LG Electronics USA HBM750 Bluetooth Headset User Manual HBM 750
LG Electronics USA Bluetooth Headset HBM 750
users manual
English
Español
All rights reserved.
LG Electronics Inc., 2007
Note : For the best performance and
to prevent any damage to, or misuse of the
HBM - 750, please read all of the information
carefully prior to using the HBM - 750.
Any modifications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
LG Electronics
BLUETOOTH®Mono Headset
HBM-750 User manual
3
Introduction
The LG Bluetooth®Headset HBM-750 is a light weight wireless
Headset utilizing Bluetooth®technology. This product can be used
as an audio accessory for devices supporting either the Headset
or Handsfree Bluetooth®Profiles.
Bluetooth®Headset User manual
Charger Warranty Card
Included in package
2
Table of Contents
Introduction 3
Part Description 4
How to use 5
- Change direction 5
- Attaching Lanyard 5
- Charging 5
- Low battery 5
- Power on 5
- Power off 6
- Pairing 6
- Auto Reconnect 7
- Volume control 7
- Calling 8
�Answering a call 8
�Making a call 8
�Voice dialing 8
�Last number redial 8
�Ending a call 8
�Transferring a call 8
�Call waiting 8
�Call Reject 8
�Mute or Unmute the microphone 8
Summary of button functions 9
LED indication 9
Troubleshooting 10
Specification 10
Precautions 11
Declaration of confirmation 13
Additional information 13
Limited warranty 16
Important safety information
16
Front
Back
4 5
How to use
Volume UP / Down Button
LED indicator
Call / End Button
Speaker
MIC
On the left Rotation On the right
Change direction
Charging Port
Part Description
Earloop
Power Button
Charging
Low battery
Power on
- Remove the cover on the charging port and connect the charger.
- When the charger is connected, with power on or off, the Headset
will turn off. While charging, the LED indicator will show a solid blue light
.
- The buttons will not function while the device is charging.
- It takes 2 hours to fully charge the Headset.
- When charging is complete, the LED indicator will turn off.
- A low battery tone will play once every 30 seconds.
- When the battery is not charged, the Headset will turn off.
- Press and Hold the PWR button for 1 second.
�The power will turn on and a booting tone will play.
7
Auto Reconnect
How to use
6
Pairing
Power off
How to use
- Press and hold the PWR button for 2 seconds.
�A shutdown tone will play, the Bluetooth link will disconnect,
and the power will turn off.
- Prior to using the Headset for the first time, you must pair it with a
Bluetooth-enabled handset.
- There are 2 Pairing Mode Methods with the HBM-750.
1) Easy Pairing
�With the Power off, press and hold the PWR button for 1 second, to
turn on the HBM-750.
�The Headset will enter Auto-Reconnect mode, for 10 seconds
(If your handset has been previously paired to the handset, the
handset will automatically reconnect to the handset, when the
HBM-750 is powered on.)
�After 10 seconds, the HBM-750 will automatically enter Paring Mode.
�When the headset enters Pairing Mode, the LED indicator will show
a solid blue light
�Using your handset, find the Bluetooth Menu and “search for” or
“add” new devices.
�
Select “LG HBM-750” from the list of devices and pair it with your handset.
�When asked for the Pass/PIN code during the pairing procedure,
please enter “0000” (4 Zeros).
�Once pairing has completed successfully, you will hear a beep.
�
After pairing successfully, be sure to “Connect” to the LG HBM-750.
�If you want to pair with other devices in the future, the Headset
must be placed in Pairing Mode.
�If the headset is in Pairing mode for three minutes without being
connected to a handset, the HBM-750 will automatically turn off.
2) Manual Pairing
�
After Power on, press and hold the CALL/END button for 5 seconds.
�When the Headset enters Pairing Mode, the LED indicator will
show a solid Blue light.
�Using your handset, find the Bluetooth Menu and “search for” or
“add” new devices.
Volume control
�Select “LG HBM-750” from the list of devices and pair it with your
handset.
�When asked for the Pass/Pin code during the pairing procedure,
please enter “0000” (4 Zeros)
�Once pairing has completed successfully, you will hear a beep.
�
After pairing successfully, be sure to “Connect” to the LG HBM-750.
�If you want to pair with other devices in the future, the Headset
must be placed in Pairing Mode.
�If the headset is in Pairing mode for three minutes without being
connected to a handset, the HBM-750 will automatically turn off.
- When the HBM-750 turns off accidentally or intentionally during
connected condition, the headset and handset will disconnect.
The Headset and handset will automatically reconnect without
pairing when the HBM-750 turns on.
[ Out of range ]
- When the HBM-750 and your handset are separated by a distance
of 33 feet (10 meters) or more, the Headset and handset will
disconnect. When the handset and HBM-750 are brought back
within the required distance, the
HBM-750
will automatically
reconnect with the handset.
- If the Headset and handset do not automatically reconnect when
they are back within the required range, briefly press the
CALL/END button to reconnect manually.
-
Press the VOLUME UP or VOLUME DOWN button to adjust the
speaker volume.
- There are eight levels of speaker volume.
9
8
How to use
LED indication
Summary of button functions
Function HBM-750
Status Action
Function HBM-750
Status Action
Power on Power off Press the PWR button for 1 second.
Power off Power on Press the PWR button for at least
2 seconds.
Volume up - Briefly press the Volume Up button.
Volume down - Briefly press the Volume Down button.
Transferring a call Talking - Handset to Headset
Briefly press the PWR button
- Headset to Handset
Press and hold the VOLUME UP button
for 5 seconds.
Answering a call Ringing Briefly press the PWR button.
Ending a call Talking Briefly press the PWR button.
Call waiting Talking Press the PWR button for 1 second.
Last number redialing
Idle Press the PWR button for 1 second.
Voice dialing Start & stop Briefly press the PWR button.
(handset must support)
voice command
Pairing mode Power off
Press the CALL/END button for 5 seconds.
Call reject Ringing Press the PWR button for 1 second.
Operating Power on The blue LED light flickers 4 times.
Power off The blue LED light flickers 4 times
and then turns off.
Pairing mode The blue LED light is lit.
Headset / handsfree The blue LED light flickers
Profile connected 2 times every 5 seconds.
Call connected The blue LED light flickers
2 times every 5 seconds.
Charging Charging The blue LED is lit.
Charging complete LED is turned off.
Calling
Answering a call
-
When there is an incoming call, the Headset will ring.
-
Briefly press the CALL/END button to answer an incoming call.
Making a call
-
If you make a call from the handset, the call will (subject to phone settings)
automatically transfer to the Headset. If the call is not automatically
transferred, you can manually transfer the call by briefly pressing the
CALL/END button on the HBM-750 (handset and headset must be paired).
Voice dialing
*
-
Briefly press the CALL/END button to activate “Voice Command”.
You will get the best results if you record the voice dialing tag
through your Headset.
Last number redial
*
-
Press and hold the CALL/END button for 1second to activate “Last
Number Redial”. The headset will beep, and call the last number dialed.
Ending a call
-
Briefly press the CALL/END button.
Transferring a call
*
-
While on a call on your handset, briefly press the CALL/END button
to transfer the audio to the Headset.(headset and handset must be paired).
-
And to transfer a call from the Headset to Handset, press and hold
VOLUME UP button for 5seconds.
Call waiting
*
-
Answer a second call without hanging up the first call by pressing the
CALL/END button for 1second. Press the CALL/END button for
1second to return to the original call.
-
Briefly press the CALL/END button to terminate both calls at once.
Call Reject
*
-
Activate Call Reject by pressing the CALL/END button for 1second
when the handset rings.
*
It is possible to use these functions only when your handset
supports them. For further information about using these features,
please consult your handset's user manua
l.
Mute or Unmute the microphone
-
During a call, press and hold the Volume Down button for 5 seconds.
To unmute the microphone during mute, press and hold the Volume
Down button for 5 seconds.
Troubleshooting
Specification
Precautions
1110
Do not drop the unit from high places.
Do not modify, repair, or take apart.
Do not expose directly to water,
alcohol, benzene, etc. for cleaning.
Do not expose directly to flammables.
Do not place or keep the unit near
flammables.
ITEM Description
Bluetooth®specification V2.0+EDR (Handsfree / Headset profiles)
Battery 3.7V, Li- Polymer
Stand by time Up to 150Hrs
Talk Time Up to 4Hrs
Charging time < 2Hrs
Operation temperature -10℃~60℃
Dimension / weight
20.2mm(W) X 42.2mm(L) X 10.2mm(H) / 9.4g
(without necklace)
Does not turn on Check whether the battery Charge the battery.
of the HBM-750 is fully
charged.
Unable to
Check whether the handset Determine whether your handset
communicate with supports the Headset or supports the Headset or
the LG Bluetooth
®
Handsfree profiles. Handsfree profiles.
Headset HBM-750 Check whether the battery Charge the battery.
of the HBM-750 is low.
Unable to pair the
Check and make sure the Press and hold the PWR button
HBM-750 with the
Headset is on.
for at least 1 second to turn
Bluetooth®device on the Headset.
Check and make sure After the power on, press and
the
Headset is placed
hold the CALL/END button for
in pairing
mode.
5 seconds to place the headset
in pairing mode.
Low sound
(speaker)
Check the speaker volume.
lncrease the volume level.
Declaration of Confirmation
1312
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any change to the antenna or the
device could result in the device exceeding the RF exposure requirements
and void user's authority to operate the device.
Additional Information
1. Radio frequency exposure
This Bluetooth®Headset, HBM - 750, is a radio transmitter and
receiver. When in operation, it communicates with a Bluetooth®
equipped mobile device by receiving and transmitting radio
frequency (RF) electromagnetic fields (microwaves) in the
frequency range 2.4 to 2.4835 GHz. The output power of the radio
transmitter is low, 0.001 watt. Your Bluetooth®Headset is designed
to operate in compliance with the RF exposure guidelines and limits
set by national authorities and international health agencies when
used any compatible LG Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially
explosive atmosphere. It is rare, but your electronic device could
generate sparks. Sparks in such areas could cause an explosion or
fire resulting in bodily injury or even death. Areas with a potentially
explosive atmosphere are often, but not always, clearly marked.
Keep unit away from humidity & dust.
Do not place the heavy objects on the unit.
Precautions
Please use it only with a LG original
charger (Travel Adaptor, Cigar Light
Adaptor). Otherwise it might be damaged.
�Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
�There is a risk of explosion if the battery is replaced by
on incorrect type.
�Dispose of used batteries according to the instructions.
�The earloop is made of a durable plastic that does not
break but bend. However, repetition of bending is
not recommended.
1514
3.Emergency calls
IMPORTANT!
This Bluetooth®Headset and the electronic device connected to the
Headset operate using radio signals, cellular and landline networks
as well as user- programmed functions, which cannot guarantee
connection under all conditions.
Therefore you should never rely solely upon any electronic device
for essential communications (e.g. medical emergencies).
Remember, in order to make or receive calls, the Headset and the
electronic device connected to the Headset must be switched on and
in a service area with adequate cellular signal strength. Emergency
calls may not be possible on all cellular phone networks or when
certain network services and/or phone features are in use. Check
with your local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly.
A new battery or one that has not been used for a long period of time
could have reduced capacity the first few times it is used.
Do not expose the battery to extreme temperatures, never above
+ 60。(+140。F) or under -20。(-4。F). For maximum battery capacity,
use the battery in room temperature. If the battery is used in low
temperatures, the battery capacity will be reduced. The battery can
only be charged in temperatures between
+ 10。(+50。F) and + 45。(+ 113。F).
5. Recycling the battery in your Bluetooth®Headset
The battery in your Bluetooth®Headset must be disposed of properly
and should never be placed in municipal waste. The LG Electronics
service partner removing battery will dispose of it according to local
regulations.
6. Safety of the lanyard
The lanyard of the Headset can be dangerous when the lanyard is
worn and hooked by some objects. To prevent any potential of
danger, the lanyard is designed to break when a mass of more than
5Kg is applied.
7. Conditions
- The warranty is valid only if the original receipt issued to the original
purchaser by the dealer, specifying the date of purchase and serial
number, is presented with the product to be repaired or replaced.
LG Electronics reserves the right to refuse warranty service if this
information has been removed or changed after the original
purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or
replaced product shall be warranted for the remaining time of the
original warranty period or for ninety (90) days from the date of
repair, whichever is longer. Repair or replacement may involve the
use of functionally equivalent reconditioned units. Replaced parts or
components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to
normal wear and tear, or due to misuse, including but not limited to
use in other than the normal and customary manner, in accordance
with instructions for use and maintenance of the product. Nor does
this warranty cover any failure of the product due to accident,
modification or adjustment, acts of God or damage resulting from
liquid.
- This warranty does not cover product failures due to improper
repair installations, modifications or service performed by a non- LG
Electronics authorized person. Tampering with any of the seals on
the product will void the warranty.
-THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT
LIMITED TO LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL
EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.
Additional Information Additional Information
16
�Some countries/states do not allow the exclusion or limitation of
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you. The warranty provided does not affect the consumer's
statutory rights under applicable national legislation in force, nor the
consumer's rights against the dealer arising from their sales/purchase
contract.
Limited Warranty
IMPORTANT SAFETY INFORMATION
Subject to the conditions of this Limited Warranty, LG Electronics warrants
this product to be free from defects in design, material and workmanship
at the time of its original purchase by a consumer, and for a subsequent
period of one (1) year. Should your product need warranty service, please
return it to the dealer from whom it was purchased or contact your local
LG Electronics contact center to get further information.
Additional Information
Avoiding hearing damage Permanent hearing loss may occur if you use
your headset at a high volume. Set the volume to a safe level. You can
adapt over time to a higher volume of sound that may sound normal but
can be damaging to your hearing. If you experience ringing in your ears or
muffled speech, stop listening and have your hearing checked. The louder
the volume, the less time is required before your hearing could be
affected. Hearing experts suggest that to protect your hearing:
�Limit the amount of time you use headset at high volume.
�Avoid turning up the volume to block out noisy surroundings.
�Turn the volume down if you can't hear people speaking near you.
For information about how to set a maximum volume limit on your
handset, please refer to the features guide for your handset.
Using headsets safely Use of headsets to listen to music while operating CE
a vehicle is not recommended and is illegal in some areas. Be careful and Hereby,LG Electronics, declares this Bluetooth Headset(HBM-750) is in
attentive while driving. Stop using this device if you find it disruptive or compliance with the essential requirements and other relevant provisions
distracting while operating any type of vehicle or performing any other of Directive 1999/5/EC.
activity that requires your full attention.
