LG Electronics USA HBS500 Bluetooth Stereo Headset User Manual
LG Electronics USA Bluetooth Stereo Headset
User manual
English
Español
Rev 1.0 US
All rights reserved.
LG Electronics Inc., 2015
Note: Please read all information carefully prior to
using the HBS-500 in order to prevent damages to
the product and to enjoy the best performance.
WARNING :
This product contains chemicals known to the State
of California to cause cancer and birth defects or
reproductive harm.
Wash hands after handling.
HBS-500 User Manual
BLUETOOTH® Stereo Headset
2
ENG
Introduction 3
- Included in the Package 3
Description of Parts 4
How to Use 5
- Power On / Power Off 5
- Charging 5
- Low Battery 5
- Battery Status Alert 5
- Pairing 5
- Multi-connection 6
- Auto Reconnect 7
- Calling 7
• Answering a Call 7
• Transferring a Call 7
• Voice Dialing 8
• Last number Redial 8
• Ending a Call 8
• Call Waiting 8
• Rejecting a Call 8
• Mic Mute 8
- Volume Control 8
- Vibrate Control 8
- Audio Streaming 9
- Equalizer 9
- Tone & Talk
TM
9
Summary of HBS-500 Functions 10
LED (or Vibrate) Indicator 11
Troubleshooting 11
Specifications 12
Precautions 12
Declaration of Confirmation 13
Additional Information 13
Limited Warranty 16
Important Safety Information 16
Table of Contents
3
ENG
The LG TONE+ (HBS-500) is a lightweight wireless headset that uses Bluetooth
technology.
This product can be used as an audio accessory for devices supporting either the
A2DP or Hands-Free Bluetooth Prole.
Included in the Package
Ear Gels (2 Sets) *USB Charging Cable
User Manual Warranty Card
* Actual product design may differ from images shown in manual.
HBS-500
Introduction
4
Description of Parts
ENG
Headset
Memory Flex Neck Strap
LED Indicator
VOLUME UP Button
(FF, Next Song)
VOLUME DOWN Button
(REW, Previous Song)
Earbud (R)
Charging Port
MFB (Multi-Function Button) :
Power/Call/Play Button
Microphone
Earbud (L)
5
ENG
Charging
- When the charger is connected (with the power on or off) the headset will turn off.
-
While charging, the LED indicator will show a solid red light and then
change to violet when charged 80% and above.
- When charging is completed, the LED indicator will show a solid blue light.
Low Battery
- A low battery alert will play once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Power On / Power Off
- Power On : Press and hold the MFB for 2 seconds.
- Power Off : Press and hold the MFB for 3 seconds.
Pairing
- Before using, HBS-500 must be paired/connected with a Bluetooth-enabled device.
1) Easy Pairing
a) Press and hold the MFB for 2 seconds to turn on the HBS-500.
b) If it is your rst time pairing the device it will automatically enter pairing mode. If
it has been paired but no paired device is in range it will enter pairing mode.
• The LED indicator will be solid blue.
Battery Status Alert
- By pressing and holding the VOLUME DOWN button for 1 second, you can check
the battery status of the HBS-500.
Battery Status High Medium Low
Voice Prompt Battery High Battery Medium Battery Low
LED Indicator Blinking
Blue
Blinking
Violet
Blinking
Red
How to Use
6
ENG
c) On the device you wish to pair, nd the Bluetooth menu and search for or add
new devices.
d) Select LG HBS500 from the list of devices.
e) If asked for a Pass/Pin Code enter 0000 (4 Zeros).
f) Once the devices are paired, you will hear “Your headset paired.”
• The HBS-500 will automatically turn off if not paired within 3 minutes.
2) Manual Pairing (pairing with another phone or re-pairing)
a) With the power off, press the VOLUME DOWN button and press and hold the
MFB for 2 seconds to enter Manual Pairing mode.
b) When the headset enters Pairing Mode, the LED indicator will show a solid
blue light. After the procedure repeat Easy Pairing steps c through f.
How to Use
Multi-connection
Advanced Multipoint
The HBS-500 is capable of having two devices connected to the headset at the
same time. This will give you the freedom of using call waiting between calls on
both of your connected phones.
Connection
- Pair the headset with one of your Bluetooth-enabled handsets (see the pairing
instructions on pages 5 and 6).
- Turn off the headset.
- Power up as manual pairing mode. (With the power off, press the VOLUME
DOWN button and press and hold the MFB for 2 seconds.)
- Pair and connect the headset with your other Bluetooth-enabled handset. This
will be your primary headset.
- Once the handset is paired and connected, connect the originally paired handset
to the headset. This will now be your secondary handset.
* NOTE: When the HBS-500 is connected to two handsets at the same time
(Multipoint), the headset calling functions will work with the primary handset.
* NOTE: In case of failure to connect to the primary phone through Easy Pairing,
HBS-500 will enter Pairing Mode.
7
ENG
Auto Reconnect
- The headset and handset will automatically reconnect when the HBS-500 is turned
back on while in range.
- The secondary handset will need to be connected manually. Select LG HBS500 from
the list of devices in the Bluetooth menu and pair.
Out of Range
- If the paired devices are separated by a range of 33 feet (10 meters) or more, the
headset and handset will disconnect and the HBS-500 will vibrate to alert you*.
* HBS-500 will not vibrate if vibration function is on ‘off’.
- If the headset and handset do not automatically reconnect when they are back within the
required range, briey press the MFB on the HBS-500 to reconnect manually.
- While in multi-connection and streaming, the inactive paired device will be disconnected
when out of range. The HBS-500 will alert you once with no attempt to reconnect.
Calling Function
- Voice Dialing and Last Number Redial features work with the primary handset (or
handset which made the last outgoing call).
Call Waiting
- While on a call, press the MFB for 1 second to switch to an incoming call.
- To switch between 2 active calls, press the MFB for 1 second.
- To end both calls briey press the MFB.
- If both handsets are receiving an incoming call, the headset will default to the primary device.
Calling
Answering a Call
- When there is an incoming call, the headset will ring and vibrate.
- Briey press the VOLUME DOWN button to stop vibration*.
* The HBS-500 will not vibrate if the vibration function has been turned off.
- Briey press the MFB to answer the incoming call.
Transferring a Call
- You can manually transfer the call to or from the headset by pressing and holding
the VOLUME UP button for 2 seconds on the HBS-500 (handset and headset must
be paired).
How to Use
8
ENG
How to Use
Volume Control
- Press the VOLUME button to adjust the speaker volume.
- To prevent hearing loss, which is caused by listening to music for long periods of
time, the HBS-500 will emit a long beep tone or two beeps when you use the upper
6 volume levels.
Vibrate Control
- To activate or deactivate device vibration, press and hold the VOLUME UP button for 2
seconds. You will hear “Vibrate on” or “Vibrate off” when it is activated or deactivated.
- When vibration is turned off, the headset will not vibrate when receiving an
incoming call or when it is out of range.
- Vibration will automatically be activated when the device is powered on.
Voice Dialing
- Briey press the MFB to activate Voice Command. For best results, record the voice
dialing tag through your headset.
NOTE: If your handset does not support voice dialing, this action may activate Last
Number Redial.
Last Number Redial
- Press and hold the MFB for 1 second to activate Last Number Redial.
The headset will beep and then call the last number dialed.
Ending a Call
- Briey press the MFB.
Call Waiting
- Answer a second call without hanging up the rst call by pressing the MFB for 1
second. Press the MFB for 1 second to return to the original call.
- Briey press the MFB to terminate both calls at once.
Rejecting a Call
- Activate call reject by pressing the MFB for 1 second when the handset rings.
* These functions may only be used if your handset supports them. For further
information about using these features, please consult your handset’s user manual.
Mic Mute
- Press and hold the VOLUME UP and VOLUME DOWN buttons at the same time for
1 second to mute/unmute the Mic during conversation.
9
ENG
Tone & TalkTM
Equalizer
- While playing music, press and hold the VOLUME UP and VOLUME DOWN
buttons at the same time for 1 second to switch between Bass Boost (default),
Normal, and Treble Boost.
- The size of the ear gel can affect the amount of bass you hear.
Audio Streaming
Play
- Double press MFB.
Pause
- While playing music, double press MFB.
Next song
- Double press VOLUME UP button.
Previous song
- Double press VOLUME DOWN button.
Fast Forward
- Press and hold VOLUME UP button.
Rewind
- Press and hold VOLUME DOWN button.
How to Use
The HBS-500 Bluetooth headset supports SMS reading on
AndroidTM based devices.
To download the application, search for Tone & Talk in Google
PlayTM * or scan the QR code. Follow the installation instructions.
* Google Play is a trademark of Google, Inc.
10
ENG
Function
HBS-500 Status
Action
Power on Power off Press and hold the MFB for 2 seconds.
Power off Power on Press and hold the MFB for 3 seconds.
Volume up Briey press the VOLUME UP button.
Volume down Briey press the VOLUME DOWN button.
Transferring a call Talking Press and hold VOLUME UP button for 2
seconds.
Answering a call Ringing Briey press the MFB.
Stop incoming call
vibration alerting Ringing Briey press the VOLUME DOWN button.
Vibration on/off Power on Press and hold VOLUME UP button for 2
seconds.
Ending a call Talking Briey press the MFB.
Call waiting Talking Press the MFB for 1 second.
Last number redial Idle Press the MFB for 1 second.
Voice dialing
(handset must
support)
Idle Briey press the MFB.
Call reject Ringing Press the MFB for 1 second.
Mic mute on/off Talking Press and hold the VOLUME UP and VOLUME
DOWN buttons at the same time for 1 second.
Pairing mode
(Manual) Power off
Press the VOLUME DOWN button and press and
hold the MFB for 2 seconds.
Battery status check
Power on Press the VOLUME DOWN button for 1 second.
Play Power on Double press MFB.
Pause Music on Double press MFB.
Next song Music on Double press VOLUME UP button.
Previous song Music on Double press VOLUME DOWN button.
Fast forward Music on Press and hold VOLUME UP button.
Rewind Music on Press and hold VOLUME DOWN button.
Equalizer settings Music on Press and hold the VOLUME UP and VOLUME
DOWN buttons at the same time for 1 second.
Summary of HBS-500 Functions
Power on
Power on
11
ENG
LED (or Vibrate) Indicator
Troubleshooting
Function HBS-500 Status Indicator
Operating
Pairing mode Solid blue LED light.
Headset / hands-free
prole connected
Call connected
The blue LED light ickers 1 time.
Charging Charging Solid red LED light, which changes to violet when
charged 80% and above.
Charging complete
Solid blue LED light.
Issue Possible problem Resolution
Does not turn on Check whether the battery of
the HBS-500 is fully charged. Charge the battery.
Unable to
communicate with
the LG Bluetooth
Headset HBS-500
Check whether the handset
supports the headset or
hands-free Bluetooth proles.
Determine whether your handset
supports the headset or hands-
free Bluetooth proles.
Check whether the battery of
the HBS-500 is low.
Charge the battery.
Unable to pair the
HBS-500 with the
Bluetooth device
Check and make sure the
headset is on.
Press and hold the MFB for 2
seconds to turn on the headset.
Check and make sure the
headset is placed in Pairing
Mode.
Press the VOLUME DOWN
button and press and hold the
MFB for 2 seconds.
Low sound (speaker) Check the speaker volume. lncrease the volume level.
12
ENG
Item Description
Bluetooth specication
4.1 (Headset / Hands-Free / A2DP / AVRCP Proles)
Battery
Battery 3.7 V / 125 mAh Li-Polymer
Talk Time Up to 9 hours
Music play time Up to 7.5 hours
Standby time Up to 500 hours
Charging time Less than 2 hours
Rated Input Power DC4.75V~5.6V, 400mA
Operation temperature 14°F ~ 140°F (-10°C ~ 60°C)
Dimensions / weight 140 mm (W) X 168 mm (L) X 18.1 mm (T) / 29 g
Do not drop the device.
Do not modify, repair, or disassemble.
Do not expose directly to water, alcohol, benzene, etc., for cleaning.
Do not expose directly to ammables.
Do not place or keep the device near ammables.
Keep the device away from excessive humidity and dust.
Do not place heavy objects on the device.
Only charge the headset with an original LG charger, otherwise it may be damaged.
• Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• There is a risk of explosion if the battery is replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
• The neck strap is made of a shape memory alloy. However, bending the neck
strap repeatedly is not recommended.
• This product contains small parts, including earphones, ear buds, and cables.
Keep out of reach of children.
• If you have an implanted medical device, consult with a doctor prior to using
this product.
Specications
Precautions
13
ENG
Declaration of Conrmation
Precautions
FCC NOTICE TO USERS:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no change to
the antenna or the device is permitted. Any change to the antenna or the device
could result in the device exceeding the RF exposure requirements and void
user’s authority to operate the device.
1. Radio frequency exposure
This Bluetooth® Stereo Headset HBS-500 is a radio transmitter and receiver. When
in operation it communicates with a Bluetooth equipped mobile device by receiving
and transmitting radio frequency (RF) electromagnetic elds (microwaves) in the
frequency range 2.4 to 2.4835 GHz. Your Bluetooth headset is designed to operate
in compliance with the RF exposure guidelines and limits set by national authorities
and international health agencies when used with any compatible LG Electronics
mobile phone.
FCC ID: BEJHBS500
14
ENG
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive
atmosphere. Although this is uncommon, your electronic device could generate
sparks. Sparks in such areas could cause an explosion or re resulting in bodily
injury or even death. Areas with a potentially explosive atmosphere are often, but
not always, clearly marked.
3. Emergency calls
IMPORTANT!
This Bluetooth® headset and the electronic device connected to the headset
operate using radio signals, mobile and landline networks as well as
user-programmed functions which cannot guarantee connection under all
conditions. Therefore you should never rely solely upon any electronic device
for essential communications (e.g. medical emergencies). Remember, in order
to make or receive calls, the headset and the electronic device connected to the
headset must be switched on and in a service area with adequate mobile signal
strength. Emergency calls may not be possible on all mobile phone networks or
when certain network services and/or phone features are in use. Check with your
local service provider.
4. Battery information
A rechargeable battery has a long service life if treated properly. A new battery
or one that has not been used for a long period of time could have reduced
capacity the rst few times it is used. Do not expose the battery to extreme
temperatures, never above +60°C (+140°F) or below -10°C (14°F). For maximum
battery capacity, use the battery at room temperature. If the battery is used in
low temperatures, the battery capacity will be reduced. The battery can only be
charged in temperatures between +10°C (+50°F) and +45°C (+113°F). For your
safety, do not remove the battery incorporated with the product. If you need to
replace the battery, take it to the nearest authorized LG Electronics service point
or dealer for assistance.
5. Recycling the battery in your Bluetooth headset
The battery in your Bluetooth headset must be disposed of properly and should
never be placed in municipal waste. The LG Electronics service partner who
removes the battery will dispose of it according to local regulations.
Additional Information
15
ENG
Additional Information
6. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser
by the dealer, specifying the date of purchase and serial number, is presented
with the product to be repaired or replaced. LG Electronics reserves the right to
refuse warranty service if this information has been removed or changed after
the original purchase of the product from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty period
or for ninety (90) days from the date of repair, whichever is longer. Repair or
replacement may involve the use of functionally equivalent reconditioned units.
Replaced parts or components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear
and tear, or due to misuse, including but not limited to use in other than the
normal and customary manner, in accordance with instructions for use and
maintenance of the product. Nor does this warranty cover any failure of the
product due to accident, modication or adjustment, acts of God or damage
resulting from liquid.
- This warranty does not cover product failures due to improper repair
installations, modications or service performed by a non- LG Electronics
authorized person. Tampering with any of the seals on the product will void
the warranty.
- THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN OR
ORAL, OTHER THAN THIS PRINTED INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL LG ELECTRONICS OR ITS
VENDORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO
LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL EXTENT THOSE
DAMAGES CAN BE DISCLAIMED BY LAW.
• Some countries/states do not allow the exclusion or limitation of incidental or
consequential damages, or limitation of the duration of implied warranties, so
the preceding limitations or exclusions may not apply to you. The warranty
provided does not affect the consumer’s statutory rights under applicable
national legislation in force, nor the consumer’s rights against the dealer arising
from their sales/purchase contract.
16
Subject to the conditions of this Limited Warranty, LG Electronics warrants this
product to be free from defects in design, material and workmanship at the time
of its original purchase by a consumer, and for a subsequent period of one (1)
year. Should your product need warranty service, please return it to the dealer
from whom it was purchased or contact your local LG Electronics contact center
to get further information.
Avoiding hearing damage
Permanent hearing loss may occur if you use your headset at a high volume.
Set the volume to a safe level. Over time you can become accustomed to a
higher volume that may sound normal but can be damaging to your hearing.
If you experience ringing in your ears or mufed speech, stop listening and have
your hearing checked. The louder the volume, the less time is required before
your hearing could be affected.
Hearing experts suggest that to protect your hearing:
• Limit the amount of time you use the headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Using headsets safely
Use of headsets to listen to music while operating a vehicle is not recommended
and is illegal in some areas. Be careful and attentive while driving. Stop using
this device if you nd it disruptive or distracting while operating any type of
vehicle or performing any other activity that requires your full attention.
Limited Warranty
Important Safety Information
ENG
www.lg.com
Any modications or changes to this manual due to typographical errors or inaccuracies of stated
information shall only be made by LG Electronics Inc
