Models/Modelos MC-1083KS
MICROWAVE / CONVECTION OVEN
Use and Care Guide
HORNO DE MICROONDAS/CONVECCIÓN
Manual de uso y cuidado
3828W5A3702
2
ENGLISH
TABLE OF CONTENTS
WARRANTY ......................................................... 2
SAFETY ........................................................... 3~4
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy......................... 3
Grounding Instructions........................................ 3
Important Safety Instructions.............................. 4
UNDERSTANDING YOUR
MICROWAVE OVEN ........................................ 5~6
Specifications...................................................... 5
Installation........................................................... 5
Parts and accessories ........................................ 6
Control Panel...................................................... 6
UNDERSTAND YOUR MICROWAVE OVEN
.... 7~10
Cooking Comparison Guide.................................7
Cookware Guide................................................. 8
How to Use Accessories......................................9
Tips for Microwave Cooking ............................. 10
Cleaning............................................................ 10
USING YOUR CONVECTION OVEN........... 11~23
Options.............................................................. 11
Options Table .................................................... 11
Child Lock ......................................................... 11
Kitchen Timer .....................................................11
Multi-Stage Cooking ......................................... 12
Microwave Power Levels.................................. 12
Add Minute........................................................ 12
Sensor Touch Operation Instruction ................ 13
Sensor Reheat...................................................13
Sensor Reheat Table .........................................13
Sensor Cook ......................................................14
Sensor Cook Table ............................................14
Sensor Popcorn .................................................14
Auto Defrost.......................................................15
Auto Defrost Table .............................................15
Tips for Convection Cooking............................. 16
Convection........................................................ 17
Convection Cooking Guide............................... 18
Convection Baking Table ...................................19
Meat Roasting Table for Convection Cooking ...20
USING YOUR COMBINATION OVEN ......... 21~23
Tips for Combination Cooking ...........................21
Helpful Hints for Combination Cooking..............21
Precautions........................................................21
Combination Roast & Bake ...............................21
Combination Cooking Guide..............................22
Combination Auto Cook.....................................23
Combination Auto Cook Gulde ..........................23
HEATING/REHEATING GUIDE.......................... 24
FRESH VEGETABLE GUIDE ............................ 25
TROUBLESHOOTING ................................. 26~28
Questions and Answers.............................. 26~27
Before Calling for Service................................. 28
MASTER PROTECTION AGREEMENTS...........29
WARRANTY
FULL ONE-YEAR WARRANTY ON
MICROWAVE OVEN
For one year from the date of purchase, if this
Kenmore microwave oven fails due to a defect
in material or workmanship, Sears will repair it
free of charge.
FULL FIVE-YEAR WARRANTY ON
THE MAGNETRON
For five years from the date of purchase, if the
magnetron in this Kenmore microwave oven
fails due to a defect in material or workmanship,
Sears will repair it free of charge.
WARRANTY SERVICE
For warranty service, return the microwave to
your nearest Sears Parts and Repair Center in
the United States. For the location of your
nearest Sears Parts and Repair Center, call
1-800-4-MY-HOME®
.
This warranty applies only while this product is
in use in the United States.
This warranty gives you specific legal rights,
and you may also have other rights which vary
from state to state.
Sears, Roebuck and Co.,
Dept. 817WA,
Hoffman Estates, IL 60179 U.S.A.
ENGLISH
3
SAFETY
• DO NOT attempt to operate this oven with the
door open, since open-door operation can
result in harmful exposure to microwave
energy. It is important not to defeat or
tamper with the safety interlocks.
• DO NOT operate the oven if it is damaged.
It is particularly important that the oven door
close properly and that there is no damage to
the:
1. door (bent)
2. hinges and latches (broken or loosened)
3. door seals and sealing surfaces.
• DO NOT place any object between the oven
front face and the door, or allow soil or
cleaner residue to accumulate on sealing
surfaces.
• THE OVEN should not be adjusted or
repaired by anyone except properly qualified
service personnel.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
GROUNDING INSTRUCTIONS
This appliance must be grounded! If an electrical short
circuit occurs, grounding reduces the risk of electric
shock by providing an escape wire for the electric
current. This appliance is equipped with a cord having
a grounding wire with a grounding plug.
Put the plug into an outlet that is properly installed and
grounded.
WARNING
If you use the grounding plug improperly, you risk electric shock.
If you use an extension cord, be sure that:
NOTE: This oven draws 12.5 amperes at 120 Volts, 60 Hz.
• The extension cord has the same electrical rating as
the appliance.
• The marked rating of the extension cord shall be
equal to or greater than the electrical rating of
the appliance.
• The extension cord is a grounding-type 3-wire cord.
• The extension cord does not drape over a
countertop or tabletop, where it can be pulled on
by children or tripped over accidentally.
• The electrical cord is dry and not pinched or
crushed in any way.
Ask a qualified electrician or the Sears Service
Department if you do not understand the grounding
instructions or if you wonder whether the appliance is
properly grounded.
This appliance has a short power supply cord to reduce
the risk of anyone’s tripping over or becoming
entangled in the cord. You may use an extension cord if
you are careful.
4
ENGLISH
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
The safety instructions below will tell you how to use your microwave oven to avoid harm to yourself or damage to your oven.
WARNING – To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to excessive
microwave energy:
SAVE THESE INSTRUCTIONS!
1. Read all the instructions before using your microwave
oven.
2. Do not allow children to use this oven without close
supervision!
3. Read and follow the specific PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY found on page 3.
4. Do not tamper with the built – in safety switches on the
oven door! The oven has several built-insafety switches to
make sure the power is off when the door is open.
5. When cleaning the door and the surfaces that touch
the door, use only mild, nonabrasive soaps or
detergents and a sponge or soft cloth.
6. If your oven is dropped or damaged, have it thoroughly
checked by a qualified service technician before using it
again.
7. To avoid a fire hazard:
a) Do not severely overcook foods. It can cause a fire in
the oven.
b) Do not use recycled paper products in your oven.
They can contain particles that can cause arcing or may
ignite.
c) Do not overcook potatoes. Overcooking could cause a
fire.
d) Do not store combustible items (bread, cookies, etc.)
in the oven, because if lightning strikes the power lines,
it may cause the oven to turn ON.
e) Do not use wire twist-ties in the oven. Be sure to
remove them before placing the item in the oven.
f) Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in the
cavity when not in use.
8. If a fire should start:
a) Keep the oven door closed.
b) Turn the oven off.
c) Disconnect the power cord or shut off thepower at
the fuse or circuit breaker panel.
9. Do not use this oven for commercial purposes. This
microwave is made for household use only.
10. Install or locate this appliance in accordance with the
provided installation instructions.
11. To avoid electric shock:
a) This appliance must be grounded! Connect it only to
a properly grounded outlet. (See the Grounding
instructions on page 3.)
b) Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly, or if it has
been damaged or dropped.
c) Do not immerse the electrical cord or plug in water.
d) Keep the cord away from heated surfaces.
e) This appliance should be serviced only by qualified
service personnel.
12. Liquids such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to
be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the microwave oven is not always present. This could
result in very hot liquids suddenly boiling over When the
container is disturbed or when a spoon or other utensil is
inserted into the liquid. To reduce the risk of injury to
persons;
1) Do not overheat the liquid.
2) Stir the liquid both before and halfway through heating it.
3) Use extreme care when inserting a spoon or other
utensil into the container once heating has begun.
4) Do not use straight-sided containers with narrow
necks.
5) After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
13. Keep the glass tray and the turntable roller rest in the
oven when you are cooking.
14. Do not use the oven outdoors. Do not store the oven
outdoors. Do not use this product near water.
– for example, near a kitchen sink, in a wet basement,
near a swimming pool, or similar location.
15. Do not cover or block any openings in the oven.
16. Do not run the microwave oven empty.
17. Do not let the cord hang over the edge of a table or
counter.
18. Do not heat glass turntable excessively.
– Do not cook bacon directly on the glass turntable.
– Do not allow the grey film on special microwave cooking
packages to touch the glass turntable.Put the package
on a microwave-safe dish.
– Keep a browning dish at least 3⁄16 inch above the glass
turntable. If you use the browning dish incorrectly, you
could break the glass turntable.
19. Be careful not to chip or scratch the edges of the
turntable. Chips or scratches may cause the turntable to
break during use.
20. Some produce such as whole eggs and sealed containers
- for example, closed glass jars are able to explode and
should not be heated in this oven.
ENGLISH
5
UNDERSTANDING YOUR MICROWAVE OVEN
SPECIFICATIONS
*IEC 60705 RATING STANDARD
Specifications subject to change without prior notice.
Power Supply
Rated Power Microwave
Consumption Convection
Power Output Microwave
Convection
Frequency
Rated Current Microwave
Convection
Overall Dimensions (WxHxD)
Oven Cavity Dimensions (WxHxD)
Capacity of Oven Cavity
120 V AC, 60 Hz
1,400 W
1,350 W
1,000W*
1,350W
2,450 MHz
12.5 A
11 A
201/8” x 121/4” x 195/16”
14” x 81/2” x 1313/16”
1.0 Cu. Ft.
INSTALLATION
A. Circuits
For safety purposes this oven must be plugged into a
20 Amp circuit. No other electrical appliances or lighting
circuits should be on this line. If in doubt, consult a
licensed electrician.
B. Voltage Warning
The voltage used at the wall receptacle must be the
same as specified on the oven name plate located on
the front or on the side of the control panel of the oven.
Use of a higher voltage is dangerous and may result in
a fire or other type of accident causing oven damage.
Low voltage will cause slow cooking. In case your
microwave oven does not perform normally in spite of
proper voltage, remove and reinsert the plug.
C. Placement of the Oven
Your microwave oven can be placed easily in your
kitchen, family room, or anywhere else in your home.
Place the oven on a flat surface such as a kitchen
countertop or a specially designed microwave oven cart
at least 100cm (39.4 inches) from floor. Do not place
oven above a gas or electric range. Free air flow around
the oven is important. Allow at least 4 inches
of space at the top, sides, and back of the oven for
proper ventilation.
NOTES:
•Never place the turntable in the oven upside down.
D. Do not block the air vents
All air vents should be kept clear during cooking. If air
vents are covered during oven operation the oven may
overheat. In this case, a sensitive thermal safety device
automatically turns the oven off. The oven will be
inoperable until it has cooled sufficiently.
E. Radio interference
1. Microwave oven operation may interfere with TV
or radio reception.
2. When there is interference, it may be reduced or
eliminated by taking the following measures:
a. Clean the door and the sealing surfaces of the
oven.
b. Reorient the receiving antenna of radio or TV.
c. Relocate the microwave oven in relation to the
TV or radio.
d. Move the microwave oven away from the
receiver.
e. Plug the microwave oven into a different outlet
so that microwave oven and receiver are on
different branch circuits.
Your oven comes with the following accessories:
1 Use and Care Guide
1 Glass Turntable
1 Turntable Roller Rest
1 Metal Tray
1 Metal Rack
6
ENGLISH
UNDERSTANDING YOUR MICROWAVE OVEN
PARTS AND ACCESSORIES
CONTROL PANEL
Easy-Clean
Oven Cavity
See-Through Door
Safety Interlock System
Oven Control
Panel
Glass Turntable
Metal Tray
Turntable Roller Rest
Metal Rack
3
6
9
10
13
16
1
2
4
5
7
8
11
12
14
15
1. DISPLAY. The display includes a clock and indicators that tell
you time of day, cooking time settings, and cooking functions
selected.
2. CONVECTION. Touch this button to cook foods on convection
mode.
3. MICROWAVE. Touch this button to cook foods on microwave
mode, and to set cooking time and power level.
4. ROAST. Touch this button to roast foods on combination mode.
5. BAKE. Touch this button to bake foods on combination mode.
6. AUTO COOK. Touch this pad to cook foods automatically on
combination mode.
7. TURN TO SELECT, PRESS TO ENTER . Turn the dial to set
clock, category, temperature, cooking time, power level, food
quantity and then press it to enter.
8. SENSOR REHEAT. Touch this button to reheat foods without
entering cooking time and power level.
9. SENSOR COOK. Touch this button to cook most of your favorite
foods without entering cooking time or power level.
10. SENSOR POPCORN. Touch this button to cook popcorn
automatically.
11. OPTIONS. Touch this button to change the oven's default
settings for sound, clock, scroll speed and Lbs/kg.
12. AUTO DEFROST: Touch this button to defrost Meat, Poultry,
Fish and Bread automatically.
13. KITCHEN TIMER. Touch this button to use your oven as a
kitchen timer.
14. START. Touch this button to start entries and to turn Child Lock
on or off.
15. ADD MINUTE. Touch this button to cook at 100% cooking power
for 1 minute to 99 minutes 59 seconds .
16. STOP/CLEAR: Touch this button to stop the oven or to clear
entries.
ENGLISH
7
COOKING COMPARISON GUIDE
UNDERSTANDING YOUR MICROWAVE OVEN
Cooking with your new oven offers a wide variety of food
preparation options: microwave cooking, convection
cooking, and combination cooking.
Microwave cooking uses very short, high-frequency
radio waves. The movement of the microwaves through
the food generates heat and cooks most foods faster
than regular methods, while retaining their natural
texture and moisture. Microwave cooking heats food
directly, not the cookware or the interior of the oven.
Reheating is easy and defrosting is particularly
convenient because less time is spent in food
preparation.
Convection cooking constantly circulates heated air
around the food, creating even browning and sealed-in
flavor by the constant motion of hot air over the food
surfaces.
Combination cooking combines microwave energy
with convection to cook with speed and accuracy, while
browning and crisping to perfection.
You can use microwave cooking, convection cooking, or
combination cooking to cook by time. Simply preset the
length of cooking time desired and your oven turns off
automatically.
The following guide shows at a glance the difference
between microwave, convection, and combination
cooking.
MICROWAVE
Microwave energy is
distributed evenly
throughout the oven for fast,
thorough cooking of food.
Microwave energy.
• Fast, high efficiency
cooking.
• Oven and surroundings do
not get hot.
• Easy clean-up.
COOKING
METHOD
HEAT SOURCE
BENEFITS
CONVECTION
Hot air circulates around
food to produce browned
exteriors and sealed-in
juices.
Circulating heated air.
• Aids in browning and seals
in flavor.
• Cooks some foods faster
than regular ovens.
COMBINATION
Microwave energy and
convection heat combine to
shorten the cooking time of
regular ovens, while
browning and sealing in
juices.
Microwave energy and
circulating heated air.
• Shortened cooking time
from microwave energy.
• Browning and crisping
from convection heat.
Read this guide to learn the many different things your Microwave/Convection/Combination Oven can do.
You will find a wide variety of cooking methods and programs designed to suit your lifestyle.
8
ENGLISH
UNDERSTANDING YOUR MICROWAVE OVEN
COOKWARE GUIDE
Microwave Cooking
Most heat-resistant, non-metallic cookware is safe for
use in your microwave oven.
However, to test cookware before using, follow these
steps:
1. Place the empty cookware in the microwave oven.
2. Measure 1 cup of water in a glass measuring cup and
place it in the oven beside the cookware.
3. Microwave on 100% power for 1 minute. If the dish is
warm, it should not be used for microwave cooking.
Convection Cooking
•Metal Pans are recommended for all types of baked
products, but especially where browning or crusting is
important.
• Dark or dull finish metal pans are best for breads and
pies because they absorb heat and produce a crisper
crust.
• Shiny aluminum pans are better for cakes, cookies, or
muffins because these pans reflect heat and help
produce a light, tender crust.
• Glass or glass-ceramic casserole or baking dishes are
best suited for egg and cheese recipes due to the
cleanability of glass.
Combination Cooking
• Glass or glass-ceramic baking containers are
recommended. Be sure not to use items with metal trim
as it may cause arcing (sparking) with oven wall or
oven shelf, damaging the cookware, the shelf or the
oven.
• Heat-resistant plastic microwave cookware (safe to
450°F) may be used, but is not recommended for foods
that require crusting or all-around browning, because
plastic is a poor conductor of heat.
COOKWARE MICROWAVE CONVECTION COMBINATION
Heat-Resistant Glass, Ceramic Glass
Yes Yes Yes
Ceramics, China Yes Yes Yes
(Do not use china
with gold or silver trim.)
Metal Cookware No Yes No
Non Heat-Resistant Glass No No No
Microwave-Safe Plastic Yes No Yes*
Plastic Wrap, Wax Paper Yes No No
Paper Products Yes No No
Straw, Wicker, and Wood Yes No No
* Use only microwave cookware that is safe to 450°F
ENGLISH
9
UNDERSTANDING YOUR MICROWAVE OVEN
HOW TO USE ACCESSORIES
Glass Turntable
MICROWAVE CONVECTION COMBINATION
Notes :
•Do not operate the oven when it is empty except preheating.
: Possible to use
: Recommended method
X: Do not use
X
X
XX
X
Metal Tray Metal Rack
10
ENGLISH
UNDERSTANDING YOUR MICROWAVE OVEN
TIPS FOR MICROWAVE COOKING
BROWNING
Meat and poultry with high fat content that are cooked
for 10 or 15 minutes or longer will brown lightly. Foods
cooked a shorter time can be brushed with a browning
agent, such as Worcestershire sauce, soy sauce, or
barbecue sauce.
COVERING
A cover traps heat and steam and causes the food to
cook more quickly. Use a lid or microwave-safe plastic
wrap with one corner folded back to vent the excess
steam. Lids on glass casseroles can become hot
during cooking. Handle carefully. Waxed paper will
prevent the food from splattering in the oven and help
retain heat. When warming bread items, use waxed
paper, napkins, or paper towels. To absorb extra
moisture, wrap sandwiches and fatty foods in paper
towels.
SPACING
Arrange individual foods, such as baked potatoes,
cupcakes, and hors d’oeuvres’ in a circle and at least
1 inch apart. This will help the food cook more evenly.
STIRRING
Stirring blends flavors and redistributes the heat in
foods. Always stir from the outside toward the center
of the dish. Food at the outside of the dish heats first.
TURNING
Large foods, such as roasts and whole poultry, should
be turned so that the top and bottom cook evenly. Also
turn over chicken pieces and chops.
ARRANGEMENT
Do not stack food. Arrange in a single layer in the dish
for more even cooking. Because dense foods cook
more slowly, place thicker portions of meat, poultry, fish,
and vegetables toward the outside of the dish.
TESTING FOR DONENESS
Because foods cook quickly in a microwave oven, you
need to test frequently for doneness.
STANDING TIME
Depending on density, food often needs to stand from
2 to 15 minutes either in or outside of oven after
cooking power shuts off. Outside of oven, you usually
need to cover food during standing time to retain heat.
Remove most foods when they are slightly undercooked
and they will finish cooking during standing time. The
internal temperature of food will rise about 10°F during
standing time.
SHIELDING
To prevent some portions of rectangular or square
dishes from overcooking, you may need to shield
them with small strips of aluminum foil to block the
microwaves. You can also cover poultry legs and
wing tips with foil to keep them from overcooking.
Always keep foil at least 1 inch from oven walls
to prevent arcing.
PIERCING
Pierce the shell, skin, or membrane of foods before
cooking to prevent them from bursting. Foods that
require piercing include yolks and whites of eggs, hot
dogs, clams, oysters, and whole vegetables, such as
potatoes and squash.
CLEANING
Wipe the oven inside and outside with a soft cloth and
a mild detergent solution. Then rinse and wipe dry.
This should be done weekly or more often, if needed.
Never use cleaning powders or rough pads.
Excessive oil splatters on the inside top will be difficult
to remove if left for many days. Wipe splatters with a
wet paper towel, especially after cooking chicken or
bacon.
REMOVABLE PARTS
The metal tray, metal rack, glass turntable and turntable
roller rest are removable. They should be hand-washed
in warm (not hot) water with a mild detergent and a soft
cloth. Once they are clean, rinse well and dry with a soft
cloth. Never use cleaning powders, steel wool, or rough
pads.
• Removable parts may be cleaned at the sink. Be
careful not to chip or scratch the edges as this may
cause them to break during use.
• The metal tray and glass turntable may also be
cleaned in a dishwasher.
• The turntable roller rest should be cleaned regularly.
SPECIAL CARE
For best performance and safety, the inner door panel
and the oven front frame should be free of food or
grease buildup. Wipe often with a mild detergent; then
rinse and wipe dry. Never use cleaning powders or
rough pads.
After cleaning the control panel, touch STOP/CLEAR
to clear any entries that might have been entered
accidentally while cleaning the panel.
ENGLISH
11
USING YOUR MICROWAVE OVEN
Time of day.
Time of day.
Use this safety feature to lock the control panel
when you are cleaning the oven, or so that children
cannot use the oven unsupervised.
Example: To set Child Lock
Touch: Display Shows:
CHILD LOCK
Turn the dial
until “3:00”
appears.
Touch and hold
until “LOCKED”
appears.
(approximately
4 seconds).
Touch and hold
until “LOCKED”
disappears.
(approximately
4 seconds).
To cancel CHILD LOCK:
Touch: Display Shows:
Time of day.
locked
1.
1.
2.
Your microwave oven can be used as a kitchen
timer. You can set up to 99 minutes.
Example: To set 3 minutes.
Touch: Display Shows:
KITCHEN TIMER
1.
2.
3.
4.
1.
Example: To set the clock for 10:30(AM)
Touch: Display Shows:
OPTIONS
2.
3.
4.
turn dial to change
option
Turn the dial.
Turn the dial
to set “AM”.
Turn the dial
until “10:00”
appears.
Turn the dial
until “10:30”
appears.
Press the dial.
Press the dial.
Press the dial.
OPTIONS TABLE
FUNCTION CHOICES
Hour, Minute, AM/PM
Sound On/Off
Clock On/Off
Fast/Normal/Slow
Lbs/kg
Clock Setting
Sound On/Off
Clock On/Off
Scroll Speed
Unit
10
clock setting press
dial
turn dial to set hour
5.
6
press dial
turn dial to set
minute
turn dial to set time
in min and sec
press start
Start timer.
7.
8.
press dial
turn dial to set
am/pm
9.
press start
NOTE: When the power cord is first plugged in, the
default settings are Sound On, Clock On, Normal
Speed and Lbs.
::
AM
10
::
30
12
ENGLISH
USING YOUR MICROWAVE OVEN
Time of day.
ADD MINUTE
A time-saving pad, this simplified control lets
you quickly set and start microwave cooking at
100% power without the need to touch START.
Example: To cook for 2 minutes.
Touch: Display Shows:
1.
2.
NOTE: If you touch ADD MINUTE, it will add
1 minute up to 99 minutes 59 seconds.
Time counting down
and power 100
For best results, some recipes call for different cooking
powers during different stages of a cook cycle. You can
program your oven for 2 stages, so that it will switch
from one power level to another during the cook cycle.
Example: To set a 2-stage cook cycle.
(Power 80% for 2 min. and power 50% for 3 min.)
Touch: Display Shows:
MULTI-STAGE COOKING
1.
2.
5.
3.
4.
6.
Time of day.
power80
press start
turn dial to set
cooking time
turn dial to set
cooking time
press start or dial
power 100
turn dial to set power
level
Press the
dial.
Turn the dial
until “2:00”
appears.
Turn the dial
until
“POWER80”
appears.
7.
9.
start cooking.
8.
10.
11.
power50 press start
Turn the dial
until
“POWER50”
appears.
press start or dial
Turn the dial
until “3:00”
appears.
power 100
turn dial to set power
level.
Press the
dial.
Twice
When the first stage is over, you will hear two
short tones as the oven begins the second
cook stage.
MICROWAVE POWER LEVELS
Your microwave oven has 10 cook power levels to let
you cook or heat a wide variety of foods. Refer to the
table below for suggestions:
Microwave Power Level Table
• Boiling water.
• Making candy.
• Cooking poultry pieces, fish, and
vegetables.
• Cooking tender cuts of meat.
• Whole poultry.
• Reheating rice, pasta, and vegetables.
• Reheating prepared foods quickly.
• Reheating sandwiches.
• Cooking egg, milk, and cheese dishes.
• Cooking cakes, breads.
• Melting chocolate.
• Cooking veal.
• Cooking whole fish.
• Cooking puddings and custard.
• Cooking ham, whole poultry, and lamb.
• Cooking rib roast, sirloin tip.
• Thawing meat, poultry, and seafood.
• Cooking less tender cuts of meat.
• Cooking pork chops, roast.
• Taking chill out of fruit.
• Softening butter.
• Keeping casseroles and main dishes warm.
• Softening butter and cream cheese.
• Standing time.
10
(High)
9
8
7
6
5
4
3
2
1
0
Use
Power
Level
ENGLISH
13
USING YOUR MICROWAVE OVEN
This feature allows you to reheat precooked room-
temperature or refrigerated foods without selecting
cooking times and power levels. This feature has 3
categories : Dinner Plate, Soup/Sauce, Casserole.
See the following table for more information.
Example : To reheat casserole.
Touch: Display Shows:
SENSOR REHEAT
The oven will reheat food automatically by sensor
system.
2. turn dial to set menu
CASSEROLE
3.
Time of day.
1.
SENSOR COOKING OPERATION
INSTRUCTION
A sensor detects steam from the food and automatically
adjusts cook time for the best cooking results. It’s easy
and convenient—the oven will guide you, step-by-step,
to cook or reheat foods. The Sensor Menu, with many
popular food choices, is preprogrammed to cook or
reheat food perfectly everytime.
For more information about Sensor Cooking
Programs, see the “Sensor Reheat & Cook Tables”
on pages 13-14. These tables provides specific
instructions for cooking and heating a variety of
foods.
•The Sensor Cooking system works by detecting a
build-up of vapor.
•Make sure the door remains closed.
•Once the vapor is detected, two beeps will sound.
•Opening the door or touching the STOP/CLEAR
before the vapor is detected will abort the
process. The oven will stop.
•Before using Sensor Cooking, make sure the
glass turntable is dry, to assure the best results.
Categories:
Sensor Reheat
Sensor Cook
Sensor Popcorn
SENSOR REHEAT TABLE
Amount
Approx.
1/2 -1lb
1-4 cups
1-4 cups
Direction
Place foods to be heated
on dinner plate or similar
dish. Cover with plastic
wrap and vent. After
cooking, allow to stand
for 3 minutes.
Place foods to be heated
in an appropriately sized
microwave container.
Cover with plastic wrap
and vent. After cooking,
stir and allow to stand for
3 minutes.
Cover dish containing
the casserole with plastic
wrap and vent. After
cooking, stir and allow to
stand for 3 minutes.
Category
Dinner
plate
Soup/
Sauce
Casse-
role
ENGLISH
14
USING YOUR MICROWAVE OVEN
The oven will cook food automatically by sensor
system.
NOTES:
•Do not attempt to reheat or cook any unpopped
kernels.
•Do not use popcorn popping devices in microwave
oven with this feature.
•If you use a microwave popper, test it on sensor.
There are many such devices available and their
results may vary.
•IN NO CASE should you use a popper that concen-
trates the microwave energy.
SENSOR COOK
SENSOR COOK allows you to cook most of your
favorite foods without having to select cooking times
and power levels. The oven automatically determines
required cooking times for each food item.
SENSOR COOK has 5 food categories.
Example : To cook frozen entrée.
Touch: Display Shows: Example : To pop 3.5 oz.
Touch: Display Shows:
Time of day.
turn dial to set menu
frozen entree
SENSOR POPCORN
SENSOR POPCORN lets you pop commercially
packaged microwave popcorn (3.0 or 3.5 oz.).
For best results:
• Use fresh popcorn.
• Place only one bag of prepackaged microwave
popcorn on the center of turntable.
2.
3.
1.
The oven will cook food automatically by sensor
system.
Time of day.
POPCORN
2.
1.
SENSOR COOK TABLE
NOTE: If you open the door or press STOP/CLEAR during sensing, the process will be canceled.
CATEGORY
Potato
Rice
Frozen
Entrée
Fresh
Vegetable
Frozen
Vegetable
DIRECTION
Pierce each potato with a fork and place on the oven tray around
the edge, at least one inch apart. After cooking, allow to stand for
5 minutes.
Place rice and twice as much liquid (water or chicken or
vegetable stock) in a 2-quart microwavable dish. Cover with
plastic wrap. When cooking is complete, allow 10 minutes
standing time. Stir for fluffier rice.
Remove from outer display package. Slit cover. If not in
microwave-safe container, place on plate, cover with plastic
wrap, and vent. After cooking, allow to stand for 5 minutes.
Prepare as desired, wash, and leave residual water on the
vegetables. Place in an appropriately-sized microwave container,
cover with plastic wrap and vent. After cooking, allow to stand for
5 minutes.
Remove from package, rinse off frost under running water. Place
in an appropriately-sized microwave container, cover with plastic
wrap and vent. After cooking, allow to stand for 5 minutes.
AMOUNT
1~4 medium approx.
8 to10 oz. each
1/2~2 cups Use medium or
long grain rice. Cook instant
rice according to directions on
the package.
10 to 21 oz.
1~4 cups
1~4 cups
ENGLISH
15
USING YOUR MICROWAVE OVEN
AUTO DEFROST
Four defrost choices are preset in the oven. The defrost
feature provides you with the best defrosting method for
frozen foods because the oven automatically sets the
defrosting times for each food item according to the
weight you enter. For added convenience, the AUTO
DEFROST includes a built-in tone mechanism that
reminds you to check, turn over, separate, or rearrange
the food during the defrost cycle. Four different
defrosting options are provided.
1. MEAT
2. POULTRY
3. FISH
4. BREAD
After touching the AUTO DEFROST button once, select
the food category by turning the dial. Available weight
ranges for Meat, Poultry and Fish are 0.1 to 6.0 lbs.
The available weight range for Bread is 0.1 to 1.0 lb.
For best results:
• Remove fish, shellfish, meat, and poultry from its
original closed paper or plastic package (wrapper).
Otherwise, the wrap will hold steam and juice close to
the foods, which can cause the outer surface of the
foods to cook.
• Form the meat into the shape of a doughnut before
freezing. When defrosting, scrape off thawed meat
when the beep sounds and continue defrosting.
• Place foods in a shallow glass baking dish or on a
microwave roasting rack to catch drippings.
• Foods should still be somewhat icy in the center
when removed from the oven.
NOTE: After you touch START button, the display
counts down the defrost time. The oven will beep once
during the Defrost cycle. At this time, open the door and
turn, separate, or rearrange the food as needed.
Remove any portions that have thawed then return
frozen portions to the oven and touch START button to
resume the defrost cycle. The oven will not STOP
during the BEEP unless the door is opened.
Example : To defrost 1.2 lbs of meat.
Touch: Display Shows:
Time of day.
turn dial to set
menu
2.
3.
1.
meat press dial
Turn the dial.
4. turn dial to enter
weight
Press the dial.
5. press start
Turn the dial
until “1.2 lbs”
appears.
6. defrost
AUTO DEFROST TABLE
Category Food
MEAT
0.1 to 6.0 lbs
(0.1 to 4.0kg)
POULTRY
0.1 to 6.0 lbs
(0.1 to 4.0kg)
FISH
0.1 to 6.0 lbs
(0.1 to 4.0kg)
BREAD
0.1 to 1.0 lbs
(0.1 to 0.5kg)
BEEF
Ground beef, Round steak, Cubes for stew,
Tenderloin steak, Pot roast, Rib roast,
Rump roast, Chuck roast, Hamburger patty.
LAMB
Chops (1-inch thick), Rolled roast
PORK
Chops (
1/2
-inch thick), Hot dogs, Spareribs,
Country-style ribs.
Rolled roast, Sausage.
VEAL
Cutlets (1 lb,
1/2
-inch thick)
POULTRY
Whole (under 4 lbs), Cut up, Breasts (boneless)
CORNISH HENS
Whole
TURKEY
Breast (under 6 lbs)
FISH
Fillets, Whole Steaks
SHELLFISH
Crab meat, Lobster tails, Shrimp, Scallops
MUFFINS
ROLL CAKE
16
ENGLISH
USING YOUR CONVECTION OVEN
TIPS FOR CONVECTION
COOKING
This section gives you cooking instructions and
procedures for operating each convection function.
Please read these instructions carefully.
Convection cooking circulates hot air through the oven
cavity with a fan. The constantly moving air surrounds
the food to heat the outer portion quickly, creating even
browning and sealed-in flavor by the constant motion of
hot air over the food surfaces. Your oven uses
convection cooking whenever you use the Convection
Button. DO NOT USE THE OVEN WITHOUT THE
TURNTABLE IN PLACE.
1. Always use the metal rack on the turntable when
convection cooking.
2. Do not cover turntable or metal rack with aluminum
foil. It interferes with the flow of air that cooks the food.
3. Round pizza pans are excellent cooking utensils for
many convection-only items.
Choose pans that do not have extended handles.
4. Use convection cooking for items like soufflés,
breads, cookies, angel food cakes, pizza, and for
some meat and fish cooking.
5. Your oven comes equipped with metal tray which can
be used for cooking on convection mode or
combination mode.
6. You do not need to use any special techniques to
adapt your favorite oven recipes to convection
cooking; however, you may need to lower some
temperatures or reduce some cooking times from the
convectional oven cooking directions. See examples
in the charts in this section.
7. When baking cakes, cookies, breads, rolls, or other
baked foods, most recipes call for preheating. Preheat
the empty oven just as you do a regular oven. You can
start heavier dense foods such as meats, casseroles,
and poultry without preheating.
8. All heatproof cookware or metal utensils can be used
in convection cooking.
9. As in conventional cooking, the distance of the food
from the heat source affects cooking results. Refer to
the charts in this Use and Care Guide.
10. Use metal utensils only for convection cooking.
Never use for microwave or combination cooking
since arcing and damage to the oven may occur.
11. After preheating, if you do not open the door, the
oven will automatically hold at the preheated
temperature for 30 minutes.
12. Lower oven temperature by 25°F from package
recommended temperature.
PRECAUTIONS
•The oven cavity, door, turntable, rotating ring, metal
racks, and cooking utensils will become very hot.
USE THICK OVEN GLOVES when removing the food,
cooking utensil, metal rack, and turntable from the oven
after convection cooking.
•Do not use lightweight plastic containers, plastic wraps,
or paper products during any convection cycle.
ENGLISH
17
USING YOUR CONVECTION OVEN
CONVECTION
During convection cooking, a heating element is used to
raise the temperature of the air inside the oven.
Convection cooking temperature range from 225°F to
450°F and 100°F may be programmed.
It is best to preheat the oven when convection cooking.
Lower oven temperature by 25°F from package
recommended temperature.
NOTES:
•When the oven reaches the set preheat temperature,
five tones will sound and the oven will automatically
hold that temperature for 30 minutes.
•The oven temperature drops very quickly when the
door is opened; however, this should not prevent food
from being fully cooked during normal cooking time.
NOTES:
• The temperature range has 10 steps from 225°F to
450°F including 100°F (dough rising).
• Turn the dial to increase/decrease the temperature by
25°F after touching the CONVECTION button. (The
default temperature is 350°F.)
After preheating display scrolls “PREAHEAT end”
with sound. Open the door, place food on the oven
rack, and close the door.
Display scrolls “ Turn dial to set cooking time”
Example: To set the convection cooking at 325°F
for 45 minutes with preheating.
Touch: Display Shows:
Time of day.
1.
turn dial to set
temperature or
press dial
2.
press start or dial
3.
preheat
4.
325f convection
6.
Turn the dial
until “325F”
appears.
press start
5. Turn the dial
until “45:00”
appears.
Example: To set the convection cooking at 375°F
for 30 minutes without preheating.
Touch: Display Shows:
Time of day.
1.
turn dial to set
temperature or
press dial
2.
press start or dial
3.
375f convection
6.
Turn the dial
until “375F”
appears.
375f Press start
5. Turn the dial
until “30:00”
appears.
375f turn dial to
set cooking time
4. Press the dial.
18
ENGLISH
USING YOUR CONVECTION OVEN
CONVECTION COOKING GUIDE
1. Always use the metal rack when convection baking.
Place food directly on rack or place in metal tray and
then place tray on rack. (See page 9.)
2. Aluminum pans conduct heat quickly. For most
convection baking, light, shiny finishes give best
results because they prevent overbrowning in the
time it takes to cook the center areas. Pans with dull
(satin-finish) bottoms are recommended for cake
pans and pie pans for best bottom browning.
3. Dark or non-shiny finishes, glass, and pyroceram
absorb heat which may result in dry, crisp crusts.
4. Preheating the oven is recommended when baking
foods by convection.
5. To prevent uneven heating and save energy, open
the oven door to check food as little as possible.
FOOD Oven Temp. Time, Min. Comments
Breads
Cakes
Cookies
Biscuits
Corn Bread
Muffins
Popovers
Nut Bread or Fruit Bread
Yeast Bread
Plain or Sweet Rolls
Angel Food
Cheesecake
Coffee Cake
Cup Cakes
Fruit Cake (loaf)
Gingerbread
Butter Cakes, Cake Mixes
(2 layers)
Fluted Tube Cake
Pound Cake
Bar
Drop or Sliced
375°F
375°F
375°F
325°F
350°F
375°F
350°F
325°F
325°F
325°F
325°F
275°F
325°F
325°F
325°F
325°F
325°F
350°F
10 to 12
15 to 20
18 to 24
30 to 40
55 to 65
18 to 25
13 to 16
40 to 50
60 to 65
25 to 30
15 to 20
80 to 90
35 to 40
30 to 40
40 to 50
60 to 70
35 to 45
10 to 14
Canned refrigerated biscuits take 2
to 4 minutes less time.
Remove from pans immediately and
cool slightly on wire rack.
Pierce each popover with a fork
after removing from oven to allow
steam to escape.
Interiors will be moist and tender.
Lightly grease baking sheet.
Invert and cool in pan.
After cooking, turn oven off and let
cheesecake stand in oven 30
minutes with door ajar.
Interior will be moist and tender.
Use 2 shelves. Top layer may bake
in less time.
Grease and flour pan.
Cool in pan 10 minutes before
inverting on wire rack.
Use same time for bar cookies from
a mix.
Use same time for sliced cookies
from a mix.
ENGLISH
19
USING YOUR CONVECTION OVEN
CONVECTION BAKING TABLE
FOOD Oven Temp. Time, Min. Comments
Fruits,
Other
Desserts
Pies,
Pastries
Casseroles
Convenience
Foods
Main
Dishes
Vegetables
Baked Apples or Pears
Bread Pudding
Cream Puffs
Custard (individual)
Meringue Shells
Frozen
Meringue-topped
Two-crust
Quiche
Pastry Shell
Meat, chicken, seafood
combinations
Pasta
Potatoes, scalloped
Vegetable
Frozen Bread Dough
Frozen Dinners
Frozen Entrée
Frozen Pizza Rolls,
Egg Rolls
Pizza
Slice and Bake Cookies
Meat Loaf
Oven-Baked Stew
Swiss Steak
Stuffed Peppers
Acorn Squash Halves
Baked Potatoes
Twice-Baked Potatoes
350°F
300°F
400°F
350°F
300°F
375°F
325°F
400°F
350°F
400°F
350°F
350°F
350°F
350°F
350°F
350°F
350°F
400°F
425°F
375°F
325°F
325°F
350°F
350°F
375°F
425°F
400°F
30 to 40
35 to 40
30 to 35
45 to 50
30 to 35
40 to 45
13 to 16
50 to 55
30 to 35
10 to 16
20 to 40
25 to 45
55 to 60
25 to 35
30 to 35
20 to 25
50 to 60
8 to 10
15 to 25
13 to 15
55 to 60
80 to 90
60 to 70
40 to 45
55 to 60
50 to 60
25 to 30
Bake in cookware with shallow sides.
Pudding is done when knife inserted
near center comes out clean.
Puncture puffs twice with toothpick
to release steam after 25 minutes
of baking time.
Set cups in baking dish. Pour
boiling water around cups to a
depth of 1 inch.
When done, turn oven off and let
shells stand in oven 1 hour to dry.
Follow package directions.
Follow package directions.
Follow package directions.
Let stand 5 minutes before cutting.
Pierce pastry with fork to prevent
shrinkage.
Cook times vary with casserole size
and ingredients.
Cook times vary with casserole size
and ingredients.
Let stand 5 minutes before serving.
Cook times vary with casserole size
and ingredients.
Follow package directions.
Follow package directions.
Follow package directions.
Follow package directions.
Follow package directions.
Let stand a few minutes before
removing from pan to cool.
Let stand 5 minutes after cooking.
Brown meat before combining with
liquid and vegetables.
Let stand 2 minutes after cooking.
Use green, red, or yellow peppers.
Pierce skin several places. Add
1/4
cup water to dish. Turn squash
halves cut side up after 30 minutes
of cook time and cover.
Pierce skin with a fork before
baking.
Pierce skin with fork before baking.
20
USING YOUR CONVECTION OVEN
MEAT ROASTING TABLE FOR CONVECTION COOKING
MEATS MINUTES/POUNDOVEN TEMPERATURE
Beef
Ham
Lamb
Pork
Poultry
Seafood
Rib (2 to 4 lbs.)
Rare
Medium
Well
Boneless Rib, Top Sirloin
Rare
Medium
Well
Beef Tenderloin
Rare
Medium
Pot Roast (2
1/2
to 3 lbs.)
Chuck, Rump
Canned (3-lb. fully cooked)
Butt (5-lb. fully cooked)
Shank (5-lb. fully cooked)
Bone-in (2 to 4 lbs.)
Medium
Well
Boneless (2 to 4 lbs.)
Medium
Well
Bone-in (2 to 4 lbs.)
Boneless (2 to 4 lbs.)
Pork Chops
(
1/2
to 1-inch thick)
2 chops
4 chops
6 chops
Whole Chicken
(2
1/2
to 3
1/2
lbs.)
Chicken Pieces
(2
1/2
to 3
1/2
lbs.)
Cornish Hens
Unstuffed (1 to 1
1/2
lbs.)
Stuffed (1 to 1
1/2
lbs.)
Duckling (4 to 5 lbs.)
Turkey Breast
(4 to 6 lbs.)
Fish, whole
(3 to 5 lbs.)
Lobster Tails
(6 to 8-oz. each)
21 to 26
26 to 31
31 to 36
25 to 30
30 to 35
35 to 40
12 to 16
16 to 20
45 to 50
20 to 25
20 to 25
17 to 20
21 to 26
26 to 31
25 to 30
29 to 34
26 to 30
32 to 36
12 to 15
15 to 18
18 to 25
25 to 35
13 to 16
10 to 15
15 to 20
19 to 21
21 to 25
10 to 15
12 to 17
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
325°F
375°F
350°F
375°F
375°F
375°F
325°F
400°F
350°F
ENGLISH
21
USING YOUR COMBINATION OVEN
TIPS FOR COMBINATION COOKING
This section gives you instructions to operate each
combination cooking function. Please read these
instructions carefully. Sometimes combination
microwave-convection cooking is suggested to get the
best cooking results since it shortens the cooking time
for foods that normally need a long time to cook. This
cooking process also leaves meats juicy on the inside
and crispy on the outside. In combination cooking, the
convection heat and microwave energy alternate
automatically. Your oven has three preprogrammed
settings that make it easy to use combination cooking.
HELPFUL HINTS FOR
COMBINATION COOKING
1. Meats may be roasted directly on the metal rack or in
a shallow roasting pan placed on the rack. When
using the metal rack, please check your cooking
guide for information on proper use.
2. Less tender cuts of beef can be roasted and
tenderized using oven cooking bags.
3. When baking, check for doneness after cooking time
is up. If not completely done, let stand in oven for a
few minutes to complete cooking.
PRECAUTIONS
1. All cookware used for combination cooking must be
BOTH microwave-safe and ovenproof.
2. During combination baking, some baking cookware
may cause arcing when it comes in contact with the
oven walls or metal accessory racks. Arcing is a
discharge of electricity that occurs when microwaves
come in contact with metal.
— If arcing occurs, place a heatproof dish between
the pan and the metal rack.
— We recommend you use the metal tray applied
with your oven. It has rubber feet that helps
prevent arcing.
— If arcing occurs with other baking cookware, do not
use them for combination cooking.
COMBINATION ROAST & BAKE
Oven Microwave
Temperature Power
Combination Roast 375°F 30%
Combination Bake 325°F 10%
Example: To roast with combination cooking for
45 minutes.
Touch: Display Shows:
Time of day.
1.
turn dial to set
temperature or
press dial
2.
375f turn dial to
set cooking time
3.
375f combi roast
5.
Press the dial.
375f press start
4. Turn the dial
until “45:00”
appears.
NOTES:
• The temperature range has 10 steps from 225°F to
450°F including 100°F (dough rising).
• By turning the dial in combination cooking, you can
set the desired temperature.
22
ENGLISH
USING YOUR COMBINATION OVEN
COMBINATION COOKING GUIDE
MEATS COMBINATION
TEMPERATURE MINUTES/POUND
Beef
Ham
Lamb
Pork
Poultry
Seafood
Rib (2 to 4 lbs.)
Rare
Medium
Well
Boneless Rib, Top Sirloin
Rare
Medium
Well
Beef Tenderloin
Rare
Medium
Chuck, Rump or Pot Roast (2
1/2
to 3 lbs.)
(Use cooking bag for best results.)
Turn over after half of cooking time.
Canned (3-lb. fully cooked)
Butt (5-lb. fully cooked)
Shank (5-lb. fully cooked)
Turn over after half of cooking time.
Bone-in (2 to 4 lbs.)
Medium
Well
Boneless (2 to 4 lbs.)
Medium
Well
Turn over after half of cooking time.
Bone-in (2 to 4 lbs.)
Boneless (2 to 4 lbs.)
Pork Chops (
3/4
to 1-inch thick)
2 chops
4 chops
6 chops
Turn over after half of cooking time.
Whole Chicken
(2
1/2
to 6 lbs.)
Chicken Pieces
(2
1/2
to 6 lbs.)
Cornish Hens
Unstuffed
Stuffed
Duckling
Turkey Breast (4 to 6 lbs.)
Turn breast side up after half of cooking time.
Fish
1-lb. fillets
Lobster Tails
(6 to 8-oz. each)
Shrimp
(1 to 2 lbs.)
Scallops
(1 to 2 lbs.)
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
275°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
300°F
350°F
350°F
350°F
400°F
375°F
375°F
375°F
375°F
300°F
350°F
350°F
350°F
350°F
11 to 14
14 to 17
17 to 20
11 to 14
14 to 17
17 to 20
14 to 17
17 to 20
30 to 40
15 to 18
15 to 18
15 to 18
13 to 18
18 to 23
14 to 19
19 to 24
13 to 16
14 to 17
10 to 13
13 to 16
16 to 19
18 to 20
15 to 18
18 to 25
23 to 30
15 to 18
11 to 15
7 to 10
10 to 15
8 to 13
8 to 13
ENGLISH
23
USING YOUR COMBINATION OVEN
COMBINATION AUTO COOK
Use this function to cook food without entering
cooking time or power level on combination mode.
AUTO COOK has 4 food categories. Refer to the
following auto cook guide for more information.
Example: To cook 3.5 lbs whole chicken.
Touch: Display Shows:
Time of day.
1.
2.
whole chicken
press dial
turn dial to set
menu
3.
WHOLE CHICKEN
6.
Turn the dial.
press start
5. Turn the dial
until “3.5 Lbs”
appears.
turn dial to enter
weight
4. Press the dial.
COMBINATION AUTO COOK
GUIDE
Amount
2.0~4.0 lbs
(0.9~1.8 kg)
0.4~2.0 lbs
(0.2~0.9 kg)
1~4 ea.
10~21 oz.
Direction
Thoroughly wash inside and
outside of chicken with cold
water. Pat chicken dry with
paper towels, secure the
legs with kitchen twine.
Brush outside of chicken
with melted butter or
margarine. Place chicken
breast side down on metal
rack on metal tray.
After cooking, loosely tent
chicken with aluminum foil.
Let stand for 10 minutes
after cooking.
Pat chicken pieces dry with
paper towels. Brush chicken
pieces with melted butter or
margarine. Arrange chicken
pieces on metal rack on
metal tray.
Pierce each potato several
times with a fork and place
on metal rack metal tray.
Remove from outer
package. Remove film cover.
If entrée is not in a
ovenproof container, place it
on a ovenproof dish. Place
on metal rack on metal tray.
Let stand for 5 minutes after
cooking.
Category
Whole
Chicken
Chicken
Pieces
Baked
Potato
Frozen
Lasagna
24
ENGLISH
HEATING / REHEATING GUIDE
To heat or reheat successfully in a microwave oven, it is important to follow several guidelines. Measure the amount
of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for best results. Room
temperature food will heat faster than refrigerated food. Canned foods should be taken out of the can and placed in a
microwave-safe container. The food will heat more evenly if covered with a microwave-safe lid or vented plastic wrap.
Remove cover carefully to prevent steam burns. Use the following chart as a guide for reheating cooked food.
ITEMS COOK TIME SPECIAL INSTRUCTIONS
(AT HIGH)
Sliced meat Place sliced meat on microwavable plate.
3 slices (1/4-inch thick) 1-2 minutes Cover with plastic wrap and vent.
Note: Gravy or sauce helps to keep meat juicy.
Chicken pieces
1 breast 2-31/2minutes Place chicken pieces on microwavable plate. Cover with plastic
1 leg and thigh 11/2-3 minutes wrap and vent.
Fish fillet Place fish on microwavable plate. Cover with plastic wrap and
(6-8 oz.) 2-4 minutes vent.
Lasagna Place lasagna on microwavable plate. Cover with plastic wrap
1 serving (101/2oz.) 4-6 minutes and vent.
Casserole
1 cup 1-31/2minutes COOK covered in microwavable casserole. Stir once halfway
4 cups 5-8 minutes through cooking.
Casserole –
cream or cheese
1 cup 11/2-3 minutes COOK covered in microwavable casserole. Stir once halfway
4 cups 31/2-51/2minutes through cooking.
Sloppy Joe or Barbecued Beef Reheat filling and bun separately.
1 sandwich 1-21/2minutes Cook filling covered in microwavable casserole. Stir once.
(1/2cup meat filling) Heat bun as directed in chart below.
without bun
Mashed potatoes
1 cup 1-3 minutes COOK covered in microwavable casserole. Stir once halfway
4 cups 5-8 minutes through cooking.
Baked beans COOK covered in microwavable casserole.Stir once halfway
1 cup 11/2-3 minutes through cooking.
Ravioli or pasta in sauce
1 cup 21/2-4 minutes COOK covered in microwavable casserole. Stir once halfway
4 cups 71/2-11 minutes through cooking.
Rice
1 cup 11/2-31/2minutes COOK covered in microwavable casserole. Stir once halfway
4 cups 4-61/2minutes through cooking.
Sandwich roll or bun
1 roll 15-30 seconds Wrap in paper towel and place on glass microwavable rack
Vegetables
1 cup 11/2-21/2minutes COOK covered in microwavable casserole. Stir once halfway
4 cups 4-6 minutes through cooking.
Soup COOK covered in microwavable casserole. Stir once halfway
1 serving (8 oz.) 11/2-21/2minutes through cooking.
ENGLISH
25
FRESH VEGETABLE GUIDE
Standing
Time
Artichokes 2 medium 5-8 Trim. Add 2 tsp water and 2 tsp juice. Cover. 2-3 minutes
(8 oz. each) 4 medium 10-13
Asparagus, 1 Ib. 3-6 Add 1/2cup water. Cover. 2-3 minutes
Fresh, Spears
Beans, Green & 1 lb. 7-11 Add 1/2cup water in 11/2qt. casserole. Stir 2-3 minutes
Wax halfway through cooking.
Beets, Fresh 1 Ib. 12-16 Add 1/2cup water in 11/2qt. covered casserole. 2-3 minutes
Rearrange halfway through cooking.
Broccoli, Fresh, 1 Ib. 4-8 Place broccoli in baking dish. Add 1/2cup water. 2-3 minutes
Spears
Cabbage, Fresh, 1 Ib. 4-7 Add 1/2cup water in 11/2qt. covered casserole. 2-3 minutes
Chopped Stir halfway through cooking.
Carrots, Fresh, 2 cups 2-4 Add 1/4cup water in 1 qt. covered casserole. 2-3 minutes
Sliced Stir halfway through cooking.
Cauliflower, 1 lb. 7-11 Trim. Add 1/4cup water in 1 qt. covered casserole. 2-3 minutes
Fresh, Whole Stir halfway through cooking.
Flowerettes, Fresh 2 cups 21/2-41/2Slice. Add 1/2 cup water in 11/2 qt. covered casserole. 2-3 minutes
Celery, Fresh, 4 cups 6-8 Stir halfway through cooking.
Sliced
Corn, Fresh 2 ears 5-9 Husk. Add 2 tbsp water in 11/2qt. baking dish. 2-3 minutes
Cover.
Mushrooms, 1/2Ib. 2-31/2Place mushrooms in 11/2qt. covered casserole. 2-3 minutes
Fresh, Sliced Stir halfway through cooking.
Parsnips, Fresh, 1 Ib. 4-8 Add 1/2cup water in 11/2 qt. covered casserole. 2-3 minutes
Sliced Stir halfway through cooking.
Peas, Green, 4 cups 7-10 Add 1/2cup water in 11/2qt. covered casserole. 2-3 minutes
Fresh Stir halfway through cooking.
Sweet Potatoes 2 medium 5-10 Pierce potatoes several times with fork. 2-3 minutes
Whole Baking 4 medium 7-13 Place on 2 paper towels. 2-3 minutes
(6-8 oz. each) Turn over halfway through cooking.
White Potatoes, 2 potatoes 5-8 Pierce potatoes several times with fork. 2-3 minutes
Whole Baking 4 potatoes 10-14 Place on 2 paper towels. 2-3 minutes
(6-8 oz. each) Turn over halfway through cooking.
Spinach, Fresh, 1 Ib. 4-7 Add 1/2cup water in 2 qt. covered casserole. 2-3 minutes
Leaf
Squash, Acorn or 1 medium 6-8 Cut squash in half. Remove seeds. 2-3 minutes
Butternut, Fresh Place in 8 x 8-inch baking dish. Cover.
Zucchini, Fresh, 1 Ib. 41/2-71/2Add 1/2cup water in 11/2qt. covered casserole. 2-3 minutes
Sliced Stir halfway through cooking.
Zucchini, Fresh, 1 Ib. 6-9 Pierce. Place on 2 paper towels. 2-3 minutes
Whole Turn over and rearrange halfway through cooking.
Vegetable Amount Instructions
Cook Time
at High
(Minute)
26
ENGLISH
TROUBLESHOOTING
Questions and Answers
Operation
Question
Why is the oven light not on during
cooking?
Why does steam come out of the air
exhaust vent?
Will the microwave oven be damaged if it
operates empty?
Does microwave energy pass through the
viewing screen in the door?
Why does a tone sound when a pad on the
control panel is touched?
Can my microwave oven be damaged if
food is cooked for too long?
When the oven is plugged into wall outlet
for the first time, it might not work properly.
What is wrong?
Why do I see light reflection around the
outer case?
What are the various sounds I hear when
the microwave oven is operating?
There may be several reasons why the oven light is not on.
Have you:
• Set a cook time?
• Touched START?
Steam is normally produced during cooking. The microwave oven
has been designed to vent this steam.
Yes. Never operate the oven empty or without the glass turntable.
No. The metal screen bounces the energy back to the oven cavity.
The holes (or ports) allow only light to pass through. They do not
let microwave energy pass through.
The tone tells you that the setting has been entered.
Like any other cooking appliance, it is possible to overcook food
to the point that the food creates smoke and even possibly fire
and damage to the inside of the oven. It is always best to be near
the oven while you are cooking.
The microcomputer controlling your oven may temporarily
become scrambled and fail to function as programmed when you
plug in for the first time or when power resumes after a power
interruption. Unplug the oven from the ~120 volt household outlet
and then plug it back in to reset the microcomputer.
This light is from the oven light which is located between the
oven cavity and the outer wall of the oven.
The clicking sound is caused by a mechanical switch turning the
microwave oven’s magnetron ON and OFF.
The heavy hum and clunk is from the change in power the
magnetron draws as it is turned ON and OFF by a mechanical
switch. The change in blower speed is from the change in line
voltage caused by the magnetron being turned ON and OFF.
Answer
Food
Question Answer
What is wrong when baked foods have a
hard, dry, brown spot?
Why do eggs sometimes pop?
A hard, dry, brown spot indicates overcooking. Shorten the
cooking or reheating time.
When baking, frying, or poaching eggs, the yolk may pop due to
steam build-up inside the yolk membrane. To prevent this,
simply pierce the yolk before cooking.
CAUTION: Never microwave eggs in the shell.
ENGLISH
27
TROUBLESHOOTING
Questions and Answers (continued)
Food
Question
What is wrong when baked foods have a
hard, dry, brown spot?
Why do eggs sometimes pop?
Why are scrambled eggs sometimes a
little dry after cooking?
Why do baked apples sometimes burst
during cooking?
Why do baked potatoes sometimes
burn during cooking?
Why is a standing time recommended
after microwave cooking time is over?
Why is additional time required for
cooking food stored in the refrigerator?
A hard, dry, brown spot indicates overcooking. Shorten the cooking
or reheating time.
When baking, frying, or poaching eggs, the yolk may pop due to
steam buildup inside the yolk membrane. To prevent this,
simply pierce the yolk with a wooden toothpick before cooking.
CAUTION: Never microwave eggs in the shell.
Eggs will dry out when they are overcooked, even if the same
recipe is used each time. The cooking time may need to be varied
for one of these reasons:
• Eggs vary in size.
• Eggs are at room temperature one time and at refrigerator
temperature another time.
• Eggs continue cooking during standing time.
The peel has not been removed from the top half of each apple to
allow for expansion of the interior of the apple during cooking. As in
conventional cooking methods, the interior of the apple expands
during the cooking process.
If the cooking time is too long, fire could result. At the end of the
recommended cooking time, potatoes should be slightly firm.
CAUTION: Do not overcook.
Standing time allows foods to continue cooking evenly for a few
minutes after the actual microwave oven cooking cycle ends. The
amount of standing time depends upon the density of the foods.
As in conventional cooking, the initial temperature of food affects
total cooking time. You need more time to cook food taken out of a
refrigerator than for food at room temperature.
Answer
28
ENGLISH
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
Problem
Oven does not start
Arcing or sparking
Incorrect time of day
Unevenly cooked foods
Overcooked foods
Undercooked foods
Improper defrosting
You can often correct operating problems yourself. If your microwave oven fails to work properly, locate the
operating problem in the list below and try the solutions listed for each problem.
If the microwave oven still does not work properly, contact the nearest Sears Parts & Repair Center, which is fully
equipped to handle your service requirements.
• Is the power cord plugged in?
• Is the door closed?
• Is the cooking time set?
• Are you using approved cookware?
• Is the oven empty?
• Have you tried to reset the time of day?
• Are you using approved cookware?
• Is the glass turntable in the oven?
• Did you turn or stir the food while it was cooking?
• Were the foods completely defrosted?
• Was the time/cooking power level correct?
• Was the time/cooking power level correct?
• Are you using approved cookware?
• Were the foods completely defrosted?
• Was the time/cooking power level correct?
• Are the ventilation ports clear?
• Are you using approved cookware?
• Was the time/cooking power level correct?
• Did you turn or stir the food during the defrosting cycle?
WARNING:
This equipment generates and uses ISM frequency
energy and if not installed and used properly, that is in
strict accordance with the manufacturer's instructions,
may cause interference to radio and television
reception. It has been type tested and found to comply
with limits for ISM Equipment pursuant to part 18 of
FCC Rules, which are designed to provide reasonable
protection against such interference in a residential
installation.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the
following:
• Reorient the receiving antenna of the radio or
television.
• Relocate the Microwave Oven with respect to the
receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so
that the microwave oven and the receiver are on
different branch circuits.
The manufacturer is not responsible for any radio
or TV interference caused by unauthorized
modification to this microwave oven. It is the
responsibility of the user to correct such interference.
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE
STATEMENT (U.S.A. ONLY)
Possible Causes
29
Master Protection Agreements
Congratulations on making a smart purchase.
Your new Kenmore®product is designed and
manufactured for years of dependable operation.
But like all products, it may require preventive
maintenance or repair from time to time.
That’s when having a Master Protection Agreement can
save you money and aggravation.
Purchase a Master Protection Agreement now and
protect yourself from unexpected hassle
and expense.
The Master Protection Agreement also helps extend the
life of your new product. Here’s
what’s included in the Agreement:
Expert service by our 12,000 professional repair
specialists
Unlimited service and no charge for parts and
labor on all covered repairs
“No-lemon” guarantee – replacement of your
covered product if four or more product failures
occur within twelve months
Product replacement if your covered product can’t
be fixed
Annual Preventive Maintenance Check at your
request – no extra charge
Fast help by phone – phone support from a Sears
technician on products requiring in-home repair,
plus convenient repair scheduling
Power surge protection against electrical damage
due to power fluctuations
Rental reimbursement if repair of your covered
product takes longer than promised
Once you purchase the Agreement, a simple phone call
is all that it takes for you to schedule service.
You can call anytime day or night, or schedule a service
appointment online.
Sears has over 12,000 professional repair specialists,
who have access to over 4.5 million quality parts and
accessories. That’s the kind of professionalism you can
count on to help prolong the life of your new purchase
for years to come. Purchase your Master Protection
Agreement today!
Some limitations and exclusions apply. For prices
and additional information call 1-800-827-6655.
Sears Installation Service
For Sears professional installation of home appliances,
garage door openers, water heaters, and other major
home items, in the U.S.A. call
1-800-4-MY-HOME®
Acuerdos Maestros de protección
Felicitaciones por haber hecho una compra inteligente
Su nuevo producto Kenmore®está diseñado y fabricado
para años de operación segura.
Pero como todo producto, puede necesitar mantenimiento
preventivo o reparaciones cada cierto tiempo. Es allí
cuando el tener un Acuerdo Maestro de protección le
puede ahorrar dinero o evitar que la falla empeore.
Adquiera un Acuerdo Maestro de protección ahora y
resguárdese de cualquier molestia o gastos inesperados.
El Contrato de Protección Maestro ayuda también extender
la vida de su nuevo producto. Estas son los aspectos
incluídos en el Contrato :
Servicio experto, llevado a cabo por cualquiera de
nuestros 12.000 profesionales especialistas en
reparaciones.
Servicio ilimitado y sin cargo alguno, por las piezas
o por el trabajo en toda las reparaciones cubiertas por
el Acuerdo.
Garantía de "No-Lemon" - cambio de su producto
cubierto si ocurre más de cuatro o más fallas al
producto dentro de doce primeros meses.
Reemplazo del producto si su este asegurado no
puede arreglarse.
Control anual de mantenimiento preventivo a
pedido suyo sin cargo extra.
Ayuda rápida vía teléfonico - Soporte telefónico de
un técnico de Sears sobre los productos que se
requiere de reparación en casa, más la programación
conveniente de servicio.
Protección contra sobrecarga eléctrica, por daños
eléctricos causados por fluctuaciones de corriente.
Reembolso de alquiler si la reparación del producto
asegurado toma más tiempo de lo prometido.
Una vez que ha comprado el Acuerdo, una simple llamada
telefónica es todo lo que le tomará para agendar un
servicio. Puede llamar a cualquier hora del día o de la
noche o hacer un compromiso de atención por teléfono.
Sears tiene más de 12,000 profesionales especialistas en
reparaciones que tienen acceso a más de 4.5 millones de
piezas de calidad y accesorios. Esa es la clase de
profesionalismo con la que puede usted contar para ayudar
a prolongar la vida de su nueva adquisición en los años por
venir. ¡Suscriba ya un Acuerdo Maestro de protección!
Se aplican algunas limitaciones y exclusiones. Por
precios e información adicional llame al 1-800-827-
6655.
Servicio de instalación Sears
Para la instalación profesional de Sears de los aparatos del
hogar, dispositivos de apertura de la puerta del garaje,
calentadores de agua, y otros items principales del hogar,
llame en los Estados Unidos a 1-800-4-MY-HOME®.
Your Home
in your home all
no matter who made it, no matter who sold it!
1-800-4-MY-HOME (1-800-469-4663)
www.sears.com www.sears.ca
Our Home
Sears Parts & Repair Center.
1-800-488-1222
www.sears.com
1-888-SU-HOGAR 1-800-LE-FOYER
1-800-827-6655 1-800-361-6665
