LG Electronics USA HBM280 Bluetooth Mono Headset User Manual

LG Electronics USA Bluetooth Mono Headset

User manual

English
Español
Rev 1.0 US
All rights reserved.
LG Electronics Inc., 2011
Note: For the best performance and to prevent
any damage to, or misuse of the HBM-280,
please read all of the information
carefully before to use.
Any modications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
LG Electronics
BLUETOOTH® Mono Headset
HBM-280 User Manual
2 3
2 3
ENG
ENG
Included in the package
The LG Bluetooth® Headset HBM-280 is a light weight wireless headset that uses
Bluetooth® technology.
This product can be used as an audio accessory for devices that support the
headset or hands-free Bluetooth® proles.
Introduction 3
- Included in Package 3
Description of parts 4
How to use 4
- Change direction 4
- Charging 5
- Low battery 5
- Battery status alert 5
- Power on 5
- Power off 5
- Pairing 6
- Auto-reconnect 7
- Volume control 7
- Calling 7
• Answering a call 7
• Making a call 7
• Voice dialing 8
• Last number redial 8
• Ending a call 8
• Transferring a call 8
• Call waiting 8
• Call reject 8
• Mic mute 8
- Advanced multipoint 9
- Audio streaming (A2DP) 10
- HD speaker 10
- SMS reader 10
Summary of button functions 11
LED indication 12
Troubleshooting 12
Specification 13
Precautions 13
Declaration of confirmation 14
Additional information 14
Limited warranty 17
Important safety information 17
LG HBM-280
Bluetooth® Headset
Ear loop Charger
User manual Warranty Card
Table of Contents Introduction
4 5
4 5
ENG
ENG
Charging
- When the charger is connected, with power on or off, the headset will turn off.
- While charging, the LED indicator will show a solid white light.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the headset.
- When charging is complete, the LED indicator will turn off.
Change direction
Low battery
- An announcement will play once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Power on
- Move the power switch to the ‘ON’ position.
• The power will turn on and a startup tone will play.
- The audible battery status alert will let you know the battery level.
Power off
- Move the power switch to the ‘OFF’ position.
• A shutdown tone will play, the Bluetooth link will disconnect and the power will
turn off.
Call Button
Volum Up/Down
Button
LED Indicator
Microphone
Speaker
Power Switch
Left Right
Battery status alert
- By pressing and holding the VOLUME DOWN button for 3 seconds, you can check
the battery status of the HBM-280. The audible battery status alert will inform you of
the battery level. There are 3 levels of battery power:
1. Battery High
2. Battery Medium
3. Battery Low
Front
Back
Description of parts How to use
How to use
Charging Port
6 7
6 7
ENG
ENG
Auto-reconnect
- If the HBM-280 is turned off (either accidentally or intentionally) while connected,
the headset will disconnect form the device.
The headset and handset will automatically reconnect when the HBM-280 is turned
back on (provided that both devices are within the required range of 33 feet (10
meters)).
Out of range
- When the connected device and the HBM-280 are separated by a range of 33 feet
(10 meters) or more, the headset will alert the user with a beep, and the headset
and device will disconnect.
When the device and the HBM-280 are within the required range again, the HBM-
280 will automatically reconnect to the handset.
- If the headset and device do not automatically reconnect when they are back within
the required range, briey press the CALL button on the HBM-280 to reconnect
manually.
- While trying to reconnect, your headset will beep and the LED indicator will icker
twice every 5 seconds.
- If the headset does not reconnected within 60minutes, it will be turned off.
- Before using the headset for the rst time, it must be paired with a Bluetooth
enabled device.
- There are 2 pairing modes with the HBM-280.
1) Easy Pairing
a) Move the Power Switch to the “ON” position.
b) The headset will enter auto-reconnect mode for 10 seconds.
(If your headset has already been paired with a device, the headset will
automatically reconnect to the device when the HBM-280 is powered on.)
c) After 10 seconds, the HBM-280 will automatically enter pairing mode.
d) When the headset enters pairing mode, the LED indicator will show a solid
white light.
e) Using your handset, nd the Bluetooth menu and “search for” or “add” new
devices.
f) Select “LG HBM-280” from the list of devices to pair it with your device.
g) If you are asked for a passkey or PIN during pairing, please enter “0000”
(4 zeros).
h) Once the devices are paired, you will hear “Headset paired”.
i) After pairing has been completed, make sure you “connect” to the
LG HBM-280.
j) If you want to pair with a different device in the future, the headset must be
placed into pairing mode.
k) If the headset is in pairing mode for 3 minutes without being connected to a
device, the HBM-280 will automatically turn off.
2) Manual Pairing
a) With the Power off, press the CALL button and move the power switch to the
‘ON’ position. Continue to hold the CALL Button for 4 seconds until the LED
indicator shows a solid white light.
b) Continue pairing process from letter e above.
Volume control
- Press the VOLUME UP or VOLUME DOWN button to adjust the speaker volume.
- There are eight levels of speaker volume.
Pairing
Calling
Answering a call
- When there is an incoming call, the headset will ring.
- Briey press and release the CALL button to answer the incoming call.
Making a call
- If you make a call from the connected handset, the call will (depending on the
phone settings) automatically transfer to the headset. If the call is not automatically
transferred, you can manually transfer the call by briey pressing the CALL button on
the HBM-280 (handset and headset must be paired).
How to use How to use
8 9
8 9
ENG
ENG
Voice dialing
- Briey press the CALL button to activate “Voice dialing”.
For best results, record the voice dialing tag through your headset.
NOTE: If your handset does not support voice dialing, this action may activate Last
Number Redial.
Last number redial
- Press and hold the CALL button for 1 second to activate “Last number redial”.
The headset will beep and then call the last number dialed.
Ending a call
- Briey press the CALL button.
Transferring a call
- While on a call on your handset, briey press the CALL button to transfer the audio
to the headset (the headset and handset must be paired).
- To transfer a call from the headset to handset, press and hold the VOLUME UP
button for 3 seconds.
Call waiting
- Answer a second call without hanging up the rst by pressing the CALL button for
1 second (You will hear a beep). Press the CALL button for 1 second to return to
the original call.
- Briey press the CALL button to end the active call or both calls at once. (subject
to handset support)
Call reject
-
Activate call reject by pressing the CALL button for 1 second when the handset rings.
* These functions may only be used if your handset supports them.
For further information about using these features, please consult your handset’s
user manual.
Mic mute
- Press and hold the VOLUME UP and VOLUME DOWN buttons simultaneously for
1 second to mute/unmute the mic during conversation.
Advanced multipoint
The HBM-280 is capable of having two devices connected to the headset at the same
time. This will give you the freedom of using call waiting between calls on both of your
connected phones.
Connection
- Pair the headset with one of your Bluetooth-enabled handsets. (per the pairing
instructions on page 6).
- Turn off the headset.
- With the Power off, press the CALL button and move the power switch to the ‘ON’
position at the same time for 4 seconds to enter Manual Pairing mode.
- Now, pair and connect the headset with your other Bluetooth-enabled handset.
(This will be your primary handset).
- Once this handset is paired and connected, go back and connect the originally paired
handset to the headset. (This will now be your secondary handset).
* NOTE: When the HBM-280 is connected to two handsets at the same
time(multipoint), the headset calling functions will work with the primary
handset.
Calling function
- Voice dialing and Last Number Redial features work with the primary handset (or
handset which made the last outgoing call).
Call waiting
- While speaking on an active call, Press the call button for 1 second to switch to an
incoming call.
- To switch between 2 active calls, Press the call button for 1 second.
- To end both calls briey press the call button.
- If both handsets are receiving an incoming call, the headset will default to the primary
device.
How to use How to use
10 11
10 11
ENG
ENG
Audio streaming (A2DP)
The HBM-280 supports music streaming (A2DP).
When you play music from your Bluetooth Enabled Device, it will automatically
transfer to your headset. Music will automatically pause when you have an incoming
call. When the call is ended the music will start playing again.
A2DP allows streaming of all audio from your handset and running applications
Including Music and GPS Navigation.
SMS reader
The HBM-280 Bluetooth Headset supports SMS reading on Android TM based
devices.
In the AndroidTM Marketplace search for the LG ‘BT Reader’ application and install
on your device to use this function.
* The 2D barcode shown below helps you download the ‘BT Reader’ application
from Android MarketTM.
Function
HBM-280 Status
Action
Power on Power off Move the power switch to the ‘ON’ side.
Power off Power on Move the power switch to the ‘OFF’ side.
Volume up Talking Briey press the VOLUME UP button.
Volume down Talking Briey press the VOLUME DOWN button.
Transferring a call Talking
- Handset to headset
Briey press the CALL button. (must be paired)
- Headset to handset
Press and hold the VOLUME UP button for
3 seconds.
Answering a call Ringing Briey press the CALL button.
Ending a call Talking Briey press the CALL button.
Call waiting Talking Press the CALL button for 1 second.
Last number redial Idle Press the CALL button for 1 second.
Voice dialing
(handset must
support)
Idle Briey press the CALL button.
Call reject Ringing Press the CALL button for 1 second.
Mic on/off Talking Press and hold VOLUME UP and VOLUME
DOWN buttons simultaneously for 1 second.
Pairing mode
(Manual) Power off
Press the CALL button and move the power
switch to the ‘ON’ side at the same time for 4
seconds.
Battery status check
Idle Press the VOLUME DOWN button for 3
seconds.
HD speaker
The HBM-280 supports high denition voice calling and audio streaming.
*Network must support HD Voice for higher quality calling.
How to use Summary of button functions
12 13
12 13
ENG
ENG
Function HBM-280 Status Action
Operating
Power on The LED will ash 4 times.
Power off
The LED will ash 4 times and then turns off.
Pairing mode The LED stays on.
Headset / Hands-Free /
A2DP proles connected
The LED will ash twice every 5 seconds.
Call connected The LED will ash twice every 5 seconds.
Out of range
For the rst 15 minutes after the devices are
disconnected the LED will ash twice every 5
seconds. After that it will ash once every 5 seconds.
Charging Charging The LED stays on.
Charging complete
The LED turns off.
Issue Possible problem Resolution
Does not turn on Check whether the battery of
the HBM-280 is fully charged. Charge the battery.
Unable to
communicate with
the LG HBM-280
Check whether the device
supports the headset or
hands-free Bluetooth proles.
Determine whether your device
supports the Headset or Hands-
free Bluetooth proles.
Check whether the battery of
the HBM-280 is low.
Charge the battery.
Unable to pair the
HBM-280 with
Bluetooth
®
device
Check and make sure the
Headset is on.
Move the power switch to the ‘ON’
side to turn on the headset.
Check and make sure the
Headset is placed in pairing
mode.
With the Power off, press the CALL
button and move the power switch
to the ‘ON’ side at the same time
for 4 seconds to manually place the
headset in pairing mode.
Low sound (speaker) Check the speaker volume. lncrease the volume level.
Not to hear audio
streaming
Check whether other device
is streaming. Stop other device streaming.
Item Description
Bluetooth
®
specication
V3.0 (Headset / Hands-Free / A2DP Proles)
Battery
3.7V, Li- Polymer, 110mAh
Talk Time Up to 9.5 Hrs
Stand by time Up to 600 Hrs
Charging time < 2 hours
Operation temperature -10°C ~ 60°C
Dimension / weight 18.2mm(W) X 48mm(L) X 10mm(H) / 9.2g
Do not drop the device.
Do not modify, repair, or disassemble.
Do not expose directly to water, alcohol, benzene, etc. for cleaning.
Do not expose directly to ammables.
Do not place or keep the device near ammables.
Keep the device away from humidity and dust.
Do not place heavy objects on the device.
Only use the headset with an original LG charger, otherwise it may be damaged.
• Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• The earloop is made of a durable plastic. However, bending the earloop
repeatedly is not recommended.
LED indication
Troubleshooting
Specication
Precautions
14 15
14 15
ENG
ENG
FCC NOTICE TO USERS:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no change to
the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void user’s
authority to operate the device.
CE NOTICE TO USERS:
Hereby, LG Electronics Inc. declares that the HBM-280 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
1. Radio frequency exposure
This Bluetooth® Headset HBM-280, is a radio transmitter and receiver. When in
operation it communicates with a Bluetooth® equipped mobile device by receiving
and transmitting radio frequency (RF) electromagnetic elds (microwaves) in the
frequency range 2.4 to 2.4835 GHz. The output power of the radio transmitter is low
(0.001 watts). Your Bluetooth® Headset is designed to operate in compliance with the
RF exposure guidelines and limits set by national authorities and international health
agencies when used with any compatible LG Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive
atmosphere. Although this is uncommon, your electronic device could generate
sparks. Sparks in such areas could cause an explosion or re resulting in bodily
injury or even death. Areas with a potentially explosive atmosphere are often, but not
always, clearly marked.
3.Emergency calls
IMPORTANT!
This Bluetooth® headset and the electronic device connected to the headset
operate using radio signals, mobile and landline networks as well as user
- programmed functions, which cannot guarantee connection under all conditions.
Therefore you should never rely solely upon any electronic device for essential
communications (e.g. medical emergencies). Remember, in order to make or
receive calls, the headset and the electronic device connected to the headset
must be switched on and in a service area with adequate mobile signal strength.
Emergency calls may not be possible on all mobile phone networks or when certain
network services and/or phone features are in use. Check with your local service
provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery or
one that has not been used for a long period of time could have reduced capacity
the rst few times it is used. Do not expose the battery to extreme temperatures,
never above +60°C(+140°F) or under -20°C(-4°F). For maximum battery capacity,
use the battery at room temperature. If the battery is used in low temperatures, the
battery capacity will be reduced. The battery can only be charged in temperatures
between +10°C(+50°F) and +45°C (+113°F). For your safety, do not remove the
battery incorporated in the product. If you need to replace the battery, take it to the
nearest authorized LG Electronics service point or dealer for assistance.
5. Recycling the battery in your Bluetooth® headset
The battery in your Bluetooth® Headset must be disposed of properly and should
never be placed in municipal waste. The LG Electronics service partner who
removes the battery will dispose of it according to local regulations.
Declaration of Conrmation
Additional Information
Additional Information
16 17
16 17
ENG
ENG
6. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser
by the dealer, specifying the date of purchase and serial number, is presented
with the product to be repaired or replaced. LG Electronics reserves the right to
refuse warranty service if this information has been removed or changed after
the original purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty period
or for ninety (90) days from the date of repair, whichever is longer. Repair or
replacement may involve the use of functionally equivalent reconditioned units.
Replaced parts or components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear and
tear, or due to misuse, including but not limited to use in other than the normal
and customary manner, in accordance with instructions for use and maintenance
of the product. Nor does this warranty cover any failure of the product due to
accident, modication or adjustment, acts of God or damage resulting from
liquid.
- This warranty does not cover product failures due to improper repair
installations, modications or service performed by a non- LG Electronics
authorised person. Tampering with any of the seals on the product will void the
warranty.
- THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO
LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL EXTENT THOSE
DAMAGES CAN BE DISCLAIMED BY LAW.
• Some countries/states do not allow the exclusion or limitation of incidental or
consequential damages, or limitation of the duration of implied warranties, so the
preceding limitations or exclusions may not apply to you. The warranty provided
does not affect the consumer’s statutory rights under applicable national
legislation in force, nor the consumer’s rights against the dealer arising from
their sales/purchase contract.
Subject to the conditions of this Limited Warranty, LG Electronics warrants this
product to be free from defects in design, material and workmanship at the time of
its original purchase by a consumer, and for a subsequent period of one (1) year.
Should your product need warranty service, please return it to the dealer from
whom it was purchased or contact your local LG Electronics contact centre to get
further information.
Avoiding hearing damage
Permanent hearing loss may occur if you use your headset at a high volume.
Set the volume to a safe level. Over time you can become accustomed to a higher
volume that may sound normal but can be damaging to your hearing. If you
experience ringing in your ears or mufed speech, stop listening and have your
hearing checked. The louder the volume, the less time is required before your
hearing could be affected.
Hearing experts suggest that to protect your hearing:
• Limit the amount of time you use the headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Using Headsets safely
Use of headsets to listen to music while operating a vehicle is not recommended
and is illegal in some areas. Be careful and attentive whilst driving. Stop using this
device if you nd it disruptive or distracting whilst operating any type of vehicle or
performing any other activity that requires your full attention.
Additional Information Limited warranty
Important safety information
MEMO

Navigation menu
