LG Electronics USA HBM210 Bluetooth Mono Headset User Manual HBM 210
LG Electronics USA Bluetooth Mono Headset HBM 210
Users Manual
All rights reserved.
LG Electronics Inc., 2009
Note : For the best performance and
to prevent any damage to, or misuse of the
HBM-210, please read all of the information
carefully prior to using the HBM-210.
Any modifications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
LG Electronics
BLUETOOTH®Mono Headset
HBM-210 User manual
English
Español
3
Introduction
The LG Bluetooth®Headset HBM-210 is a light weight wireless
Headset utilizing Bluetooth®technology. This product can be used
as an audio accessory for devices that support the headset or
handsfree Bluetooth®profiles.
Included in package
2
Table of Contents
LG HBM-210
Bluetooth®Headset User manual
Warranty Card
Introduction 3
- Included in Package 3
Part Description 4
How to use 4
- Change direction 4
- Charging 5
- Low battery 5
- Power on 5
- Power off 5
- Pairing 5
�Easy Pairing 6
�Manual Pairing 6
- Auto Reconnect 7
- Volume control 7
- Calling 7
�Answering a call 7
�Making a call 7
�Voice dialing 8
�Last number redial 8
�Ending a call 8
�Transferring a call 8
�Call waiting 8
�Call Reject 8
Summary of button functions 9
LED indication 9
Troubleshooting 10
Specification 10
Precautions 11
Declaration of confirmation 13
Additional information 13
Limited warranty 16
Important safety information 16
Charger
Ear loop
Back
4
Description of parts
Front
MFB
(Multi-Function Button)
How to use
Change direction
5
Charging
Low battery
Power on
- Connect the charger to the charging port.
- When the charger is connected, with the power on or off,
the Headset will turn off automatically, and cannot be used.
While charging, the LED indicator will show a solid blue light.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the Headset.
- When charging is complete, the LED indicator will turn off.
Pairing
Power off
- Press and hold the MFB for 4 seconds.
�A shutdown tone will play, the Bluetooth link will disconnect,
and the power will turn off.
- Prior to using the Headset for the first time, you must pair it with a
Bluetooth-enabled handset.
- There are 2 Pairing Mode Methods with the HBM-210.
How to use
- A low battery tone will play once every 30 seconds.
- If the battery is not charged, the Headset will turn off.
- Press and Hold the MFB for 4 seconds.
�The power will turn on and a booting tone will play.
Charging Port
Volume UP / Down
Button
Speaker
Mic
LED Indicator
7
Auto Reconnect
6
How to use
1) Easy Pairing
�With the Power off, press and hold the MFB for 4 seconds, to turn
on the HBM-210.
�The Headset will enter Auto-Reconnect mode, for 10 seconds
(If your headset has been previously paired to the handset, the
headset will automatically reconnect to the handset, when the
HBM-210 is powered on.)
�After 10 seconds, the HBM-210 will automatically enter Paring Mode.
�When the headset enters Pairing Mode, the LED indicator will show
a solid blue light
�Using your handset, find the Bluetooth Menu and “search for” or
“add” new devices.
�
Select “LG HBM-210” from the list of devices and pair it with your handset.
�When asked for the Pass/PIN code during the pairing procedure,
please enter “0000” (4 Zeros).
�Once pairing has completed successfully, you will hear a beep.
�After pairing successfully, be sure to “Connect” to the LG HBM-210.
�If you want to pair with a different device in the future, the Headset
must be placed in Pairing Mode.
�If the headset is in Pairing mode for three minutes without being
connected to a handset, the HBM-210 will automatically turn off.
2) Manual Pairing
�With the Power off, press and hold the MFB for 6 seconds.
�When the Headset enters Pairing Mode, the LED indicator will
show solid blue light.
�Using your handset, find the Bluetooth Menu and “search for” or
“add” new devices.
�Select “LG HBM-210” from the list of devices and pair it with your
handset.
�When asked for the Pass/Pin code during the pairing procedure,
please enter “0000” (4 Zeros)
�Once pairing has completed successfully, you will hear a beep.
�After pairing successfully, be sure to “Connect” to the LG HBM-210.
�If you want to pair with a different device in the future, the Headset
must be placed in Pairing Mode.
Volume control
Calling
How to use
�If the headset is in Pairing mode for three minutes without being
connected to a handset, the HBM-210 will automatically turn off.
- When the HBM-210 turns off (accidentally or intentionally) while
connected to a handset, the headset and handset will disconnect.
The Headset and handset will automatically reconnect when the
HBM-210 is turned back on(as long as both devices are within
the required range of 33ft. or 10m).
[ Out of range ]
- When the HBM-210 and your handset are separated by a distance of
33 feet (10 meters) or more, the Headset and handset will disconnect.
When the handset and HBM-210 are brought back within the required
distance, the HBM-210 will automatically reconnect with the handset.
- If the Headset and handset do not automatically reconnect when they
are back within the required range, briefly press the MFB on the HBM-
210 to reconnect manually.
- Press the VOLUME UP or VOLUME DOWN button to adjust the
speaker volume.
- There are eight levels of speaker volume.
Answering a call
-
When there is an incoming call, the Headset will ring.
-
Briefly press the MFB to answer an incoming call.
Making a call
- If you make a call from the handset, the call will (subject to phone
settings) automatically transfer to the Headset. If the call is not
automatically transferred, you can manually transfer the call by briefly
pressing the MFB on the HBM-210 (handset and headset must be
paired).
9
8
How to use
LED indication
Summary of button functions
Function HBM-210
Status Action
Function HBM-210 Status Action
Power on Power off Press the MFB for 4 seconds.
Power off Power on Press the MFB for at least 4 seconds.
Volume up Talking Briefly press the Volume Up button.
Volume down Talking Briefly press the Volume Down button.
Transferring a call Talking - Handset to Headset
Briefly press the MFB (must be paired)
- Headset to Handset
Press and hold the VOLUME UP
button for 5 seconds.
Answering a call Ringing Briefly press the MFB.
Ending a call Talking Briefly press the MFB.
Call waiting Talking Press the MFB for 1 second.
Last number redial Idle Press the MFB for 1 second.
Voice dialing Idle Briefly press MFB.
(handset must support)
Call reject Ringing Press the MFB for 1 second.
Pairing Mode(Manual) Power off Press the MFB for 6 seconds.
Operating Power on The blue LED light flickers 4 times.
Power off The blue LED light flickers 4 times
and then turns off.
Pairing mode The blue LED light stays on.
Headset / handsfree The blue LED light flickers
Profile connected 2 times every 5 seconds.
Call connected The blue LED light flickers
2 times every 5 seconds.
Charging Charging The blue LED stays on.
Charging complete LED turns off.
Voice dialing*
- Briefly press the MFB to activate “Voice Command”.
You will get the best results if you record the voice dialing tag through
your Headset.
NOTE: If the handset does not support Voice Dialing, it is possible
that performing this action will activate Last Number redial.
Last number redial*
- Press and hold the MFB for 1second to activate “Last Number
Redial”. The headset will beep, and call the last number dialed.
Ending a call
- Briefly press the MFB.
Transferring a call*
- While on a call on your handset, briefly press the MFB to transfer
the audio to the Headset.(headset and handset must be paired).
- And to transfer a call from the Headset to Handset, press and hold
the VOLUME UP button for 5seconds.
Call waiting*
- Answer a second call without hanging up the first call by pressing
the MFB for 1second. Press the MFB for 1second to return to the
original call.
- Briefly press the MFB to terminate both calls at once.
Call Reject*
- Activate Call Reject by pressing the MFB for 1second when the
handset rings.
*It is possible to use these functions only when your handset supports
them. For further information about using these features, please
consult your handset's user manual.
Troubleshooting
Specification
Precautions
1110
Do not drop the unit from high places.
Do not modify, repair, or take apart.
Do not expose directly to water,
alcohol, benzene, etc. for cleaning.
Do not expose directly to flammables.
Do not place or keep the unit near
flammables.
ITEM Description
Bluetooth®specification V2.1 (Handsfree / Headset profiles)
Battery 3.7V, Li- Polymer, 110mAh
Stand by time Up to 420Hrs
Talk Time Up to 10Hrs
Charging time < 2Hrs
Operation temperature -10℃~60℃
Dimension / weight 19.5mm(W) X 44.5mm(L) X 9.8mm(H) / 10.4g
Does not turn on Check whether the battery Charge the battery.
of the HBM-210 is fully
charged.
Unable to Check whether Determine whether your
communicate with the handset supports handset supports
the LG Bluetooth
®
the Headset or Handsfree the Headset or Handsfree
Headset HBM-210 Bluetooth profiles. Bluetooth profiles.
Check whether the battery Charge the battery.
of the HBM-210 is low.
Unable to pair the Check and make sure the Press and hold the MFB for
HBM-210 with the Headset is on. at least 4 seconds to turn
Bluetooth®device on the Headset.
Check and make sure With the power off, press
the Headset is placed and hold the MFB for
in pairing mode. 6 seconds to place the
headset in pairing mode.
Low sound
(speaker)
Check the speaker volume.
lncrease the volume level.
Declaration of Confirmation
1312
Additional Information
1. Radio frequency exposure
This Bluetooth®Headset, HBM-210, is a radio transmitter and
receiver. When in operation, it communicates with a Bluetooth®
equipped mobile device by receiving and transmitting radio frequency
(RF) electromagnetic fields (microwaves) in the frequency range 2.4 to
2.4835 GHz. The output power of the radio transmitter is low, 0.001
watt. Your Bluetooth®Headset is designed to operate in compliance
with the RF exposure guidelines and limits set by national authorities
and international health agencies when used any compatible LG
Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially
explosive atmosphere. It is rare, but your electronic device could
generate sparks. Sparks in such areas could cause an explosion or
fire resulting in bodily injury or even death. Areas with a potentially
explosive atmosphere are often, but not always, clearly marked.
Keep unit away from humidity & dust.
Do not place heavy objects on the unit.
Precautions
Please only use the headset with an LG
original charger (Travel Adaptor, Vehicle
Power Charger). Otherwise the headset
might be damaged.
�Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
�There is a risk of explosion if the battery is replaced by
an incorrect type.
�Dispose of used batteries according to the
instructions.
�The earloop is made of a durable plastic.
However, bending the earloop repeatedly
is not recommended.
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any change to the antenna or the
device could result in the device exceeding the RF exposure requirements
and void user's authority to operate the device.
CE NOTICE TO USERS :
Hereby, LG Electronics Inc. declares that this HBM-210 is in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC.
1514
3.Emergency calls
IMPORTANT!
This Bluetooth®Headset and the electronic device connected to the
Headset operate using radio signals, mobile and landline networks as
well as user - programmed functions, which cannot guarantee connection
under all conditions. Therefore you should never rely solely upon any
electronic device for essential communications (e.g. medical emergencies).
Remember, in order to make or receive calls, the Headset and the
electronic device connected to the Headset must be switched on and
in a service area with adequate mobile signal strength. Emergency
calls may not be possible on all mobile phone networks or when certain
network services and/or phone features are in use. Check with your
local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly.
A new battery or one that has not been used for a long period of time
could have reduced capacity the first few times it is used. Do not expose
the battery to extreme temperatures, never above +60。(+140。F) or
under -20。(-4。F). For maximum battery capacity, use the battery in
room temperature. If the battery is used in low temperatures, the battery
capacity will be reduced. The battery can only be charged in temperatures
between +10。(+50。F) and +45。(+113。F). For your safety, do not remove
the battery incorperated in the product. If you need to replace the battery,
take it to the nearest authorised LG Electronics service point or dealer
for assistance.
5. Recycling the battery in your Bluetooth®Headset
The battery in your Bluetooth®Headset must be disposed of properly
and should never be placed in municipal waste. The LG Electronics
service partner removing battery will dispose of it according to local
regulations.
6. Conditions
- The warranty is valid only if the original receipt issued to the original
purchaser by the dealer, specifying the date of purchase and serial
number, is presented with the product to be repaired or replaced.
LG Electronics reserves the right to refuse warranty service if this
information has been removed or changed after the original purchase
of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period or for ninety (90) days from the date of repair, whichever is longer.
Repair or replacement may involve the use of functionally equivalent
reconditioned units. Replaced parts or components will become the
property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal
wear and tear, or due to misuse, including but not limited to use in
other than the normal and customary manner, in accordance with
instructions for use and maintenance of the product. Nor does this
warranty cover any failure of the product due to accident, modification
or adjustment, acts of God or damage resulting from liquid.
- This warranty does not cover product failures due to improper repair
installations, modifications or service performed by a non- LG
Electronics authorized person. Tampering with any of the seals on
the product will void the warranty.
-THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT
LIMITED TO LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL
EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
�Some countries/states do not allow the exclusion or limitation of
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you. The warranty provided does not affect the consumer's
statutory rights under applicable national legislation in force, nor the
consumer's rights against the dealer arising from their sales/purchase
contract.
Additional Information Additional Information
16
IMPORTANT SAFETY INFORMATION
Subject to the conditions of this Limited Warranty, LG Electronics
warrants this product to be free from defects in design, material and
workmanship at the time of its original purchase by a consumer,
and for a subsequent period of one (1) year. Should your product
need warranty service, please return it to the dealer from whom it
was purchased or contact your local LG Electronics contact center
to get further information.
Limited Warranty
Avoiding hearing damage Permanent hearing loss may occur if you
use your headset at a high volume. Set the volume to a safe level.
You can adapt over time to a higher volume of sound that may sound
normal but can be damaging to your hearing. If you experience ringing
in your ears or muffled speech, stop listening and have your hearing
checked. The louder the volume, the less time is required before your
hearing could be affected. Hearing experts suggest that to protect your
hearing:
�Limit the amount of time you use headset at high volume.
�Avoid turning up the volume to block out noisy surroundings.
�Turn the volume down if you can't hear people speaking near you.
Please refer to your handset user guide for more information on how
to adjust listening levels on your handset
Using headsets safely Use of headsets to listen to music while
operating a vehicle is not recommended and is illegal in some areas.
Be careful and attentive while driving. Stop using this device if you
find it disruptive or distracting while operating any type of vehicle or
performing any other activity that requires your full attention.
