LG Electronics USA HBM585 BLUETOOTH Mono Headset User Manual HBM 585
LG Electronics USA BLUETOOTH Mono Headset HBM 585
Manual
Rev 1.0 US
All rights reserved.
LG Electronics Inc., 2010
Note: For optimal performance and to prevent
any damage to, or misuse of the HBM-585,
please read all the information carefully
before using the HBM-585
Any modifications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
LG Electronics
BLUETOOTH®Mono Headset
HBM-585 User manual
English
3
Introduction
The LG Bluetooth®Headset HBM-585 is a lightweight wireless
headset that uses Bluetooth®technology.
This product can be used as an audio accessory for devices
that support the headset or hands-free Bluetooth®profiles.
Included in the package
2
Table of Contents
LG HBM-585
Bluetooth®Headset
User manual
HBM-585
Warranty Card
Introduction 3
- Included in the package 3
Description of parts 4
How to use 4
- Change direction 4
- Charging 5
- Low battery 5
- Battery status check 5
- Power on 5
- Power off 5
- Pairing 5
•Easy pairing 5
•Manual pairing 6
- Auto reconnect 7
- Volume control 7
- Calling 7
•Answering a call 7
•Making a call 7
•Voice dialing 8
•Last number redial 8
•Ending a call 8
•Transferring a call 8
•Call waiting 8
•Call Reject 8
- Advanced multipoint 9
Summary of button functions 10
LED indication 10
Troubleshooting 11
Specification 11
Precautions 12
Declaration of confirmation 13
Additional information 13
Limited warranty 16
Important safety information 16
Ear loop 5 Pin Data Cable
Ear buds Quick Start Guide
Small Charging
Cradle
Vehicle Power
Adaptor
Charger
How to use
Change direction
Small Charging Cradle
Vehicle Power Adaptor
4
Description of parts
Headset
MFB
(Multi-Function Button)
Charging Port
LED
Indicator
USB Port
Left Right
Volume Button
Mic
LED Indicator
Charging ontacts
Speaker
5
Charging
Low battery
Battery status Alert
Power on
- Slide the HBM-585 into the Small Charging Cradle or the Vehicle Power Adaptor.
- When the headset is placed into either charging device, the headset will turn off.
- While charging, the LED indicator will show a solid white light.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the headset.
- When charging is complete, the LED indicator will turn off.
NOTE: When the HBM-585 is removed from the charging device (Small Charging
Cradle of Vehicle Power Adaptor), it will automatically power ON. If the headset
has already been paired to your handset, it will automatically reconnect when
removed.
Pairing
Power off
- Press and hold the MFB for 3 seconds.
•A shutdown tone will play, the Bluetooth link will be disconnected and the power
will turn off.
How to use
- A low battery tone will play once every 30 seconds.
- If the battery is not charged, the headset will turn off.
- By pressing and holding the VOLUME button for 3 seconds, you can check the battery
status of the HBM-585. The audible battery status alert will inform you of the battery
level. There are 3 levels of battery power:
1. Battery High
2. Battery Medium
3. Battery Low
- Press and hold the MFB for 3 seconds.
•The power will turn on and a startup tone will play.
- The audible battery status alert will let you know the battery level.
- Before using the headset for the first time, it must be paired with a Bluetooth-
enabled handset.
- There are 2 pairing modes with the HBM-585.
1) Easy Pairing
•Press and hold the MFB for 3 seconds to turn on the HBM-585.
•The headset will enter auto-reconnect mode for 10 seconds.
(if your headset has already been paired with the handset, the headset will
automatically reconnect to the handset when the HBM-585 is powered on).
7
Auto reconnect
6
How to use
•After 10 seconds, the HBM-585 will automatically enter pairing mode.
•When the headset enters pairing mode, the LED indicator will show
a solid white light.
•Using your handset, find the Bluetooth menu and “search for” or
“add” new devices.
•Select “LG HBM-585” from the list of devices and pair it with your
handset.
•If you are asked for the passkey or PIN during pairing, please enter
“0000” (4 zeros).
•Once pairing has been completed successfully, you will hear "Headset
paired".
•After pairing has been completed, make sure you “connect” to the
LG HBM-585. You will hear "Connected".
•If you want to pair with a different device in the future, the headset
must be in pairing mode.
•If the headset is in pairing mode for 3 minutes without being
connected to a handset, the HBM-585 will automatically turn off.
2) Manual Pairing
•With the power off, press and hold the MFB for 6 seconds.
•When the headset enters pairing mode, the LED indicator will show
a solid white light.
•Using your handset, find the Bluetooth menu and “search for” or
“add” new devices.
•Select “LG HBM-585” from the list of devices and pair it with your
handset.
•If you are asked for the passkey or PIN during pairing, please enter
“0000” (4 zeros).
•Once pairing has been completed successfully, you will hear "Headset
paired".
•After pairing has been completed, make sure you “connect” to the
LG HBM-585. You will hear "Connected"
•If you want to pair with a different device in the future, the headset
must be in pairing mode.
•If the headset is in pairing mode for 3 minutes without being
connected to a handset, the HBM-585 will automatically turn off.
Volume control
- If the HBM-585 is turned off (either accidentally or intentionally) while
connected to a handset, the headset and handset will disconnect.
The headset and handset will automatically reconnect when the
HBM-585 is turned back on (provided that both devices are within
the required range of 33 feet 10 metres).
[ Out of range ]
- When your handset and HBM-585 are separated by a range of 33
feet (10 metres) or more, the headset and handset will disconnect.
When the handset and HBM-585 are within the required range again,
the HBM-585 will automatically reconnect to the handset.
- If the headset and handset do not automatically reconnect when
they are back within the required range, briefly press the MFB on
the HBM-585 to reconnect manually.
-Press the VOLUME button to adjust the speaker volume.
- There are eight levels of speaker volume. The volume will increase
one level, each time the volume button is pressed. When the headset
reaches the maximum volume level, the next press of the button returns
the headset to the lowest volume level.
Calling
How to use
Answering a call
- When there is an incoming call, the headset will ring.
- Briefly press the MFB to answer the incoming call.
Making a call
- If you make a call from the handset, the call will (depending on the
phone settings) automatically transfer to the headset. If the call is
not automatically transferred, you can manually transfer the call by
briefly pressing the MFB on the HBM-585 (handset and headset
must be paired).
Advanced multipoint
8 9
How to use
Voice dialing*
- Briefly press the MFB to activate “Voice Command”.
For best results, record the voice dialing tag through your headset.
NOTE: If your handset does not support voice dialing, this action
may activate Last Number Redial.
Last number redial*
- Press and hold the MFB for 1 second to activate “Last number redial”.
The headset will beep and then call the last number dialled.
Ending a call
- Briefly press the MFB.
Transferring a call*
- While on a call, briefly press the MFB to transfer the audio from the
handset to the headset (the headset and handset must be paired).
- To transfer a call from the headset to handset, press and hold the
VOLUME button for 3 seconds.
Call waiting*
- Answer a second call without hanging up the first call by pressing the
MFB for 1second. Press the MFB for 1 second to return to the original
call.
- Briefly press the MFB to terminate both calls at once.
Call Reject*
- Activate call reject by pressing the MFB for 1 second when the handset
rings.
* These functions may only be used if your handset supports them.
For further information about using these features, please consult
your handset's user manual.
How to use
The LG HBM-585 is capable of having two handsets connected to the
headset at the same time. This will give you the freedom of having only one
headset to operate both of your handsets.
Activation
- For advanced multipoint connection, press the MFB and VOLUME button
simultaneously for 6 seconds with the power off. Your headset will beep,
and enter pairing mode (LED will be solid white).
Connection
- Pair the headset with one of your Bluetooth-enabled handsets. (per the
pairing instructions on pages 6).
- Turn off the headset.
- With the power off, press and hold the MFB and VOLUME button on the
HBM-585 for 6 seconds to enter Manual Pairing mode.
- Now, pair and connect the headset with your other Bluetooth-enabled
handset. (This will be your primary handset).
- Once this handset is paired and connected, go back and connect the first
paired handset to the headset. (This will be your secondary handset).
* Note: When the HBM-585 is connected to two handsets at the same
time(multipoint), the headset calling functions will work with the primary
handset (or handset which made the last outgoing call).
Calling function
- Voicedialing and Last Number Redial features work with the primary
handset (or handset which made the last outgoing call).
- The first connected device is set as primary handset and the next
connected device is set as secondary handset.
- The device which made the last outgoing call will always be set as the
primary handset.
- If there is an incoming call on each handset, the first incoming call can be
answered by a brief press of the MFB.
10
Summary of button functions
LED indication
Function HBM-585
Status Action
Function HBM-585 Status Action
Power on Power off Press the MFB for 3 seconds.
Power off Power on Press the MFB for at least 4 seconds.
Volume Talking Briefly press the VOLUME button.
Transferring a call Talking - handset to headset
Briefly press the MFB (must be paired)
- headset to handset
Press and hold the VOLUME button
for 3 seconds.
Answering a call Ringing Briefly press the MFB.
Ending a call Talking Briefly press the MFB.
Call waiting Talking Press the MFB for 1 second.
Last number redial Idle Press the MFB for 1 second.
Voice dialing Idle Briefly press the MFB.
(handset must support)
Call reject Ringing Press the MFB for 1 second.
Pairing mode(Manual) Power off Press the MFB for 6 seconds.
Battery status check Idle Press the VOLUME button for 3 seconds
Operating Power on The white LED light flickers 4 times.
Power off The white LED light flickers 4 times
and then turns off.
Pairing mode The white LED light stays on.
Headset / Hands-free The white LED light flickers
profile connected twice every 5 seconds.
Call connected The white LED light flickers
twice every 5 seconds.
Charging Charging The white LED light stays on.
Charging complete The LED light turns off.
Troubleshooting
Specification
11
ITEM Description
Bluetooth®specification V2.1 (Headset / Hands-Free Profiles)
Battery 3.7V, Li- Polymer, 60mAh
Talk time Up to 5 Hrs
Standby time Up to 120 Hrs
Charging time < 2 hours
Operation temperature -10℃~50℃
Dimension / weight Headset : 15mm(W) X 61.5mm(L) X 3.8mm(H) / 7.2g
Cradle 18.7mm(W) X 30.6mm(L) X 9.2mm(H) / 6.5g
Does not turn on Check whether the battery Charge the battery.
of the HBM-585 is fully
charged.
Unable to Check whether Determine whether your
communicate with the handset supports handset supports
the LG Bluetooth®the headset or hands-free the headset or hands-free
Headset HBM-585 Bluetooth profiles Bluetooth profiles.
Check whether the battery Charge the battery.
of the HBM-585 is low.
Unable to pair the Check and make sure the Press and hold the MFB for
HBM-585 with the headset is on. at least 3 seconds to turn
Bluetooth®device on the headset.
Check and make sure With the power off, press
the headset is placed and hold the MFB for
in pairing mode. 6 seconds to place the
headset in pairing mode.
Low sound (speaker) Check the speaker volume. lncrease the volume level.
Declaration of confirmation
13
Additional iInformation
1. Radio frequency exposure
This Bluetooth®Headset HBM-585, is a radio transmitter and receiver.
When in operation it communicates with a Bluetooth®equipped
mobile device by receiving and transmitting radio frequency (RF)
electromagnetic fields (microwaves) in the frequency range 2.4 to
2.4835 GHz. The output power of the radio transmitter is low.
Your Bluetooth®Headset is designed to operate in compliance
with the RF exposure guidelines and limits set by national authorities
and international health agencies when used any compatible LG
Electronics mobile phone.
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the
antenna or the device could result in the device exceeding the RF
exposure requirements and void user's authority to operate the device.
CE NOTICE TO USERS :
Hereby, LG Electronics Inc. declares that this HBM-585 is in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Do not modify, repair, or disassemble.
Do not expose directly to water, alcohol, benzene, etc. for cleaning.
Do not expose directly to flammables.
Do not place or keep the device near flammables.
Do not drop the device.
12
Precautions
Keep the device away from humidity and dust.
Only use the headset with an original LG charger, otherwise the it
may be damaged.
Do not place heavy objects on the device.
•Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
•There is a risk of explosion if the battery is replaced by
an incorrect type.
•Dispose of used batteries according to the
instructions.
•The earloop is made of a durable plastic.
However, bending the earloop repeatedly
is not recommended.
15
6. Conditions
- The warranty is valid only if the original receipt issued to the original
purchaser by the dealer, specifying the date of purchase and serial
number, is presented with the product to be repaired or replaced.
LG Electronics reserves the right to refuse warranty service if this
information has been removed or changed after the original purchase
of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period or for ninety (90) days from the date of repair, whichever is longer.
Repair or replacement may involve the use of functionally equivalent
reconditioned units. Replaced parts or components will become the
property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal
wear and tear, or due to misuse, including but not limited to use in other
than the normal and customary manner, in accordance with instructions
for use and maintenance of the product. Nor does this warranty cover
any failure of the product due to accident, modification or adjustment,
acts of God or damage resulting from liquid.
- This warranty does not cover product failures due to improper repair
installations, modifications or service performed by a non- LG Electronics
authorised person. Tampering with any of the seals on the product will
void the warranty.
-THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR ORAL,
OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY.
IN NO EVENT SHALL LG ELECTRONICS OR ITS VENDORS BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER,
INCLUDING BUT NOT LIMITED TO LOST PROFITS OR COMMERCIAL LOSS,
TO THE FULL EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
•Some countries/states do not allow the exclusion or limitation of
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you. The warranty provided does not affect the consumer's
statutory rights under applicable national legislation in force, nor the
consumer's rights against the dealer arising from their sales/purchase
contract.
Additional information
14
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially
explosive atmosphere. Although this is uncommon, your electronic
device could generate sparks. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death. Areas with
a potentially explosive atmosphere are often, but not always, clearly
marked.
3. Emergency calls
IMPORTANT!
This Bluetooth®headset and the electronic device connected to the
headset operate using radio signals, mobile and landline networks
as well as user - programmed functions, which cannot guarantee
connection under all conditions. Therefore you should never rely
solely upon any electronic device for essential communications (e.g.
medical emergencies). Remember, in order to make or receive calls,
the headset and the electronic device connected to the headset must
be switched on and in a service area with adequate mobile signal
strength. Emergency calls may not be possible on all mobile phone
networks or when certain network services and/or phone features
are in use. Check with your local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly.
A new battery or one that has not been used for a long period of
time could have reduced capacity the first few times it is used.
Do not expose the battery to extreme temperatures, never above
+60。C(+140。F) or under -20。C(-4。F). For maximum battery capacity,
use the battery at room temperature. If the battery is used in low
temperatures, the battery capacity will be reduced. The battery can
only be charged in temperatures between +10。C(+50。F) and +45。C
(+113。F). For your safety, do not remove the battery incorperated in
the product. If you need to replace the battery, take it to the nearest
authorised LG Electronics service point or dealer for assistance.
5. Recycling the battery in your Bluetooth®headset
The battery in your Bluetooth®Headset must be disposed of properly
and should never be placed in municipal waste. The LG Electronics
service partner who removes the battery will dispose of it according
to local regulations.
Additional information
16
IMPORTANT SAFETY INFORMATION
Subject to the conditions of this Limited Warranty, LG Electronics
warrants this product to be free from defects in design, material and
workmanship at the time of its original purchase by a consumer, and
for a subsequent period of one (1) year. Should your product need
warranty service, please return it to the dealer from whom it was
purchased or contact your local LG Electronics contact centre to
get further information.
Limited warranty
Avoiding hearing damage Permanent hearing loss may occur if you
use your headset at a high volume. Set the volume to a safe level.
Over time you can become accustomed to a higher volume that may
sound normal but can be damaging to your hearing. If you experience
ringing in your ears or muffled speech, stop listening and have your
hearing checked. The louder the volume, the less time is required
before your hearing could be affected.
Hearing experts suggest that to protect your hearing:
•Limit the amount of time you use the headset at high volume.
•Avoid turning up the volume to block out noisy surroundings.
•Turn the volume down if you can't hear people speaking near you.
Using headsets safely Use of headsets to listen to music while
operating a vehicle is not recommended and is illegal in some areas.
Be careful and attentive whilst driving. Stop using this device if you
find it disruptive or distracting whilst operating any type of vehicle or
performing any other activity that requires your full attention.
