saved conversations.
]
Settings:
- Display Name
- My Status: Allows you to set your status
to Available, Busy or Invisible.
- Offline Contacts
- Set Sound: Allows you to turn on/off
an alert for the Contact when they have
activity on their session.
- Auto Sign In
]
Sign Out: This begins the Logout process.
When cursor is located on a
Contact
]
Add a Contact: This adds a new contact
to the selected contacts list; contacts are
searched on the basis of Email Address,
First Name or Last Name.
]
Delete Contact: This deletes the selected
Contact.
]
Move Contact: Allows you to move a
Contact to another Contact List.
]
Block/Unblock Contact: This allows you
to block/unblock a conversation with the
selected Contact.
]
Contact Info: This allows you to view
information. It provides User ID, Status Text.
Messaging
42
]
Settings:
- Display Name
- My Status: Allows you to set your status
to Available, Busy or Invisible.
- Offline Contacts
- Set Sound: Allows you to turn on/off
an alert for the Contact when they have
activity on their session.
- Auto Sign In
]
Sign Out: This begins the Logout process.
Menu options available in the
Conversation screen
]
Insert: You can insert a Symbol, Template
and emoticons in the conversation screen.
This feature is accessed by pressing the
left soft key.
]
Back to Contacts: This brings the screen
back to the contacts.
]
My Communities: Displays the list of
Email providers.
]
Block/Unblock Contact: This allows you
to block/unblock a conversation with the
selected Contact.
]
Add to Contact List: Allows you to add
the person you are currently having a
conversation with to a Contact List.
]
Save Conversation: Stores the currently
active conversation.
]
End Conversation: This ends the active
conversation and clears the conversation
buffer.
]
Settings:
- Display Name
- My Status: Allows you to set your status
to Available, Busy or Invisible.
- Offline Contacts
- Set Sound: Allows you to turn on/off
an alert for the Contact when they have
activity on their session.
- Auto Sign In
Messaging
43
]
Text Entry Mode: Sets the text input mode
such as abc, Abc, ABC, T9 abc, T9 Abc, T9
ABC and 123.
]
Text Entry Mode Settings: This selects
the T9 predictive mode Language. This
feature also allows you to turn T9 mode on
or off, and to access the T9 Dictionary, Text
Entry Language.
]
Minimize: Minimizes the IM window and
returns to standby mode.
]
Sign Out: This begins the logout process.
n
Note
• In the conversation window, you can use
the up/down select for scrolling through the
conversation.
• The maximum number of characters
supported by a message is 800 characters, for
receiving, and 127 characters for sending.
• The current information might not update
in real time so the "Refresh List"/"Refresh
Contact" option can be used for the
most up to date status.
Mobile Email
Mobile Email allows you to access your
Yahoo! Mail, AOL Mail, AIM Mail, Windows
Live Hotmail, AT&T Yahoo!, BellSouth Mail
and Other providers accounts on your phone.
So, now you can quickly and easily check your
email while you are away from your computer.
To Set Up Mobile Email
]
Open Mobile Email: From the Standby
screen, Touch Menu, and touch Mobile
Email.
]
Select an Email Provider: Touch and hold
the email provider you wish to use.
]
Log In
1. Highlight the ID entry field, touch and
then type in your existing email ID.
2. Touch the Password field, highlight on
the select, and enter your password.
Quick Tip: Your password is case
sensitive. Press the button on the
keypad to change to lower case or upper
case.
Messaging
44
3. To save your password scroll down to
Remember Me and press down on the
select to check the box.
4. Select Sign In.
]
Opening an Email: Just scroll down and
highlight the email subject line you want
to open and touch on the select. When
the email is open, select Options to reply,
forward or delete.
]
Deleting an Email: Scroll down to the
email you want to delete, Touch, then
Delete.
For additional details,
visit www.att.com/email.
Drafts
You can view the messages saved as drafts.
To see the Drafts, in the Standby screen,
Touch and touch . Touch Drafts.
Outbox
Outbox is a temporary storage place for
messages waiting to be sent. When you press
the [SEND] key, you can make a call
to the number of the recipient number of the
selected message.
If the message is not sent from the Outbox,
you will receive a sound alert along with
a Message Sending Failure notice on the
screen. Another attempt will be made to
send the failed message and after two
unsuccessful attempts, the message will no
longer be sent automatically. In order to send
the message that has failed, you must touch
Resend to resend the message.
After the maximum number of Send attempts
has been reached, the Send function has
failed. If you were trying to send a text
message, open the message and check that
the Sending options are correct.
When the message Send has failed, the
following [Options] are available in the
Outbox list.
Messaging
45
]
View Status: Shows the status of each
message.
]
Edit: Allows you to edit the selected
message.
]
Select slide: View Attachment You can
view attachment of the message.
]
Message Details: Allows you to view the
information on the message.
Voicemail
This menu provides you with a quick way of
accessing your voice mailbox (if provided by
your network).
This may already be available; to check the
voicemail, touch and hold the key.
n
Note
Please check with your network service provider
for details of their service in order to configure
the handset accordingly.
Message Settings
To set the message, Touch .
Touch Message Settings.
Message Alert
You can set the Sounds and Alert Type here.
Save to: Choose between Phone and SIM
Card to save message.
Signature
This feature allows you to create your Text
signature. You can use symbols, templates
and contacts as part of the signature.
Text Message
There are 6 predefined messages in the list.
You can view and edit the template messages
or create new messages.
The following [Options] are available.
]
Text Template
- Send: Allows you to send the selected
template via Message.
- Delete: Allows you to delete the selected
template message.
Messaging
46
- Edit: Allows you to edit the selected
template message.
- Delete All: Deletes all messages in the
folder.
]
Message Center Number: If you want
to send a text message, you can get the
address of the SMS center by using this
menu.
]
E-mail Gateway: You can send the text
message to an Email Address via this
gateway.
]
Message Subject: You can enter the SMS
Subject when this menu is ON. You can
switch between to by dragging it
from left to right.
]
Message Types: Convert your text into
Voice, Fax, X.400 or Email.
]
Validity Period: This network service
allows you to decide how long your
multimedia messages will be stored at the
message center.
]
Delivery Receipt: Allows you to send a
delivery confirmation mail for a Multimedia
Message.
]
Reply via Same Message Center: The
details for the Multimedia gateway are
pre-loaded onto your handset and should
not be changed.
]
Insert Signature: Insert signature you
created.
Multimedia Message
]
Multimedia Templates: The preset
multimedia templates are available.
]
Priority: You can choose to set the priority
of the message.
]
Message Subject: You can enter the
MMS Subject when this option is selected.
]
Validity Period: This network service
allows you to decide how long your
multimedia messages will be stored at the
message center.
]
Send Delivery Receipt: Allows you to
send a delivery confirmation mail for a
Multimedia Message.
]
Send Read Receipt: Allows you to send
a message read confirmation mail for a
Multimedia Message.
Messaging
47
]
Download Options
- Download Without Ask: Allows
Multimedia Messages to be downloaded
automatically.
- Ask Always: You can download a
multimedia message manually.
- Discard: Used when the user rejects
download of the Multimedia Message.
]
Message Center: The details for the
Multimedia gateway are pre-loaded onto
your handset and should not be changed.
Voicemail Number
This menu allows you to set the voicemail
center number if this feature is supported by
AT&T. Please check with AT&T for details of
their service in order to configure the handset
correctly.
Service Message
You can set the Service option to determine
whether or not you will receive service
messages.
48
YELLOWPAGES.COM
Unleash the power of YELLOWPAGES.COM
local search on your mobile phone.
Find a business, get maps and directions,
and save your favorites: our mobile app gives
you what you need, whenever and wherever
you need it.
]
Search for local businesses.
]
View ratings and call businesses.
]
Save businesses for future access.
]
Get maps and view step-by-step directions.
* For more information, refer to the
www.yellowpage.com
49
MEdia Net
MEdia Net
This connects to the homepage, which is
defined in the activated account. The default
account connects to AT&T’s homepage.
This menu shows how to access the Internet
by launching the WAP browser.
MEdia Net is one of the services provided by
AT&T and it gives you access to all the cool
things you can do with your wireless phone.
n
Note
Check the availability of WAP services, pricing
and tariffs with your network operator and/or
the service provider whose service you wish
to use. Service providers will also give you
instructions on how to use their services.
Please contact your service provider to open an
Internet account.
To launch the browser in standby mode, Touch
and choose . Touch .
Once connected, the homepage is displayed.
The content depends on the service provider.
To exit the browser at any time, press the
key.
Menus for the Browser
You can surf the Internet using either the
phone keys or the WAP Browser menu.
Using the WAP Browser Menu
Online menu
Once you are connected to the Internet, the
following menu options are available:
]
Back: Moves to the previous page.
]
Forward: Moves to the next page.
]
Refresh: Loads the current page again.
]
Home: Moves to the initial homepage.
]
EnterURL: Connects to the specific URL
after editing.
]
Bookmarks: You can add or save the
current page to Bookmark or view the list
saved under Bookmark.
]
Search Text: You can search the text what
you want to find.
]
Recent Pages: You can manage the list of
the Internet pages you visited.
]
Settings: Allows you to set options such as
Full Screen View, Cache, Cookie, Qpass and
other Browser Settings.
50
MEdia Mall
Shop Tones
This menu option connects to AT&T’s ringtone
download site.
n
Note
Additional charges may incur when
downloading ringtones. Contact AT&T for
additional information.
Shop Games
This menu option connects to AT&T’s game
download site. This allows users to download
the various games by connecting to the
Internet.
n
Note
Additional charges may incur when
downloading games. Contact AT&T for
additional information
Shop Graphics
This menu option connects to AT&T’s graphics
download site.
n
Note
Additional charges may incur when
downloading graphics. Contact AT&T for
additional information.
Shop Multimedia
This allows you to connect to AT&T’s
multimedia download site.
n
Note
Additional charges may incur when
downloading multimedia contents. Contact
AT&T for additional information.
MEdia Mall
51
Shop Applications
This menu option connects to AT&T’s
application download site. This allows users
to download the various applications by
connecting to the Internet.
n
Note
Additional charges may incur when
downloading applications. Contact AT&T for
additional information.
Shop Video
This menu option connects to AT&T’s video
download site.
n
Note
Additional charges may incur when
downloading applications. Contact AT&T for
additional information.
MEdia Net
This connects to the homepage, which is
defined in the activated account. The default
account connects to AT&T’s homepage.
52
Applications
This menu displays the list of Java programs
downloaded using WAP. All previously
downloaded programs can be selected,
deleted or viewed in detail within the
Application menu.
Shop Applications
This menu option connects to AT&T’s
application download site. This allows users
to download the various applications by
connecting to the Internet.
MobiTV
This applications enables you watch Mobile
TV.
Mobile Banking
You can check your bank account, transfer
money or etc things via this applications.
My-Cast Weather
Allows you to search quickly weather
forecast.
53
AT&T Music
Music Player
]
All Songs: You can view all the songs in
your music library.
]
Playlists: You can make your own playlists
by choosing songs from the All songs
menu list.
]
Artists: Shows the list of artists of all the
songs in your music library, and shows all
the songs by a chosen artist.
]
Albums: Shows the list of albums of all the
songs in your music library, and shows all
the songs on a chosen album.
]
Genres: Shows the list of genres of all the
songs in your music library, and shows all
songs of a specific genre.
Tip!
It supports formats such as MP3, AAC,
AAC+, WMA, MP4 (audio only) or 3GP
(audio only).
n
Note
Copyrights of music files may be protected by
copyright and intellectual property laws. Please
ensure that you adhere to the applicable Terms
of Use of materials laws prior to downloading
or copying files.
Playing Music
To listen to music that you have transferred to
your phone, follow these quick easy steps:
1. Touch and touch .
2. Touch .
3. Select Music Player to view your options.
You can select from Now Playing, All
Songs, Playlists, Artists, Albums and
Genres to select your Music.
AT&T Music
54
]
Touch to pause a selected song.
While playing, touch to adjust the
volume. Touch and to skip to
the next song or previous song.
]
Touch to Minimize the music player
and access other phone functions while
music is playing.
n
Note
Files under 300kb are stored as ringtone files.
Adding Music To Your Handset
Music files can be added to your handset by
using one or more of the following methods:
]
Download music and ringtones over the
AT&T network directly to your device via
the Shop Music link in the AT&T Music
Folder or the Shop Tones link in the AT&T
MEdia Mall folder
]
From your existing digital media collection
on your PC via Windows Media® Player
and/or Windows Explorer.
]
From your PC using other music subscription
services, such as Napster or eMusic.
AT&T Music
55
Purchasing and downloading
Music directly to your Device
1. Touch and touch .
2. Touch .
3. Select Shop Music.
4. Navigate the Shop Music page to
download today’s hottest music, ringtones
and other personalized content directly to
your phone.
n
Note
Some sites are data intensive (i.e. previews via
streaming) so the user should be enrolled in an
unlimited data plan before using these services
to avoid per-use data charges.
n
Note
Additional charges may apply when
downloading music, ringtones etc.
Transferring Music using your
PC
Before You Get Started
To transfer music from your PC to your device,
you will need the following:
]
Windows Media® Player 10 (or above) or
other digital music management software
such as Napster or eMusic
]
Music on your PC in one of these formats:
MP3, .AAC, AAC+ or WMA
]
A MicroSD™ card*
(supports up to 8GB cards)
]
USB data cable*
* MicroSD™ card and USB data cable sold
separately; go to att.com/wireless for
details.
n
Note
This device is not compatible with iTunes and/or
iTunes files.
AT&T Music
56
Transferring Music from the
Digital Music Service (such as
Napster or eMusic)
1. Using your computer, open your preferred
PC music management client.
2. Download the selected song to your library.
3. Make sure the microSD™ card is inserted
properly into the headset.
4. Use the USB adapter cable to connect the
handset to the PC. When you try to connect
handset on your PC, the handset displays
“Connecting as Music Sync...”.
5. Once the USB connection has been
established, the handset displays
“Connected as Music Sync Mode. Do
not disconnect during transfer.“ and the
computer screen then shows the GR500
device. If the detection does not occur, skip
to Changing USB Connection Settings
section on page 45.
6. Follow the instruction in the program to
transfer music to your handset.
n
Note
If you have a USB hub, connect the handset
directly to your computer rather than through
the hub.
Transferring Music using
Windows Media Player
1. Open Windows Media® Player on your
computer (version 10.0 or higher).
2. Use the USB adapter cable to connect the
handset to the PC. When you try to connect
handset on your PC, the handset displays
“Connecting as Music Sync...”.
3. Once the USB connection has been
established, the handset displays
“Connected as Music Sync Mode. Do
not disconnect during transfer.“ and the
computer screen then shows the GR500
device.
AT&T Music
57
n
Note
If you have a USB hub, connect the handset
directly to your computer rather than through
the hub. If the target computer does not detect
the newly connected handset or provide an
MTP Player dialog window on the PC screen, If
the detection does not occur, skip to Changing
USB Connection Settings section on page 45.
4. From within the Windows Media®
Player application, click on the Sync tab.
Previously downloaded songs are then
listed on the left side of the application.
5. Choose the destination location for the
media files. The GR500 Music Sync Player
appears in a drop-down list on the right
side of the screen.
n
Note
If there are no items present in the playlist,
click the Edit Playlist button and begin adding
the music files from among the various media
categories.
6. Click on the checkmark boxes (to the left of
the song entry) to select the song you want
to synchronize to your handset.
7. Click the Start Sync button at the upper
right corner of the application to download
the selected songs to your handset.
A “synchronization in progress” message
appears on the application. Do not unplug
the handset during this process. Once
complete, a Music folder appears below
the GR500 Music Sync Player on the right
of the Sync tab.
8. It is now safe to unplug the USB connector
from the handset.
Drag and Drop Music Using
GR500 As A Mass Storage
Device
1. Insert a microSD™ memory card.
2. Power on the phone.
3. Connect the device to a PC using a GR500
USB data cable.
4. A bubble may appear, “Found New
Hardware LG USB Modem”.
5. Access My Computer on the PC.
6. The phone’s memory card will be listed
under “Devices with Removable Storage” in
the same location as an optical drive.
AT&T Music
58
n
Note
The PC will automatically assign a drive letter.
7. File explore in a new window for desired
music files.
8. Drag and drop the desired music content
from the PC window to the “Storage Card”
window.
9. Disconnect the device from the cable.
10. Access the Music Player on the phone.
n
Note
If the target computer does not detect the
newly connected handset as Mass Storage,
skip to Changing USB Connection Settings
section below.
Changing USB Connection
Settings
1. Touch and touch .
2. Touch More.
3. Select Connection.
4. Touch USB Connection Mode.
5. Touch Music Sync (if using Windows
Media® Player or other Digital Music
Services) or Mass Storage (if you are going
to drag or drop files).
6. Reconnect the device to a PC.
Deleting Music Files
When you have transferred files with the
Music Sync feature and you want to delete
them from your phone, you should connect
the phone to your PC with Music Sync. Even
if you have deleted files on your phone that
were transferred with Music Sync by one of
the following methods, delete them again
with Music Sync. The following are the three
options available to delete Music from your
Phone:
1. Delete a file using Mass Storage, but not
using Music sync function.
2. Delete a file by directly inserting the
microSD™ external memory onto the PC.
3. Delete a file using delete function on the
phone.
AT&T Music
59
n
Note
Be aware that all of the existing data will be
erased on microSD™ card if you use the below
process.
1. Use the Master Clear > memory card
function in the Settings menu.
2. Format external memory using Mass Storage.
Additional Music Services
There may be other AT&T music applications
preloaded or available for your phone that
allow you to:
]
Identify the name, artist and album to a
song from a song sample.
]
Listen to the latest Hip Hop, R&B, Rock,
Jazz, or Country streaming commercial-free
radio channels, anywhere you go.
]
View the latest music videos.
]
View music news and information.
]
Cut custom-made ringtones from the
favorite parts of your favorite songs, etc.
n
Note
Some sites are data intensive (i.e. previews via
streaming) so the user should be enrolled in an
unlimited data plan before using these services
to avoid per-use data charges.
n
Note
Additional charges may apply for downloading
content or use of these services.
60
Multimedia
CV
CV brings you quick, on-demand access to
news, sports, weather and entertainment
video clips. Catch up on TV’s hottest shows,
funniest comedians, biggest headlines
and latest sports scores. You can even
personalize your homepage for quick access
to your favorites. In addition, the CV service
automatically streams localized weather
information to your personalized “News &
Weather” page each and every day.
Games
n
Note
The JAR file is a compressed format of the Java
program and the JAD file is a description file
that includes all detailed information. From the
network, prior to download, you can view all
detailed file descriptions from the JAD file.
n
Warning
Only J2ME (Java 2 Micro Edition) based
programs will run in a phone environment.
J2SE (Java 2 Standard Edition) based programs
will only run in a PC environment.
]
Shop Games: This menu option connects
to AT&T’s game download site.
You can see the default and downloaded
games in the list.
61
My Stuff
CV
CV brings you quick, on-demand access to
news, sports, weather and entertainment
video clips. Catch up on TV’s hottest shows,
funniest comedians, biggest headlines
and latest sports scores. You can even
personalize your homepage for quick access
to your favorites. In addition, the CV service
automatically streams localized weather
information to your personalized “News &
Weather” page each and every day.
Audio
]
Shop Tones: This menu option connects to
AT&T’s ringtone download site.
]
Answer Tones: This menu option shows
the list of the sites which is related with
AT&T’s answer tone.
]
Voice Recorder: You can record your own
audio by touching .
]
You can view the audio files in the list.
Games
n
Note
The JAR file is a compressed format of the Java
program and the JAD file is a description file
that includes all detailed information. From the
network, prior to download, you can view all
detailed file descriptions from the JAD file.
n
Warning
Only J2ME (Java 2 Micro Edition) based
programs will run in a phone environment.
J2SE (Java 2 Standard Edition) based programs
will only run in a PC environment.
]
Shop Games: This menu option connects
to AT&T’s game download site.
You can see the default and downloaded
games in the list.
My Stuff
62
This allows you to view pictures when
browsing.
]
Shop Graphics: Connects to AT&T’s
graphic download site.
]
Take Photo: It takes you to move to the
camera mode.
]
Make Animated GIF: You can make an
animation file with the selected images
in the list.
]
Camera Album: You can open your camera
album.
]
You can view the graphic files in the list.
Video
]
Shop Videos: You can download videos.
]
Record Video: You can record your own
video.
]
You can view the video files in the list.
n
Note
DRM sometimes restricts some functions, such
as send and edit.
Tools
Voice Command
Voice command is the function whereby
your phone’s voice recognition engine
identifies the voice of the user and carries
out the requested commands. When the user
operates the voice command function, there
are five possible commands, call <name
or number>, Listen to voicemail, missed
calls, messages and time and date. Also, to
Activate the Voice Command function while in
standby mode:
My Stuff
63
1. Call <Name or Number>: This function
is activated only when the user says the
command "Call" followed by the name
stored in the address book or specified
phone number. The voice engine inside the
handset recognizes the user's utterance
and displays name lists or phone numbers
from the phone's address book. However,
interfering noise might cause a problem
displaying candidates. Additionally, the user
has the option to superimpose a number
type at the end, such as "mobile", "home"
or "office."
2. Listen Voicemail: this command is
activated when the user says the words
"Listen Voicemail." The user will then be
automatically connected to your voicemail.
3. Missed Calls: this command is activated
when the user says the words "Missed
Calls."The mobile phone presents missed
call lists.
• commands available to user
- yes: make the phone call
- no: moves to the next missed call list
- cancel: go back to the main voice
command menu
- exit: terminate voice command
4. Messages: this command is activated
when the user says the word "Messages."
Mobile phone displays details of unread
SMS or MMS messages.
• commands available to user
- yes: make the phone call
- no: moves to the next unread message
- cancel: go back to the main voice
command menu
- exit: terminate voice command
5. Time & Date: this command is activated
when the user says the words "time and
date." The phone displays the current local
time and date.
My Stuff
64
The voice command also has menu
options
• mode
- speed: voice command is abbreviated
- normal: voice command is played
normally
• train
- answer: enables the user to train for
answers used via voice command
- number: enables the user to train the
voice command for numbers used
• best match
- 1 match: the most likely match will be
displayed, finding a number from the
address book
- 4 matches: the four most likely matched
names will be displayed, finding a name
from the address book
• Sensitivity
- High: Operation and performance of
the voice recognition engine is rarely
affected by the user's voice command and
surrounding sound.
- Medium: Operation of voice recognition
engine is normally affected by user's voice
command and surrounding sound.
- Low: Operation of voice recognition
engine is strongly affected by user's voice
command and surrounding sound.
• Speakerphone mode
- automatic on: When this option is
selected, sound is loud enough so you can
hear the output when the phone is away
from the ear, at a distance
- off: When this option is selected, sound
is quieter, and cannot be heard when the
phone is away from the ear, at a distance
My Stuff
65
Notepad
You can create up to a maximum of 30
memos.
1. Touch and choose . Touch
and choose Notepad.
2. Input the memo and touch
to save.
World Clock
The World clock function provides time
information for major cities worldwide.
1. Touch and select New City.
2. Touch the default city name and it will
show alphabetically ordered cities name.
3. To make it easier, touch and It will
show the Globe. Touch twice the continent
and choose city you want to know the time.
My Stuff
66
4. You will see its date and time of that city
on the bottom side of the screen.Touch
and touch .
Tasks
This feature allows you to save and manage
a task.
1. Touch .
2. Input Due Date, Note and Priority for the
new Task.
3. Touch to save the Task item.
The following [Options] are available in the
Task list.
]
New Task: Allows you to create a new
task.
]
Delete: Deletes the selected task.
]
Selective Delete: Allows you to delete
tasks for All Completed/All Past Tasks
selectively.
]
Send Task Via: Enables the selected task
to be sent via Text Message/Multimedia
Message/Bluetooth®.
]
View Calendar: The calendar pop-up
window will display, from there you will be
able to create New Tasks.
My Stuff
67
Stopwatch
This menu allows you to record the elapsed
time of an event. The duration of an individual
lap time (up to 20 times) and the total time
can also be displayed.
]
New Time
1. To start timing, touch .
The running time is displayed as
HH.MM.SS.hh (hours, minutes, seconds,
hundredths of a second).
2. During the timing, you can record an
individual lap time by touching [Lap]. Up
to 20 lap times can be recorded.
3. You can stop or restart timing by
touching Stop or Start.
4. To reset the stop watch, touch [Reset].
]
Saved Times: You can see the saved
recorded times.
Tip Calculator
This feature allows you to quickly and easily
calculate the tip amount based on the total
bill as well as the split of the total bill based
on the number of people.
Unit Converter
This function converts any measurement into
a unit you want.
There are 6 types of units that can
be converted: Area, Length, Weight,
Temperature, Volume and Velocity.
n
Note
You can input a decimal by pressing the
[Star] key.
My Stuff
68
Alarm Clock
The alarm function allows you to set up
multiple separate alarms. You can also set
the time, repetition interval and alarm sound.
Select your desired alarm setting to configure
from the alarm list. If there is no alarm
setting, .
]
Time: Select the desired set time mode
using the select. Input your desired alarm
time by specifying the hour and minutes. If
the time is in the 12 hour format, you have
to select either or by touching it.
]
Repeat: Select the desired repeat mode
using the select.
]
Alarm Tone: Select the alarm sound to use
for the alarm using the Center key.
]
Memo: Input alarm name.
]
Snooze Interval: You can set the snooze
interval at 5 Minutes, 15 Minutes,
30 Minutes, 45 Minutes or I Hour. Now,
Touch to save your new
Alarm.
Calendar
When you enter this menu, a calendar will
be displayed. The red square cursor is used
to locate a particular day. The bottom bar on
the calendar indicates schedule(s) for that
day. This function helps to remind you of the
schedule. The phone will sound an alarm tone
if it has been set for a specific schedule item.
The chart below shows the keys that can be
used to navigate the Calendar:
The following [Options] are available when a
Calendar event is selected from the Calendar
menu.
]
Add new: Allows you to add a new
schedule on the date you select.
]
Search: Allows you to search the saved
schedule(s).
]
Delete: Allows you to delete the selected
schedule.
]
Set Holiday: Allows you to set your
personal holiday for the selected date.
My Stuff
69
]
View All: Allows you to view all saved
schedules.
]
Week View: Allows you to change
Calendar view mode from Monthly View to
Week View.
]
Go to Date: Allows you to jump to a
specific date.
]
Selective Delete: Allows you to delete
Old Schedules or All Schedules selectively.
]
Select Multiple: Allows you to select
multiple schedules.
]
Settings: Allows you set Default View and
Weekly Begin day.
Calculator
The calculator function allows you to add,
subtract, multiply and divide. You can input
numbers using the number keys, and input
operators using the touch key pad.
Use the key to delete numbers.
Camera & Recordings
Take Photo
Using the camera module built into your
phone, you can take pictures of people or
events while on the move. Additionally, you
can send photos to other people in a picture
message.
Use the select to the [Album] icon to access
the Album menu.
]
Album: You can see saved image files.
]
Video: Go to the video application, also
enabling you to record a video clip.
]
Capture: You can capture the image.
]
Flash: You can set the flash mode.
]
Macro: You can set macro On or Off.
The right soft key [Setting] will bring up the
following options.
My Stuff
70
Getting to know the viewfinder
Settings: Touch this icon to open the
settings menu. See Using the advanced
settings on page 49 for details.
Camera mode: Camera mode is selected.
Flash status
Size
Back: Touch here to return to the standby
screen.
Flash: See Using the flash on page 43.
Shot type: See Choosing a shot type on
page 43.
Shutter: Take the picture
Zoom: Touch to zoom in or to
zoom out. Alternatively you can use the side
volume keys.
Video camera mode: Convert from camera
to video camera mode.
My Stuff
71
n
Note
The shortcut options disappear after a few
seconds automatically. Simply touch the centre
of the viewfinder once. To recall the options
touch the screen again.
Preview tab
]
View Mode: Choose between Full Image
and Full Screen.
]
Image Size: The resolution of the image
can be captured in 1600*1200 / 1280*960 /
640*480 / 320*240.
]
Brightness: Adjust brightness by adjusting
slider.
]
Color Effects: Includes options of Color/
Mono/Sepia/Negative/Blue.
]
White Balance: Set the White Balance as
Auto/Daylight/Cloudy/Illuminate/Indoors.
]
Timer: Set the Timer can be set to
Off/3 Seconds/5 Seconds/10 Seconds.
]
Night Mode: This is useful to take a photo
at dark place.
]
Continuous Shot: This is great for taking
photos of moving objects or at sporting
events. Allows you to set 3 shots, 6 shots
or 9 shots continuously.
Others tab
]
Video Share: You can make a Video Share
Call. For more details, refer to Video Share
Calling (page 19).
]
Save to: Choose save a photo to Phone or
Memory Card.
]
Shutter Tones: Can be set to Tone 1/
Tone 2/Tone 3/Off.
]
Reset Settings: Allows you to set to the
default settings.
My Stuff
72
n
Note
In Take Photo mode, you can adjust the zoom
scale by moving the slider. The maximum zoom
scale depends on the resolution as follows.
Resolution Zoom scale
1600*1200 Level 1
1280*960 Level 1
640*480 Level 1 ~ Level 10
320*240 Level 1 ~ Level 10
Record Video
You can record a video clip in this menu by
pressing the Camera key or Center key. Before
starting to record, Touch [Settings] to set the
following values.
]
Album: You can see saved video files.
]
Photo: Go to the photo application, also
enabling you to create an image file.
]
Record: You can record the video.
]
Flash: You can set the flash mode.
]
Video Share: You can make a Video Share
Call. For more details, refer to Video Share
Calling (page 19).
My Stuff
73
Preview Tab
]
Video Size: Sets the size of video to
320*240 or 176*144. The selected size
appears on the capture screen.
]
Recording Speed: Sets the recording
speed from Fast/Normal/Slow.
]
Scene Mode: Select from Auto/Portrait/
Landscape/Night/Beach/Sports/Party.
]
Brightness: Adjust brightness by adjusting
slider.
]
Color Effects: Includes options of Color/
Mono/Sepia/Negative/Blue.
]
White Balance: Set the White Balance as
Auto/Daylight/Cloudy/Illuminate/Indoors.
]
Video Quality: Determines the quality
of a video clip. Includes options for Super
Fine/Fine/Normal.
]
Duration: Set the duration from General/
Video Share/MMS Mode.
Others Tab
]
Save to: Choose save a video clip to Phone
or Memory Card.
]
Voice: Mute or unmute the voice.
]
Recording Tones: Set Recording Tones
On or Off.
]
Reset Settings: Allows you to set to the
default settings.
n
Note
In Video Record mode, you can adjust the zoom
scale by moving the slider. The maximum zoom
scale depends on the resolution as follows.
Resolution Zoom scale
320*240 Level 1 ~ Level 10
176*144 Level 1 ~ Level 10
My Stuff
74
Camera Album
You can view the images that are captured
from Camera mode, using the options
One by One View/Sort by/Send/Use As/
Print via Bluetooth/Delete/Slide Show/
Edit/Display Date/File Information.
Record Voice
You can record an audio clip in this menu. The
recorded audio file is saved automatically in
the Audio & Ringtones menu.
Touching will bring up the following
options.
]
Record Mode: Sets the recording mode to
either MMS or General.
]
Quality: Determines the quality of an
audio clip.
]
Set Storage Defaults: You can set the
default storage of the recorded audio to the
Handset Memory or the Memory Card.
Touch [Gallery], which take you to Camera
album directly.
Web Pages
RSS Reader
With this program, you can open and view
files created in the format with RSS. The
following [Options] are available.
]
Update: You can update one RSS feed if
you can access the network.
]
Update all: You can update RSS feeds with
just one click.
]
New RSS Feed: You can add an RSS feed
manually.
]
Move: Move a RSS feed to another folder
which you added manually.
]
Delete: Allows you to erase the selected
RSS feed.
]
Send URL: Allows the RSS information to
be sent via SMS to another person.
]
New Folder: Add a new folder manually.
]
Update schedule: You can change the
schedule for updating RSS feeds.
]
Delete All: Delete all RSS feed.
My Stuff
75
Bookmarks
This function allows you to store and edit
frequently accessed sites.
The following [Options] are available.
]
New Bookmark: Add a new bookmark
manually.
]
Send URL: Allows the bookmark
information to be sent via SMS to another
person.
]
List View: You can view the preset
bookmarks list.
]
Select Multiple: Allows you to select
multiple bookmarks for moving or deleting.
n
Note
Pre-installed bookmarks cannot be deleted or
edited by users.
In order to change the text input mode for
symbol input, please refer to the General
Functions section.
Saved Pages
This saves the page on display as an offline
file. A maximum of 20 pages can be saved.
Recent Pages
You can manage the list of the Internet pages
you visited.
More
My Stuff
76
Other Files
When you receive files of an undefined format
(such as .vcs, .vcf, etc.) via email, the files are
saved in this folder.
The following [Options] are available.
]
Send via: Send the selected file via
Bluetooth® or MMS.
]
Delete: Allows you to delete the selected
file.
]
Move To: You can move the selected file.
]
Copy To: You can copy the selected file.
]
Rename: You can edit the name of the
selected file.
]
Select Multiple: You can delete, copy,
move, Send Via Message or Send via
Bluetooth® multiple files at once.
]
New Folder: Allows you to make a new
folder.
]
Sort by: You can sort the folders by name,
date and type.
]
Information: You can view information
about the selected file.
Memory Card
This function shows the status of the external
microSD™ card memory.
77
Contact List
This menu allows you to save and manage
contact address information. The Contact
List's functions allow you to add a new
address or search saved contact addresses
by name.
New Contact
This menu allows you to add a new contact
address. You can enter contact address
information including name, phone numbers,
email addresses, group information items,
memos, ring tones and images (photographs).
Caller Groups
This menu allows you to manage group
information. By default, there are 4 groups:
family, friends, colleagues and school. You
can also configure a ring tone for a group so
that the group ring tone sounds when a call
from a specific contact address within that
group is received and there is no ring tone
configured for the specific contact address.
Speed Dial List
This menu allows you to configure the speed
dial numbers. You can select a number from
2 to 9 as a speed dial. You can configure
speed dial numbers for any of the 8 numbers
for a specific contact address so that a
contact address may have multiple speed dial
numbers.
Address Book
Address Book
78
Contacts Management
This menu allows you to copy all of the
information from your SIM card, e.g. name,
handset number, etc. to your handset. If
a name is duplicated during the copying
operation, the information is also duplicated.
You can copy the entry from the SIM card to
the phone memory. You can copy the entry
from the handset memory to the SIM card (not
all the data will be copied).
You can delete all entries in the SIM card the
Handset. Press the [END] key to return
to standby mode.
Service Dial Numbers
You can view the list of Service Dialing
Numbers (SDN) assigned by your network
provider. Such numbers could include the
emergency services, directory assistance and
voice mail numbers.
1. Select the Service dial number option.
2. The names of the available services will
be shown.
3. Touch a service number. Press the
[SEND] key.
My Numbers
This displays your phone numbers stored in
the SIM card.
79
Settings
Audio & Ringtones
There are 5 sound modes: General, Vibrate
All, Alarm Only, Silent All and Ear Mic.
All modes can be changed from the Volume
menu under Ringtone. In addition, pressing
and holding the [Star] key on idle screen
mode switches between Normal mode and
Vibrating mode. Ear Mic is available when
respective instruments are attached.
Shop Tones
Connects to AT&T Ringtone Shops.
Volume
This menu controls Ringtone & Alerts,
Multimedia, Call and Keypad volume.
Ringtone
]
Sounds: Shows and plays ring tones.
These can be downloaded ring tones from
Ringtone shops.
]
Alert Type: Supports 3 ring alert types.
Ring, Ring and Vibration and Ring after
Vibration.
]
Increasing Ringtone: Allows you to select
an Increasing Ringtone type which is played
when you receive an incoming call. You can
elect to turn this On or Off.
Message Tone
]
Sounds: Shows and plays message tones.
These can be downloaded ring tones from
Ringtone shops.
]
Alert Type: Supports 6 message alert
types: Ring Once, Ring Every 2 Min., Ring
Every 15 Min., Ring & Vibrate, Vibrate and
Silent.
n
Note
Full length music tracks cannot be set as either
ringtones or message tones.
Alert Tone
]
Sounds: Allows you to select a set of alert
tones. Supports 2 alert tone types, Alert
Tone 1 and Alert Tone 2.
]
Alert Type: You can elect to turn Alert
Tones to Ring or Silent.
Settings
80
Keypad Tone
This menu option allows you to select a tone
that the phone sounds when a key is pressed.
You can select an option from Melody and
Voice.
Power On/Off Tones
You can elect to turn Power On/Off Tones to
Ring or Silent.
Phone Settings
Date & Time
]
Set Date: This allows you to enter the day,
month and year. You can change the date
format via the Date Format menu option.
]
Date Format:
ddd, MM DD (day, month date)
MM/DD/YYYY (month/date/year)
DD/MM/YYYY (date/month/year)
YYYY/MM/DD (year/month/date)
]
Set Time: This allows you to enter the
current time. You can choose the time
format via the Time Format menu option.
]
Time Format: 12 Hours/24 Hours
]
Auto Update: Select On to set the phone
to automatically update the time and date
according to the current local time zone.
Languages
You can change the language for the display
text on your phone. This change will also
affect the Language Input mode.
Set Shortcuts
You can change the preferences on the
Shortcuts that are currently assigned for your
select Touchpad.
Auto Key Lock
This allows you to set the amount of time
before your Keys lock automatically.
Settings
81
Set Flight Mode
This allows you to use only the phone's
features that do not require the use of the
wireless network when you are in an airplane
or in places where the wireless network is
prohibited. If you set the flight mode on, the
icon will be displayed on the screen instead
of the network signal icon.
]
On: You cannot make (or receive) any calls,
including emergency calls or use other
features that require network coverage.
]
Off: You can deactivate the flight mode and
restart your handset to access the network.
Security
Various codes and passwords are used to
protect the features and settings of your
phone. They are described in the following
sections.
Reset Settings
This function allows you to restore factory
settings. To do this, you need the security
code.
]
Master Reset: Restores the settings (e.g.:
Audio, Display, Language, Date & Time,
Bluetooth® Settings) stored in the handset
memory to default values.
]
Master Clear: Deletes downloaded/user
created contents (e.g.: images, videos)
from Handset content and the External
Memory card.
• Phone
- Deletes all downloaded/user created
Images, Videos & Sounds from the
Handset Memory.
- Restores Deletes Personal Information
stored in the handset memory (e.g.:
address book, messages, tasks, alarm,
Calendar schedules) to default values.
- Restores the settings stored in the
handset memory to the default values.
• Memory Card: Deletes all contents from
the External Memory Card.
Settings
82
Display
Shop Graphics
Connects to AT&T’s graphic download site.
Wallpapers
From this menu you can select to have a
picture for a background or a Solid Color.
Fonts
You can configure the font size and color of
the numbers which appear in the home screen
when you make a call.
Clocks & Calendar
This feature allows you to select the Clock or
Calendar display that appears on the standby
screen.
Brightness
You can set the brightness of the display
screen and the keypad. The default setting is
on Automatic - this phone comes equipped
with a light sensor that automatically adjusts
the brightness depending on your surrounding
environment.
Backlight Timer
Use this to set the duration of the backlight
and keypad.
Color Schemes
You can change the color of the menu, soft
key area, title bar area and cursor by changing
the Color Schemes. You can select Black or
White Schemes.
Menu Styles
You can configure the menu style to Icon style
or List style.
Touch Keypad
You can set the Touch light style and Respond
Type such as Vibrate Only, Sound Only, Sound
& Vibration and Sient.
Settings
83
Call
Call Forwarding
When this network service is activated, you
can direct your incoming calls to another
number, for example, to your voice mailbox
number. For details, contact AT&T. Select one
of the divert options, for example, select If
Busy to divert voice calls when your number is
busy or when you reject an incoming call.
The following options are available:
]
All Voice Calls: Diverts voice calls
unconditionally.
]
If Busy: Diverts voice calls when the phone
is in use.
]
If No Answer: Diverts voice calls which
you do not answer.
]
If Out of Reach: Diverts voice calls
when the phone is switched off or out of
coverage.
Send My Number
This network service allows you to set your
phone number to be displayed On or hidden
Off from the person you are calling. You
can select Set by Network if you prefer to
have different settings for different service
providers.
Auto Redial
Select On, your phone redials the number
you're trying to call up to 10 times after you
hear a quick, busy signal. Press [END]
to stop the call attempts.
This feature attempts to redial numbers that
are engaged due to the wireless network. It
does not redial numbers to an engaged party.
n
Note
There will be no alert indicating the call has
been connected. You must stay on the line to
hear when the call is connected.
Recent Calls
This shows recent calls categorized to All/
Missed/Dialed/Received by tab.
Settings
84
Answer Mode
This allows you to determine how to answer
the phone.
]
Any Key: You can answer an incoming
call by touching the [SEND] or
[Clear] Key. except the [END] key.
]
Send Key Only: You can only answer
an incoming call by pressing the
[SEND] key.
]
Slide Open: You can slide open the phone
to answer an incoming call.
Minute Minder
This option allows you to specify whether
the phone will beep every minute during an
outgoing call to keep you informed of the
length of the call.
Call Waiting
The network will notify you of a new incoming
call while you have a call in progress. Select
Activate to request the network to activate
call waiting, Deactivate to request the
network to deactivate call waiting or View
Status, to check if the function is active or
not.
Call Reject
This menu allows you to enable or disable call
reject for all numbers or a specific number.
]
Call Reject On/Off: This feature
allows you to choose whether to reject
the incoming calls unconditionally by
disconnecting. When the Reject All Calls
option is set, all incoming calls are routed
directly to Voicemail. Reject on List allows
you to enable Call Reject for the numbers
saved on your Call Reject List.
]
Call Reject List: Configures conditional
call reject mode. After tapping [New], you
can add to the call reject list by selecting
[Contact List] or [New Number]. When
you add a number to the list, you can add
the number by entering it directly or by
searching for the number in the Contact
List.
Send DTMF Tones
Select from On/Off
TTY
Select from TTY Full/TTY Talk/TTY Hear/TTY
Off.
Settings
85
Time & Cost
You can check Call Duration and Data Counter.
Connection
Bluetooth
®
Your phone has built-in Bluetooth® wireless
technology, which makes it possible for you
to connect your phone wirelessly to other
Bluetooth® devices such as a hands-free
device, PC, PDA, a remote screen or other
phones. The devices registered in your phone
can only be connected one at a time. (To make
a connection to the same type of device or
change Bluetooth® preferences, disconnect
the existing device first.)
You can have a conversation via a cordless
Bluetooth® hands-free phone or browse the
Internet, wirelessly connected, via a mobile
phone.
You can also exchange, for example, business
cards, calendar items and pictures.
MobiTV, XMRadio or Music Playing is
supported through a Bluetooth® headset.
Hands-free profile
This icon appears when the hands-free
profile is used between the hands-free
device. This allows you to call using a
Bluetooth® connection.
A2DP profile
This icon appears when the A2DP profile
is used between the stereo headset
device and the phone. This allows you
to listen to an audio clip. A2DP is the
Advanced Audio Distribution Profile,
which provides support for streaming
either mono or stereo audio using
Bluetooth®.
Hands-free + A2DP profile
This icon appears when both profiles of
the hands-free and the A2DP are used
between the compatible device and
the phone. This allows you to call and
listen to an audio clip using a Bluetooth®
connection.
When using each device, see the manual that
comes with the device.
Settings
86
n
Note
We recommend that your phone and the
Bluetooth® device you are communicating with
should be no more than 10 meters apart. The
connection may be improved if there are no
solid objects between your phone and the other
Bluetooth® device.
]
Turn On/Off: This menu sets the Bluetooth®
on or off.
]
My Visibility On/Off
- Selecting the On option exposes your
phone to other Bluetooth® devices.
- Selecting Off shows your phone to
already-paired devices only.
]
Search New Device: This function allows
you to search for and add new devices.
]
My Devices: This function allows you to
view the list of all devices that are paired
with your phone.
1. Touch Search new device to search for
the device that can be connected, and
which is also within range.
2. If you want to stop searching, press the
right soft key [Cancel].
3. All of the devices found are displayed.
Touch the desired device and enter the
password.
]
My Bluetooth® Info: This menu allows you
to configure the profile for Bluetooth®.
- Enter My Name: Allows you to change
the handset's name, this can be seen by
other Bluetooth® devices.
- Supported Services: Shows you all
services that the handset supports.
Settings
87
USB Connection Mode
You can transfer files from a compatible PC
to the memory in your phone using the Mass
Storage. When you connect the phone to a PC
using the USB cable, this will be displayed as
a removable disk through Windows Explorer.
The USB Connection Mode determines how
your Phone will communicate with other
USB devices when they are connected with
a USB cable.
Internet Profiles
This menu shows the Internet Profiles. You
can add, delete and edit Internet Profiles by
using the Options Menu. However, you cannot
delete or edit default configurations provided
by AT&T.
Access Points
This menu shows the Access Points. You can
register, delete and edit by using the Options
Menu. However, you cannot delete or edit
default configurations provided by AT&T.
Memory
Used Space
This function shows the status of the user
memory of the handset.
Phone Reserved
This function shows the status of the reserved
memory for the user (Text Message, Contact
List, Calendar, Tasks, Memo).
Memory Card
If your phone has a multimedia memory
card in the card slot, you can save images,
sounds and videos on the memory card. You
can check the current status of the external
memory card in the Memory status menu.
SIM Card
This function shows the status of the SIM
Card user memory.
Settings
88
Set Storage Defaults
Application Settings
This Menu allows you to adjust the settings
to the following features on the phone:
Video Share
]
Audio Alert: Enable/Disable auditory alert
when Video Share is available.
]
Auto Record: Enable/Disable automatic
video clip recording when live Video Share
starts.
Messaging
Browser
Accounts
This includes the network information used
to connect the browser to the Internet.
Select the desired account by tapping the
screen, then tap [Activate]. This will activate
the account that will be used for future
connections. MEdia Net is the predefined
account that is set as default.
]
Activate: Select the account among the
list of accounts, so it can be used for future
connections.
]
View: Allows you to see the specific
account information.
The following options will be available when
you press on the right soft key [Options]:
]
Edit: Allows you to change the account
information.
]
Delete: Allows you to delete the account.
]
New: Allows you to create a maximum of
20 new accounts.
Settings
89
n
Note
You cannot edit and delete pre-installed
accounts.
In order to create a new account, please fill in
the network information.
1. Account Name: Name associated with
new account.
2. Homepage: Homepage URL.
3. Internet Profile: You can choose one from
the Internet profiles.
Note you can choose a Internet profile by
selecting the list option on the center key.
n
Note
1. AT&T has provided default settings regarding
account information.
2. Creating or editing an account requires
caution. The browser cannot connect to
the Internet if the account information is
incorrect.
Appearance
You can choose the settings of the browser
appearance (Text size, Character Encoding,
Scrolling Control, Show Image, Java Script).
Cache
The web pages you have accessed are stored
in the memory of the phone.
]
Clear Cache: Remove all cached data in
the memory.
]
Allow Cache: Set a value to determine
whether a connection attempt is made
through the cache or not.
n
Note
A cache is a buffer memory, which is used to
store data temporarily, especially when it is
online.
Cookies
The information of services you have accessed
are stored in what is called a Cookie.
From this Menu you can choose to Allow
Cookies, or not, or to Delete Cookies that are
already on your phone.
Qpass
If set to On, the user's personal information
such as their ID and Password used to access
the Internet site will be saved automatically
for future use.
Settings
90
Security
A list of the available certificates is shown.
]
Certificates: You can see the list of
certificates and view them in detail.
]
Clear Session: Removes the secure
session.
Secure Pop-up
You can control the pop-up which indicates a
secure page or not.
Browser Shortcut
If this is set to On, you can use the browser
more quickly and conveniently with the
key pad in the phone. If Shortcut is on, the
following number of buttons is available.
1. Enter URL
3. Add This Page
5. Full Screen
7. Page Down
9. Search Text
*. View Bookmarks
2. Recent Page
4. Page up
6. Page Overview
8. New Window/Tab
0. Zoom In
#. Zoom Out
Voice Command
Software Update
If new software exists, the AT&T server
notifies devices using a WAP push message.
Before updating new software after
downloading it from the AT&T server, users
can decide whether they would like to
postpone the operation. Reminder times can
be set to 30 minutes, 1 hour and 4 hours.
When the time is up, users are prompted
again or users can resume the postponed
operation using this menu at any time.
Phone Information
This menu is used to view My Numbers,
Manufacturer, Model Name, Device ID,
Hardware Version, Software Version,
Language and DM Client Version.
