The LG BluetoothⓇHeadset HBM-500 is a light
weight wireless Headset utilizing BluetoothⓇ
technology. This product can be used as an audio
accessory for devices supporting either the
Headset or Handsfree BluetoothⓇProfiles.
IInncclluuddeedd iinn ppaacckkaaggee
BluetoothⓇHeadset User manual
Charger
P
Pa
ar
rt
t d
de
es
sc
cr
ri
ip
pt
ti
io
on
n
I
In
nt
tr
ro
od
du
uc
ct
ti
io
on
n
F
Fr
ro
on
nt
t
R
Re
ea
ar
r
Status LED
Call/Power Button
Charging Port
Ear Speaker
Speaker Volume button
MIC
S
St
ta
ar
rt
t
C
Co
on
nf
fi
ig
gu
ur
ra
at
ti
io
on
n
CChhoooossiinngg wweeaarriinngg pprreeffeerreennccee
1. Rotate the earpiece to select your left or right ear.
2. Place the Headset on your ear.
3. Extend the ear ring then slip it over the top of
your ear,and press the speaker gently toward
your ear for a snug fit.
CChhaannggee DDiirreeccttiioonn
On the Left Rotation
On the Right
CChhaarrggiinngg HHBBMM--550000
Please ensure that your new HBM-500 is fully charged
before your initial use.
1. Open the charging port cover on the side of the headset.
2. Plug the charger into the charging port outlet.
3. While charging, the red LED indicator is lit and will remain lit,
until the headset is fully charged.
4. The red LED light changes to the green color after full charge.
5. Charge the headset for approximately 3 hours
or until the red LED changes to the green LED
NNOOTTEE LLooww bbaatttteerryy wwaarrnniinngg
The Headset needs to be recharged when
- You hear a short beeping sound through the Headset’s
speaker at 15 second intervals.
- You see the red LED light flickers 2 times every 2 seconds.
- You see the low battery warning on the LCD.
Power on
- In order to turn the Headset on, press and hold the Call/Power
button located in front of the product for at least 2 seconds.
* If you want to check the battery state on LCD, please wait for 5
seconds after power on.
Because it may not be collect to the real state.
Power off
- In order to turn the Headset off, press and hold the Call/Power
button located in front of the product for at least 3 seconds.
H
Ho
ow
w t
to
o u
us
se
e
BBlluueettooootthhⓇPPaaiirriinngg
Before using your headset for the first time, you must
pair it with another BluetoothⓇdevice, such as a mobile
phone.
Follow the steps below for most devices.
1. Place the LG BluetoothⓇHeadset HBM-500 in Pairing mode.
- Turn your headset on.
- The LCD displays the LG logo, “LG Electronics”
and “HBM-500”
- Press the Call/Power button for 2 seconds and make
your headset discoverable.
- The LCD displays“Pairing”.
2. Your Handset will find “HBM-500”
- Set your Handset Bluetooth mode.
- Search your headset from your Handset.
- Enter passkey “0000”(Four zeros) when you prompted to
enter PIN number.
- Confirm to connect when the Handset asks.
- The LCD displays“HF/HS Connected”.
* If you want to use the fully supported Headset functions, please
make the Handsfree profile connection.
* Some phones automatically make the Headset profile connection,
so please be careful.
NNOOTTEEIIff ppaaiirriinngg iiss ssuucccceessssffuull,, tthhee bblluuee LLEEDD
lliigghhtt wwiillll ffllaasshh iinn ssttaannddbbyy mmooddee eevveerryy 44 sseeccoonnddss..
AAddddiinngg mmuullttiippllee HHaannddsseettss..
1. The LG BluetoothⓇheadset HBM-500 stores up to
8 different Handset registrations in memory.
2. If you add the 9th Handset, the LG BluetoothⓇHeadset
HBM-500 will automatically remove the registration
information of the least registered Handset.
3. Priority is given to the Handset most recently used
paired.
4. When you want to change the Handset priority, try
to connect manually from the Handset.
NNOOTTEEOOnnccee aa HHaannddsseett iiss rreeggiisstteerreedd ttoo tthhee
LLGG BBlluueettooootthhⓇHHeeaaddsseett HHBBMM--550000,, iitt wwiillll bbee ssttaayyeedd
iinn ppaaiirreedd ssttaattuuss uunnttiill ddeelleetteedd..
* On Power on, the LG Bluetooth Headset HBM-500
connects to the most recently used Handset automatically.
B
Ba
as
si
ic
c u
us
sa
ag
ge
e
Answering a call
Press the Call/Power button to capture and transfer
the call to the Headset.
Ending a call
Press the Call/Power button to terminate the call.
Making a call
If you make a call from the Handset, the call will
(subject to Handset settings) be automatically transferred
to the Headset. If not automatically transferred,
you can transfer the call manually by pressing
the Call/Power button.
Last number redialing *
Activate last number redial by pressing the Call/Power
button for 2 seconds.
Voice dialing *
Activate voice dialing by pressing the Call/Power
button.
•It is possible to use this function only when your Handset
supports the voice dialing function.
For further information about using this feature, please
consult your Handset’s user manual.
You will get the best results if you record the voice-dialing
tag through your Headset.
Volume control
Press the Up or Down button to increase or
decrease the speaker volume.
The volume control button allows you to adjust the
Headset volume to one of 8 levels.
Transferring a call *
To transfer a call from the Handset to the Headset
, press the Call/Power button.
Call waiting *
Answering a second call without hanging up the
first call by pressing the Call/Power button for 2 seconds.
Press the Call/Powe button for 2 seconds to turn
to another call.
Press the Call/Power button to terminate the calls at once.
* It is dependent on your handset supporting this function.
Please check your handset’s user manual for further details.
L
LE
ED
D i
in
nd
di
ic
ca
at
ti
io
on
n
S
Su
um
mm
ma
ar
ry
y o
of
f b
bu
ut
tt
to
on
n f
fu
un
nc
ct
ti
io
on
ns
s
Power On Power Off Press the Call/Power button for at
least 2 seconds
Power Of f
Volume Up
Volume Down
Transferring a Call
Answering a Call
Ending a Call
Power On
-
-
Talking
Ringing
Talking
Press the Call/Power button for at
least 3 seconds
Press the Up button
Press the Down button
Press the Call/Power button
Press the Call/Power button
Press the Call/Power button
Press the Call/Power
button for 2 seconds
Press the Call/Power button
Press the Call/Power button
for 2 seconds
Press the Call/Power button
Talking
Talking
Ready
Start & Stop
Voice Command
Voice Dialing
(Handset should
support)
Last Number
redialing
Call Waiting Mode
(terminating both
calls at once)
Call Waiting Mode
(Answering a second
call or Return to original
call)
F
Fu
un
nc
ct
ti
io
on
n H
HB
BM
M-
-5
50
00
0 s
st
ta
at
tu
us
sA
Ac
ct
ti
io
on
n
Operating Power On The blue LED light flickers 3
times every 2 seconds
Charging
Power Off
Pairing mode
Headset/Handsfree
Profile Connected
Call Connected
Charging
The red LED light is lit and
then turns off
The red and blue LED light
flicker in turn continuously.
The blue LED light flickers 2
times every 4 seconds.
The blue LED light flickers 1
time every 2 seconds.
The red LED is lit.
The green LED is lit.
Charging Complete
F
Fu
un
nc
ct
ti
io
on
n H
HB
BM
M-
-5
50
00
0 s
st
ta
at
tu
us
sL
LE
ED
D S
St
ta
at
tu
us
s
Press the Down button
for 2 seconds (Toggle)
Talking
Mute On/Off
T
Tr
ro
ou
ub
bl
le
es
sh
ho
oo
ot
ti
in
ng
g
L
LC
CD
D i
in
nd
di
ic
ca
at
ti
io
on
n
Operating Power On LG logo -> LG Electronics ->
HBM-500 -> Connecting
Power Off
Pairing mode
Headset/Handsfree
Profile Connected
Incoming Call
Outgoing Call
Call Connected
POWER OFF
Pairing
HS/HF Connected
Caller ID or Incoming Call
(Only Handsfree Profile)
Outgoing Call (Handsfree Profile)
Call Connected
LastNum Redial -> Outgoing
Call (Handsfree Profile)
HS Connected (Headset Profile)
HF Connected (Handsfree Profile)
Voice Command (Handsfree Profile)
HS Connected (Headset Profile)
Call Ended -> HS/HF Connected
Last Number Call
Call Cancellation in the
Headset
Call Cancellation in the
Handset
Call Rejection
F
Fu
un
nc
ct
ti
io
on
n H
HB
BM
M-
-5
50
00
0 s
st
ta
at
tu
us
sL
LC
CD
D S
St
ta
at
tu
us
s
Stop Voice Command
Start Voice Command
Link Loss
Waiting Call
Call Transfer
Low battery warning
Call Cancel -> HS/HF Connected
Low Battery
Call Swap (Handsfree Profile)
Call Connected
Out of Range
Call Reject -> HS/HF Connected
(Handsfree Profile)
Does not turn on Check whether the battery
of the HBM-500 is fully
discharged.
Charge the battery
Unable to communicate
with the LG BluetoothⓇ
Headset HBM-500
Check whether the Handset
supports the Headset or
Handsfree BluetoothⓇProfiles.
Determine whether your
Handset supports the Headset or
Handsfree BluetoothⓇProfiles.
Check whether the
Headset is on.
Check whether the battery
of the HBM-500 is low
Charge the battery
Check whether the
Headset is placed in
pairing mode.
Press and hold the Call/Power
button for at least 2 seconds to
place the Headset in pairing
mode.
Low sound from the
speaker
Check the speaker volume. lncrease the volume level.
Unable to pair the
HBM-500 with the
BluetoothⓇdevice.
Press the Call/Power button for
at least 2 seconds to turn on the
Headset.
Mute On MIC GAIN : MUTE
Mute OFF Volume Level
P
Pr
re
ec
ca
au
ut
ti
io
on
ns
s
Do not drop the unit from high places.
Do not modify,repair & take a part at discretion.
Do not expose directly to the water, alcohol,
benzene, etc. for cleaning.
Do not expose directly to flammables.
Do not place or keep the unit near the flammables.
●lt may cause an explosion.
S
Sp
pe
ec
ci
if
fi
ic
ca
at
ti
io
on
n
Bluetooth Specificaton
Supported Profile
Rx. Sensitivity
Battery
Rated Input
Speaker
MIC
I
IT
TE
EM
M D
De
es
sc
cr
ri
ip
pt
ti
io
on
n
Standby Current
Talk Current
Standby Time
Talk Time
Operating Temperature
Dimension
V1.2
Handsfree / Headset
Typ -70dBm
3.7V, 180mAh, Li-Polymer
5.0V/1.0A (USA, CDMA),
5.2V/0.8A (Europe & Russia, GSM)
32Ω/ 10Ø
-50dB / Omni directional
1mA (Avr)
22mA
Up to 200Hrs
Up to 9Hrs
- 20 。C ~ 60 。C
24.1mm(W) x 72.2mm( L ) x12.5mm(H)
P
Pr
re
ec
ca
au
ut
ti
io
on
ns
s
Do not place the heavy objects on the unit.
Keep away from direct light or heat.
Keep unit away from humidity & dust.
●Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
●Risk of explotion if battery is replaced by an incorrect type.
●Dispose of used batteries according to the instructions.
D
De
ec
cl
la
ar
ra
at
ti
io
on
n o
of
f C
Co
on
nf
fi
ir
rm
ma
at
ti
io
on
n
W
WE
EE
EE
E
D
Di
is
sp
po
os
sa
al
l o
of
f y
yo
ou
ur
r o
ol
ld
d a
ap
pp
pl
li
ia
an
nc
ce
e
1.When this crossed-out wheeled bin symbol
is attached to a product it means the product
is covered by the European Directive
2002/96/EC.
2.All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection facilities
appointed by the government or the local authorities.
3.The correct disposal of your old appliance will
help prevent potential negative consequences for
the environment and human health.
4.For more detailed information about disposal of
your old appliance, please contact your city office,
waste disposal service or the shop where you
purchased the product.
A
Ad
dd
di
it
ti
io
on
na
al
l l
ln
nf
fo
or
rm
ma
at
ti
io
on
n
11.. RRaaddiioo ffrreeqquueennccyy eexxppoossuurree
This BluetoothⓇHeadset, HBM-300, is a radio transmitter and
receiver.When in operation, it communicates with a BluetoothⓇ
equipped mobile device by receiving and transmitting radio
frequency (RF) electromagnetic fields (microwaves) in the
frequency range 2.4 to 2.4835 MHz. The output power of the
radio transmitter is low, 0.001 watt. Your BluetoothⓇHeadset
is designed to operate in compliance with the RF exposure
guidelines and limits set by national authorities and
international health agencies when used any compatible LG
Electronics mobile phone.
22.. PPootteennttiiaallllyy eexxpplloossiivvee aattmmoosspphheerree
Turn off your electronic device when in any area with a
potentially explosive atmosphere. It is rare, but your electronic
device could generate sparks.
Sparks in such areas could cause an explosion or fire resulting
in bodily injury or even death. Areas with a potentially
explosive atmosphere are often, but not always, clearly
marked.
33..EEmmeerrggeennccyy ccaallllss
I
IM
MP
PO
OR
RT
TA
AN
NT
T!
!
This BluetoothⓇHeadset and the electronic device connected to
the Headset operate using radio signals, cellular and landline
networks as well as user-programmed functions, which cannot
guarantee connection under all conditions. Therefore you
should never rely solely upon any electronic device for
essential communications (e.g. medical emergencies).
Remember, in order to make or receive calls, the Headset and
the electronic device connected to the Headset must be
switched on and in a service area with adequate cellular
signal strength. Emergency calls may not be possible on all
cellular phone networks or when certain network services
and/or phone features are in use. Check with your local
service provider.
A
Ad
dd
di
it
ti
io
on
na
al
l l
ln
nf
fo
or
rm
ma
at
ti
io
on
n
•If LG Electronics repairs or replaces the product, the repaired
or replaced product shall be warranted for the remaining time
of the original warranty period or for ninety (90) days from the
date of repair, whichever is longer. Repair or replacement may
involve the use of functionally equivalent reconditioned units.
Replaced parts or components will become the property of
LG Electronics.
•This Warranty does not cover any failure of the product due to
normal wear and tear, or due to misuse, including but not limited
to use in other than the normal and customary manner, in
accordance with instructions for use and maintenance of the
product. Nor does this warranty cover any failure of the
product due to accident, modification or adjustment, acts
of God or damage resulting from liquid.
•This warranty does not cover product failures due to improper
repair installations, modifications or service performed by a
non-LG Electronics authorized person.
•Tampering with any of the seals on the product will void the
warranty.
•THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR ORAL,
OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
APARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT
LIMITED TO LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL
EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
Some countries/states do not allow the exclusion or limitation
ofincidental or consequential damages, or limitation of the duration
of implied warranties, so the preceding limitations or exclusions may
not apply to you. The warranty provided does not affect the
consumer's statutory rights under applicable national legislation in
force, nor the consumer's rights against the dealer arising from their
sales/purchase contract.
A
Ad
dd
di
it
ti
io
on
na
al
l l
ln
nf
fo
or
rm
ma
at
ti
io
on
n
44.. BBaatttteerryy iinnffoorrmmaattiioonn
A rechargeable battery has a long service life if treated
properly. A new battery or one that has not been used for a
long period of time could have reduced capacity the first few
times it is used. Do not expose the battery to extreme
temperatures, never above +60°(+140°F) or under -20°(-4°F).
For maximum battery capacity, use the battery in room
temperature. If the battery is used in low temperatures, the
battery capacity will be reduced. The battery can only be
charged in temperatures between +10° (+50 °F) and
+45°(+113°F ).
55.. RReeccyycclliinngg tthhee bbaatttteerryy iinn yyoouurr BBlluueettooootthhⓇHHeeaaddsseett
The battery in your BluetoothⓇHeadset must be disposed of
properly and should never be placed in municipal waste. The
LG Electronics service partner removing battery will dispose of
it according to local regulations.
66.. CCoonnddiittiioonnss
•The warranty is valid only if the original receipt issued to the
original purchaser by the dealer, specifying the date of
purchase and serial number, is presented with the product to be
repaired or replaced. LG Electronics reserves the right to
refuse warranty service if this information has been removed
or changed after the original purchase of the product
from the dealer.
L
Li
im
mi
it
te
ed
d W
Wa
ar
rr
ra
an
nt
ty
y
Subject to the conditions of this Limited Warranty, LG
Electronics warrants this product to be free from defects in
design, material and workmanship at the time of its original
purchase by a consumer, and for a subsequent period of one
(1) year. Should your product need warranty service, please
return it to the dealer from whom it was purchased or contact
your local LG Electronics contact center to get further
information.

Navigation menu
