User Manual
-1-
LG Electronics
Bluetooth®Mono Headset
HBM-710
User Manual English
Spanish
AAllll rriigghhttss rreesseerrvveedd..
LLGG EElleeccttrroonniiccss IInncc..,, 22000066
NNoottee :: FFoorr tthhee bbeesstt ppeerrffoorrmmaannccee
aanndd ttoo pprreevveenntt aannyy ddaammaaggee ttoo,, oorr mmiissuussee
ooff tthhee HHBBMM--771100,, pplleeaassee rreeaadd aallll ooff tthhee
iinnffoorrmmaattiioonn ccaarreeffuullllyy pprriioorr ttoo uussiinngg tthhee HHBBMM--771100
AAnnyy mmooddiiffiiccaattiioonnss oorr cchhaannggeess ttoo tthhiiss mmaannuuaall dduuee ttoo
ttyyppooggrraapphhiiccaall eerrrroorrss oorr iinnaaccccuurraacciieess ooff ssttaatteedd iinnffoorrmmaattiioonn
sshhaallll oonnllyy bbee mmaaddee bbyy LLGG EElleeccttrroonniiccss IInncc..
Included in package
Bluetooth® Headset User manual
Charger
The LG Bluetooth®Headset HBM-710 is a light weight wireless Headset utilizing
Bluetooth®technology. This product can be used as an audio accessory for devices
supporting either the Headset or Handsfree Bluetooth®Profiles.
-3--2-
Table of contents Introduction
Introduction ōōōōōōōōōōōōōōōōōōōōōōōōōō3
Parts description ōōōōōōōōōōōōōōōōōōōōōōōō4
How to use ōōōōōōōōōōōōōōōōōōōōōōōōōō5
- Change direction ōōōōōōōōōōōōōōōōōōōōōō5
- Chargingōōōōōōōōōōōōōōōōōōōōōōōōōō6
- Low battery ōōōōōōōōōōōōōōōōōōōōōōōō6
- Power on ōōōōōōōōōōōōōōōōōōōōōōōōō6
- Power off ōōōōōōōōōōōōōōōōōōōōōōōōō6
- Pairing ōōōōōōōōōōōōōōōōōōōōōōōōōō6
- Connectingōōōōōōōōōōōōōōōōōōōōōōōōō7
- Volume control ōōōōōōōōōōōōōōōōōōōōōōō7
- Calling ōōōōōōōōōōōōōōōōōōōōōōōōōō8
ᶀAnswering a call ōōōōōōōōōōōōōōōōōōōōō8
ᶀMaking a callōōōōōōōōōōōōōōōōōōōōōōō8
ᶀVoice dialing ōōōōōōōōōōōōōōōōōōōōōōō8
ᶀLast number redial ōōōōōōōōōōōōōōōōōōōō8
ᶀEnding a call ōōōōōōōōōōōōōōōōōōōōōōō8
ᶀTransferring a call ōōōōōōōōōōōōōōōōōōōō8
ᶀCall waiting ōōōōōōōōōōōōōōōōōōōōōōō8
Summary of button function ōōōōōōōōōōōōōōōōōōō9
LED Indication ōōōōōōōōōōōōōōōōōōōōōōōōō9
Troubleshooting ōōōōōōōōōōōōōōōōōōōōōōō10
Specification ōōōōōōōōōōōōōōōōōōōōōōōōō10
Precautions ōōōōōōōōōōōōōōōōōōōōōōōōō11
Declaration of confirmation ōōōōōōōōōōōōōōōōōōō13
WEEE ōōōōōōōōōōōōōōōōōōōōōōōōōōōō13
Additional information ōōōōōōōōōōōōōōōōōōōōō15
Limited warranty ōōōōōōōōōōōōōōōōōōōōōōō16
-5-
How to use
Change Direction
On the left Rotation On the right
-4-
Parts Description
Front
Rear
PWR/END Button
Charging Port
MIC
LED Indicator
Speaker
Volume
Up/Down Button
Volume
Up/Down Button
- Remove the cover on the charging port and connect the charger.
- When the charger is connected with power on or off, the Headset will turn off. While charging,
the LED indicator will show a solid red light.
- The buttons will not function while the device is charging.
- It takes 3 hours to fully charge the headset.
- When charging is complete, the LED indicator will turn off.
- The LED indicator will blink red when the battery power is low.
- When the battery is not charged, the LED indicator will be blinked red and then turn off.
- When this occurs, the battery needs to be charged.
- Press and hold the PWR/END button for 2 seconds
✓The power will turn on and a booting tone will play.
- Press and hold the PWR/END button for 5 seconds.
✓A shutdown tone will play , the Bluetooth link will be disconnected, and the power will turn
off.
- With the HBM-710 off, press and hold the PWR/END button for 5 seconds.
✓You will hear a short beep and the LED indicator will stay red, when the device enters
Pairing Mode.
Using your handset, find the “Bluetooth menu” and “search for” or “add”new devices.
Select “LG HBM-710” from the list of devices and pair it with your handset.
-7--6-
Charging
Low battery
Power on
Power off
✓When asked for the Pass/PIN code during the pairing procedure, please enter “0000”
(4 Zeros).
✓Once pairing has completed successfully, you will hear a beep.
✓After pairing successfully, be sure to “Connect” to the LG HBM-710.
✓If you want to pair with other devices in the future, the headset must be in “Pairing mode”.
✓ If it will be not connected the “Pairing” for three minutes, it will be turned off.
[ Call connection]
- Briefly press the PWR/END button to activate “Voice command”.**
**Your handset must support the “Voice command” function.
✓Press the PWR/END button for 1 second to activate last number redial. The Headset will
enter “Redial” and call the most recent number after making a beep.
- To end a call, briefly press the “PWR/END” button.
[ Auto reconnect ]
- When the HBM-710 and your handset are separated by a distance of 33 feet (10meters) or
more, the Headset and handset will disconnect. When the handset and HBM-710 are brought
back within the required distance, the HBM-710 will automatically reconnect with the handset.
- If the Headset and Handset do not automatically reconnect when they are back within the
required range, briefly press the PWR/END button to reconnect manually.
- Briefly press the “VOLUME UP” or “VOLUME DOWN” button to adjust the speaker volume.
- There are eight levels of speaker volume.
Connecting
Pairing
Volume control
-9--8-
Calling
AAnnsswweerriinngg aa ccaallll
- When there is an incoming call, the Headset will ring.
- Briefly press the PWR/END button to answer an incoming call.
MMaakkiinngg aa ccaallll
- If you make a call from the handset, the call will (subject to phone settings) transfer
automatically to the Headset. If not automatically transferred, you can manually transfer the
call by briefly pressing the PWR/END button.
VVooiiccee ddiiaalliinngg
*
- Briefly press the PWR/END button. You will get the best results if you record the
voice dialing tag through your Headset.
LLaasstt nnuummbbeerr rreeddiiaall
- Press and hold the PWR/END button for 1second until beeping sound is heard.
EEnnddiinngg aa ccaallll
- Briefly press the PWR/END button.
TTrraannssffeerrrriinngg aa ccaallll
*
- While on a call, briefly press the PWR/END button for transferring the audio to
the Headset.
CCaallll wwaaiittiinngg
*
- Answer a second call without hanging up the first call by pressing the PWR/END
button for 1 second. Press the PWR/END button for 1 second to return to the
original call.
- Press the PWR/END button to terminate both calls at once.
*It is possible to use these functions only when your handset supports them.
For further information about using these features, please consult your handset’s
user manual.
Summary of button functions
Function HBM-710 Status Action
Power on Power off Press the PWR/END button for 2 seconds
Power off Power on Press the PWR/END button
for at least 5 seconds
Volume up - Briefly press the “Volume up” button
Volume down - Briefly press the “Volume down” button
Transferring a call Talking Briefly press the PWR/END button
Answering a call Ringing Briefly press the PWR/END button
Ending a call Talking Briefly press the PWR/END button
Call waiting Talking Press the PWR/END button for 1 second
Last number redialing Ready Press the PWR/END button for 1 second
Voice dialing Start& stop voice Briefly press the PWR/END button
(Handset should support) Command
Pairing mode Power off Press the PWR/END button for 5 seconds
Call rejection Ringing Press the PWR/END button for 1 second
Function HBM-710 Status Action
Operating Power on The red LED light flickers 3 times.
Power off The red LED light is lit and then turns off.
Pairing mode The red LED light is lit.
Headset/Handsfree The red LED light flickers
Profile connected 2 times every 5 seconds.
Call connected The red LED light flickers
2 times every 5 seconds.
Charging Charging The red LED is lit.
Charging complete LED is turned off.
LED Indication
-11-
Precautions
Do not drop the unit from high places.
Do not modify,repair & take a part at discretion.
Do not expose directly to the water, alcohol,
benzene, etc. for cleaning.
Do not expose directly to flammables.
Do not place or keep the unit near the flammables.
-10-
Troubleshooting
Does not turn on Check whether the battery Charge the battery.
of the HBM-710 is fully
charged.
Unable to communicate Check whether the handset Determine whether your handset
with the HBM-710 supports the Headset or supports the Headset, or
Handsfree Profiles. Handsfree Profiles.
Check whether the battery Charge the battery.
of the HBM-710 is low.
Unable to pair the Check and make sure the Press and hold the PWR/END button
HBM-710 with the Headset is on. for 2 seconds to turn on
Bluetooth®device the Headset.
Check and make sure the With the power off, press and hold
Headset is placed in pairing the PWR/End button for 5 seconds to
mode. place the Headset in pairing mode.
Low sound (Speaker) Check the speaker volume lncrease the volume level.
ITEM Description
Bluetooth specification V1.2 (Handsfree / Headset Profiles)
Battery 3.7V, 80mAh, Li-Polymer
Standby time Up to 150Hrs
Talk time Up to 5Hrs
Charging time < 3Hrs
Operation temperature -10°C 60°C
Dimension/ Weight 16mm(W) X 65mm(L) X 84mm(H) / 11.6g
Specification
-13--12-
Keep unit away from humidity & dust.
Do not place the heavy objects on the unit.
Keep away from direct light or heat.
ᵄChanges or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
ᵄRisk of explosion if the battery is replaced by an
incorrect type.
ᵄDispose of used batteries according to the instructions.
Declaration of confirmation
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
IMPORTANT NOTE : To comply with the FCC RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any change to the antenna or
the device could result in the device exceeding the RF exposure
requirements and void user’s authority to operate the device.
Disposal of your old appliance
1.When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
2.All electrical and electronic products should be disposed of separately
from the municipal waste stream via designated collection facilities
appointed by the government or the local authorities.
3.The correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
4.For more detailed information about disposal of your old appliance,
please contact your city office, waste disposal service or the shop where
you purchased the product.
WEEE
-15-
5. Recycling the battery in your Bluetooth®Headset
The battery in your Bluetooth®Headset must be disposed of properly and should never be
placed in municipal waste. The LG Electronics service partner removing battery will dispose of
it according to local regulations.
6. Conditions
The warranty is valid only if the original receipt issued to the original purchaser by the
dealer, specifying the date of purchase and serial number, is presented with the product to be
repaired or replaced. LG Electronics reserves the right to refuse warranty service if this
information has been removed or changed after the original purchase of the product from the
dealer.
If LG Electronics repairs or replaces the product, the repaired or replaced product shall be
warranted for the remaining time of the original warranty period or for ninety (90) days from
the date of repair, whichever is longer. Repair or replacement may involve the use of
functionally equivalent reconditioned units. Replaced parts or components will become the
property of LG Electronics.
This warranty does not cover any failure of the product due to normal wear and tear, or due
to misuse, including but not limited to use in other than the normal and customary manner, in
accordance with instructions for use and maintenance of the product. Nor does this warranty
cover any failure of the product due to accident, modification or adjustment, acts of God or
damage resulting from liquid.
This warranty does not cover product failures due to improper repair installations,
modifications or service performed by a non-LG Electronics authorized person.
Tampering with any of the seals on the product will void the warranty.
THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE, ARE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE
WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST PROFITS OR COMMERCIAL LOSS,
TO THE FULL EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
-14-
Additional Information
1. Radio frequency exposure
This Bluetooth®Headset, HBM-710, is a radio transmitter and receiver. When in operation, it
communicates with a Bluetooth® equipped mobile device by receiving and transmitting radio
frequency (RF) electromagnetic fields (microwaves) in the frequency range 2.4 to 2.4835
GHz. The output power of the radio transmitter is low, 0.001 watt. Your Bluetooth®Headset
is designed to operate in compliance with the RF exposure guidelines and limits set by national
authorities and international health agencies when used any compatible LG Electronics mobile
phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive atmosphere. It is
rare, but your electronic device could generate sparks. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked.
3.Emergency calls
IMPORTANT!
This Bluetooth®Headset and the electronic device connected to the Headset operate using
radio signals, cellular and landline networks as well as user-programmed functions, which
cannot guarantee connection under all conditions. Therefore you should never rely solely
upon any electronic device for essential communications (e.g. medical emergencies).
Remember, in order to make or receive calls, the Headset and the electronic device connected
to the Headset must be switched on and in a service area with adequate cellular signal
strength. Emergency calls may not be possible on all cellular phone networks or when certain
network services and/or phone features are in use. Check with your local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery or one that
has not been used for a long period of time could have reduced capacity the first few times it
is used. Do not expose the battery to extreme temperatures, never above +60 (+140 F) or
under -20 (-4 F). For maximum battery capacity, use the battery in room temperature. If the
battery is used in low temperatures, the battery capacity will be reduced. The battery can only
be charged in temperatures between +10 (+50 F) and +45 (+113 F ).
-16-
Some countries/states do not allow the exclusion or limitation ofincidental or consequential
damages, or limitation of the duration of implied warranties, so the preceding limitations or
exclusions may not apply to you. The warranty provided does not affect the consumer's
statutory rights under applicable national legislation in force, nor the consumer's rights
against the dealer arising from their sales/purchase contract.
Limited Warranty
Subject to the conditions of this Limited Warranty, LG Electronics warrants this product to be
free from defects in design, material and workmanship at the time of its original purchase by a
consumer, and for a subsequent period of one (1) year. Should your product need warranty
service, please return it to the dealer from whom it was purchased or contact your local LG
Electronics contact center to get further information.
