LG Electronics USA HBM310 BLUETOOTH HEADSET User Manual HBM 310
LG Electronics USA BLUETOOTH HEADSET HBM 310
USERS MANUAL
All rights reserved.
LG Electronics Inc., 2008
Note : For the best performance and
to prevent any damage to, or misuse of the
HBM-310, please read all of the information
carefully prior to using the HBM-310.
Any modifications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
LG Electronics
BLUETOOTH®Mono Headset
HBM-310 User manual
English
Español
Français
3
Introduction
The LG Bluetooth®Headset HBM-310 is a light weight wireless
Headset utilizing Bluetooth®technology. This product can be used
as an audio accessory for devices supporting either the Headset
or Handsfree Bluetooth®Profiles.
Included in package
2
Table of Contents
Introduction 3
Part Description 4
How to use 5
- Charging 5
- Low battery 5
- Power on 5
- Power off 5
- Pairing 5
- Auto Reconnect 7
- Volume control 7
- Calling 8
�Answering a call 8
�Making a call 8
�Voice dialing 8
�Last number redial 8
�Ending a call 8
�Transferring a call 8
�Call waiting 8
�Call Reject 8
Summary of button functions 9
LED indication 9
Troubleshooting 10
Specification 10
Precautions 11
Declaration of confirmation 13
Additional information 13
Limited warranty 16
Important safety information 16
Bluetooth®Headset User manual
Charger Warranty Card
Front
Back
4 5
Volume UP / Down Button
LED indicator
Speaker
MIC
Charging Port
Part Description
Power Button
Charging
Low battery
Power on
- Remove the cover on the charging port and connect the charger.
- When the charger is connected, with power on or off, the Headset
will turn off. While charging, the LED indicator will show a solid blue light
.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the Headset.
- When charging is complete, the LED indicator will turn off.
- A low battery tone will play once every 30 seconds.
- If the battery is not charged, the Headset will turn off.
- Press and Hold the PWR button for 4 seconds.
�The power will turn on and a booting tone will play.
Call Button
Pairing
Power off
- Press and hold the PWR button for 2 seconds.
�A shutdown tone will play, the Bluetooth link will disconnect,
and the power will turn off.
- Prior to using the Headset for the first time, you must pair it with a
Bluetooth-enabled handset.
- There are 2 Pairing Mode Methods with the HBM-310.
How to use
7
Auto Reconnect
How to use
6
How to use
1) Easy Pairing
�With the Power off, press and hold the PWR button for 5 seconds,
to turn on the HBM-310.
�The Headset will enter Auto-Reconnect mode, for 10 seconds
(If your headset has been previously paired to the handset, the
headset will automatically reconnect to the handset, when the
HBM-310 is powered on.)
�After 10 seconds, the HBM-310 will automatically enter Paring Mode.
�When the headset enters Pairing Mode, the LED indicator will show
a solid blue light
�Using your handset, find the Bluetooth Menu and “search for” or
“add” new devices.
�
Select “LG HBM-310” from the list of devices and pair it with your handset.
�When asked for the Pass/PIN code during the pairing procedure,
please enter “0000” (4 Zeros).
�Once pairing has completed successfully, you will hear a beep.
�After pairing successfully, be sure to “Connect” to the LG HBM-310.
�If you want to pair with a different device in the future, the Headset
must be placed in Pairing Mode.
�If the headset is in Pairing mode for three minutes without being
connected to a handset, the HBM-310 will automatically turn off.
2) Manual Pairing
�With the Power off, press and hold the PWR button for 7 seconds.
�When the Headset enters Pairing Mode, the LED indicator will show
a solid blue light.
�Using your handset, find the Bluetooth Menu and “search for” or
“add” new devices.
�Select “LG HBM-310” from the list of devices and pair it with your
handset.
Volume control
�When asked for the Pass/Pin code during the pairing procedure,
please enter “0000” (4 Zeros)
�Once pairing has completed successfully, you will hear a beep.
�After pairing successfully, be sure to “Connect” to the LG HBM-310.
�If you want to pair with a different device in the future, the Headset
must be placed in Pairing Mode.
�If the headset is in Pairing mode for three minutes without being
connected to a handset, the HBM-310 will automatically turn off.
- When the HBM-310 turns off (accidentally or intentionally) while
connected to a handset, the headset and handset will disconnect.
The Headset and handset will automatically reconnect when the
HBM-310 is turned back on(as long as both devices are within
the required range of 33ft. or 10m).
[ Out of range ]
- When the HBM-310 and your handset are separated by a distance of
33 feet (10 meters) or more, the Headset and handset will disconnect.
When the handset and HBM-310 are brought back within the required
distance, the HBM-310 will automatically reconnect with the handset.
- If the Headset and handset do not automatically reconnect when they
are back within the required range, briefly press the CALL button on
the HBM-310 to reconnect manually.
- Press the VOLUME UP or VOLUME DOWN button to adjust the
speaker volume.
- There are eight levels of speaker volume.
9
8
How to use
LED indication
Summary of button functions
Function HBM-310
Status Action
Function HBM-310
Status Action
Power on Power off Press the PWR button for 4 seconds.
Power off Power on Press the PWR button for at least
2 seconds.
Volume up Talking Briefly press the Volume Up button.
Volume down Talking Briefly press the Volume Down button.
Transferring a call Talking - Handset to Headset
Briefly press the CALL button
(must be paired)
- Headset to Handset
Press and hold the VOLUME UP button
for 5 seconds.
Answering a call Ringing Briefly press the CALL button.
Ending a call Talking Briefly press the CALL button.
Call waiting Talking Press the CALL button for 1 second.
Last number redial Idle Press the CALL button for 1 second.
Voice dialing Idle Briefly press the CALL button.
(handset must support)
Pairing mode Power off
Press the PWR button for 7 seconds.
Call reject Ringing Press the
CALL
button for 1 second.
Operating Power on The blue LED light flickers 4 times.
Power off The blue LED light flickers 4 times
and then turns off.
Pairing mode The blue LED light stays on.
Headset / handsfree The blue LED light flickers
Profile connected 2 times every 5 seconds.
Call connected The blue LED light flickers
2 times every 5 seconds.
Charging Charging The blue LED stays on.
Charging complete LED is turned off.
Calling
Answering a call
-
When there is an incoming call, the Headset will ring.
-
Briefly press the CALL button to answer an incoming call.
Making a call
-
If you make a call from the handset, the call will (subject to phone settings)
automatically transfer to the Headset. If the call is not automatically
transferred, you can manually transfer the call by briefly pressing the
CALL button on the HBM-310 (handset and headset must be paired).
Voice dialing
*
-
Briefly press the CALL button to activate “Voice Command”.
You will get the best results if you record the voice dialing tag through
your Headset.
NOTE: If the handset does not support Voice Dialing, it is possible that
performing this action will activate Last Number redial.
Last number redial
*
-
Press and hold the CALL button for 1second to activate “Last Number
Redial”. The headset will beep, and call the last number dialed.
Ending a call
-
Briefly press the CALL button.
Transferring a call
*
-
While on a call on your handset, briefly press the CALL button to
transfer the audio to the Headset.(headset and handset must be paired).
-
And to transfer a call from the Headset to Handset, press and hold
VOLUME UP button for 5seconds.
Call waiting
*
-
Answer a second call without hanging up the first call by pressing the
CALL button for 1second. Press the CALL button for 1second to
return to the original call.
-
Briefly press the CALL button to terminate both calls at once.
Call Reject
*
-
Activate Call Reject by pressing the CALL button for 1second when
the handset rings.
*
It is possible to use these functions only when your handset supports
them. For further information about using these features, please
consult your handset's user manua
l.
Troubleshooting
Specification
Precautions
1110
Do not drop the unit from high places.
Do not modify, repair, or take apart.
Do not expose directly to water,
alcohol, benzene, etc. for cleaning.
Do not expose directly to flammables.
Do not place or keep the unit near
flammables.
ITEM Description
Bluetooth®specification V2.0 (Handsfree / Headset profiles)
Battery 3.7V, Li- Polymer
Stand by time Up to 150Hrs
Talk Time Up to 6Hrs
Charging time < 2Hrs
Operation temperature -10℃~60℃
Dimension / weight 19.1mm(W) X 52.9mm(L) X 11.1mm(H) / 11.0g
Does not turn on Check whether the battery Charge the battery.
of the HBM-310 is fully
charged.
Unable to Check whether Determine whether your
communicate with the handset supports handset supports
the LG Bluetooth
®
the Headset or Handsfree the Headset or Handsfree
Headset HBM-310 Bluetooth profiles. Bluetooth profiles.
Check whether the battery Charge the battery.
of the HBM-310 is low.
Unable to pair the Check and make sure the
Press and hold the PWR button
HBM-310 with the Headset is on. for at least 4 seconds to turn
Bluetooth®device on the Headset.
Check and make sure With the power off, press
the Headset is placed and hold the PWR button
in pairing mode. for 7 seconds to place the
headset in pairing mode.
Low sound
(speaker)
Check the speaker volume.
lncrease the volume level.
1514
3.Emergency calls
IMPORTANT!
This Bluetooth®Headset and the electronic device connected to the
Headset operate using radio signals, cellular and landline networks
as well as user- programmed functions, which cannot guarantee
connection under all conditions. Therefore you should never rely
solely upon any electronic device for essential communications (e.g.
medical emergencies). Remember, in order to make or receive calls,
the Headset and the electronic device connected to the Headset
must be switched on and in a service area with adequate cellular
signal strength. Emergency calls may not be possible on all cellular
phone networks or when certain network services and/or phone
features are in use. Check with your local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly.
A new battery or one that has not been used for a long period of
time could have reduced capacity the first few times it is used.
Do not expose the battery to extreme temperatures, never above
+ 60。(+140。F) or under -20。(-4。F). For maximum battery capacity,
use the battery in room temperature. If the battery is used in low
temperatures, the battery capacity will be reduced. The battery
can only be charged in temperatures between + 10。(+50。F) and
+ 45。(+ 113。F).
5. Recycling the battery in your Bluetooth®Headset
The battery in your Bluetooth®Headset must be disposed of properly
and should never be placed in municipal waste. The LG Electronics
service partner removing battery will dispose of it according to local
regulations.
6. Conditions
-
The warranty is valid only if the original receipt issued to the original
purchaser by the dealer, specifying the date of purchase and serial
number, is presented with the product to be repaired or replaced.
LG Electronics reserves the right to refuse warranty service if this
information has been removed or changed after the original
purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or
replaced product shall be warranted for the remaining time of the
original warranty period or for ninety (90) days from the date of
repair, whichever is longer. Repair or replacement may involve the
use of functionally equivalent reconditioned units. Replaced parts
or components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to
normal wear and tear, or due to misuse, including but not limited to
use in other than the normal and customary manner, in accordance
with instructions for use and maintenance of the product. Nor does
this warranty cover any failure of the product due to accident,
modification or adjustment, acts of God or damage resulting from
liquid.
- This warranty does not cover product failures due to improper
repair installations, modifications or service performed by a non-
LG Electronics authorized person. Tampering with any of the seals
on the product will void the warranty.
-THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT
LIMITED TO LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL
EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
�
Some countries/states do not allow the exclusion or limitation of
incidental or consequential damages, or limitation of the duration
of implied warranties, so the preceding limitations or exclusions
may not apply to you. The warranty provided does not affect the
consumer's statutory rights under applicable national legislation in
force, nor the consumer's rights against the dealer arising from
their sales/purchase contract.
Additional Information Additional Information
16
IMPORTANT SAFETY INFORMATION
Subject to the conditions of this Limited Warranty, LG Electronics
warrants this product to be free from defects in design, material and
workmanship at the time of its original purchase by a consumer, and
for a subsequent period of one (1) year. Should your product need
warranty service, please return it to the dealer from whom it was
purchased or contact your local LG Electronics contact center to get
further information.
Limited Warranty
Avoiding hearing damage Permanent hearing loss may occur if you
use your headset at a high volume. Set the volume to a safe level.
You can adapt over time to a higher volume of sound that may sound
normal but can be damaging to your hearing. If you experience ringing
in your ears or muffled speech, stop listening and have your hearing
checked. The louder the volume, the less time is required before your
hearing could be affected. Hearing experts suggest that to protect
your hearing:
�Limit the amount of time you use headset at high volume.
�Avoid turning up the volume to block out noisy surroundings.
�Turn the volume down if you can't hear people speaking near you.
For information about how to set a maximum volume limit on your
handset, please refer to the features guide for your handset.
Using headsets safely Use of headsets to listen to music while
operating a vehicle is not recommended and is illegal in some areas.
Be careful and attentive while driving. Stop using this device if you
find it disruptive or distracting while operating any type of vehicle or
performing any other activity that requires your full attention.
reservados todos los derechos.
LG Electronics Inc., 2008
Nota : Para la major funcionamien to
y para prevenir cualquier daño o mal uso
de HBM-310, por favor lean toda la
información antes de uasar el producto.
Cualesquier modificación o cambio a este manual
debido a los errores tipográficos o a las inexactitudes de
la información indicada serán realizados solamente por la
Electrónica inc. de LG.
LG Electronics
BLUETOOTH®Mono Headset
HBM-310 Manual de usuarios
Español
English
Français
